GRACO INC. S10595

GG 25C977

KIT, 10 PACK, ELBOW, 3/16-1/8NPT

Graco 25C977 Electric Grease Jockey System Truck with Greaseable Spring Pins - 3/16 in. to 1/8 in. NPT Elbows, 10-Pack

• 3/16 in to 1/8 NPT elbows, 10-Pack (qty)

• Application: On-Road Vehicles

• Compatible Material: Grease

• Connection Type: Tube End, Threaded

• For Use With: Tube

• Material: Brass

GG 25C978

KIT, 10 PACK, 3/16-1/8NPT

Graco 25C978 Electric Grease Jockey System Truck with Greaseable Spring Pins - 3/16 in. to 1/8 in. NPT Straights, 10-Pack

• 3/16 in to 1/8 NPT straights, 10-Pack

• Application: On-Road Vehicles

• Compatible Material: Grease

• Connection Type: Tube End, Threaded

• For Use With: Tube

• Material: Brass

GG 25C979

KIT, ELBOW, 15K784, 5 PK

Graco 25C979 Electric Grease Jockey System Truck with Greaseable Spring Pins - 1/4-28 in. to 1/8 in. NPT Female, 5-Pack

• 1/4-28 SAE to 1/8 NPT (F), 5-Pack

• Application: On-Road Vehicles

• Compatible Material: Grease

• Connection Type: Threaded

• Finish/Coating: Zinc

• For Use With: Pipe

• Material: Steel

GG 25C983

KIT, DOUBLING, OUTPUT

Graco 25C983 Electric Grease Jockey Pump Output Doubling Kit

• Output doubling kit

• Model: Grease Jockey

GG 25D011

GG 25D136

GG 25D135

GG 25D137

GG 25D138

GG 25D143

GG 25D145

GG 25D235

GG 25D236

GG 25D237

GG 25D238

GG 25D244

GG 25D245

GG 25D246

GG 25D248

GG 25D259

GG 25D260

GG 25D262

GG 25D295

KIT, COMPLETE, CS T3, AIR/FLUID

Graco 25D295 T3 Complete Package: Includes 2 Pumps (Carbon Steel), 2 Supply Hoses, Air Supply Kit and Desicant Dryer Kit

Transfer Pumps are required to move A and B materials to the Reactor Spray Systems. The T3 Transfer Pump combines Graco's proven Merkur air-motor and popular T2 stainless steel lower. The T3 is a 3:1 ratio pump - using less air pressure to provide the same fluid pressure required.

• Easier to maneuver - The overall height of the T3 is 3.7 inches (9.4 cm) shorter above the drum than the T2, making it easier to remove from the drum inside of a spray rig.
• More quiet - Studies show the T3 Transfer Pump is about 3x more quiet than the T2 Transfer Pump.
• Less maintenance - the Merkur air-motor is based on air pilot valve technology. The air-motor switching

  is purely pneumatic. This differs from T1 and T2 Transfer Pumps, which use a mechanical

  reversing mechanism in the air-motor

• Model: T3
• Series: Carbon Steel

• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Industrial

• Compatible Material: Polyurethane Foam, Polyurea

• Cycles Per Gallon: 30

• Fluid Outlet Size (in): 3/4
• Fluid Outlet Size (mm): 19.05
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT

• Includes: Fluid Supply Kit, Air Hose Kit

• Material: Carbon Steel

• Maximum Air Inlet Pressure (bar): 6.9
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (MPa): 0.69
• Maximum Air Inlet Pressure (psi): 100

• Maximum Flow Rate (GPM): 4.5
• Maximum Flow Rate (L/min): 17.03

• Maximum Operating Temperature ( degree C): 88
• Maximum Operating Temperature ( degree F): 190

• Maximum Working Pressure (bar): 21.7
• Maximum Working Pressure (kPa): 2170
• Maximum Working Pressure (MPa): 2.2
• Maximum Working Pressure (psi): 315

• Package Options: Air Supply & Supply Hose

• Pump Ratio: 3:1

GG 25D296

KIT, SUPPLY, CS T3, /W PLUMBING

Graco 25D296 T3 Package: Includes 2 Pumps (Carbon Steel) and 2 Supply Hoses

Transfer Pumps are required to move A and B materials to the Reactor Spray Systems. The T3 Transfer Pump combines Graco's proven Merkur air-motor and popular T2 stainless steel lower. The T3 is a 3:1 ratio pump - using less air pressure to provide the same fluid pressure required.

• Easier to maneuver - The overall height of the T3 is 3.7 inches (9.4 cm) shorter above the drum than the T2, making it easier to remove from the drum inside of a spray rig.
• More quiet - Studies show the T3 Transfer Pump is about 3x more quiet than the T2 Transfer Pump.
• Less maintenance - the Merkur air-motor is based on air pilot valve technology. The air-motor switching is purely pneumatic. This differs from T1 and T2 Transfer Pumps, which use a mechanical reversing mechanism in the air-motor

• Model: T3
• Series: Carbon Steel

• Material: Carbon Steel

• Package Options: Supply Hose

GG 25D312

GG 25D458

GG 25D460

GG 25D477

GG 25D482

KIT,14 VALVE CC CONTROL

Graco 25D482 14 Valve Color Change Solenoid Module Kit

GG 25D483

KIT,15 VALVE CC CONTROL

Graco 25D483 15 Valve Color Change Solenoid Module Kit

GG 25D486

KIT, 18 VALVE CC CONTROL

Graco 25D486 18 Valve Color Change Solenoid Module Kit

GG 25D511

GG 25D340

LINELAZER SPRAYER, V, 250SPS, 2 GUN, 2PBS, LSR

Graco 25D340 LineLazer V 250SPS HP Reflective Series Self-Propelled Gas Hydraulic Airless Line Striper, 2 Auto Guns, 2 Tanks, LazerGuide 3000

With exclusive automatic paint guns and hydraulic power, the LineLazer V 250SPS HP Reflective Series is a self-propelled system with reflective bead capability designed for large, heavy-duty line striping jobs including parking lots and road jobs.

