GRACO INC. S10595

GG 222082

DISPENCER KIT

Graco 222082 Dispense Kit for Undercoating and Rustproofing Pump Packages - 25 ft (7.6 m) Hose

Utilizing the durable Fire-Ball 300 pump, these kits are designed for use in medium-volume undercoating and rustproofing dispense applications. The 3 inch (7.62 cm) differential air motor ensures smooth pumping, and the double acting pump design provides reliable material flow and accurate dispense.

• Durable -Thick cast aluminum air motor housing offers unmatched durability.
• Superior Material Handling - Double-acting pump ensures smooth fluid flow.
• Extended Seal Life -In-line pump design aligns the air motor piston and fluid piston rods to maximize seal life.
• Corrosion-Resistant - Corrosion-resistant design utilizes liquid nitrating, nickel plating, stainless steel, aluminum and chrome on key components for longer life.

• Compatible Material: Undercoating

• For Use With: 15:1 Ratio Fire-Ball Undercoater Pumps

• Kit Type: Dispense Kit

• Number of Pieces: 12

GG 222085

FIREBALL 300 PUMP, LUBT, HP

Graco 222085 Fire-Ball 300 Series 50:1 120 lb. (54 kg) Grease Pump - Lube Truck Package

As the mainstay pump in the industry for decades, the reputation of Fire-Ball is unrivaled. Built to withstand the test of time with fewer moving parts, our flagship pump is built to extend uptime so customers can be more productive. The durable pumps are renowned for their durability, with pumps built decades ago still operating efficiently.

• Reliable Flow - A 3 inch (76.2 mm) differential air motor and the double-acting pump design provides reliable fluid flow and accurate dispense.
• Durable - Thick cast aluminum air motor housing offers unmatched durability.
• Fewer Repairs - Fewer moving parts in the air motor assembly means less downtime and low repair cost.
• Reduce Downtime - Displacement rods have minimal wear due to a proprietary Graco manufacturing process.
• Superior Sealing - Non-metallic poppet valves offer positive sealing performance, even with contaminated " dirty" air environments for long life without repair.
• Reduced Icing - Large air porting design provides efficient use of compressed air supply for continuous pump operation and reduced icing.
• Corrosion-Resistant - Corrosion-resistant design utilizes liquid salt nitriding, nickel plating, stainless steel, aluminum and chrome on key components for longer life.

• Model: Fire-Ball
• Series: 300

• Air Inlet Size (in): 0.375
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Industrial

• Compatible Drum Size (gal): N/A

• Compatible Material: Grease

• Container Size (lb): 120

• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT
• Fluid Inlet Type: Slotted

• Fluid Outlet Size (cm): 0.635
• Fluid Outlet Size (in): 1/4
• Fluid Outlet Size (mm): 6.35
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT

• Includes: Fireball 50:1 300 Pump, Hose and Fitting Kit, Cover, Follow Plate, Hold-Down Kit

• Maximum Air Working Pressure: 140

• Maximum Working Pressure (bar): 350
• Maximum Working Pressure (kPa): 35000
• Maximum Working Pressure (MPa): 35
• Maximum Working Pressure (psi): 5000

• Motor Type: Pneumatic

• Mount Location: Drum Mount

• Power Type: Pneumatic

• Pump Ratio: 50:1
• Pump Weight (lb): 22

GG 222095

FIREBALL 425 PUMP, 10:1, 55 GL

Graco 222095 Fire-Ball 425 Series 10:1 55 Gallon (200 Liter) Drum Size Oil Pump - Bung Mount

With a large 4.25 inch (107.9 mm) air motor to supply the power you need for long pipe runs and higher volume dispensing, the Fire-Ball 425 delivers field-proven durability for multiple fluid types and exceptional cost savings that are hard to beat!

• Durable Casting - Thick cast aluminum air motor housing offers unmatched durability.
• Fewer Repairs - Fewer moving parts in the air motor assembly means less downtime and low repair cost.
• Extended Seal Life - In-line pump design aligns the air motor piston and fluid piston rods to maximize seal life.
• Superior Sealing - Non-metallic poppet valves offer positive sealing performance, even with contaminated dirtyair environments for long life without repair.
• Reduced Icing - Large air porting design provides efficient use of compressed air supply for continuous pump operation and reduced icing.
• Corrosion-Resistant - Corrosion-resistant design utilizes liquid salt nitriding, nickel plating, stainless steel, aluminum and chrome on key components for longer life.

• Model: Fire-Ball
• Series: 425

• Air Inlet Size (in): 0.5
• Air Inlet Size (mm): 12.7
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT
• Air Motor Effective Diameter (in): 4.25

• Application: Industrial

• Compatible Material: Oil

• Cycles Per Gallon: 19.6

• Fluid Inlet Size (in): 1-1/2
• Fluid Inlet Size (mm): 38.1
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (in): 3/4
• Fluid Outlet Size (mm): 19.05
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT

• For Use With: Petroleum- and synthetic-based oils (motor, gear and ATF)

• Maximum Air Inlet Pressure (bar): 12.41
• Maximum Air Inlet Pressure (kPa): 1241
• Maximum Air Inlet Pressure (psi): 180

• Maximum Continuous Cycle Rate (CPM): 66

• Maximum Intermittent Cycle Rate (CPM): 66

• Maximum Working Pressure (bar): 124
• Maximum Working Pressure (kPa): 12400
• Maximum Working Pressure (MPa): 12.4
• Maximum Working Pressure (psi): 1800

• Power Type: Pneumatic

• Pump Ratio: 10:1

GG 222087

FIREBALL 300 PUMP, 5:1, 275 GL, BUNG MT

Graco 222087 Fire-Ball 300 Series 5:1 275 Gallon (1040 Liter) Drum Size Oil Pump - Bung Mount

As the mainstay pump in the industry for decades, the reputation of Fire-Ball is unrivaled. Built to withstand the test of time with fewer moving parts, our flagship pump is built to extend uptime so customers can be more productive. The durable pumps are renowned for their durability, with pumps built decades ago still operating efficiently.

