GRACO INC. S10595

GG 24F108

PROMIX 2KE PROPORTIONER, SYSTEM, PUMP

Graco 24F108 ProMix 2KE Proportioner, air, 35:1 Air Assist Merkur & Merkur Bellows pumps, screen reporting, for hazardous location

The ProMix 2KE is an entry level, compact, easy to use plural component system allowing you to mix on-demand for all spray technologies.

• Designed for multi-color, two component, in-booth applications
• Choose between pump-based or meter-based plural component systems with mix ratios up to 30:1
• Stay on ratio within predefined tolerance limits, down to plus/minus 02% with the pump version, plus/minus 01% with meter
• Easy-to-use LCD display allows you to track material usage, display mix ratio, program maintenance reminders operate, control operation functions and more

• Model: ProMix
• Series: 2KE

• Air Inlet Size (cm): 0.9525
• Air Inlet Size (in): 3/8
• Air Inlet Size (mm): 9.525
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Amperage (A): 2
• Applicator Type: Manual Air-Assist

• Component Type: Two Component

• Flush Type: Solvent

• Frequency (Hz): 50/60

• Gun Activation: Manual

• Includes: Air Motor, A-Lower, B-Lower, A-Tie Rod, B-Tie Rod, Lower Adapter, TSL Reservoir

• Material Type: Two Component

• Maximum Air Inlet Pressure (bar): 6.9
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Fluid Viscosity (cP): 5000

• Maximum Fluid Viscosity (cP): 5000

• Maximum Mix Ratio: 30:1
• Maximum Number of Colors: Up to 3

• Maximum Working Pressure (bar): 241
• Maximum Working Pressure (kPa): 24100
• Maximum Working Pressure (MPa): 24.1
• Maximum Working Pressure (psi): 3500
• Measuring Type: Pump

• Minimum Fluid Viscosity (cP): 20
• Minimum Mix Ratio: 0.1:1

• Mix Accuracy (%): 1

• Number of Catalysts: 1
• Number of Color Valves: N/A
• Number of Colors: 1

• Number of Resin Colors: 1

• Overall Depth (cm): 37.6
• Overall Depth (in): 14.8
• Overall Depth (mm): 376

• Overall Height (cm): 91.7
• Overall Height (in): 36.1
• Overall Height (mm): 917
• Overall Width (cm): 51.1
• Overall Width (in): 20.1
• Overall Width (mm): 511

• Power Source: Air

• Proportioning Type: Manual Electronic

• Pump Ratio: 35:1
• Pump Type: Air-Assisted Bellows

GG 24F087

PROMIX 2KE PROPORTIONER, SYSTEM, METER

Graco 24F087 ProMix 2KE Proportioner, air, G3000 meter, 3 color/1 catalyst, USB reporting, for hazardous location

The ProMix 2KE is an entry level, compact, easy to use plural component system allowing you to mix on-demand for all spray technologies.

• Designed for multi-color, two component, in-booth applications
• Choose between pump-based or meter-based plural component systems with mix ratios up to 30:1
• Stay on ratio within predefined tolerance limits, down to plus/minus 02% with the pump version, plus/minus 01% with meter
• Easy-to-use LCD display allows you to track material usage, display mix ratio, program maintenance reminders operate, control operation functions and more

• Model: ProMix
• Series: 2KE

• Air Inlet Size (cm): 0.9525
• Air Inlet Size (in): 3/8
• Air Inlet Size (mm): 9.525
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Amperage (A): 2
• Applicator Type: Manual Air Spray, Air-Assist

• Component Type: Two Component

• Flush Type: Solvent

• Frequency (Hz): 50/60

• Gun Activation: Manual

• Includes: 2KE Meter-Based Proportioner, G3000 Meter, 3 Color, 1 Catalyst, USB Module

• Material Type: Two Component

• Maximum Air Inlet Pressure (bar): 6.9
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Flow Rate (cc/min): 3790

• Maximum Flow Rate (GPM): 1
• Maximum Flow Rate (L/min): 3.79

• Maximum Fluid Viscosity (cP): 5000

• Maximum Fluid Viscosity (cP): 5000

• Maximum Mix Ratio: 30:1
• Maximum Number of Colors: Up to 3

• Maximum Operating Temperature ( degree C): 50
• Maximum Operating Temperature ( degree F): 122

• Maximum Working Pressure (bar): 206.8
• Maximum Working Pressure (kPa): 20680
• Maximum Working Pressure (MPa): 20.7
• Maximum Working Pressure (psi): 3000
• Measuring Type: Meter

• Minimum Flow Rate (cc/min): 75
• Minimum Flow Rate (GPM): 0.02
• Minimum Flow Rate (L/min): 0.075

• Minimum Fluid Viscosity (cP): 20
• Minimum Mix Ratio: 0.1:1

• Mix Accuracy (%): 1

• Number of Catalysts: 1
• Number of Color Valves: N/A
• Number of Colors: 3

• Number of Resin Colors: 3

• Overall Depth (cm): 37.6
• Overall Depth (in): 14.8
• Overall Depth (mm): 376

• Overall Height (cm): 91.7
• Overall Height (in): 36.1
• Overall Height (mm): 917
• Overall Width (cm): 51.1
• Overall Width (in): 20.1
• Overall Width (mm): 511

• Power Source: Air

• Proportioning Type: Manual Electronic

• Pump Ratio: Meter only

GG 24F085

PROMIX 2KE PROPORTIONER, SYSTEM, METER

Graco 24F085 ProMix 2KE Proportioner, air, G3000 meter, 3 color/1 catalyst, screen reporting, for hazardous location

The ProMix 2KE is an entry level, compact, easy to use plural component system allowing you to mix on-demand for all spray technologies.

• Designed for multi-color, two component, in-booth applications
• Choose between pump-based or meter-based plural component systems with mix ratios up to 30:1
• Stay on ratio within predefined tolerance limits, down to plus/minus 02% with the pump version, plus/minus 01% with meter
• Easy-to-use LCD display allows you to track material usage, display mix ratio, program maintenance reminders operate, control operation functions and more

• Model: ProMix
• Series: 2KE

• Air Inlet Size (cm): 0.9525
• Air Inlet Size (in): 3/8
• Air Inlet Size (mm): 9.525
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Amperage (A): 2
• Applicator Type: Manual Air Spray, Air-Assist

• Component Type: Two Component

• Flush Type: Solvent

• Frequency (Hz): 50/60

• Gun Activation: Manual

• Includes: 2KE Meter-Based Proportioner, G3000 Meter, 3 Color, 1 Catalyst

• Material Type: Two Component

• Maximum Air Inlet Pressure (bar): 6.9
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Flow Rate (cc/min): 3790

• Maximum Flow Rate (GPM): 1
• Maximum Flow Rate (L/min): 3.79

• Maximum Fluid Viscosity (cP): 5000

• Maximum Fluid Viscosity (cP): 5000

• Maximum Mix Ratio: 30:1
• Maximum Number of Colors: Up to 3

• Maximum Operating Temperature ( degree C): 50
• Maximum Operating Temperature ( degree F): 122

• Maximum Working Pressure (bar): 206.8
• Maximum Working Pressure (kPa): 20680
• Maximum Working Pressure (MPa): 20.7
• Maximum Working Pressure (psi): 3000
• Measuring Type: Meter

• Minimum Flow Rate (cc/min): 75
• Minimum Flow Rate (GPM): 0.02
• Minimum Flow Rate (L/min): 0.075

• Minimum Fluid Viscosity (cP): 20
• Minimum Mix Ratio: 0.1:1

• Mix Accuracy (%): 1

• Number of Catalysts: 1
• Number of Color Valves: N/A
• Number of Colors: 3

• Number of Resin Colors: 3

• Overall Depth (cm): 37.6
• Overall Depth (in): 14.8
• Overall Depth (mm): 376

• Overall Height (cm): 91.7
• Overall Height (in): 36.1
• Overall Height (mm): 917
• Overall Width (cm): 51.1
• Overall Width (in): 20.1
• Overall Width (mm): 511

• Power Source: Air

• Proportioning Type: Manual Electronic

• Pump Ratio: Meter only

GG 24E916

GG 24F113

PROMIX 2KE PROPORTIONER, SYSTEM, PUMP

Graco 24F113 ProMix 2KE Proportioner, air, 3:1 Air Spray Merkur & Merkur Bellows pumps, USB reporting, for hazardous location

The ProMix 2KE is an entry level, compact, easy to use plural component system allowing you to mix on-demand for all spray technologies.

• Designed for multi-color, two component, in-booth applications
• Choose between pump-based or meter-based plural component systems with mix ratios up to 30:1
• Stay on ratio within predefined tolerance limits, down to plus/minus 02% with the pump version, plus/minus 01% with meter
• Easy-to-use LCD display allows you to track material usage, display mix ratio, program maintenance reminders operate, control operation functions and more

• Model: ProMix
• Series: 2KE

• Air Inlet Size (cm): 0.9525
• Air Inlet Size (in): 3/8
• Air Inlet Size (mm): 9.525
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Amperage (A): 2
• Applicator Type: Manual Air Spray

• Component Type: Two Component

• Flush Type: Solvent

• Frequency (Hz): 50/60

• Gun Activation: Manual

• Includes: Air Motor, Adapter Plate, A-Lower, B-Lower, A-Tie Rod, B-Tie Rod, Coupling, Lower Adapter, TSL Reservoir

• Material Type: Two Component

• Maximum Air Inlet Pressure (bar): 6.9
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Fluid Viscosity (cP): 5000

• Maximum Fluid Viscosity (cP): 5000

• Maximum Mix Ratio: 30:1
• Maximum Number of Colors: Up to 3

• Maximum Working Pressure (bar): 21
• Maximum Working Pressure (kPa): 2100
• Maximum Working Pressure (MPa): 2.1
• Maximum Working Pressure (psi): 300
• Measuring Type: Pump

• Minimum Fluid Viscosity (cP): 20
• Minimum Mix Ratio: 0.1:1

• Mix Accuracy (%): 1

• Number of Catalysts: 1
• Number of Color Valves: N/A
• Number of Colors: 1

• Number of Resin Colors: 1

• Overall Depth (cm): 37.6
• Overall Depth (in): 14.8
• Overall Depth (mm): 376

• Overall Height (cm): 91.7
• Overall Height (in): 36.1
• Overall Height (mm): 917
• Overall Width (cm): 51.1
• Overall Width (in): 20.1
• Overall Width (mm): 511

• Power Source: Air

• Proportioning Type: Manual Electronic

• Pump Ratio: 3:1
• Pump Type: Air Spray Bellows

GG 24F144

GG 24F150

MERKUR SPRAYER, ES, AA, 15:1, CS, WALL

Graco 24F150 15:1 Merkur ES Air Assisted Package, 0.4 gpm (1.5 lpm) fluid flow, wall mount, with PerformAA 15 gun, suction hose, and plated steel

The Merkur ES is one of the most efficient sprayers designed to use less material than the competition and to reduce air usage and pulsation.

