GRACO INC. S10595

GG 77X122

KIT, STDRUM, 24VDC, HF, 400#

Graco 77X122 Standard Drum Kits - 24 VDC HF Pump and Cover for 400 lb (180 kg). Reservoir

The Dyna-Star HP and HF 24VDC Electric Lubrication Pumps complement our Dyna-Star 10:1 Hydraulic and Fire-Ball 300 50:1 Pneumatic pump offering. Now you have three power source options for automatic lubrication systems and transfer applications. Heavy-duty construction and mining equipment rely on fresh lubricant to flush contaminants from critical pivot points. An automatic lubrication system from Graco provides continuous lube replenishment, reducing expensive component failures to keep your equipment working.

• Auto Fill Shut Off - mechanical shut off of fill pump for clean and efficient refill
• Graco Advantage Drive - heavy duty gear drive-lubed for life
• Tube-in-tube vent and fill path - convert drum to injector system instantly
• Motor control - speed and AMP control
• Cold weather performance (-40 degree C)
• More efficient seal replacement

• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35
• Air Inlet Thread Type: NPT

• Application: In-Plant Machinery, Off-Road Equipment

• Compatible Material: Grease
• Compatible Metering Device: Single Line Parallel

• Fluid Outlet Size (in): 0.375
• Fluid Outlet Size (mm): 9.5250
• Fluid Outlet Thread Type: NPT

• Includes: HF Pump 24 VDC, Cover for 120 lb (54 kg) reservoir

• IP Rating: IP69K

• Maximum Working Pressure (bar): 241
• Maximum Working Pressure (kPa): 24100
• Maximum Working Pressure (MPa): 24.1
• Maximum Working Pressure (psi): 3500

• Minimum cST Grade (cST): 40

• Overall Height (cm): 112.5
• Overall Height (in): 44.3
• Overall Height (mm): 1125
• Overall Width (cm): 27.9
• Overall Width (in): 11
• Overall Width (mm): 279

• Power Connection Type: M23

• Power Type: Pneumatic

GG 7734-06

GG 24K285

GG 24K414

KIT, ACCESSORY, PRESS SWITCH

Graco 24K414 General Pressure Switch, 1/4 NPT Male, 9.6-32 VDC, 4-Pin, M12 Micro-Connector

Signals your lubrication controller when the lube system reaches the desired pressure level.

• Easy to visually adjust line pressure and reset pressure to ensure your lube system has vented properly
• LED lights visually display pressure switch functions
• Modern 4-pin M12 micro-connector easily connects to the G3 and other controllers
• Sends an alarm signal to alert either a high or low pressure condition
• Available for hydraulic pressures from 290 to 5800 psi (20 to 400 bar)
• 1/4 in NPT thread allows quick connection to injector systems

• Adjustable: Adjustable

• Application: On-Road Vehicles, Off-Road Equipment

• Inlet Size (cm): 0.635
• Inlet Size (in): 0.25
• Inlet Size (mm): 6.35

• Inlet Thread Type: NPT

• Maximum Operating Pressure (psi): 5800

• Power Connection Type: 4-Pin

GG 24K694

KIT, GLYCERIN, GALLON, GR

Graco 24K694 Glycerin Based Hose Lube (1 gallon)

GG 24K682

GG 24K801

KIT,FMA,CARTRIDGE,HI RES,016

KIT INCLUDES: PLATE, FMA, CARTRIDGE, HI RES, 016 [QTY. 1], DOCUMENT, DECLARATION [QTY. 1], CONNECTOR, SPLITTER, (2)M12(M)XM12(F) [QTY. 1], CABLE, CAN, FEMALE/FEMALE, 15.0M [QTY. 1]

GG 24K803

KIT,FMA,MASTIC,HI RES,016

KIT INCLUDES: PLATE, FMA, MASTIC, HI RES, 016 [QTY. 1], DOCUMENT, DECLARATION [QTY. 1], CONNECTOR, SPLITTER, (2)M12(M)XM12(F) [QTY. 1], CABLE, CAN, FEMALE/FEMALE, 15.0M [QTY. 1]

GG 24K903

KIT, DIAPHRAGM-L1 FK

Graco 24K903 FKM (Viton) Diaphragm Kit for 3-inch Pump

GG 24K906

GG 24K928

KIT, SEAT 3300 AC

Graco 24K928 3-inch Acetal Seat Kit

GG 24K934

KIT, SEAT 3300 SP

Graco 24K934 Seat Kit

GG 24K935

KIT, SEAT 3300 SS

Graco 24K935 Seat Kit

GG 24K943

KIT, BALL-L1/L2 PT

Graco 24K943 Ball Kit

GG 24K944

KIT, BALL-L1/L2 SP

Graco 24K944 Ball Kit

GG 24K954

GG 24K994

GG 24K993

GG 24N323

CHANNEL, XD ENCLOSURE, 1 REEL

Graco 24N323 XD Series Hose Reel Enclosed Reel Mounting Channel - Accommodates 1 Reel

• Number of Pieces: 9

GG 24M392

GG 24N350

GG 24M478

VALVE, VENT, 12VDC, N.O. NPT, DEU RH

Graco 24M478 Direct-Mount Vent Valves for G3 Pumps - NPT, 12 VDC, 500-3500 psi (35-241 bar), Normally Open, RH

Industry leading feature for your lube system needs.

• Easily mounts to your G3 pump.
• Eliminates time and material costs associated with remote mounted vent valves.
• 12 VDC
• The normally open valve works with the G3 Standard no control pump. With an external control just add power to the pump and valve to run a lube cycle, and remove power from both to vent pressure.
• Adjustable pressure relief is integrated into the valve, no need to purchase an additional relief valve.
• Deutsch Power Connection

• Model: Trabon

• Application: On-Road Vehicles, Off-Road Equipment

• Compatible Material: Grease

• Factory Set Pressure (bar): 280
• Factory Set Pressure (kPa): 28000
• Factory Set Pressure (psi): 4000

• For Use With: G3 Pumps

• Inlet Thread Type: NPT

• Maximum Flow Rate (GPM): 5
• Maximum Flow Rate (L/min): 19

• Maximum Working Pressure (bar): 241
• Maximum Working Pressure (kPa): 24100
• Maximum Working Pressure (MPa): 24
• Maximum Working Pressure (psi): 3500

• Outlet Thread Type: NPT

GG 24M122

GG 24N095

HUSKY PUMP, 515F-PP01AP3PVPTPOPT

Graco 24N095 Husky 515 PVDF Pump, PP Center Section, PVDF Seats, PTFE Balls & PO Diaphragm

The Husky 515 air-operated double diaphragm pump features a stall-free low pulsation air valve which provides a smooth and rapid changeover.

The bolt through fluid cover design eliminates leaks and makes the Husky safer with higher reliability.