• Reliable Flow - A 3 inch (76.2 mm) differential air motor and the double-acting pump design provides reliable fluid flow and accurate dispense.
• Durable - Thick cast aluminum air motor housing offers unmatched durability.
• Fewer Repairs - Fewer moving parts in the air motor assembly means less downtime and low repair cost.
• Reduce Downtime - Displacement rods have minimal wear due to a proprietary Graco manufacturing process.
• Superior Sealing - Non-metallic poppet valves offer positive sealing performance, even with contaminated dirtyair environments for long life without repair.
• Reduced Icing - Large air porting design provides efficient use of compressed air supply for continuous pump operation and reduced icing.
• Corrosion-Resistant - Corrosion-resistant design utilizes liquid salt nitriding, nickel plating, stainless steel, aluminum and chrome on key components for longer life.

• Model: Fire-Ball
• Series: 300

• Air Inlet Size (in): 3/8
• Air Inlet Size (mm): 9.525
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT
• Air Motor Effective Diameter (in): 3

• Application: Industrial

• Compatible Material: Oil

• Cycles Per Gallon: 30

• Fluid Inlet Size (in): 1-1/2
• Fluid Inlet Size (mm): 38.1
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (in): 1/2
• Fluid Outlet Size (mm): 12.7
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT

• For Use With: Petroleum- and synthetic-based oils (motor, gear and ATF)

• Maximum Air Consumption (SCFM): 25
• Maximum Air Inlet Pressure (bar): 12.41
• Maximum Air Inlet Pressure (kPa): 1241
• Maximum Air Inlet Pressure (psi): 180

• Maximum Continuous Cycle Rate (CPM): 70

• Maximum Intermittent Cycle Rate (CPM): 70

• Maximum Working Pressure (bar): 62
• Maximum Working Pressure (kPa): 6200
• Maximum Working Pressure (MPa): 6.2
• Maximum Working Pressure (psi): 900

• Power Type: Pneumatic

• Pump Ratio: 5:1

GG 222100

GG 222121

REGULATOR, PRESSURE, FLUID

Graco 222121 Mini High Pressure Corrosion Resistant Fluid Regulator, 1500 Max psi, 150-1200 psi Range, 1.0 GPM, SST, Spring Type, 1/4(f) x 1/4(m)

• Stainless steel wetted materials are compatible with catalyst and waterborne materials
• Tungsten and carbide materials ensure low wear and long life
• Valve cartridge for quick cleaning and replacement - reduce downtime
• Pressure adjustment key with locking mechanism protects production settings

• Actuation Type: Spring

• Includes: Regulator Only
• Inlet Size (cm): 0.635
• Inlet Size (in): 1/4
• Inlet Size (mm): 6.35

• Inlet Thread Type: NPT

• Maximum Flow Rate (GPM): 1
• Maximum Flow Rate (L/min): 3.8

• Maximum Regulated Pressure (bar): 83
• Maximum Regulated Pressure (kPa): 8300
• Maximum Regulated Pressure (MPa): 8.3
• Maximum Regulated Pressure (psi): 1200

• Maximum Viscosity (cP): 500

• Maximum Working Pressure (bar): 103
• Maximum Working Pressure (kPa): 10300
• Maximum Working Pressure (MPa): 10.3
• Maximum Working Pressure (psi): 1500

• Minimum Regulated Pressure (bar): 10.4
• Minimum Regulated Pressure (kPa): 1040
• Minimum Regulated Pressure (MPa): 1.0
• Minimum Regulated Pressure (psi): 150

• Outlet Size (cm): 0.635
• Outlet Size (in): 1/4
• Outlet Size (mm): 6.35

GG 22213-01

GG 22218-00

GG 22213-02

GG 220589

KIT, REPAIR, PUMP SEAL

Graco 220589 High Flo Pump UHMWPE Seal Kit

GG 22213-03

GG 222139

GG 222140

KIT, REPAIR

Graco 222140 Repair Kit for Fluid Pressure Regulator

GG 222200

VALVE, RESTRICTOR

Graco 222200 Back Pressure Valve with Carbide Needle and Seat

GG 22234-00

GG 22236-00

GG 222515

GG 222639

CHECK-MATE PUMP,SHOVEL,55:1 (SD)

Graco 222639 55:1 Ratio Severe Duty Pump Shovel

• Model: Check-Mate

• Application: Bonding, Sealing, Gasketing, Potting, Encapsulation, Molding, Spray, Fluid Transfer, Unloading, Underfill

GG 222657

GG 222101

KIT, REPAIR

KIT INCLUDES: PACKING, O-RING [QTY. 1], NUT, PACKING [QTY. 1], PACKING, O-RING [QTY. 3], PACKING, O-RING [QTY. 1], PIN, COTTER [QTY. 1], PACKING, O-RING [QTY. 1], STACK, GLAND/PACKING [QTY. 1], STACK, GLAND/PACKING [QTY. 1], STACK, GLAND/PACKING [QTY. 1]

GG 222695

AGITATOR

Graco 222695 Pail Cover Agitator for 5 gallon (18 L) pails, air driven, 1/4 HP, 13.25 inches (33.6 cm), stainless steel material, round prop