• Quick flush system requires less than 1 minute to flush
• 45% less material to fill the system than the leading competitors
• Delivers a superior, consistent spray finish
• Easily set and monitor air control, plus an integrated carrying handle for transport
• Air motor provides consistent finishes with smooth, rapid changeover
• Suction hose and strainer leaves less material in the supply container
• Lightweight, flexible 1/8 in fluid hose reduces material and solvent usage

• Model: Merkur
• Series: ES

• Convertible: Non-Convertible

• Fluid Outlet Size (cm): 0.635
• Fluid Outlet Size (in): 1/4
• Fluid Outlet Size (mm): 6.35
• Fluid Outlet Thread Type: NPSM

• Gun Included: 1
• Gun Model: G15
• Gun Technology: Air-Assisted
• Gun Type: Air-Assisted

• Hose Inlet Diameter (cm): 0.3175
• Hose Inlet Diameter (in): 0.125
• Hose Inlet Diameter (mm): 3

• Includes: G15 Gun, Suction Hose, Wall Mount

• Maximum Flow Rate (GPM): 0.4

• Maximum Hose Length (ft): 25
• Maximum Hose Length (m): 7.6

• Maximum Sound Pressure Level (dB(A)): 76.5

• Maximum Tip Size (cm): 0.0483
• Maximum Tip Size (in): 0.019
• Maximum Tip Size (mm): 0.4826

• Maximum Working Pressure (bar): 103
• Maximum Working Pressure (kPa): 10300
• Maximum Working Pressure (MPa): 10.3
• Maximum Working Pressure (psi): 1500

• Motor Type: Pneumatic

• Mount Type: Wall Mount

• Number of Guns: 1

• Power Source: Air

• Pressure Type: High Pressure
• Product Type: Spray Package

• Pump Ratio: 15:1
• Pump Sleeve Material: Carbon Steel
• Pump Type: Pneumatic Piston Pump

GG 24F148

KIT, HOSE, SUCTION, 5 GAL, 3/8 OD

Graco 24F148 Suction hose, 3/8" OD, for 5 gal (18.9 l) pail

GG 24F152

MERKUR SPRAYER, ES, AA, 30:1, SST, WALL

Graco 24F152 30:1 Merkur ES Air Assisted Package, 0.4 gpm (1.5 lpm) fluid flow, wall mount, with PerformAA 50 gun, suction hose, and stainless steel

The Merkur ES is one of the most efficient sprayers designed to use less material than the competition and to reduce air usage and pulsation.

• Quick flush system requires less than 1 minute to flush
• 45% less material to fill the system than the leading competitors
• Delivers a superior, consistent spray finish
• Easily set and monitor air control, plus an integrated carrying handle for transport
• Air motor provides consistent finishes with smooth, rapid changeover
• Suction hose and strainer leaves less material in the supply container
• Lightweight, flexible 1/8 in fluid hose reduces material and solvent usage

• Model: Merkur
• Series: ES

• Convertible: Non-Convertible

• Fluid Outlet Size (cm): 0.635
• Fluid Outlet Size (in): 1/4
• Fluid Outlet Size (mm): 6.35
• Fluid Outlet Thread Type: NPSM

• Gun Included: 1
• Gun Model: G40
• Gun Technology: Air-Assisted
• Gun Type: Air-Assisted

• Hose Inlet Diameter (cm): 0.3175
• Hose Inlet Diameter (in): 0.125
• Hose Inlet Diameter (mm): 3

• Includes: G40 Gun, Suction Hose, Wall Mount

• Maximum Flow Rate (GPM): 0.4

• Maximum Hose Length (ft): 25
• Maximum Hose Length (m): 7.6

• Maximum Sound Pressure Level (dB(A)): 77.9

• Maximum Tip Size (cm): 0.0483
• Maximum Tip Size (in): 0.019
• Maximum Tip Size (mm): 0.4826

• Maximum Working Pressure (bar): 207
• Maximum Working Pressure (kPa): 20700
• Maximum Working Pressure (MPa): 20.7
• Maximum Working Pressure (psi): 3000

• Motor Type: Pneumatic

• Mount Type: Wall Mount

• Number of Guns: 1

• Power Source: Air

• Pressure Type: High Pressure
• Product Type: Spray Package

• Pump Ratio: 30:1
• Pump Sleeve Material: Stainless Steel
• Pump Type: Pneumatic Piston Pump

GG 24F151

MERKUR SPRAYER, ES, AA, 15:1, CS, STAND

Graco 24F151 15:1 Merkur ES Air Assisted Package, 0.4 gpm (1.5 lpm) fluid flow, standard mount, with PerformAA 15 gun, suction hose, and plated steel

The Merkur ES is one of the most efficient sprayers designed to use less material than the competition and to reduce air usage and pulsation.

• Quick flush system requires less than 1 minute to flush
• 45% less material to fill the system than the leading competitors
• Delivers a superior, consistent spray finish
• Easily set and monitor air control, plus an integrated carrying handle for transport
• Air motor provides consistent finishes with smooth, rapid changeover
• Suction hose and strainer leaves less material in the supply container
• Lightweight, flexible 1/8 in fluid hose reduces material and solvent usage

• Model: Merkur
• Series: ES

• Convertible: Non-Convertible

• Fluid Outlet Size (cm): 0.635
• Fluid Outlet Size (in): 1/4
• Fluid Outlet Size (mm): 6.35
• Fluid Outlet Thread Type: NPSM

• Gun Included: 1
• Gun Model: G15
• Gun Technology: Air-Assisted
• Gun Type: Air-Assisted

• Hose Inlet Diameter (cm): 0.3175
• Hose Inlet Diameter (in): 0.125
• Hose Inlet Diameter (mm): 3

• Includes: G15 Gun, Suction Hose, Stand Mount

• Maximum Flow Rate (GPM): 0.4

• Maximum Hose Length (ft): 25
• Maximum Hose Length (m): 7.6

• Maximum Sound Pressure Level (dB(A)): 76.5

• Maximum Tip Size (cm): 0.0483
• Maximum Tip Size (in): 0.019
• Maximum Tip Size (mm): 0.4826

• Maximum Working Pressure (bar): 103
• Maximum Working Pressure (kPa): 10300
• Maximum Working Pressure (MPa): 10.3
• Maximum Working Pressure (psi): 1500

• Motor Type: Pneumatic

• Mount Type: Stand Mount

• Number of Guns: 1

• Power Source: Air

• Pressure Type: High Pressure
• Product Type: Spray Package

• Pump Ratio: 15:1
• Pump Sleeve Material: Carbon Steel
• Pump Type: Pneumatic Piston Pump

GG 24F153

MERKUR SPRAYER, ES, AA, 30:1, SST, STAND

Graco 24F153 30:1 Merkur ES Air Assisted Package, 0.4 gpm (1.5 lpm) fluid flow, standard mount, with PerformAA 50 gun, suction hose, and stainless steel

The Merkur ES is one of the most efficient sprayers designed to use less material than the competition and to reduce air usage and pulsation.

• Quick flush system requires less than 1 minute to flush
• 45% less material to fill the system than the leading competitors
• Delivers a superior, consistent spray finish
• Easily set and monitor air control, plus an integrated carrying handle for transport
• Air motor provides consistent finishes with smooth, rapid changeover
• Suction hose and strainer leaves less material in the supply container
• Lightweight, flexible 1/8 in fluid hose reduces material and solvent usage

• Model: Merkur
• Series: ES

• Convertible: Non-Convertible

• Fluid Outlet Size (cm): 0.635
• Fluid Outlet Size (in): 1/4
• Fluid Outlet Size (mm): 6.35
• Fluid Outlet Thread Type: NPSM

• Gun Included: 1
• Gun Model: G40
• Gun Technology: Air-Assisted
• Gun Type: Air-Assisted

• Hose Inlet Diameter (cm): 0.3175
• Hose Inlet Diameter (in): 0.125
• Hose Inlet Diameter (mm): 3

• Includes: G40 Gun, Suction Hose, Stand Mount

• Maximum Flow Rate (GPM): 0.4

• Maximum Hose Length (ft): 25
• Maximum Hose Length (m): 7.6

• Maximum Sound Pressure Level (dB(A)): 77.9

• Maximum Tip Size (cm): 0.0483
• Maximum Tip Size (in): 0.019
• Maximum Tip Size (mm): 0.4826

• Maximum Working Pressure (bar): 207
• Maximum Working Pressure (kPa): 20700
• Maximum Working Pressure (MPa): 20.7
• Maximum Working Pressure (psi): 3000

• Motor Type: Pneumatic

• Mount Type: Stand Mount

• Number of Guns: 1

• Power Source: Air

• Pressure Type: High Pressure
• Product Type: Spray Package

• Pump Ratio: 30:1
• Pump Sleeve Material: Stainless Steel
• Pump Type: Pneumatic Piston Pump

GG 24F155

GG 24F156

MERKUR SPRAYER, ES, AA, 30:1, CS, WALL

Graco 24F156 30:1 Merkur ES Air Assisted Package, 0.4 gpm (1.5 lpm) fluid flow, wall mount, with PerfermAA 50 gun, suction hose, and plated steel

The Merkur ES is one of the most efficient sprayers designed to use less material than the competition and to reduce air usage and pulsation.