• Center and end porting options.
• No mechanical seals to cause fluid leaks or failures
• Runs quietly at less than 85 dBa with easy-to-use remote muffler capability for even lower noise levels
• Operates on as little as 20 psi (1.4 bar, 0.14 MPa)
• Split manifold option to pump multiple fluids without mixing
• Delivery up to 15 gpm (56.7 lpm)
• Easy-to-service air valve and ball checks
• Reliable air valve for years of dependable performance

• Model: Husky
• Series: 515

• Air Exhaust Port Size (in): 3/8
• Air Exhaust Port Thread Gender: Female
• Air Exhaust Port Thread Type: NPT
• Air Inlet Size (in): 1/4
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Industrial

• Ball Material: PTFE

• Center Section Material: Polypropylene

• Compatible Material: Antifreeze, Detergents, Resin, Polymers, Motor Oil, Grease & Oil, Hydraulic Fluid, Transmission Fluid, Cutting Oil, Water - Wastewater Treatment, Ink

• Connection Type: Threaded

• Diaphragm Compatible Material: PTFE
• Diaphragm Material: PTFE Overmold

• Fluid Inlet Size (cm): 1.27
• Fluid Inlet Size (in): 1/2
• Fluid Inlet Size (mm): 12.7
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (cm): 1.27
• Fluid Outlet Size (in): 1/2
• Fluid Outlet Size (mm): 12.7
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT
• Fluid Section Material: PVDF (Kynar)

• Manifold Configuration: Center Port
• Manifold O-Ring Material: PTFE
• Material: PVDF

• Maximum Air Consumption (SCFM): 28
• Maximum Air Pressure (bar): 7

• Maximum Air Pressure (kPa): 700
• Maximum Air Pressure (MPa): 0.7
• Maximum Air Pressure (psi): 100

• Maximum Cycle Rate (CPM): 400

• Maximum Flow Rate (GPM): 15
• Maximum Flow Rate (L/min): 56.8

• Maximum Fluid Pressure (bar): 7
• Maximum Fluid Pressure (kPa): 700
• Maximum Fluid Pressure (MPa): 0.7
• Maximum Fluid Pressure (psi): 100

• Maximum Fluid Pressure (bar): 7
• Maximum Fluid Pressure (kPa): 700
• Maximum Fluid Pressure (MPa): 0.7
• Maximum Fluid Pressure (psi): 100

• Maximum Operating Temperature ( degree C): 107
• Maximum Operating Temperature ( degree F): 225

• Maximum Solid Size (cm): 0.2383
• Maximum Solid Size (in): 0.09375
• Maximum Solid Size (mm): 2.4

• Minimum Operating Temperature ( degree C): 4
• Minimum Operating Temperature ( degree F): 40

• Overall Height (in): 10.63

• Power Source: Air

GG 24N096

HUSKY PUMP, 515AC-PP01AA3ACPTPOPT

Graco 24N096 Husky 515 1/2 in NPT AC Pump, PP Center Section, AC Seats, PTFE Balls & PO Diaphragm

Our Husky air-operated double diaphragm pumps are loaded with features to help you get the job done right, every time, and are built to save you money. The Husky 515 air-operated double diaphragm pump features a stall-free low pulsation air valve which provides a smooth and rapid changeover. The bolt through fluid cover design eliminates leaks and makes the Husky safer with higher reliability.

• Rugged construction

  Resists corrosion for reliable performance and long life

  • Heavy-duty design

    Offers long life, increased productivity and lower overall cost of ownership

    • Benefits of the Husky 515 double diaphragm pump

      Center and end porting options.

      No mechanical seals to cause fluid leaks or failures

      Runs quietly at less than 85 dBa with easy-to-use remote muffler capability for even lower noise levels

      Easy-to-service air valve and ball checks

      Operates on as little as 20 psi (1.4 bar, 0.14 MPa)

      Split manifold option to pump multiple fluids without mixing

      • Delivery up to 15 gpm (56.7 lpm)
      • Easy-to-service air valve and ball checks
      • Reliable air valve for years of dependable performance
      • Lube-free for cleaner operation
      • DataTrak available to prevent pump runaway and track material usage




      • Model: Husky
      • Series: 515
      • Air Exhaust Port Size (in): 3/8
      • Air Exhaust Port Thread Gender: Female
      • Air Exhaust Port Thread Type: NPT
      • Air Inlet Size (in): 1/4
      • Air Inlet Thread Gender: Female
      • Air Inlet Thread Type: NPT
      • Application: Industrial
      • Ball Material: PTFE
      • Center Section Material: Polypropylene
      • Compatible Material: Antifreeze, Detergents, Resin, Polymers, Motor Oil, Grease & Oil, Hydraulic Fluid, Transmission Fluid, Cutting Oil, Water - Wastewater Treatment, Ink
      • Connection Type: Threaded
      • Diaphragm Compatible Material: PTFE
      • Diaphragm Material: PTFE Overmold
      • Fluid Inlet Size (cm): 1.27
      • Fluid Inlet Size (in): 1/2
      • Fluid Inlet Size (mm): 12.7
      • Fluid Inlet Thread Gender: Female
      • Fluid Inlet Thread Type: NPT
      • Fluid Outlet Size (cm): 1.27
      • Fluid Outlet Size (in): 1/2
      • Fluid Outlet Size (mm): 12.7
      • Fluid Outlet Thread Gender: Female
      • Fluid Outlet Thread Type: NPT
      • Fluid Section Material: Acetal
      • Manifold Configuration: Center Port
      • Manifold O-Ring Material: PTFE
      • Material: Acetal
      • Maximum Air Consumption (SCFM): 28
      • Maximum Air Pressure (bar): 7
      • Maximum Air Pressure (kPa): 700
      • Maximum Air Pressure (MPa): 0.7
      • Maximum Air Pressure (psi): 100
      • Maximum Cycle Rate (CPM): 400
      • Maximum Flow Rate (GPM): 15
      • Maximum Flow Rate (L/min): 56.8
      • Maximum Fluid Pressure (bar): 7
      • Maximum Fluid Pressure (kPa): 700
      • Maximum Fluid Pressure (MPa): 0.7
      • Maximum Fluid Pressure (psi): 100
      • Maximum Fluid Pressure (bar): 7
      • Maximum Fluid Pressure (kPa): 700
      • Maximum Fluid Pressure (MPa): 0.7
      • Maximum Fluid Pressure (psi): 100
      • Maximum Operating Temperature ( degree C): 82

GG 24M154

GG 24M261

KIT, METER, I.S. CORLIOLIS 1/4"

Graco 24M261 Coriolis Meter Kit, Cubemass DCI Meter with 1/4 in (6 mm) metering tube for ProControl 1KS and ProMix 2KS/2KE/3KS

GG 24M174

GG 24M121

GG 24M644

KIT, ACCESSORY, FILL STUD/CAP

Graco 24M644 G-Series Pump Accessories - High Capacity Fill Zerk with Quick Disconnect and Dust Cover

• High capacity fill zerk with quick disconnect and dust cover

• Connection Type: Quick-Disconnect

GG 24N258

HUSKY PUMP, 716A-PP01AA1SSPTPOPT

Graco 24N258 Husky 716 AL Pump, PP Center Section, SS Seats, PTFE Balls & PO Diaphragm

The Husky 716 air operated diaphragm pump features an external controller for remote control capabilities.

