GRACO INC. S10595
SS Piston, 4:1 Glutton Pump
GG 189432
PISTON, PUMP
Graco 189432 Air Powered Glutton Pump Piston, Pump, 17-4 PH stainless stell, hard chrome (4:1)
Cylinder, Pump
GG 189437
CYLINDER, PUMP
Graco 189437 Stainless Steel Pump Cylinder for Check-Mate 800 Displacement Pump
Cable, M8, 4Pin, M/F, 16M
GG 17H352
CABLE, M8, 4PIN, M/F, 16M
Graco 17H352 Leak Sensor Connection Cable for BLDC Pumps (52.5ft / 16meter)
Linelazer Sprayer, V, 130Hs, Standard 1 Gun
GG 17H447
LINELAZER SPRAYER, V, 130HS, STANDARD 1 GUN
Graco 17H447 LineLazer 130HS Standard Series Gas Hydraulic Airless Line Striper, 1 Manual Gun
The LineLazer 130HS is the preferred hydraulic airless striping unit that consistently delivers everyday striping performance with proven power, day in and day out.
- EasyMark Gun Adjustment System
Easy Gun Adjustments
Perfect gun alignment every time with easy-to-use guide mark system
2-gun capability with QuikSelect gun selector
- EZ Align Wheel System
Perfect Striper Tracking
Simple front wheel alignment, no special tools needed
- DualComfort Handlebar System
Easy Handlebar Adjustment
- Honda GX Engine
Reliable, Easy-to-Start Power
Contractor-preferred - excellent power and proven reliability
Oil Alert shuts down engine to prevent damage if oil level drops too low
- Endurance Chromex Pump
Reliable, Long-Life Pump
Industry-best pump performance - field-proven design
Handle the most demanding materials with long-life rod treatment
4X harder than ordinary chrome
- High-Efficiency Hydraulic Motor
Uninterrupted Performance
No-Stall design
- High-Capacity Cooling System
Reduced Downtime
Innovative design allows the pump to run cooler and more efficiently
Easier and more thorough fluid changes
Reservoir cooling fins deflect more heat
No special hydraulic fluid needed
- Easy Out Pump Filter
Easy Pump Maintenance & Less Clogging
Inside-out design means less mess with fewer tip clogs
- Storage Compartment
New compartment for tips, guards and miscellaneous items
- Model: LineLazer
- Series: 130HS
- Product Series: Standard
- Compatible Material: Road-Marking Paint
- Compatible Surfaces: Pavement, Turf
- Engine Brand: Honda
- Engine Model: GX120
- Fuel Tank Capacity (gal): 0.66
- Fuel Tank Capacity (L): 2.5
- Gun Activation: Manual
- Includes: Tips, Guard, Gun, Hose, Pump Filter, TSL
- Maximum Flow Rate (GPM): 1.3
- Maximum Flow Rate (L/min): 4.9
- Maximum Sound Pressure Level (dB(A)): 96
- Maximum Tip Size (cm): 0.0940
- Maximum Tip Size (in): 0.037
- Maximum Tip Size (mm): 0.9398
- Maximum Working Pressure (bar): 227
- Maximum Working Pressure (kPa): 2270
- Maximum Working Pressure (psi): 3300
- Number of Colors: One Color
- Number of Guns: 1
- Number of Hoppers: 1
- Number of Pumps: 1
- Overall Height (cm): 113.03
- Overall Height (in): 44.5
- Overall Height (mm): 1130.3
- Overall Length (cm): 173.36
- Overall Length (in): 68.25
- Overall Length (mm): 1733.55
- Overall Width (cm): 87.0
- Overall Width (in): 34.25
- Overall Width (mm): 870
- Power Rating (HP): 4
- Power Rating (kW): 2.98
- Power Source: Gas Hydraulic
- Pump Type: Endurance
Linelazer Sprayer, V, 3900, Auto, 1A 1M, Lsr
GG 17H452
LINELAZER SPRAYER, V, 3900, AUTO, 1A 1M, LSR
Graco 17H452 LineLazer V 3900 HP Automatic Series Gas Airless Line Striper, 1 Auto Gun, 1 Manual Gun
For those advanced striping jobs that require layout work or skip lines, the LineLazer V 3900 HP Automatic Series line striper includes additional features to help you work smarter, finish jobs faster and increase your profitability.
