GRACO INC. S10595

GG 25T722

KIT, VALVE SEAT, REPLACEMENT

GG 25S071

GG 25T415

GG 25T725

KIT, HOUSING, BASE

GG 25T723

KIT, CHECK VALVE PARTS

GG 25R647

REGULATOR, BP, MECHANICAL, HIGH-FLOW

Graco 25R647 Low Shear Fluid Back Pressure Regulator, 300 Max psi, 25 gpm Max flow rate, SST, Mechanical, high wear, sanitary inlet/outlet

Graco's low shear back pressure regulator (BPR) minimizes shear and prevents paint degradation so that manufacturers produce consistent finish quality.

• Innovative flow path geometry provides industry-leading low shear capability
• Ultralife series ceramic coated seat and flow directors significantly increase wear resistance capability and service life
• Best-in-class performance holds pressure constant while flow rate changes

• Compatible Material: Waterborne, Solvent borne

• Gauge Port Size (cm): 0.635
• Gauge Port Size (in): 1/4
• Gauge Port Size (mm): 6.35

• Gauge Port Type: NPT

• Inlet Size (cm): 3.8
• Inlet Size (in): 1.5
• Inlet Size (mm): 38

• Inlet Thread Type: Sanitary Flange

• Maximum Flow Rate (GPM): 25
• Maximum Flow Rate (L/min): 95

• Maximum Operating Temperature ( degree C): 50
• Maximum Operating Temperature ( degree F): 122

• Maximum Regulated Pressure (bar): 17.6
• Maximum Regulated Pressure (kg/cm 2): 17.6
• Maximum Regulated Pressure (kPa): 1724
• Maximum Regulated Pressure (psi): 250

• Maximum Viscosity (cP): 1000

• Maximum Working Pressure (bar): 21.1
• Maximum Working Pressure (kg/cm 2): 21.1
• Maximum Working Pressure (kPa): 2068
• Maximum Working Pressure (psi): 300

• Minimum Operating Temperature ( degree C): 0
• Minimum Operating Temperature ( degree F): 32

• Minimum Regulated Pressure (bar): 1.8
• Minimum Regulated Pressure (kg/cm 2): 1.8
• Minimum Regulated Pressure (kPa): 172
• Minimum Regulated Pressure (MPa): 0.17
• Minimum Regulated Pressure (psi): 25

• Outlet Size (cm): 3.8
• Outlet Size (in): 1.5
• Outlet Size (mm): 38
• Outlet Thread Type: Sanitary Flange

GG 25T743

GG 25R648

GG 25T731

KIT, RATIO CHECK

GG 25R646

GG 25R588

GG 25R634

GG 25R584

GG 25T730

KIT, NIGHT CAP

GG 25T473

DYNAMITE SUPPLY UNIT, 1 GAL, 22:1

Graco 25T473 DynaMite Supply Pump for 1 Gallon pails

The Graco Dynamite Supply Pumps are an ideal solution for delivering precise and consistent material feed from small 1 gallon pails.

• Features and Benefits:

  Proven Graco Merkur motor allows for compact and lightweight design

  Longer product lifecycle due to diamond-like carbon coating and improved rid and piston designs

  Simple and user-friendly control panel

  • Typical Markets:

    Automotive Electronics

    Telecommunication Electronics

    Consumer Electronics

    • Typical Fluids Handled:

      Thermal Interface Materials

      Silicon

      Colorants

      Grease

      Ink

      Adhesives




      • Model: DynaMite
      • Series: 22
      • Air Inlet Size (in): 0.314961
      • Air Inlet Thread Gender: None
      • Ambient/Warm Melt/Hot Melt: Ambient
      • Control Options: Standard
      • Fluid Outlet Size (in): 1/4
      • Fluid Outlet Thread Gender: Female
      • Fluid Outlet Thread Type: NPT
      • Material Container Volume (gal): 1
      • Material Container Volume (l): 3.79
      • Maximum Air Inlet Pressure (bar): 6.9
      • Maximum Air Inlet Pressure (kPa): 700
      • Maximum Air Inlet Pressure (psi): 100
      • Maximum Fluid Pressure (bar): 140
      • Maximum Fluid Pressure (MPa): 140
      • Maximum Fluid Pressure (psi): 0
      • Maximum Fluid Pressure (bar): 140
      • Maximum Fluid Pressure (MPa): 140
      • Maximum Fluid Pressure (psi): 0
      • Maximum Operating Temperature ( degree C): 60
      • Maximum Operating Temperature ( degree F): 140
      • Maximum Working Pressure (bar): 152
      • Maximum Working Pressure (MPa): 15.2
      • Maximum Working Pressure (psi): 2200
      • Number of Wipers: Single Ring
      • Plate Material: Rubber
      • Power Type: Pneumatic
      • Pump Type: Piston
      • Ram Post Diameter (mm): 172

GG 25T817

EGP ON DEMAND PUMP, 115V, 4GPM

Graco 25T817 EGP On-Demand Pump, 115 VAC, 3.7 gpm (14.0 lpm), 500 psi (34.5 bar)

Choose cost-saving convenience with the all-new Graco EGP electric pumps. Install the EGP on-demand pump to replace traditional pneumatic pumps and reduce operating costs. These pumps offer the same powerful, high-quality performance you've come to expect from Graco - only for less operating cost and more convenience.