• Center- and end-porting
• No mechanical seals which causes fluid leaks or failures
• Runs quietly at less than 85 dBa with easy-to-use remote muffler capability for even lower noise levels
• 3/4 in (19.05 mm) center- and end-porting
• No seals to leak or fail
• Quiet running less than 85 dBa with easy-to-use remote muffler capability for even lower noise levels
• Easy-to-service air valve and ball checks

• Model: Husky
• Series: 716

• Air Exhaust Port Size (in): 3/8
• Air Exhaust Port Thread Gender: Female
• Air Exhaust Port Thread Type: NPT
• Air Inlet Size (in): 1/4
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Industrial

• Ball Material: PTFE

• Center Section Material: Polypropylene

• Compatible Material: Antifreeze, Detergents, Motor Oil, Grease & Oil, Hydraulic Fluid, Cutting Oil, Water - Wastewater Treatment, Water, Ink

• Connection Type: Threaded

• Diaphragm Compatible Material: PTFE
• Diaphragm Material: PTFE Overmold

• Fluid Inlet Size (cm): 1.905
• Fluid Inlet Size (in): 3/4
• Fluid Inlet Size (mm): 19.05
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (cm): 1.905
• Fluid Outlet Size (in): 3/4
• Fluid Outlet Size (mm): 19.05
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT
• Fluid Section Material: Aluminum

• Manifold Configuration: Center Port
• Manifold O-Ring Material: PTFE
• Material: Aluminum

• Maximum Air Consumption (SCFM): 28
• Maximum Air Pressure (bar): 7

• Maximum Air Pressure (kPa): 700
• Maximum Air Pressure (MPa): 0.7
• Maximum Air Pressure (psi): 100

• Maximum Cycle Rate (CPM): 400

• Maximum Flow Rate (GPM): 16
• Maximum Flow Rate (L/min): 60.6

• Maximum Fluid Pressure (bar): 7
• Maximum Fluid Pressure (kPa): 700
• Maximum Fluid Pressure (MPa): 0.7
• Maximum Fluid Pressure (psi): 100

• Maximum Fluid Pressure (bar): 7
• Maximum Fluid Pressure (kPa): 700
• Maximum Fluid Pressure (MPa): 0.7
• Maximum Fluid Pressure (psi): 100

• Maximum Operating Temperature ( degree C): 107
• Maximum Operating Temperature ( degree F): 225

• Maximum Solid Size (cm): 0.2383
• Maximum Solid Size (in): 0.09375
• Maximum Solid Size (mm): 2.4

• Minimum Operating Temperature ( degree C): 4
• Minimum Operating Temperature ( degree F): 40

• Overall Height (in): 10.43

• Power Source: Air

GG 24M833

GG 24N365

GG 24N468

GLC CONTROL, 2200

Graco 24N468 GLC 2200 Series Controller

You spend a lot on your equipment. The GLC 2200 controller helps protect components by alerting you to lube events, failures and low lubrication levels. You have peace of mind knowing your investment is protected.

• Easy to mount without having to open up the control box
• LEDs let you know what your system is doing at a glance
• Easy to read digital display makes it simple to program and monitor your equipment
• Simple icon based push buttons make programming easy
• Color coded wiring harness with flying leads and easy to follow wiring diagrams makes installations efficient

• Model: GLC
• Series: 2200

• Amperage (A): 7, 9
• Application: In-Plant Machinery, Off-Road Equipment

• For Use With: Automatic Lubrication Systems

• Intrusion Rating: IP54

• Maximum Operating Temperature ( degree C): 80
• Maximum Operating Temperature ( degree F): 176

• Maximum Storage Temperature ( degree C): 80
• Maximum Storage Temperature ( degree F): 176

• Maximum Voltage (V dc): 30

• Minimum Operating Temperature ( degree C): -40
• Minimum Operating Temperature ( degree F): -40

• Minimum Storage Temperature ( degree C): -40
• Minimum Storage Temperature ( degree F): -40

• Power Consumption (W): 1

• Power Source: DC

GG 24N551

WB3000 SYSTEM, ISOLATION, WB, AA

Graco 24N551 WB3000 Waterborne Iso Enclosure, Pro Xp60 ES AA WB Gun, Grounded Air/Unshielded WB Fluid Hoses, FM Approved & Compliant with EN50059

Gracos WB3000 is the dependable way to isolate waterborne coatings when spraying with electrostatic equipment. Ideal for spray booth systems.

• Ideal for high pressure waterborne material spraying with the Pro Xp60 AA WB gun for a superior finish quality and operator comfort
• Merkur ES 30:1 pump is one of the most efficient sprayers designed to use less material and reduce air usage and pulsation
• Standard voltage display allows for easy monitoring of voltage for overall performance
• Electrostatic gun Smart Controls help you analyze performance, adapt to your voltage needs and make troubleshooting easier
• Portable cabinet increases mobility for a wide variety of applications

• Model: WB3000

• Compatible Material: Waterborne, Single Components, Topcoats, Lacquer

• Convertible: Non-Convertible

• Gun Included: 1
• Gun Model: Waterborne
• Gun Technology: Electrostatic
• Gun Type: Electrostatic

• Includes: Standard Electrostatic Air-Assisted Spray Gun, Unshielded Waterborne Fluid Hose

• Maximum Flow Rate (GPM): 0.4

• Maximum Sound Pressure Level (dB(A)): 99

• Maximum Working Pressure (bar): 210
• Maximum Working Pressure (kPa): 21000
• Maximum Working Pressure (MPa): 21
• Maximum Working Pressure (psi): 3000

• Motor Type: Pneumatic

• Number of Guns: 1

• Power Source: Air

• Pressure Type: High Pressure
• Product Type: Spray Package

• Pump Ratio: 30:1
• Pump Sleeve Material: Stainless Steel
• Pump Type: Pneumatic Piston Pump

GG 24N528

KIT,ADAPTER, 60KV AND 85KV

Graco 24N528 Gun Flush Box Adapter Kit for 60 kV and 85 kV guns

• Coating Type: Standard, Specialty

• Compatible Paint Type: Automotive, Base Coat, Clear Coat, Enamels, High Solids, Metallics, Plural Component Materials, Primers, Solventborne, Urethanes

GG 24N642

GG 24N650

GG 24N662

GG 556032

ELEMENT, FILTER, 20 MICRON

Graco 556032 Replacement Element for Cartridge Oil Filter - 20 Micron, Lubriquip part number 183-100-106

