INGERSOLL-RAND IR TOOL S12880

IR 3129XPA

Mini Air Polisher and Buffer, 3" Hook & Loop Pad, 6,000 RPM, 0.3 HP, Pistol

This mini polisher excels in buffing and polishing paint, metal, and plastic surfaces to a high-gloss finish. Performing at a speed of 6,000 RPM, this tool delivers as well as ones twice its size.

Features And Benefits

• Maximum Control: With a 2-speed gearbox and variable speed, this sander is easy to control and can be adjusted to your exact preferences.
• Comfort: This tool’s composite housing and ergonomic textured grip provides user comfort, and its lightweight pistol grip design is engineered for balance and one-handed operation.
• Access: Small and lightweight, this tool can fit into tough spaces with ease.
• Usage: This mini polisher excels in buffing and polishing paint, metal, and plastic surfaces to a high-gloss finish.
• Also available in the 3129KA 4-piece kit which includes a 3" Hook and Loop Backing Pad and (3) Foams.

Product Application and Uses: Buffing and polishing paint, metal, and plastic surfaces to a high-gloss finish.
Actuation/Throttle Type/Switch Type: Trigger
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Color: Grey
Configuration/Handle Type: Pistol Grip
Duty Rating: Standard Duty
Exhaust Location: Handle
Housing Material: Composite
Max Free Speed (rpm): 6000
Max Pressure (bar): 6.2
Min Hose Size (in): 3/8
Pad Diameter or Size (in): 3
Pad Face: Hook & Loop
Power Source: Air Powered
Product Length (in): 6.1
Product Width (in): 1.7
Product Height (in): 5.7
Product Weight (lb): 1.4
Rated Power (hp): 0.3
Sound Pressure/Power Db(A): 83.5 / 94.5
Speed Setting: Variable Speed
Vibration Level (m/s2): 3.5
Vibration Uncertainy K* (m/s2): 1.3
Warranty: 1-year

IR 312A

Random Orbital Air Sander, 3.67 X 6.75" Paper Clamp Pad, 8,000 RPM, 0.3 HP

This orbital air sander can handle virtually any project, whether you’re smoothing fiberglass or sanding paint jobs.

Features And Benefits

• Durable: This sander can withstand harsh environments, so no matter where you decide to work, you’ll never have to worry about your tools functioning.
• Comfort: The compact, contoured palm-grip on this sander allows for one-handed use.
• Performance: With variable speed and a finely tuned motor, you can be sure this sander will perform quickly and efficiently every time.

Includes: Bare Tool
Product Application and Uses: Smoothing Fiberglass, Wood, And Body Filler
Actuation/Throttle Type/Switch Type: Automatic release throttle lever with positive stop action
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Average Air Consumption (cfm): 9
Average Air Consumption (l/min): 255
Color: Black
Configuration/Handle Type: Palm
Duty Rating: Maintenance Duty
Exhaust Location: Rear
Housing Material: Aluminum
Max Free Speed (rpm): 8000
Max Pressure (bar): 6.2
Min Hose Size (in): 3/8
Pad Diameter or Size (in): 3.67 x 6.75
Pad Face: Paper Clamp
Power Source: Air Powered
Product Length (in): 8.5
Product Width (in): 5.5
Product Height (in): 4.33
Product Weight (lb): 4.6
Rated Power (hp): 0.3
Shroud Style: No
Sound Pressure/Power Db(A): 86.0 / 87.0
Special Features: Automatic release throttle lever with positive stop action
Speed Setting: Variable Speed
Standards/Certifications: Ce
Vacuum: None
Vibration Level (m/s2): 7.7
Vibration Uncertainy K* (m/s2): 1.9
Warranty: 1-year

Similar IR

• 315

IR 312A-22

SANDING PAD SHOE BEARING

IR 312A-565

INLET BUSHING

IR 312A-A140

BASE PLATE ASSEMBLY

IR 312A-A226

SANDING PAD SHOE ASSEM

IR 312A-A825

Pad Assembly for Ingersoll Rand 312A Orbital Sander

For Use With

• 312A

IR 313A-226

Pad Nut Part for Ingersoll Rand 313A, 314A Sander

Product Application and Uses: For use with Ingersoll Rand 313A and 314A Sander Polisher

For Use With

• 313A
• 314A

IR 313A-42-4

VANE PACK

IR 313A-48

DEAD HANDLE

IR 313A-A11

FRONT END PLATE ASSEMBLY

IR 313A-A12

Rear End Plate Assembly for Ingersoll Rand 313A Angle Sander and 314A Angle Polisher and Buffer

IR 313A-A283

KIT, GASKET

IR 313A-A302

Throttle Assembly for Ingersoll Rand 313A Angle Sander and 314A Angle Polisher and Buffer

IR 313A-A53

ROTOR ASSEMBLY

IR 313A-A552

GEAR ASSEMBLY

IR 313A-825-7

7" Backing Pad for Ingersoll Rand 313A Angle Sander and 314A Angle Polisher and Buffer

Arbor/Collet: 5/16"-24 Thread
Max Free Speed (rpm): 10000
Number of Vacuum Holes: 0
Pad Diameter or Size (in): 7
Pad Face: Adhesive

For Use With

• 313-B

IR 313A-A591

ARBOR ASSEMBLY

IR 313A-A555

BEARING HOUSING ASSEMBLY

IR 313-B-A11

FRONT END PLATE ASSEMBLY

IR 313-B-A273

LEVER ASSEMBLY

IR 317A-226

Flange Nut for Ingersoll Rand 317A and 317G Air Sander

IR 313-B-A3

CYLINDER ASSEMBLY

IR 317A-42-4

Vane Pack Set of 4 for Ingersoll Rand 317A and 317G Air Sander

IR 317A-825

Backing Pad for Ingersoll Rand 317A and 317G Air Sander

For Use With

• 317A

IR 315

Straight Line Air Sander, 2.75" x 17.5" Pad, 3000 SPM

Great for tough sanding jobs, this straight-line air sander provides smooth finishes and runs up to 3,000 reciprocating strokes per minute.

Features And Benefits

• Performance: This sander's top handle provides an easy grip that allows you to exercise full control over the tool for perfect performance every time.
• Variable Speed: With variable speed, you can adjust your tool to your specifications whenever you need.
• Paper Size: Paper size should be 17.5" long to accommodate wrap around clamps.