• Electrical Flexibility - Available in 12 VDC and 115 VAC power options.
• Smooth Fluid Flow 4 gpm (15 lpm) - Output flow is continuous and non-pulsating up to 4 gpm (15 lpm).
• Heavy-Duty Motor with Long Life - Industrial-grade electric motors with over-temperature protection on 115 VAC models.
• Pump Reliability - Internal inlet and outlet checks keep pump section flooded to maintain prime for reliable performance.
• Simultaneous Dispenses - Pump long distances and supply fluid to multiple dispense points.

• Model: EGP

• Compatible Material: Oil

• Fluid Pressure Control Type: Internal Bypass, Electrical Pressure Shut Off Switch

• Inlet Thread Gender: Female
• Inlet Thread Size (in): 0.75
• Inlet Thread Type: NPT

• Maximum Current (A): 14.4

• Maximum Flow Rate (GPM): 4
• Maximum Flow Rate (L/min): 15.1

• Maximum Speed (RPM): 1750

• Maximum Working Pressure (bar): 34.5
• Maximum Working Pressure (psi): 500

• Outlet Thread Gender: Female
• Outlet Thread Size (in): 0.5
• Outlet Thread Type: NPT

• Overall Depth (in): 12.5
• Overall Depth (mm): 317.5

• Overall Height (in): 8
• Overall Height (mm): 203.2
• Overall Width (in): 6.75
• Overall Width (mm): 171.4

• Power Rating (HP): 1.5
• Power Type: Electric

GG 25R656

GG 25T767

GG 25T845

KIT,SLEEVE,GUIDE,6.5 RAM

GG 25T862

KIT, AGITATOR, SUB ASSY

Graco 25T862 Radial Piston Air Motor Retrofit Kit for Back-Geared Agitators

By upgrading back-geared agitators with radial piston air motors, factory paint mix rooms can cut compressed air costs by up to 85 percent.

• Installs quickly for immediate cost savings
• Needs no air line lubrication to keep running well
• Operates more quietly than comparable rotary vane agitator air motors

• Air Inlet Size (cm): 0.635
• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35
• Air Inlet Thread Type: NPT

• For Use With: 55 Gallon (208 Liter) Drum

• Maximum Air Inlet Pressure (bar): 5
• Maximum Air Inlet Pressure (kPa): 500
• Maximum Air Inlet Pressure (psi): 70

• Maximum Speed (RPM): 83

• Maximum Viscosity (cP): 3000

• Maximum Working Pressure (bar): 5
• Maximum Working Pressure (kPa): 500
• Maximum Working Pressure (psi): 70

• Motor Type: Pneumatic - Radial Piston

• Power Rating (HP): 0.16

GG 25T742

GG 25T806

GG 25T820

EGP TRANSFER PUMP, 115V, 4.25GPM

Graco 25T820 EGP Transfer Pump and Dispense Package, 115 VAC, 3.9 gpm (14.8 lpm), 65 psi (4.5 bar)

Choose cost-saving convenience with the all-new Graco EGP electric pumps. Attach the EGP transfer pump directly to roll-around barrels for more mobility in more places. These pumps offer the same powerful, high-quality performance you've come to expect from Graco - only for less operating cost and more convenience.

• Electrical Flexibility - Available in 12 VDC and 115 VAC power options.
• Smooth Fluid Flow 8 gpm (30 lpm) - Output flow is continuous and non-pulsating up to 8 gpm (30 lpm).
• Heavy-Duty Motor with Long Life - Industrial-grade electric motors with over-temperature protection on 115 VAC models.
• Pump Protection - Includes inlet strainer to keep larger debris out of pump housing and extend pump life.
• Plug and Play - Self-priming, precision-machined pump design.