• Pressure Filter - Replacement Elements - 20 micron

• For Use With: Meter-Flo Pump Packages, Cartridge Oil Filters

GG 557494

NUT, LOCK 3/8-24

Graco 557494 Trabon MX Divider Valve - Tie Rod Nut

• MX tie rod nut (8 required per assembly)
• Lubriquip part number 510-506-001

• Model: Trabon
• Series: MX

• Finish/Coating: Zinc

• Grade: C

• Inside Diameter (in): 0.375
• Inside Diameter (mm): 9.525

• Nut Type: Lock Nut

• Overall Height (in): 0.415
• Overall Height (mm): 10.541
• Overall Width (in): 0.5625
• Overall Width (mm): 14.2875

GG 557732

ROD, TIE, MSP, 4 SECTON

Graco 557732 Trabon MSP Divider Valve - 4 Section Tie Rod (3 Required)

• 4-Section Tie Rods
• Three tie rods and tie rod nuts required for assembly
• Lubriquip part number 527-001-830

• Model: Trabon
• Series: MSP

• Application: On-Road Vehicles, Off-Road Equipment, Compressor Equipment

GG 557392

ADAPTER, 1/8 NPTF HEX

Graco 557392 Pipe Extension - 1/8 NPT male X 1/8 NPT female, 3/4 long

• 1/8 NPTF Thread Pipe Extension Nipple - Steel
• 3/4overall length
• Lubriquip part number 509-027-000

• Connection Type: Threaded

• Finish/Coating: Zinc

• For Use With: Pipe

• Material: Steel

GG 557438

DISK, .688 2950 PSI BLUE

Graco 557438 Replacement Rupture Disk, 11/16 in, 2950 psi, Blue

• Used in conjunction with system pressure switch - can warn of a fault while allowing lube system to continue to deliver to critical bearings.
• Requires replacement of the rupture disc to restart the lube system.
• Easy information on blocked lines, high system pressure or blocked bearings.
• Lubriquip part number 509-297-000
• Trabon part number 9297

• Color: Blue

• Maximum Working Pressure (bar): 203
• Maximum Working Pressure (kPa): 20326
• Maximum Working Pressure (MPa): 20.3
• Maximum Working Pressure (psi): 2950

• Number of Pieces: 6

• Overall Diameter (cm): 1.7
• Overall Diameter (in): 0.688

• Overall Diameter (mm): 17

GG 557518

ROD, TIE MJ 6

Graco 557518 Trabon MJ Divider Valve - 6 Section Tie Rod (2 Required)

• 6-Section Tie Rods
• Two tie rods and tie rod nuts required for assembly.
• NPSF
• Trabon part number 10999-6

• Model: Trabon
• Series: MJ

• Application: On-Road Vehicles, Off-Road Equipment

GG 557433

DISK, .688 1450 PSI YELLOW

Graco 557433 Replacement Rupture Disk, 11/16 in, 1450 psi, Yellow

• Used in conjunction with system pressure switch - can warn of a fault while allowing lube system to continue to deliver to critical bearings.
• Requires replacement of the rupture disc to restart the lube system.
• Easy information on blocked lines, high system pressure or blocked bearings.
• Lubriquip part number 509-292-000
• Trabon part number 9292

• Color: Yellow

• Maximum Working Pressure (bar): 100
• Maximum Working Pressure (kPa): 9991
• Maximum Working Pressure (MPa): 10
• Maximum Working Pressure (psi): 1450

• Number of Pieces: 6

• Overall Diameter (cm): 1.7
• Overall Diameter (in): 0.688

• Overall Diameter (mm): 17

GG 557428

DISK, .375 2950/7300 PSI BLU

Graco 557428 Replacement Rupture Disk, 3/8 in, 7300 psi, Blue

• Used in conjunction with system pressure switch - can warn of a fault while allowing lube system to continue to deliver to critical bearings.
• Requires replacement of the rupture disc to restart the lube system.
• Easy information on blocked lines, high system pressure or blocked bearings.
• Lubriquip part number 509-283-000
• Trabon part number 9283

• Color: Blue

• Maximum Working Pressure (bar): 503
• Maximum Working Pressure (kPa): 50297
• Maximum Working Pressure (MPa): 50.3
• Maximum Working Pressure (psi): 7300

• Number of Pieces: 1

• Overall Diameter (cm): 1
• Overall Diameter (in): 0.375

• Overall Diameter (mm): 10

GG 557374

FITTING, FILL STUD, 1/4 NPT

Graco 557374 Trabon Style Fill Stud, 1/4 inch NPT male

• Trabon Style Fill Stud
• Lubriquip part number 506-189-001
• Trabon part number 6189-1

• Series: Trabon

• Connection Type: Threaded

• End A Inlet Thread Gender: None

• Maximum Working Pressure (psi): 500

• Outlet Size (in): 1/4-18 NPTF
• Outlet Thread Gender: Male

GG 557735

ROD, TIE, MSP, 7 SECTION

Graco 557735 Trabon MSP Divider Valve - 7 Section Tie Rod (3 Required)

• 7-Section Tie Rods
• Three tie rods and tie rod nuts required for assembly
• Lubriquip part number 527-001-860

• Model: Trabon
• Series: MSP

• Application: On-Road Vehicles, Off-Road Equipment, Compressor Equipment

GG 557734

ROD, TIE, MSP, 6 SECTION

Graco 557734 Trabon MSP Divider Valve - 6 Section Tie Rod (3 Required)

• 6-Section Tie Rods
• Three tie rods and tie rod nuts required for assembly
• Lubriquip part number 527-001-850

• Model: Trabon
• Series: MSP

• Application: On-Road Vehicles, Off-Road Equipment, Compressor Equipment

GG 557427

DISK, .375 2650/6400 PSI PNK

Graco 557427 Replacement Rupture Disk, 3/8 in, 6400 psi, Pink

• Used in conjunction with system pressure switch - can warn of a fault while allowing lube system to continue to deliver to critical bearings.
• Requires replacement of the rupture disc to restart the lube system.
• Easy information on blocked lines, high system pressure or blocked bearings.
• Lubriquip part number 509-282-000
• Trabon part number 9282

• Color: Pink

• Maximum Working Pressure (bar): 441
• Maximum Working Pressure (kPa): 44096
• Maximum Working Pressure (MPa): 44.1
• Maximum Working Pressure (psi): 6400

• Number of Pieces: 1

• Overall Diameter (cm): 1
• Overall Diameter (in): 0.375

• Overall Diameter (mm): 10

GG 557425

DISK, .375 2050/5500 PSI OR

Graco 557425 Replacement Rupture Disk, 3/8 in, 5500 psi, Orange

• Used in conjunction with system pressure switch - can warn of a fault while allowing lube system to continue to deliver to critical bearings.
• Requires replacement of the rupture disc to restart the lube system.
• Easy information on blocked lines, high system pressure or blocked bearings.
• Lubriquip part number 509-280-000
• Trabon part number 9280

• Color: Orange

• Maximum Working Pressure (bar): 379
• Maximum Working Pressure (kPa): 37895
• Maximum Working Pressure (MPa): 37.9
• Maximum Working Pressure (psi): 5500