• Pressurized EZ Bead System
  • Superior Bead Application Performance
  • Ensures proper bead flow and paint penetration
  • Dual bead tanks hold up to 120 lbs each
• Automatic Paint Gun System
  • Automatically Stripe Skip-Lines
  • Reduce operator fatigue - push button line production
  • Quality solenoid driven system
• LazerGuide 3000 Long-Line Lazer
  • Easier, laser-straight lines
  • Longer distance accuracy
  • Highly-visible laser guise
  • Faster, simple operation
• 25-Gallon Paint Hopper
  • Less Refilling
  • Extended striping time with large capacity hopper
• Honda GX Engine
  • Reliable, Easy-to-Start Power
  • Contractor-preferred - excellent power and proven reliability
  • Oil Alert shuts down engine to prevent damage if oil level drops too low
• Electric Start
  • Fast starting
• EasyMark Gun Adjustment System
  • Easy Gun Adjustments
  • Perfect gun alignment every time with easy-to-use guide mark system
  • 2-gun capability with QuikSelect gun selector
• Front or Rear Gun Mount
  • Straighter long lines
  • Use up to six guns
• Additional Features
  • Self-Centering Front Wheel
  • Easy Handlebar Adjustment
  • Endurance Chromex Pump
  • High-Efficiency Hydraulic Motor
  • High-Capacity Cooling System
  • Easy Out Pump Filter

• Model: LineLazer V
• Series: 250SPS
• Product Series: HP Reflective

• Attachments: LazerGuide 3000

• Bead System: Pressurized Bead System
• Bead Tank Size (lb): 240

• Compatible Material: Road-Marking Paint
• Compatible Surfaces: Pavement, Turf

• Engine Brand: Honda
• Engine Model: GX390

• Features: SmartControl

• Fuel Tank Capacity (gal): 1.4
• Fuel Tank Capacity (L): 5.3

• Gun Activation: 2 Automatic

• Hopper Volume Capacity (gal): 25
• Hopper Volume Capacity (L): 95

• Includes: LazerGuide 3000, Pressurized Bead System (2 Tanks), Flex Plus Gun (2), LineLazer RAC 5 321 Spray Tip (2), LineLazer RAC 5 425 Spray Tip (2), LineLazer RAC 5 627 Spray Tip (2), RAC 5 Tip Guard (2), 3/8 in x 12 ft (3.7 m) BlueMax II Airless Hose, 3/8 in x 3 ft (0.9 m) BlueMax II Airless Whip Hose, TSL 4 oz (118 mL)

• Maximum Flow Rate (GPM): 2.5
• Maximum Flow Rate (L/min): 9.46

• Maximum Tip Size (cm): 0.1397
• Maximum Tip Size (in): 0.055
• Maximum Tip Size (mm): 1.397

• Maximum Working Pressure (bar): 227
• Maximum Working Pressure (kPa): 2270
• Maximum Working Pressure (psi): 3300

• Number of Colors: One Color

• Number of Guns: 2
• Number of Hoppers: 1
• Number of Pumps: 1

• Power Rating (HP): 13

GG 25D433

GG 25D480

KIT,12 VALVE CC CONTROL

Graco 25D480 12 Valve Color Change Solenoid Module Kit

GG 25E493

GG 25E470

GG 25D934

GG 25D515

GG 25E299

GG 25D605

KIT, PD2K REMOTE MAN, DVM HP

Graco 25D605 ProMix PD2K High Pressure Remote Manifold Custom Valve Mapping Kit

To add optional color change function and at-the-gun mixing of two component materials when used with a ProMix PD Proportioner for Automatic Spray Applications.

• Model: ProMix
• Series: PD2K

GG 25D846

GG 25E152

GG 25D893

GG 25D842

GG 25D543

KIT, PD2K REMOTE MANIFOLD, DVM LP

Graco 25D543 ProMix PD2K Low Pressure Remote Manifold Custom Valve Mapping Kit

To add optional color change function and at-the-gun mixing of two component materials when used with a ProMix PD Proportioner for Automatic Spray Applications.

• Model: ProMix
• Series: PD2K

GG 25E492

GG 25E298

GG 25D535

GG 25E217

GG 25D632

GG 25D844

GG 25E426

GG 25E491

GG 25E490

GG 25E670

GG 25E618

GG 25E658

GG 25E494

gg 25F088

GG 25F103

KIT, POTENTIOMETER, IND HAZLOC

Graco 25F103 QUANTM i-Series Pump Control Knob for Hazardous Location Industrial Pump Models

• Includes:
  • 1 control knob bracket
  • 2 fasteners
  • 1 control encoder
  • 1 push nut
  • 1 control knob with 2 fasteners, hex head
  • 1 seal
  • 1 packet of anti-seize lubricant

GG 25F089

GG 25F113

GG 25F122

KIT, REPAIR, Q30 ROTOR

Graco 25F122 QUANTM i/h30 Rotor Kit

• Includes:
  • 1 rotor with bearing
  • 1 shaft

GG 25F155

MANIFOLD, AUTO, GUN

Graco 25F155 Stellair Auto Manifold, Side Fluid Inlet, with Inch Threads

Side fluid inlet manifold connects a Stellair Auto air spray gun to an automated finishing system's robot, reciprocator, or flat line machine.

• Stellair Auto manifold has the same tool center point as legacy AirPro Auto air spray guns, making it easy to upgrade paint line and spray booth equipment.
• Durable and lightweight construction reduces equipment wear, especially on high speed production lines.
• Two-screw, gun-to-manifold connection simplifies automatic air spray gun removal and maintenance.

GG 25F168

GUN, AUTO, CONV, .042, ADJ

Graco 25F168 Stellair Automatic Air Spray Gun, Conventional, 0.042 in (1.1 mm) Nozzle for General Industry with fluid control knob

Conventional air spray gun delivers stellar results as part of a robotic, reciprocator, flat line or other automated finishing system.

• Conventional is the most widely used air spray method, producing Class A, automotive finish quality.
• General industry air caps and nozzles produce a uniform, high quality spray pattern with low atomizing pressure.
• Precise fluid flow control click knob with true zero set point ensures accurate paint thickness.
• One piece fluid cartridge can be removed and replaced so quickly that it nearly eliminates maintenance related downtime.
• Direct stainless steel fluid path cuts the amount of solvent needed to flush the gun, reducing VOC (volatile organic compound) emissions.

• Application: General Industry
• Applicator Type: Automatic

• Body Material: Metal

• Compatible Material: Adhesives, Ceramics, Fast-Set, High Solids, Sealants, Solventborne Paints, Stain, UV Coating, Waterborne

• Fluid Adjustment Knob: Clicking
• Fluid Orifice Size (in): 0.042
• Fluid Orifice Size (mm): 1.10

• Gun Model: Stellair
• Gun Series: Automatic
• Gun Type: Conventional Gun
• Gun Weight (g): 430
• Gun Weight (lb): 1

• Manifold Type: Not Included

• Maximum Air Pressure (bar): 7

• Maximum Air Pressure (MPa): 0.7
• Maximum Air Pressure (psi): 100

• Maximum Flow Rate (oz/min): 14

• Maximum Fluid Temperature ( degree C): 49
• Maximum Fluid Temperature ( degree F): 120

• Maximum Fluid Temperature ( degree C): 49
• Maximum Fluid Temperature ( degree F): 120

• Maximum Fluid Working Pressure (bar): 21
• Maximum Fluid Working Pressure (MPa): 2.1
• Maximum Fluid Working Pressure (psi): 300

• Minimum Air Inlet Pressure (bar): 3.4
• Minimum Air Inlet Pressure (MPa): 0.34
• Minimum Air Inlet Pressure (psi): 50

• Needle Tip Material: PEEK
• Nozzle Size (in): 0.042
• Nozzle Size (mm): 1.10

• Overall Height (in): 1.9
• Overall Height (mm): 48.3
• Overall Length (in): 5.9
• Overall Length (mm): 150
• Overall Width (in): 1.63
• Overall Width (mm): 41.4

GG 25F173

GUN, AUTO, HVLP, .070

Graco 25F173 Stellair Automatic Air Spray Gun, HVLP, 0.070 in (1.8 mm) Nozzle for General Applications

High volume low pressure (HVLP) air spray gun produces stellar results on an automated paint line or in a robotic spray booth.