Product Application and Uses: This sander is designed for smoothing down body filler or shaping and leveling large flat surfaces.
Actuation/Throttle Type/Switch Type: Lever
Air Consumption @ Load (cfm): 9
Air Consumption @ Load (l/min): 255
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Average Air Consumption (cfm): 8
Average Air Consumption (l/min): 226
Color: Red
Configuration/Handle Type: Straight
Duty Rating: Maintenance Duty
Exhaust Location: Rear
Max Free Speed (rpm): 3000
Max Pressure (bar): 6.2
Min Hose Size (in): 3/8
Pad Diameter or Size (in): 2.75 x 17.5
Pad Face: Paper Clamp
Product Length (in): 17.5
Product Width (in): 2.8
Product Height (in): 6
Product Weight (lb): 6.1
Sound Pressure/Power Db(A): 93.3 / 106.3
Speed Setting: Variable Speed
Stroke Length (in): 1
Strokes (per min): 3000
Vacuum: None
Vibration Level (m/s2): 20.5
Vibration Uncertainy K* (m/s2): 1.6
Warranty: 1-year

IR 313-B-A591

ARBOR ASSEMBLY

IR 314-B

Air Angle Polisher & Buffer, 7" Composite Pad, 3,000 RPM, 0.5 HP

From a range of jobs to a range of surfaces, the air angle polisher and buffer will see you through any application.

Features And Benefits

• Ease of Use: With variable speed options, you can adjust your tool for your applications as needed.
• Reach: This buffer is designed to be able to reach deep, hard to reach spaces.
• Performance: Equipped with a heavy duty .5 HP motor that is ready to handle tough jobs, you’ll perform well any time you use it.

Product Application and Uses: Buff and polish all painted surfaces
Actuation/Throttle Type/Switch Type: Lever
Air Consumption @ Load (cfm): 7.5
Air Consumption @ Load (l/min): 210
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Average Air Consumption (cfm): 6.75
Average Air Consumption (l/min): 190
Color: Silver
Configuration/Handle Type: Right Angle
Duty Rating: Maintenance Duty
Exhaust Location: Side- Handle
Housing Material: Aluminum
Max Free Speed (rpm): 3000
Max Pressure (bar): 6.2
Min Hose Size (in): 3/8
Pad Diameter or Size (in): 7
Power Source: Air Powered
Product Length (in): 12.2
Product Height (in): 3.94
Product Weight (lb): 4.67
Rated Power (hp): 0.5
Sound Pressure/Power Db(A): 91.3/101.3
Special Features: Variable speed for better control
Speed Setting: Variable Speed
Standards/Certifications: CE
Vibration Level (m/s2): 4.7
Warranty: 1-year

Supersedes

• 314A

IR 313-B-42-4

VANE PACK

IR 313-B-A283

Gasket Kit

IR 315-39

Straight Line Sander Backing Pad 2.75" x 17.5" for Ingersoll Rand 315G Sander

Ingersoll Rand's 315-39 Sander Backing pads are durable and strong enough for any application. Pair with your EDGE Series 315G to smooth or flatten large surfaces before painting.

Product Application and Uses: For use with your EDGE Series 315G Air Sander

For Use With

• 315G

IR 313-B

Air Angle Sander, 7" Composite Pad, 5,000 RPM, 0.5 HP, 5/8"-11 Thread, Side Handle Exhaust

With a 7-inch pad that works up to 5,000 RPM, the speed of this air angle sander will have you breezing through every job.

Features And Benefits

• Variety: With a side handle exhaust that blows air away from the work area, you never have to worry about debris getting in your space.
• Performance: Equipped with a heavy duty .5HP motor that is ready to handle tough jobs, you’ll perform well any time you use it.
• Reliability: This powerful sander will deliver reliable output time and time again.

Product Application and Uses: Roughing body filler, removing rust, and smoothing welds
Actuation/Throttle Type/Switch Type: Lever
Air Consumption @ Load (cfm): 6.5
Air Consumption @ Load (l/min): 210
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Arbor/Collet: 5/8"-11 Thread
Average Air Consumption (cfm): 6.75
Average Air Consumption (l/min): 190
Color: Silver
Configuration/Handle Type: Right Angle
Exhaust Location: Side- Handle
Housing Material: Aluminum
Max Free Speed (rpm): 5000
Max Pressure (bar): 6.2
Min Hose Size (in): 3/8
Pad Diameter or Size (in): 7
Pad Face: Adhesive
Power Source: Air Powered
Product Length (in): 12.2
Product Height (in): 3.94
Product Weight (lb): 4.67
Rated Power (hp): 0.5
Sound Pressure/Power Db(A): 94.3/104.7
Standards/Certifications: CE
Vibration Level (m/s2): 2
Warranty: 1-year

Similar IR

• 317-B
• 318-B
• M2L025RS10
• G3L086RS10
• G4621-K22

Supersedes

• 313A

IR 317-B

Air Sander, 3" & 5" Fiber Pad, 18,000 RPM, 0.45 HP, Front Exhaust

This economical high-speed sander is ideal for light sanding, feather edging, and rust removal. With a 0.45 HP, 18,000 RPM motor and built-in power regulator, you can bet this small tool works as well as its bigger counterparts.

Features And Benefits

• Performance: With a built-in power regulator and variable speed, you can exercise full control over your tool and choose exactly how to use it. 0.45 Horsepower and 18000 RPM.
• Comfort: Compact, lightweight, and easy to handle for your prolonged comfort.
• Access: With a 3" (75mm) and 5" (125mm) pad, this sander is great for small jobs and hard-to-reach places.

Includes: 3” and 5” backing pads
Product Application and Uses: For small jobs and hard-to-reach light sanding, feather edging, and rust removal
Actuation/Throttle Type/Switch Type: Trigger
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Average Air Consumption (cfm): 14.8
Average Air Consumption (l/min): 420
Color: Silver
Configuration/Handle Type: Pistol Grip
Duty Rating: Maintenance Duty
Exhaust Location: Front
Housing Material: Aluminum
Max Free Speed (rpm): 18000
Max Pressure (bar): 6.2
Min Hose Size (in): 3/8
Pad Diameter or Size (in): 3 and 5
Pad Face: Fiber
Pad Face: Adhesive
Power Source: Air Powered
Product Length (in): 2
Product Width (in): 1.81
Product Height (in): 6.14
Product Weight (lb): 2.8
Rated Power (hp): 0.45
Sound Pressure/Power Db(A): 94 / 105
Special Features: Built-in Power Regulator
Speed Setting: Variable Speed
Standards/Certifications: CE
Vibration Level (m/s2): 3.2
Vibration Uncertainy K* (m/s2): .81
Warranty: 1-year

Similar IR

• 4151
• 4152
• M2L025RS10
• G4621
• G4621-K22
• 313-B

Supersedes

• 317A

IR 317A-A93

Trigger Assembly for Ingersoll Rand 317A & 317G Air Sander

IR 317-B-A12

Rear End Plate Assembly Service Part for Ingersoll Rand Air Sander

Includes: Rear Rotor Bearing, Rear End Plate, Rear End Plate Dowel
Product Application and Uses: For use with Ingersoll Rand 317-B Air Sander

For Use With

• 317-B

IR 317-B-A11

Front End Plate Assembly Service Part for Ingersoll Rand Air Sander

Includes: Front End Plate, Rotor Spacer, Front Rotor Bearing
Product Application and Uses: For use with Ingersoll Rand 317-B Air Sander