Application: The HP Automatic Series adds enhanced features that provide contractors automatic line production capability, including skip-lines, as well as real-time job performance data for proof-of-job requirements.- Automatic Paint Gun System
Automatically Stripe Skip-Lines
Reduce operator fatigue - push button line production
Quality solenoid driven system
- Auto-Layout II
Simplify Parking Lot Layout
SmartControl measures while you walk and puts down pre-marks
No need for measuring tape, string lines or aerosol cans
Cuts your layout time in half
- LiveLook Display with SmartControl
Striping Information At-A-Glance
Track, measure and control every aspect of your job
Accessible proof-of-job data from the J-Log System with USB Download
Consistent spraying pressure for perfect lines
- Honda GX Engine
Reliable, Easy-to-Start Power
Contractor-preferred - excellent power and proven reliability
Oil Alert shuts down engine to prevent damage if oil level drops too low
- EasyMark Gun Adjustment System
Easy Gun Adjustments
Perfect gun alignment every time with easy-to-use guide mark system
2-gun capability with QuikSelect gun selector
- EZ Align Wheel System
Perfect Striper Tracking
Simple front wheel alignment, no special tools needed
- DualComfort Handlebar System
Easy Handlebar Adjustment
- Endurance Chromex Pump
Reliable, Long-Life Pump
Industry-best pump performance - field-proven design
Handle the most demanding materials with long-life rod treatment
4X harder than ordinary chrome
- Additional Features
QuikSelect Gun Selector
Easy Out Pump Filter
LazerGuide 1700 Start/Stop Laser
- Model: LineLazer V
- Series: 3900
- Product Series: HP Automatic
- Attachments: LazerGuide 1700
- Bead System: Optional
- Compatible Material: Road-Marking Paint
- Compatible Surfaces: Pavement, Turf
- Engine Brand: Honda
- Engine Model: GX120
- Features: Auto-Layout II, Automatic Gun, J-Log Data Loggin System, On-Board Power
- Fuel Tank Capacity (gal): 0.66
- Fuel Tank Capacity (L): 2.5
- Gun Activation: 1 Automatic & 1 Manual
- Includes: LazerGuide 1700, Flex Plus Gun (2), LineLazer RAC 5 319 Spray Tip (2), LineLazer RAC 5 421 Spray Tip (2), RAC 5 Tip Guard (2), 3/8 in x 50 ft BlueMax II Airless Hose, 3/8 in x 3 ft BlueMax II Airless Whip Hose, TSL, 4 oz
- Maximum Flow Rate (GPM): 1.25
- Maximum Flow Rate (L/min): 4.73
- Maximum Sound Pressure Level (dB(A)): 86.5
- Maximum Tip Size (cm): 0.0635
- Maximum Tip Size (in): 0.025
- Maximum Tip Size (mm): 0.635
- Maximum Working Pressure (bar): 227
- Maximum Working Pressure (kPa): 2270
- Maximum Working Pressure (psi): 3300
- Number of Colors: One Color <
Cable, M8, 4Pin, Female, 7.5M
GG 17H390
CABLE, M8, 4PIN, FEMALE, 7.5M
Graco 17H390 Leak Sensor Connection Cable for AC Pumps (24.6ft / 7.5meter)
Cable, M12, 5 Pin, Rev Key, M/F, 16M
GG 17H364
Cable, M12, 5 Pin, Rev Key, M/F, 16M
Linelazer Sprayer, V, 250Sps, 2 Gun
GG 17H467
LINELAZER SPRAYER, LL V, 250SPS, 2 GUN
Graco 17H467 LineLazer V 250SPS HP Automatic Series Self-Propelled Gas Hydraulic Airless Line Striper, 2 Auto Guns
With exclusive automatic paint guns and hydraulic power, the LineLazer V 250SPS HP Automatic Series is a self-propelled system that is ideal for large, heavy-duty line striping jobs including parking lots and road jobs.
Application: The HP Automatic Series adds enhanced features that provide contractors automatic line production capability, including skip-lines, as well as real-time job performance data for proof-of-job requirements.- Automatic Paint Gun System
Automatically Stripe Skip-Lines
Reduce operator fatigue - push button line production
Quality solenoid driven system
- Remote Mount Control Box
Striping Information At-A-Glance
Simple to use and easy to see in all conditions
- 25-Gallon Paint Hopper
Less Refilling
Extended striping time with large capacity hopper
- Electric Start
Fast starting
- EasyMark Gun Adjustment System
Easy Gun Adjustments
Perfect gun alignment every time with easy-to-use guide mark system
2-gun capability with QuikSelect gun selector
- Front or Rear Gun Mount
Straighter long lines
Use up to six guns
- Self-Centering Front Wheel
Simple operation
Foam-filled, three-wheel design for stability
- Easy Handlebar Adjustment
- Additional Features
Endurance Chromex Pump
High-Efficiency Hydraulic Motor
High-Capacity Cooling System
Easy Out Pump Filter
Flex Plus Guns
- Model: LineLazer V
- Series: 250SPS
- Product Series: HP Automatic
- Attachments: None
- Compatible Material: Road-Marking Paint
- Compatible Surfaces: Pavement, Turf
- Engine Brand: Honda
- Engine Model: GX390
- Fuel Tank Capacity (gal): 1.4
- Fuel Tank Capacity (L): 5.3
- Gun Activation: 2 Automatic
- Hopper Volume Capacity (gal): 25
- Hopper Volume Capacity (L): 95
- Includes: Flex Plus Gun (2), LineLazer RAC 5 321 Spray Tip (2), LineLazer RAC 5 425 Spray Tip (2), LineLazer RAC 5 627 Spray Tip (2), RAC 5 Tip Guard (2), 3/8 in x 12 ft (3.7 m) BlueMax II Airless Hose, 3/8 in x 3 ft (0.9 m) BlueMax II Airless Whip Hose, TSL 4 oz (118 mL)
- Maximum Flow Rate (GPM): 2.5
- Maximum Flow Rate (L/min): 9.5
- Maximum Operating Speed (km/h): 16.1
- Maximum Operating Speed (mph): 10
- Maximum Sound Pressure Level (dB(A)): 89.1
- Maximum Speed (RPM): 3600
- Maximum Tip Size (cm): 0.0991
- Maximum Tip Size (in): 0.039
- Maximum Tip Size (mm): 0.9906
- Maximum Working Pressure (bar): 227
- Maximum Working Pressure (kPa): 2270
- Maximum Working Pressure (psi): 3300
- Number of Colors: One Color
- Number of Guns: 2
- Number of Hoppers: 1
- Number of Pumps: 1
- Overall Height (cm): 128.3
- Overall Height (in): 50.5
- Overall Height (mm): 1282.7
- Overall Length (cm): 186.7
- Overall Length (in): 73.5
- Overall Length (mm): 1866.9
- Overall Width (cm): 83.8
- Overall Width (in): 33
- Overall
Linelazer Sprayer, V5900HP, Automatic Series
GG 17H457
LINELAZER SPRAYER, V, 5900, AUTO, 1A 1M, LSR
Graco 17H457 LineLazer V 5900 HP Automatic Series Gas Airless Line Striper, 1 Auto Gun, 1 Manual Gun
When it's time for 1 or 2-gun airless line striping performance with extra power, the LineLazer V 5900 HP Automatic Series striper is an excellent choice. These durable striping machines deliver higher performance and consistent lines for all your basic striping needs.
