INGERSOLL-RAND IR TOOL S12880

IR 170-36

Drive Bushing for Ingersoll Rand 170G, 1770G,R3000, 1207MAX, 107, 109 Series Air Ratchet

IR 170-TK

Throttle Valve Kit for Ingersoll Rand 170G, 1770G, 107 Series Air Ratchet

IR 1710B-329

IR 1720P-23

Exhaust Deflector for Ingersoll Rand 271, 261, 1720P Impact Wrench

• For Use With: 1720P1
• For Use With: 1720P3
• For Use With: 261
• For Use With: 261-3
• For Use With: 261-6
• For Use With: 271

IR 1720P-TK2

IR 170-97

IR 170-42-4

Vane Pack Set of 4 for Ingersoll Rand 1207MAX, 107 Series Air Ratchet

IR 170PG

Air Needle Scaler, 3000 BPM, 1.4" Stroke

Description: This pistol grip needle scaler is designed with both power and ergonomics in mind. With a rubber over mold grip for maximum comfort, you can use this tool for hours with minimal fatigue.

Features And Benefits:

• Comfort: Ergonomic handle and low vibration provides operator comfort.
• Power: 3,000 blows per minute maximize material removal.

Product Application and Uses:

Designed for removing weld splatter or other unwanted surface deposits from metal

• Includes: Tool, (19) flat tip 7" (3mm) carbon steel needles
• Actuation/Throttle Type/Switch Type: Lever
• Air Consumption @ Load (cfm): 5.5
• Air Consumption @ Load (l/min): 15.6
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90

• Blows per Min: 3000
• Bore Diameter (in): 0.93

• Color: Black
• Configuration/Handle Type: Pistol Grip
• Duty Rating: Industrial Duty

• Lock Mechanism: Bayonet Needle

• Max Pressure (bar): 6.2
• Min Hose Size (in): 5/16
• Needle Length: 7"
• Needle Qty: 19

• Power Source: Air Powered
• Product Length (in): 12.4

• Product Weight (lb): 6.6

• Shank SIze (in): .5
• Shank Type: Ingersoll Rand Shank

• Standards/Certifications: Vibration : ISO 28927-9:2009Sound : ISO 15744:2008Safety : ISO 11148-4:2012
• Stroke Length (in): 1.4

• Warranty: 1-year

• Accessories: NS11-122-19

• Lubrication: 10P
• Parts: 22038194

IR 17RB078

Spur Gear Air Motor, 1-1/2" Keyed Shaft, 69 RPM, 2.2 HP, 739 NM, Reversible

• Air Consumption at Max HP (scfm): 100
• Air Inlet: 3/8" NPT
• Air Pressure (psi): 90

• Drive Size (in): 1-1/2
• Drive Type: Round Keyed

• Exhaust Location: Side
• Finish: Paint, Yellow
• Gear Reduction: Double
• Gear Train: Spur Gear

• Housing Material: Steel Motor, Aluminum Gear Housing

• Max Free Speed (rpm): 69
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 545
• Max Torque (in-lb): 6541
• Max Torque (nm): 739
• Motor: Rotary Vane
• Motor: Spur Gear
• Mounting Type: Foot and Face

• Power Source: Air Powered

• Product Weight (lb): 72
• Rated Power (hp): 2.2
• Rated Power (kW): 1.64
• Reversible: Reversible

• Speed at Max Power (rpm): 36
• Starting Torque (ft-lb): 327
• Starting Torque (nm): 443

• Warranty: 1-year

IR 1710-A626A

IR 17M13B195

IR 182A53-685

IR 182A13-CXRSN50

IR 182A53-689

IR 182A53-593

IR 182A83-606

IR 182A83-593

IR 182A83-A602

IR 182L

Air Chisel Scaler, 4000 BPM, 1-1/16" Stroke

Description: With 4000 blows-per-minute and 1" stroke, the 182 is our most powerful and chisel durable scaler. The 'swan' neck grip option add an extra level of comfort for both vertical and horizontal operation

Features And Benefits:

• Easy Adjustment: The adjustable bayonet-type needle housing lock allows for easy adjustment without special tools.
• Durability: These scalers feature a rubber faced throttle valve to ensure positive sealing of internal components, and they're durable enough to withstand repeated drops and harsh conditions with ease.
• Comfort: Compact, well balanced and low vibration maximize operators comfort
• Power: The powerful motor featured in the 182 Series makes work easier and more efficient.

Product Application and Uses:

Remove Paint, Rust, Dirt, Weld Slags

• Includes: Bare Tool
• Actuation/Throttle Type/Switch Type: Lever
• Air Consumption @ Load (cfm): 13
• Air Consumption @ Load (l/min): 368
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90

• Blows per Min: 4000
• Bore Diameter (in): 0.94

• Color: Silver
• Configuration/Handle Type: Straight
• Duty Rating: Heavy Duty

• Max Pressure (bar): 6.2
• Min Hose Size (in): 5/16

• Non Sparking: No
• Power Source: Air Powered
• Product Length (in): 9

• Product Width (in): 6.93
• Product Height (in): 2.76
• Product Weight (lb): 4.1

• Shank SIze (in): .5
• Shank Type: Ingersoll Rand Shank

• Sound Pressure/Power Db(A): 107.2 / 118.2
• Stroke Length (in): 1.06

• Vibration Level (m/s2): 12.7
• Warranty: 1-year

• Accessories: WF-14-12
• Accessories: WF-14A-007
• Accessories: WF-14B-007
• Accessories: WF-14B-012
• Accessories: WF-14C-007
• Accessories: WF-14C-012
• Accessories: WF-14C-018
• Accessories: WF-14D-007
• Accessories: WF-14D-012
• Accessories: WF-14D-018
• Accessories: WF-14F-12
• Accessories: WF-14F-18
• Accessories: WF-14F-7

• Complete Tool Kits: 182K1

• Lubrication: 10G
• Lubrication: 10P
• Parts: NS11-27
• Parts: NS11-A24

IR 182LNA1

Air Needle Scaler, 4000 BPM, 1-1/16" Stroke

Description: With 4000 blows-per-minute and 1" stroke, the 182 is our most powerful and chisel durable scaler.