• Model: EGP

• Application: Oil

• Compatible Material: Oil, Hydraulic Fluid, Antifreeze

• Fluid Pressure Control Type: Internal Bypass

• Frequency (Hz): 60

• Inlet Thread Gender: Female
• Inlet Thread Size (in): 1
• Inlet Thread Type: NPT

• Maximum Flow Rate (GPM): 4
• Maximum Flow Rate (L/min): 15.1

• Maximum Speed (RPM): 1700

• Maximum Working Pressure (bar): 4.5
• Maximum Working Pressure (MPa): 0.5
• Maximum Working Pressure (psi): 65

• Outlet Thread Gender: Female
• Outlet Thread Size: 0.75

• Overall Depth (in): 12.5
• Overall Depth (mm): 317.5

• Overall Height (in): 8
• Overall Height (mm): 203.2
• Overall Width (in): 6.75
• Overall Width (mm): 171.4

• Power Rating (HP): 0.5
• Power Type: Electric

GG 25U110

GG 25U037

GG 25U109

GG 25U116

GG 25U241

KIT, 515/716 CENT SECT REPAIR

GG 25U291

GG 25U312

GG 25U310

GG 25U371

GG 25U387

GG 25U421

GG 25U418

GG 25U444

GG 25U445

GG 25U546

LINELAZER SPRAYER, ES500, NA

Graco 25U546 LineLazer ES 500 Battery-Powered Airless Line Striper

The LineLazer ES 500 is a fully-capable line striper for those small to medium-sized re-stripe jobs - while introducing the benefits of battery-powered technology.

• NO ENGINE NOISE, VIBRATION OR FUMES

  Benefits of Battery Power Over a Gas Engine
  • Reduce user fatigue while delivering perfect lines
  • Improved jobsite conditions

• EXTENDED RUNTIME

  DEWALT 9.0 Ah FlexVolt Battery
  • Spray up to 10 gallons with two fully charged DEWALT FlexVolt batteries
  • Capable of completing 200+ parking lot stalls

• FAST CHARGING

  DEWALT Fan-Cooled Fast Charger
  • Quickly charges battery in under 60 minutes
  • Allows contractors to finish jobs without interruptions

• IMPROVED TRACKING AND LINE QUALITY

  Proven Frame Design
  • Durable, steel construction
  • Accepts 15-gallon hopper and EZ Bead System

• EASIER MANEUVERABILITY

  Front Swivel Wheel
  • Ability to stripe right up to the curb
  • Makes easy work of hard-to-do curves
  • Years of dependable operation with tapered locking pin design

• THE LONGEST LASTING DRIVE

  Advantage Drive
  • Hardened steel gears provide extremely quiet operation and a lifetime warranty

• DURABLE PUMP

  Endurance Pump
  • Last 2X longer than the next leading brand
  • Long life V-Max Blue Packings, Chromex rod, and hardened stainless steel cylinder
  • Faster cleaning with the QuikAccess intake valve

• ELIMINATE COSTLY DOWNTIME

  ProConnect Pump Replacement
  • Swap pump in minutes - no tools, pins or parts to lose

• EASY MAINTENANCE AND LESS CLOGGING

  Easy Out Filter
  • Exclusive inside-out filtering design reduces tip clogs

• Model: LineLazer
• Series: ES 500
• Product Series: Standard

• Attachments: None

• Number of Guns: 1

• Power Source: Battery Powered

GG 25U629

GG 25U628

GG 25V080

KIT, ACCESSORY, HAZ I/O CABLE

Graco 25V080 QUANTM Pump Input/Output (I/O) Cable

For use with QUANTM electric double diaphragm pumps that are certified for use in explosive athospheres or hazardous (classified) locations.

• For Use With: QUANTM Electric Double Diaphragm Pump

• Includes: 1 cable clamp assembly, 2 clamp fasteners, 1 ground fastener

• Maximum Operating Temperature ( degree C): 40
• Maximum Operating Temperature ( degree F): 104

• Minimum Operating Temperature ( degree C): -20
• Minimum Operating Temperature ( degree F): -4

GG 25X675

GG 25V370

GG 25V018

GG 25V176

GG 260292

GG 25V129

KIT, STATOR CAP, I30(QTC)

Graco 25V129 QUANTM i30 Stator Cap Kit

• Model: QUANTM
• Series: i30

GG 25V054

GG 260434

GG 260407

PUMP, PISTON HAND, FUEL

Graco 260407 Piston Hand Pump for Petroleum Products

• Lightweight die cast aluminum construction
• Corrosion resistant design
• High quality piston seals are designed for long life and smooth operation.
• Adjustable bung adapter allows pump to be rotated
• One quart per stroke gives fast, efficient fluid transfer
• Locking mechanism prevents unauthorized dispensing

• Application: Industrial

• Compatible Material: Oil, Grease

• Fluid Inlet Size (in): 1
• Fluid Inlet Size (mm): 25.4
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (in): 0.75
• Fluid Outlet Size (mm): 19.05
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT

• Includes: Hose, Die Cast Aluminum Nozzle, Inlet Suction Tube, Bung Adapter

GG 25V317

KIT, I80(QTD)SS, PT, PO, PT

Graco 25V317 QUANTM i180 Complete Fluid Repair Kit with SS Seat, PT Ball, PO Diaphragm and PT Seal

GG 25U661

GG 25V267

KIT, I30(QTC)SS, PT, PO, PT

Graco 25V267 QUANTM i30 Complete Fluid Repair Kit with SS Seat, PT Ball, PO Diaphragm and PT Seal

GG 260293

GG 25V520

GG 25V053

GG 260495

GG 25U645

GG 260504

GG 25U646

GG 261328

REACTOR HEATED HOSE, 25', 3/8, W/O CABLE

Graco 261328 25 ft (7.6 m) Heated 2 Component Low Pressure Hose with 3/8 in (9.5 mm) Inside Diameter and Ground Wire

Graco's heated hoses are designed specifically for use with Reactor Equipment. Hoses are a key component to the total system, making it important to achieve accurate and uniform heating for the best application possible.

• New multi-strand copper heating element has greatly increased hose quality:

  Provides 10-times* the flex life compared to previous flat copper heating element

  Long-term, even heating without hot spots

  Backwards compatible with existing Reactor heated hoses

  • Copper-heated hoses are designed specifically for use with Graco proportioners
  • Covered with proprietary butyl cover for protection against moisture sensitive isocyanate
  • Different fitting sizes on the isocyanate and resin hoses prevent accidentally connecting the wrong hoses together
  • Hoses use custom designed splice kit to electrically connect hoses without having to run copper under the fittings
  • Helix-design whip hose uses braided copper wires for added flexibility and longer life




  • Model: Reactor Heated Hoses
  • Series: No Scuff
  • Hose Heating Type: External Heated
  • Hose Length (ft): 25
  • Hose Length (m): 7.6
  • Maximum Working Pressure (bar): 138
  • Maximum Working Pressure (kPa): 13800
  • Maximum Working Pressure (MPa): 13.8
  • Maximum Working Pressure (psi): 2000

GG 261337

REACTOR HEATED HOSE, 1/4X3/8, DUAL CABLE

Graco 261337 50 ft (15 m) Heated Custom Application 2 Component Hose with 3/8 (9.5 mm) and 1/4 in (6.3 mm) Inside Diameter

Graco's heated hoses are designed specifically for use with Reactor Equipment. Hoses are a key component to the total system, making it important to achieve accurate and uniform heating for the best application possible.

• New multi-strand copper heating element has greatly increased hose quality:

  Provides 10-times* the flex life compared to previous flat copper heating element

  Long-term, even heating without hot spots

  Backwards compatible with existing Reactor heated hoses

  • Copper-heated hoses are designed specifically for use with Graco proportioners
  • Covered with proprietary butyl cover for protection against moisture sensitive isocyanate
  • Different fitting sizes on the isocyanate and resin hoses prevent accidentally connecting the wrong hoses together
  • Hoses use custom designed splice kit to electrically connect hoses without having to run copper under the fittings
  • Helix-design whip hose uses braided copper wires for added flexibility and longer life




  • Model: Reactor Heated Hoses
  • Series: Specialty
  • For Use With: Plural Component Proportioners
  • Hose Inside Diameter (in): 1/4
  • Hose Inside Diameter (mm): 6.35
  • Hose Length (ft): 50
  • Hose Length (m): 15.2
  • Maximum Working Pressure (bar): 241
  • Maximum Working Pressure (kPa): 24100
  • Maximum Working Pressure (MPa): 24.1
  • Maximum Working Pressure (psi): 3500

GG 261821

GG 261670

GG 261847

GG 261854

GG 261870

GG 261875

GG 261878

GG 261883

GG 261897

GG 261899

GG 261901

GG 262004

LINEDRIVER MODULE, 160CC

Graco 262004 LineDriver Ride-On Attachment

Why walk when you can ride? Graco LineDriver Systems provide the most innovative, user-friendly ride-on systems in the industry. The LineDriver is the industry standard ride-on system that will help you maximize productivity on any striping, thermoplastic and scarifying application.