Application: The HP Automatic Series adds enhanced features that provide contractors automatic line production capability, including skip-lines, as well as real-time job performance data for proof-of-job requirements.- Automatic Paint Gun System
Automatically Stripe Skip-Lines
Reduce operator fatigue - push button line production
Quality solenoid driven system
- Auto-Layout II
Simplify Parking Lot Layout
SmartControl measures while you walk and puts down pre-marks
No need for measuring tape, string lines or aerosol cans
Cuts your layout time in half
- LiveLook Display with SmartControl
Striping Information At-A-Glance
Track, measure and control every aspect of your job
Accessible proof-of-job data from the J-Log System with USB Download
Consistent spraying pressure for perfect lines
- Honda GX Engine
Reliable, Easy-to-Start Power
Contractor-preferred - excellent power and proven reliability
Oil Alert shuts down engine to prevent damage if oil level drops too low
- EasyMark Gun Adjustment System
Easy Gun Adjustments
Perfect gun alignment every time with easy-to-use guide mark system
2-gun capability with QuikSelect gun selector
- EZ Align Wheel System
Perfect Striper Tracking
Simple front wheel alignment, no special tools needed
- DualComfort Handlebar System
Easy Handlebar Adjustment
- Endurance Chromex Pump
Reliable, Long-Life Pump
Industry-best pump performance - field-proven design
Handle the most demanding materials with long-life rod treatment
4X harder than ordinary chrome
- Additional Features
QuikSelect Gun Selector
Easy Out Pump Filter
LazerGuide 1700 Start/Stop Laser
- Model: LineLazer V
- Series: 5900
- Product Series: HP Automatic
- Attachments: LazerGuide 1700
- Bead System: Optional
- Compatible Material: Road-Marking Paint
- Compatible Surfaces: Pavement, Turf
- Engine Brand: Honda
- Engine Model: GX160
- Fuel Tank Capacity (gal): 0.95
- Fuel Tank Capacity (L): 3.6
- Gun Activation: 1 Automatic & 1 Manual
- Includes: LazerGuide 1700, Flex Plus Gun (2), LineLazer RAC 5 319 Spray Tip (2), LineLazer RAC 5 421 Spray Tip (2), RAC 5 Tip Guard (2), 3/8 in x 50 ft BlueMax II Airless Hose, 3/8 in x 3 ft BlueMax II Airless Whip Hose, TSL, 4 oz
- Maximum Flow Rate (GPM): 1.6
- Maximum Flow Rate (L/min): 6.06
- Maximum Sound Pressure Level (dB(A)): 87.1
- Maximum Tip Size (cm): 0.1092
- Maximum Tip Size (in): 0.043
- Maximum Tip Size (mm): 1.092
- Maximum Working Pressure (bar): 227
- Maximum Working Pressure (kPa): 2270
- Maximum Working Pressure (psi): 3300
- Number of Colors: One Color
- Number of Guns: 2
- Number of Pumps: 1<
LineLazer V 200HS HP Automatic Series Gas Hydraulic Airless Line Striper, 1 Auto Gun, 1 Manual Gun
GG 17H463
LINELAZER SPRAYER, V, 200HS, AUTO, 1A 1M, LSR
Graco 17H463 LineLazer V 200HS HP Automatic Series Gas Hydraulic Airless Line Striper, 1 Auto Gun, 1 Manual Gun
With high production features, the LineLazer V 200HS HP Automatic Series is a true workhorse designed for high performance striping on the most demanding jobs like large parking lots, airports, and city jobs that require precise lines.
Application: The HP Automatic Series adds enhanced features that provide contractors automatic line production capability, including skip-lines, as well as real-time job performance data for proof-of-job requirements.- Automatic Paint Gun System
- Automatically Stripe Skip-Lines
- Reduce operator fatigue - push button line production
- Quality solenoid driven system
- Auto-Layout II
- Simplify Parking Lot Layout
- SmartControl measures while you walk and puts down pre-marks
- No need for measuring tape, string lines or aerosol cans
- Cuts your layout time in half
- LiveLook Display with SmartControl
- Striping Information At-A-Glance
- Track, measure and control every aspect of your job
- Accessible proof-of-job data from the J-Log System with USB Download
- Consistent spraying pressure for perfect lines
- Honda GX Engine
- Reliable, Easy-to-Start Power
- Contractor-preferred - excellent power and proven reliability
- Oil Alert shuts down engine to prevent damage if oil level drops too low
- EasyMark Gun Adjustment System
- Easy Gun Adjustments
- Perfect gun alignment every time with easy-to-use guide mark system
- 2-gun capability with QuikSelect gun selector
- EZ Align Wheel System
- Perfect Striper Tracking
- Simple front wheel alignment, no special tools needed
- DualComfort Handlebar System
- Easy Handlebar Adjustment
- Endurance Chromex Pump
- Reliable, Long-Life Pump
- Industry-best pump performance - field-proven design
- Handle the most demanding materials with long-life rod treatment
- 4X harder than ordinary chrome
- Additional Features
- High-Efficiency Hydraulic Motor
- High-Capacity Cooling System
- QuikSelect Gun Selector
- Easy Out Pump Filter
- LazerGuide 1700 Start/Stop Laser
- Model: LineLazer V
- Series: 200HS
- Product Series: HP Automatic
- Attachments: LazerGuide 1700
- Bead System: Optional
- Compatible Material: Road-Marking Paint
- Compatible Surfaces: Pavement, Turf
- Engine Brand: Honda
- Engine Model: GX200
- Fuel Tank Capacity (gal): 0.95
- Fuel Tank Capacity (L): 3.6
- Gun Activation: 1 Automatic & 1 Manual
- Includes: LazerGuide 1700, Flex Plus Gun (2), LineLazer RAC 5 319 Spray Tip (2), LineLazer RAC 5 421 Spray Tip (2), RAC 5 Tip Guard (2), 3/8 in x 22 ft BlueMax II Airless Hose, 3/8 in x 3 ft BlueMax II Airless Whip Hose, TSL, 4 oz
- Maximum Flow Rate (GPM): 2.15
- Maximum Flow Rate (L/min): 8.14
- Maximum Sound Pressure Level (dB(A)): 86.5
- Maximum Tip Size (cm): 0.1194
- Maximum Tip Size (in): 0.047
- Maximum Tip Size (mm): 1.194
- Maximum Working Pressure (bar): 227
- Maximum Working Pressure (kPa): 2270
- Maximum Working Pressure (psi): 3300
- Number of Colors: One Color
- Number of Guns: 2
- Number of Pumps: 1
- Power Rating (HP): 6.5
- Power Rating (kW): 4.85
- Pow
Linelazer Sprayer, V, 200Hs, Standard 2 Gun
GG 17H461
LINELAZER SPRAYER, V, 200HS, STANDARD 2 GUN
Graco 17H461 LineLazer V 200HS Standard Series Gas Hydraulic Airless Line Striper, 2 Manual Guns
The LineLazer V 200HS Standard Series is a true workhorse designed for high performance striping on demanding jobs like large parking lots, airports, and city jobs that require precise lines.
