Plural Component

GG 247576

GG 248376

FUSION AP GUN, AR2929, AUTO

Graco 248376 Round Fusion Air-Purge Gun with 00 Mix Chamber

With long-life mix chamber and durable side seals, Fusion guns are designed to reduce maintenance and downtime, and provide a better mix.

• Easy air-blast tip cleaning reduces build-up and tip clogging.
• Long-lasting side seals means less downtime for maintenance
• Quick-release fluid housing - lets you easily change the mix chambers without tools
• Ergonomic handle

• Model: Fusion AP
• Series: Auto

• Compatible Material: Adhesives, Polyurethane, Polyurea, Polyurethane Coating, Spray Polyurethane Foam

• Fluid Orifice Size (cm): 0.074
• Fluid Orifice Size (in): 0.029
• Fluid Orifice Size (mm): 0.74

• Gun Type: Air Purge Gun

• Maximum Air Inlet Pressure (bar): 9
• Maximum Air Inlet Pressure (kPa): 900
• Maximum Air Inlet Pressure (MPa): 0.9
• Maximum Air Inlet Pressure (psi): 130
• Maximum Air Pressure (bar): 9

• Maximum Air Pressure (kPa): 900
• Maximum Air Pressure (MPa): 0.9
• Maximum Air Pressure (psi): 130

• Maximum Flow Rate @ PSI (lb/min): 50

• Maximum Fluid Pressure (bar): 241
• Maximum Fluid Pressure (kPa): 24100
• Maximum Fluid Pressure (MPa): 24.1
• Maximum Fluid Pressure (psi): 3500
• Maximum Fluid Temperature ( degree C): 93
• Maximum Fluid Temperature ( degree F): 200

• Maximum Fluid Pressure (bar): 241
• Maximum Fluid Pressure (kPa): 24100
• Maximum Fluid Pressure (MPa): 24.1
• Maximum Fluid Pressure (psi): 3500
• Maximum Fluid Temperature ( degree C): 93
• Maximum Fluid Temperature ( degree F): 200

• Minimum Air Inlet Pressure (bar): 5.5
• Minimum Air Inlet Pressure (kPa): 550
• Minimum Air Inlet Pressure (MPa): 0.55
• Minimum Air Inlet Pressure (psi): 80

• Mix Chamber: 00 (.029)

• Overall Height (cm): 9.5
• Overall Height (in): 3.75
• Overall Height (mm): 95
• Overall Length (cm): 19.3
• Overall Length (in): 7.6
• Overall Length (mm): 193
• Overall Width (cm): 7.9
• Overall Width (in): 3.1
• Overall Width (mm): 79

GG 248377

FUSION AP GUN, AR4242, AUTO

Graco 248377 Round Fusion Air-Purge Gun with 01 Mix Chamber

With long-life mix chamber and durable side seals, Fusion guns are designed to reduce maintenance and downtime, and provide a better mix.

• Easy air-blast tip cleaning reduces build-up and tip clogging.
• Long-lasting side seals means less downtime for maintenance
• Quick-release fluid housing - lets you easily change the mix chambers without tools
• Ergonomic handle

• Model: Fusion AP
• Series: Auto

• Compatible Material: Adhesives, Polyurethane, Polyurea, Polyurethane Coating, Spray Polyurethane Foam

• Fluid Orifice Size (cm): 0.107
• Fluid Orifice Size (in): 0.042
• Fluid Orifice Size (mm): 1.07

• Gun Type: Air Purge Gun

• Maximum Air Inlet Pressure (bar): 9
• Maximum Air Inlet Pressure (kPa): 900
• Maximum Air Inlet Pressure (MPa): 0.9
• Maximum Air Inlet Pressure (psi): 130
• Maximum Air Pressure (bar): 9

• Maximum Air Pressure (kPa): 900
• Maximum Air Pressure (MPa): 0.9
• Maximum Air Pressure (psi): 130

• Maximum Flow Rate @ PSI (lb/min): 50

• Maximum Fluid Pressure (bar): 241
• Maximum Fluid Pressure (kPa): 24100
• Maximum Fluid Pressure (MPa): 24.1
• Maximum Fluid Pressure (psi): 3500
• Maximum Fluid Temperature ( degree C): 93
• Maximum Fluid Temperature ( degree F): 200

• Maximum Fluid Pressure (bar): 241
• Maximum Fluid Pressure (kPa): 24100
• Maximum Fluid Pressure (MPa): 24.1
• Maximum Fluid Pressure (psi): 3500
• Maximum Fluid Temperature ( degree C): 93
• Maximum Fluid Temperature ( degree F): 200