Waterborne compatible

• Lift handles for easy moving and color changes
• Locking bolts to secure cover and reduce spills
• Ideal for wall mount pumps or spray packages

• Air Inlet Size (cm): 0.3175
• Air Inlet Size (in): 1/8
• Air Inlet Size (mm): 3.175
• Air Inlet Thread Type: NPT

• For Use With: 5 Gallon Pail

• Maximum Speed (RPM): 800

• Maximum Working Pressure (bar): 7
• Maximum Working Pressure (kPa): 700
• Maximum Working Pressure (psi): 100

• Motor Type: Pneumatic - Rotary Vane

• Power Rating (HP): 0.25

GG 222698

AGITATOR, DIRECT DRIVE

Graco 222698 Drum agitator without mounting tube, air driven, 3/4 HP, 31.25 inches (79.3 cm) in length, stainless steel material

• Agitators mount directly to mix tank or drum covers
• Dual propeller ensures efficient and thorough mixing
• Easy adjustment knob for fine tuning agitator speed to ideal mixing parameters

• Air Inlet Size (cm): 0.635
• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35
• Air Inlet Thread Type: NPT

• For Use With: 55 Gallon Drums and 30 Gallon Mix Tanks

• Maximum Speed (RPM): 3000

• Maximum Working Pressure (bar): 7
• Maximum Working Pressure (kPa): 700
• Maximum Working Pressure (psi): 100

• Motor Type: Pneumatic - Rotary Vane

• Power Rating (HP): 0.75

GG 222308

GG 222805

PUMP,RECIP,DISPL

GG 222812

PLATE, WIPER, 5 GALLON

Graco 222812 5 gal (20 liter) Carbon Steel Wiper Plate

• Model: Check-Mate

GG 222792

KIT, SHIELD, 55 GALLON RAM

KIT INCLUDES: SHIELD, 55 GALLON RAM [QTY. 10 ], KIT INCLUDES: SEAT, INTAKE (6 CM) [QTY. 1], SEAL, [QTY. 1], VALVE, INTAKE (6CM) [QTY. 1], SEAL, VALVE (4.5 CM) [QTY. 1], SEAL, VALVE [QTY. 1]

GG 222801

PUMP, RECIP, DISPL

Graco 222801 Dura-Flo 2400 (580 cc) Lower, Carbon Steel, 3 PTFE/2 Leather Packings

GG 222793

GG 222764

GG 222795

HOUSING,VALVE SEAT ASSY

GG 222773

KIT, REPAIR (4.5 CM)

KIT INCLUDES: PACKING, O-RING, PTFE [QTY. 2], SEAL, [QTY. 1], SEAL, PISTON (4.5 CM) [QTY. 1], SEAL, VALVE (4.5 CM) [QTY. 1], PACKING, O-RING, PTFE [QTY. 1], SEAL, VALVE [QTY. 1]

GG 222803

PUMP,RECIP,DISPL

Graco 222803 Dura-Flo 2400 (580 cc) Lower, Stainless Steel, 3 UHMWPE/2 PTFE Packings

GG 222785

KIT,REPAIR,THROAT,POLY

KIT INCLUDES: GLAND, PACKING FEMALE [QTY. 1], GLAND, PACKINGMALE [QTY. 1], PACKING, VEE [QTY. 3], PACKING, VEE [QTY. 2]

GG 222810

CHECK-MATE 2100 PUMP,RECIP,DISPL

Graco 222810 21 cm Carbon Steel Pump Shovel

• Model: Check-Mate

• Application: Bonding, Sealing, Gasketing, Potting, Encapsulation, Molding, Spray, Fluid Transfer, Unloading, Underfill

GG 222796

PUMP,RECIP,DISPL(18CM-CSTL)

Graco 222796 Dura-Flo 1800 (430 cc) Carbon Steel Lower

GG 222794

HOUSING, VALVE

Graco 222794 Dura-FloLowers Seat, Carbide Steel

GG 222802

HOUSING, VALVE, SEAT

Graco 222802 Dura-Flo 2400 (580 cc) Lower Piston, Carbide Seat

GG 222834

VISCOUNT II PUMP,20:1

Graco 222834 Viscount Hydraulic Motor with Dura-Flo 2400 (580 cc) Lower, 3 PTFE/2 Leather Packings

The rugged pump lower construction with Severe Duty rods and cylinders reduces downtime and extends the interval between repairs. The simple construction makes service and repair fast and easy. The efficient hydraulic powered piston makes these pumps the ideal choice for factory and outdoor mobile use, even at below freezing temperatures.

• Clean, quiet operation with no airborne contamination
• Up to three times more energy efficient than comparable compressed air systems
• Positive displacement, 2-ball piston design provides uniform and easily controlled delivery
• Eliminate downtime without ice build-up

GG 222845

KIT, REPAIR

Graco 222845 Packing Conversion Kit for Dura-Flo 1000 and 1800- UHMWPE and PTFE Packings

Packing Conversion Kit

GG 222838

HOUSING, VALVE

Graco 222838 Dura-Flo 1800 & 2400 Lowers Seat, intake valve, carbide

• Compatible Material: Waterborne, Solventborne, High Solids, Xirallic, CARC, Metallics, Topcoats, Stains, Varnish

GG 222846

KIT, REPAIR

Graco 222846 PTFE Packings Repair Kit, Dura-Flo 1800 (standard for 222998)

GG 222848

KIT, REPAIR

Graco 222848 UHMWPE and Leather Packings Repair Kit, for Dura-Flo 1800 (standard for 246925, 24W644)