• High volume low pressure (HVLP) air spray produces a controlled, low velocity spray pattern that reduces bounce back and overspray, while meeting environmental regulations.
• General industry air caps and nozzles produce a uniform, high quality spray pattern with low atomizing pressure.
• Patented spray pattern alignment and pathing tool ensures accurate and repeatable spray angle. It is easily attached and detached from the gun to keep production moving.
• Small and light size does not weigh down or wear out robot arms, reciprocators or flat line machines.
• Direct stainless steel fluid path cuts the amount of solvent needed to flush the gun, reducing VOC (volatile organic compound) emissions.

• Application: General
• Applicator Type: Automatic

• Body Material: Metal

• Compatible Material: Adhesives, Ceramics, Fast-Set, High Solids, Sealants, Solvent borne Paints, Stains, UV Coating, Waterborne

• Fluid Adjustment Knob: N/A
• Fluid Orifice Size (in): 0.070
• Fluid Orifice Size (mm): 1.8

• Gun Model: Stellair
• Gun Series: Automatic
• Gun Type: HVLP Gun
• Gun Weight (g): 430
• Gun Weight (lb): 1

• Manifold Type: Not Included

• Maximum Air Pressure (bar): 7

• Maximum Air Pressure (MPa): 0.7
• Maximum Air Pressure (psi): 100

• Maximum Flow Rate (oz/min): 20

• Maximum Fluid Temperature ( degree C): 49
• Maximum Fluid Temperature ( degree F): 120

• Maximum Fluid Temperature ( degree C): 49
• Maximum Fluid Temperature ( degree F): 120

• Maximum Fluid Working Pressure (bar): 21
• Maximum Fluid Working Pressure (MPa): 2.1
• Maximum Fluid Working Pressure (psi): 300

• Minimum Air Inlet Pressure (bar): 3.4
• Minimum Air Inlet Pressure (MPa): 0.34
• Minimum Air Inlet Pressure (psi): 50

• Needle Tip Material: PEEK
• Nozzle Size (in): 0.070
• Nozzle Size (mm): 1.8

• Overall Height (in): 1.9
• Overall Height (mm): 48.3
• Overall Length (in): 5.10
• Overall Length (mm): 129.5
• Overall Width (in): 1.63
• Overall Width (mm): 41.4

GG 25F181

GG 25F167

GUN, AUTO, CONV, .030, ADJ

Graco 25F167 Stellair Automatic Air Spray Gun, Conventional, 0.030 in (0.8 mm) Nozzle for General Industry with fluid control knob

Conventional air spray gun delivers stellar results as part of a robotic, reciprocator, flat line or other automated finishing system.

• Conventional is the most widely used air spray method, producing Class A, automotive finish quality.
• General industry air caps and nozzles produce a uniform, high quality spray pattern with low atomizing pressure.
• Precise fluid flow control click knob with true zero set point ensures accurate paint thickness.
• One piece fluid cartridge can be removed and replaced so quickly that it nearly eliminates maintenance related downtime.
• Direct stainless steel fluid path cuts the amount of solvent needed to flush the gun, reducing VOC (volatile organic compound) emissions.

• Application: General Industry
• Applicator Type: Automatic

• Body Material: Metal

• Compatible Material: Adhesives, Ceramics, Fast-Set, High Solids, Sealants, Solventborne Paints, Stain, UV Coating, Waterborne

• Fluid Adjustment Knob: Clicking
• Fluid Orifice Size (in): 0.030
• Fluid Orifice Size (mm): 0.8

• Gun Model: Stellair
• Gun Series: Automatic
• Gun Type: Conventional Gun
• Gun Weight (g): 430
• Gun Weight (lb): 1

• Manifold Type: Not Included

• Maximum Air Pressure (bar): 7

• Maximum Air Pressure (MPa): 0.7
• Maximum Air Pressure (psi): 100

• Maximum Flow Rate (oz/min): 10

• Maximum Fluid Temperature ( degree C): 49
• Maximum Fluid Temperature ( degree F): 120

• Maximum Fluid Temperature ( degree C): 49
• Maximum Fluid Temperature ( degree F): 120

• Maximum Fluid Working Pressure (bar): 21
• Maximum Fluid Working Pressure (MPa): 2.1
• Maximum Fluid Working Pressure (psi): 300

• Minimum Air Inlet Pressure (bar): 3.4
• Minimum Air Inlet Pressure (MPa): 0.34
• Minimum Air Inlet Pressure (psi): 50

• Needle Tip Material: PEEK
• Nozzle Size (in): 0.03
• Nozzle Size (mm): 0.8

• Overall Height (in): 1.9
• Overall Height (mm): 48.3
• Overall Length (in): 5.9
• Overall Length (mm): 150
• Overall Width (in): 1.63
• Overall Width (mm): 41.4

GG 25F169

GUN, AUTO, CONV, .055, ADJ

Graco 25F169 Stellair Automatic Air Spray Gun, Conventional, 0.055 in (1.4 mm) Nozzle for General Industry with fluid control knob

Conventional air spray gun delivers stellar results as part of a robotic, reciprocator, flat line or other automated finishing system.

• Conventional is the most widely used air spray method, producing Class A, automotive finish quality.
• General industry air caps and nozzles produce a uniform, high quality spray pattern with low atomizing pressure.
• Precise fluid flow control click knob with true zero set point ensures accurate paint thickness.
• One piece fluid cartridge can be removed and replaced so quickly that it nearly eliminates maintenance related downtime.
• Direct stainless steel fluid path cuts the amount of solvent needed to flush the gun, reducing VOC (volatile organic compound) emissions.

• Application: General Industry
• Applicator Type: Automatic

• Body Material: Metal

• Compatible Material: Adhesives, Ceramics, Fast-Set, High Solids, Sealants, Solventborne Paints, Stain, UV Coating, Waterborne

• Fluid Adjustment Knob: Clicking
• Fluid Orifice Size (in): 0.055
• Fluid Orifice Size (mm): 1.4

• Gun Model: Stellair
• Gun Series: Automatic
• Gun Type: Conventional Gun
• Gun Weight (g): 430
• Gun Weight (lb): 1

• Manifold Type: Not Included

• Maximum Air Pressure (bar): 7

• Maximum Air Pressure (MPa): 0.7
• Maximum Air Pressure (psi): 100

• Maximum Flow Rate (oz/min): 18

• Maximum Fluid Temperature ( degree C): 49
• Maximum Fluid Temperature ( degree F): 120

• Maximum Fluid Temperature ( degree C): 49
• Maximum Fluid Temperature ( degree F): 120

• Maximum Fluid Working Pressure (bar): 21
• Maximum Fluid Working Pressure (MPa): 2.1
• Maximum Fluid Working Pressure (psi): 300

• Minimum Air Inlet Pressure (bar): 3.4
• Minimum Air Inlet Pressure (MPa): 0.34
• Minimum Air Inlet Pressure (psi): 50

• Needle Tip Material: PEEK
• Nozzle Size (in): 0.055
• Nozzle Size (mm): 1.4

• Overall Height (in): 1.9
• Overall Height (mm): 48.3
• Overall Length (in): 5.9
• Overall Length (mm): 150
• Overall Width (in): 1.63
• Overall Width (mm): 41.4

GG 25F175

GUN, AUTO, HVLP, .042, ADJ

Graco 25F175 Stellair Automatic Air Spray Gun, HVLP, 0.042 in (1.1 mm) Nozzle for General Applications with fluid control knob

High volume low pressure (HVLP) air spray gun produces stellar results on an automated paint line or in a robotic spray booth.