• Minimum Air Inlet Pressure (bar): 5.5
• Minimum Air Inlet Pressure (kPa): 550
• Minimum Air Inlet Pressure (MPa): 0.55
• Minimum Air Inlet Pressure (psi): 80

• Mix Chamber: 01 (.042)

• Overall Height (cm): 9.5
• Overall Height (in): 3.75
• Overall Height (mm): 95
• Overall Length (cm): 19.3
• Overall Length (in): 7.6
• Overall Length (mm): 193
• Overall Width (cm): 7.9
• Overall Width (in): 3.1
• Overall Width (mm): 79

GG 248381

FUSION AP GUN, AF2929 FT0438, AUTO

Graco 248381 Fusion Air-Purge Gun, 0.038 in (0.96 mm) Orifice Size, 0.029 in (0.74 mm) Impingement Port & 8-10 in (203-254 mm) Flat Pattern Size

With long-life mix chamber and durable side seals, Fusion guns are designed to reduce maintenance and downtime, and provide a better mix.

• Easy air-blast tip cleaning reduces build-up and tip clogging.
• Long-lasting side seals means less downtime for maintenance
• Quick-release fluid housing - lets you easily change the mix chambers without tools
• Ergonomic handle

• Model: Fusion AP
• Series: Auto

• Compatible Material: Adhesives, Polyurethane, Polyurea, Polyurethane Coating, Spray Polyurethane Foam

• Fluid Orifice Size (cm): 0.074
• Fluid Orifice Size (in): 0.029
• Fluid Orifice Size (mm): 0.74

• Gun Type: Air Purge Gun

• Maximum Air Inlet Pressure (bar): 9
• Maximum Air Inlet Pressure (kPa): 900
• Maximum Air Inlet Pressure (MPa): 0.9
• Maximum Air Inlet Pressure (psi): 130
• Maximum Air Pressure (bar): 9

• Maximum Air Pressure (kPa): 900
• Maximum Air Pressure (MPa): 0.9
• Maximum Air Pressure (psi): 130

• Maximum Flow Rate @ PSI (lb/min): 50

• Maximum Fluid Pressure (bar): 241
• Maximum Fluid Pressure (kPa): 24100
• Maximum Fluid Pressure (MPa): 24.1
• Maximum Fluid Pressure (psi): 3500
• Maximum Fluid Temperature ( degree C): 93
• Maximum Fluid Temperature ( degree F): 200

• Maximum Fluid Pressure (bar): 241
• Maximum Fluid Pressure (kPa): 24100
• Maximum Fluid Pressure (MPa): 24.1
• Maximum Fluid Pressure (psi): 3500
• Maximum Fluid Temperature ( degree C): 93
• Maximum Fluid Temperature ( degree F): 200

• Minimum Air Inlet Pressure (bar): 5.5
• Minimum Air Inlet Pressure (kPa): 550
• Minimum Air Inlet Pressure (MPa): 0.55
• Minimum Air Inlet Pressure (psi): 80

• Mix Chamber: 00 (.029)

• Overall Height (cm): 9.5
• Overall Height (in): 3.75
• Overall Height (mm): 95
• Overall Length (cm): 19.3
• Overall Length (in): 7.6
• Overall Length (mm): 193
• Overall Width (cm): 7.9
• Overall Width (in): 3.1
• Overall Width (mm): 79

• Pattern Size (in): 8-10 in @ 24 in from target

GG 24F108

PROMIX 2KE PROPORTIONER, SYSTEM, PUMP

Graco 24F108 ProMix 2KE Proportioner, air, 35:1 Air Assist Merkur & Merkur Bellows pumps, screen reporting, for hazardous location

The ProMix 2KE is an entry level, compact, easy to use plural component system allowing you to mix on-demand for all spray technologies.

• Designed for multi-color, two component, in-booth applications
• Choose between pump-based or meter-based plural component systems with mix ratios up to 30:1
• Stay on ratio within predefined tolerance limits, down to plus/minus 02% with the pump version, plus/minus 01% with meter
• Easy-to-use LCD display allows you to track material usage, display mix ratio, program maintenance reminders operate, control operation functions and more

• Model: ProMix
• Series: 2KE

• Air Inlet Size (cm): 0.9525
• Air Inlet Size (in): 3/8
• Air Inlet Size (mm): 9.525
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Amperage (A): 2
• Applicator Type: Manual Air-Assist

• Component Type: Two Component

• Flush Type: Solvent

• Frequency (Hz): 50/60

• Gun Activation: Manual

• Includes: Air Motor, A-Lower, B-Lower, A-Tie Rod, B-Tie Rod, Lower Adapter, TSL Reservoir

• Material Type: Two Component

• Maximum Air Inlet Pressure (bar): 6.9
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Fluid Viscosity (cP): 5000