Features And Benefits:

• Easy Adjustment: The adjustable bayonet-type needle housing lock allows for easy adjustment without special tools.
• Durability: These scalers feature a rubber faced throttle valve to ensure positive sealing of internal components, and they're durable enough to withstand repeated drops and harsh conditions with ease.
• Comfort: Compact, well balanced and low vibration maximize operators comfort
• Power: The powerful motor featured in the 182 Series makes work easier and more efficient.
• Tested and approved in accordance with MIL-S-23492A (Ships).
• Includes (19) steel precision heat-treated needles for maximum performance. (1/8" diameter, 5" length)

Product Application and Uses:

Remove Paint, Rust, Dirt, Weld Slags

• Includes: 19 steel precision heat-treated needles (1/8" diameter, 5" length)
• Actuation/Throttle Type/Switch Type: Lever
• Air Consumption @ Load (cfm): 13
• Air Consumption @ Load (l/min): 368
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90

• Blows per Min: 4000
• Bore Diameter (in): 0.94

• Color: Black
• Configuration/Handle Type: Straight
• Duty Rating: Heavy Duty

• Max Pressure (bar): 6.2
• Min Hose Size (in): 5/16
• Needle Qty: 19 Needles

• Non Sparking: No
• Power Source: Air Powered
• Product Length (in): 15

• Product Width (in): 6.6
• Product Height (in): 2.7
• Product Weight (lb): 5.8

• Shank SIze (in): .5
• Shank Type: Ingersoll Rand Shank

• Sound Pressure/Power Db(A): 107.2 / 118.2
• Stroke Length (in): 1.06

• Vibration Level (m/s2): 10.1
• Warranty: 1-year

• Accessories: NS11-122-19
• Accessories: NS11-22-19

• Lubrication: 10G
• Lubrication: 10P
• Parts: NS11-A24
• Parts: NS11A

IR 1841N

Inline Multi-Vane Air Motor, 5/8" Keyed Shaft, 1700 RPM, 1.2 HP, 17 NM, Reversible

• Air Consumption at Max HP (scfm): 43
• Air Inlet: 3/8" NPT
• Air Pressure (psi): 90

• Drive Size (in): 5/8
• Drive Type: Round Keyed

• Exhaust Location: Rear
• Finish: Black Oxide
• Gear Train: Planetary

• Housing Material: Steel

• Max Free Speed (rpm): 1700
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 13
• Max Torque (in-lb): 150
• Max Torque (nm): 17
• Motor: Rotary Vane
• Motor: In line
• Mounting Type: Face

• Number of Mounting Holes: 2
• Power Source: Air Powered

• Product Weight (lb): 5.5
• Rated Power (hp): 1.2
• Rated Power (kW): 0.89
• Reversible: Reversible

• Speed at Max Power (rpm): 800
• Starting Torque (ft-lb): 9.3
• Starting Torque (nm): 12.6

• Warranty: 1-year

• Parts: R1801-A123

IR 182G

Air Chisel Scaler, 4000 BPM, 1-1/16" Stroke

Description: With 4,000 blows-per-minute and a 1-1/16 inch stroke, the 182G is our most powerful and durable chisel scaler. The 'swan' neck grip option adds an extra level of comfort for both vertical and horizontal operation.

Features And Benefits:

• Easy Adjustment: The adjustable bayonet-type needle housing lock allows for easy adjustment without special tools.
• Durability: These scalers feature a rubber faced throttle valve to ensure positive sealing of internal components, and they're durable enough to withstand repeated drops and harsh conditions with ease.
• Power: With 4,000 blows-per-minute and a 1-1/16 inch stroke, the 182G is our most powerful and durable chisel scaler.
• Comfort: Compact, well balanced and low vibration maximize operators comfort.

Product Application and Uses:

Designed for removal of unwanted deposits from metal and other hardened materials through repetitive application of linear impacts of a tool steel that is retained and driven by the scaler. Such deposits include weld splatter, paint, coatings and other surface materials.

• Actuation/Throttle Type/Switch Type: Outside Trigger
• Air Consumption @ Load (cfm): 13
• Air Consumption @ Load (l/min): 368
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90

• Blows per Min: 4000
• Bore Diameter (in): .94

• Color: Silver
• Configuration/Handle Type: Swan Neck

• Max Pressure (bar): 6.2
• Min Hose Size (in): 5/16

• Power Source: Air Powered
• Product Length (in): 12.8

• Product Weight (lb): 5.3

• Shank SIze (in): .5
• Shank Type: Ingersoll Rand Shank

• Sound Pressure/Power Db(A): 107.2 / 118.2
• Stroke Length (in): 1.06

• Vibration Level (m/s2): 8.5
• Vibration Uncertainy K* (m/s2): 1.2
• Warranty: 1-year

• Accessories: WF-14-12
• Accessories: WF-14A-007
• Accessories: WF-14B-007
• Accessories: WF-14B-012
• Accessories: WF-14C-007
• Accessories: WF-14C-012
• Accessories: WF-14C-018
• Accessories: WF-14D-007
• Accessories: WF-14D-012
• Accessories: WF-14D-018
• Accessories: WF-14F-12
• Accessories: WF-14F-18
• Accessories: WF-14F-7

IR 1841P

Inline Multi-Vane Air Motor, 5/8" Keyed Shaft, 900 RPM, 1.1 HP, 27.1 NM, Reversible

• Air Consumption at Max HP (scfm): 43
• Air Inlet: 3/8" NPT
• Air Pressure (psi): 90

• Drive Size (in): 5/8
• Drive Type: Round Keyed

• Exhaust Location: Rear
• Finish: Black Oxide
• Gear Train: Planetary

• Housing Material: Steel

• Max Free Speed (rpm): 900
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 20
• Max Torque (in-lb): 240
• Max Torque (nm): 27.1
• Motor: Rotary Vane
• Motor: In line
• Mounting Type: Face

• Number of Mounting Holes: 2
• Power Source: Air Powered

• Product Weight (lb): 5.88
• Rated Power (hp): 1.1
• Rated Power (kW): 0.82
• Reversible: Reversible

• Speed at Max Power (rpm): 430
• Starting Torque (ft-lb): 15
• Starting Torque (nm): 20.3

• Warranty: 1-year

• Parts: R1801-A123

IR 1841Q

Inline Multi-Vane Air Motor, 5/8" Keyed Shaft, 550 RPM, 1.1 HP, 48.8 NM, Reversible

• Air Consumption at Max HP (scfm): 43
• Air Inlet: 3/8" NPT
• Air Pressure (psi): 90

• Drive Size (in): 5/8
• Drive Type: Round Keyed

• Exhaust Location: Rear
• Finish: Black Oxide
• Gear Train: Planetary

• Housing Material: Steel

• Max Free Speed (rpm): 550
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 36
• Max Torque (in-lb): 432
• Max Torque (nm): 48.8
• Motor: Rotary Vane
• Motor: In line
• Mounting Type: Face

• Number of Mounting Holes: 2
• Power Source: Air Powered
• Product Length (in): 8.5

• Product Weight (lb): 5.88
• Rated Power (hp): 1.1
• Rated Power (kW): 0.82
• Reversible: Reversible

• Speed at Max Power (rpm): 260
• Starting Torque (ft-lb): 27
• Starting Torque (nm): 36.6

• Warranty: 1-year

• Parts: R1801-A123

IR 18602

IR 1LL1A1

IR 1RLMC1

IR 1RPNC1

IR 1RPQS1

IR 1RTQS1

IR 1RTNS1

IR 172-TK2

IR 1RPNS1

IR 204A19BSXTRA916

IR 202-664

IR 2025MAX

1/2" Angle Air Impact Wrench, 180 ft-lb Torque, Friction Ring Retainer

Description: This Right Angle Impact Wrench is lightweight, durable, and easy to use. Paired with its powerful vane motor and trigger actuation, this tool will quickly become your favorite on any job site.