• FlexBeam LED Light System

  LED light for improved brightness with long life and less amp draw

  Retractable, breakaway design prevents damage and keeps you striping

• Patented Dual Foot Pedal System

  For forward and reverse

  Easily move between jobs without having to push

• ProStart Engine Starting System

  Easy Starting

  Up to 50% less pulling effort to start the engine - no more broken recoils

  Outperforms manual pull and electric start systems when the weather starts turning cooler

• Cool-Comfort Seat

  Gray color stays cool in direct sunlight

  High-back seat for added support

  Extra padding for all-day comfort

• Model: LineDriver

• Engine Brand: Honda
• Engine Model: GX Engine

• For Use With: GrindLazer, ThermoLazer 300TC, ThermoLazer ProMelt, LineLazer 130HS, LineLazer ES 1000, LineLazer V 200HS, LineLazer V 250DC, LineLazer V 250SPS, LineLazer V 3900, LineLazer V 5900
• Fuel Tank Capacity (gal): 0.95
• Fuel Tank Capacity (L): 3.6

• Maximum Operating Speed (km/h): 16
• Maximum Operating Speed (mph): 10

• Maximum Reverse Speed (km/h): 10
• Maximum Reverse Speed (mph): 6

• Power Rating (cc): 160
• Power Rating (HP): 5.5
• Power Rating (kW): 4.1

GG 262005

LINEDRIVER MODULE, HD 200CC

Graco 262005 LineDriver HD Ride-On Attachment

Why walk when you can ride? Graco LineDriver Systems provide the most innovative, user-friendly ride-on systems in the industry. The LineDriver HD provides the higher power and performance you need to maximize your productivity on any striping, thermoplastic and scarifying application.

• FlexBeam LED Light System

  LED light for improved brightness with long life and less amp draw

  Retractable, breakaway design prevents damage and keeps you striping

• Patented Dual Foot Pedal System

  For forward and reverse

  Easily move between jobs without having to push

• ProStart Engine Starting System

  Easy Starting

  Up to 50% less pulling effort to start the engine - no more broken recoils

  Outperforms manual pull and electric start systems when the weather starts turning cooler

• Cool-Comfort Seat

  Gray color stays cool in direct sunlight

  High-back seat for added support

  Extra padding for all-day comfort

• Model: LineDriver
• Series: HD

• Engine Brand: Honda
• Engine Model: GX Engine

• For Use With: LineLazer, GrindLazer, ThermoLazer
• Fuel Tank Capacity (gal): 0.95
• Fuel Tank Capacity (L): 3.6

• Maximum Operating Speed (km/h): 16
• Maximum Operating Speed (mph): 10

• Maximum Reverse Speed (km/h): 10
• Maximum Reverse Speed (mph): 6

• Power Rating (cc): 200
• Power Rating (HP): 6.5

GG 262034

GG 262236

GG 262240

GG 262257

GG 262370

GG 262371

GG 262381

PROCONTROL 1KS PROPORTIONER, PROMX, REMTE

Graco 262381 ProControl 1KS with G3000 Meter

Maintain a closed loop flow control system for a superior finish with the same proven technology as the ProMix 2KS

• Single Component Flow Control
• Integrated Flushing
• Optional Color Change Modules

• Model: ProControl
• Series: 1KS

• Air Inlet Size (cm): 0.9525
• Air Inlet Size (in): 3/8
• Air Inlet Size (mm): 9.525
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Amperage (A): 2

• Fluid Inlet Size (cm): 0.635
• Fluid Inlet Size (in): 1/4
• Fluid Inlet Size (mm): 6.35
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (in): 1/4
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT

• Frequency (Hz): 50/60

• Includes: ProControl 1KS Module, G3000 Meter

• Maximum Air Inlet Pressure (bar): 6.9
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Flow Rate (cc/min): 3790

• Maximum Flow Rate (GPM): 1
• Maximum Flow Rate (L/min): 3.79

• Maximum Fluid Viscosity (cP): 5000

• Maximum Fluid Viscosity (cP): 5000

• Maximum Number of Colors: Up to 30

• Maximum Operating Temperature ( degree C): 50
• Maximum Operating Temperature ( degree F): 122

• Maximum Working Pressure (bar): 275.8
• Maximum Working Pressure (kPa): 27580
• Maximum Working Pressure (MPa): 27.6
• Maximum Working Pressure (psi): 4000

• Minimum Flow Rate (cc/min): 75
• Minimum Flow Rate (GPM): 0.02
• Minimum Flow Rate (L/min): 0.075

• Minimum Fluid Viscosity (cP): 20

GG 262398

MANIFOLD, MIX, PLURAL COMPONENT

Graco 262398 Fluid Mix Manifold for ProMix 2KE Proportioner, Sequential Dosing

GG 262399

MANIFOLD, MIX PLURAL COMPONENT

• Compatible Material: Waterborne, Solventborne, High Solids, Xirallic, CARC, Metallics, Topcoats, Stains, Varnish, UV Coating

GG 262412

GG 262484

GG 262522

GG 262549

REGULATOR, MASTIC

GG 262561

GG 262572

REACTOR A-25 PROPORTIONER, BARE

Graco 262572 Reactor A-25 Bare Proportioner

The Reactor A-25 is a Graco-engineered spray foam proportioner that gives you the reliability you expect on the jobsite. It maintains consistent temperature control, even when you're spraying at maximum flow rates - resulting in better quality foam.