For Use With

• 317-B

IR 318A-42-4

Vane Kit set of 4 for Ingersoll Rand 318A, 319A Polisher/Sander

IR 318A-A10

PLANET GEAR ASSEMBLY

IR 318A-A3

CYLINDER ASSEMBLY

IR 315-740

Backhead Gasket Replacement Part for Ingersoll Rand Straight Line Air Sander

IR 317A-MK1

MUFFLER KIT

IR 318A-A53

ROTOR ASSEMBLY

IR 318A-A825

Pad Assembly for Ingersoll Rand 318A, 319A Vertical Sander

IR 313-B-A12

REAR END PLATE ASSEMBLY

IR 320-40

Housing for Ingersoll Rand 320PG Air Pencil Grinder

Includes:

1 housing

Product Application/Uses:

For use with Ingersoll Rand 320PG Pencil Grinder

IR 320-26

Spanner for Ingersoll Rand 320PG Air Pencil Grinder

Includes: 1 spanner wrench
Product Application and Uses: For use with Ingersoll Rand 320PG Pencil Grinder
Product Length (in): 2.7
Product Width (in): 0.79
Product Height (in): 0.09
Product Weight (lb): 0.02

For Use With

• 320PG
• 320PGK

IR 313-B-A552

GEAR ASSEMBLY

IR 315-38

Board for Ingersoll Rand 315G Straight Line Air Sander

IR 313-B-A302

THROTTLE ASSEMBLY

IR 313-B-A53

Rotor Assembly

IR 318-B

Air Vertical Polisher and Buffer, 7" Pad, 2,000 RPM, 1 HP

This air vertical polisher and buffer is ideal for polishing and buffing all painted surfaces. Even on tough jobs, this tool will give you the results you want, without having to worry about paint burning or overexertion.

Features And Benefits

• Clean Work Area: With a side handle exhaust, you can blow all the debris away from your workspace and work precisely on the task at hand.
• Comfort: The sander’s simple design is lightweight but sturdy, weighing only 4.5 pounds.

Product Application and Uses: Designed for buffing and polishing paint, metal and plastic surfaces to a high-gloss finish.
Actuation/Throttle Type/Switch Type: Lever
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Arbor/Collet: 5/8"-11 Thread
Average Air Consumption (cfm): 20.4
Average Air Consumption (l/min): 190
Color: Silver
Configuration/Handle Type: Vertical
Duty Rating: Maintenance Duty
Exhaust Location: Side- Handle
Handle Material: Aluminum with Rubber Overmold
Housing Material: Aluminum
Max Free Speed (rpm): 2000
Max Pressure (bar): 6.2
Min Hose Size (in): 3/8
Pad Diameter or Size (in): 7
Power Source: Air Powered
Product Length (in): 9.41
Product Width (in): 8.74
Product Height (in): 7.36
Product Weight (lb): 4.5
Rated Power (hp): 1
Sound Pressure/Power Db(A): 84/95
Speed Setting: Variable Speed
Standards/Certifications: CE
Vibration Level (m/s2): 2.2
Warranty: 1-year

Similar IR

• 313-B

Supersedes

• 318A

IR 314AC4A

SUPERCEDED TO 5104MAX

IR 320-747

Grip for Ingersoll Rand 320PG Air Pencil Grinder

Includes:

1 grip

Product Application/Uses:

For use with Ingersoll Rand 320PG Pencil Grinder

IR 318A-37

RING GEAR

IR 318A-A86

CLAMP NUT ASSEMBLY

IR 319A-A10

Planet Gear Assembly for Ingersoll Rand 319A Sander/Polisher

Product Application and Uses: For use with Ingersoll Rand 319A Sander/Polisher

IR 77H-53ARH

ROTOR

IR 77H-98

CYLINDER DOWEL

IR 7802A

3/8" Keyed Chuck Air Drill, 2000 RPM, 0.5 HP, 44in-lb Torque, Pistol

A classic pistol-shaped air drill, the ⅜” comes in multiple configurations and is great for honing, reaming or drilling holes.

Features And Benefits

• Reliable: With a sturdy aluminum housing and variable speed throttle, you can be sure you’ll be able to control your tool and trust that it’ll perform the way you want it to.
• Performance: Powerful .5 HP 2,000 RPM motor
• Lightweight: Lightweight at 2.4 lbs. and 6.4 inches long.

Includes: 3/8 Chuck
Product Application and Uses: Great For Honing, Reaming Or Drilling Holes.
Actuation/Throttle Type/Switch Type: Trigger
Air Consumption @ Load (cfm): 27
Air Consumption @ Load (l/min): 764
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Arbor/Collet: 3/8"-24 Thread
Average Air Consumption (cfm): 4
Average Air Consumption (l/min): 113
Bearing Type: Ball & Roller
Chuck Capacity/Bit Capacity (in): 3/8
Chuck Type: Keyed Chuck
Color: Silver
Configuration/Handle Type: Pistol Grip
Duty Rating: General Duty
Exhaust Location: Handle
Gear Train: Planetary
Handle Material: Aluminum
Height Over Spindle (in): 5.2
Housing Material: Aluminum
Max Free Speed (rpm): 2000
Max Pressure (bar): 6.2
Max Torque (ft-lb): 3.7
Max Torque (in-lb): 44
Max Torque (nm): 4.97
Min Hose Size (in): 3/8
Nominal Drilling Capabilities (Alum 2024t4): 15/64
Nominal Drilling Capabilities (Steel 1213): 1/4
Nominal Drilling Capabilities (Stnls Steel Type 34): 1/8
Nominal Drilling Capabilities (Wood Med or Frp): 5/16"
Power Source: Air Powered
Product Length (in): 6.5
Product Width (in): 7.09
Product Height (in): 6
Product Weight (lb): 2.6
Rated Power (hp): 0.5
Reversible: Non-reversible
Side to Center Distance (in): 0.91
Side to Center Distance (mm): 23
Sound Pressure/Power Db(A): 83.0 / 94.0
Speed Setting: Variable Speed
Spindle Attachment: Drill Chuck
Vibration Level (m/s2): 2.8
Warranty: 1-year

Similar IR

• 7802RA
• 7802RAKCEX
• 7807R-A

IR 7802A-105

BEARING

IR 7802A-A10

PLANET GEAR SET

IR 7802A-A40

HOUSING ASSEMBLY

IR 7802A-A50

Inlet/Exhaust Assembly for Ingersoll Rand 7802, 7803 Series Air Drill

IR 7802A-A53

MOTOR ASSEBMLY

IR 7802A-A8

SPINDLE

IR 7802A-A93

Trigger Assembly for Ingersoll Rand 7802 Series Air Drill

IR 7802AKC

3/8" Keyless Chuck Air Drill, 2000 RPM, 0.5 HP, 2.65in-lb Torque, Pistol

A classic pistol-shaped 3/8" air drill with a keyless chuck and is great for honing, reaming or drilling holes.