Features And Benefits:

• Power: With a finely tuned vane motor and power regulation, you'll have full control of your tool while never having to settle for less power.
• Access: Thanks to this wrench's angle grip and composite housing, you'll be able to access any hard-to-reach spaces with ease.
• Fluctuation: The Right Angle Impact Wrench features a square socket retaining ring anvil, allowing it switch sockets with ease. Perfect for automotive repair work.
• Feather touch trigger, 2-position forward power regulator, forward/reverse ring
• Compact design, with head height under 2 inches, makes operation and access easier in tight spots so you can perform even the most detailed work with this air impact wrench
• Ergonomically sound rear exhaust system
• Offers the same reach as a ratchet
• 180 ft-lb max torque
• Free speed: 7,100 revolutions per minute
• Optimized for the vehicle repair industry, body shops, and MRO
• 1-year warranty

Product Application and Uses:

General Industrial, Facility Maintenance

• Includes: Bare Tool
• Actuation/Throttle Type/Switch Type: Feather-touch Trigger
• Air Consumption @ Load (cfm): 19
• Air Consumption @ Load (l/min): 538
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Anvil Length: Standard
• Average Air Consumption (cfm): 3.5
• Average Air Consumption (l/min): 99

• Blows per Min: 2100

• Color: Grey
• Configuration/Handle Type: Right Angle
• Drive Size (in): 1/2
• Drive Type: Square
• Duty Rating: Maintenance Duty

• End Plates: Aluminum with Hard-coating
• Exhaust Location: Bottom
• Free Speed Sound Pressure/Power Db(A): 94.1 / 105.1

• Hammer Case: Aluminum
• Handle Material: Composite
• Impact Mechanism: Single Hammer
• Impacting Sound Pressure/Power Db(A): 96.6 / 107.6

• Max Bolt Diameter (in): 7/16
• Max Free Speed (rpm): 9000
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 180
• Max Torque (in-lb): 2160
• Max Torque (nm): 244
• Min Hose Size (in): 3/8
• Motor: Reverse Bias

• Number of Power Settings: 2
• Power Source: Air Powered
• Power to Weight Ratio (Nut-busting Torque/Weight) (ft-lb/lb): 52.9
• Product Length (in): 13.1

• Product Width (in): 2.2
• Product Height (in): 3.1
• Product Weight (lb): 3.4
• Recommended Forward Torque Range (ft-lb): 45-140
• Recommended Forward Torque Range (in-lb): 540-1682
• Recommended Forward Torque Range (nm): 61-190
• Recommended Reverse Torque (ft-lb): 45-160
• Recommended Reverse Torque (nm): 61-217
• Retainer Type: Friction Ring

• Side to Center Distance (in): 1.1
• Side to Center Distance (mm): 28

• Standards/Certifications: Iso 11148-6, Cagi B186, Iso 28927-2, Iso 15744

• Tool Type: Full-size
• Vanes: 7
• Vibration Level (m/s2): 17.4
• Warranty: 1-year

• Accessories: 2015-BOOT
• Accessories: S64H1316L-PS1
• Accessories: S64H1516L-PS1
• Accessori

IR 202-739

IR 2080-A826-6

IR 209M19X01

IR 2080-A93

IR SLB150-5

SLB150-5 Manual Hoist, .75 Ton Capacity, 5ft of Lift, Overload Protection

3/4 - 6 metric ton Line Pull Capacity. Give us a place to stand and we'll help you move the earth. Archimedes principle of leverage is improved yet again in the Silver Series Lever Chain Hoist. Meets ANSI/ASME B30.16 and all pertinent world standards, including the European Machinery Directive. The patent pending "Arrow-Notch"; free chain system is simple and reliable. Just one hand turns the indicator and operators will enjoy the easiest free chaining we have ever tested. Try to operate an SLB in free chain mode and the brake instantly engages, holding the load, minimizing the risk of an accident. The Silver Series has a zinc-nickel-chrome plated finish, which is more durable and corrosion resistant than paint. Plus the SLB has the quality features you expect from Ingersoll Rand.

Product Application/Uses:

Features and Benefits:

• Meets Specifications and HST - 3M standard
• Value priced lever hoist with industrial rated performance
• Low handle force required
• One hand operation with the best free chaining available
• If a load is applied in the free chain mode, the brake will automatically engage, minimizing operator setup error
• 360 degree handle rotation
• Comfortable, rubber handle grip
• Reliable disc braking system
• Premium grade 100 alloy load chain
• Hardened swivel latch hooks
• Light weight design for better portability

Capacity (lb): 1650

Lift (ft): 5

IR SLB300-20

SLB300-20 Manual Hoist, 1.5 Ton Capacity, 20ft of Lift, Overload Protection

3/4 - 6 metric ton Line Pull Capacity. Give us a place to stand and we'll help you move the earth. Archimedes principle of leverage is improved yet again in the Silver Series Lever Chain Hoist. Meets ANSI/ASME B30.16 and all pertinent world standards, including the European Machinery Directive. The patent pending "Arrow-Notch"; free chain system is simple and reliable. Just one hand turns the indicator and operators will enjoy the easiest free chaining we have ever tested. Try to operate an SLB in free chain mode and the brake instantly engages, holding the load, minimizing the risk of an accident. The Silver Series has a zinc-nickel-chrome plated finish, which is more durable and corrosion resistant than paint. Plus the SLB has the quality features you expect from Ingersoll Rand.

Product Application/Uses:

Features and Benefits:

• Meets Specifications and HST - 3M standard
• Value priced lever hoist with industrial rated performance
• Low handle force required
• One hand operation with the best free chaining available
• If a load is applied in the free chain mode, the brake will automatically engage, minimizing operator setup error
• 360 degree handle rotation
• Comfortable, rubber handle grip
• Reliable disc braking system
• Premium grade 100 alloy load chain
• Hardened swivel latch hooks
• Light weight design for better portability

Capacity (lb): 3300

Lift (ft): 20

IR SLB200-15

SLB200-15 Manual Hoist, 1 Ton Capacity, 15ft of Lift, Overload Protection

3/4 - 6 metric ton Line Pull Capacity. Give us a place to stand and we'll help you move the earth. Archimedes principle of leverage is improved yet again in the Silver Series Lever Chain Hoist. Meets ANSI/ASME B30.16 and all pertinent world standards, including the European Machinery Directive. The patent pending "Arrow-Notch"; free chain system is simple and reliable. Just one hand turns the indicator and operators will enjoy the easiest free chaining we have ever tested. Try to operate an SLB in free chain mode and the brake instantly engages, holding the load, minimizing the risk of an accident. The Silver Series has a zinc-nickel-chrome plated finish, which is more durable and corrosion resistant than paint. Plus the SLB has the quality features you expect from Ingersoll Rand.

