INGERSOLL-RAND IR TOOL S12880

IR 77A-A593

IR 77H-20

IR 77H-24

IR 77H-282

IR 77H-33-H6

IR 77H-3

IR 77H90-A524ARH

IR 77H-824-H6

IR 77H-66-H6

IR 77H-53RH

IR 7802A-A3

IR 7802RA-TK1

IR 7802A-A12

IR 77H-11

IR 77H-A400

IR 77A-AM825-9

IR 7802S-K1

IR 7803A-A10

IR 7811-10

IR 7A-DRILLS-TK1

IR 7AH-42A-4

IR 7AH-AST40A

IR 7AH-565

IR 24061624

IR 24141

IR 26966

IR 26999

IR 28690

IR 27925-XLP

IR 27925-SX

IR 30000-150-2

IR 30000-190-2

IR 30000-200-2

IR 30000-210-2

IR 30015

IR 30038

IR 30116-500

IR 30114-375

IR 30081-72

IR 30081-120

IR 30116-375

IR 30182

IR 30183

IR 30185

IR 30193

IR 30272

IR 30200-300-2

IR 30195-024

IR 30231

IR 30275

IR 30277

IR 30303

IR 30196

IR 30500-180-2

IR 30500-100-2

IR 30500-160-2

IR 30309-42

IR 30579

IR 30515

IR 30500-210-2

IR 30500-220-2

IR 30581

IR 30500-200-2

IR 30599

IR 30718-3600

IR 30719-2850

IR 30814-048

IR 30814-012

IR 30814-072

IR 30814-060

IR 30806

IR 30824

IR 30852

IR 30918-2

IR 311-311

IR 37655

IR 37653-16

IR 37571

IR 35019

IR 37654

IR 30804

IR 37706

IR 37719

IR 37723

IR 3800M2/A123

IR 382-35944

IR 382-31483

IR 3840U

Inline Multi-Vane Air Motor, 3/4" Keyed Shaft, 162 RPM, 1.35 HP, 181 NM, Reversible

Description: With durable inline planetary gearing and a robust vane motor, the 3800 Series is one of the most durable motors on the market.

Features And Benefits:

• Safety: Meets ATEX Standards
• Durable: The 3800 Series is designed to withstand harsh environments and keep on running.
• Ease of Service: Easily serviceable, the 3800 Series will enhance productivity by eliminating long repair times.

Product Application and Uses:

Industrial Machinery, Insert tools, Conveyers, Index machines, Fastener/Insert tools, Automotive assembly fixtures, Meat processing, Aircraft Assembly, Pipe Cutting, Pipe Beveling, Tip Dressers, Strapping tools, Wood working machinery, Tapping/Drilling Machines, tandem trailer puller

• Air Consumption at Max HP (scfm): 44
• Air Inlet: 1/2" NPT
• Air Pressure (psi): 90

• Drive Length (in): 2.1875
• Drive Size (in): 3/4
• Drive Type: Round Keyed

• Exhaust Location: Rear
• Finish: Black Oxide
• Gear Ratio: 19.3:1
• Gear Reduction: Double
• Gear Train: Planetary

• Housing Material: Steel
• Keyaway Length (in): 1.5

• Max Free Speed (rpm): 162
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 133
• Max Torque (in-lb): 1602
• Max Torque (nm): 181
• Motor: Rotary Vane
• Motor: In line
• Mounting Type: Face

• Number of Mounting Holes: 6
• Operating Temperature Range: 0F to 150F
• Power Source: Air Powered
• Product Length (in): 8.69

• Product Width (in): 3.25
• Product Height (in): 3.25
• Product Weight (lb): 8.75
• Rated Power (hp): 1.35
• Rated Power (kW): 1.01
• Reversible: Reversible

• Speed at Max Power (rpm): 83
• Standards/Certifications: ATEX
• Starting Torque (ft-lb): 100
• Starting Torque (nm): 135

• Warranty: 1-year

• Parts: R3800-A123

IR 402-1-A

IR 42203000

IR 43146012

IR 43146013

IR 47529152001

IR 45519618-1200

IR 45519063

IR 47549516001

IR 47549517001

IR 47623776001

IR 4800M

Inline Multi-Vane Air Motor, 1" Keyed Shaft, 1050 RPM, 3.7 HP, 93.6 NM, Non-reversible

Description: The 4800 Series has a durable inline planetary gearing system and robust vane motor design making it one of the most durable motors around.