Application: The LineLazer V Standard Series is ideal for the higher production re-striping contractor completing and considering larger re-striping jobs with basic pattern applications requiring a single-color, single or dual gun striping solution.- LiveLook Display with SmartControl
Striping Information At-A-Glance
Track, measure and control every aspect of your job
Accessible proof-of-job data from the J-Log System with USB Download
Consistent spraying pressure for perfect lines
- Honda GX Engine
Reliable, Easy-to-Start Power
Contractor-preferred - excellent power and proven reliability
Oil Alert shuts down engine to prevent damage if oil level drops too low
- EasyMark Gun Adjustment System
Easy Gun Adjustments
Perfect gun alignment every time with easy-to-use guide mark system
2-gun capability with QuikSelect gun selector
- DualComfort Handlebar System
Easy Handlebar Adjustment
- Endurance Chromex Pump
Reliable, Long-Life Pump
Industry-best pump performance - field-proven design
Handle the most demanding materials with long-life rod treatment
4X harder than ordinary chrome
- High-Efficiency Hydraulic Motor
Uninterrupted Performance
No-Stall design
- High-Capacity Cooling System
Reduced Downtime
Innovative design allows the pump to run cooler and more efficiently
Easier and more thorough fluid changes
Reservoir cooling fins deflect more heat
No special hydraulic fluid needed
- QuikSelect Gun Selector
Simple Gun Control
Independently control of two guns with one lever - solid/skip
- Easy Out Pump Filter
Easy Pump Maintenance & Less Clogging
Inside-out design means less mess with fewer tip clogs
- Model: LineLazer V
- Series: 200HS
- Product Series: Standard
- Attachments: None
- Compatible Material: Road-Marking Paint
- Compatible Surfaces: Pavement, Turf
- Engine Brand: Honda
- Engine Model: GX200
- Fuel Tank Capacity (gal): 0.95
- Fuel Tank Capacity (L): 3.6
- Gun Activation: 2 Manual
- Includes: Flex Plus Gun (2), LineLazer RAC 5 319 Spray Tip (2), LineLazer RAC 5 421 Spray Tip (2), RAC 5 Tip Guard (2), 3/8 in x 22 ft BlueMax II Airless Hose, 3/8 in x 3 ft BlueMax II Airless Whip Hose, TSL, 4 oz
- Maximum Flow Rate (GPM): 2.15
- Maximum Flow Rate (L/min): 8.14
- Maximum Sound Pressure Level (dB(A)): 86.5
- Maximum Tip Size (cm): 0.0838
- Maximum Tip Size (in): 0.033
- Maximum Tip Size (mm): 0.8382
- Maximum Working Pressure (bar): 227
- Maximum Working Pressure (kPa): 2270
- Maximum Working Pressure (psi): 3300
- Number of Colors: One Color
- Number of Guns: 2
- Number of Pumps: 1
- Overall Height (cm): 113.03
- Overall Height (in): 44.5
- Overall Height (mm): 1130.3
- Overa
Kit, Repair, Pkg, 3900 Pro, Qp
GG 17H841
KIT, REPAIR, PKG, 3900 PRO, QP
Graco 17H841 QuikPak Cartridge Repair System
Repack your pump in minutes with modular pre-oiled cartridge packings that are designed to install correctly every time.
Application: Replaces the packings on the Endurance Vortex MaxLife Piston Pump on the Ultra Max II 695/795 ProContractor Series and GMAX II 3900 ProContractor Series sprayers model year 2014 and newer.- Repack your worn packings in three quick and easy steps
Insert pre-oiled packing cartridge assembly
Remove disposable clip
Assemble pump
- Model: QuikPak
- For Use With: Ultra Max II 695 ProContractor Series (2014 and newer), Ultra Max II 795 ProContractor Series (2014 and newer), GMAX II 3900 ProContractor Series (2014 and newer)
Hose, Heated, 10Ft #16 3000Psi
GG 17J667
THERM-O-FLOW HOSE,HEATED,10FT #16,3000 PSI
Hose, Heated, 15 ft, #12, 3000 psi
GG 17J663
THERM-O-FLOW HOSE,HEATED,15FT #12,3000 PSI
Hose, Heated, 20 ft #12 3000PSI
GG 17J664
THERM-O-FLOW HOSE,HEATED,20FT #12,3000 PSI
Hose, Heated, 15Ft, 3000 PSI
GG 17J656
THERM-O-FLOW HOSE,HEATED,15FT #10,3000 PSI
Graco 17J656 #10 0.495 in Core Diameter 15 ft Heated Hose
Hose, Heated, 10 ft #12, 3000 psi
GG 17J662
THERM-O-FLOW HOSE,HEATED,10FT #12,3000 PSI
Kit, Hose, Texture, Blue, 1" X 25'
GG 17J420
KIT, HOSE, TEXTURE, BLUE, 1" X 25'
Graco 17J420 Blue Translucent Hose Kit, 25 ft x 1 in
Replace a worn or damaged hose with genuine Graco parts. Refer to the parts manual for your sprayer to ensure part compatibility
Application: Graco's dedication to delivering the highest quality products also allows you to protect your investment by offering products that can be repaired to ensure years of reliable service. High quality parts have years of service, but wear parts will need replacement over time. Use Genuine Graco parts to keep your sprayer in peak working order for years to come.- Graco Tech Support can further assist with troubleshooting sprayer operation
Repair Kit, Outlet Valve
GG 17J880
KIT, REPAIR, OUTLET VALVE
Graco 17J880 Repair Kit, Outlet Valve, ProX17, ProX19, ProX21 Stand/Cart
Replace a worn or damaged outlet valve with genuine Graco parts. Valve comes in a kit for easy replacement. For ProX series stand or cart model sprayers. Refer to the parts manual for your sprayer to ensure part compatibility