Product Application/Uses:

Features and Benefits:

• Meets Specifications and HST - 3M standard
• Value priced lever hoist with industrial rated performance
• Low handle force required
• One hand operation with the best free chaining available
• If a load is applied in the free chain mode, the brake will automatically engage, minimizing operator setup error
• 360 degree handle rotation
• Comfortable, rubber handle grip
• Reliable disc braking system
• Premium grade 100 alloy load chain
• Hardened swivel latch hooks
• Light weight design for better portability

Capacity (lb): 2200

Lift (ft): 15

IR SMB010-10-8V

SMB010-10-8V Manual Chain Hoist, 1 Ton Capacity, 10ft of Lift, 8ft Hand Chain Drop, Overload Protection

1/2 - 5 metric ton Lifting Capacity; A new design for the modern workplace with safety and performance in mind. Meets or exceeds world specifications including ASME B30.16. A value-packed product with premium features at a great price.

Product Application/Uses:

Features and Benefits:

• Meets Specifications and HST - 2M standards
• Overload Protection to deter and reduce downtime and repair costs resulting from abuse
• All steel, low headroom, light weight construction
• Self-adjusting disc type double pawl mechanical load brake
• Hardened roller bearings for maximum efficiency and durability
• 4 layer finish of nickel, copper, nickel, and chrome - rugged enough to last
• Ideal for the Rental and Construction markets

Capacity (lb): 2200

Lift (ft): 10

IR SMB010-20-18V

SMB010-20-18V Manual Chain Hoist, 1 Ton Capacity, 20ft of Lift, 18ft Hand Chain Drop, Overload Protection

1/2 - 5 metric ton Lifting Capacity; A new design for the modern workplace with safety and performance in mind. Meets or exceeds world specifications including ASME B30.16. A value-packed product with premium features at a great price.

Product Application/Uses:

Features and Benefits:

• Meets Specifications and HST - 2M standards
• Overload Protection to deter and reduce downtime and repair costs resulting from abuse
• All steel, low headroom, light weight construction
• Self-adjusting disc type double pawl mechanical load brake
• Hardened roller bearings for maximum efficiency and durability
• 4 layer finish of nickel, copper, nickel, and chrome - rugged enough to last
• Ideal for the Rental and Construction markets

Capacity (lb): 2200

Lift (ft): 20

IR SMB005-20-18V

SMB005-20-18V Manual Chain Hoist, .5 Ton Capacity, 20ft of Lift, 18ft Hand Chain Drop, Overload Protection

1/2 - 5 metric ton Lifting Capacity; A new design for the modern workplace with safety and performance in mind. Meets or exceeds world specifications including ASME B30.16. A value-packed product with premium features at a great price.

Product Application/Uses:

Features and Benefits:

• Meets Specifications and HST - 2M standards
• Overload Protection to deter and reduce downtime and repair costs resulting from abuse
• All steel, low headroom, light weight construction
• Self-adjusting disc type double pawl mechanical load brake
• Hardened roller bearings for maximum efficiency and durability
• 4 layer finish of nickel, copper, nickel, and chrome - rugged enough to last
• Ideal for the Rental and Construction markets

Capacity (lb): 1100

Lift (ft): 20

IR SMB005-15-13V

SMB005-15-13V Manual Chain Hoist, .5 Ton Capacity, 15ft of Lift, 13ft Hand Chain Drop, Overload Protection

1/2 - 5 metric ton Lifting Capacity; A new design for the modern workplace with safety and performance in mind. Meets or exceeds world specifications including ASME B30.16. A value-packed product with premium features at a great price.

Product Application/Uses:

Features and Benefits:

• Meets Specifications and HST - 2M standards
• Overload Protection to deter and reduce downtime and repair costs resulting from abuse
• All steel, low headroom, light weight construction
• Self-adjusting disc type double pawl mechanical load brake
• Hardened roller bearings for maximum efficiency and durability
• 4 layer finish of nickel, copper, nickel, and chrome - rugged enough to last
• Ideal for the Rental and Construction markets

Capacity (lb): 1100

Lift (ft): 15

IR SLB150-20

SLB150-20 Manual Hoist, .75 Ton Capacity, 20ft of Lift, Overload Protection

3/4 - 6 metric ton Line Pull Capacity. Give us a place to stand and we'll help you move the earth. Archimedes principle of leverage is improved yet again in the Silver Series Lever Chain Hoist. Meets ANSI/ASME B30.16 and all pertinent world standards, including the European Machinery Directive. The patent pending "Arrow-Notch"; free chain system is simple and reliable. Just one hand turns the indicator and operators will enjoy the easiest free chaining we have ever tested. Try to operate an SLB in free chain mode and the brake instantly engages, holding the load, minimizing the risk of an accident. The Silver Series has a zinc-nickel-chrome plated finish, which is more durable and corrosion resistant than paint. Plus the SLB has the quality features you expect from Ingersoll Rand.

Product Application/Uses:

Features and Benefits:

• Meets Specifications and HST - 3M standard
• Value priced lever hoist with industrial rated performance
• Low handle force required
• One hand operation with the best free chaining available
• If a load is applied in the free chain mode, the brake will automatically engage, minimizing operator setup error
• 360 degree handle rotation
• Comfortable, rubber handle grip
• Reliable disc braking system
• Premium grade 100 alloy load chain
• Hardened swivel latch hooks
• Light weight design for better portability

Capacity (lb): 1650

Lift (ft): 20

IR SMB005-10-8V

SMB005-10-8V Manual Chain Hoist, .5 Ton Capacity, 10ft of Lift, 8ft Hand Chain Drop, Overload Protection

1/2 - 5 metric ton Lifting Capacity; A new design for the modern workplace with safety and performance in mind. Meets or exceeds world specifications including ASME B30.16. A value-packed product with premium features at a great price.

Product Application/Uses:

Features and Benefits:

• Meets Specifications and HST - 2M standards
• Overload Protection to deter and reduce downtime and repair costs resulting from abuse
• All steel, low headroom, light weight construction
• Self-adjusting disc type double pawl mechanical load brake
• Hardened roller bearings for maximum efficiency and durability
• 4 layer finish of nickel, copper, nickel, and chrome - rugged enough to last
• Ideal for the Rental and Construction markets

Capacity (lb): 1100

Lift (ft): 10

IR SLB300-15

SLB300-15 Manual Hoist, 1.5 Ton Capacity, 15ft of Lift, Overload Protection

3/4 - 6 metric ton Line Pull Capacity. Give us a place to stand and we'll help you move the earth. Archimedes principle of leverage is improved yet again in the Silver Series Lever Chain Hoist. Meets ANSI/ASME B30.16 and all pertinent world standards, including the European Machinery Directive. The patent pending "Arrow-Notch"; free chain system is simple and reliable. Just one hand turns the indicator and operators will enjoy the easiest free chaining we have ever tested. Try to operate an SLB in free chain mode and the brake instantly engages, holding the load, minimizing the risk of an accident. The Silver Series has a zinc-nickel-chrome plated finish, which is more durable and corrosion resistant than paint. Plus the SLB has the quality features you expect from Ingersoll Rand.