• Number of Pieces: 1

• Overall Diameter (cm): 1
• Overall Diameter (in): 0.375

• Overall Diameter (mm): 10

GG 557736

ROD, TIE, MSP, 8 SECTION

Graco 557736 Trabon MSP Divider Valve - 8 Section Tie Rod (3 Required)

• 8-Section Tie Rods
• Three tie rods and tie rod nuts required for assembly
• Lubriquip part number 527-001-870

• Model: Trabon
• Series: MSP

• Application: On-Road Vehicles, Off-Road Equipment, Compressor Equipment

GG 557490

ROD, TIE, MX 5

Graco 557490 Trabon MX Divider Valve - 5 Section Tie Rod

• 5-Section Tie Rods
• Lubriquip part number 510-505-050
• Trabon part number 10505-5

• Model: Trabon
• Series: MX

• Application: In-Plant Machinery

GG 557700

STRAINER, 138 MICRON

Graco 557700 Replacement Filter Element, 149 micron/100 mesh, Lubriquip part number 525-766-010

• Replacement element for filter assemblies 563507, 557517, 564406

• For Use With: In-Line Oil & Grease Strainers

GG 557488

ROD, TIE, MX 3

Graco 557488 Trabon MX Divider Valve - 3 Section Tie Rod

• 3-Section Tie Rods
• Lubriquip part number 510-505-030
• Trabon part number 10505-3

• Model: Trabon
• Series: MX

• Application: In-Plant Machinery

GG 557515

ROD, TIE, FEEDER, MJ-3

Graco 557515 Trabon MJ Divider Valve - 3 Section Tie Rod (2 Required)

• 3-Section Tie Rods
• Two tie rods and tie rod nuts required for assembly.
• NPSF
• Trabon part number 10999-3

• Model: Trabon
• Series: MJ

• Application: On-Road Vehicles, Off-Road Equipment

GG 557434

DISK, .688 1750 PSI RED

Graco 557434 Replacement Rupture Disk, 11/16 in, 1750 psi, Red

• Used in conjunction with system pressure switch - can warn of a fault while allowing lube system to continue to deliver to critical bearings.
• Requires replacement of the rupture disc to restart the lube system.
• Easy information on blocked lines, high system pressure or blocked bearings.
• Lubriquip part number 509-293-000
• Trabon part number 9293

• Color: Red

• Maximum Working Pressure (bar): 121
• Maximum Working Pressure (kPa): 12058
• Maximum Working Pressure (MPa): 12.1
• Maximum Working Pressure (psi): 1750

• Number of Pieces: 6

• Overall Diameter (cm): 1.7
• Overall Diameter (in): 0.688

• Overall Diameter (mm): 17

GG 557546

BRACKET, SWITCH, T-CYCLE

Graco 557546 Replacement Bracket for Cycle Switch

• Replacement bracket for 563272, 563273, 564357
• Lubriquip part number 511-968-002

GG 557436

DISK, .688 2350 PSI ALUM

Graco 557436 Replacement Rupture Disk, 11/16 in, 2350 psi, Aluminum

• Used in conjunction with system pressure switch - can warn of a fault while allowing lube system to continue to deliver to critical bearings.
• Requires replacement of the rupture disc to restart the lube system.
• Easy information on blocked lines, high system pressure or blocked bearings.
• Lubriquip part number 509-295-000
• Trabon part number 9295

• Color: Aluminum

• Maximum Working Pressure (bar): 162
• Maximum Working Pressure (kPa): 16192
• Maximum Working Pressure (MPa): 16.2
• Maximum Working Pressure (psi): 2350

• Number of Pieces: 6

• Overall Diameter (cm): 1.7
• Overall Diameter (in): 0.688

• Overall Diameter (mm): 17

GG 557731

ROD, TIE, MSP, 3 SECTION

Graco 557731 Trabon MSP Divider Valve - 3 Section Tie Rod (3 Required)

• 3-Section Tie Rods
• Three tie rods and tie rod nuts required for assembly
• Lubriquip part number 527-001-820

• Model: Trabon
• Series: MSP

• Application: On-Road Vehicles, Off-Road Equipment, Compressor Equipment

GG 557733

ROD, TIE, MSP, 5 SECTION

Graco 557733 Trabon MSP Divider Valve - 5 Section Tie Rod (3 Required)

• 5-Section Tie Rods
• Three tie rods and tie rod nuts required for assembly
• Lubriquip part number 527-001-840

• Model: Trabon
• Series: MSP

• Application: On-Road Vehicles, Off-Road Equipment, Compressor Equipment

GG 557797

CAP, FILL, RESERVOIR

Graco 557797 Reservoir Fill Cap

• Fill Cup
• Lubriquip part number 534-147-000
• Trabon part number 34147

• For Use With: LubeMaster Pumps

GG 557766

ROD, TIE, MXP, 3 SECTION

Graco 557766 Trabon MXP Divider Valve - 3 Section Tie Rod (3 Required)

• 3-Section Tie Rod
• Three required per assembly
• Lubriquip part number 527-300-270

• Model: Trabon
• Series: MXP

• Application: In-Plant Machinery

GG 557813

METER-FLO PUMP, 18/30 CU IN/MIN CCW NPT

Graco 557813 Meter-Flo Electric Pump, 30 cu in/min (492 cc/min) @ 1,725 rpm, NPT Ports, CCW

With its solid pump housing, these rugged gear pumps are designed for dependable operation in high demand applications. The gear pump is available with a direct-coupled 1/2 horsepower motor capable of 1,725 rpm's with output volumes of 245 cubic inches per minute (4015 cc/min).

• Ideal for applications requiring continuous oil delivery up to 1,000 lubrication points
• Positive displacement helps assure constant delivery of proper volume.
• Match-ground heat-treated steel gears are enclosed in a rigid, cast-iron housing to assure dependability and long life.
• Adjustable pressure relief valve protects pump against overload conditions.
• Meter-flo pumps are available with a special coupling that allows easy replacement of older Meter-Flo pumps.
• Lubriquip part number 540-800-001

• Model: Meter-Flo

• Application: In-Plant Machinery

• Compatible Material: Oil
• Compatible Metering Device: Series Progressive

• Fluid Outlet Size (in): 0.5
• Fluid Outlet Size (mm): 12.7000
• Fluid Outlet Thread Type: NPT

• Maximum Flow Rate (ci/min): 30

• Maximum Fluid Output Pressure (bar): 103
• Maximum Fluid Output Pressure (psi): 1500

• Maximum Fluid Output Pressure (bar): 103
• Maximum Fluid Output Pressure (psi): 1500

• Maximum Operating Temperature ( degree C): 66
• Maximum Operating Temperature ( degree F): 150

• Maximum SUS Grade (SUS): 3000

• Maximum Working Pressure (bar): 103
• Maximum Working Pressure (kPa): 10300
• Maximum Working Pressure (MPa): 10.3
• Maximum Working Pressure (psi): 1500

• Minimum Operating Temperature ( degree C): 10
• Minimum Operating Temperature ( degree F): 50

• Minimum SUS Grade (SUS): 300

• Power Type: Electric

GG 557815

METER-FLO PUMP, 55/83 CU IN/MIN CCW NPT

Graco 557815 Meter-Flo Electric Pump, 84 cu in/min (1377 cc/min) @ 1,725 rpm, NPT Ports, CCW

With its solid pump housing, these rugged gear pumps are designed for dependable operation in high demand applications. The gear pump is available with a direct-coupled 1/2 horsepower motor capable of 1,725 rpm's with output volumes of 245 cubic inches per minute (4015 cc/min).