GG 222849

KIT, REPAIR

Graco 222849 PTFE and Leather Packing Repair Kit for Dura Flo 1000 and 1800

GG 222860

KIT, REPAIR

KIT INCLUDES: GLAND, PACKING, MALE [QTY. 1], GLAND, PACKING, FEMALE [QTY. 1], GLAND, PACKINGMALE [QTY. 1], GLAND, PACKING FEMALE [QTY. 1], PACKING, VEE [QTY. 3], PACKING, VEE [QTY. 2], PACKING, VEE, PTFE [QTY. 2], PACKING, VEE [QTY. 2], PACKING, O-RING [QTY. 1], SEAL, ACETAL [QTY. 3], SEAL, PISTON [QTY. 1], SEAL, VALVE [QTY. 1]

GG 222862

GG 222866

GG 222875

KIT, REPAIR PUMP 24CM PTFE

Graco 222875 UHMWPE and PTFE Packings Repair Kit, Dura-Flo 2400 (standard for 222803, 236226, L580CS, L580SS)

• Compatible Material: CARC, Enamel, Epoxies, High Solids, Latex, Lacquer, Metallics, Stains, Single Components, Solventborne Paints, Solventborne, Varnish Primers

GG 222877

GG 222876

KIT, REPAIR

Graco 222876 PTFE Packings Repair Kit, for Dura-Flo 2400 (standard for 222992, 222994)

• Compatible Material: CARC, Enamel, Epoxies, High Solids, Latex, Lacquer, Metallics, Stains, Single Components, Solventborne Paints, Solventborne, Varnish Primers, Waterborne

GG 222879

KIT, REPAIR

Graco 222879 Packing Repair Kit for Dura Flo 2400 Pumps

KIT INCLUDES: GLAND, PACKING, MALE [QTY. 1], GLAND, PACKING, FEMALE [QTY. 1], GLAND, PACKING, MALE [QTY. 1], GLAND, PACKING, FEMALE [QTY. 1], PACKING, VEE, PTFE [QTY. 3], PACKING, VEE, PTFE [QTY. 3], PACKING, VEE, LEATHER [QTY. 2], PACKING, VEE, LEATHER [QTY. 2], PACKING, O-RING [QTY. 1], PACKING, O-RING [QTY. 1], SEAL, ACETAL [QTY. 2]

GG 222880

KIT, REPAIR

Graco 222880 UHMWPE and PTFE Packings Repair Kit, for Dura-Flo 2400 (standard for 241648)

• Compatible Material: CARC, Enamel, Epoxies, High Solids, Latex, Lacquer, Metallics, Stains, Single Components, Solventborne Paints, Solventborne, Varnish Primers, Waterborne

GG 222881

KIT,REPAIR

Graco 222881 UHMWPE and Leather Packings Repair Kit, for Dura-Flo 2400 (standard for 15F298)

KIT INCLUDES: GLAND, PACKING, MALE [QTY. 1], GLAND, PACKING, FEMALE [QTY. 1], GLAND, PACKING, MALE [QTY. 1], GLAND, PACKING, FEMALE [QTY. 1], PACKING, VEE [QTY. 3], PACKING, VEE [QTY. 3], PACKING, VEE, LEATHER [QTY. 4 ], PACKING, VEE, LEATHER [QTY. 2], PACKING, O-RING [QTY. 1], PACKING, O-RING [QTY. 1], SEAL, ACETAL [QTY. 2]

• Compatible Material: CARC, Enamel, Epoxies, High Solids, Latex, Lacquer, Metallics, Stains, Single Components, Solventborne Paints, Solventborne, Varnish Primers

GG 222900

VISCOUNT II PUMP, 20:1

Graco 222900 Viscount Hydraulic Motor with Dura-Flo 2400 (580 cc) Lower, 3 UHMWPE/2 PTFE Packings

The rugged pump lower construction with Severe Duty rods and cylinders reduces downtime and extends the interval between repairs. The simple construction makes service and repair fast and easy. The efficient hydraulic powered piston makes these pumps the ideal choice for factory and outdoor mobile use, even at below freezing temperatures.

• Clean, quiet operation with no airborne contamination
• Up to three times more energy efficient than comparable compressed air systems
• Positive displacement, 2-ball piston design provides uniform and easily controlled delivery
• Eliminate downtime without ice build-up

• Model: Viscount
• Series: II

• Application: Supply

• Compatible Material: Waterborne, Solvent borne, High Solids, Xirallic, CARC, Metallics, Topcoats, Stains, Varnish

• Fluid Inlet Size (in): 2
• Fluid Inlet Size (mm): 50.8
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (in): 1-1/2
• Fluid Outlet Size (mm): 38.1
• Fluid Outlet Thread Gender: Male
• Fluid Outlet Thread Type: NPT
• Fluid Section Type: 2-Ball

• Material: Stainless Steel

• Maximum Flow Rate (GPM): 9.2
• Maximum Flow Rate (L/min): 34.83

• Maximum Hydraulic Fluid Inlet Pressure (bar): 103
• Maximum Hydraulic Fluid Inlet Pressure (kPa): 10300
• Maximum Hydraulic Fluid Inlet Pressure (psi): 1500

• Maximum Intermittent Cycle Rate (CPM): 60

• Maximum Operating Temperature ( degree C): 66
• Maximum Operating Temperature ( degree F): 150

• Maximum Working Pressure (bar): 207
• Maximum Working Pressure (kPa): 20700
• Maximum Working Pressure (MPa): 20.7
• Maximum Working Pressure (psi): 3000

• Portable: Non-Portable

• Pump Ratio: 20:1

GG 222902

CHECK-MATE 2100 PUMP, VISCOUNT II, 2.4:1

Graco 222902 Viscount II 2.4:1 Ratio Hydraulic Pump

Field-Proven, Energy-Efficient. When paired with any of Graco's priming piston pumps, the Viscount II hydraulic motor offers exceptional cost savings by operating on 20% of the energy used by a pneumatic motor.