• High volume low pressure (HVLP) air spray produces a controlled, low velocity spray pattern that reduces bounce back and overspray, while meeting environmental regulations.
• General industry air caps and nozzles produce a uniform, high quality spray pattern with low atomizing pressure.
• Precise fluid flow control click knob with true zero set point ensures accurate paint thickness.
• One piece fluid cartridge can be removed and replaced so quickly that it nearly eliminates maintenance related downtime.
• Direct stainless steel fluid path cuts the amount of solvent needed to flush the gun, reducing VOC (volatile organic compound) emissions.

• Application: General
• Applicator Type: Automatic

• Body Material: Metal

• Compatible Material: Adhesives, Ceramics, Fast-Set, High Solids, Sealants, Solvent borne Paints, Stains, UV Coating, Waterborne

• Fluid Adjustment Knob: Clicking
• Fluid Orifice Size (in): 0.042
• Fluid Orifice Size (mm): 1.10

• Gun Model: Stellair
• Gun Series: Automatic
• Gun Type: HVLP Gun
• Gun Weight (g): 430
• Gun Weight (lb): 1

• Manifold Type: Not Included

• Maximum Air Pressure (bar): 7

• Maximum Air Pressure (MPa): 0.7
• Maximum Air Pressure (psi): 100

• Maximum Flow Rate (oz/min): 14

• Maximum Fluid Temperature ( degree C): 49
• Maximum Fluid Temperature ( degree F): 120

• Maximum Fluid Temperature ( degree C): 49
• Maximum Fluid Temperature ( degree F): 120

• Maximum Fluid Working Pressure (bar): 21
• Maximum Fluid Working Pressure (MPa): 2.1
• Maximum Fluid Working Pressure (psi): 300

• Minimum Air Inlet Pressure (bar): 3.4
• Minimum Air Inlet Pressure (MPa): 0.34
• Minimum Air Inlet Pressure (psi): 50

• Needle Tip Material: PEEK
• Nozzle Size (in): 0.042
• Nozzle Size (mm): 1.10

• Overall Height (in): 1.9
• Overall Height (mm): 48.3
• Overall Length (in): 5.9
• Overall Length (mm): 150
• Overall Width (in): 1.63
• Overall Width (mm): 41.4

GG 25F206

GUN, AUTO, HVLP TRIM, .042, ADJ

Graco 25F206 Stellair Automatic Air Spray Gun, HVLP Trim, 0.042 in (1.1 mm) Nozzle for General Applications with fluid control knob

High volume low pressure (HVLP) air spray gun produces stellar results for general industry applications using robots, reciprocators, flat line machines or other automated finishing technologies.

• High volume low pressure (HVLP) air spray produces a controlled, low velocity spray pattern that reduces bounce back and overspray, while meeting environmental regulations.
• Trim air cap produces a well-defined edge with minimal overspray that's required for edges, trim, dielectric coating and other selective applications.
• Precise fluid flow control click knob with true zero set point ensures accurate paint thickness.
• One piece fluid cartridge can be removed and replaced so quickly that it nearly eliminates maintenance related downtime.
• Direct stainless steel fluid path cuts the amount of solvent needed to flush the gun, reducing VOC (volatile organic compound) emissions.

• Application: General
• Applicator Type: Automatic

• Body Material: Metal

• Compatible Material: Dielectrics, Fast-Set, High Solids, Solvent borne Paints, Stains, UV Coating, Waterborne

• Fluid Adjustment Knob: Clicking
• Fluid Orifice Size (in): 0.042
• Fluid Orifice Size (mm): 1.10

• Gun Model: Stellair
• Gun Series: Automatic
• Gun Type: HVLP Gun
• Gun Weight (g): 430
• Gun Weight (lb): 1

• Manifold Type: Not Included

• Maximum Air Pressure (bar): 7

• Maximum Air Pressure (MPa): 0.7
• Maximum Air Pressure (psi): 100

• Maximum Flow Rate (oz/min): 14

• Maximum Fluid Temperature ( degree C): 49
• Maximum Fluid Temperature ( degree F): 120

• Maximum Fluid Temperature ( degree C): 49
• Maximum Fluid Temperature ( degree F): 120

• Maximum Fluid Working Pressure (bar): 21
• Maximum Fluid Working Pressure (MPa): 2.1
• Maximum Fluid Working Pressure (psi): 300

• Minimum Air Inlet Pressure (bar): 3.4
• Minimum Air Inlet Pressure (MPa): 0.34
• Minimum Air Inlet Pressure (psi): 50

• Needle Tip Material: PEEK
• Nozzle Size (in): 0.042
• Nozzle Size (mm): 1.10

• Overall Height (in): 1.9
• Overall Height (mm): 48.3
• Overall Length (in): 5.9
• Overall Length (mm): 150
• Overall Width (in): 1.63
• Overall Width (mm): 41.4

GG 25F209

GG 25F214

GUN, AUTO, HVLP .055, MANIFOLD

Graco 25F214 Stellair Automatic Air Spray Gun, HVLP, 0.055 in (1.4 mm) Nozzle for General Applications with side inlet manifold (imperial)

High volume low pressure (HVLP) air spray gun produces stellar results on an automated paint line or in a robotic spray booth.

• High volume low pressure (HVLP) air spray produces a controlled, low velocity spray pattern that reduces bounce back and overspray, while meeting environmental regulations.
• General industry air caps and nozzles produce a uniform, high quality spray pattern with low atomizing pressure.
• Two-screw manifold to gun connection makes installation easy.
• One piece fluid cartridge can be removed and replaced so quickly that it nearly eliminates maintenance related downtime.
• Direct stainless steel fluid path cuts the amount of solvent needed to flush the gun, reducing VOC (volatile organic compound) emissions.