Features And Benefits

• Reliable: With a sturdy aluminum housing and variable speed throttle, you can be sure you’ll be able to control your tool and trust that it’ll perform the way you want it to. Comes with a 1-year warranty.

Product Application and Uses: These drills are designed for drilling, valve guide reaming and cylinder honing operations.
Actuation/Throttle Type/Switch Type: Trigger
Air Consumption @ Load (cfm): 26
Air Consumption @ Load (l/min): 736
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Arbor/Collet: 3/8"-24 Thread
Average Air Consumption (cfm): 4
Average Air Consumption (l/min): 113
Bearing Type: Double Row Ball
Chuck Capacity/Bit Capacity (in): 3/8
Chuck Type: Keyless Chuck
Color: Silver
Configuration/Handle Type: Pistol Grip
Duty Rating: Industrial Duty
Exhaust Location: Handle
Gear Train: Planetary
Handle Material: Aluminum
Height Over Spindle (in): 7.8
Housing Material: Aluminum
Max Free Speed (rpm): 2000
Max Pressure (bar): 6.2
Max Torque (ft-lb): 0.2
Max Torque (in-lb): 2.7
Max Torque (nm): 0.3
Min Hose Size (in): 3/8
Power Source: Air Powered
Product Length (in): 7.8
Product Weight (lb): 2.6
Rated Power (hp): 0.5
Reversible: Non-reversible
Side to Center Distance (in): 0.9
Side to Center Distance (mm): 23
Sound Pressure/Power Db(A): 83
Speed Setting: Variable Speed
Vibration Level (m/s2): 2.8
Warranty: 1-year

Similar IR

• 7802RAKC

IR 7802RA-A40

HOUSING ASSEMBLY

IR 7802RA-A93

Trigger Assembly for Ingersoll Rand 7802, 7803 Series Air Drill

IR 7802RAKC

3/8" Keyless Chuck Air Drill, 2000 RPM, 0.5 HP, 2.65in-lb Torque, Pistol

A classic reversible pistol-shaped 3/8" air drill with a keyed chuck and is great for honing, reaming or drilling holes.

Features And Benefits

• Reversible Motor: The quick reverse lever allows you to choose between forward and reverse on the .5 HP motor.
• Reliable: With a sturdy aluminum housing and variable speed throttle, you can be sure you’ll be able to control your tool and trust that it’ll perform the way you want it to.

Includes: 3/8 Chuck
Product Application and Uses: These drills are designed for drilling, valve guide reaming and cylinder honing operations.
Actuation/Throttle Type/Switch Type: Trigger
Air Consumption @ Load (cfm): 26
Air Consumption @ Load (l/min): 736
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Arbor/Collet: 3/8"-24 Thread
Average Air Consumption (cfm): 4
Average Air Consumption (l/min): 113
Bearing Type: Double Row Ball
Chuck Capacity/Bit Capacity (in): 3/8
Chuck Type: Keyless Chuck
Color: Silver
Configuration/Handle Type: Pistol Grip
Duty Rating: Industrial Duty
Exhaust Location: Handle
Gear Train: Planetary
Handle Material: Aluminum
Height Over Spindle (in): 7.4
Housing Material: Aluminum
Max Free Speed (rpm): 2000
Max Pressure (bar): 6.2
Max Torque (ft-lb): 0.2
Max Torque (in-lb): 2.7
Max Torque (nm): 0.3
Min Hose Size (in): 3/8
Nominal Drilling Capabilities (Alum 2024t4): 15/64
Nominal Drilling Capabilities (Steel 1213): 1/4
Nominal Drilling Capabilities (Stnls Steel Type 34): 1/8
Nominal Drilling Capabilities (Wood Med or Frp): 5/16"
Power Source: Air Powered
Product Length (in): 7.4
Product Width (in): 7.09
Product Height (in): 6
Product Weight (lb): 2.9
Rated Power (hp): 0.5
Reversible: Reversible
Side to Center Distance (in): 0.9
Side to Center Distance (mm): 23
Sound Pressure/Power Db(A): 82
Speed Setting: Variable Speed
Spindle Attachment: Drill Chuck
Vibration Level (m/s2): 2.8
Warranty: 1-year

Similar IR

• 7802RAKCEX

IR 7802RA

3/8" Keyed Chuck Air Drill, 2000 RPM, 0.5 HP, 2.65 in-lb Torque, Pistol

A classic reversible pistol-shaped 3/8" air drill with a keyed chuck and is great for honing, reaming or drilling holes.

Features And Benefits

• Performance: 2.65 in-lb Torque, 0.5 HP and 2000 RPM.
• Reversible: Allows you to choose between forward and reverse
• Reliable: With a sturdy aluminum housing and variable speed throttle, you can be sure you’ll be able to control your tool and trust that it’ll perform the way you want it to. Comes with a 1-year warranty.

Includes: 3/8" Chuck
Product Application and Uses: General purpose drilling, honing, reaming, and hole-sawing.
Actuation/Throttle Type/Switch Type: Trigger
Air Consumption @ Load (cfm): 26
Air Consumption @ Load (l/min): 736
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Arbor/Collet: 3/8"-24 Thread
Average Air Consumption (cfm): 4
Average Air Consumption (l/min): 113
Bearing Type: Double Row Ball
Chuck Capacity/Bit Capacity (in): 3/8
Chuck Type: Keyed Chuck
Color: Silver
Configuration/Handle Type: Pistol Grip
Duty Rating: Industrial Duty
Exhaust Location: Handle
Gear Train: Planetary
Handle Material: Aluminum
Height Over Spindle (in): 7.4
Housing Material: Aluminum
Max Free Speed (rpm): 2000
Max Pressure (bar): 6.2
Max Torque (ft-lb): 0.2
Max Torque (in-lb): 2.7
Max Torque (nm): 0.3
Min Hose Size (in): 3/8
Nominal Drilling Capabilities (Alum 2024t4): 15/64
Nominal Drilling Capabilities (Steel 1213): 1/4
Nominal Drilling Capabilities (Stnls Steel Type 34): 1/8
Nominal Drilling Capabilities (Wood Med or Frp): 5/16"
Power Source: Air Powered
Product Length (in): 7.8
Product Width (in): 7.24
Product Height (in): 6
Product Weight (lb): 2.9
Rated Power (hp): 0.5
Reversible: Reversible
Side to Center Distance (in): 0.9
Side to Center Distance (mm): 23
Sound Pressure/Power Db(A): 82
Speed Setting: Variable Speed
Spindle Attachment: Drill Chuck
Vibration Level (m/s2): 2.8
Warranty: 1-year

Similar IR

• 7802A

IR 7802S-6027

Spacer Bushing for Ingersoll Rand 7802 Series Air Drill, 2-Pack

IR 7802RAKCEX

3/8" Keyless Chuck Air Drill, 2000 RPM, 0.5 HP, 43in-lb Torque, Pistol

When it comes to getting the toughest jobs done, professionals around the world choose Ingersoll Rand for tools specifically designed to meet safety regulations for working in dangerous atmospheres. From petrochemical refineries to plastic manufacturers, Ingersoll Rand offers safe and productive solutions to meet the demands of our customers, because making tools that can’t work where our customers work is not an option. 7802RAKCEX is a classic pistol grip air drill, specifically designed to meet ATEX Zone 1 or Zone 2 requirements and is great for honing, reaming or drilling holes.