Application: Graco's dedication to delivering the highest quality products also allows you to protect your investment by offering products that can be repaired to ensure years of reliable service. Paints and coatings wear down valves from normal use due to the abrasives used in coatings. Use Genuine Graco parts to keep your sprayer in peak working order for years to come.- Check outlet valve for wear, scratches or rust if the sprayer does not prime or spray
- Graco tech support can further assist with troubleshooting sprayer operation
- Use with magnum ProX17, ProX19 and ProX21 sprayer models 17G177, 17G178, 17G179, 17G180, 17G181, 17G182
- For Use With: ProX17 Cart, ProX17 Stand, ProX19 Cart, ProX19 Stand, ProX21 Cart, ProX21 Stand
- Includes: Instruction Manual, Housing
- Number of Pieces: 2
Blue Translucent Texture Hose Kit, 3/4 in x 25 ft
GG 17J454
KIT, HOSE, TEXTUR, BLUE, .75" X25'
Graco 17J454 Blue Translucent Texture Hose Kit, 3/4 in x 25 ft
Replace a worn or damaged hose with genuine Graco parts. Refer to the parts manual for your sprayer to ensure part compatibility
Application: Graco's dedication to delivering the highest quality products also allows you to protect your investment by offering products that can be repaired to ensure years of reliable service. High quality parts have years of service, but wear parts will need replacement over time. Use Genuine Graco parts to keep your sprayer in peak working order for years to come.- Graco Tech Support can further assist with troubleshooting sprayer operation
Hose, Heated, 25ft #12 3000 PSI
GG 17J665
THERM-O-FLOW HOSE,HEATED,25FT #12,3000 PSI
Hose, Heated, 15Ft #16 3000Psi
GG 17J668
THERM-O-FLOW HOSE,HEATED,15FT #16,3000 PSI
Hose, Heated, 20Ft #16 3000Psi
GG 17J669
THERM-O-FLOW HOSE,HEATED,20FT #16,3000 PSI
Hose Heated 25 FT #10 3000PSI
GG 17J658
THERM-O-FLOW HOSE,HEATED,25FT #10,3000 PSI
Hose Heated 20 FT #10 3000PSI
GG 17J657
THERM-O-FLOW HOSE,HEATED,20FT #10,3000 PSI
Graco 17J657 #10 0.495 in Core Diameter 20 ft Heated Hose
Hose, Heated, 15Ft #20 3000Psi
GG 17J672
THERM-O-FLOW HOSE,HEATED,15FT #20,3000 PSI
Kit, Pot Strainer
GG 17K025
KIT, POT STRAINER
This item is no longer available. Please contact Graco Customer Service for replacement options.
Kit, Hose, Pinch
GG 17K051
KIT, HOSE, PINCH
This item is no longer available. Please contact Graco Customer Service for replacement options.
10 FT SS BRAIDED PTFE AMBIENT HOSE NO 8
GG 17K263
HOSE, CPLED, 4000PSI, 400F, 10', #8
Graco 17K263 10 ft. (3.0 M) Stainless Steel Braided PTFE Ambient Hose, No. 8 (0.401 in. / 10.2 mm ID)
Graco ambient temperature hoses bring reliable performance to Sealant and Adhesive dispensing installations. Whether your material is moisture sensitive, corrosive, or inert, Graco hoses have the materials of construction and build-quality to hold up to all your application's needs.
- For use with Graco sealants and adhesives systems.
- Hose Diameter (in): 0.401
- Hose Diameter (mm): 10.2
- Hose Heating Type: Ambient
- Hose Length (ft): 10
- Hose Length (m): 3
- Inside Diameter (in): 0.401
- Inside Diameter (mm): 10.2
- JIC Size: JIC 08
- Material: PTFE Lined Stainless Steel Braid
- Maximum Temperature ( degrees C): 100
- Maximum Temperature ( degrees F): 212
- Maximum Working Pressure (bar): 276
- Maximum Working Pressure (MPa): 27.6
- Maximum Working Pressure (psi): 4000
Kit, Valve, 3-Way, Eq2
GG 17K055
KIT, VALVE, 3-WAY, EQ2
This item is no longer available. Please contact Graco Customer Service for replacement options.
10 ft. (3.0 M) Stainless Steel Braided PTFE Ambient Hose, No. 10 (0.495 in. / 12.6 mm ID)
GG 17K266
HOSE, CPLED, 4000PSI, 400F, 10'#10
Graco 17K266 10 ft. (3.0 M) Stainless Steel Braided PTFE Ambient Hose, No. 10 (0.495 in. / 12.6 mm ID)
Graco ambient temperature hoses bring reliable performance to Sealant and Adhesive dispensing installations. Whether your material is moisture sensitive, corrosive, or inert, Graco hoses have the materials of construction and build-quality to hold up to all your application's needs.
- For use with Graco sealants and adhesives systems.
- Hose Diameter (in): 0.495
- Hose Diameter (mm): 12.6
- Hose Heating Type: Ambient
- Hose Length (ft): 10
- Hose Length (m): 3
- Inside Diameter (in): 0.495
- Inside Diameter (mm): 12.573
- JIC Size: JIC 10
- Material: PTFE Lined Stainless Steel Braid
- Maximum Temperature ( degrees C): 100
- Maximum Temperature ( degrees F): 212
- Maximum Working Pressure (bar): 276
- Maximum Working Pressure (MPa): 27.6
- Maximum Working Pressure (psi): 4000
6ft 0.495 ID HOSE
GG 17K265
HOSE, CPLED, 4000PSI, 400F, 6', #10
Graco 17K265 6 ft. (1.8 M) Stainless Steel Braided PTFE Ambient Hose, No. 10 (0.495 in. / 12.6 mm ID)
Graco ambient temperature hoses bring reliable performance to Sealant and Adhesive dispensing installations. Whether your material is moisture sensitive, corrosive, or inert, Graco hoses have the materials of construction and build-quality to hold up to all your application's needs.