• Application: General
• Applicator Type: Automatic

• Body Material: Metal

• Compatible Material: Adhesives, Ceramics, Fast-Set, High Solids, Sealants, Solvent borne Paints, Stains, UV Coating, Waterborne

• Fluid Adjustment Knob: N/A
• Fluid Orifice Size (in): 0.055
• Fluid Orifice Size (mm): 1.4

• Gun Model: Stellair
• Gun Series: Automatic
• Gun Type: HVLP Gun
• Gun Weight (g): 430
• Gun Weight (lb): 1

• Manifold Type: Side Inlet

• Maximum Air Pressure (bar): 7

• Maximum Air Pressure (MPa): 0.7
• Maximum Air Pressure (psi): 100

• Maximum Flow Rate (oz/min): 18

• Maximum Fluid Temperature ( degree C): 49
• Maximum Fluid Temperature ( degree F): 120

• Maximum Fluid Temperature ( degree C): 49
• Maximum Fluid Temperature ( degree F): 120

• Maximum Fluid Working Pressure (bar): 21
• Maximum Fluid Working Pressure (MPa): 2.1
• Maximum Fluid Working Pressure (psi): 300

• Minimum Air Inlet Pressure (bar): 3.4
• Minimum Air Inlet Pressure (MPa): 0.34
• Minimum Air Inlet Pressure (psi): 50

• Needle Tip Material: PEEK
• Nozzle Size (in): 0.055
• Nozzle Size (mm): 1.4

• Overall Height (in): 2.95
• Overall Height (mm): 75
• Overall Length (in): 5.10
• Overall Length (mm): 129.5
• Overall Width (in): 3.55
• Overall Width (mm): 90.2

GG 25F233

GG 25F234

GG 25F317

GG 25F344

GG 25M224

LINELAZER SPRAYER, V, 3400

Graco 25M224 LineLazer 3400 Gas Airless Line Striper, 1 Manual Gun

The LineLazer 3400 is the professional choice for dependable, 1-gun striping for small parking lots, mini malls, seal coating contractors, schools and park and recreation departments.

• Updated Frame


  Improved Tracking & Line Quality

  Added stability with newly designed, 3-inch longer frame

  Accepts 15-gallon hopper and EZ Bead System

• Rear Mount Hose Wrap


  Easier Stencil Jobs

  Easy on/off functionality

• Easy-To-Reach Controls


  Fine-tune the striper without stopping

  Operator controls are located on the handlebars

• Electronic Pressure Control


  Improved Line Quality

  Accurate, tight tolerance system

• Endurance Chromex Pump


  Reliable, Long-Life Pump

  Industry-best pump performance - field-proven design

  Handle the most demanding materials with long-life rod treatment

  4X harder than ordinary chrome

• Honda GX Engine


  Reliable, Easy-to-Start Power

  Contractor-preferred - excellent power and proven reliability

  Oil Alert shuts down engine to prevent damage if oil level drops too low

• Easy Out Pump Filter


  Easy Pump Maintenance & Less Clogging

  Inside-out design means less mess with fewer tip clogs

• Front Swivel Wheel


  Easier Maneuverability

  Ability to stripe right up to the curb

  Makes easy work of hard-to-do curves

  Years of dependable operation with tapered locking pin design

• Model: LineLazer
• Series: 3400
• Product Series: Standard

• Attachments: None

• Compatible Material: Road-Marking Paint
• Compatible Surfaces: Pavement, Turf

• Engine Brand: Honda
• Engine Model: GX120

• Fuel Tank Capacity (gal): 0.66
• Fuel Tank Capacity (L): 2.5

• Gun Activation: 1 Manual

• Hopper Volume Capacity (gal): 15
• Hopper Volume Capacity (L): 56.8

• Includes: Flex Plus Gun, LineLazer RAC 5 317 Spray Tip, LineLazer RAC 5 319 Spray Tip, RAC 5 Tip Guard, 1/4 in x 50 ft (15 m) BlueMax II Airless Hose, 1/4 in x 3 ft (0.9 m) BlueMax II Airless Whip Hose, TSL, 4 oz (118 ml)

• Maximum Flow Rate (GPM): 0.75
• Maximum Flow Rate (L/min): 2.8

• Maximum Sound Pressure Level (dB(A)): 91

• Maximum Tip Size (cm): 0.0686
• Maximum Tip Size (in): 0.027
• Maximum Tip Size (mm): 0.6858

• Maximum Working Pressure (bar): 227
• Maximum Working Pressure (kPa): 2270
• Maximum Working Pressure (psi): 3300

• Number of Colors: One Color

• Number of Guns: 1
• Number of Pumps: 1

• Overall Height (cm): 100.0
• Overall Height (in): 39.4
• Overall Height (mm): 1000.76
• Overall Length (cm): 168.4
• Overall Length (in): 66.3
• Overall Length (mm): 1684.02
• Overall Width (cm): 66.0
• Overall Width (in): 26.0
• Overall Width (mm): 660.4

• Power Rating (HP): 4
• Power Rating (kW): 2.98
• Power Rating (W): 2980
• Power Source: Gas

• Pump Type: Endurance

• Recommended Annual Usage: Up to 250 gallons per week

GG 25M323

PULSE PRO METER VALVE, FMS, 1/2 NPT, RIGID, OIL, HF

Graco 25M323 Pulse Metered Dispense Valve for Oil Applications - 1/2 in NPT, Rigid Extension, High Flow Nozzle

Graco dispense meters designed for our Pulse fluid management system are durable and easy to use. Everything you need is at your fingertips. Enter PINs and other data using the intuitive display.

• Track and record inventory levels with electronic metering
• Increase technician productivity
• Flexible - one meter can handle all fluids
• Large, Intuitive Display - high-contrast display for low and bright light conditions
• Protective trigger guard - prevents accidental dispenses
• Four finger trigger with lock-on feature
• No need to leave bay or use computer to complete dispense
• Long battery life - uses 4 AA easy-to-replace batteries

• Model: Pulse

• Display Type: LCD

• Extension Type: Rigid

• Fluid Inlet Thread Gender: Female

• Includes: Extension, Nozzle, Batteries, Swivel Boot
• Inlet Size (cm): 1.27
• Inlet Size (in): 1/2
• Inlet Size (mm): 12.7

• Inlet Thread Type: NPT

• Maximum Flow Rate (GPM): 18

• Maximum Operating Temperature ( degree C): 70
• Maximum Operating Temperature ( degree F): 158

• Maximum Storage Temperature ( degree C): 70
• Maximum Storage Temperature ( degree F): 158

• Maximum Working Pressure (bar): 103.4
• Maximum Working Pressure (kPa): 10340
• Maximum Working Pressure (MPa): 10.3
• Maximum Working Pressure (psi): 1500
• Meter Accuracy (%): plus/minus 00.5
• Meter Technology: Oval Gear

• Metering Gun Weight (kg): 2.4
• Metering Gun Weight (lb): 5.3

• Minimum Flow Rate (GPM): 0.25
• Minimum Flow Rate (L/min): 0.9

• Minimum Operating Temperature ( degree C): -16
• Minimum Operating Temperature ( degree F): 4

• Nozzle Type: High Flow

• Overall Length (cm): 33
• Overall Length (ft): 1
• Overall Length (in): 13
• Overall Length (m): 0.33
• Overall Length (mm): 330
• Overall Width (cm): 9.5
• Overall Width (in): 3.75
• Overall Width (mm): 95

• Product Type: Meter

GG 25M404

SD SERIES SDM8 VALVE, 1/2NPT, RIGID, OIL

Graco 25M404 SDM8 Series Electronic Manual Oil Meter - Rigid Extension - 1/2 in. (13 mm) Inlet

Graco's premium SD meters were designed from the ground up to provide the best user experience. These robust meters feature high flow, improved ergonomics and a large high-contrast LCD screen to make viewing dispense amounts easy in all lighting conditions.