• Quick flush system requires less than 1 minute to flush
• 45% less material to fill the system than the leading competitors
• Delivers a superior, consistent spray finish
• Easily set and monitor air control, plus an integrated carrying handle for transport
• Air motor provides consistent finishes with smooth, rapid changeover
• Suction hose and strainer leaves less material in the supply container
• Lightweight, flexible 1/8 in fluid hose reduces material and solvent usage

• Model: Merkur
• Series: ES

• Convertible: Non-Convertible

• Fluid Outlet Size (in): 1/4
• Fluid Outlet Size (mm): 6.35
• Fluid Outlet Thread Type: NPSM

• Gun Included: 1
• Gun Model: G40
• Gun Technology: Air-Assisted
• Gun Type: Air-Assisted

• Hose Inlet Diameter (cm): 0.3175
• Hose Inlet Diameter (in): 1/8
• Hose Inlet Diameter (mm): 3

• Includes: G40 Gun, Suction Hose, Wall Mount

• Maximum Flow Rate (GPM): 0.40
• Maximum Flow Rate (L/min): 1.5

• Maximum Hose Length (ft): 25
• Maximum Hose Length (m): 7.5

• Maximum Tip Size (in): 0.019

• Maximum Working Pressure (bar): 207
• Maximum Working Pressure (kPa): 20700
• Maximum Working Pressure (MPa): 20.7
• Maximum Working Pressure (psi): 3000

• Motor Type: Pneumatic

• Mount Type: Wall Mount

• Number of Guns: 1

• Power Source: Air

• Pressure Type: High Pressure
• Product Type: Spray Package

• Pump Ratio: 30:1
• Pump Type: Pneumatic Piston Pump

GG 24F157

MERKUR SPRAYER, ES, AA, 30:1, CS, STAND

Graco 24F157 30:1 Merkur ES Air Assisted Package, 0.4 gpm (1.5 lpm) fluid flow, standard mount, with PerformAA 50 gun, suction hose, and plated steel

The Merkur ES is one of the most efficient sprayers designed to use less material than the competition and to reduce air usage and pulsation.

• Quick flush system requires less than 1 minute to flush
• 45% less material to fill the system than the leading competitors
• Delivers a superior, consistent spray finish
• Easily set and monitor air control, plus an integrated carrying handle for transport
• Air motor provides consistent finishes with smooth, rapid changeover
• Suction hose and strainer leaves less material in the supply container
• Lightweight, flexible 1/8 in fluid hose reduces material and solvent usage

• Model: Merkur
• Series: ES

• Convertible: Non-Convertible

• Fluid Outlet Size (cm): 0.635
• Fluid Outlet Size (in): 1/4
• Fluid Outlet Size (mm): 6.35
• Fluid Outlet Thread Type: NPSM

• Gun Included: 1
• Gun Model: PerformAA 50 Air Assist
• Gun Technology: Air-Assisted
• Gun Type: Air-Assisted

• Hose Inlet Diameter (cm): 0.3175
• Hose Inlet Diameter (in): 0.125
• Hose Inlet Diameter (mm): 3

• Includes: PerformAA 50 Gun, Suction Hose, Stand Mount,

• Maximum Flow Rate (GPM): 0.4

• Maximum Hose Length (ft): 25
• Maximum Hose Length (m): 7.6

• Maximum Sound Pressure Level (dB(A)): 77.9

• Maximum Tip Size (cm): 0.0483
• Maximum Tip Size (in): 0.019
• Maximum Tip Size (mm): 0.4826

• Maximum Working Pressure (bar): 207
• Maximum Working Pressure (kPa): 20700
• Maximum Working Pressure (MPa): 20.7
• Maximum Working Pressure (psi): 3000

• Motor Type: Pneumatic

• Mount Type: Stand Mount

• Number of Guns: 1

• Power Source: Air

• Pressure Type: High Pressure
• Product Type: Spray Package

• Pump Ratio: 30:1
• Pump Sleeve Material: Carbon Steel
• Pump Type: Pneumatic Piston Pump

GG 24F159

MERKUR SPRAYER, ES, AA, 15:1, SST, STAND

Graco 24F159 15:1 Merkur ES Air Assisted Package, 0.4 gpm (1.5 lpm) fluid flow, standard mount, with PerformAA 15 gun, suction hose, and stainless steel

The Merkur ES is one of the most efficient sprayers designed to use less material than the competition and to reduce air usage and pulsation.

• Quick flush system requires less than 1 minute to flush
• 45% less material to fill the system than the leading competitors
• Delivers a superior, consistent spray finish
• Easily set and monitor air control, plus an integrated carrying handle for transport
• Air motor provides consistent finishes with smooth, rapid changeover
• Suction hose and strainer leaves less material in the supply container
• Lightweight, flexible 1/8 in fluid hose reduces material and solvent usage

• Model: Merkur
• Series: ES

• Convertible: Non-Convertible

• Fluid Outlet Size (cm): 0.635
• Fluid Outlet Size (in): 1/4
• Fluid Outlet Size (mm): 6.35
• Fluid Outlet Thread Type: NPSM

• Gun Included: 1
• Gun Model: G15
• Gun Technology: Air-Assisted
• Gun Type: Air-Assisted

• Hose Inlet Diameter (cm): 0.3175
• Hose Inlet Diameter (in): 0.125
• Hose Inlet Diameter (mm): 3

• Includes: G15 Gun, Suction Hose, Stand Mount

• Maximum Flow Rate (GPM): 0.4

• Maximum Hose Length (ft): 25
• Maximum Hose Length (m): 7.6

• Maximum Sound Pressure Level (dB(A)): 76.5

• Maximum Tip Size (cm): 0.0483
• Maximum Tip Size (in): 0.019
• Maximum Tip Size (mm): 0.4826

• Maximum Working Pressure (bar): 103
• Maximum Working Pressure (kPa): 10300
• Maximum Working Pressure (MPa): 10.3
• Maximum Working Pressure (psi): 1500

• Motor Type: Pneumatic

• Mount Type: Stand Mount

• Number of Guns: 1

• Power Source: Air

• Pressure Type: High Pressure
• Product Type: Spray Package

• Pump Ratio: 15:1
• Pump Sleeve Material: Stainless Steel
• Pump Type: Pneumatic Piston Pump

GG 24F158

MERKUR SPRAYER, ES, AA, 15:1, SST, WAL

Graco 24F158 15:1 Merkur ES Air Assisted Package, 0.4 gpm (1.5 lpm) fluid flow, wall mount, with PerformAA 15 gun, suction hose, and stainless steel

The Merkur ES is one of the most efficient sprayers designed to use less material than the competition and to reduce air usage and pulsation.

• Quick flush system requires less than 1 minute to flush
• 45% less material to fill the system than the leading competitors
• Delivers a superior, consistent spray finish
• Easily set and monitor air control, plus an integrated carrying handle for transport
• Air motor provides consistent finishes with smooth, rapid changeover
• Suction hose and strainer leaves less material in the supply container
• Lightweight, flexible 1/8 in fluid hose reduces material and solvent usage

• Model: Merkur
• Series: ES

• Convertible: Non-Convertible

• Fluid Outlet Size (cm): 0.635
• Fluid Outlet Size (in): 1/4
• Fluid Outlet Size (mm): 6.35
• Fluid Outlet Thread Type: NPSM

• Gun Included: 1
• Gun Model: G15
• Gun Technology: Air-Assisted
• Gun Type: Air-Assisted

• Hose Inlet Diameter (cm): 0.3175
• Hose Inlet Diameter (in): 0.125
• Hose Inlet Diameter (mm): 3

• Includes: G15 Gun, Suction Hose, Wall Mount

• Maximum Flow Rate (GPM): 0.4

• Maximum Hose Length (ft): 25
• Maximum Hose Length (m): 7.6

• Maximum Sound Pressure Level (dB(A)): 76.5

• Maximum Tip Size (cm): 0.0483
• Maximum Tip Size (in): 0.019
• Maximum Tip Size (mm): 0.4826

• Maximum Working Pressure (bar): 103
• Maximum Working Pressure (kPa): 10300
• Maximum Working Pressure (MPa): 10.3
• Maximum Working Pressure (psi): 1500

• Motor Type: Pneumatic

• Mount Type: Wall Mount

• Number of Guns: 1

• Power Source: Air

• Pressure Type: High Pressure
• Product Type: Spray Package

• Pump Ratio: 15:1
• Pump Sleeve Material: Stainless Steel
• Pump Type: Pneumatic Piston Pump

GG 24F160

GG 24F166

KIT, HOSE, FLUID, 25FT, SST

Graco 24F166 Fluid Hose, 1/8" ID, 25 ft (7.5 m), stainless steel

GG 24F195

SANIFORCE PISTON PUMP, 5:1 DB DL

Graco 24F195 5:1 Ratio SaniForce Double Ball Stubby Piston Pump with 4 in Inlet

The SaniForce 5:1 transfer piston pump is constructed of 300 series stainless steel, with a 2 inch (50.8 mm) sanitary tube flange outlet and can be fitted into open-head drums or directly inserted into a 4.5 inch (114 mm) closed-head drum bung. Our sanitary piston pumps are ideal for most food-related, cosmetic and personal care applications.