• Ideal for applications requiring continuous oil delivery up to 1,000 lubrication points
• Positive displacement helps assure constant delivery of proper volume.
• Match-ground heat-treated steel gears are enclosed in a rigid, cast-iron housing to assure dependability and long life.
• Adjustable pressure relief valve protects pump against overload conditions.
• Meter-flo pumps are available with a special coupling that allows easy replacement of older Meter-Flo pumps.
• Lubriquip part number 540-800-021

• Model: Meter-Flo

• Application: In-Plant Machinery

• Compatible Material: Oil
• Compatible Metering Device: Series Progressive

• Fluid Outlet Size (in): 0.5
• Fluid Outlet Size (mm): 12.7000
• Fluid Outlet Thread Type: NPT

• Maximum Flow Rate (ci/min): 84

• Maximum Fluid Output Pressure (bar): 103
• Maximum Fluid Output Pressure (psi): 1500

• Maximum Fluid Output Pressure (bar): 103
• Maximum Fluid Output Pressure (psi): 1500

• Maximum Operating Temperature ( degree C): 66
• Maximum Operating Temperature ( degree F): 150

• Maximum SUS Grade (SUS): 3000

• Maximum Working Pressure (bar): 103
• Maximum Working Pressure (kPa): 10300
• Maximum Working Pressure (MPa): 10.3
• Maximum Working Pressure (psi): 1500

• Minimum Operating Temperature ( degree C): 10
• Minimum Operating Temperature ( degree F): 50

• Minimum SUS Grade (SUS): 300

• Power Type: Electric

GG 557816

METER-FLO PUMP, 76/116 CU IN/MIN CCW NPT

Graco 557816 Meter-Flo Electric Pump, 117 cu in/min (1917 cc/min) @ 1,725 rpm, NPT Ports, CCW

With its solid pump housing, these rugged gear pumps are designed for dependable operation in high demand applications. The gear pump is available with a direct-coupled 1/2 horsepower motor capable of 1,725 rpm's with output volumes of 245 cubic inches per minute (4015 cc/min).

• Ideal for applications requiring continuous oil delivery up to 1,000 lubrication points
• Positive displacement helps assure constant delivery of proper volume.
• Match-ground heat-treated steel gears are enclosed in a rigid, cast-iron housing to assure dependability and long life.
• Adjustable pressure relief valve protects pump against overload conditions.
• Meter-flo pumps are available with a special coupling that allows easy replacement of older Meter-Flo pumps.
• Lubriquip part number 540-800-041

• Model: Meter-Flo

• Application: In-Plant Machinery

• Compatible Material: Oil
• Compatible Metering Device: Series Progressive

• Fluid Outlet Size (in): 0.5
• Fluid Outlet Size (mm): 12.7000
• Fluid Outlet Thread Type: NPT

• Maximum Flow Rate (ci/min): 117

• Maximum Fluid Output Pressure (bar): 103
• Maximum Fluid Output Pressure (psi): 1500

• Maximum Fluid Output Pressure (bar): 103
• Maximum Fluid Output Pressure (psi): 1500

• Maximum Operating Temperature ( degree C): 66
• Maximum Operating Temperature ( degree F): 150

• Maximum SUS Grade (SUS): 3000

• Maximum Working Pressure (bar): 103
• Maximum Working Pressure (kPa): 10300
• Maximum Working Pressure (MPa): 10.3
• Maximum Working Pressure (psi): 1500

• Minimum Operating Temperature ( degree C): 10
• Minimum Operating Temperature ( degree F): 50

• Minimum SUS Grade (SUS): 300

• Power Type: Electric

GG 557866

GAUGE, 3000 PSI 1/4NPT C/B LIQ

Graco 557866 Pressure Gauge, Back-Mounted, 0-3000 psi, 2 1/2 in. Dial Diameter

• Dial Diameter (cm): 6
• Dial Diameter (in): 2.5
• Dial Diameter (mm): 64

• Inlet Size (cm): 0.635
• Inlet Size (in): 1/4
• Inlet Size (mm): 6.35

• Inlet Thread Type: NPT

• Maximum Working Pressure (bar): 207
• Maximum Working Pressure (kPa): 20700
• Maximum Working Pressure (MPa): 20.7
• Maximum Working Pressure (psi): 3000

GG 557941

GG 557998

KIT, RELIEF VLV VIKING PUMP

Graco 557998 Meter-Flo Relief Valve Repair Kit

• Meter-Flo Relief Valve Repair Kit - 540-800-XX1 Models
• Lubriquip part number 560-001-920

• For Use With: Viking Pumps

• Includes: Poppet, Cap, Spring, Hardware

• Kit Type: Repair Kit

GG 558015

GG 558022

CABLE, CONN 12'

Graco 558022 Mini-Straight Connection Cable - 12 ft, 3-Pin

• 3-pin cable, straight connector, 12 feet (3.66 m)
• Lubriquip part number 570-999-090

• For Use With: MSP Divider Valves, Proximity Switches, Air Oil Lubrication System

GG 558025

CABLE, CONN CABLE 4PN 24V

Graco 558025 Proximity Switch Connector Cable - 24 V, 12 ft, 4-Pin, Straight Connector, Polarity, PNP

• 4-pin cable, straight connector, polarity, PNP, 12 feet (3.66 m)
• Lubriquip part number 570-999-953

• For Use With: Proximity Switches

GG 558024

CABLE, 5 PIN W/ CONN

Graco 558024 Proximity Switch Connector Cable - 12 ft, 5-Pin

• 5-pin cable, straight connector, 12 feet (3.66 m)
• Lubriquip part number 570-999-170

• For Use With: Proximity Switches

GG 558188

GG 558190

GG 558189

NUT, BRASS 5/32 TUBE COMPR

Graco 558189 Thrif-T Luber Hardware - TLCN-00 - Compression Nut

• Thrif-T Luber Hardware - TLCN-00 - Compression Nut
• Lubriquip part number 435-390-070

• Inside Diameter (in): 0.3125
• Inside Diameter (mm): 7.9375

• Material: Brass

• Nut Type: Hex Nut

GG 558730

O-RING, -908 VITON

Graco 558730 O-Ring, Viton

• Lubriquip part number GOV-060-020

• For Use With: Husky 1050e Pump, SaniForce 1040e Pump

• Inside Diameter (cm): 1.6
• Inside Diameter (in): 0.644
• Inside Diameter (mm): 16.4