Product Application/Uses:

Features and Benefits:

• Meets Specifications and HST - 3M standard
• Value priced lever hoist with industrial rated performance
• Low handle force required
• One hand operation with the best free chaining available
• If a load is applied in the free chain mode, the brake will automatically engage, minimizing operator setup error
• 360 degree handle rotation
• Comfortable, rubber handle grip
• Reliable disc braking system
• Premium grade 100 alloy load chain
• Hardened swivel latch hooks
• Light weight design for better portability

Capacity (lb): 3300

Lift (ft): 15

IR SLB200-10

SLB200-10 Manual Hoist, 1 Ton Capacity, 10ft of Lift, Overload Protection

3/4 - 6 metric ton Line Pull Capacity. Give us a place to stand and we'll help you move the earth. Archimedes principle of leverage is improved yet again in the Silver Series Lever Chain Hoist. Meets ANSI/ASME B30.16 and all pertinent world standards, including the European Machinery Directive. The patent pending "Arrow-Notch"; free chain system is simple and reliable. Just one hand turns the indicator and operators will enjoy the easiest free chaining we have ever tested. Try to operate an SLB in free chain mode and the brake instantly engages, holding the load, minimizing the risk of an accident. The Silver Series has a zinc-nickel-chrome plated finish, which is more durable and corrosion resistant than paint. Plus the SLB has the quality features you expect from Ingersoll Rand.

Product Application/Uses:

Features and Benefits:

• Meets Specifications and HST - 3M standard
• Value priced lever hoist with industrial rated performance
• Low handle force required
• One hand operation with the best free chaining available
• If a load is applied in the free chain mode, the brake will automatically engage, minimizing operator setup error
• 360 degree handle rotation
• Comfortable, rubber handle grip
• Reliable disc braking system
• Premium grade 100 alloy load chain
• Hardened swivel latch hooks
• Light weight design for better portability

Capacity (lb): 2200

Lift (ft): 10

IR SLB600-15

SLB600-15 Manual Hoist, 3 Ton Capacity, 15ft of Lift, Overload Protection

3/4 - 6 metric ton Line Pull Capacity. Give us a place to stand and we'll help you move the earth. Archimedes principle of leverage is improved yet again in the Silver Series Lever Chain Hoist. Meets ANSI/ASME B30.16 and all pertinent world standards, including the European Machinery Directive. The patent pending "Arrow-Notch"; free chain system is simple and reliable. Just one hand turns the indicator and operators will enjoy the easiest free chaining we have ever tested. Try to operate an SLB in free chain mode and the brake instantly engages, holding the load, minimizing the risk of an accident. The Silver Series has a zinc-nickel-chrome plated finish, which is more durable and corrosion resistant than paint. Plus the SLB has the quality features you expect from Ingersoll Rand.

Product Application/Uses:

Features and Benefits:

• Meets Specifications and HST - 3M standard
• Value priced lever hoist with industrial rated performance
• Low handle force required
• One hand operation with the best free chaining available
• If a load is applied in the free chain mode, the brake will automatically engage, minimizing operator setup error
• 360 degree handle rotation
• Comfortable, rubber handle grip
• Reliable disc braking system
• Premium grade 100 alloy load chain
• Hardened swivel latch hooks
• Light weight design for better portability

Capacity (lb): 6600

Lift (ft): 15

IR SLB600-20

SLB600-20 Manual Hoist, 3 Ton Capacity, 20ft of Lift, Overload Protection

3/4 - 6 metric ton Line Pull Capacity. Give us a place to stand and we'll help you move the earth. Archimedes principle of leverage is improved yet again in the Silver Series Lever Chain Hoist. Meets ANSI/ASME B30.16 and all pertinent world standards, including the European Machinery Directive. The patent pending "Arrow-Notch"; free chain system is simple and reliable. Just one hand turns the indicator and operators will enjoy the easiest free chaining we have ever tested. Try to operate an SLB in free chain mode and the brake instantly engages, holding the load, minimizing the risk of an accident. The Silver Series has a zinc-nickel-chrome plated finish, which is more durable and corrosion resistant than paint. Plus the SLB has the quality features you expect from Ingersoll Rand.

Product Application/Uses:

Features and Benefits:

• Meets Specifications and HST - 3M standard
• Value priced lever hoist with industrial rated performance
• Low handle force required
• One hand operation with the best free chaining available
• If a load is applied in the free chain mode, the brake will automatically engage, minimizing operator setup error
• 360 degree handle rotation
• Comfortable, rubber handle grip
• Reliable disc braking system
• Premium grade 100 alloy load chain
• Hardened swivel latch hooks
• Light weight design for better portability

Capacity (lb): 6600

Lift (ft): 20

IR SM8AMAN

IR SLB200-20

SLB200-20 Manual Hoist, 1 Ton Capacity, 20ft of Lift, Overload Protection

3/4 - 6 metric ton Line Pull Capacity. Give us a place to stand and we'll help you move the earth. Archimedes principle of leverage is improved yet again in the Silver Series Lever Chain Hoist. Meets ANSI/ASME B30.16 and all pertinent world standards, including the European Machinery Directive. The patent pending "Arrow-Notch"; free chain system is simple and reliable. Just one hand turns the indicator and operators will enjoy the easiest free chaining we have ever tested. Try to operate an SLB in free chain mode and the brake instantly engages, holding the load, minimizing the risk of an accident. The Silver Series has a zinc-nickel-chrome plated finish, which is more durable and corrosion resistant than paint. Plus the SLB has the quality features you expect from Ingersoll Rand.

Product Application/Uses:

Features and Benefits:

• Meets Specifications and HST - 3M standard
• Value priced lever hoist with industrial rated performance
• Low handle force required
• One hand operation with the best free chaining available
• If a load is applied in the free chain mode, the brake will automatically engage, minimizing operator setup error
• 360 degree handle rotation
• Comfortable, rubber handle grip
• Reliable disc braking system
• Premium grade 100 alloy load chain
• Hardened swivel latch hooks
• Light weight design for better portability

Capacity (lb): 2200

Lift (ft): 20

IR SMB010-15-13V

SMB010-15-13V Manual Chain Hoist, 1 Ton Capacity, 15ft of Lift, 13ft Hand Chain Drop, Overload Protection

1/2 - 5 metric ton Lifting Capacity; A new design for the modern workplace with safety and performance in mind. Meets or exceeds world specifications including ASME B30.16. A value-packed product with premium features at a great price.

Product Application/Uses:

Features and Benefits:

• Meets Specifications and HST - 2M standards
• Overload Protection to deter and reduce downtime and repair costs resulting from abuse
• All steel, low headroom, light weight construction
• Self-adjusting disc type double pawl mechanical load brake
• Hardened roller bearings for maximum efficiency and durability
• 4 layer finish of nickel, copper, nickel, and chrome - rugged enough to last
• Ideal for the Rental and Construction markets

Capacity (lb): 2200

Lift (ft): 15

IR SLB600-5

SLB600-5 Manual Hoist, 3 Ton Capacity, 5ft of Lift, Overload Protection

3/4 - 6 metric ton Line Pull Capacity. Give us a place to stand and we'll help you move the earth. Archimedes principle of leverage is improved yet again in the Silver Series Lever Chain Hoist. Meets ANSI/ASME B30.16 and all pertinent world standards, including the European Machinery Directive. The patent pending "Arrow-Notch"; free chain system is simple and reliable. Just one hand turns the indicator and operators will enjoy the easiest free chaining we have ever tested. Try to operate an SLB in free chain mode and the brake instantly engages, holding the load, minimizing the risk of an accident. The Silver Series has a zinc-nickel-chrome plated finish, which is more durable and corrosion resistant than paint. Plus the SLB has the quality features you expect from Ingersoll Rand.

