INGERSOLL-RAND IR TOOL S12880

IR 6WTN-17

IR 705-93

Trigger for Ingersoll Rand 2705P1, 2705P1, 231C

• For Use With: 231C
• For Use With: 2705P1
• For Use With: 2707P1

IR 705-941

IR 71053748

IR 71079594

IR 711077126

IR 71126759

IR 71273353

IR 71293179

IR 71296891

IR 71467690

IR 728-739

IR 728-A12

IR 728-A503

IR 728N-A48

IR 7526-0356

IR 77A-307

IR 77A-826

IR 77A-A552

IR 77H120-A524RH

IR 77A-A593

IR 77H-20

IR 77H-24

IR 77H-282

IR 77H-33-H6

IR 77H-3

IR 77H90-A524ARH

IR 77H-824-H6

IR 77H-66-H6

IR 77H-53RH

IR 7802A-A3

IR 7802RA-TK1

IR 7802A-A12

IR 77H-11

IR 77H-A400

IR 77A-AM825-9

IR 7802S-K1

IR 7803A-A10

IR 7811-10

IR 7A-DRILLS-TK1

IR 7AH-42A-4

IR 7AH-AST40A

IR 7AH-565

IR 24061624

IR 24141

IR 26966

IR 26999

IR 28690

IR 27925-XLP

IR 27925-SX

IR 30015

IR 30038

IR 30182

IR 30183

IR 30185

IR 30193

IR 30272

IR 30231

IR 30275

IR 30277

IR 30303

IR 30196

IR 30579

IR 30515

IR 30581

IR 30599

IR 30806

IR 30824

IR 30852

IR 311-311

IR 37655

IR 37571

IR 35019

IR 37654

IR 30804

IR 37706

IR 37719

IR 37723

IR 3800M2/A123

IR 382-31483

IR 3840U

Inline Multi-Vane Air Motor, 3/4" Keyed Shaft, 162 RPM, 1.35 HP, 181 NM, Reversible

Description: With durable inline planetary gearing and a robust vane motor, the 3800 Series is one of the most durable motors on the market.

Features And Benefits:

• Safety: Meets ATEX Standards
• Durable: The 3800 Series is designed to withstand harsh environments and keep on running.
• Ease of Service: Easily serviceable, the 3800 Series will enhance productivity by eliminating long repair times.

Product Application and Uses:

Industrial Machinery, Insert tools, Conveyers, Index machines, Fastener/Insert tools, Automotive assembly fixtures, Meat processing, Aircraft Assembly, Pipe Cutting, Pipe Beveling, Tip Dressers, Strapping tools, Wood working machinery, Tapping/Drilling Machines, tandem trailer puller

• Air Consumption at Max HP (scfm): 44
• Air Inlet: 1/2" NPT
• Air Pressure (psi): 90

• Drive Length (in): 2.1875
• Drive Size (in): 3/4
• Drive Type: Round Keyed

• Exhaust Location: Rear
• Finish: Black Oxide
• Gear Ratio: 19.3:1
• Gear Reduction: Double
• Gear Train: Planetary

• Housing Material: Steel
• Keyaway Length (in): 1.5

• Max Free Speed (rpm): 162
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 133
• Max Torque (in-lb): 1602
• Max Torque (nm): 181
• Motor: Rotary Vane
• Motor: In line
• Mounting Type: Face

• Number of Mounting Holes: 6
• Operating Temperature Range: 0F to 150F
• Power Source: Air Powered
• Product Length (in): 8.69

• Product Width (in): 3.25
• Product Height (in): 3.25
• Product Weight (lb): 8.75
• Rated Power (hp): 1.35
• Rated Power (kW): 1.01
• Reversible: Reversible

• Speed at Max Power (rpm): 83
• Standards/Certifications: ATEX
• Starting Torque (ft-lb): 100
• Starting Torque (nm): 135

• Warranty: 1-year

• Parts: R3800-A123

IR 402-1-A

IR 42203000

IR 43146012

IR 43146013

IR 47529152001

IR 45519063

IR 47549516001

IR 47549517001

IR 47623776001

IR 4800M

Inline Multi-Vane Air Motor, 1" Keyed Shaft, 1050 RPM, 3.7 HP, 93.6 NM, Non-reversible

Description: The 4800 Series has a durable inline planetary gearing system and robust vane motor design making it one of the most durable motors around.