• Built-In Reliability - Self-lubricating vertical design for long life and reliable operation in high-vibration environments.
• Quiet Hydraulic Motor - No need for add-on mufflers.
• High-Efficiency Motor - Uses less hydraulic oil.

• Model: Viscount
• Series: II

• Application: Bonding, Sealing, Gasketing, Potting, Encapsulation, Molding, Spray, Fluid Transfer, Unloading, Underfill

• Fluid Outlet Size (in): 1-1/2
• Fluid Outlet Thread Gender: Male
• Fluid Outlet Thread Type: NPT

• Material: Carbon Steel

• Maximum Continuous Cycle Rate (CPM): 60

• Maximum Flow Rate (GPM): 7.5
• Maximum Flow Rate (L/min): 28.4

• Maximum Hydraulic Fluid Inlet Pressure (bar): 103
• Maximum Hydraulic Fluid Inlet Pressure (kPa): 10300
• Maximum Hydraulic Fluid Inlet Pressure (psi): 1500

• Maximum Operating Temperature ( degree C): 66
• Maximum Operating Temperature ( degree F): 150

• Maximum Working Pressure (bar): 159
• Maximum Working Pressure (kPa): 15900
• Maximum Working Pressure (MPa): 15.9
• Maximum Working Pressure (psi): 2300

• Portable: Non-Portable

• Power Type: Hydraulic

• Pump Ratio: 2.4:1

GG 222915

GG 222921

GG 222951

GG 222982

KIT, DETENT, AIR VALVE

Graco 222982 Air Valve Detent Kit for Premier Air Motor

GG 223070

HOSE, COUPLED, 61268, 25 FT

Graco 223070 Standard Grounded Air Hose (Grey)- 0.315 in. (8 mm) ID, 1/4 npsm(f) x 1/4 npsm(f) left-hand thread, 25 ft (7.6 m) length

• Color: Grey

GG 223073

HOSE, COUPLED, 61268, 75 FT

Graco 223073 Standard Grounded Air Hose, Gray, 75 ft (23 m)

GG 223074

HOSE, COUPLED, 61268, 100 FT

Graco 223074 Standard Grounded Air Hose, Gray, 100 ft (30.5 m)

GG 223099

KIT, REPAIR

Graco 223099 Air Motor Replacement Kit

GG 223105

GG 223107

FIREBALL 425 PUMP, LUBT, HP (LUBERANGR)

Graco 223107 Fire-Ball 425 Series 50:1 120 lb. (54 kg) Grease Pump - Lube Truck Package

The Fire-Ball 425 features a large air motor to supply the power you need for long pipe runs and higher-volume dispensing. An ideal choice for applications where multiple dispenses happen at the same time.

• Durable Casting - Thick cast aluminum air motor housing offers unmatched durability.
• Fewer Repairs - Fewer moving parts in the air motor assembly means less downtime and low repair cost.
• Superior Sealing - Non-metallic poppet valves offer positive sealing performance, even with contaminated dirtyair environments for long life without repair.
• Corrosion-Resistant - Corrosion-resistant design utilizes liquid salt nitriding, nickel plating, stainless steel, aluminum and chrome on key components for longer life.

• Model: Fire-Ball
• Series: 425

• Air Inlet Size (in): 0.5
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Industrial

• Compatible Material: Grease

• Container Size (lb): 120

• Fluid Inlet Type: Slotted

• Fluid Outlet Size (cm): 0.9525
• Fluid Outlet Size (in): 3/8
• Fluid Outlet Size (mm): 9.525
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT

• Includes: Fireball 50:1 425 Pump, Hose and Fitting Kit, Cover, Follow Plate, Hold-Down Kit

• Maximum Air Working Pressure: 150

• Maximum Working Pressure (bar): 276
• Maximum Working Pressure (kPa): 27600
• Maximum Working Pressure (MPa): 27.6
• Maximum Working Pressure (psi): 4000

• Motor Type: Pneumatic

• Mount Location: Drum Mount

• Power Type: Pneumatic

• Pump Ratio: 50:1
• Pump Weight (lb): 34

GG 223108

FIREBALL 425 PUMP, 50:1, PKG

Graco 223108 Fire-Ball 425 50:1 120 lb. (55 kg) Grease Pump - Stationary Supply Package

The Fire-Ball 425 features a large air motor to supply the power you need for long pipe runs and higher-volume dispensing. An ideal choice for applications where multiple dispenses happen at the same time.

• Durable Casting - Thick cast aluminum air motor housing offers unmatched durability.
• Fewer Repairs - Fewer moving parts in the air motor assembly means less downtime and low repair cost.
• Superior Sealing - Non-metallic poppet valves offer positive sealing performance, even with contaminated dirtyair environments for long life without repair.
• Corrosion-Resistant - Corrosion-resistant design utilizes liquid salt nitriding, nickel plating, stainless steel, aluminum and chrome on key components for longer life.