• Available in double-ball and priming piston designs
• Fluid transfer and supply of low to medium viscosity fluids
• Suitable to pump products such as: cosmetics, fruit juice concentrates, creamy candy fillings, ice cream variegates, jams and jellies

• Model: SaniForce

• Air Inlet Size (in): 0.5
• Air Inlet Size (mm): 12.7
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPSM

• Application: Sanitary

• Compatible Material: Food, Personal Care

• Fluid Outlet Size (in): 2
• Fluid Outlet Size (mm): 50.8

• For Use With: Food, Personal Care, & Pharmaceutical

• Maximum Air Consumption (SCFM): 75
• Maximum Air Inlet Pressure (bar): 5.5
• Maximum Air Inlet Pressure (kPa): 550
• Maximum Air Inlet Pressure (psi): 80

• Maximum Continuous Cycle Rate (CPM): 60

• Maximum Flow Rate (GPM): 14
• Maximum Flow Rate (L/min): 53

• Maximum Intermittent Cycle Rate (CPM): 60

• Maximum Working Pressure (bar): 28.3
• Maximum Working Pressure (kPa): 2830
• Maximum Working Pressure (MPa): 2.8
• Maximum Working Pressure (psi): 410

• Pump Ratio: 5:1

GG 24F202

AIRPRO GUN, PRESSURE, CONV

Graco 24F202 AirPro Air Spray Pressure Feed Gun, Conventional, 0.042 inch (1.1 mm) Nozzle, Air Brush Applications

The AirPro air spray gun delivers exceptional spray performance while addressing your environmental and operator concerns - whether you're a custom shop or a high volume manufacturing facility.

• Even material distribution through the spray pattern for optimum coverage
• Improved transfer efficiency through reduced air consumption
• Enhanced atomization through material-specific aircaps
• Ultra-light trigger pull reduces operator muscle stress
• Ergonomic gun handle provides a comfortable grip
• Rounded control knobs for operator comfort
• Optimize spray performance with our cutting edge aircap and nozzle design
• Choose from a wide range of gun models to meet the needs of your specific application

• Model: AirPro

• Air Inlet Size (cm): 0.635
• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35
• Air Inlet Thread Type: NPSM

• Application: Air Brush
• Applicator Type: Manual

• Bleed Type: Non-Bleeder

• Compatible Material: Latex, Plural Component Materials, Sealants, Solvent borne, Urethane, Waterborne

• Feed Type: Pressure Feed

• Fluid Inlet Size (cm): 0.9525
• Fluid Inlet Size (in): 3/8
• Fluid Inlet Size (mm): 9.525
• Fluid Inlet Thread Type: NPSM
• Fluid Orifice Size (cm): 0.11
• Fluid Orifice Size (in): 0.042
• Fluid Orifice Size (mm): 1.1

• Gun Activation: Manual
• Gun Included: 1
• Gun Type: Conventional Gun
• Gun Weight (g): 410

• Includes: Air Cap, Needle Assembly, Nozzle, Tool Kit

• Maximum Air Inlet Pressure (bar): 7
• Maximum Air Inlet Pressure (kPa): 700
• Maximum Air Inlet Pressure (MPa): 0.7
• Maximum Air Inlet Pressure (psi): 100
• Maximum Air Pressure (bar): 7

• Maximum Air Pressure (kPa): 700
• Maximum Air Pressure (MPa): 0.7
• Maximum Air Pressure (psi): 100

• Maximum Fluid Pressure (bar): 21
• Maximum Fluid Pressure (kPa): 2100
• Maximum Fluid Pressure (MPa): 2.1
• Maximum Fluid Pressure (psi): 300
• Maximum Fluid Temperature ( degree C): 43
• Maximum Fluid Temperature ( degree F): 109

• Maximum Fluid Pressure (bar): 21
• Maximum Fluid Pressure (kPa): 2100
• Maximum Fluid Pressure (MPa): 2.1
• Maximum Fluid Pressure (psi): 300
• Maximum Fluid Temperature ( degree C): 43
• Maximum Fluid Temperature ( degree F): 109

• Product Type: Spray Gun

GG 24F245

KIT,REPAIR,THROAT,UHMWPE/LEAT

Graco 24F245 Standard Throat Packing Kit for 4-Ball Lowers

• Chop Gun Type: Without Cutter

• Compatible Material: Polyester Resin, Gel-Coat

GG 24F251

GG 24F271

GG 24F272

GG 24F295

GG 24F297

MODULE,ACPP,230V,MTO

GG 24F398

KIT, DIAPHRAGM-F1 PS

Graco 24F398 PTFE/Santoprene 2-Piece Diaphragm Kit for 1.5-inch Pump

GG 24F140

KIT, REPAIR, SEAT

Graco 24F140 Seat Repair Kit for Low Flow Fluid Regulator

• Compatible Material: Gel Coat, Polyester Resin

GG 24F399

KIT, DIAPHRAGM-H1 PS

Graco 24F399 PTFE/Santoprene 2-Piece Diaphragm Kit for 2-inch Pump

GG 24F404

KIT, CHECKS

Graco 24F404 TSL Check Valve Repair Kit for 4-Ball Lowers

GG 24F456

GG 24F458

GG 24F490

GG 24F516

FLUID,CARTON,1QT,6-PACK

Graco 24F516 IsoGuard Select

GG 24F529

NOZZLE, W/SWIVEL, DEF

Graco 24F529 SD Automatic Shut-Off SST Blue Nozzle with Swivel - 3/4 in. - BSPP

Designed to perform in heavy-equipment shops, fleet maintenance

shops, municipal garages and higher-volume in-plant applications

with longer plumbing runs and larger fluid usage.

Application: Typical applications include automotive and heavy-duty dealerships, agriculture, service and fast lube centers, and fleet service facilities.

• Heavy-duty design
• Automatic shut-off valve with stainless steel nozzle
• 11 gpm (41.6 lpm) flow rate
• 3/4 in BSPP inlet

• Model: SD

• Compatible Material: Diesel Exhaust Fluid

• Extension Type: Rigid

• Inlet Size (cm): 1.27
• Inlet Size (in): 1/2
• Inlet Size (mm): 12.7

• Inlet Thread Type: BSPP

• Maximum Working Pressure (bar): 3.5
• Maximum Working Pressure (kPa): 35
• Maximum Working Pressure (psi): 50

• Outlet Size (cm): 1.27
• Outlet Size (in): 1/2
• Outlet Size (mm): 12.7
• Outlet Thread Type: BSPP

GG 24F597

PLATE, BASE, 4 SECTION, MHH

Graco 24F597 Manzel MHH Divider Valve - 4 Section Base Plate Assemblies - NPSF

Same capable design as the Trabon MSP Series, with even tighter and more exacting tolerances. The Manzel MHH Series delivers highly accurate lube delivery for demanding high pressure grease and oil applications.

• Quick change valve sections can be removed from the base assembly without disturbing any lube lines - minimizing labor cost and maximizing your machine uptime.
• Can be easily accessorized with magnetic and electronic proximity switch cycle indicators to provide positive assurance of a successful lube event.
• Alternate outlet on face of valves can be fitted with optional performance indicators, taking the guesswork out of troubleshooting.

• Model: Manzel
• Series: MHH

• Application: In-Plant Machinery, Compressor Equipment

• Compatible Material: Oil, Grease

• Discharge Per Piston Stroke (in cu ): N/A

• Divider Valve Series: MHH

• Inlet Thread Type: NPSF

• Material: Steel

• Maximum NLGI Grade: #2

• Maximum Working Pressure (bar): 517
• Maximum Working Pressure (kPa): 51700
• Maximum Working Pressure (psi): 7500

• Number of Outlets: 8

• Outlet Thread Type: NPSF

GG 24F599

PLATE, BASE, 6 SECTION, MHH

Graco 24F599 Manzel MHH Divider Valve - 6 Section Base Plate Assemblies - NPSF

Same capable design as the Trabon MSP Series, with even tighter and more exacting tolerances. The Manzel MHH Series delivers highly accurate lube delivery for demanding high pressure grease and oil applications.

• Quick change valve sections can be removed from the base assembly without disturbing any lube lines - minimizing labor cost and maximizing your machine uptime.
• Can be easily accessorized with magnetic and electronic proximity switch cycle indicators to provide positive assurance of a successful lube event.
• Alternate outlet on face of valves can be fitted with optional performance indicators, taking the guesswork out of troubleshooting.

• Model: Manzel
• Series: MHH

• Application: In-Plant Machinery, Compressor Equipment

• Compatible Material: Oil, Grease

• Discharge Per Piston Stroke (in cu ): N/A

• Divider Valve Series: MHH

• Inlet Thread Type: NPSF

• Material: Steel

• Maximum NLGI Grade: #2

• Maximum Working Pressure (bar): 517
• Maximum Working Pressure (kPa): 51700
• Maximum Working Pressure (psi): 7500

• Number of Outlets: 12

• Outlet Thread Type: NPSF

GG 24F617

KIT, REPAIR, MINI PUMP SEALS

Graco 24F617 TSL Pump Repair Kit for 4-Ball Lower Pumps

GG 24F620

GG 24F625

SANIFORCE PISTON PUMP, 12:1 PP ST

Graco 24F625 SaniForce 12:1 Stubby Piston Pump

Gracos sanitary piston pumps are ideal for most food-related, cosmetic and personal care applications. The SaniForce 12:1 sanitary piston pump has flow rates up to 8.5 gpm (32 lpm) and maximum viscosity up to 1,000,000 cps when mounted on a drum or bin unloader.

• Quick knockdown lower
• Suitable to pump products such as: cosmetics, fruit juice concentrates, creamy candy fillings, ice cream variegates, jams and jellies
• Product highlights:

  Quick knockdown lowers are made with 300 series stainless steel for fast cleaning and long-lasting durability

  Easily removable FDA-compliant shroud to clean and access modular air valve - reducing downtime

  Most advanced air motor on the market




  • Model: SaniForce
  • Air Inlet Thread Gender: Female
  • Air Inlet Thread Type: NPSM
  • Application: Sanitary
  • Compatible Material: Food, Personal Care
  • Fluid Outlet Size (in): 2
  • Fluid Outlet Size (mm): 50.8
  • For Use With: Food, Personal Care, & Pharmaceutical
  • Material: Stainless Steel
  • Maximum Air Consumption (SCFM): 128
  • Maximum Air Inlet Pressure (bar): 6.9
  • Maximum Air Inlet Pressure (kPa): 690
  • Maximum Air Inlet Pressure (psi): 100
  • Maximum Continuous Cycle Rate (CPM): 60
  • Maximum Flow Rate (GPM): 8.5
  • Maximum Flow Rate (L/min): 32.18
  • Maximum Intermittent Cycle Rate (CPM): 60
  • Maximum Working Pressure (bar): 100.4
  • Maximum Working Pressure (kPa): 10040
  • Maximum Working Pressure (MPa): 10
  • Maximum Working Pressure (psi): 1450
  • Portable: Non-Portable
  • Pump Ratio: 12:1

GG 24F626

SANIFORCE PISTON PUMP, 12:1 PPC ST

Graco 24F626 SaniForce 12:1 Stubby Piston Pump for Sticky Viscous Material

Gracos sanitary piston pumps are ideal for most food-related, cosmetic and personal care applications. The SaniForce 12:1 sanitary piston pump has flow rates up to 8.5 gpm (32 lpm) and maximum viscosity up to 1,000,000 cps when mounted on a drum or bin unloader.