Features And Benefits:

• Safety: Meets ATEX Standards
• Durable: Able to withstand harsh environments, you never have to worry about the 4800 Series letting you down.
• Ease of Service: Without having to worry about repair time, you'll be able to spend more time focused on the job.

Product Application and Uses:

Industrial Machinery, Insert tools, Conveyers, Index machines, Fastener/Insert tools, Automotive assembly fixtures, Meat processing, Aircraft Assembly, Pipe Cutting, Pipe Beveling, Tip Dressers, Strapping tools, Wood working machinery, Tapping/Drilling Machines, tandem trailer puller

• Air Consumption at Max HP (scfm): 95
• Air Inlet: 1/2" NPT
• Air Pressure (psi): 90

• Drive Size (in): 1
• Drive Type: Round Keyed

• Exhaust Location: Rear
• Finish: Black Oxide
• Gear Reduction: Single
• Gear Train: Planetary

• Housing Material: Steel

• Max Free Speed (rpm): 1050
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 69
• Max Torque (in-lb): 828
• Max Torque (nm): 93.6
• Motor: Rotary Vane
• Motor: In line
• Mounting Type: Face

• Number of Mounting Holes: 6
• Power Source: Air Powered
• Product Length (in): 11.38

• Product Width (in): 4
• Product Height (in): 4
• Product Weight (lb): 15.25
• Rated Power (hp): 3.7
• Rated Power (kW): 2.76
• Reversible: Non-reversible

• Speed at Max Power (rpm): 560
• Standards/Certifications: ATEX
• Starting Torque (ft-lb): 51
• Starting Torque (nm): 69.2

• Warranty: 1-year

• Parts: 518-104
• Parts: R4901-102

IR 4800U2

Inline Multi-Vane Air Motor, 1" Square Shaft, 185 RPM, 3.5 HP, 480 NM, Non-reversible

Description: The 4800 Series has a durable inline planetary gearing system and robust vane motor design making it one of the most durable motors around.

Features And Benefits:

• Safety: Meets ATEX Standards
• Durable: Able to withstand harsh environments, you never have to worry about the 4800 Series letting you down.
• Ease of Service: Without having to worry about repair time, you'll be able to spend more time focused on the job.

Product Application and Uses:

Industrial Machinery, Insert tools, Conveyers, Index machines, Fastener/Insert tools, Automotive assembly fixtures, Meat processing, Aircraft Assembly, Pipe Cutting, Pipe Beveling, Tip Dressers, Strapping tools, Wood working machinery, Tapping/Drilling Machines, tandem trailer puller

• Air Consumption at Max HP (scfm): 95
• Air Inlet: 1/2" NPT
• Air Pressure (psi): 90

• Drive Length (in): 2.25
• Drive Size (in): 1
• Drive Type: Round Keyed

• Exhaust Location: Rear
• Finish: Black Oxide
• Gear Ratio: 53.5:1
• Gear Reduction: Double
• Gear Train: Planetary

• Housing Material: Steel

• Max Free Speed (rpm): 185
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 354
• Max Torque (in-lb): 4248
• Max Torque (nm): 480
• Motor: Rotary Vane
• Motor: In line
• Mounting Type: Face

• Number of Mounting Holes: 6
• Operating Temperature Range: 0F to 150F
• Power Source: Air Powered
• Product Length (in): 11.38

• Product Width (in): 4
• Product Height (in): 4
• Product Weight (lb): 19.75
• Rated Power (hp): 3.5
• Rated Power (kW): 2.61
• Reversible: Non-reversible

• Speed at Max Power (rpm): 97
• Standards/Certifications: ATEX
• Starting Torque (ft-lb): 265
• Starting Torque (nm): 359

• Warranty: 1-year

• Parts: R4800-A123

ELK25-1NS25-1PHH-10-6-1CF30

IR 03611720

IR 04324596

IR 1/4HXSQAD

IR 125-A-21

IR 125-A-227

Spring Replacement Part for Ingersoll Rand 125 Series Scalers

Product Application and Uses:

For use with Ingersoll Rand 125-A and 125CI-A Scalers

• For Use With: 125-A

IR 170-283

IR 1702B-A249