• Model: Fire-Ball
• Series: 425

• Air Inlet Size (in): 0.5
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Industrial

• Compatible Material: Grease

• Container Size (lb): 120

• Fluid Inlet Type: Slotted

• Fluid Outlet Size (cm): 0.9525
• Fluid Outlet Size (in): 3/8
• Fluid Outlet Size (mm): 9.525
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT

• Includes: Fireball 50:1 425 Pump, Hose and Fitting Kit, Cover, Follow Plate

• Maximum Air Working Pressure: 150

• Maximum Working Pressure (bar): 276
• Maximum Working Pressure (kPa): 27600
• Maximum Working Pressure (MPa): 27.6
• Maximum Working Pressure (psi): 4000

• Motor Type: Pneumatic

• Mount Location: Drum Mount

• Power Type: Pneumatic

• Pump Ratio: 50:1
• Pump Weight (lb): 34

GG 223177

PUMP, DISPL, RECIP

Graco 223177 Displacement Pump, Carbon Steel, UHMWPE and Leather Packed Pump

GG 223126

GG 223183

PRESIDENT PUMP, 4:1

Graco 223183 President 4:1 Pneumatic 2-Ball Piston Pump, CS, Drum Length

2-ball pneumatic piston pumps for a wide range of applications.

• Reliable President air motor designed for low maintenance operation and long life
• Positive displacement, 2-ball piston design provides uniform and easily controlled delivery
• Stainless steel or carbon steel models available to handle various fluids, including catalyzed materials

• Model: President
• Series: 2-Ball

• Air Inlet Size (in): 3/8
• Air Inlet Size (mm): 9.525
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Supply

• Compatible Material: Waterborne, Solvent borne, High Solids, Xirallic, CARC, Metallics, Topcoats, Stains, Varnish

• Fluid Outlet Size (in): 1
• Fluid Outlet Size (mm): 25.4
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT
• Fluid Section Type: 2-Ball

• Includes: Drum Length

• Material: Carbon Steel

• Maximum Air Inlet Pressure (bar): 6.9
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Continuous Cycle Rate (CPM): 60

• Maximum Flow Rate (GPM): 8
• Maximum Flow Rate (L/min): 30.28

• Maximum Operating Temperature ( degree C): 82
• Maximum Operating Temperature ( degree F): 180

• Maximum Working Pressure (bar): 25
• Maximum Working Pressure (kPa): 2500
• Maximum Working Pressure (MPa): 2.5
• Maximum Working Pressure (psi): 360

• Portable: Non-Portable

• Pump Ratio: 4:1

GG 223184

PRESIDENT PUMP, 4:1

Graco 223184 President 4:1 Pneumatic 2-Ball Piston Pump, CS, Stubby Length

2-ball pneumatic piston pumps for a wide range of applications.

• Reliable President air motor designed for low maintenance operation and long life
• Positive displacement, 2-ball piston design provides uniform and easily controlled delivery
• Stainless steel or carbon steel models available to handle various fluids, including catalyzed materials

• Model: President
• Series: 2-Ball

• Air Inlet Size (in): 0.5
• Air Inlet Size (mm): 12.7
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Supply

• Compatible Material: Waterborne, Solvent borne, High Solids, Xirallic, CARC, Metallics, Topcoats, Stains, Varnish

• Fluid Outlet Size (in): 1
• Fluid Outlet Size (mm): 25.4
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT
• Fluid Section Type: 2-Ball

• Includes: Stubby Length

• Material: Carbon Steel

• Maximum Air Inlet Pressure (bar): 6.9
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Continuous Cycle Rate (CPM): 60

• Maximum Flow Rate (GPM): 8
• Maximum Flow Rate (L/min): 30.28

• Maximum Operating Temperature ( degree C): 82
• Maximum Operating Temperature ( degree F): 180

• Maximum Working Pressure (bar): 248
• Maximum Working Pressure (kPa): 24800
• Maximum Working Pressure (MPa): 24.8
• Maximum Working Pressure (psi): 3600

• Portable: Non-Portable

• Pump Ratio: 4:1

GG 223185

MONARK PUMP, 2:1

Graco 223185 Monark 2:1 Pneumatic 2-Ball Piston Pump, CS, Drum Length

Designed for high production applications, Monark pumps provides uniform and easily controlled delivery with its reliable Monark air motor. Handles a wide range of fluids including cleaning fluids, high-solid coatings, acid-catalyzed materials, resins, high-solid plural component coatings, Solvent borne and waterborne fluids, stains, lacquers and varnishes.

• Drum and stubby length models available for mounting and application flexibility
• Positive displacement, 2-ball piston design provides uniform and easily controlled delivery
• Stainless steel or carbon steel models available to handle various fluids
• Ultra High Molecular Weight Polyethylene (UHMWPE) packings for extended pump life in abrasive fluids

• Model: Monark
• Series: 2-Ball

• Air Inlet Size (in): 3/8
• Air Inlet Size (mm): 9.525
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPSM

• Application: Supply

• Compatible Material: Waterborne, Solvent borne, High Solids, Xirallic, CARC, Metallics, Topcoats, Stains, Varnish

• Fluid Outlet Size (in): 1
• Fluid Outlet Size (mm): 25.4
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT
• Fluid Section Type: 2-Ball

• Includes: Drum Length

• Material: Carbon Steel

• Maximum Air Inlet Pressure (bar): 6.9
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Continuous Cycle Rate (CPM): 60

• Maximum Flow Rate (GPM): 5.4
• Maximum Flow Rate (L/min): 20.44

• Maximum Operating Temperature ( degree C): 82
• Maximum Operating Temperature ( degree F): 180

• Maximum Working Pressure (bar): 12
• Maximum Working Pressure (kPa): 1200
• Maximum Working Pressure (MPa): 1.2
• Maximum Working Pressure (psi): 180

• Portable: Non-Portable

• Pump Ratio: 2:1

GG 223186

MONARK PUMP, 2:1

Graco 223186 Monark 2:1 Pneumatic 2-Ball Piston Pump, CS, Stubby Length

Designed for high production applications, Monark pumps provides uniform and easily controlled delivery with its reliable Monark air motor. Handles a wide range of fluids including cleaning fluids, high-solid coatings, acid-catalyzed materials, resins, high-solid plural component coatings, Solvent borne and waterborne fluids, stains, lacquers and varnishes.

