INGERSOLL-RAND IR TOOL S12880
INGERSOLL-RAND IR TOOL S12880 branded products
VANE PACK
IR 7811R-42-6
IR 7811R-42-6
Ingersoll Rand Vane Pack Replacement Part, Set of 6
Product Application and Uses: For use with Ingersoll Rand 7802SA Air Shear, 7802A, 7803A, 7802RA, 7803RA Series Air Drill
$15.00
8 PC CARBIDE BUR KIT
IR 814TIN
IR 814TIN
Carbide Burr Kit, 8-Piece, 1/4" Shank, 1/2 & 3/8" Head Diameter with Hard Case
Ingersoll Rand carbide burrs are titanium nitride (TiN) coated to provide maximum edge retention and corrosion resistance. The TiN coating can improve the average lifetime of the burr by more than three times. Note: Burrs have a maximum operating speed of 40,000 rpm.Finish: Titanium Nitride (TiN) Coated
Shank SIze (in): 1/4
For Use With
- 308B
- 308B-M
- 308BK
$335.00
POWER MOTOR
IR 8206-A
IR 8206-A
Inline Multi-Vane Air Motor, 7/8" Keyed Shaft, 275 RPM, 1.9 HP, 142.3 NM, Reversible
Air Consumption at Max HP (scfm): 93.5Air Inlet: 3/8" NPT
Air Pressure (psi): 90
Drive Size (in): 7/8
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 49:1
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 275
Max Pressure (bar): 6.2
Max Torque (ft-lb): 105
Max Torque (in-lb): 1259
Max Torque (nm): 142.3
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 4
Power Source: Air Powered
Product Weight (lb): 18.24
Rated Power (hp): 1.9
Rated Power (kW): 1.42
Reversible: Reversible
Sound Level dB(A): 95
Speed at Max Power (rpm): 150
Torque Output @ Max HP (ft-lb): 66
Torque Output @ Max HP (nm): 90.1
Warranty: 1-year
$5,100.00
CHUCK 1/2" CAP
IR 7816-99
IR 7816-99
Chuck 1/2" Cap for Ingersoll Rand 7803A, 7803RA Air Drill
Product Application and Uses: For use with Ingersoll Rand 7803A and 7803RA Air Drills.For Use With
- 7803A
- 7803RA
$74.00
CHUCK SCREW
IR 7816R-254
IR 7816R-254
Chuck Screw for Ingersoll Rand 7802RA, 7803RA Series Air Drill
$15.00
POWER MOTOR
IR 8231-1B
IR 8231-1B
Inline Multi-Vane Air Motor, 3/8" Keyed Shaft, 18000 RPM, 0.5 HP, 0.7 NM, Reversible
Air Consumption at Max HP (scfm): 41Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 3/8
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 1:1
Gear Reduction: Direct Drive
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 18000
Max Pressure (bar): 6.2
Max Torque (ft-lb): 0.5
Max Torque (in-lb): 6.2
Max Torque (nm): 0.7
Motor: Rotary Vane
Motor: In line
Mounting Type: Foot Mount Optional
Power Source: Air Powered
Product Weight (lb): 2.45
Rated Power (hp): 0.5
Rated Power (kW): 0.37
Reversible: Reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 9200
Torque Output @ Max HP (ft-lb): 0.3
Torque Output @ Max HP (nm): 0.4
Warranty: 1-year
$1,827.00
Air Strainer
IR 834-61
IR 834-61
Air Strainer Screen
Product Application and Uses: For use with Ingersoll Rand 99HG45H108, 99HG60H106 Grinders, 77V, 88V, 99V Series Grinders, 2161, 2171, 2925TI Impacts, A, W, D Series Chipping HammersFor Use With
- 2161XP
- 2161XP-6
- 2171XP
- 2925B2TI
- 2925P1TI
- 2925P3TI
- 2925RB2TI
- 2925RBP1TI
- 2925RBP1TIEX
- 2925RBP3TI
$15.00
Seal (49440-3)
IR 85H-167
IR 85H-167
Valve Seal Replacement Part for Ingersoll Rand Air Drills, Impact Wrenches and Die Grinders
Product Application and Uses: For use with 7A, and 5 Series Air Drills; 280, 290, 3940, 3942, 293, and 3955 Series Impact Wrenches; G3 Series Air Die Grinders
$15.00
SPRING LOCK FOR BARR GRVD, QTY 1
IR 89938450
IR 89938450
Spring Lock, Threaded or Grooved Barrel for Ingersoll Rand Rivet Busters
Product Application and Uses: For use with Ingersoll Rand 8001A, 9001A, 11001A rivet busters.Housing Material: Steel
For Use With
- 11001A
- 8001A
- 9001A
$15.00
Vertical Grinder - 6, 000 RPM
IR 88V60P107
IR 88V60P107
Vertical Air Grinder, 7" Type 27/28 Wheel, 6000 RPM, 2.1 HP, 5/8 in-11 Thread, Side Exhaust
Ingersoll Rand Pro Series are tough, easy to handle, and ready to tackle any project you need them for. They are specially designed for heavy duty applications. With their superior power output, they are best suited for big tasks involving heavy material removal in foundries, welding shops, fabrication facilities, steel mills or shipyards.Features And Benefits
- Safety: The 88 Pro Series’ lock-out lever, guard and side-handle safety is designed to increase comfort and block sparks and debris.