• Quick knockdown lower
• Suitable to pump products such as: cosmetics, fruit juice concentrates, creamy candy fillings, ice cream variegates, jams and jellies
• Product highlights:

  Quick knockdown lowers are made with 300 series stainless steel for fast cleaning and long-lasting durability

  Easily removable FDA-compliant shroud to clean and access modular air valve - reducing downtime

  Most advanced air motor on the market




  • Model: SaniForce
  • Air Inlet Thread Gender: Female
  • Air Inlet Thread Type: NPSM
  • Application: Sanitary
  • Compatible Material: Food, Personal Care
  • Fluid Outlet Size (in): 2
  • Fluid Outlet Size (mm): 50.8
  • For Use With: Food, Personal Care, & Pharmaceutical
  • Material: Stainless Steel
  • Maximum Air Consumption (SCFM): 128
  • Maximum Air Inlet Pressure (bar): 6.9
  • Maximum Air Inlet Pressure (kPa): 690
  • Maximum Air Inlet Pressure (psi): 100
  • Maximum Continuous Cycle Rate (CPM): 60
  • Maximum Flow Rate (GPM): 8.5
  • Maximum Flow Rate (L/min): 32.18
  • Maximum Intermittent Cycle Rate (CPM): 60
  • Maximum Working Pressure (bar): 100
  • Maximum Working Pressure (kPa): 10000
  • Maximum Working Pressure (MPa): 10
  • Maximum Working Pressure (psi): 1450
  • Portable: Non-Portable
  • Pump Ratio: 12:1

GG 24F660

KIT, REPAIR, SEAL, 750 CC

Graco 24F660 Complete Pump Repair Kit for 750 cc Lower Pumps

GG 24F661

KIT, REPAIR, SEAL, 1000 CC

Graco 24F661 Complete Pump Repair Kit for 1000 cc Lower Pumps

GG 24F662

KIT, REPAIR, SEAL, 1500 CC

Graco 24F662 Complete Pump Repair Kit for 1500 cc Lower Pumps

GG 24F902

GG 24F903

GG 24F915

CART, 180 KG

Graco 24F915 LD Series 50:1 Grease Pump Drum Cart with Pneumatic Wheels for 400 lb. Drums, Includes Chain for Securing Drum to Cart

• Drum cart with pneumatic wheels for 400 lb drums
• Includes chain for securing drum to cart

GG 24F910

GG 24G588

LD SERIES OIL PUMP, 5:1, UNIVERSAL, NPT

Graco 24G588 LD Series 5:1 Universal Oil Pump with Bung Adapter - NPT

The LD Series Pumps offer amazing performance at an amazingly competitive price. These affordable and full-featured pumps are designed for low volume applications to provide long life and serviceability. LD has a powerful three inch air motor to deliver the fluids you need while the built-in thermal relief protects your equipment from thermal expansion.

• Three Inch Air Motor - Provides more power to create better flow.
• Innovative Air Valve - Designed to reduce icing in continuous use applications and uses less air than competitive pumps for better efficiency. Easy to repair or replace without tearing down internal pump components for less downtime.
• Engineered for Durability - Patent-pending cup and plate design eliminates the need for O-rings that wear out faster for a more durable, longer-lasting solution.
• Pilot Valve - Patent-pending, self-cleaning design increases reliability in dirty air environments and minimizes pressure drop with rapid changeovers for reduced stalling and smoother flow.
• Adjustable Bung Adapter Included - Built-in slide adjustment with easy-set hand screws can fit into more applications.
• Built-In Thermal Relief and Inlet Strainer - Built-in thermal relief protects your equipment from thermal expansion without the need to buy and install an additional kit. Inlet strainer (oil only) is built-in to protect pump from containments that can damage your pump.

• Model: LD

• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35

• Application: Oil

• Compatible Material: Oil

• Fluid Inlet Size (in): 1
• Fluid Inlet Size (mm): 25.4

• Fluid Outlet Size (in): 1/2
• Fluid Outlet Size (mm): 12.7

• Maximum Air Inlet Pressure (bar): 10.34
• Maximum Air Inlet Pressure (kPa): 1034
• Maximum Air Inlet Pressure (psi): 150

• Maximum Working Pressure (bar): 51.7
• Maximum Working Pressure (kPa): 5170
• Maximum Working Pressure (MPa): 5.2
• Maximum Working Pressure (psi): 750

• Power Type: Pneumatic

• Pump Ratio: 5:1

GG 24G429

GG 24G490

PLATE, BASE, 8 SECTION, MSP NPSF

Graco 24G490 Trabon MSP Divider Valve - 8 Section Base Plate Assemblies - NPSF

The Trabon MSP Series sets the industry standard for quality, reliability, and ease of use features. It was the original modular-style series progressive divider valve - and is still the best!

• Quick change valve sections can be removed from the base assembly without disturbing any lube lines - minimizing labor cost and maximizing your machine uptime.
• Accessories such as magnetic and electronic proximity switch cycle indicators provide positive assurance of a successful lube event.
• Alternate outlet on face of valves can be fitted with optional performance indicators, taking the guesswork out of troubleshooting.

• Model: Trabon
• Series: MSP

• Application: On-Road Vehicles, Off-Road Equipment, In-Plant Machinery

• Compatible Material: Oil, Grease

• Cycle Indicator: None

• Discharge Per Piston Stroke (in cu ): N/A

• Divider Valve Series: MSP

• Inlet Size (in): 1/4

• Inlet Thread Gender: Female
• Inlet Thread Type: NPSF

• Material: Carbon Steel

• Maximum NLGI Grade: #2

• Maximum Operating Temperature ( degree C): 176
• Maximum Operating Temperature ( degree F): 350

• Maximum Working Pressure (bar): 241
• Maximum Working Pressure (kPa): 24100
• Maximum Working Pressure (psi): 3500

• Number of Outlets: 16

• Outlet Size (cm): 0.3175
• Outlet Size (in): 1/8
• Outlet Size (mm): 3.175
• Outlet Thread Gender: Female
• Outlet Thread Type: NPSF

GG 24G551

KIT, REPAIR, PUMP, 5:1 SANITARY

Graco 24G551 Lower Repair Kit 5:1 Double Ball

GG 24G594

LD SERIES OIL PUMP, ASSEMBLY, 5:1, NPT

Graco 24G594 LD 5:1 Oil Pump with 55 Gallon (200 Liter) Steel Down Tube and Bung Adapter - NPT

The LD Series Pumps offer amazing performance at an amazingly competitive price. These affordable and full-featured pumps are designed for low volume applications to provide long life and serviceability. LD has a powerful three inch air motor to deliver the fluids you need while the built-in thermal relief protects your equipment from thermal expansion.

• Three Inch Air Motor - Provides more power to create better flow.
• Innovative Air Valve - Designed to reduce icing in continuous use applications and uses less air than competitive pumps for better efficiency. Easy to repair or replace without tearing down internal pump components for less downtime.
• Engineered for Durability - Patent-pending cup and plate design eliminates the need for O-rings that wear out faster for a more durable, longer-lasting solution.
• Pilot Valve - Patent-pending, self-cleaning design increases reliability in dirty air environments and minimizes pressure drop with rapid changeovers for reduced stalling and smoother flow.
• Adjustable Bung Adapter Included - Built-in slide adjustment with easy-set hand screws can fit into more applications.
• Built-In Thermal Relief and Inlet Strainer - Built-in thermal relief protects your equipment from thermal expansion without the need to buy and install an additional kit. Inlet strainer (oil only) is built-in to protect pump from containments that can damage your pump.
• Includes 200L (55gal) drum down tube

• Model: LD

• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35

• Application: Oil

• Compatible Material: Oil

• Fluid Inlet Size (in): 1
• Fluid Inlet Size (mm): 25.4

• Fluid Outlet Size (in): 1/2
• Fluid Outlet Size (mm): 12.7

• Maximum Air Inlet Pressure (bar): 10.34
• Maximum Air Inlet Pressure (kPa): 1034
• Maximum Air Inlet Pressure (psi): 150

• Maximum Working Pressure (bar): 51.7
• Maximum Working Pressure (kPa): 5170
• Maximum Working Pressure (MPa): 5.2
• Maximum Working Pressure (psi): 750

• Power Type: Pneumatic

• Pump Ratio: 5:1

GG 24G576

LD SERIES OIL PUMP, 3:1, UNIVERSAL, NPT

Graco 24G576 LD Series 3:1 Universal Oil Pump with Bung Adapter - NPT

The LD Series Pumps offer amazing performance at an amazingly competitive price. These affordable and full-featured pumps are designed for low volume applications to provide long life and serviceability. LD has a powerful three inch air motor to deliver the fluids you need while the built-in thermal relief protects your equipment from thermal expansion.

• Three Inch Air Motor - Provides more power to create better flow.
• Innovative Air Valve - Designed to reduce icing in continuous use applications and uses less air than competitive pumps for better efficiency. Easy to repair or replace without tearing down internal pump components for less downtime.
• Engineered for Durability - Patent-pending cup and plate design eliminates the need for O-rings that wear out faster for a more durable, longer-lasting solution.
• Pilot Valve - Patent-pending, self-cleaning design increases reliability in dirty air environments and minimizes pressure drop with rapid changeovers for reduced stalling and smoother flow.
• Adjustable Bung Adapter Included - Built-in slide adjustment with easy-set hand screws can fit into more applications.
• Built-In Thermal Relief and Inlet Strainer - Built-in thermal relief protects your equipment from thermal expansion without the need to buy and install an additional kit. Inlet strainer (oil only) is built-in to protect pump from containments that can damage your pump.