• Large, Intuitive Display - high-contrast display for low and bright light conditions
• Long valve life - cartridge spool valve specifically designed to reduce wear and reduce costly down time
• Ergonomic - four-finger trigger and easy-to-use button pad reduce worker fatigue
• Durable - Thick cast aluminum body allows this meter to endure harsh, heavy-duty applications
• Long battery life - uses 4 AA easy-to-replace batteries

• Model: SDM8

• Compatible Material: Oil, ATF

• Dispense Type: Manual

• Display Type: Electronic

• Extension Type: Rigid

• Fluid Inlet Thread Gender: Female

• Fluid Outlet Thread Gender: Female

• Includes: Nozzle, Rigid Extension
• Inlet Size (cm): 1.27
• Inlet Size (in): 1/2
• Inlet Size (mm): 12.7

• Inlet Thread Type: NPT

• Maximum Flow Rate (GPM): 8
• Maximum Flow Rate (L/min): 30

• Maximum Operating Temperature ( degree C): 70
• Maximum Operating Temperature ( degree F): 158

• Maximum Recorded Dispense: 9999

• Maximum Storage Temperature ( degree C): 70
• Maximum Storage Temperature ( degree F): 158

• Maximum Working Pressure (bar): 103.4
• Maximum Working Pressure (kPa): 10340
• Maximum Working Pressure (MPa): 10.3
• Maximum Working Pressure (psi): 1500
• Meter Accuracy (%): plus/minus 00.5
• Meter Technology: Oval Gear

• Metering Gun Weight (kg): 2.4
• Metering Gun Weight (lb): 5.3

• Minimum Flow Rate (GPM): 0.25
• Minimum Flow Rate (L/min): 0.9

• Minimum Operating Temperature ( degree C): -16
• Minimum Operating Temperature ( degree F): 4

• Nozzle Type: Oil Automatic Quick-Close

• Outlet Thread Type: Straight Thread O-Ring Boss

• Overall Height (cm): 14.6
• Overall Height (in): 5.75
• Overall Height (mm): 146
• Overall Length (cm): 33
• Overall Length (in): 13
• Overall Length (mm): 330
• Overall Width (cm): 9.5
• Overall Width (in): 3.75
• Overall Width (mm): 95

• Recommended Environment: Indoor

GG 25M405

SD SERIES SDM8 VALVE, 1/2NPT, RIGID, AF

Graco 25M405 SDM8 Series Electronic Manual Antifreeze Meter - Rigid Extension - 1/2 in. (13 mm) Inlet

Graco's premium SD meters were designed from the ground up to provide the best user experience. These robust meters feature high flow, improved ergonomics and a large high-contrast LCD screen to make viewing dispense amounts easy in all lighting conditions.

• Large, Intuitive Display - high-contrast display for low and bright light conditions
• Long valve life - cartridge spool valve specifically designed to reduce wear and reduce costly down time
• Ergonomic - four-finger trigger and easy-to-use button pad reduce worker fatigue
• Durable - Thick cast aluminum body allows this meter to endure harsh, heavy-duty applications
• Long battery life - uses 4 AA easy-to-replace batteries

• Model: SDM8

• Compatible Material: Oil, Antifreeze, ATF, Gear Oil

• Dispense Type: Manual

• Display Type: Electronic

• Extension Type: Rigid

• Fluid Inlet Thread Gender: Female

• Fluid Outlet Thread Gender: Female

• Includes: Nozzle, Rigid Extension
• Inlet Size (cm): 1.27
• Inlet Size (in): 1/2
• Inlet Size (mm): 12.7

• Inlet Thread Type: NPT

• Maximum Flow Rate (GPM): 8
• Maximum Flow Rate (L/min): 30

• Maximum Operating Temperature ( degree C): 70
• Maximum Operating Temperature ( degree F): 158

• Maximum Recorded Dispense: 9999

• Maximum Storage Temperature ( degree C): 70
• Maximum Storage Temperature ( degree F): 158

• Maximum Working Pressure (bar): 103.4
• Maximum Working Pressure (kPa): 10340
• Maximum Working Pressure (MPa): 10.3
• Maximum Working Pressure (psi): 1500
• Meter Accuracy (%): plus/minus 00.5
• Meter Technology: Oval Gear

• Metering Gun Weight (kg): 2.4
• Metering Gun Weight (lb): 5.3

• Minimum Flow Rate (GPM): 0.25
• Minimum Flow Rate (L/min): 0.9

• Minimum Operating Temperature ( degree C): -16
• Minimum Operating Temperature ( degree F): 4

• Nozzle Type: Manual

• Outlet Thread Type: Straight Thread O-Ring Boss

• Overall Height (cm): 14.6
• Overall Height (in): 5.75
• Overall Height (mm): 146
• Overall Length (cm): 33
• Overall Length (in): 13
• Overall Length (mm): 330
• Overall Width (cm): 9.5
• Overall Width (in): 3.75
• Overall Width (mm): 95

• Recommended Environment: Indoor

GG 25M406

SD SERIES SDM8 VALVE, 1/2NPT, FLEX, OIL

Graco 25M406 SDM8 Series Electronic Manual Oil Meter - Flexible Extension - 1/2 in. (13 mm) Inlet

Graco's premium SD meters were designed from the ground up to provide the best user experience. These robust meters feature high flow, improved ergonomics and a large high-contrast LCD screen to make viewing dispense amounts easy in all lighting conditions.