Features And Benefits

• Performance: 2,000 RPM, 0.5 HP, Keyless Chuck, 2.5 lbs, and 6.4” Long.
• Reversible: The 3/8” Air Drill allows you to choose between forward and reverse.
• Reliable: With a sturdy aluminum housing and variable speed throttle, you can be sure you’ll be able to control your tool and trust that it’ll perform the way you want it to.
• ATEX Markings: ATEX 2014/34/EU and Ex h IIA T6 Gb X
• ISO 80079-36 Certified

Includes: 3/8 Chuck
Product Application and Uses: Great For Honing, Reaming Or Drilling Holes.
Actuation/Throttle Type/Switch Type: Feather-touch Trigger
Air Consumption @ Load (cfm): 24.3
Air Consumption @ Load (l/min): 841
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Arbor/Collet: 3/8"-24 Thread
Average Air Consumption (cfm): 29.7
Average Air Consumption (l/min): 841
Bearing Type: Ball & Roller
Chuck Capacity/Bit Capacity (in): 3/8
Chuck Type: Keyless Chuck
Color: Silver
Configuration/Handle Type: Pistol Grip
Duty Rating: Atex/Hazardous Duty
Exhaust Location: Handle
Gear Train: Planetary
Handle Material: Aluminum
Height Over Spindle (in): 5.05
Housing Material: Aluminum
Max Free Speed (rpm): 2000
Max Pressure (bar): 6.2
Max Torque (ft-lb): 3.6
Max Torque (in-lb): 43
Max Torque (nm): 4.86
Min Hose Size (in): 3/8
Nominal Drilling Capabilities (Alum 2024t4): 15/64
Nominal Drilling Capabilities (Steel 1213): 1/4
Nominal Drilling Capabilities (Stnls Steel Type 34): 1/8
Nominal Drilling Capabilities (Wood Med or Frp): 5/16"
Power Source: Air Powered
Product Length (in): 6.5
Product Width (in): 7.09
Product Height (in): 6
Product Weight (lb): 2.9
Rated Power (hp): 0.5
Reversible: Reversible
Side to Center Distance (in): 0.91
Side to Center Distance (mm): 23
Sound Pressure/Power Db(A): 83.0 / 94.0
Speed Setting: Variable Speed
Spindle Attachment: Drill Chuck
Standards/Certifications: Atex 2014/34/Eu, Atex Ex H Iia T6 Gb X, Iso 80079-36
Vibration Level (m/s2): 2.8
Warranty: 1-year

Similar IR

• 7802A
• 7802RAKC
• 7807R-A
• 6AMST6
• D3141-K22

IR 7802SA

Air Shears, 20 Gauge Capacity, 4200 Strokes per Minute

The versatile 7802SA air shears makes clean cuts in cold rolled steel up to 20 gauge without chips, making it the ideal tool for anyone in vehicle repair or machine shops.

Features And Benefits

• Performance: The trigger actuation allows for featherable speed up to 4,200 strokes per minute and more control over your tool.
• Reliability: With heavy duty cutting blades, this tool is designed to last and produce the high quality you expect from the Ingersoll Rand brand.
• Shears: Most types of plastics and all types of aluminum, tin and steel.
• Cuts: Makes clean clean cuts in cold rolled steel up to 20 gauge. Cuts squares, angles and circles.

Includes: Tool, 2 blades (Left and Right)
Product Application and Uses: Shears cut most types of plastics and all types of aluminum, tin, and steel. Used in vehicle repair or machine shops.
Actuation/Throttle Type/Switch Type: Trigger
Air Consumption @ Load (cfm): 21
Air Consumption @ Load (l/min): 595
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Average Air Consumption (cfm): 4
Average Air Consumption (l/min): 113
Color: Silver
Configuration/Handle Type: Pistol Grip
Duty Rating: General Duty
Exhaust Location: Handle
Housing Material: Aluminum
Max Pressure (bar): 6.2
Min Hose Size (in): 3/8
Number of Power Settings: Continuous
Power Source: Air Powered
Product Length (in): 9.4
Product Height (in): 6.1
Product Weight (lb): 2.8
Rated Power (hp): 0.5
Sound Pressure/Power Db(A): 83 / 94
Steel Capacity (Gauge): 20
Strokes (per min): 4200
Vibration Level (m/s2): 3
Warranty: 1-year

Similar IR

• 429
• 529

IR 7802S-A6022

Blade Kit for Ingersoll Rand 7802SA Air Shears

For Use With

• 7802SA

IR 7803A

1/2" Keyed Chuck Air Drill, 500 RPM, 0.5 HP, 10.6in-lb Torque, Pistol

A classic pistol-shaped 1/2” air drill with a feather trigger for variable speed options and a keyed chuck. This drill is great for honing, reaming or drilling holes.

Features And Benefits

• Reliable: With the durability of its aluminum housing, you can count on this tool to be reliable and work well time after time. Comes with a 1-year warranty.

Product Application and Uses: These drills are designed for drilling, valve guide reaming and cylinder honing operations in the automotive industry.
Actuation/Throttle Type/Switch Type: Trigger
Air Consumption @ Load (cfm): 27
Air Consumption @ Load (l/min): 765
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Average Air Consumption (cfm): 4
Average Air Consumption (l/min): 113
Bearing Type: Double Row Ball
Chuck Capacity/Bit Capacity (in): 1/2
Chuck Type: Keyed Chuck
Color: Silver
Configuration/Handle Type: Pistol Grip
Duty Rating: Industrial Duty
Exhaust Location: Handle
Gear Train: Planetary
Handle Material: Aluminum
Height Over Spindle (in): 9
Housing Material: Aluminum
Max Free Speed (rpm): 500
Max Pressure (bar): 6.2
Max Torque (ft-lb): 0.9
Max Torque (in-lb): 11
Max Torque (nm): 1.2
Min Hose Size (in): 3/8
Power Source: Air Powered
Product Length (in): 9
Product Weight (lb): 3.2
Rated Power (hp): 0.5
Reversible: Non-reversible
Side to Center Distance (in): 0.9
Side to Center Distance (mm): 23
Sound Pressure/Power Db(A): 83
Speed Setting: Variable Speed
Vibration Level (m/s2): <2.5
Warranty: 1-year

Similar IR

• 7803RA

IR 7803A-A8

Spindle for Ingersoll Rand 7802A, 7803A, 7802RA, 7803RA Series Air Drill

IR 7803AKC

1/2" Keyless Chuck Air Drill, 500 RPM, 0.5 HP, 10.6in-lb Torque, Pistol

A classic pistol-shaped 1/2” air drill with a feather trigger for variable speed options and a keyless chuck. This drill is great for honing, reaming or drilling holes.