- Durability: You can count on the 88 Pro Series to withstand chemical spills, repeated drops, and other harsh environments.
- Reliability: The patented motor controller removes material faster, prevents over speeding and reduces operator fatigue.
Includes: Guard
Product Application and Uses: Heavy Stock Removal And Rough Grinding In Metal Fabrication Operations
Actuation/Throttle Type/Switch Location: Top
Actuation/Throttle Type/Switch Type: Safety Lever
Air Consumption @ Load (cfm): 61
Air Consumption @ Load (l/min): 1728
Air Inlet: 1/2" NPT
Air Pressure (psi): 90
Arbor/Collet: 5/8"-11 Thread
Bearing Type: Ball Bearing
Color: Black
Configuration/Handle Type: Vertical
Duty Rating: Heavy Duty
Exhaust Location: Side
Grinder Type: Vertical Type 27/28
Height Over Spindle (in): 6.1
Housing Material: Aluminum
Lock Mechanism: Lever lock in off position
Max Free Speed (rpm): 6000
Max Pressure (bar): 6.2
Min Hose Size (in): 3/4
Power Source: Air Powered
Product Length (in): 15.9
Product Width (in): 11.3
Product Height (in): 8.2
Product Weight (lb): 8.75
Rated Power (hp): 2.1
Side to Center Distance (in): 2.1
Side to Center Distance (mm): 53
Sound Pressure/Power Db(A): 86.2 / 97.2
Standards/Certifications: En Iso 28927-1, En Iso 15744, En Iso 11148-7
Vibration Level (m/s2): 3.1
Vibration Uncertainy K* (m/s2): 0.9
Warranty: 1-year
Wheel Diameter (in): 7
Wheel Thickness (in): 1/4
Wheel Type: Type 27, 28
Similar IR
- 99V60P107
- 88V60P109
- 99V60P109
$931.50
VERTICAL SANDER - 6, 000
IR 88S60W107
IR 88S60W107
Vertical Air Sander, 7" Pad, 6,000 RPM, 2 HP, 5/8"-11 Thread, Side Exhaust
These Pro Series sanders are made to tackle large areas and heavy duty materials.Features And Benefits
- The 88S sander was made with a solid steel motor, arbor housing, and double-row ball bearings to assure long life and smooth operation.
- Featuring a built-in mist lubricator, this tool stays well-oiled every time the throttle is activated.
- Made to tackle large areas and heavy duty materials.
Product Application and Uses: These Air Sanders are designed for both light and heavy sanding jobs such as roughing body filler, removing rust, and smoothing welds.
Actuation/Throttle Type/Switch Type: Safety Lever
Air Inlet: 1/2" NPT
Air Pressure (psi): 90
Arbor/Collet: 5/8"-11 Thread
Bearing Type: Double Row Ball
Configuration/Handle Type: Vertical
Exhaust Location: Side
Max Free Speed (rpm): 6000
Max Pressure (bar): 6.2
Min Hose Size (in): 3/4
Pad Diameter or Size (in): 7
Power Source: Air Powered
Product Weight (lb): 7.13
Rated Power (hp): 2
Sound Pressure/Power Db(A): 77.2
Vibration Level (m/s2): <2.5
Warranty: 1-year
$1,028.10
FLAT CHISEL - 18"
IR 9001-276-18
IR 9001-276-18
18" Flat Rivet Buster Chisel Steel, Jumbo Shank
Ingersoll Rand offers a complete line of construction tool steels and accessories for countless applications. Our construction heritage dates back to 1871 with the invention of the world’s first rockdrill. Drawing on our long and successful history in the construction industry, we use top-grade materials to manufacture a line of tough, durable products that are versatile enough to be used in virtually every tool brand. Our jumbo shank rivet buster steels and attachments are ideal for general demolition and steel demolition applications.Includes: (15) Rivet Buster Chisel Steels
Product Application and Uses: Designed for general demolition. For use with Ingersoll Rand 8001A, 9001, 9001A, 11001A, 11001 rivet busters.