• Drum and stubby length models available for mounting and application flexibility
• Positive displacement, 2-ball piston design provides uniform and easily controlled delivery
• Stainless steel or carbon steel models available to handle various fluids
• Ultra High Molecular Weight Polyethylene (UHMWPE) packings for extended pump life in abrasive fluids

• Model: Monark
• Series: 2-Ball

• Air Inlet Size (in): 3/8
• Air Inlet Size (mm): 12.7
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPSM

• Application: Supply

• Compatible Material: Waterborne, Solvent borne, High Solids, Xirallic, CARC, Metallics, Topcoats, Stains, Varnish

• Fluid Outlet Size (in): 1
• Fluid Outlet Size (mm): 25.4
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT
• Fluid Section Type: 2-Ball

• Includes: Stubby Length

• Material: Carbon Steel

• Maximum Air Inlet Pressure (bar): 6.9
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Continuous Cycle Rate (CPM): 60

• Maximum Flow Rate (GPM): 5.4
• Maximum Flow Rate (L/min): 20.44

• Maximum Operating Temperature ( degree C): 82
• Maximum Operating Temperature ( degree F): 180

• Maximum Working Pressure (bar): 41
• Maximum Working Pressure (kPa): 4100
• Maximum Working Pressure (MPa): 4.1
• Maximum Working Pressure (psi): 600

• Portable: Non-Portable

• Pump Ratio: 2:1

GG 223320

REP KIT

Graco 223320 Repair Kit for Displacement Pump

GG 223340

FORGED CARBON STEEL SWIVEL, Z

Graco 223340 Carbon Steel Z-Swivel with PTFE Packings

Allows Non-Binding Movement for Hard-to-Reach Locations

GG 223363

GG 223364

GG 223367

GG 223373

GG 223426

GG 223427

GG 223439

KIT, REPAIR

Graco 223439 Repair Kit for Carbon Steel 1000 cc Lower with UHMWPE/Leather Packings

GG 223514

GG 223543

GG 223072

HOSE, COUPLED, 61268, 50 FT

Graco 223072 Standard Grounded Air Hose (Grey)- 0.315 in. (8 mm) ID, 1/4 npsm(f) x 1/4 npsm(f) left-hand thread, 50 ft (15 m) length

GG 223547

GG 223689

KIT, SHIELD, 5 GAL. RAM

KIT INCLUDES: SHIELD, 5 GALLON RAM [QTY. 10 ], KIT INCLUDES: FITTING, UNION, SWIVEL [QTY. 1], FITTING, SWIVEL, 90 DEGREE [QTY. 1], HOSE, COUPLED 61020 [QTY. 1], FITTING, ADAPTER, UNION [QTY. 1], FITTING, UNION, ADAPTER [QTY. 1], FITTING, BUSHING, PIPE [QTY. 1], FITTING, SWIVEL, UNION, 90 DEGREE [QTY. 1]

GG 223625

COUPLER, TWIST LOCK

Graco 223625 Straight adapter- twist lock and 3/8 npsm inlet

• Stainless steel construction

• Quickly change between guns, regulators, and lines to reduce setup, changeover, and maintenance time

• Don't flush through guns tips, disconnect and flush through quick connects. Reduce flushing time and avoid premature tip wear.

  Provide flexibility for operators, especially those that own or maintain their own guns. Promote daily maintenance.

• Compatible with Graco Gun Regulators and Restrictors

• Quick couplers automatically seal once disconnected

GG 223586

PRESIDENT PUMP, 30:1

Graco 223586 President 30:1 Pneumatic 2-Ball Piston Pump, CS, Stubby Length

2-ball pneumatic piston pumps for a wide range of applications.

• Reliable President air motor designed for low maintenance operation and long life
• Positive displacement, 2-ball piston design provides uniform and easily controlled delivery
• Stainless steel or carbon steel models available to handle various fluids, including catalyzed materials

• Model: President
• Series: 2-Ball

• Air Inlet Size (in): 0.5
• Air Inlet Size (mm): 12.7
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Supply

• Compatible Material: Waterborne, Solvent borne, High Solids, Xirallic, CARC, Metallics, Topcoats, Stains, Varnish

• Fluid Outlet Size (in): 3/8
• Fluid Outlet Size (mm): 9.525
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT
• Fluid Section Type: 2-Ball

• Includes: Stubby Length

• Material: Carbon Steel

• Maximum Air Inlet Pressure (bar): 8.27
• Maximum Air Inlet Pressure (kPa): 827
• Maximum Air Inlet Pressure (psi): 120

• Maximum Continuous Cycle Rate (CPM): 60

• Maximum Flow Rate (GPM): 1
• Maximum Flow Rate (L/min): 3.79

• Maximum Operating Temperature ( degree C): 82
• Maximum Operating Temperature ( degree F): 180

• Maximum Working Pressure (bar): 248
• Maximum Working Pressure (kPa): 24800
• Maximum Working Pressure (MPa): 24.8
• Maximum Working Pressure (psi): 3600