• Material: Viton

• Number of Pieces: 1

• Outside Diameter (cm): 2.1
• Outside Diameter (in): 0.818
• Outside Diameter (mm): 20.8

GG 558692

O-RING, -113 VITON-A 75 DURO

• Lubriquip part number 422-041-130
• Trabon part number 25613-V
• Manzel part number 22X4-113

• Inside Diameter (cm): 1.4
• Inside Diameter (in): 0.549
• Inside Diameter (mm): 13.9

• Material: Viton

• Number of Pieces: 1

• Outside Diameter (cm): 1.9
• Outside Diameter (in): 0.755
• Outside Diameter (mm): 19.2

GG 558906

COUPLER, 1/4, W/CHECK

Graco 558906 Mating Coupler/Coupling for grease fill stud on Trabon Reservoirs, 1/4 in. NPT female, with Check

• Mating Coupler for Trabon Grease Fill Stud
• Former part numbers: Lubriquip 506-322-000, Trabon 6322
• Mates to fill stud 557374
• Trabon part number 6322

• Series: Trabon

• Connection Type: Threaded

• End A Inlet Thread Gender: Female
• End A Inlet Thread Type: NPTF

• Finish/Coating: Cadium

• Inlet Size (in): 1/4-18

• Inlet Thread Gender: Female

• Material: Brass

• Maximum Working Pressure (bar): 21
• Maximum Working Pressure (kPa): 2100
• Maximum Working Pressure (MPa): 2.1
• Maximum Working Pressure (psi): 300

• Outlet Size (in): 1/4 inch diameter Quick Disconnect, mates to air chuck style grease fill stud used on Trabon grease reservoirs
• Outlet Thread Gender: None

GG 558927

BRACKET, MTG RTN FILTER

Graco 558927 Filter Mounting Bracket

• Filter Mounting Bracket
• Lubriquip part number 521-010-440

• Color: Gray

• Finish/Coating: Paint

• For Use With: Spin-On Filter

• Material: Steel

• Overall Height (cm): 12.5425
• Overall Height (in): 4.938
• Overall Height (mm): 125.4252
• Overall Length (cm): 6
• Overall Length (in): 2.5
• Overall Length (mm): 64
• Overall Width (cm): 6.985
• Overall Width (in): 2.75
• Overall Width (mm): 69.85

GG 558949

METER-FLO PUMP, 55/83 CU IN/MIN CW NPT

Graco 558949 Meter-Flo Electric Pump, 84 cu in/min (1377 cc/min) @ 1,725 rpm, NPT Ports, CW

With its solid pump housing, these rugged gear pumps are designed for dependable operation in high demand applications. The gear pump is available with a direct-coupled 1/2 horsepower motor capable of 1,725 rpm's with output volumes of 245 cubic inches per minute (4015 cc/min).

• Ideal for applications requiring continuous oil delivery up to 1,000 lubrication points
• Positive displacement helps assure constant delivery of proper volume.
• Match-ground heat-treated steel gears are enclosed in a rigid, cast-iron housing to assure dependability and long life.
• Adjustable pressure relief valve protects pump against overload conditions.
• Meter-flo pumps are available with a special coupling that allows easy replacement of older Meter-Flo pumps.
• Lubriquip part number 540-800-031

• Model: Meter-Flo

• Application: In-Plant Machinery

• Compatible Material: Oil
• Compatible Metering Device: Series Progressive

• Fluid Outlet Size (in): 0.5
• Fluid Outlet Size (mm): 12.7000
• Fluid Outlet Thread Type: NPT

• Maximum Flow Rate (ci/min): 84

• Maximum Fluid Output Pressure (bar): 103
• Maximum Fluid Output Pressure (psi): 1500

• Maximum Fluid Output Pressure (bar): 103
• Maximum Fluid Output Pressure (psi): 1500

• Maximum Operating Temperature ( degree C): 66
• Maximum Operating Temperature ( degree F): 150

• Maximum SUS Grade (SUS): 3000

• Maximum Working Pressure (bar): 207
• Maximum Working Pressure (kPa): 20700
• Maximum Working Pressure (MPa): 20.7
• Maximum Working Pressure (psi): 3000

• Minimum Operating Temperature ( degree C): 10
• Minimum Operating Temperature ( degree F): 50

• Minimum SUS Grade (SUS): 300

• Power Type: Electric

GG 560543

COUPLING, ANCHOR CROSS 1/8

Graco 560543 Cross Anchor Fitting, 1/8 in. NPSF

• Cross Anchor Fitting, 1/8 in. NPSF
• Lubriquip part number 509-189-000
• Trabon part number 9189

• Connection Type: Threaded

• Finish/Coating: Zinc

• For Use With: Hose

• Material: Steel

GG 560643

BLOCK, INLET SECTION, MJ

Graco 560643 Trabon MJ Divider Valve - Standard Inlet

• Standard Inlet (Must be ordered in multiples of five)
• NPSF
• Lubriquip part number 510-992-002

• Model: Trabon
• Series: MJ

• Application: On-Road Vehicles, Off-Road Equipment

• Inlet Size (cm): 0.3175
• Inlet Size (in): 1/8
• Inlet Size (mm): 3.175

• Inlet Thread Type: NPSF

GG 560620

BLOCK, INLET MACH MX

Graco 560620 Trabon MX Divider Valve - MX Inlet

• MX inlet
• Lubriquip part number 510-914-003

• Model: Trabon
• Series: MX

• Application: In-Plant Machinery

• Inlet Size (cm): 0.9525
• Inlet Size (in): 3/8
• Inlet Size (mm): 9.525

• Inlet Thread Type: NPT

GG 560645

BLOCK, END SECTION MJ

Graco 560645 Trabon MJ Divider Valve - Standard End Section

• Standard end section (Must be ordered in multiples of five)
• NPSF
• Lubriquip part number 510-994-002

• Model: Trabon
• Series: MJ

• Application: On-Road Vehicles, Off-Road Equipment

• Outlet Thread Type: NPSF

GG 560919

BLOCK, INLET, MSP/MHH NPSF

Graco 560919 Manzel MHH Divider Valve - Inlet - 1/4-18 NPSF

• Standard Inlet
• 1/4-18 NPSF (NPT)
• Lubriquip part number 527-001-800

• Model: Manzel
• Series: MHH

• Application: On-Road Vehicles, Off-Road Equipment, Compressor Equipment

• Inlet Size (cm): 0.635
• Inlet Size (in): 1/4
• Inlet Size (mm): 6.35

• Inlet Thread Type: NPSF

GG 562502

MJ VALVE, BLOCK, STD SECTION, MJ-15S

Graco 562502 Trabon MJ Series-Flo Divider Valve - MJ-15S - 0.030 in cu (0.49 cm cu )

The Trabon MJ series features a compact and easily customizable design that can be tailor fit to meet a variety of specific lube requirements. Capable of handling grease grades up to NLGI #1.

