Other Pumps

GG P30LC1

GG P32LSS

DURA-FLO PUMP, 6500/430

Graco P32LSS 32:1 - 430cc Dura-Flo Pump with NXT 6500 Air Motor, Severe Duty Stainless Steel Construction

Graco Supply Pumps reliably deliver one-component sealants, adhesives and other low to medium-viscosity materials to metering and dispensing systems. Maximize your plants production capacity.

• NXT 6500 Air Motor


  Low Noise

  Modular design for easier maintenance

  Rugged body armor wont rust or dent

  Highest technology air motor on the market

• 430cc Dura-Flo Lower


  Severe Duty coatings on rods and cylinder Extends production time

• Standard Threaded Coupler -

• Replaceable Seat

  Minimizes service costs

• Cast Outlet and Inlet Housing

  Improves structural integrity

  • Optional DataTrak Control

    Runaway protection

    Pump diagnostics

    Material usage




    • Model: Dura-Flo
    • Ambient/Warm Melt/Hot Melt: Ambient
    • Application: Bonding, Sealing, Gasketing, Potting, Encapsulation, Molding, Spray, Fluid Transfer, Unloading, Underfill
    • Compatible Material: CARC, High Solids, Metallics, Solvent borne, Stains, Varnish, Xirallic
    • Fluid Inlet Size (in): 2
    • Fluid Inlet Size (mm): 50.8000
    • Fluid Inlet Thread Gender: Female
    • Fluid Inlet Thread Type: NPT
    • Fluid Outlet Size (in): 1-1/2
    • Fluid Outlet Thread Gender: Male
    • Fluid Outlet Thread Type: NPT
    • Includes: Motor, Lower, Rod Tie, Collar Coupling, Adaptor, Nut Coupling, Nut Hex, Wrench
    • Material: Stainless Steel
    • Maximum Working Pressure (bar): 209
    • Maximum Working Pressure (kPa): 20900
    • Maximum Working Pressure (MPa): 20.9
    • Maximum Working Pressure (psi): 3030
    • Power Type: Pneumatic
    • Pump Ratio: 32:1

GG P40DC1

GG PF3540

SPX P59

SPX RH203

AA DAB05-ASAA-2-A

AA DAB05-ASCC-2-G

AA DAB05-ASTT-2-A

AA DAB05-PPAA-2-A

AA DAB05-PPAA-2-E

AA DAB05-PPCC-2-A

AA DAB05-PPTT-2-A

AA DAB05-SSTT-2-A

AA DAB05-SSTT-2-H

AA P237A1-EU

AA P35A1-EU

ASC ASC-A-2-BMP-NPT

GG 205627

GG 205628

GG 232434

GG 237958

GG 243663

GG 244680

HUSKY SYSTEM, BULK ANTIFREEZE/WWS

Graco 244680 Husky 1050 - Single Inlet Bulk Antifreeze and Windshield Solvent Transfer Packages

The Husky 1050 air-operated diaphragm pump features a stall-free low pulsation air valve which provides a smooth and rapid changeover. The one-piece center section eliminates leaks and reduces maintenance on Husky pumps when compared to other diaphragm pumps.

• Longer Diaphragm Life - Up to 5x longer diaphragm life for less maintenance and downtime
• Modular Air Valve - Stall-free, low pulsation operation provides smooth and rapid changeover
• One-Piece Center Section - Eliminates air leaks for more efficient operation
• Multiple Ports - Increased number of ports for installation flexibility
• Optional Features - DataTrak (Runaway protection and tracks material usage), Pulse Output (Cycle count capability)
• Spring loaded, externally serviceable pilot valves for faster change over and reduced pulsation
• 30% more efficient than the market leader
• 20% increase in fluid flow compared to the Husky 1040

• Model: Husky
• Series: 1050

• Application: Industrial

• Ball Material: Acetal

• Compatible Material: Antifreeze, Windshield Washer Fluid

• Diaphragm Material: Thermoplastic Polyester Elastomer

• Fluid Inlet Size (cm): 2.5400
• Fluid Inlet Size (in): 1
• Fluid Inlet Size (mm): 25.4
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (cm): 2.54
• Fluid Outlet Size (in): 1
• Fluid Outlet Size (mm): 25.4
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT

• For Use With: Anti-Freeze, Windshield Solvent

• Includes: 1050 AODD Pump, Air Regulator, Fluid Connect Hose, Air Connect Hose, Air Shut-Off Valve, Wall Mount Bracket, Suction Kit, Thermal Relief Kit

• Inlet Thread Gender: Female
• Inlet Thread Type: NPT

• Material: Aluminum, Buna-N

• Maximum Air Pressure (bar): 7

• Maximum Air Pressure (kPa): 70
• Maximum Air Pressure (psi): 100

• Maximum Cycle Rate (CPM): 280

• Maximum Flow Rate (GPM): 50

• Maximum Fluid Pressure (bar): 8.3
• Maximum Fluid Pressure (kPa): 83
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Fluid Pressure (bar): 8.3
• Maximum Fluid Pressure (kPa): 83
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Solid Size (cm): 0.3175
• Maximum Solid Size (in): 0.125
• Maximum Solid Size (mm): 3.175

GG 244682

HUSKY SYSTEM, ANTI-FREEZE, WWS

Graco 244682 Husky 716 - Single Inlet Bulk Antifreeze and Windshield Solvent Transfer Packages

The Husky 716 air operated diaphragm pump delivers up to 16 gpm (60.6 lpm) of fluid and features center and end porting options.

• Center- and end-porting
• No mechanical seals which causes fluid leaks or failures
• Runs quietly at less than 85 dBa with easy-to-use remote muffler capability for even lower noise levels
• 3/4 in (19.05 mm) center- and end-porting
• No seals to leak or fail
• Quiet running less than 85 dBa with easy-to-use remote muffler capability for even lower noise levels
• Easy-to-service air valve and ball checks

• Model: Husky
• Series: 716

• Application: Industrial

• Compatible Material: Antifreeze, Windshield Washer Fluid

• Fluid Inlet Size (cm): 1.9050
• Fluid Inlet Size (in): 3/4
• Fluid Inlet Size (mm): 19.05
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (cm): 1.905
• Fluid Outlet Size (in): 3/4
• Fluid Outlet Size (mm): 19.05
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT

• For Use With: Anti-Freeze, Windshield Solvent

• Includes: 716 AODD Pump, Air Regulator, Fluid Connect Hose, Air Connect Hose, Air Shut-Off Valve, Wall Mount Bracket, Suction Kit, Thermal Relief Kit

• Inlet Thread Gender: Female
• Inlet Thread Type: NPT

• Material: Aluminum, Buna-N

• Maximum Air Pressure (bar): 7

• Maximum Air Pressure (kPa): 70
• Maximum Air Pressure (psi): 100

• Maximum Cycle Rate (CPM): 400

• Maximum Flow Rate (GPM): 16

• Maximum Fluid Pressure (bar): 7
• Maximum Fluid Pressure (kPa): 70
• Maximum Fluid Pressure (MPa): 0.7
• Maximum Fluid Pressure (psi): 100

• Maximum Fluid Pressure (bar): 7
• Maximum Fluid Pressure (kPa): 70
• Maximum Fluid Pressure (MPa): 0.7
• Maximum Fluid Pressure (psi): 100

• Maximum Solid Size (cm): 0.2381
• Maximum Solid Size (in): 0.09375
• Maximum Solid Size (mm): 2.3813