• Portable: Non-Portable

• Pump Ratio: 30:1

GG 223596

MONARK PUMP,23:1 (CHROME)

Graco 223596 Series B 23:1 Ratio Monark Pump

• Reliable, low maintenance air motor
• Positive displacement, 2-ball piston design provides uniform and easily controlled delivery
• Stainless steel or carbon steel models available to handle various fluids Drum and stubby length models available for mounting and application flexibility

• Air Inlet Size (in): 3/8
• Air Inlet Size (mm): 9.525
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

GG 223624

COUPLER, TWIST LOCK

Graco 223624 Stainless Steel Twist Lock Coupler

• Stainless steel construction

• Quickly change between guns, regulators, and lines to reduce setup, changeover, and maintenance time

• Don't flush through guns tips, disconnect and flush through quick connects. Reduce flushing time and avoid premature tip wear.

  Provide flexibility for operators, especially those that own or maintain their own guns. Promote daily maintenance.

• Compatible with Graco Gun Regulators and Restrictors

• Quick couplers automatically seal once disconnected

• Compatible Material: Waterborne, Solventborne, High Solids, Xirallic, CARC, Metallics, Topcoats, Stains, Varnish

GG 223842

PUMP, DISPL, RECIP

Graco 223842 Severe Duty Stainless Steel Displacement Pump, Series B

• Compatible Material: CARC, Enamel, Epoxies, High Solids, Latex, Lacquer, Metallics, Stains, Single Components, Solventborne Paints, Solventborne, Varnish Primers

GG 223593

HOUSING, VALVE, INTAKE

Graco 223593 Intake Housing Valve, Stainless Steel with Tungsten Carbide Seat

GG 223833

TANK, PRESSURE, 2.5 GAL

Graco 223833 2.5 Gallon Pressure Pot. Aluminum construction, up to 50 psi, with dual regulators for fluid and air control.

• Painted aluminum tank ideal for adhesives or other coatings
• Dual regulators for pulsation-free fluid delivery
• Built-in handle for easy movement

• Includes: Dual Regulator
• Inlet Size (cm): 0.635
• Inlet Size (in): 1/4
• Inlet Size (mm): 6.35

• Inlet Thread Gender: Male
• Inlet Thread Type: NPT

• Maximum Volume Capacity (gal): 2.5
• Maximum Volume Capacity (L): 9

• Maximum Working Pressure (bar): 3.5
• Maximum Working Pressure (kPa): 350
• Maximum Working Pressure (MPa): 0.4
• Maximum Working Pressure (psi): 50

• Outlet Size (cm): 0.9525
• Outlet Size (in): 3/8
• Outlet Size (mm): 9.525
• Outlet Thread Gender: Male
• Outlet Thread Type: NPSM

• Overall Height (cm): 53.3
• Overall Height (in): 21
• Overall Height (mm): 533
• Overall Width (cm): 28.6
• Overall Width (in): 11.25
• Overall Width (mm): 286

GG 223688

GG 223844

MONARK PUMP,15-1 (SST)

Graco 223844 15:1 Ratio Monark Pump, Series A, 2700 psi max fluid working pressure, 180 psi max air input pressure

GG 223675

KIT, REPAIR, SST

Graco 223675 Pump Repair Kit for Graco President 30:1 with Severe Duty Pump Lower

GG 223587

PUMP, DISP, RECIP

Graco 223587 Displacement Pump Assembly for 30:1 President, 15:1 Monark and Viscount I 3000 Pumps

GG 223954

GG 223623

REGULATOR, PRESS, FLUID

Graco 223623 Gun Mounted Fluid Regulator, 3/8 twistlock inlet/outlet, 200 max inbound fluid psi (14 bar), SST wetted parts

• Stainless steel materials are compatible with catalyst and waterborne materials
• Easy and accurate pressure adjustment at the gun to fine tune pressure settings during production
• Connects quickly to spray guns using twistlock connector

• Includes: Regulator Only
• Inlet Size (cm): 0.635
• Inlet Size (in): 1/4
• Inlet Size (mm): 6.35

• Inlet Thread Type: NPSM

• Maximum Regulated Pressure (bar): 2.4
• Maximum Regulated Pressure (kPa): 240
• Maximum Regulated Pressure (MPa): 0.24
• Maximum Regulated Pressure (psi): 35

• Maximum Working Pressure (bar): 13.8
• Maximum Working Pressure (kPa): 1380
• Maximum Working Pressure (MPa): 1.4
• Maximum Working Pressure (psi): 200

• Minimum Regulated Pressure (bar): 0.34
• Minimum Regulated Pressure (kPa): 34
• Minimum Regulated Pressure (MPa): 0.034
• Minimum Regulated Pressure (psi): 5

• Outlet Size (cm): 0.635
• Outlet Size (in): 1/4
• Outlet Size (mm): 6.35

GG 223654

KIT, REPAIR

Graco 223654 Repair Kit for Viscount II Hydraulic Motor

GG 223628

FITTING, COUPLER (TWIST LOCK)

Graco 223628 1.3 oz Twist Lock Coupler Stem 3/8 npsm, 300 psi maximum inbound fluid pressure

• Stainless steel construction

• Quickly change between guns, regulators, and lines to reduce setup, changeover, and maintenance time

• Don't flush through guns tips, disconnect and flush through quick connects. Reduce flushing time and avoid premature tip wear.

  Provide flexibility for operators, especially those that own or maintain their own guns. Promote daily maintenance.

• Compatible with Graco Gun Regulators and Restrictors

• Quick couplers automatically seal once disconnected