Features And Benefits:

• Safety: Meets ATEX Standards
• Durable: Able to withstand harsh environments, you never have to worry about the 4800 Series letting you down.
• Ease of Service: Without having to worry about repair time, you'll be able to spend more time focused on the job.

Product Application and Uses:

Industrial Machinery, Insert tools, Conveyers, Index machines, Fastener/Insert tools, Automotive assembly fixtures, Meat processing, Aircraft Assembly, Pipe Cutting, Pipe Beveling, Tip Dressers, Strapping tools, Wood working machinery, Tapping/Drilling Machines, tandem trailer puller

• Air Consumption at Max HP (scfm): 95
• Air Inlet: 1/2" NPT
• Air Pressure (psi): 90

• Drive Size (in): 1
• Drive Type: Round Keyed

• Exhaust Location: Rear
• Finish: Black Oxide
• Gear Reduction: Single
• Gear Train: Planetary

• Housing Material: Steel

• Max Free Speed (rpm): 1050
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 69
• Max Torque (in-lb): 828
• Max Torque (nm): 93.6
• Motor: Rotary Vane
• Motor: In line
• Mounting Type: Face

• Number of Mounting Holes: 6
• Power Source: Air Powered
• Product Length (in): 11.38

• Product Width (in): 4
• Product Height (in): 4
• Product Weight (lb): 15.25
• Rated Power (hp): 3.7
• Rated Power (kW): 2.76
• Reversible: Non-reversible

• Speed at Max Power (rpm): 560
• Standards/Certifications: ATEX
• Starting Torque (ft-lb): 51
• Starting Torque (nm): 69.2

• Warranty: 1-year

• Parts: 518-104
• Parts: R4901-102

IR 4800U2

Inline Multi-Vane Air Motor, 1" Square Shaft, 185 RPM, 3.5 HP, 480 NM, Non-reversible

Description: The 4800 Series has a durable inline planetary gearing system and robust vane motor design making it one of the most durable motors around.

Features And Benefits:

• Safety: Meets ATEX Standards
• Durable: Able to withstand harsh environments, you never have to worry about the 4800 Series letting you down.
• Ease of Service: Without having to worry about repair time, you'll be able to spend more time focused on the job.

Product Application and Uses:

Industrial Machinery, Insert tools, Conveyers, Index machines, Fastener/Insert tools, Automotive assembly fixtures, Meat processing, Aircraft Assembly, Pipe Cutting, Pipe Beveling, Tip Dressers, Strapping tools, Wood working machinery, Tapping/Drilling Machines, tandem trailer puller

• Air Consumption at Max HP (scfm): 95
• Air Inlet: 1/2" NPT
• Air Pressure (psi): 90

• Drive Length (in): 2.25
• Drive Size (in): 1
• Drive Type: Round Keyed

• Exhaust Location: Rear
• Finish: Black Oxide
• Gear Ratio: 53.5:1
• Gear Reduction: Double
• Gear Train: Planetary

• Housing Material: Steel

• Max Free Speed (rpm): 185
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 354
• Max Torque (in-lb): 4248
• Max Torque (nm): 480
• Motor: Rotary Vane
• Motor: In line
• Mounting Type: Face

• Number of Mounting Holes: 6
• Operating Temperature Range: 0F to 150F
• Power Source: Air Powered
• Product Length (in): 11.38

• Product Width (in): 4
• Product Height (in): 4
• Product Weight (lb): 19.75
• Rated Power (hp): 3.5
• Rated Power (kW): 2.61
• Reversible: Non-reversible

• Speed at Max Power (rpm): 97
• Standards/Certifications: ATEX
• Starting Torque (ft-lb): 265
• Starting Torque (nm): 359

• Warranty: 1-year

• Parts: R4800-A123