Features And Benefits

• Reliable: With the durability of its aluminum housing, you can count on this tool to be reliable and work well time after time. Comes with a 1-year warranty.

Includes: tool
Product Application and Uses: These drills are designed for drilling, valve guide reaming and cylinder honing operations.
Actuation/Throttle Type/Switch Type: Trigger
Air Consumption @ Load (cfm): 27
Air Consumption @ Load (l/min): 765
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Average Air Consumption (cfm): 4
Average Air Consumption (l/min): 113
Bearing Type: Double Row Ball
Chuck Capacity/Bit Capacity (in): 1/2
Chuck Type: Keyless Chuck
Color: Silver
Configuration/Handle Type: Pistol Grip
Duty Rating: Industrial Duty
Exhaust Location: Handle
Gear Train: Planetary
Handle Material: Aluminum
Height Over Spindle (in): 8.7
Housing Material: Aluminum
Max Free Speed (rpm): 500
Max Pressure (bar): 6.2
Max Torque (ft-lb): 0.9
Max Torque (in-lb): 11
Max Torque (nm): 1.2
Min Hose Size (in): 3/8
Power Source: Air Powered
Product Length (in): 8.7
Product Weight (lb): 3.3
Rated Power (hp): 0.5
Reversible: Non-reversible
Side to Center Distance (in): 0.9
Side to Center Distance (mm): 23
Sound Pressure/Power Db(A): 83
Speed Setting: Variable Speed
Vibration Level (m/s2): <2.5
Warranty: 1-year

Similar IR

• 7803RAKC

IR 7803RAKC

1/2" Keyless Chuck Air Drill, 500 RPM, 0.5 HP, 10.6in-lb Torque, Pistol

A classic pistol-shaped 1/2” reversible air drill with a keyless chuck great for honing, reaming or drilling holes.

Features And Benefits

• Reversible: Allows you to choose between forward and reverse
• Reliable: With the durability of its aluminum housing, you can count on this tool to be reliable and work well time after time. Comes with a 1-year warranty.

Includes: 1/2" Chuck, 7816-A48 Side Handle
Product Application and Uses: These drills are designed for drilling, valve guide reaming and cylinder honing operations.
Actuation/Throttle Type/Switch Type: Trigger
Air Consumption @ Load (cfm): 27
Air Consumption @ Load (l/min): 765
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Arbor/Collet: 3/8"-24 Thread
Average Air Consumption (cfm): 4
Average Air Consumption (l/min): 113
Bearing Type: Double Row Ball
Chuck Capacity/Bit Capacity (in): 1/2
Chuck Type: Keyless Chuck
Color: Silver
Configuration/Handle Type: Pistol Grip
Duty Rating: Industrial Duty
Exhaust Location: Handle
Gear Train: Planetary
Handle Material: Aluminum
Height Over Spindle (in): 8.7
Housing Material: Aluminum
Max Free Speed (rpm): 500
Max Pressure (bar): 6.2
Max Torque (ft-lb): 0.9
Max Torque (in-lb): 11
Max Torque (nm): 1.2
Min Hose Size (in): 3/8
Nominal Drilling Capabilities (Alum 2024t4): 1/4
Nominal Drilling Capabilities (Steel 1213): 3/16
Nominal Drilling Capabilities (Stnls Steel Type 34): 3/32
Nominal Drilling Capabilities (Wood Med or Frp): 5/16"
Power Source: Air Powered
Product Length (in): 8.7
Product Width (in): 7.24
Product Height (in): 6
Product Weight (lb): 3.3
Rated Power (hp): 0.5
Reversible: Reversible
Side to Center Distance (in): 0.9
Side to Center Distance (mm): 23
Sound Pressure/Power Db(A): 83
Speed Setting: Variable Speed
Spindle Attachment: Drill Chuck
Vibration Level (m/s2): <2.5
Warranty: 1-year

Similar IR

• 7803RAKCEX

IR 7803RAKCEX

1/2" Keyless Chuck Air Drill, 500 RPM, 0.5 HP, 161in-lb Torque Pistol

When it comes to getting the toughest jobs done, professionals around the world choose Ingersoll Rand for tools specifically designed to meet safety regulations for working in dangerous atmospheres. From petrochemical refineries to plastic manufacturers, Ingersoll Rand offers safe and productive solutions to meet the demands of our customers, because making tools that can’t work where our customers work is not an option. 7803RAKCEX is a classic pistol grip air drill, specifically designed to meet ATEX Zone 1 or Zone 2 requirements and is great for honing, reaming or drilling holes.

Features And Benefits

• Performance: 2,000 RPM, 0.5HP, Keyless Chuck, 2.5 lbs, and 6.4” Long.
• Reversible: The 1/2” Air Drill allows you to choose between forward and reverse.
• Reliable: With a sturdy aluminum housing and variable speed throttle, you can be sure you’ll be able to control your tool and trust that it’ll perform the way you want it to.
• ATEX Markings: ATEX 2014/34/EU and Ex h IIA T6 Gb X
• ISO 80079-36 Certified

Includes: 1/2 Chuck, 7816-A48 Side Handle
Product Application and Uses: Great For Honing, Reaming Or Drilling Holes.
Actuation/Throttle Type/Switch Type: Feather-touch Trigger
Air Consumption @ Load (cfm): 26.1
Air Consumption @ Load (l/min): 891
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Average Air Consumption (cfm): 31.58
Average Air Consumption (l/min): 891
Bearing Type: Ball & Roller
Chuck Capacity/Bit Capacity (in): 1/2
Chuck Type: Keyless Chuck
Color: Silver
Configuration/Handle Type: Pistol Grip
Duty Rating: Atex/Hazardous Duty
Exhaust Location: Handle
Gear Train: Planetary
Handle Material: Aluminum
Height Over Spindle (in): 7.05
Housing Material: Aluminum
Max Free Speed (rpm): 500
Max Pressure (bar): 6.2
Max Torque (ft-lb): 13
Max Torque (in-lb): 161
Max Torque (nm): 18.19
Min Hose Size (in): 3/8
Nominal Drilling Capabilities (Alum 2024t4): 1/4
Nominal Drilling Capabilities (Steel 1213): 3/16
Nominal Drilling Capabilities (Stnls Steel Type 34): 3/32
Nominal Drilling Capabilities (Wood Med or Frp): 5/16"
Power Source: Air Powered
Product Length (in): 8.7
Product Width (in): 7.24
Product Height (in): 2
Product Weight (lb): 3.3
Rated Power (hp): 0.5
Reversible: Reversible
Side to Center Distance (in): 0.91
Side to Center Distance (mm): 23
Sound Pressure/Power Db(A): 83.0 / 94.0
Speed Setting: Variable Speed
Spindle Attachment: Drill Chuck
Standards/Certifications: Atex 2014/34/Eu, Ex H Iia T6 Gb X, Iso 80079-36
Vibration Level (m/s2): < 2.5
Warranty: 1-year