Product Application/Uses:

Features and Benefits:

• Meets Specifications and HST - 3M standard
• Value priced lever hoist with industrial rated performance
• Low handle force required
• One hand operation with the best free chaining available
• If a load is applied in the free chain mode, the brake will automatically engage, minimizing operator setup error
• 360 degree handle rotation
• Comfortable, rubber handle grip
• Reliable disc braking system
• Premium grade 100 alloy load chain
• Hardened swivel latch hooks
• Light weight design for better portability

Capacity (lb): 6600

Lift (ft): 5

IR SLB300-5

SLB300-5 Manual Hoist, 1.5 Ton Capacity, 5ft of Lift, Overload Protection

3/4 - 6 metric ton Line Pull Capacity. Give us a place to stand and we'll help you move the earth. Archimedes principle of leverage is improved yet again in the Silver Series Lever Chain Hoist. Meets ANSI/ASME B30.16 and all pertinent world standards, including the European Machinery Directive. The patent pending "Arrow-Notch"; free chain system is simple and reliable. Just one hand turns the indicator and operators will enjoy the easiest free chaining we have ever tested. Try to operate an SLB in free chain mode and the brake instantly engages, holding the load, minimizing the risk of an accident. The Silver Series has a zinc-nickel-chrome plated finish, which is more durable and corrosion resistant than paint. Plus the SLB has the quality features you expect from Ingersoll Rand.

Product Application/Uses:

Features and Benefits:

• Meets Specifications and HST - 3M standard
• Value priced lever hoist with industrial rated performance
• Low handle force required
• One hand operation with the best free chaining available
• If a load is applied in the free chain mode, the brake will automatically engage, minimizing operator setup error
• 360 degree handle rotation
• Comfortable, rubber handle grip
• Reliable disc braking system
• Premium grade 100 alloy load chain
• Hardened swivel latch hooks
• Light weight design for better portability

Capacity (lb): 3300

Lift (ft): 5

IR SMB005-30-28V

SMB005-30-28V Manual Chain Hoist, .5 Ton Capacity, 30ft of Lift, 28ft Hand Chain Drop, Overload Protection

1/2 - 5 metric ton Lifting Capacity; A new design for the modern workplace with safety and performance in mind. Meets or exceeds world specifications including ASME B30.16. A value-packed product with premium features at a great price.

Product Application/Uses:

Features and Benefits:

• Meets Specifications and HST - 2M standards
• Overload Protection to deter and reduce downtime and repair costs resulting from abuse
• All steel, low headroom, light weight construction
• Self-adjusting disc type double pawl mechanical load brake
• Hardened roller bearings for maximum efficiency and durability
• 4 layer finish of nickel, copper, nickel, and chrome - rugged enough to last
• Ideal for the Rental and Construction markets

Capacity (lb): 1100

Lift (ft): 30

IR SM8AMA

IR SLB600-10

SLB600-10 Manual Hoist, 3 Ton Capacity, 10ft of Lift, Overload Protection

3/4 - 6 metric ton Line Pull Capacity. Give us a place to stand and we'll help you move the earth. Archimedes principle of leverage is improved yet again in the Silver Series Lever Chain Hoist. Meets ANSI/ASME B30.16 and all pertinent world standards, including the European Machinery Directive. The patent pending "Arrow-Notch"; free chain system is simple and reliable. Just one hand turns the indicator and operators will enjoy the easiest free chaining we have ever tested. Try to operate an SLB in free chain mode and the brake instantly engages, holding the load, minimizing the risk of an accident. The Silver Series has a zinc-nickel-chrome plated finish, which is more durable and corrosion resistant than paint. Plus the SLB has the quality features you expect from Ingersoll Rand.

Product Application/Uses:

Features and Benefits:

• Meets Specifications and HST - 3M standard
• Value priced lever hoist with industrial rated performance
• Low handle force required
• One hand operation with the best free chaining available
• If a load is applied in the free chain mode, the brake will automatically engage, minimizing operator setup error
• 360 degree handle rotation
• Comfortable, rubber handle grip
• Reliable disc braking system
• Premium grade 100 alloy load chain
• Hardened swivel latch hooks
• Light weight design for better portability

Capacity (lb): 6600

Lift (ft): 10

IR SLB200-5

SLB200-5 Manual Hoist, 1 Ton Capacity, 5ft of Lift, Overload Protection

3/4 - 6 metric ton Line Pull Capacity. Give us a place to stand and we'll help you move the earth. Archimedes principle of leverage is improved yet again in the Silver Series Lever Chain Hoist. Meets ANSI/ASME B30.16 and all pertinent world standards, including the European Machinery Directive. The patent pending "Arrow-Notch"; free chain system is simple and reliable. Just one hand turns the indicator and operators will enjoy the easiest free chaining we have ever tested. Try to operate an SLB in free chain mode and the brake instantly engages, holding the load, minimizing the risk of an accident. The Silver Series has a zinc-nickel-chrome plated finish, which is more durable and corrosion resistant than paint. Plus the SLB has the quality features you expect from Ingersoll Rand.

Product Application/Uses:

Features and Benefits:

• Meets Specifications and HST - 3M standard
• Value priced lever hoist with industrial rated performance
• Low handle force required
• One hand operation with the best free chaining available
• If a load is applied in the free chain mode, the brake will automatically engage, minimizing operator setup error
• 360 degree handle rotation
• Comfortable, rubber handle grip
• Reliable disc braking system
• Premium grade 100 alloy load chain
• Hardened swivel latch hooks
• Light weight design for better portability

Capacity (lb): 2200

Lift (ft): 5

IR SMB015-10-8V

SMB015-10-8V Manual Chain Hoist, 1.5 Ton Capacity, 10ft of Lift, 8ft Hand Chain Drop, Overload Protection

1/2 - 5 metric ton Lifting Capacity; A new design for the modern workplace with safety and performance in mind. Meets or exceeds world specifications including ASME B30.16. A value-packed product with premium features at a great price.