- For use with Graco sealants and adhesives systems.
- Hose Diameter (in): 0.495
- Hose Diameter (mm): 12.6
- Hose Heating Type: Ambient
- Hose Length (ft): 6
- Hose Length (m): 1.8
- Inside Diameter (in): 0.495
- Inside Diameter (mm): 12.573
- JIC Size: JIC 10
- Material: PTFE Lined Stainless Steel Braid
- Maximum Temperature ( degree C): 100
- Maximum Temperature ( degree F): 212
- Maximum Working Pressure (bar): 276
- Maximum Working Pressure (MPa): 27.6
- Maximum Working Pressure (psi): 4000
20 ft. (6.1 M) Stainless Steel Braided PTFE Ambient Hose, No. 10 (0.495 in. / 12.6 mm ID)
GG 17K268
20 ft. (6.1 M) Stainless Steel Braided PTFE Ambient Hose, No. 10 (0.495 in. / 12.6 mm ID)
26ft 0.495 ID HOSE
GG 17K269
HOSE, CPLED, 4000PSI, 400F, 25'#10
Graco 17K269 25 ft. (7.6 M) Stainless Steel Braided PTFE Ambient Hose, No. 10 (0.495 in. / 12.6 mm ID)
Graco ambient temperature hoses bring reliable performance to Sealant and Adhesive dispensing installations. Whether your material is moisture sensitive, corrosive, or inert, Graco hoses have the materials of construction and build-quality to hold up to all your application's needs.
- For use with Graco sealants and adhesives systems.
- Hose Diameter (in): 0.495
- Hose Diameter (mm): 12.6
- Hose Heating Type: Ambient
- Hose Length (ft): 25
- Hose Length (m): 7.6
- Inside Diameter (in): 0.495
- Inside Diameter (mm): 12.573
- JIC Size: JIC 10
- Material: PTFE Lined Stainless Steel Braid
- Maximum Temperature ( degree C): 100
- Maximum Temperature ( degree F): 212
- Maximum Working Pressure (bar): 276
- Maximum Working Pressure (MPa): 27.6
- Maximum Working Pressure (psi): 4000
6 FT SS BRAIDED PTFE HOSE
GG 17K272
HOSE, CPLED, 4000PSI, 400F, 6'#12
Graco 17K272 6 ft. (1.8 M) Stainless Steel Braided PTFE Ambient Hose, No. 12 (0.617 in. / 15.7 mm ID)
Graco ambient temperature hoses bring reliable performance to Sealant and Adhesive dispensing installations. Whether your material is moisture sensitive, corrosive, or inert, Graco hoses have the materials of construction and build-quality to hold up to all your application's needs.
- For use with Graco sealants and adhesives systems.
- Hose Diameter (in): 0.617
- Hose Diameter (mm): 15.7
- Hose Heating Type: Ambient
- Hose Length (ft): 6
- Hose Length (m): 1.8
- Inside Diameter (in): 0.617
- Inside Diameter (mm): 15.672
- JIC Size: JIC 12
- Material: PTFE Lined Stainless Steel Braid
- Maximum Temperature ( degree C): 100
- Maximum Temperature ( degree F): 212
- Maximum Working Pressure (bar): 276
- Maximum Working Pressure (MPa): 27.6
- Maximum Working Pressure (psi): 4000
20ft SS Braided PTFE Ambient Hose, No.12
GG 17K275
HOSE, CPLED, 4000PSI, 400F, 20'#12
Graco 17K275 20 ft. (6.1 M) Stainless Steel Braided PTFE Ambient Hose, No. 12 (0.617 in. / 15.7 mm ID)
Graco ambient temperature hoses bring reliable performance to Sealant and Adhesive dispensing installations. Whether your material is moisture sensitive, corrosive, or inert, Graco hoses have the materials of construction and build-quality to hold up to all your application's needs.
- For use with Graco sealants and adhesives systems.
- Hose Diameter (in): 0.617
- Hose Diameter (mm): 15.7
- Hose Heating Type: Ambient
- Hose Length (ft): 20
- Hose Length (m): 6.1
- Inside Diameter (in): 0.617
- Inside Diameter (mm): 15.672
- JIC Size: JIC 12
- Material: PTFE Lined Stainless Steel Braid
- Maximum Temperature ( degree C): 100
- Maximum Temperature ( degree F): 212
- Maximum Working Pressure (bar): 276
- Maximum Working Pressure (MPa): 27.6
- Maximum Working Pressure (psi): 4000
25 ft. (7.6 M) Stainless Steel Braided PTFE Ambient Hose, No. 12 (0.617 in. / 15.7 mm ID)
GG 17K276
HOSE, CPLED, 4000PSI, 400F, 25'#12
Graco 17K276 25 ft. (7.6 M) Stainless Steel Braided PTFE Ambient Hose, No. 12 (0.617 in. / 15.7 mm ID)
Graco ambient temperature hoses bring reliable performance to Sealant and Adhesive dispensing installations. Whether your material is moisture sensitive, corrosive, or inert, Graco hoses have the materials of construction and build-quality to hold up to all your application's needs.
- For use with Graco sealants and adhesives systems.
- Hose Diameter (in): 0.617
- Hose Diameter (mm): 15.7
- Hose Heating Type: Ambient
- Hose Length (ft): 25
- Hose Length (m): 7.6
- Inside Diameter (in): 0.617
- Inside Diameter (mm): 15.672
- JIC Size: JIC 12
- Material: PTFE Lined Stainless Steel Braid
- Maximum Temperature ( degree C): 100
- Maximum Temperature ( degree F): 212
- Maximum Working Pressure (bar): 276
- Maximum Working Pressure (MPa): 27.6
- Maximum Working Pressure (psi): 4000
10ft SS Braided PTFE Ambient Hose, No.12
GG 17K273
HOSE, CPLED, 4000PSI, 400F, 10'#12
Graco 17K273 10 ft. (3.0 M) Stainless Steel Braided PTFE Ambient Hose, No. 12 (0.617 in. / 15.7 mm ID)
Graco ambient temperature hoses bring reliable performance to Sealant and Adhesive dispensing installations. Whether your material is moisture sensitive, corrosive, or inert, Graco hoses have the materials of construction and build-quality to hold up to all your application's needs.