• Large, Intuitive Display - high-contrast display for low and bright light conditions
• Long valve life - cartridge spool valve specifically designed to reduce wear and reduce costly down time
• Ergonomic - four-finger trigger and easy-to-use button pad reduce worker fatigue
• Durable - Thick cast aluminum body allows this meter to endure harsh, heavy-duty applications
• Long battery life - uses 4 AA easy-to-replace batteries

• Model: SDM8

• Compatible Material: Oil, ATF

• Dispense Type: Manual

• Display Type: Electronic

• Extension Type: Flexible

• Fluid Inlet Thread Gender: Female

• Fluid Outlet Thread Gender: Female

• Includes: Nozzle, Flexible Extension
• Inlet Size (cm): 1.27
• Inlet Size (in): 1/2
• Inlet Size (mm): 12.7

• Inlet Thread Type: NPT

• Maximum Flow Rate (GPM): 8
• Maximum Flow Rate (L/min): 30

• Maximum Operating Temperature ( degree C): 70
• Maximum Operating Temperature ( degree F): 158

• Maximum Recorded Dispense: 9999

• Maximum Storage Temperature ( degree C): 70
• Maximum Storage Temperature ( degree F): 158

• Maximum Working Pressure (bar): 103.4
• Maximum Working Pressure (kPa): 10340
• Maximum Working Pressure (MPa): 10.3
• Maximum Working Pressure (psi): 1500
• Meter Accuracy (%): plus/minus 00.5
• Meter Technology: Oval Gear

• Metering Gun Weight (kg): 2.4
• Metering Gun Weight (lb): 5.3

• Minimum Flow Rate (GPM): 0.25
• Minimum Flow Rate (L/min): 0.9

• Minimum Operating Temperature ( degree C): -16
• Minimum Operating Temperature ( degree F): 4

• Nozzle Type: Oil Automatic Quick-Close

• Outlet Thread Type: Straight Thread O-Ring Boss

• Overall Height (cm): 14.6
• Overall Height (in): 5.75
• Overall Height (mm): 146
• Overall Length (cm): 33
• Overall Length (in): 13
• Overall Length (mm): 330
• Overall Width (cm): 9.5
• Overall Width (in): 3.75
• Overall Width (mm): 95

• Recommended Environment: Indoor

GG 25M410

SD SERIES SDM18 VALVE, 1/2NPT, RIGD, OIL, HF

Graco 25M410 SDM18 Series Electronic Manual Oil/Antifreeze Meter - Rigid Extension - 1/2 in. (13 mm) Inlet

Graco's premium SD meters were designed from the ground up to provide the best user experience. These robust meters feature high flow, improved ergonomics and a large high-contrast LCD screen to make viewing dispense amounts easy in all lighting conditions.

• Large, Intuitive Display - high-contrast display for low and bright light conditions
• Long valve life - cartridge spool valve specifically designed to reduce wear and reduce costly down time
• Ergonomic - four-finger trigger and easy-to-use button pad reduce worker fatigue
• Durable - Thick cast aluminum body allows this meter to endure harsh, heavy-duty applications
• Long battery life - uses 4 AA easy-to-replace batteries

• Model: SDM18

• Compatible Material: Oil, Antifreeze, ATF, Gear Oil

• Dispense Type: Manual

• Display Type: Electronic

• Extension Type: Rigid

• Fluid Inlet Thread Gender: Female

• Fluid Outlet Thread Gender: Female

• Includes: Nozzle, Rigid Extension
• Inlet Size (cm): 1.27
• Inlet Size (in): 1/2
• Inlet Size (mm): 12.7

• Inlet Thread Type: NPT

• Maximum Flow Rate (GPM): 18
• Maximum Flow Rate (L/min): 68

• Maximum Operating Temperature ( degree C): 70
• Maximum Operating Temperature ( degree F): 158

• Maximum Recorded Dispense: 9999

• Maximum Storage Temperature ( degree C): 70
• Maximum Storage Temperature ( degree F): 158

• Maximum Working Pressure (bar): 103.4
• Maximum Working Pressure (kPa): 10340
• Maximum Working Pressure (MPa): 10.3
• Maximum Working Pressure (psi): 1500
• Meter Accuracy (%): plus/minus 00.5
• Meter Technology: Oval Gear

• Metering Gun Weight (kg): 2.4
• Metering Gun Weight (lb): 5.3

• Minimum Flow Rate (GPM): 0.25
• Minimum Flow Rate (L/min): 0.9

• Minimum Operating Temperature ( degree C): -16
• Minimum Operating Temperature ( degree F): 4

• Nozzle Type: Manual

• Outlet Thread Type: Straight Thread O-Ring Boss

• Overall Height (cm): 14.6
• Overall Height (in): 5.75
• Overall Height (mm): 146
• Overall Length (cm): 33
• Overall Length (in): 13
• Overall Length (mm): 330
• Overall Width (cm): 9.5
• Overall Width (in): 3.75
• Overall Width (mm): 95

• Recommended Environment: Indoor

GG 25M413

SD SERIES SDM8 VALVE, 1/2NPT, GL

Graco 25M413 SDM8 Series Electronic Manual Gear Lube Meter - Rigid Extension - 1/2 in. (13 mm) Inlet

Graco's premium SD meters were designed from the ground up to provide the best user experience. These robust meters feature high flow, improved ergonomics and a large high-contrast LCD screen to make viewing dispense amounts easy in all lighting conditions.

• Large, Intuitive Display - high-contrast display for low and bright light conditions
• Long valve life - cartridge spool valve specifically designed to reduce wear and reduce costly down time
• Ergonomic - four-finger trigger and easy-to-use button pad reduce worker fatigue
• Durable - Thick cast aluminum body allows this meter to endure harsh, heavy-duty applications
• Long battery life - uses 4 AA easy-to-replace batteries

• Model: SDM8

• Compatible Material: Gear Oil, Oil, ATF

• Dispense Type: Manual

• Display Type: Electronic

• Extension Type: Rigid

• Fluid Inlet Thread Gender: Female

• Fluid Outlet Thread Gender: Female

• Includes: Nozzle, Gear Lube Extension
• Inlet Size (cm): 1.27
• Inlet Size (in): 1/2
• Inlet Size (mm): 12.7

• Inlet Thread Type: NPT

• Maximum Flow Rate (GPM): 8
• Maximum Flow Rate (L/min): 30

• Maximum Operating Temperature ( degree C): 70
• Maximum Operating Temperature ( degree F): 158

• Maximum Recorded Dispense: 9999

• Maximum Storage Temperature ( degree C): 70
• Maximum Storage Temperature ( degree F): 158

• Maximum Working Pressure (bar): 103.4
• Maximum Working Pressure (kPa): 10340
• Maximum Working Pressure (MPa): 10.3
• Maximum Working Pressure (psi): 1500
• Meter Accuracy (%): plus/minus 00.5
• Meter Technology: Oval Gear

• Metering Gun Weight (kg): 2.4
• Metering Gun Weight (lb): 5.3

• Minimum Flow Rate (GPM): 0.25
• Minimum Flow Rate (L/min): 0.9

• Minimum Operating Temperature ( degree C): -16
• Minimum Operating Temperature ( degree F): 4

• Nozzle Type: Manual

• Outlet Thread Type: Straight Thread O-Ring Boss

• Overall Height (cm): 14.6
• Overall Height (in): 5.75
• Overall Height (mm): 146
• Overall Length (cm): 33
• Overall Length (in): 13
• Overall Length (mm): 330
• Overall Width (cm): 9.5
• Overall Width (in): 3.75
• Overall Width (mm): 95

• Recommended Environment: Indoor

GG 25M415

SD SERIES SDM8 VALVE, 1/2NPT, WWS

Graco 25M415 SDM8 Metered Dispense Valve for Windshield Wash Applications - 1/2 in NPT, Rigid Open Extension

Graco's premium SD meters were designed from the ground up to provide the best user experience. These robust meters feature high flow, improved ergonomics and a large high-contrast LCD screen to make viewing dispense amounts easy in all lighting conditions.