Product Application/Uses:

Features and Benefits:

• Meets Specifications and HST - 2M standards
• Overload Protection to deter and reduce downtime and repair costs resulting from abuse
• All steel, low headroom, light weight construction
• Self-adjusting disc type double pawl mechanical load brake
• Hardened roller bearings for maximum efficiency and durability
• 4 layer finish of nickel, copper, nickel, and chrome - rugged enough to last
• Ideal for the Rental and Construction markets

Capacity (lb): 3300

Lift (ft): 10

IR SMB015-20-18V

SMB015-20-18V Manual Chain Hoist, 1.5 Ton Capacity, 20ft of Lift, 18ft Hand Chain Drop, Overload Protection

1/2 - 5 metric ton Lifting Capacity; A new design for the modern workplace with safety and performance in mind. Meets or exceeds world specifications including ASME B30.16. A value-packed product with premium features at a great price.

Product Application/Uses:

Features and Benefits:

• Meets Specifications and HST - 2M standards
• Overload Protection to deter and reduce downtime and repair costs resulting from abuse
• All steel, low headroom, light weight construction
• Self-adjusting disc type double pawl mechanical load brake
• Hardened roller bearings for maximum efficiency and durability
• 4 layer finish of nickel, copper, nickel, and chrome - rugged enough to last
• Ideal for the Rental and Construction markets

Capacity (lb): 3300

Lift (ft): 20

IR SMB010-30-28V

SMB010-30-28V Manual Chain Hoist, 1 Ton Capacity, 30ft of Lift, 28ft Hand Chain Drop, Overload Protection

1/2 - 5 metric ton Lifting Capacity; A new design for the modern workplace with safety and performance in mind. Meets or exceeds world specifications including ASME B30.16. A value-packed product with premium features at a great price.

Product Application/Uses:

Features and Benefits:

• Meets Specifications and HST - 2M standards
• Overload Protection to deter and reduce downtime and repair costs resulting from abuse
• All steel, low headroom, light weight construction
• Self-adjusting disc type double pawl mechanical load brake
• Hardened roller bearings for maximum efficiency and durability
• 4 layer finish of nickel, copper, nickel, and chrome - rugged enough to last
• Ideal for the Rental and Construction markets

Capacity (lb): 2200

Lift (ft): 30

IR SMB015-30-28V

SMB015-30-28V Manual Chain Hoist, 1.5 Ton Capacity, 30ft of Lift, 28ft Hand Chain Drop, Overload Protection

1/2 - 5 metric ton Lifting Capacity; A new design for the modern workplace with safety and performance in mind. Meets or exceeds world specifications including ASME B30.16. A value-packed product with premium features at a great price.

Product Application/Uses:

Features and Benefits:

• Meets Specifications and HST - 2M standards
• Overload Protection to deter and reduce downtime and repair costs resulting from abuse
• All steel, low headroom, light weight construction
• Self-adjusting disc type double pawl mechanical load brake
• Hardened roller bearings for maximum efficiency and durability
• 4 layer finish of nickel, copper, nickel, and chrome - rugged enough to last
• Ideal for the Rental and Construction markets

Capacity (lb): 3300

Lift (ft): 30

IR SMB015-15-13V

SMB015-15-13V Manual Chain Hoist, 1.5 Ton Capacity, 15ft of Lift, 13ft Hand Chain Drop, Overload Protection

1/2 - 5 metric ton Lifting Capacity; A new design for the modern workplace with safety and performance in mind. Meets or exceeds world specifications including ASME B30.16. A value-packed product with premium features at a great price.

Product Application/Uses:

Features and Benefits:

• Meets Specifications and HST - 2M standards
• Overload Protection to deter and reduce downtime and repair costs resulting from abuse
• All steel, low headroom, light weight construction
• Self-adjusting disc type double pawl mechanical load brake
• Hardened roller bearings for maximum efficiency and durability
• 4 layer finish of nickel, copper, nickel, and chrome - rugged enough to last
• Ideal for the Rental and Construction markets

Capacity (lb): 3300

Lift (ft): 15

IR SMB020-10-8V

SMB020-10-8V Manual Chain Hoist, 2 Ton Capacity, 10ft of Lift, 8ft Hand Chain Drop, Overload Protection

1/2 - 5 metric ton Lifting Capacity; A new design for the modern workplace with safety and performance in mind. Meets or exceeds world specifications including ASME B30.16. A value-packed product with premium features at a great price.

Product Application/Uses:

Features and Benefits:

• Meets Specifications and HST - 2M standards
• Overload Protection to deter and reduce downtime and repair costs resulting from abuse
• All steel, low headroom, light weight construction
• Self-adjusting disc type double pawl mechanical load brake
• Hardened roller bearings for maximum efficiency and durability
• 4 layer finish of nickel, copper, nickel, and chrome - rugged enough to last
• Ideal for the Rental and Construction markets

Capacity (lb): 4400

Lift (ft): 10

IR SMB020-15-13V

SMB020-15-13V Manual Chain Hoist, 2 Ton Capacity, 15ft of Lift, 13ft Hand Chain Drop, Overload Protection

1/2 - 5 metric ton Lifting Capacity; A new design for the modern workplace with safety and performance in mind. Meets or exceeds world specifications including ASME B30.16. A value-packed product with premium features at a great price.

Product Application/Uses:

Features and Benefits:

• Meets Specifications and HST - 2M standards
• Overload Protection to deter and reduce downtime and repair costs resulting from abuse
• All steel, low headroom, light weight construction
• Self-adjusting disc type double pawl mechanical load brake
• Hardened roller bearings for maximum efficiency and durability
• 4 layer finish of nickel, copper, nickel, and chrome - rugged enough to last
• Ideal for the Rental and Construction markets

Capacity (lb): 4400

Lift (ft): 15

IR SMB020-20-18V

SMB020-20-18V Manual Chain Hoist, 2 Ton Capacity, 20ft of Lift, 18ft Hand Chain Drop, Overload Protection

1/2 - 5 metric ton Lifting Capacity; A new design for the modern workplace with safety and performance in mind. Meets or exceeds world specifications including ASME B30.16. A value-packed product with premium features at a great price.

Product Application/Uses:

Features and Benefits:

• Meets Specifications and HST - 2M standards
• Overload Protection to deter and reduce downtime and repair costs resulting from abuse
• All steel, low headroom, light weight construction
• Self-adjusting disc type double pawl mechanical load brake
• Hardened roller bearings for maximum efficiency and durability
• 4 layer finish of nickel, copper, nickel, and chrome - rugged enough to last
• Ideal for the Rental and Construction markets

Capacity (lb): 4400

Lift (ft): 20

IR SMB020-30-28V

SMB020-30-28V Manual Chain Hoist, 2 Ton Capacity, 30ft of Lift, 28ft Hand Chain Drop, Overload Protection

1/2 - 5 metric ton Lifting Capacity; A new design for the modern workplace with safety and performance in mind. Meets or exceeds world specifications including ASME B30.16. A value-packed product with premium features at a great price.

