GG 563308
MODU-FLO PUMP, ASSY, AL-50
Graco 563308 Modu-Flo® AL-50 Pneumatic Pump without Reservoir
Mix and match pumps, reservoir and manifolds in any configuration to meet any application. Replace the pump or reservoir without disconnecting lubrication lines.
- Easy to standardize on components and reduce inventory
- Adjustable pump output for fast, convenient customizing
- Lubriquip part number 521-000-041
- Model: Modu-Flo
- Series: AL-50
- Application: In-Plant Machinery
- Compatible Material: Oil, Grease
- Compatible Metering Device: Series Progressive
- Maximum Air Inlet Pressure (bar): 10.34
- Maximum Air Inlet Pressure (kPa): 1034
- Maximum Air Inlet Pressure (psi): 150
- Maximum Cycle Rate (CPM): 30
- Maximum Fluid Output Pressure (bar): 241
- Maximum Fluid Output Pressure (psi): 3500
- Maximum Fluid Output Pressure (bar): 241
- Maximum Fluid Output Pressure (psi): 3500
- Maximum Working Pressure (bar): 207
- Maximum Working Pressure (kPa): 20680
- Maximum Working Pressure (MPa): 31
- Maximum Working Pressure (psi): 3000
- Overall Depth (cm): 8.1
- Overall Depth (in): 3.188
- Overall Depth (mm): 81
- Overall Height (cm): 8.1
- Overall Height (in): 3.188
- Overall Height (mm): 81
- Overall Width (cm): 32.5
- Overall Width (in): 12.812
- Overall Width (mm): 325