• Space efficient - from 6 to 16 points from one block assembly
• Built-in outlet check valves ensure accurate lube delivery, every time
• Alternate outlet on face of valves can be fitted with optional performance indicators, taking the guesswork out of troubleshooting
• Lubriquip part number 001-015-001

• Model: Trabon
• Series: MJ

• Application: On-Road Vehicles, Off-Road Equipment, In-Plant Machinery

• Compatible Material: Oil, Grease

• Cycle Indicator: None

• Discharge Per Piston Stroke (in cu ): 0.030

• Divider Valve Series: MJ

• Material: Carbon Steel

• Maximum Cycle Rate (cycles/min): 200

• Maximum NLGI Grade: #1

• Maximum Operating Temperature ( degree C): 93
• Maximum Operating Temperature ( degree F): 200

• Maximum Working Pressure (bar): 138
• Maximum Working Pressure (kPa): 13800
• Maximum Working Pressure (psi): 2000

• Minimum Working Pressure (psi): 200

• Number of Outlets: 1

• Outlet Size (cm): 0.3175
• Outlet Size (in): 1/8
• Outlet Size (mm): 3.175
• Outlet Thread Gender: Female
• Outlet Thread Type: NPSF

GG 561471

GG 562503

MJ VALVE, ASSY MJ 5T

Graco 562503 Trabon MJ Series-Flo Divider Valve - MJ-5T - 0.005 in cu (0.082 cm cu )

The Trabon MJ series features a compact and easily customizable design that can be tailor fit to meet a variety of specific lube requirements. Capable of handling grease grades up to NLGI #1.

• Space efficient - from 6 to 16 points from one block assembly
• Built-in outlet check valves ensure accurate lube delivery, every time
• Alternate outlet on face of valves can be fitted with optional performance indicators, taking the guesswork out of troubleshooting
• Lubriquip part number 001-005-002

• Model: Trabon
• Series: MJ

• Application: On-Road Vehicles, Off-Road Equipment, In-Plant Machinery

• Compatible Material: Oil, Grease

• Cycle Indicator: None

• Discharge Per Piston Stroke (in cu ): 0.005

• Divider Valve Series: MJ

• Material: Carbon Steel

• Maximum Cycle Rate (cycles/min): 200

• Maximum NLGI Grade: #1

• Maximum Operating Temperature ( degree C): 93
• Maximum Operating Temperature ( degree F): 200

• Maximum Working Pressure (bar): 138
• Maximum Working Pressure (kPa): 13800
• Maximum Working Pressure (psi): 2000

• Minimum Working Pressure (psi): 200

• Number of Outlets: 2

• Outlet Size (cm): 0.3175
• Outlet Size (in): 1/8
• Outlet Size (mm): 3.175
• Outlet Thread Gender: Female
• Outlet Thread Type: NPSF

GG 562504

MJ VALVE, ASSY MJ 10T

Graco 562504 Trabon MJ Series-Flo Divider Valve - MJ-10T - 0.010 in cu (0.16 cm cu )

The Trabon MJ series features a compact and easily customizable design that can be tailor fit to meet a variety of specific lube requirements. Capable of handling grease grades up to NLGI #1.

• Space efficient - from 6 to 16 points from one block assembly
• Built-in outlet check valves ensure accurate lube delivery, every time
• Alternate outlet on face of valves can be fitted with optional performance indicators, taking the guesswork out of troubleshooting
• Lubriquip part number 001-010-002

• Model: Trabon
• Series: MJ

• Application: On-Road Vehicles, Off-Road Equipment, In-Plant Machinery

• Compatible Material: Oil, Grease

• Cycle Indicator: None

• Discharge Per Piston Stroke (in cu ): 0.010

• Divider Valve Series: MJ

• Material: Carbon Steel

• Maximum Cycle Rate (cycles/min): 200

• Maximum NLGI Grade: #1

• Maximum Operating Temperature ( degree C): 93
• Maximum Operating Temperature ( degree F): 200

• Maximum Working Pressure (bar): 138
• Maximum Working Pressure (kPa): 13800
• Maximum Working Pressure (psi): 2000

• Minimum Working Pressure (psi): 200

• Number of Outlets: 2

• Outlet Size (cm): 0.3175
• Outlet Size (in): 1/8
• Outlet Size (mm): 3.175
• Outlet Thread Gender: Female
• Outlet Thread Type: NPSF

GG 562505

MJ VALVE, ASSY MJ 15T

Graco 562505 Trabon MJ Series-Flo Divider Valve - MJ-15T - 0.015 in cu (0.246 cm cu )

The Trabon MJ series features a compact and easily customizable design that can be tailor fit to meet a variety of specific lube requirements. Capable of handling grease grades up to NLGI #1.

• Space efficient - from 6 to 16 points from one block assembly
• Built-in outlet check valves ensure accurate lube delivery, every time
• Alternate outlet on face of valves can be fitted with optional performance indicators, taking the guesswork out of troubleshooting
• Lubriquip part number 001-015-002

• Model: Trabon
• Series: MJ

• Application: On-Road Vehicles, Off-Road Equipment, In-Plant Machinery

• Compatible Material: Oil, Grease

• Cycle Indicator: None

• Discharge Per Piston Stroke (in cu ): 0.015

• Divider Valve Series: MJ

• Material: Carbon Steel

• Maximum Cycle Rate (cycles/min): 200

• Maximum NLGI Grade: #1

• Maximum Operating Temperature ( degree C): 93
• Maximum Operating Temperature ( degree F): 200

• Maximum Working Pressure (bar): 138
• Maximum Working Pressure (kPa): 13800
• Maximum Working Pressure (psi): 2000

• Minimum Working Pressure (psi): 200

• Number of Outlets: 2

• Outlet Size (cm): 0.3175
• Outlet Size (in): 1/8
• Outlet Size (mm): 3.175
• Outlet Thread Gender: Female
• Outlet Thread Type: NPSF

GG 562510

MJ VALVE, ASSY IND MJ 10T

Graco 562510 Trabon MJ Series-Flo Divider Valve with Right Hand Cycle Pin - MJ-10T - 0.010 in cu (0.16 cm cu )

The Trabon MJ series features a compact and easily customizable design that can be tailor fit to meet a variety of specific lube requirements. Capable of handling grease grades up to NLGI #1.

• Space efficient - from 6 to 16 points from one block assembly
• Built-in outlet check valves ensure accurate lube delivery, every time
• Alternate outlet on face of valves can be fitted with optional performance indicators, taking the guesswork out of troubleshooting
• Lubriquip part number 001-010-602

• Model: Trabon
• Series: MJ

• Application: On-Road Vehicles, Off-Road Equipment, In-Plant Machinery

• Compatible Material: Oil, Grease

• Cycle Indicator: Cycle Indicator

• Discharge Per Piston Stroke (in cu ): 0.010