• Maintains temperature setpoints for better yield
• Maintains consistent output pressure for uniform spray pattern
• Easy to operate and maintain
• DataTrak Control
  • Resettable counter tracks material usage
• Three Heat Zones
  • Three independent heat zones - ISO, resin and hose heat
  • Provide accurate heat control for reliable spraying to handle different chemical viscosities
  • Digital temperature controls
• Recirculation Manifold
  • A quick, easy way to balance system pressures
• NXT Air Motor
  • Low air consumption for increased efficiency
  • Muffler provides low operating noise levels
  • Air valve provides smooth and rapid changeover
• Quick Knockdown Lower Pumps
  • For easy disassembly and maintenance
• ISO Pump Lube System
  • Prevents isocyanate crystallization on the pump seal and shaft
• ISO Pump Lube System
  • Prevents isocyanate crystallization on the pump seal and shaft

• Model: Reactor
• Series: A-25

• Air Inlet Size (cm): 1.27
• Air Inlet Size (in): 1/2
• Air Inlet Size (mm): 12.7
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Amperage (A): 18.5 @ 380 V ac (3-Phase WYE), 32 @ 230 V ac (3-Phase Delta), 40 @ 230 V ac (1-Phase)
• Application: Spray Foam
• Applicator Type: Manual

• Compatible Material: Plural-Component

• Component A Inlet Size (in): 3/4
• Component A Inlet Size (mm): 19.05
• Component A Thread Gender: Female
• Component A Thread Type: NPT
• Component B Inlet Size (in): 3/4
• Component B Inlet Size (mm): 19.05
• Component B Thread Gender: Female
• Component B Thread Type: NPT
• Component Type: Two Component

• Flush Type: Solvent

• Frequency (Hz): 50/60

• Gun Type: No Gun

• Includes: Proportioner, Heated Hose

• Material Application: Polyurethane Foam

• Maximum Air Consumption (SCFM): 28 scfm at 1500 psi
• Maximum Air Inlet Pressure (bar): 8.62
• Maximum Air Inlet Pressure (kPa): 862
• Maximum Air Inlet Pressure (psi): 125

• Maximum Flow Rate (kg/min): 11.34
• Maximum Flow Rate (lb/min): 25

• Maximum Fluid Temperature ( degree C): 88
• Maximum Fluid Temperature ( degree F): 190
• Maximum Fluid Viscosity (cP): 1500

• Maximum Fluid Temperature ( degree C): 88
• Maximum Fluid Temperature ( degree F): 190
• Maximum Fluid Viscosity (cP): 1500

• Maximum Hose Length (ft): 210
• Maximum Hose Length (m): 64

• Maximum Mix Ratio: 1:1

• Maximum Working Pressure (bar): 138
• Maximum Working Pressure (kPa): 13800
• Maximum Working Pressure (MPa): 14
• Maximum Working Pressure (psi): 2000

• Minimum Fluid Viscosity (cP): 250

• Overall Depth (cm): 62.2

GG 262573

GG 262614

REACTOR A-25 PROPORTIONER, WHEELS, CYCLE COUNT

Graco 262614 Reactor A-25 Proportioner with Wheels, DataTrak

The Reactor A-25 is a Graco-engineered spray foam proportioner that gives you the reliability you expect on the jobsite. It maintains consistent temperature control, even when youre spraying at maximum flow rates - resulting in better quality foam.

• Maintains temperature setpoints for better yield
• Maintains consistent output pressure for uniform spray pattern
• Easy-to-service fluid section reduces maintenance and increases productivity
• DataTrak Control

  Resettable counter tracks material usage

• Three Heat Zones

  Three independent heat zones - ISO, resin and hose heat

  Provide accurate heat control for reliable spraying to handle different chemical viscosities