Chisel Edge Style: Flat
Chisel Style: Flat
Housing Material: Steel
Product Length (in): 18
Product Weight (lb): 3.75
Shank SIze (in): 0.866
Shank Type: Jumbo
For Use With
- 11001
- 11001A
- 8001A
- 9001
- 9001A
$51.00
SPRING (48951-172)
IR 908B5-918
IR 908B5-918
Socket Retainer Replacement Part for Ingersoll Rand 259G and 261 3/4" Drive Impact Wrench
Includes: 3/4" socket retainerProduct Application and Uses: For use with Ingersoll Rand 259G and 261 Series 3/4" drive Impact Wrenches
For Use With
- 259G
- 261
- 261-3
- 261-6
$20.00
GASKET
IR 910-36
IR 910-36
Hammer Case Gasket for Ingersoll Rand 1720, 261, 271 Impact Wrench
For Use With- 1720P1
- 1720P3
- 261
- 261-3
- 261-6
- 271
$15.00
SPRING
IR 910E5-918
IR 910E5-918
Retainer Ring Replacement Part for Ingersoll Rand 1" Drive 295A and 271 Impact Wrench
Product Application and Uses: For use with Ingersoll Rand 295A and 271 Series 1" drive impact wrenchesFor Use With
- 271
- 295A
$19.00
CONTROL SWITCH GCH 2-BUTTON +NA, LIFT 19.6FT
IR 9290.1089.3
IR 9290.1089.3
CONTROL SWITCH GCH 2-BUTTON +NA, LIFT 19.6FT
$555.00
MOTOR -- MULTI-VANE
IR 92RB029
IR 92RB029
Spur Gear Air Motor, 1-1/2" Keyed Shaft, 327 RPM, 7.9 HP, 545 NM, Reversible
Air Consumption at Max HP (scfm): 225Air Inlet: 1" NPT
Air Pressure (psi): 90
Drive Size (in): 1-1/2
Drive Type: Round Keyed
Exhaust Location: Side
Finish: Paint, Yellow
Gear Reduction: Double
Gear Train: Spur Gear
Housing Material: Aluminum
Max Free Speed (rpm): 327
Max Pressure (bar): 6.2
Max Torque (ft-lb): 402
Max Torque (in-lb): 4824
Max Torque (nm): 545
Motor: Rotary Vane
Motor: Spur Gear
Mounting Type: Foot and Face
Power Source: Air Powered
Product Weight (lb): 78
Rated Power (hp): 7.9
Rated Power (kW): 5.89
Reversible: Reversible
Speed at Max Power (rpm): 160
Starting Torque (ft-lb): 280
Starting Torque (nm): 380
Warranty: 1-year
$8,134.50
MOTOR -- MULTI-VANE
IR 92RB045
IR 92RB045
Spur Gear Air Motor, 1-1/2" Keyed Shaft, 210 RPM, 7.9 HP, 849 NM, Reversible
Air Consumption at Max HP (scfm): 225Air Inlet: 1" NPT
Air Pressure (psi): 90
Drive Size (in): 1-1/2
Drive Type: Round Keyed
Exhaust Location: Side
Finish: Paint, Yellow
Gear Reduction: Double
Gear Train: Spur Gear
Housing Material: Aluminum
Max Free Speed (rpm): 210
Max Pressure (bar): 6.2
Max Torque (ft-lb): 626
Max Torque (in-lb): 7514
Max Torque (nm): 849
Motor: Rotary Vane
Motor: Spur Gear
Mounting Type: Foot and Face
Power Source: Air Powered
Product Weight (lb): 78
Rated Power (hp): 7.9
Rated Power (kW): 5.89
Reversible: Reversible
Speed at Max Power (rpm): 103
Starting Torque (ft-lb): 440
Starting Torque (nm): 597
Warranty: 1-year
$8,352.00
MOTOR -- MULTI-VANE
IR 92RM2
IR 92RM2
Spur Gear Air Motor, 7/8" Keyed Shaft, 3980 RPM, 9.9 HP, 61 NM, Non-reversible
Air Consumption at Max HP (scfm): 240Air Inlet: 1" NPT
Air Pressure (psi): 90
Drive Size (in): 7/8
Drive Type: Round Keyed
Exhaust Location: Side
Finish: Paint, Yellow
Gear Train: Spur Gear
Housing Material: Aluminum
Max Free Speed (rpm): 3980