• Model: LD

• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35

• Application: Oil

• Compatible Material: Oil

• Fluid Inlet Size (in): 1
• Fluid Inlet Size (mm): 25.4

• Fluid Outlet Size (in): 1/2
• Fluid Outlet Size (mm): 12.7

• Maximum Air Inlet Pressure (bar): 10.34
• Maximum Air Inlet Pressure (kPa): 1034
• Maximum Air Inlet Pressure (psi): 150

• Maximum Working Pressure (bar): 51.7
• Maximum Working Pressure (kPa): 5170
• Maximum Working Pressure (MPa): 5.2
• Maximum Working Pressure (psi): 750

• Power Type: Pneumatic

• Pump Ratio: 3:1

GG 24G488

PLATE, BASE, 6 SECTION, MSP NPSF

Graco 24G488 Trabon MSP Divider Valve - 6 Section Base Plate Assemblies - NPSF

The Trabon MSP Series sets the industry standard for quality, reliability, and ease of use features. It was the original modular-style series progressive divider valve - and is still the best!

• Quick change valve sections can be removed from the base assembly without disturbing any lube lines - minimizing labor cost and maximizing your machine uptime.
• Accessories such as magnetic and electronic proximity switch cycle indicators provide positive assurance of a successful lube event.
• Alternate outlet on face of valves can be fitted with optional performance indicators, taking the guesswork out of troubleshooting.

• Model: Trabon
• Series: MSP

• Application: On-Road Vehicles, Off-Road Equipment, In-Plant Machinery

• Compatible Material: Oil, Grease

• Cycle Indicator: None

• Discharge Per Piston Stroke (in cu ): N/A

• Divider Valve Series: MSP

• Inlet Size (in): 1/4

• Inlet Thread Gender: Female
• Inlet Thread Type: NPSF

• Material: Carbon Steel

• Maximum NLGI Grade: #2

• Maximum Operating Temperature ( degree C): 176
• Maximum Operating Temperature ( degree F): 350

• Maximum Working Pressure (bar): 241
• Maximum Working Pressure (kPa): 24100
• Maximum Working Pressure (psi): 3500

• Number of Outlets: 12

• Outlet Size (cm): 0.3175
• Outlet Size (in): 1/8
• Outlet Size (mm): 3.175
• Outlet Thread Gender: Female
• Outlet Thread Type: NPSF

GG 24G548

GG 24G486

PLATE, BASE, 4 SECTION, MSP NPSF

Graco 24G486 Trabon MSP Divider Valve - 4 Section Base Plate Assemblies - NPSF

The Trabon MSP Series sets the industry standard for quality, reliability, and ease of use features. It was the original modular-style series progressive divider valve - and is still the best!

• Quick change valve sections can be removed from the base assembly without disturbing any lube lines - minimizing labor cost and maximizing your machine uptime.
• Accessories such as magnetic and electronic proximity switch cycle indicators provide positive assurance of a successful lube event.
• Alternate outlet on face of valves can be fitted with optional performance indicators, taking the guesswork out of troubleshooting.

• Model: Trabon
• Series: MSP

• Application: On-Road Vehicles, Off-Road Equipment, In-Plant Machinery

• Compatible Material: Oil, Grease

• Cycle Indicator: None

• Discharge Per Piston Stroke (in cu ): N/A

• Divider Valve Series: MSP

• Inlet Size (in): 1/4

• Inlet Thread Gender: Female
• Inlet Thread Type: NPSF

• Material: Carbon Steel

• Maximum NLGI Grade: #2

• Maximum Operating Temperature ( degree C): 176
• Maximum Operating Temperature ( degree F): 350

• Maximum Working Pressure (bar): 241
• Maximum Working Pressure (kPa): 24100
• Maximum Working Pressure (psi): 3500

• Number of Outlets: 8

• Outlet Size (cm): 0.3175
• Outlet Size (in): 1/8
• Outlet Size (mm): 3.175
• Outlet Thread Gender: Female
• Outlet Thread Type: NPSF

GG 24G485

PLATE, BASE, 3 SECTION, MSP NPSF

Graco 24G485 Trabon MSP Divider Valve - 3 Section Base Plate Assemblies - NPSF

The Trabon MSP Series sets the industry standard for quality, reliability, and ease of use features. It was the original modular-style series progressive divider valve - and is still the best!

• Quick change valve sections can be removed from the base assembly without disturbing any lube lines - minimizing labor cost and maximizing your machine uptime.
• Accessories such as magnetic and electronic proximity switch cycle indicators provide positive assurance of a successful lube event.
• Alternate outlet on face of valves can be fitted with optional performance indicators, taking the guesswork out of troubleshooting.

• Model: Trabon
• Series: MSP

• Application: On-Road Vehicles, Off-Road Equipment, In-Plant Machinery

• Compatible Material: Oil, Grease

• Cycle Indicator: None

• Discharge Per Piston Stroke (in cu ): N/A

• Divider Valve Series: MSP

• Inlet Size (in): 1/4

• Inlet Thread Gender: Female
• Inlet Thread Type: NPSF

• Material: Carbon Steel

• Maximum NLGI Grade: #2

• Maximum Operating Temperature ( degree C): 176
• Maximum Operating Temperature ( degree F): 350

• Maximum Working Pressure (bar): 241
• Maximum Working Pressure (kPa): 24100
• Maximum Working Pressure (psi): 3500

• Number of Outlets: 6

• Outlet Size (cm): 0.3175
• Outlet Size (in): 1/8
• Outlet Size (mm): 3.175
• Outlet Thread Gender: Female
• Outlet Thread Type: NPSF

GG 24G487

PLATE, BASE, 5 SECTION, MSP NPSF

Graco 24G487 Trabon MSP Divider Valve - 5 Section Base Plate Assemblies - NPSF

The Trabon MSP Series sets the industry standard for quality, reliability, and ease of use features. It was the original modular-style series progressive divider valve - and is still the best!

• Quick change valve sections can be removed from the base assembly without disturbing any lube lines - minimizing labor cost and maximizing your machine uptime.
• Accessories such as magnetic and electronic proximity switch cycle indicators provide positive assurance of a successful lube event.
• Alternate outlet on face of valves can be fitted with optional performance indicators, taking the guesswork out of troubleshooting.

• Model: Trabon
• Series: MSP

• Application: On-Road Vehicles, Off-Road Equipment, In-Plant Machinery

• Compatible Material: Oil, Grease

• Cycle Indicator: None

• Discharge Per Piston Stroke (in cu ): N/A

• Divider Valve Series: MSP

• Inlet Size (in): 1/4

• Inlet Thread Gender: Female
• Inlet Thread Type: NPSF

• Material: Carbon Steel

• Maximum NLGI Grade: #2

• Maximum Operating Temperature ( degree C): 176
• Maximum Operating Temperature ( degree F): 350

• Maximum Working Pressure (bar): 241
• Maximum Working Pressure (kPa): 24100
• Maximum Working Pressure (psi): 3500

• Number of Outlets: 10

• Outlet Size (cm): 0.3175
• Outlet Size (in): 1/8
• Outlet Size (mm): 3.175
• Outlet Thread Gender: Female
• Outlet Thread Type: NPSF

GG 24G597

LD SERIES OIL PUMP, ASSEMBLY, 5:1, NPT

Graco 24G597 LD 5:1 Oil Pump with 275 Gallon (1040 Liter) Steel Down Tube and Bung Adapter - NPT

The LD Series Pumps offer amazing performance at an amazingly competitive price. These affordable and full-featured pumps are designed for low volume applications to provide long life and serviceability. LD has a powerful three inch air motor to deliver the fluids you need while the built-in thermal relief protects your equipment from thermal expansion.

• Three Inch Air Motor - Provides more power to create better flow.
• Innovative Air Valve - Designed to reduce icing in continuous use applications and uses less air than competitive pumps for better efficiency. Easy to repair or replace without tearing down internal pump components for less downtime.
• Engineered for Durability - Patent-pending cup and plate design eliminates the need for O-rings that wear out faster for a more durable, longer-lasting solution.
• Pilot Valve - Patent-pending, self-cleaning design increases reliability in dirty air environments and minimizes pressure drop with rapid changeovers for reduced stalling and smoother flow.
• Adjustable Bung Adapter Included - Built-in slide adjustment with easy-set hand screws can fit into more applications.
• Built-In Thermal Relief and Inlet Strainer - Built-in thermal relief protects your equipment from thermal expansion without the need to buy and install an additional kit. Inlet strainer (oil only) is built-in to protect pump from containments that can damage your pump.
• Includes 1040 liter (275gal) tote down tube

• Model: LD

• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35

• Application: Oil

• Compatible Material: Oil

• Fluid Inlet Size (in): 1
• Fluid Inlet Size (mm): 25.4

• Fluid Outlet Size (in): 1/2
• Fluid Outlet Size (mm): 12.7

• Maximum Air Inlet Pressure (bar): 10.34
• Maximum Air Inlet Pressure (kPa): 1034
• Maximum Air Inlet Pressure (psi): 150

• Maximum Working Pressure (bar): 51.7
• Maximum Working Pressure (kPa): 5170
• Maximum Working Pressure (MPa): 5.2
• Maximum Working Pressure (psi): 750

• Power Type: Pneumatic

• Pump Ratio: 5:1

GG 24G434

GG 24F942

SANIFORCE PISTON PUMP, 6:1 DB BL

Graco 24F942 6:1 Ratio SaniForce Bin Length Double Ball Piston Pump

Gracos SaniForce 6:1 quick knockdown piston pumps are constructed of 300 series stainless steel. The air motor improves serviceability, increases efficiency and offers a lower cost of ownership. Our sanitary piston pumps are ideal for most food-related, cosmetic and personal care applications.