  Digital temperature controls

  • Recirculation Manifold

    A quick, easy way to balance system pressures

  • NXT Air Motor

    Low air consumption for increased efficiency

    Muffler provides low operating noise levels

    Air valve provides smooth and rapid changeover

    • Quick Knockdown Lower Pumps

      For easy disassembly and maintenance

    • ISO Pump Lube System

      Prevents isocyanate crystallization on the pump seal and shaft

    • ISO Pump Lube System

      Prevents isocyanate crystallization on the pump seal and shaft




    • Model: Reactor
    • Series: A-25
    • Air Inlet Size (cm): 1.27
    • Air Inlet Size (in): 1/2
    • Air Inlet Size (mm): 12.7
    • Air Inlet Thread Gender: Female
    • Air Inlet Thread Type: NPT
    • Amperage (A): 18.5 @ 380 V ac (3-Phase WYE), 32 @ 230 V ac (3-Phase Delta), 40 @ 230 V ac (1-Phase)
    • Application: Spray Foam
    • Applicator Type: Manual
    • Compatible Material: Plural Components
    • Component A Inlet Size (in): 3/4
    • Component A Inlet Size (mm): 19.05
    • Component A Thread Gender: Female
    • Component A Thread Type: NPT
    • Component B Inlet Size (in): 3/4
    • Component B Inlet Size (mm): 19.05
    • Component B Thread Gender: Female
    • Component B Thread Type: NPT
    • Component Type: Two Component
    • Flush Type: Solvent
    • Frequency (Hz): 50/60
    • Gun Type: No Gun
    • Includes: Proportioner, Heated Hose, Wheels, DataTrak
    • Material Application: Polyurethane Foam
    • Maximum Air Consumption (SCFM): 28 scfm at 1500 psi
    • Maximum Air Inlet Pressure (bar): 8.62
    • Maximum Air Inlet Pressure (kPa): 862
    • Maximum Air Inlet Pressure (MPa): 0.86
    • Maximum Air Inlet Pressure (psi): 125
    • Maximum Flow Rate (kg/min): 11.34
    • Maximum Flow Rate (lb/min): 25
    • Maximum Fluid Temperature ( degree C): 88
    • Maximum Fluid Temperature ( degree F): 190
    • Maximum Fluid Viscosity (cP): 1500
    • Maximum Fluid Temperature ( degree C): 88
    • Maximum Fluid Temperature ( degree F): 190
    • Maximum Fluid Viscosity (cP): 1500
    • Maximum Hose Length (ft): 210
    • Maximum Hose Length (m): 64
    • Maximum Mix Ratio: 1:1
    • Maximum Working Pressure (bar): 138
    • Maximum Working

GG 262696

GG 262711

GG 262700

KIT,AIR CAP,HORIZONTAL

Graco 262700 Horizontal Air Cap Kit

KIT INCLUDES: AIR CAP, ASM, HORIZ, EXTERNAL MIX [QTY. 1], KIT INCLUDES: AIR CAP, ASM, INTERNAL MIX [QTY. 1],

GG 262740

GG 262805

MAGNUM SPRAYER, X7

Graco 262805 Magnum X7 Electric TrueAirless Sprayer

DIY homeowners and handymen will save time and money with the Magnum X7 with built-in cart. Tackle any interior project, exterior houses, fences and decks. The X7 supports a larger tip size for spraying heavier coatings and the convenient cart makes any painting project faster and easier.

• Hardened Stainless Steel Piston Pump - Delivers high pressure power to spray unthinned paints
• Flexible Suction Hose - Spray directly from 1 or 5 gallon paint container
• Convenient Cart - Easily move sprayer around on the job
• TrueAirless Spray Tip with SoftSpray Technology - greater control and less overspray with a wide range of coatings
• Power Flush Adapter - Connects to a garden hose for fast and easy cleaning
• PushPrime - Fast and reliable start-up every time
• Adjustable Pressure Control - Easy control of paint flow

• Model: Magnum
• Series: X7
• Product Series: Project

• Amperage (A): 9.0

• Compatible Tip Size (in): 0.009, 0.011, 0.013, 0.015, 0.017

• Engine Size (HP): 0.625

• Fluid Outlet Size (in): 1/4
• Fluid Outlet Size (mm): 6.35
• Fluid Outlet Thread Type: NPSM

• Frame Configuration: Cart

• Includes: SG2 Spray Gun, TrueAirless 515 Spray Tip, Spray Tip Guard, 1/4 in x 25 ft DuraFlex Hose, Pump Armor Storage Fluid (8 oz), Quick Start-Up Guide
• Inlet Paint Strainer: 35 Mesh Stainless Steel Screen

• Maximum Flow Rate (GPM): 0.31
• Maximum Flow Rate (L/min): 1.2

• Maximum Hose Length (ft): 100
• Maximum Hose Length (m): 30

• Maximum Tip Size (in): 0.017
• Maximum Tip Size Gun 1 (in): 0.017

• Maximum Working Pressure (bar): 207
• Maximum Working Pressure (kPa): 20700
• Maximum Working Pressure (MPa): 20.7
• Maximum Working Pressure (psi): 3000

• Minimum Generator Power (W): 2500

• Motor Type: Universal

• Number of Guns: 1

• Overall Height (cm): 94.0
• Overall Height (in): 37.0
• Overall Height (mm): 940
• Overall Length (cm): 49
• Overall Length (in): 19.3
• Overall Length (mm): 490
• Overall Width (cm): 38.9
• Overall Width (in): 15.3
• Overall Width (mm): 389

• Phase: 1

• Power Rating (HP): 0.625
• Power Rating (kW): 0.47
• Power Rating (W): 466
• Power Source: Electric
• Pressure Control Type: Adjustable

• Pump Rod Type: Hardened Stainless Steel
• Pump Sleeve Material: Stainless Steel

• Recommended Annual Usage (gal): 125

GG 262854

XHF GUN, SPRAY

Graco 262854 XHF Airless Spray Gun, XHD RAC Tip

Designed to spray high viscosity materials, the XHF Gun is rugged, reliable and easy to maintain.