• Large, Intuitive Display - high-contrast display for low and bright light conditions
• Long valve life - cartridge spool valve specifically designed to reduce wear and reduce costly down time
• Ergonomic - four-finger trigger and easy-to-use button pad reduce worker fatigue
• Durable - Thick cast aluminum body allows this meter to endure harsh, heavy-duty applications
• Long battery life - uses 4 AA easy-to-replace batteries

• Model: SDM8

• Compatible Material: Windshield Washer Fluid

• Dispense Type: Manual

• Display Type: Electronic

• Extension Type: Rigid

• Fluid Inlet Thread Gender: Female

• Fluid Outlet Thread Gender: Female

• Includes: WWS Extension
• Inlet Size (cm): 1.27
• Inlet Size (in): 1/2
• Inlet Size (mm): 12.7

• Inlet Thread Type: NPT

• Maximum Flow Rate (GPM): 8
• Maximum Flow Rate (L/min): 30

• Maximum Operating Temperature ( degree C): 70
• Maximum Operating Temperature ( degree F): 158

• Maximum Recorded Dispense: 9999

• Maximum Storage Temperature ( degree C): 70
• Maximum Storage Temperature ( degree F): 158

• Maximum Working Pressure (bar): 103.4
• Maximum Working Pressure (kPa): 10340
• Maximum Working Pressure (MPa): 10.3
• Maximum Working Pressure (psi): 1500
• Meter Accuracy (%): plus/minus 00.5
• Meter Technology: Oval Gear

• Metering Gun Weight (kg): 2.4
• Metering Gun Weight (lb): 5.3

• Minimum Flow Rate (GPM): 0.25
• Minimum Flow Rate (L/min): 0.9

• Minimum Operating Temperature ( degree C): -16
• Minimum Operating Temperature ( degree F): 4

• Nozzle Type: Rigid

• Outlet Thread Type: Straight Thread O-Ring Boss

• Overall Height (cm): 14.6
• Overall Height (in): 5.75
• Overall Height (mm): 146
• Overall Length (cm): 33
• Overall Length (in): 13
• Overall Length (mm): 330
• Overall Width (cm): 9.5
• Overall Width (in): 3.75
• Overall Width (mm): 95

• Recommended Environment: Indoor

GG 25M416

SD SERIES SDM18 VALVE, 3/4NPT, RIGD, OIL, HF

Graco 25M416 SDM18 Series Electronic Manual Oil/Antifreeze Meter - Rigid Extension - 3/4 in. Inlet

Graco's premium SD meters were designed from the ground up to provide the best user experience. These robust meters feature high flow, improved ergonomics and a large high-contrast LCD screen to make viewing dispense amounts easy in all lighting conditions.

• Large, Intuitive Display - high-contrast display for low and bright light conditions
• Long valve life - cartridge spool valve specifically designed to reduce wear and reduce costly down time
• Ergonomic - four-finger trigger and easy-to-use button pad reduce worker fatigue
• Durable - Thick cast aluminum body allows this meter to endure harsh, heavy-duty applications
• Long battery life - uses 4 AA easy-to-replace batteries

• Model: SDM18

• Compatible Material: Oil, Antifreeze, ATF, Gear Oil

• Dispense Type: Manual

• Display Type: Electronic

• Extension Type: Rigid

• Fluid Inlet Thread Gender: Female

• Fluid Outlet Thread Gender: Female

• Includes: Nozzle, Rigid Extension
• Inlet Size (cm): 1.905
• Inlet Size (in): 3/4
• Inlet Size (mm): 19.05

• Inlet Thread Type: NPT

• Maximum Flow Rate (GPM): 18
• Maximum Flow Rate (L/min): 68

• Maximum Operating Temperature ( degree C): 70
• Maximum Operating Temperature ( degree F): 158

• Maximum Recorded Dispense: 9999

• Maximum Storage Temperature ( degree C): 70
• Maximum Storage Temperature ( degree F): 158

• Maximum Working Pressure (bar): 103.4
• Maximum Working Pressure (kPa): 10340
• Maximum Working Pressure (MPa): 10.3
• Maximum Working Pressure (psi): 1500
• Meter Accuracy (%): plus/minus 00.5
• Meter Technology: Oval Gear

• Metering Gun Weight (kg): 2.4
• Metering Gun Weight (lb): 5.3

• Minimum Flow Rate (GPM): 0.25
• Minimum Flow Rate (L/min): 0.9

• Minimum Operating Temperature ( degree C): -16
• Minimum Operating Temperature ( degree F): 4

• Nozzle Type: Manual

• Outlet Thread Type: Straight Thread O-Ring Boss

• Overall Height (cm): 14.6
• Overall Height (in): 5.75
• Overall Height (mm): 146
• Overall Length (cm): 33
• Overall Length (in): 13
• Overall Length (mm): 330
• Overall Width (cm): 9.5
• Overall Width (in): 3.75
• Overall Width (mm): 95

• Recommended Environment: Indoor

GG 25M417

SD SERIES SDM18 VALVE, 3/4NPT, FLEX, OIL, HF

Graco 25M417 SDM18 Series Electronic Manual Oil/Antifreeze Meter - Flexible Extension - 3/4 in. Inlet

Graco's premium SD meters were designed from the ground up to provide the best user experience. These robust meters feature high flow, improved ergonomics and a large high-contrast LCD screen to make viewing dispense amounts easy in all lighting conditions.

• Large, Intuitive Display - high-contrast display for low and bright light conditions
• Long valve life - cartridge spool valve specifically designed to reduce wear and reduce costly down time
• Ergonomic - four-finger trigger and easy-to-use button pad reduce worker fatigue
• Durable - Thick cast aluminum body allows this meter to endure harsh, heavy-duty applications
• Long battery life - uses 4 AA easy-to-replace batteries

• Model: SDM18

• Compatible Material: Oil, Antifreeze, ATF, Gear Oil

• Dispense Type: Manual

• Display Type: Electronic

• Extension Type: Flexible

• Fluid Inlet Thread Gender: Female

• Fluid Outlet Thread Gender: Female

• Includes: Nozzle, Flexible Extension
• Inlet Size (cm): 1.905
• Inlet Size (in): 3/4
• Inlet Size (mm): 19.05

• Inlet Thread Type: NPT

• Maximum Flow Rate (GPM): 18
• Maximum Flow Rate (L/min): 68

• Maximum Operating Temperature ( degree C): 70
• Maximum Operating Temperature ( degree F): 158

• Maximum Recorded Dispense: 9999

• Maximum Storage Temperature ( degree C): 70
• Maximum Storage Temperature ( degree F): 158

• Maximum Working Pressure (bar): 103.4
• Maximum Working Pressure (kPa): 10340
• Maximum Working Pressure (MPa): 10.3
• Maximum Working Pressure (psi): 1500
• Meter Accuracy (%): plus/minus 00.5
• Meter Technology: Oval Gear