Max Pressure (bar): 6.2
Max Torque (ft-lb): 45
Max Torque (in-lb): 540
Max Torque (nm): 61
Motor: Rotary Vane
Motor: Spur Gear
Mounting Type: Face
Number of Mounting Holes: 18
Power Source: Air Powered
Product Weight (lb): 24.25
Rated Power (hp): 9.9
Rated Power (kW): 7.38
Reversible: Non-reversible
Speed at Max Power (rpm): 2095
Starting Torque (ft-lb): 33
Starting Torque (nm): 44.7
Warranty: 1-year
$6,325.00
MOTOR -- MULTI-VANE
IR 92RM1
IR 92RM1
Spur Gear Air Motor, 7/8" Keyed Shaft, 3980 RPM, 9.9 HP, 61 NM, Non-reversible
Air Consumption at Max HP (scfm): 240Air Inlet: 1" NPT
Air Pressure (psi): 90
Drive Size (in): 7/8
Drive Type: Round Keyed
Exhaust Location: Side
Finish: Paint, Yellow
Gear Train: Spur Gear
Housing Material: Aluminum
Max Free Speed (rpm): 3980
Max Pressure (bar): 6.2
Max Torque (ft-lb): 45
Max Torque (in-lb): 540
Max Torque (nm): 61
Motor: Rotary Vane
Motor: Spur Gear
Mounting Type: Face
Number of Mounting Holes: 18
Power Source: Air Powered
Product Weight (lb): 24.25
Rated Power (hp): 9.9
Rated Power (kW): 7.38
Reversible: Non-reversible
Speed at Max Power (rpm): 2095
Starting Torque (ft-lb): 33
Starting Torque (nm): 44.7
Warranty: 1-year
$6,275.00
DIGGER
IR 93A1
IR 93A1
Digger, 7/8 x 3-1/4" Hex Shank, 2350 BPM, 2.5" Stroke Length, 1.69" Bore
Ideal for digging clay, frozen ground, horizontal concrete demolition, tunneling, and bridgework, the 93 Series diggers can tackle almost anything. With a short, powerful 2.5 inch piston stroke and multiple configurations available, you can remove material quickly and easily.Features And Benefits
- Access: The 93 Series features a tease throttle for maximum precision, coupled with a D-shape handle to allow access to tighter spaces.
- Durability: With a rubber buffer retainer to absorb shock and protect the tool, the 93 Series diggers will last for years.
- Reliability: The side exhaust and steel cone increase user safety and productivity for better use every time.
- Weight: Built with premium materials, the 93 Series diggers are lightweight weighing 22 lbs. and easy to use.
Product Application and Uses: Ideal for digging clay, frozen ground, horizontal concrete demolition, tunneling, and bridgework
Actuation/Throttle Type/Switch Type: Inside Trigger
Air Consumption @ Load (cfm): 45
Air Consumption @ Load (l/min): 12.74
Air Inlet: 3/8" NPT
Air Pressure (psi): 90
Blows per Min: 2350
Bore Diameter (in): 1.69
Collar Type: Round
Color: Beige
Configuration/Handle Type: D-Handle
Duty Rating: Industrial Duty
Exhaust Location: Side
Housing Material: Aluminum
Max Pressure (bar): 6.2
Min Hose Size (in): 1/2
Power Source: Air Powered
Product Length (in): 18.88
Product Weight (lb): 22
Retainer Type: Sleeve
Shank SIze (in): 7/8 x 3-1/4
Shank Type: Hex
Stroke Length (in): 2.5
Vibration Level (m/s2): 28 / 8.0
Warranty: 1-year
Similar IR
- 93A4
- 93LA1
- 95A1
- 95LA1
$1,345.20
RETAINING PIN Ø4X22 CLAMP GPM250, GP 250
IR 9500.3134.4
IR 9500.3134.4
RETAINING PIN Ø4X22 CLAMP GPM250, GP 250
$15.00