• Most advanced air motor on the market
• Available in double-ball and priming piston designs
• Fluid transfer and supply of low to medium viscosity fluids
• FDA-Compliant Shroud:

  Easily removable FDA-compliant shroud to clean and access modular air valve - reducing downtime

  Quick knockdown lowers are made with 300 series stainless steel for long-lasting durability




  • Model: SaniForce
  • Air Inlet Thread Gender: Female
  • Air Inlet Thread Type: NPSM
  • Application: Sanitary
  • Compatible Material: Food, Personal Care
  • Fluid Outlet Size (in): 1-1/2
  • Fluid Outlet Size (mm): 38.1
  • For Use With: Food, Personal Care, & Pharmaceutical
  • Material: Stainless Steel
  • Maximum Air Consumption (SCFM): 29
  • Maximum Air Inlet Pressure (bar): 6.9
  • Maximum Air Inlet Pressure (kPa): 690
  • Maximum Air Inlet Pressure (psi): 100
  • Maximum Continuous Cycle Rate (CPM): 60
  • Maximum Flow Rate (GPM): 4
  • Maximum Flow Rate (L/min): 15.14
  • Maximum Intermittent Cycle Rate (CPM): 60
  • Maximum Working Pressure (bar): 44.8
  • Maximum Working Pressure (kPa): 4480
  • Maximum Working Pressure (MPa): 4.5
  • Maximum Working Pressure (psi): 650
  • Portable: Non-Portable
  • Pump Ratio: 6:1

GG 24G578

LD SERIES OIL PUMP, 3:1, UNIVERSAL, BSPT

Graco 24G578 LD Series 3:1 Universal Oil Pump with Bung Adapter - BSPT

The LD Series Pumps offer amazing performance at an amazingly competitive price. These affordable and full-featured pumps are designed for low volume applications to provide long life and serviceability. LD has a powerful three inch air motor to deliver the fluids you need while the built-in thermal relief protects your equipment from thermal expansion.

• Three Inch Air Motor - Provides more power to create better flow.
• Innovative Air Valve - Designed to reduce icing in continuous use applications and uses less air than competitive pumps for better efficiency. Easy to repair or replace without tearing down internal pump components for less downtime.
• Engineered for Durability - Patent-pending cup and plate design eliminates the need for O-rings that wear out faster for a more durable, longer-lasting solution.
• Pilot Valve - Patent-pending, self-cleaning design increases reliability in dirty air environments and minimizes pressure drop with rapid changeovers for reduced stalling and smoother flow.
• Adjustable Bung Adapter Included - Built-in slide adjustment with easy-set hand screws can fit into more applications.
• Built-In Thermal Relief and Inlet Strainer - Built-in thermal relief protects your equipment from thermal expansion without the need to buy and install an additional kit. Inlet strainer (oil only) is built-in to protect pump from containments that can damage your pump.

• Model: LD

• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35

• Application: Oil

• Compatible Material: Oil

• Fluid Inlet Size (in): 1
• Fluid Inlet Size (mm): 25.4

• Fluid Outlet Size (in): 1/2
• Fluid Outlet Size (mm): 12.7

• Maximum Air Inlet Pressure (bar): 10.34
• Maximum Air Inlet Pressure (kPa): 1034
• Maximum Air Inlet Pressure (psi): 150

• Maximum Working Pressure (bar): 51.7
• Maximum Working Pressure (kPa): 5170
• Maximum Working Pressure (MPa): 5.2
• Maximum Working Pressure (psi): 750

• Power Type: Pneumatic

• Pump Ratio: 3:1

GG 24G585

LD SERIES OIL PUMP, ASSEMBLY, 3:1, NPT

Graco 24G585 LD 3:1 Oil Pump with 275 Gallon (1040 Liter) Steel Down Tube and Bung Adapter - NPT

The LD Series Pumps offer amazing performance at an amazingly competitive price. These affordable and full-featured pumps are designed for low volume applications to provide long life and serviceability. LD has a powerful three inch air motor to deliver the fluids you need while the built-in thermal relief protects your equipment from thermal expansion.

• Three Inch Air Motor - Provides more power to create better flow.
• Innovative Air Valve - Designed to reduce icing in continuous use applications and uses less air than competitive pumps for better efficiency. Easy to repair or replace without tearing down internal pump components for less downtime.
• Engineered for Durability - Patent-pending cup and plate design eliminates the need for O-rings that wear out faster for a more durable, longer-lasting solution.
• Pilot Valve - Patent-pending, self-cleaning design increases reliability in dirty air environments and minimizes pressure drop with rapid changeovers for reduced stalling and smoother flow.
• Adjustable Bung Adapter Included - Built-in slide adjustment with easy-set hand screws can fit into more applications.
• Built-In Thermal Relief and Inlet Strainer - Built-in thermal relief protects your equipment from thermal expansion without the need to buy and install an additional kit. Inlet strainer (oil only) is built-in to protect pump from containments that can damage your pump.
• Includes 1040 liter (275gal) tote down tube

• Model: LD

• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35

• Application: Oil

• Compatible Material: Oil

• Fluid Inlet Size (in): 1
• Fluid Inlet Size (mm): 25.4

• Fluid Outlet Size (in): 1/2
• Fluid Outlet Size (mm): 12.7

• Maximum Air Inlet Pressure (bar): 10.34
• Maximum Air Inlet Pressure (kPa): 1034
• Maximum Air Inlet Pressure (psi): 150

• Maximum Working Pressure (bar): 51.7
• Maximum Working Pressure (kPa): 5170
• Maximum Working Pressure (MPa): 5.2
• Maximum Working Pressure (psi): 750

• Power Type: Pneumatic

• Pump Ratio: 3:1

GG 24G579

LD SERIES OIL PUMP, ASSEMBLY, 3:1, NPT

Graco 24G579 LD 3:1 Oil Pump with Cut-to-Length PVC Downtube and Bung Adapter - NPT

The LD Series Pumps offer amazing performance at an amazingly competitive price. These affordable and full-featured pumps are designed for low volume applications to provide long life and serviceability. LD has a powerful three inch air motor to deliver the fluids you need while the built-in thermal relief protects your equipment from thermal expansion.

• Three Inch Air Motor - Provides more power to create better flow.
• Innovative Air Valve - Designed to reduce icing in continuous use applications and uses less air than competitive pumps for better efficiency. Easy to repair or replace without tearing down internal pump components for less downtime.
• Engineered for Durability - Patent-pending cup and plate design eliminates the need for O-rings that wear out faster for a more durable, longer-lasting solution.
• Pilot Valve - Patent-pending, self-cleaning design increases reliability in dirty air environments and minimizes pressure drop with rapid changeovers for reduced stalling and smoother flow.
• Adjustable Bung Adapter Included - Built-in slide adjustment with easy-set hand screws can fit into more applications.
• Built-In Thermal Relief and Inlet Strainer - Built-in thermal relief protects your equipment from thermal expansion without the need to buy and install an additional kit. Inlet strainer (oil only) is built-in to protect pump from containments that can damage your pump.
• Includes cut-to-length downtube

• Model: LD

• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35

• Application: Oil

• Compatible Material: Oil

• Fluid Inlet Size (in): 1
• Fluid Inlet Size (mm): 25.4

• Fluid Outlet Size (in): 1/2
• Fluid Outlet Size (mm): 12.7

• Maximum Air Inlet Pressure (bar): 10.34
• Maximum Air Inlet Pressure (kPa): 1034
• Maximum Air Inlet Pressure (psi): 150

• Maximum Working Pressure (bar): 51.7
• Maximum Working Pressure (kPa): 5170
• Maximum Working Pressure (MPa): 5.2
• Maximum Working Pressure (psi): 750

• Power Type: Pneumatic

• Pump Ratio: 3:1

GG 24G600

LD SERIES GREASE PUMP, 50:1, 16 KG, NPT

Graco 24G600 LD Series 50:1 Pump for 35 lb (16 kg). Pail - NPT

The LD Series Pumps offer amazing performance at an amazingly competitive price. These affordable and full-featured pumps are designed for low volume applications to provide long life and serviceability. LD has a powerful three inch air motor to deliver the fluids you need while the built-in thermal relief protects your equipment from thermal expansion.

• Three Inch Air Motor - Provides more power to create better flow.
• Innovative Air Valve - Designed to reduce icing in continuous use applications and uses less air than competitive pumps for better efficiency. Easy to repair or replace without tearing down internal pump components for less downtime.
• Engineered for Durability - Patent-pending cup and plate design eliminates the need for O-rings that wear out faster for a more durable, longer-lasting solution.
• Pilot Valve - Patent-pending, self-cleaning design increases reliability in dirty air environments and minimizes pressure drop with rapid changeovers for reduced stalling and smoother flow.
• Adjustable Bung Adapter Included - Built-in slide adjustment with easy-set hand screws can fit into more applications.
• Built-In Thermal Relief and Inlet Strainer - Built-in thermal relief protects your equipment from thermal expansion without the need to buy and install an additional kit. Inlet strainer (oil only) is built-in to protect pump from containments that can damage your pump.
• 35 lb (16 kg) Grease Pump - 50:1

• Model: LD

• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35

• Application: Grease

• Compatible Material: Grease

• Fluid Outlet Size (in): 1/4
• Fluid Outlet Size (mm): 6.35

• Maximum Air Inlet Pressure (bar): 10.34
• Maximum Air Inlet Pressure (kPa): 1034
• Maximum Air Inlet Pressure (psi): 150

• Maximum Working Pressure (bar): 517
• Maximum Working Pressure (kPa): 51700
• Maximum Working Pressure (MPa): 51.7
• Maximum Working Pressure (psi): 7500

• Power Type: Pneumatic

• Pump Ratio: 50:1

GG 24F926

KIT, DIAPHRAGM-E1 PS

Graco 24F926 Diaphragm Kit

GG 24G552

KIT, REPAIR, PUMP, 5:1 SANITARY

Graco 24G552 Lower Repair Kit 5:1 Priming Piston

GG 24G582

LD SERIES OIL PUMP, ASSEMBLY, 3:1, NPT

Graco 24G582 LD 3:1 Oil Pump with 55 Gallon (200 Liter) Down Tube and Bung Adapter - NPT

The LD Series Pumps offer amazing performance at an amazingly competitive price. These affordable and full-featured pumps are designed for low volume applications to provide long life and serviceability. LD has a powerful three inch air motor to deliver the fluids you need while the built-in thermal relief protects your equipment from thermal expansion.

