GG 24J394
GBL 7500 PUMP, GRAVITY, 3/16
Graco 24J394 Manzel® GBL 7500 Replacement Pump, Gravity Fed, 3/16 in (4.8 mm)
The Graco Manzel GBL 7500 Gravity pump is engineered for long-life and maximum flexibility for easy system integration. It has been improved to perform in best-practice applications for a durable solution that is hard to beat.
Application: For force-feed oil lubrication systems
- Mechanically driven from camshaft in reservoir.
- Adjustable from 1 to 27 drops per stroke and develop pressures up to 7,500 psi (517 bar).
- Rugged construction for high quality performance and durability with easy to adjust pump output.
- Double Ball Outlet Check reduces ball travel.
- Improved O-ring seals to eliminate leak paths.
- Patent pending Built-in-Socket spreads force evenly over piston tip to avoid bending and wear for long piston and rocker life.
- Ball bearing roller has superior rotation to help protect camshaft from damage. Larger diameter roller spreads load pressure to reduce wear and improve pump life.
- Model: Manzel
- Series: GBL 7500
- Application: In-Plant Machinery, Compressor Equipment
- Maximum Cycle Rate (CPM): 50
- Maximum Output Volume (in³): 0.014
- Maximum Working Pressure (bar): 517
- Maximum Working Pressure (kPa): 51700
- Maximum Working Pressure (MPa): 51.7
- Maximum Working Pressure (psi): 7500