- For use with Graco sealants and adhesives systems.
- Hose Diameter (in): 0.617
- Hose Diameter (mm): 15.7
- Hose Heating Type: Ambient
- Hose Length (ft): 10
- Hose Length (m): 3
- Inside Diameter (in): 0.617
- Inside Diameter (mm): 15.672
- JIC Size: JIC 12
- Material: PTFE Lined Stainless Steel Braid
- Maximum Temperature ( degrees C): 100
- Maximum Temperature ( degrees F): 212
- Maximum Working Pressure (bar): 276
- Maximum Working Pressure (MPa): 27.6
- Maximum Working Pressure (psi): 4000
10ft SS Braided PTFE Ambient Hose, No.16
GG 17K278
HOSE, CPLED, 4000PSI, 400F, 10'#16
Graco 17K278 10 ft. (3.0 M) Stainless Steel Braided PTFE Ambient Hose, No. 16 (0.867 in. / 22.0 mm ID)
Graco ambient temperature hoses bring reliable performance to Sealant and Adhesive dispensing installations. Whether your material is moisture sensitive, corrosive, or inert, Graco hoses have the materials of construction and build-quality to hold up to all your application's needs.
- For use with Graco sealants and adhesives systems.
- Hose Diameter (in): 0.867
- Hose Diameter (mm): 22.0
- Hose Heating Type: Ambient
- Hose Length (ft): 10
- Hose Length (m): 3
- Inside Diameter (in): 0.867
- Inside Diameter (mm): 22.022
- JIC Size: JIC 16
- Material: PTFE Lined Stainless Steel Braid
- Maximum Temperature ( degrees C): 100
- Maximum Temperature ( degrees F): 212
- Maximum Working Pressure (bar): 276
- Maximum Working Pressure (MPa): 27.6
- Maximum Working Pressure (psi): 4000
15 FT SS BRAIDED PTFE HOSE
GG 17K279
HOSE, CPLED, 4000PSI, 400F, 15'#16
Graco 17K279 15 ft. (4.6 M) Stainless Steel Braided PTFE Ambient Hose, No. 16 (0.867 in. / 22.0 mm ID)
Graco ambient temperature hoses bring reliable performance to Sealant and Adhesive dispensing installations. Whether your material is moisture sensitive, corrosive, or inert, Graco hoses have the materials of construction and build-quality to hold up to all your application's needs.
- For use with Graco sealants and adhesives systems.
- Hose Diameter (in): 0.867
- Hose Diameter (mm): 22.0
- Hose Heating Type: Ambient
- Hose Length (ft): 15
- Hose Length (m): 4.6
- Inside Diameter (in): 0.867
- Inside Diameter (mm): 22.022
- JIC Size: JIC 16
- Material: PTFE Lined Stainless Steel Braid
- Maximum Temperature ( degree C): 100
- Maximum Temperature ( degree F): 212
- Maximum Working Pressure (bar): 276
- Maximum Working Pressure (MPa): 27.6
- Maximum Working Pressure (psi): 4000
25 ft. (7.6 M) Stainless Steel Braided PTFE Ambient Hose, No. 16 (0.867 in. / 22.0 mm ID)
GG 17K281
HOSE, CPLED, 4000PSI, 400F, 25'#16
Graco 17K281 25 ft. (7.6 M) Stainless Steel Braided PTFE Ambient Hose, No. 16 (0.867 in. / 22.0 mm ID)
Graco ambient temperature hoses bring reliable performance to Sealant and Adhesive dispensing installations. Whether your material is moisture sensitive, corrosive, or inert, Graco hoses have the materials of construction and build-quality to hold up to all your application's needs.
- For use with Graco sealants and adhesives systems.
- Hose Diameter (in): 0.867
- Hose Diameter (mm): 22.0
- Hose Heating Type: Ambient
- Hose Length (ft): 25
- Hose Length (m): 7.6
- Inside Diameter (in): 0.867
- Inside Diameter (mm): 22.022
- JIC Size: JIC 16
- Material: PTFE Lined Stainless Steel Braid
- Maximum Temperature ( degree C): 100
- Maximum Temperature ( degree F): 212
- Maximum Working Pressure (bar): 276
- Maximum Working Pressure (MPa): 27.6
- Maximum Working Pressure (psi): 4000
10 ft. (3.0 M) Stainless Steel Braided PTFE Ambient Hose, No. 20 (1.125 in. / 28.6 mm ID
GG 17K282
10 ft. (3.0 M) Stainless Steel Braided PTFE Ambient Hose, No. 20 (1.125 in. / 28.6 mm ID
20ft SS Braided PTFE Ambient Hose, No.16
GG 17K280
HOSE, CPLED, 4000PSI, 400F, 20'#16
Graco 17K280 20 ft. (6.1 M) Stainless Steel Braided PTFE Ambient Hose, No. 16 (0.867 in. / 22.0 mm ID)
Graco ambient temperature hoses bring reliable performance to Sealant and Adhesive dispensing installations. Whether your material is moisture sensitive, corrosive, or inert, Graco hoses have the materials of construction and build-quality to hold up to all your application's needs.
- For use with Graco sealants and adhesives systems.