Similar IR

• 7803RA
• 7803RAKC
• 7803A

IR 7804KA

1/4" Keyed Chuck Air Drill, 1875 RPM, 0.25 HP, Pistol

This 1/4" reversible mini air drill/driver is an extremely compact and lightweight tool packed with power. It easily fits in the palm of the hand and is great for automotive services or working in tight spaces and for fine-detailing jobs. Featuring a keyed chuck for a secure connection and an adjustable speed setting to provide variability for a broad range of applications. 22-piece kit includes Drill bits, Phillips bits, Slotted bits, Hex bits, Torx bits, 3/8" Socket adaptor and a Magnetic bit extender.

Features And Benefits

• Performance: 1875 RPM, .25 HP, 16.2 CFM, Variable Speed Trigger
• Access: This compact air drill/driver measures 7.6" in length and is great for working in tight spaces.
• Comfort: With a composite housing that insulates from the cold air, you can use this tool for prolonged periods of time without getting fatigued or uncomfortable.
• 22 Piece Kit Includes: 7 Drill bits (1/16", 3/32", 1/8", 5/32", 3/16", 7/32", 1/4), 3 Phillips bits (#1,#2,#3), 3 Slotted bits (#6,#8,#10), 3 Hex bits (3/18", 5/32", 1/8"), 4 Torx bits (T23, T20, T15, T10), 3/8" Socket adaptor and a Magnetic bit extender.

Includes: 7804XPA Mini Air Drill/Driver; (7) Drill bits sizes 1/16", 3/32", 1/8", 5/32", 3/16", 7/32", 1/4"; (3) Phillips screw driver bits sizes #1, #2, #3; (3) Slotted screw driver bits sizes #6, #8, #10; (3) Hex screw driver bits sizes 3/18", 5/32", 1/8"; (4) Torx screw driver bits sizes T23, T20, T15, T10; 3/8" Socket adaptor and a Magnetic bit extender;
Product Application and Uses: Great for the automotive services or working in tight spaces and for fine-detailing jobs.
Actuation/Throttle Type/Switch Type: Trigger
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Average Air Consumption (cfm): 16.2
Average Air Consumption (l/min): 459
Chuck Capacity/Bit Capacity (in): 1/4
Chuck Type: Keyed Chuck
Color: Grey
Configuration/Handle Type: Pistol Grip
Exhaust Location: Handle
Handle Material: Composite
Housing Material: Composite
Max Free Speed (rpm): 1875
Max Pressure (bar): 6.2
Min Hose Size (in): 3/8
Number of Power Settings: 2
Power Source: Air Powered
Product Length (in): 7.6
Product Width (in): 1.7
Product Height (in): 6.4
Product Weight (lb): 1.8
Rated Power (hp): 0.25
Reversible: Reversible
Sound Pressure/Power Db(A): 84.3 / 95.3
Speed Setting: Variable Speed
Vibration Level (m/s2): 2.9
Vibration Uncertainy K* (m/s2): .8
Warranty: 1-year

IR 7804XPA

1/4" Keyed Chuck Air Drill, 1875 RPM, 0.25 HP, Pistol

This 1/4" reversible mini air drill/driver is an extremely compact and lightweight tool packed with power. It easily fits in the palm of the hand and is great for automotive services or working in tight spaces and for fine-detailing jobs. Featuring a keyed chuck for a secure connection and an adjustable speed setting to provide variability for a broad range of applications.

Features And Benefits

• Performance: 1875 RPM, .25 HP, 16.2 CFM, Variable Speed Trigger
• Access: This compact air drill/driver measures 7.6" in length and is great for working in tight spaces.
• Comfort: With a composite housing that insulates from the cold air, you can use this tool for prolonged periods of time without getting fatigued or uncomfortable.
• Also available in the 7804KA 22-piece kit which includes Drill bits, Phillips bits, Slotted bits, Hex bits, Torx bits, 3/8" socket adaptor and a magnetic bit extender.

Product Application and Uses: Great for automotive services or working in tight spaces and for fine-detailing jobs.
Actuation/Throttle Type/Switch Type: Trigger
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Average Air Consumption (cfm): 16.2
Average Air Consumption (l/min): 459
Chuck Capacity/Bit Capacity (in): 1/4
Chuck Type: Keyed Chuck
Color: Grey
Configuration/Handle Type: Pistol Grip
Exhaust Location: Handle
Handle Material: Composite
Housing Material: Composite
Max Free Speed (rpm): 1875
Max Pressure (bar): 6.2
Min Hose Size (in): 3/8
Number of Power Settings: 2
Power Source: Air Powered
Product Length (in): 7.6
Product Width (in): 7.24
Product Height (in): 6.4
Product Weight (lb): 1.8
Rated Power (hp): 0.25
Reversible: Reversible
Sound Pressure/Power Db(A): 84.3 / 95.3
Speed Setting: Variable Speed
Vibration Level (m/s2): 2.9
Vibration Uncertainy K* (m/s2): .8
Warranty: 1-year

IR 7807R-A

3/8" Keyed Chuck Angle Air Drill, 1800 RPM, 0.33 HP

The 3/8" Right Angle Air Drill is a durable, reliable tool that’s great for drilling in all types of materials, including sheet metal, wood and composites.

Features And Benefits

• Performance: .33HP and 1,800 RPM
• Precision: With an angle configuration that allows easier reach and access with an easy-to-control speed lever, you’ll be able to use this air drill with precision and get every job done right.
• Durability: With aluminum housing, this tool is sturdy and durable, and can withstand repeated drops and harsh environments with ease.
• Reliability: You can count on this drill to work time and time again.

