INGERSOLL-RAND IR TOOL S12880
INGERSOLL-RAND IR TOOL S12880 branded products
TRIGGER ASSEM/MAC TOOLS AND CORNWELL ONLY
IR 2135-D93G
IR 2135-D93G
TRIGGER ASSEM/MAC TOOLS AND CORNWELL ONLY
$6.00
1/2" IMPACT WRENCH
IR 2135PTIMAX-A
IR 2135PTIMAX-A
1/2" Air Impact Wrench, 1100 ft-lb Torque, Titanium Hammercase, Pin Retainer, Pistol
Powerful, durable and reliable, the 2135PTiMAX Series Impact Wrench will excel in any market.Features And Benefits
- Power: This wrench's high torque output and power regulator allow easy control over your tool.
- Durability: With a composite housing and a hammer case made of titanium, this wrench can endure repeated drops and harsh environments.
- Reliability: With twin hammer mechanism and powerful motor, the 2135PTiMAX is built not only for performance, but to last. Comes with a 1-year warranty.
Product Application and Uses: Designed to remove and install threaded fasteners for vehicle repair, general industrial, facility maintenance applications.
Actuation/Throttle Type/Switch Type: Trigger
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Anvil Length: Standard
Average Air Consumption (cfm): 5
Average Air Consumption (l/min): 142
Blows per Min: 1250
Color: Grey
Configuration/Handle Type: Pistol Grip
Drive Size (in): 1/2
Drive Type: Square
Duty Rating: Maintenance Duty
End Plates: Aluminum with Hard-coating
Exhaust Location: Bottom
Free Speed Sound Pressure/Power Db(A): 109.2 / 120.2
Hammer Case: Titanium
Handle Material: Composite
Housing Material: Impact and chemical-resistant composite housing and patented steel reinforced frame
Impact Mechanism: Twin Hammer
Impacting Sound Pressure/Power Db(A): 99.8 / 110.8
Max Bolt Diameter (in): 9/16
Max Free Speed (rpm): 9800
Max Pressure (bar): 6.2
Max Torque (ft-lb): 780
Max Torque (in-lb): 9364
Max Torque (nm): 1058
Min Hose Size (in): 3/8
Motor: Reverse Bias
Number of Power Settings: 4
Nut-busting/Breakaway Torque (ft-lb): 1100
Nut-busting/Breakaway Torque (in-lb): 13196
Nut-busting/Breakaway Torque (nm): 1491
Power Source: Air Powered
Power to Weight Ratio (Nut-busting Torque/Weight) (ft-lb/lb): 278.48
Product Length (in): 7.35
Product Width (in): 2.7
Product Height (in): 7.2
Product Weight (lb): 3.95
Recommended Forward Torque Range (ft-lb): 600
Recommended Forward Torque Range (in-lb): 7196
Recommended Forward Torque Range (nm): 813
Retainer Type: Pin Detent
Side to Center Distance (in): 1.37
Side to Center Distance (mm): 35
Special Features: Titanium Hammer case
Speed Setting: Variable Speed
Standards/Certifications: CE
Tool Type: Full-size
Vanes: 7
Vibration Level (m/s2): 13.3
Warranty: 1-year
$6,350.00
IMPACTOOL
IR 244A-2
IR 244A-2
1/2" Air Impact Wrench, 2" Ext Anvil, Super Duty, 500 ft-lb Torque, Friction Ring Retainer, Pistol
The 244A Series ½” Impact Wrench comes loaded with a steel hammer case, square socket retaining ring, vane motor and metal housing — making this wrench one of the toughest, most durable impact wrenches on the market.Features And Benefits
- Increased Control: The power regulator on the 244A Series provides you with increased control and stability on even your toughest projects.
- Durability: Tough and durable, the metal housing and steel hammer case on the 244A Series will help it hold up through repeated drops and harsh environments.
- Two-Piece Construction: Easy-to-service two-piece construction.
- Comfort and Control: Contoured handle for comfort and control. Patented one-hand forward/reverse for easy operation.
- Pressure Feed Lubrication: Pressure feed lubrication system automatically greases the impact mechanism.
- Extended Reach: The 2-inch extended anvil provides you with increased reach that’s invaluable when working with deeper fasteners.
Product Application and Uses: General Industrial, Facility Maintenance
Actuation/Throttle Type/Switch Type: Trigger
Air Consumption @ Load (cfm): 21
Air Consumption @ Load (l/min): 595
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Anvil Length: 2" Extended
Average Air Consumption (cfm): 5.4
Average Air Consumption (l/min): 153
Blows per Min: 1300
Color: Silver
Configuration/Handle Type: Pistol Grip
Drive Size (in): 1/2
Drive Type: Square
Duty Rating: Super Duty
End Plates: Steel
Exhaust Location: Bottom
Free Speed Sound Pressure/Power Db(A): 93.0 / 104.0
Hammer Case: Steel
Handle Material: Aluminum
Housing Material: Aluminum
Impact Mechanism: Twin Hammer
Max Bolt Diameter (in): 9/16
Max Free Speed (rpm): 7000
Max Pressure (bar): 6.2
Max Torque (ft-lb): 500
Max Torque (in-lb): 6001
Max Torque (nm): 678
Min Hose Size (in): 3/8
Motor: Reverse Bias
Number of Power Settings: 6
Power Source: Air Powered
Product Length (in): 9.5
Product Width (in): 2.95
Product Height (in): 7.85
Product Weight (lb): 6.3
Recommended Forward Torque Range (ft-lb): 40-350
Recommended Forward Torque Range (in-lb): 478-4204
Recommended Forward Torque Range (nm): 54-475
Recommended Reverse Torque (ft-lb): 40-350
Recommended Reverse Torque (nm): 54-475
Retainer Type: Friction Ring
Side to Center Distance (in): 1.5
Side to Center Distance (mm): 38
Standards/Certifications: Iso 11148-6, Cagi B186, Iso 28927-2, Iso 15744
Tool Type: Full-size
Vanes: 6
Vibration Level (m/s2): 8.6
Warranty: 1-year
Similar IR
- 244A
- 2135QXPA-2
- 2235TIMAX-2
$615.00
Wheel (Altered) Reference: 3107948.2D07
IR 24509549
IR 24509549
Wheel (Altered) Reference: 3107948.2D07
$500.00
RUBBER BUTT FITS 5/8" TPD ROD, QTY 1
IR 24SR-83R-5
IR 24SR-83R-5
RUBBER BUTT FITS 5/8" TPD ROD, QTY 1
$219.00
RUBBER TIPPED BUTT FITS 5/8" TPD ROD, QTY 1
IR 24SR-93R
IR 24SR-93R
RUBBER TIPPED BUTT FITS 5/8" TPD ROD, QTY 1
$123.00
NAMEPLATE/WARNING LABEL, 259 IMPACT
IR 259-301
IR 259-301
NAMEPLATE/WARNING LABEL, 259 IMPACT
$15.00
Kit, Overload Seal. K5C2-E/K52C-Y
IR 27995
IR 27995
Kit, Overload Seal. K5C2-E/K52C-Y
Call for pricing