- Hose Diameter (in): 0.867
- Hose Diameter (mm): 22.0
- Hose Heating Type: Ambient
- Hose Length (ft): 20
- Hose Length (m): 6.1
- Inside Diameter (in): 0.867
- Inside Diameter (mm): 22.022
- JIC Size: JIC 16
- Material: PTFE Lined Stainless Steel Braid
- Maximum Temperature ( degree C): 100
- Maximum Temperature ( degree F): 212
- Maximum Working Pressure (bar): 276
- Maximum Working Pressure (MPa): 27.6
- Maximum Working Pressure (psi): 4000
15 ft. (4.6 M) Stainless Steel Braided PTFE Ambient Hose, No. 20 (1.125 in. / 28.6 mm ID)
GG 17K283
HOSE, CPLED, 3000PSI, 400F, 15'#20
Graco 17K283 15 ft. (4.6 M) Stainless Steel Braided PTFE Ambient Hose, No. 20 (1.125 in. / 28.6 mm ID)
Graco ambient temperature hoses bring reliable performance to Sealant and Adhesive dispensing installations. Whether your material is moisture sensitive, corrosive, or inert, Graco hoses have the materials of construction and build-quality to hold up to all your application's needs.
- For use with Graco sealants and adhesives systems.
- Hose Diameter (in): 1.125
- Hose Diameter (mm): 28.6
- Hose Heating Type: Ambient
- Hose Length (ft): 15
- Hose Length (m): 4.6
- Inside Diameter (in): 1.125
- Inside Diameter (mm): 28.6
- JIC Size: JIC 20
- Material: PTFE Lined Stainless Steel Braid
- Maximum Temperature ( degree C): 100
- Maximum Temperature ( degree F): 212
- Maximum Working Pressure (bar): 276
- Maximum Working Pressure (MPa): 27.6
- Maximum Working Pressure (psi): 3000
10 ft. (3.0 M) Stainless Steel Braided PTFE Ambient Hose, No. 6 (0.31 in. / 7.9 mm ID)
GG 17K284
HOSE, CPLED, 3000PSI, 400F, 10'#6
Graco 17K284 10 ft. (3.0 M) Stainless Steel Braided PTFE Ambient Hose, No. 6 (0.31 in. / 7.9 mm ID)
Graco ambient temperature hoses bring reliable performance to Sealant and Adhesive dispensing installations. Whether your material is moisture sensitive, corrosive, or inert, Graco hoses have the materials of construction and build-quality to hold up to all your application's needs.
- For use with Graco sealants and adhesives systems.
- Hose Diameter (in): 0.310
- Hose Diameter (mm): 7.9
- Hose Heating Type: Ambient
- Hose Length (ft): 10
- Hose Length (m): 3
- Inside Diameter (in): 0.310
- Inside Diameter (mm): 7.9
- JIC Size: JIC 06
- Material: PTFE Lined Stainless Steel Braid
- Maximum Temperature ( degrees C): 100
- Maximum Temperature ( degrees F): 212
- Maximum Working Pressure (bar): 276
- Maximum Working Pressure (MPa): 27.6
- Maximum Working Pressure (psi): 4000
Kit, Pump, 4B, Bellows, 750 Cc
GG 17K656
KIT,PUMP,4B,BELLOWS,750 CC
Graco 17K656 Sealed 4-Ball Lower, 750 cc, Stainless Steel, Ultralife Rod & Cylinder, Tri-Clamp Fittings
Kit, Pump, 4B, Bellows, 1000 Cc
GG 17K657
KIT,PUMP,4B,BELLOWS,1000 CC
Graco 17K657 Sealed 4-Ball Lower, 1000 cc, Stainless Steel, Ultralife Rod & Cylinder, Tri-Clamp Fittings
ZX OUTLET SEAL KIT FOR 4-BALL LOWERS
GG 17K757
ZX OUTLET SEAL KIT FOR 4-BALL LOWERS
Kit, Pump, 4B, Bellows, 1500 Cc
GG 17K658
KIT, PUMP, 4B, BELLOWS, 1500 CC
Graco 17K658 Sealed 4-Ball Lower, 1500 cc, Stainless Steel, Ultralife Rod & Cylinder, Tri-Clamp Fittings
4-BALL LOWER, OPEN WET CUP, 1500 CC, CARBON STEEL, NPT CONNECTION
GG 17K662
4-BALL LOWER, OPEN WET CUP, 1500 CC, CARBON STEEL, NPT CONNECTION
Kit, Pump, 4B, Bellows, 2000 Cc
GG 17K659
KIT, PUMP, 4B, BELLOWS, 2000 CC
Graco 17K659 Sealed 4-Ball Lower, 2000 cc, Stainless Steel, Ultralife Rod & Cylinder, Tri-Clamp Fittings
Graco's Sealed 4-Ball Lower needs no routine maintenance and prevents unexpected downtime. The sealed fluid section eliminates the need for TSL (throat seal liquid). Designed to keep pumping in the event of a bellows failure, the lower allows you to schedule maintenance.
- Ultralife coating on lower rods and cylinders means a smoother finish, better wear and longer seal life for most applications.
- Connection kits contain tie rods and adapters - everything required to upgrade most legacy Graco circulation pumps to the latest technology. Refer to manual 311876 for complete information.
- Fluid Inlet Size (cm): 3.81
- Fluid Inlet Size (in): 1.5
- Fluid Inlet Thread Gender: Male
- Fluid Inlet Thread Type: Tri-Clamp
- Fluid Outlet Size (in): 1.5
- Fluid Outlet Thread Gender: Male
- Fluid Outlet Thread Type: Tri-Clamp
- Maximum Flow Rate (GPM): 10.6
- Maximum Operating Temperature ( degree F): 150
- Maximum Output (cm cu ): 40000
- Maximum Pump Speed (CPM): 20
- Maximum Working Pressure (psi): 460
4-Ball Lower, Open Wet Cup, 750 cc, Stainless Steel, NPT Connection
GG 17K668
KIT,PUMP,4B,OPEN,SST,750,NPT
Graco 17K668 4-Ball Lower, Open Wet Cup, 750 cc, Stainless Steel, NPT Connection
Kit, Repair, 1500Cc, S4B, Comp
GG 17K762
KIT,REPAIR, 1500CC, S4B, COMP
Graco 17K762 Complete Pump Repair Kit for 1500 cc Sealed 4-Ball Lowers
Payment options