• High-flow, high pressure gun
• Handles epoxy intumescent materials, high-viscosity coatings, fiber filled materials
• Reduced clogging means more productivity and uptime

• Applicator Type: Manual

• Compatible Material: Epoxy Intumescent Fireproofing

• Fluid Inlet Size (cm): 0.9525
• Fluid Inlet Size (in): 3/8
• Fluid Inlet Size (mm): 9.525
• Fluid Inlet Thread Gender: Male
• Fluid Inlet Thread Type: NPT
• Fluid Orifice Size (cm): 0.32
• Fluid Orifice Size (in): 0.125
• Fluid Orifice Size (mm): 3.2

• For Use With: Protective Coating High-Pressure Equipment

• Gun Activation: Manual
• Gun Included: 1
• Gun Type: Airless Gun
• Gun Weight (g): 720
• Gun Weight (kg): 0.72
• Gun Weight (lb): 1.6
• Gun Weight (oz): 25

• Includes: XHD RAC Guard, XHD429 SwitchTip

• Maximum Fluid Pressure (bar): 500
• Maximum Fluid Pressure (kPa): 50000
• Maximum Fluid Pressure (MPa): 50
• Maximum Fluid Pressure (psi): 7250

• Maximum Fluid Pressure (bar): 500
• Maximum Fluid Pressure (kPa): 50000
• Maximum Fluid Pressure (MPa): 50
• Maximum Fluid Pressure (psi): 7250

• Maximum Fluid Working Pressure (bar): 500
• Maximum Fluid Working Pressure (MPa): 50
• Maximum Fluid Working Pressure (psi): 7250

• Overall Height (cm): 17.8
• Overall Height (in): 7.0
• Overall Height (mm): 178
• Overall Length (cm): 21
• Overall Length (in): 8.25
• Overall Length (mm): 210

• Product Type: Spray Gun

• Purge Method: Liquid

GG 262929

G40 GUN, ASSY, AA, RAC TIP

Graco 262929 G40 Air-Assisted Airless Gun

Designed to maximize efficiency and quality, G40 air-assist spray guns use the highest quality components for long lasting reliable performance. The AAF tip line is designed for soft spray and improved transfer efficiency.

• High quality air-assisted spraying in a variety of applications
• All tips have a ring to retain the tip in the aircap
• Designed to minimize wear of replacement parts
• Trigger pull force is ultra-light, reducing operator fatigue and muscle stress

• Model: G40

• Air Inlet Size (cm): 0.635
• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35
• Air Inlet Thread Type: NPSM

• Applicator Type: Manual

• Bleed Type: Non-Bleeder

• Compatible Material: Lacquer, Latex, Plural Component Materials, Polyurethane, Solvent borne, Urethane, UV Coating, Varnish, Waterborne

• Feed Type: Pressure Feed

• Gun Activation: Manual
• Gun Included: 1
• Gun Type: Air-Assisted Gun
• Gun Weight (g): 16
• Gun Weight (oz): 16

• Includes: RAC X FF LP Spray Tip

• Maximum Air Inlet Pressure (bar): 7
• Maximum Air Inlet Pressure (kPa): 700
• Maximum Air Inlet Pressure (MPa): 0.7
• Maximum Air Inlet Pressure (psi): 100
• Maximum Air Pressure (bar): 7

• Maximum Air Pressure (kPa): 700
• Maximum Air Pressure (MPa): 0.7
• Maximum Air Pressure (psi): 100

• Maximum Fluid Pressure (bar): 280
• Maximum Fluid Pressure (kPa): 28000
• Maximum Fluid Pressure (MPa): 28.0
• Maximum Fluid Pressure (psi): 4000
• Maximum Fluid Temperature ( degree C): 43
• Maximum Fluid Temperature ( degree F): 110

• Maximum Fluid Pressure (bar): 280
• Maximum Fluid Pressure (kPa): 28000
• Maximum Fluid Pressure (MPa): 28.0
• Maximum Fluid Pressure (psi): 4000
• Maximum Fluid Temperature ( degree C): 43
• Maximum Fluid Temperature ( degree F): 110

• Minimum Flow Rate @ PSI (oz/min): 5

• Product Type: Spray Gun

GG 262942