• Three Inch Air Motor - Provides more power to create better flow.
• Innovative Air Valve - Designed to reduce icing in continuous use applications and uses less air than competitive pumps for better efficiency. Easy to repair or replace without tearing down internal pump components for less downtime.
• Engineered for Durability - Patent-pending cup and plate design eliminates the need for O-rings that wear out faster for a more durable, longer-lasting solution.
• Pilot Valve - Patent-pending, self-cleaning design increases reliability in dirty air environments and minimizes pressure drop with rapid changeovers for reduced stalling and smoother flow.
• Adjustable Bung Adapter Included - Built-in slide adjustment with easy-set hand screws can fit into more applications.
• Built-In Thermal Relief and Inlet Strainer - Built-in thermal relief protects your equipment from thermal expansion without the need to buy and install an additional kit. Inlet strainer (oil only) is built-in to protect pump from containments that can damage your pump.
• Includes 200L (55gal) drum down tube

• Model: LD

• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35

• Application: Oil

• Compatible Material: Oil

• Fluid Inlet Size (in): 1
• Fluid Inlet Size (mm): 25.4

• Fluid Outlet Size (in): 1/2
• Fluid Outlet Size (mm): 12.7

• Maximum Air Inlet Pressure (bar): 10.34
• Maximum Air Inlet Pressure (kPa): 1034
• Maximum Air Inlet Pressure (psi): 150

• Maximum Working Pressure (bar): 51.7
• Maximum Working Pressure (kPa): 5170
• Maximum Working Pressure (MPa): 5.2
• Maximum Working Pressure (psi): 750

• Power Type: Pneumatic

• Pump Ratio: 3:1

GG 24G698

GG 24G603

LD SERIES GREASE PUMP, 50:1, 55 KG, NPT

Graco 24G603 LD Series 50:1 Pump for 120 lb (55 kg). Pail - NPT

The LD Series Pumps offer amazing performance at an amazingly competitive price. These affordable and full-featured pumps are designed for low volume applications to provide long life and serviceability. LD has a powerful three inch air motor to deliver the fluids you need while the built-in thermal relief protects your equipment from thermal expansion.

• Three Inch Air Motor - Provides more power to create better flow.
• Innovative Air Valve - Designed to reduce icing in continuous use applications and uses less air than competitive pumps for better efficiency. Easy to repair or replace without tearing down internal pump components for less downtime.
• Engineered for Durability - Patent-pending cup and plate design eliminates the need for O-rings that wear out faster for a more durable, longer-lasting solution.
• Pilot Valve - Patent-pending, self-cleaning design increases reliability in dirty air environments and minimizes pressure drop with rapid changeovers for reduced stalling and smoother flow.
• Adjustable Bung Adapter Included - Built-in slide adjustment with easy-set hand screws can fit into more applications.
• Built-In Thermal Relief and Inlet Strainer - Built-in thermal relief protects your equipment from thermal expansion without the need to buy and install an additional kit. Inlet strainer (oil only) is built-in to protect pump from containments that can damage your pump.
• 120 lb (55 kg) Grease Pump - 50:1

• Model: LD

• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35

• Application: Grease

• Compatible Material: Grease

• Fluid Outlet Size (in): 1/4
• Fluid Outlet Size (mm): 6.35

• Maximum Air Inlet Pressure (bar): 10.34
• Maximum Air Inlet Pressure (kPa): 1034
• Maximum Air Inlet Pressure (psi): 150

• Maximum Working Pressure (bar): 517
• Maximum Working Pressure (kPa): 51700
• Maximum Working Pressure (MPa): 51.7
• Maximum Working Pressure (psi): 7500

• Power Type: Pneumatic

• Pump Ratio: 50:1

GG 24G606

LD SERIES GREASE PUMP, 50:1, 180 KG, NPT

Graco 24G606 LD Series 50:1 Pump for 400 lb (180 kg). Pail - NPT

The LD Series Pumps offer amazing performance at an amazingly competitive price. These affordable and full-featured pumps are designed for low volume applications to provide long life and serviceability. LD has a powerful three inch air motor to deliver the fluids you need while the built-in thermal relief protects your equipment from thermal expansion.

• Three Inch Air Motor - Provides more power to create better flow.
• Innovative Air Valve - Designed to reduce icing in continuous use applications and uses less air than competitive pumps for better efficiency. Easy to repair or replace without tearing down internal pump components for less downtime.
• Engineered for Durability - Patent-pending cup and plate design eliminates the need for O-rings that wear out faster for a more durable, longer-lasting solution.
• Pilot Valve - Patent-pending, self-cleaning design increases reliability in dirty air environments and minimizes pressure drop with rapid changeovers for reduced stalling and smoother flow.
• Adjustable Bung Adapter Included - Built-in slide adjustment with easy-set hand screws can fit into more applications.
• Built-In Thermal Relief and Inlet Strainer - Built-in thermal relief protects your equipment from thermal expansion without the need to buy and install an additional kit. Inlet strainer (oil only) is built-in to protect pump from containments that can damage your pump.
• 400 lb (180 kg) Grease Pump - 50:1

• Model: LD

• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35

• Application: Grease

• Compatible Material: Grease

• Fluid Outlet Size (in): 1/4
• Fluid Outlet Size (mm): 6.35

• Maximum Air Inlet Pressure (bar): 10.34
• Maximum Air Inlet Pressure (kPa): 1034
• Maximum Air Inlet Pressure (psi): 150

• Maximum Working Pressure (bar): 517
• Maximum Working Pressure (kPa): 51700
• Maximum Working Pressure (MPa): 51.7
• Maximum Working Pressure (psi): 7500

• Power Type: Pneumatic

• Pump Ratio: 50:1

GG 24G694

GG 24G615

GG 24F931

GG 289520

GG 289605

GG 289455

KIT,NEEDLE PACKING

Graco 289455 Needle Packing Repair Kit

GG 289463

KIT,NEEDLE AND NOZZLE,.055 SST

Graco 289463 Needle/ Nozzle Kit for AirPro Guns with 0.055 inch (1.4 mm) Nozzle, General Metal with Stainless Steel Tip

GG 289623

TRITON SPRAYER, SS PUMP WALL MNT, COMP

Graco 289623 Triton SST Spray Package, Wall, 100 psi Regulator, Air & Fluid Hoses, AirPro Compliant Gun .055 in (1.4 mm) Nozzle, Waterborne Applications

Air-operated diaphragm spray package designed for the finishing market. It is a more effective alternative to traditional pressure pots and standard diaphragm pumps.

• Superior finish quality for conventional, HVLP and compliant or electrostatic applications
• Supplies up to 35% extra air flow to gun for superior atomization
• Saves material and time during flushing, priming and color changes
• Rugged, stainless steel or aluminum construction pump handles a wide variety of fluids

• Model: Triton
• Series: 308

• Application: Waterborne

• Compatible Material: CARC, Enamel, Epoxies, High Solids, Latex, Lacquer, Metallics, Stains, Single Components, Solvent borne Paints, Solvent borne, Varnish Primers, Waterborne

• Fluid Inlet Size (cm): 1.905
• Fluid Inlet Size (in): 3/4
• Fluid Inlet Size (mm): 19.05
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (cm): 0.9525
• Fluid Outlet Size (in): 3/8
• Fluid Outlet Size (mm): 9.525
• Fluid Outlet Thread Type: NPT

• Gun Included: 1
• Gun Model: AirPro
• Gun Technology: Compliant
• Gun Type: Air Spray

• Includes: 25 ft Air Hose, 25 ft Fluid Hose, Regulator, Applicator

• Maximum Air Inlet Pressure (bar): 7
• Maximum Air Inlet Pressure (kPa): 700
• Maximum Air Inlet Pressure (psi): 100

• Maximum Flow Rate (GPM): 8.5
• Maximum Flow Rate (L/min): 32

• Maximum Working Pressure (bar): 7
• Maximum Working Pressure (kPa): 700
• Maximum Working Pressure (psi): 100

• Mount Location: Wall Mount
• Mount Type: Wall Mount

• Power Source: Air

• Pressure Type: Low Pressure
• Product Type: Spray Package

• Pump Ratio: 1:1
• Pump Type: Pneumatic Diaphragm Pump

GG 289630

TRITON SPRAYER, AL WALL MNT CONV STAIN

Graco 289630 Triton Alum Spray Package, Wall, Air & Fluid Hoses, AirPro Conventional Gun .040 in (1.0 mm) Nozzle for Wood Applications

Air-operated diaphragm spray package designed for the finishing market. It is a more effective alternative to traditional pressure pots and standard diaphragm pumps.

• Superior finish quality for conventional, HVLP and compliant or electrostatic applications
• Supplies up to 35% extra air flow to gun for superior atomization
• Saves material and time during flushing, priming and color changes
• Rugged, stainless steel or aluminum construction pump handles a wide variety of fluids

• Model: Triton
• Series: 308

• Application: Wood

• Compatible Material: CARC, Enamel, Epoxies, High Solids, Latex, Lacquer, Metallics, Stains, Single Components, Solvent borne Paints, Solvent borne, Varnish Primers

• Fluid Inlet Size (cm): 1.905
• Fluid Inlet Size (in): 3/4
• Fluid Inlet Size (mm): 19.05
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (cm): 0.9525
• Fluid Outlet Size (in): 3/8
• Fluid Outlet Size (mm): 9.525
• Fluid Outlet Thread Type: NPT

• Gun Included: 1
• Gun Model: AirPro
• Gun Technology: Conventional
• Gun Type: Air Spray

• Includes: 25 ft Air Hose, 25 ft Fluid Hose, Applicator