Includes: 3/8 Chuck
Product Application and Uses: Great for drilling in all types of materials, including sheet metal, wood and composites.
Actuation/Throttle Type/Switch Type: Lever
Air Consumption @ Load (cfm): 26
Air Consumption @ Load (l/min): 736
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Arbor/Collet: 3/8"-24 Thread
Average Air Consumption (cfm): 4
Average Air Consumption (l/min): 113
Bearing Type: Ball & Roller
Chuck Capacity/Bit Capacity (in): 3/8
Chuck Type: Keyed Chuck
Color: Silver
Configuration/Handle Type: Right Angle
Duty Rating: General Duty
Exhaust Location: Handle
Gear Train: Planetary
Handle Material: Aluminum
Housing Material: Aluminum
Max Free Speed (rpm): 1800
Max Pressure (bar): 6.2
Min Hose Size (in): 3/8
Power Source: Air Powered
Product Length (in): 8.06
Product Width (in): 1.65
Product Height (in): 4.12
Product Weight (lb): 2.5
Rated Power (hp): 0.33
Rated Power (kW): 0.25
Reversible: Reversible
Sound Pressure/Power Db(A): 87 / 98
Speed Setting: Variable Speed
Vibration Level (m/s2): <2.5
Warranty: 1-year

Similar IR

• 7LM3A43
• 7AKST6
• 7802A
• 6AMST6
• D3141-K22
• 7802RAKCEX

Supersedes

• 7807R
• 7807R-EU

IR 7810-1B

Inline Multi-Vane Air Motor, 1/2" Keyed Spindle, 450 RPM, 0.7 HP, 39.8 NM, Reversible

Air Consumption at Max HP (scfm): 37.3
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 1/2
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 450
Max Pressure (bar): 6.2
Max Torque (ft-lb): 29
Max Torque (in-lb): 352
Max Torque (nm): 39.8
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 4
Power Source: Air Powered
Product Weight (lb): 5.67
Rated Power (hp): 0.7
Rated Power (kW): 0.52
Reversible: Reversible
Sound Level dB(A): 85
Speed at Max Power (rpm): 240
Torque Output @ Max HP (ft-lb): 15
Torque Output @ Max HP (nm): 21
Warranty: 1-year

IR 7803RA

1/2" Keyed Chuck Air Drill, 500 RPM, 0.5 HP, 10.6in-lb Torque, Pistol

A classic pistol-shaped 1/2” reversible air drill with a feather trigger for variable speed options and a keyed chuck. this drill is as versatile as it is efficient.

Features And Benefits

• Reliable: With the durability of its aluminum housing, you can count on this tool to be reliable and work well time after time.
• Reversible Motor: The quick reverse lever allows you to choose between forward and reverse on the .5 HP motor.
• Balanced: Planetary gear reduction balances the load.

Includes: 1/2 Chuck Tool, 7816-A48 Side Handle
Product Application and Uses: Designed for drilling, hole-sawing, cylinder honing, and any other job that calls for a 1/2” size
Actuation/Throttle Type/Switch Type: Trigger
Air Consumption @ Load (cfm): 27
Air Consumption @ Load (l/min): 765
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Arbor/Collet: 1/2"-24 Thread
Average Air Consumption (cfm): 4
Average Air Consumption (l/min): 113
Bearing Type: Double Row Ball
Chuck Capacity/Bit Capacity (in): 1/2
Chuck Type: Keyed Chuck
Color: Silver
Configuration/Handle Type: Pistol Grip
Duty Rating: Industrial Duty
Exhaust Location: Handle
Gear Train: Planetary
Handle Material: Aluminum
Height Over Spindle (in): 8.7
Housing Material: Aluminum
Max Free Speed (rpm): 500
Max Pressure (bar): 6.2
Max Torque (ft-lb): 0.9
Max Torque (in-lb): 11
Max Torque (nm): 1.2
Min Hose Size (in): 3/8
Nominal Drilling Capabilities (Alum 2024t4): 1/4
Nominal Drilling Capabilities (Steel 1213): 3/16
Nominal Drilling Capabilities (Stnls Steel Type 34): 3/32
Nominal Drilling Capabilities (Wood Med or Frp): 5/16"
Power Source: Air Powered
Product Length (in): 8.7
Product Width (in): 7.09
Product Height (in): 6
Product Weight (lb): 3.3
Rated Power (hp): 0.5
Reversible: Reversible
Side to Center Distance (in): 0.9
Side to Center Distance (mm): 23
Sound Pressure/Power Db(A): 83
Speed Setting: Variable Speed
Spindle Attachment: Drill Chuck
Vibration Level (m/s2): <2.5
Warranty: 1-year

Similar IR

• 7803A

IR 7811R-13

SPRING PIN

IR 7810-B

Inline Multi-Vane Air Motor, 1/2" Keyed Spindle, 450 RPM, 0.7 HP, 39.8 NM, Reversible

Air Consumption at Max HP (scfm): 37.3
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 1/2
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 450
Max Pressure (bar): 6.2
Max Torque (ft-lb): 29
Max Torque (in-lb): 352
Max Torque (nm): 39.8
Motor: Rotary Vane
Motor: In line
Mounting Type: Foot Mount Optional
Power Source: Air Powered
Product Weight (lb): 5.17
Rated Power (hp): 0.7
Rated Power (kW): 0.52
Reversible: Reversible
Sound Level dB(A): 85
Speed at Max Power (rpm): 240
Torque Output @ Max HP (ft-lb): 15
Torque Output @ Max HP (nm): 21
Warranty: 1-year

IR 7811R-254

Chuck Screw for Ingersoll Rand 7802A, 7803A, 7802RA, 7803RA Series Air Drill

IR 7L1A-593

BEARING

IR 7AJ-A10

SPINDLE PLANET GEAR ASSEMBLY

IR 7849-E

DRILL

IR 7RL-42-5

Vane Pack

IR 7RAQT4

TAPPER

IR 7RL-A40

HOUSING

IR 7S60L

Air Sander and Polisher, 7" Pad, 6,000 RPM, 0.8 HP, 5/8"-11 Thread, Side Exhaust

Designed for large areas and heavy duty materials, the Pro Series 7P sander and polishers are ready to get any job done.

Features And Benefits

• Complete with solid steel motor and arbor housing, these tools can withstand repeated drops and harsh conditions.
• These tools have a built-in mist lubricator that automatically oils the motor whenever the throttle is activated for smooth operation.

Product Application and Uses: These Sanders and Polishers are designed for standard duty sanding and polishing operations.
Actuation/Throttle Type/Switch Type: Safety Lever
Air Consumption @ Load (cfm): 15.5
Air Consumption @ Load (l/min): 439
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Color: Silver
Configuration/Handle Type: Vertical
Duty Rating: Industrial Duty
Exhaust Location: Side
Max Free Speed (rpm): 6000
Max Pressure (bar): 6.2
Min Hose Size (in): 5/16
Mounting Type: Arbor
Pad Diameter or Size (in): 7
Power Source: Air Powered
Product Weight (lb): 3.25
Rated Power (hp): 0.8
Sound Pressure/Power Db(A): 79.0
Speed Setting: Variable Speed
Vacuum: None
Vibration Level (m/s2): <2.5
Warranty: 1-year
Wheel Diameter (in): 7

IR 7S60L-273

Lever

IR 7AN-80

GEAR HEAD SPACER

IR 8000-109

CAP

IR 8000-159A

Valve Face

IR 7RL-S/D-A/T-TK1

TUNE-UP KIT