Product Application/Uses:

Features and Benefits:

• Meets Specifications and HST - 2M standards
• Overload Protection to deter and reduce downtime and repair costs resulting from abuse
• All steel, low headroom, light weight construction
• Self-adjusting disc type double pawl mechanical load brake
• Hardened roller bearings for maximum efficiency and durability
• 4 layer finish of nickel, copper, nickel, and chrome - rugged enough to last
• Ideal for the Rental and Construction markets

Capacity (lb): 4400

Lift (ft): 30

IR SMB030-10-8V

SMB030-10-8V Manual Chain Hoist, 3 Ton Capacity, 10ft of Lift, 8ft Hand Chain Drop, Overload Protection

1/2 - 5 metric ton Lifting Capacity; A new design for the modern workplace with safety and performance in mind. Meets or exceeds world specifications including ASME B30.16. A value-packed product with premium features at a great price.

Product Application/Uses:

Features and Benefits:

• Meets Specifications and HST - 2M standards
• Overload Protection to deter and reduce downtime and repair costs resulting from abuse
• All steel, low headroom, light weight construction
• Self-adjusting disc type double pawl mechanical load brake
• Hardened roller bearings for maximum efficiency and durability
• 4 layer finish of nickel, copper, nickel, and chrome - rugged enough to last
• Ideal for the Rental and Construction markets

Capacity (lb): 6600

Lift (ft): 10

IR SMB030-15-13V

SMB030-15-13V Manual Chain Hoist, 3 Ton Capacity, 15ft of Lift, 13ft Hand Chain Drop, Overload Protection

1/2 - 5 metric ton Lifting Capacity; A new design for the modern workplace with safety and performance in mind. Meets or exceeds world specifications including ASME B30.16. A value-packed product with premium features at a great price.

Product Application/Uses:

Features and Benefits:

• Meets Specifications and HST - 2M standards
• Overload Protection to deter and reduce downtime and repair costs resulting from abuse
• All steel, low headroom, light weight construction
• Self-adjusting disc type double pawl mechanical load brake
• Hardened roller bearings for maximum efficiency and durability
• 4 layer finish of nickel, copper, nickel, and chrome - rugged enough to last
• Ideal for the Rental and Construction markets

Capacity (lb): 6600

Lift (ft): 15

IR SMB030-20-18V

SMB030-20-18V Manual Chain Hoist, 3 Ton Capacity, 20ft of Lift, 18ft Hand Chain Drop, Overload Protection

1/2 - 5 metric ton Lifting Capacity; A new design for the modern workplace with safety and performance in mind. Meets or exceeds world specifications including ASME B30.16. A value-packed product with premium features at a great price.

Product Application/Uses:

Features and Benefits:

• Meets Specifications and HST - 2M standards
• Overload Protection to deter and reduce downtime and repair costs resulting from abuse
• All steel, low headroom, light weight construction
• Self-adjusting disc type double pawl mechanical load brake
• Hardened roller bearings for maximum efficiency and durability
• 4 layer finish of nickel, copper, nickel, and chrome - rugged enough to last
• Ideal for the Rental and Construction markets

Capacity (lb): 6600

Lift (ft): 20

IR SMB050-10-8V

SMB050-10-8V Manual Chain Hoist, 5 Ton Capacity, 10ft of Lift, 8ft Hand Chain Drop, Overload Protection

1/2 - 5 metric ton Lifting Capacity; A new design for the modern workplace with safety and performance in mind. Meets or exceeds world specifications including ASME B30.16. A value-packed product with premium features at a great price.

Product Application/Uses:

Features and Benefits:

• Meets Specifications and HST - 2M standards
• Overload Protection to deter and reduce downtime and repair costs resulting from abuse
• All steel, low headroom, light weight construction
• Self-adjusting disc type double pawl mechanical load brake
• Hardened roller bearings for maximum efficiency and durability
• 4 layer finish of nickel, copper, nickel, and chrome - rugged enough to last
• Ideal for the Rental and Construction markets

Capacity (lb): 11000

Lift (ft): 10

IR SMB030-30-28V

SMB030-30-28V Manual Chain Hoist, 3 Ton Capacity, 30ft of Lift, 28ft Hand Chain Drop, Overload Protection

1/2 - 5 metric ton Lifting Capacity; A new design for the modern workplace with safety and performance in mind. Meets or exceeds world specifications including ASME B30.16. A value-packed product with premium features at a great price.

Product Application/Uses:

Features and Benefits:

• Meets Specifications and HST - 2M standards
• Overload Protection to deter and reduce downtime and repair costs resulting from abuse
• All steel, low headroom, light weight construction
• Self-adjusting disc type double pawl mechanical load brake
• Hardened roller bearings for maximum efficiency and durability
• 4 layer finish of nickel, copper, nickel, and chrome - rugged enough to last
• Ideal for the Rental and Construction markets

Capacity (lb): 6600

Lift (ft): 30

IR SMB050-15-13V

SMB050-15-13V Manual Chain Hoist, 5 Ton Capacity, 15ft of Lift, 13ft Hand Chain Drop, Overload Protection

1/2 - 5 metric ton Lifting Capacity; A new design for the modern workplace with safety and performance in mind. Meets or exceeds world specifications including ASME B30.16. A value-packed product with premium features at a great price.

Product Application/Uses:

Features and Benefits:

• Meets Specifications and HST - 2M standards
• Overload Protection to deter and reduce downtime and repair costs resulting from abuse
• All steel, low headroom, light weight construction
• Self-adjusting disc type double pawl mechanical load brake
• Hardened roller bearings for maximum efficiency and durability
• 4 layer finish of nickel, copper, nickel, and chrome - rugged enough to last
• Ideal for the Rental and Construction markets

Capacity (lb): 11000

Lift (ft): 15

IR SMB050-20-18V

SMB050-20-18V Manual Chain Hoist, 5 Ton Capacity, 20ft of Lift, 18ft Hand Chain Drop, Overload Protection

1/2 - 5 metric ton Lifting Capacity; A new design for the modern workplace with safety and performance in mind. Meets or exceeds world specifications including ASME B30.16. A value-packed product with premium features at a great price.

Product Application/Uses:

Features and Benefits:

• Meets Specifications and HST - 2M standards
• Overload Protection to deter and reduce downtime and repair costs resulting from abuse
• All steel, low headroom, light weight construction
• Self-adjusting disc type double pawl mechanical load brake
• Hardened roller bearings for maximum efficiency and durability
• 4 layer finish of nickel, copper, nickel, and chrome - rugged enough to last
• Ideal for the Rental and Construction markets

Capacity (lb): 11000

Lift (ft): 20

IR SRV150SS

IR QA8AALS055NP35S08

IR QA6-A93

IR QA6-M37-4P27

IR QA8AALS090NP43S08

IR QA6ASRS025NF41S06

IR QA6AALD030NP35S06

IR QA6AALS055NP35S08

IR QA8AALS070NP43S08

IR QA6ASLS055NP41S08

IR QA8AALS115NP48S08

IR QA8-42-5

IR QA8AALS200NF56S12

IR QA8AALS150NP48S08

IR QA8ASLS055NP41S08

IR QA8ASLS070NP41S08

IR QA8ASLS090NP41S08

IR QA8ASLS150NF41S08

IR QA8ASLS180NF41S08

IR QA8ASRS055NF41S08

IR QA8ASRS070NF41S08

IR QA8ASRS090NF41S08