• Maximum Fluid Viscosity (cP): 5000

• Maximum Mix Ratio: 30:1
• Maximum Number of Colors: Up to 3

• Maximum Working Pressure (bar): 241
• Maximum Working Pressure (kPa): 24100
• Maximum Working Pressure (MPa): 24.1
• Maximum Working Pressure (psi): 3500
• Measuring Type: Pump

• Minimum Fluid Viscosity (cP): 20
• Minimum Mix Ratio: 0.1:1

• Mix Accuracy (%): 1

• Number of Catalysts: 1
• Number of Color Valves: N/A
• Number of Colors: 1

• Number of Resin Colors: 1

• Overall Depth (cm): 37.6
• Overall Depth (in): 14.8
• Overall Depth (mm): 376

• Overall Height (cm): 91.7
• Overall Height (in): 36.1
• Overall Height (mm): 917
• Overall Width (cm): 51.1
• Overall Width (in): 20.1
• Overall Width (mm): 511

• Power Source: Air

• Proportioning Type: Manual Electronic

• Pump Ratio: 35:1
• Pump Type: Air-Assisted Bellows

GG 24F109

PROMIX 2KE PROPORTIONER, SYSTEM, PUMP

Graco 24F109 ProMix 2KE Proportioner, air, 3:1 Air Spray Merkur pumps, USB reporting, for hazardous location

The ProMix 2KE is an entry level, compact, easy to use plural component system allowing you to mix on-demand for all spray technologies.

• Designed for multi-color, two component, in-booth applications
• Choose between pump-based or meter-based plural component systems with mix ratios up to 30:1
• Stay on ratio within predefined tolerance limits, down to plus/minus 02% with the pump version, plus/minus 01% with meter
• Easy-to-use LCD display allows you to track material usage, display mix ratio, program maintenance reminders operate, control operation functions and more

• Model: ProMix
• Series: 2KE

• Air Inlet Size (cm): 0.9525
• Air Inlet Size (in): 3/8
• Air Inlet Size (mm): 9.525
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Amperage (A): 2
• Applicator Type: Manual Air Spray

• Component Type: Two Component

• Flush Type: Solvent

• Frequency (Hz): 50/60

• Gun Activation: Manual

• Includes: Air Motor, Adapter Plate, A-Lower, B-Lower, A-Tie Rod, B-Tie Rod, Coupling, Lower Adapter, TSL Reservoir

• Material Type: Two Component

• Maximum Air Inlet Pressure (bar): 6.9
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Fluid Viscosity (cP): 5000

• Maximum Fluid Viscosity (cP): 5000

• Maximum Mix Ratio: 30:1
• Maximum Number of Colors: Up to 3

• Maximum Working Pressure (bar): 21
• Maximum Working Pressure (kPa): 2100
• Maximum Working Pressure (MPa): 2.1
• Maximum Working Pressure (psi): 300
• Measuring Type: Pump

• Minimum Fluid Viscosity (cP): 20
• Minimum Mix Ratio: 0.1:1

• Mix Accuracy (%): 1

• Number of Catalysts: 1
• Number of Color Valves: N/A
• Number of Colors: 1

• Number of Resin Colors: 1

• Overall Depth (cm): 37.6
• Overall Depth (in): 14.8
• Overall Depth (mm): 376

• Overall Height (cm): 91.7
• Overall Height (in): 36.1
• Overall Height (mm): 917
• Overall Width (cm): 51.1
• Overall Width (in): 20.1
• Overall Width (mm): 511

• Power Source: Air

• Proportioning Type: Manual Electronic

• Pump Ratio: 3:1
• Pump Type: Air Spray

GG 24Z013

PROMIX 2KE PROPORTIONER, METER, ACID

Graco 24Z013 ProMix 2KE Acid Catalyst Meter, 1 color/1 catalyst, IS, intrinsically safe alternator power

The ProMix 2KE meter-based system manages tough acid catalyst materials, such as conversion varnish for cabinetry and bar counter tops. The compact, entry-level proportioner easily handles strong acid catalysts with its corrosion resistant fluid section and smart fluid plate.

• Made with durable, high grade, stainless steel components like gears with ceramic bearings, the G3000A meter gauges the exact mix ratio while withstanding corrosion.
• Choose between pump-based or meter-based plural component systems with mix ratios up to 30:1
• Stay on ratio within predefined tolerance limits, down to plus/minus 02% with the pump version, plus/minus 01% with meter
• Easy-to-use LCD display allows you to track material usage, display mix ratio, program maintenance reminders operate, control operation functions and more

• Model: ProMix
• Series: 2KE

• Air Inlet Size (cm): 0.9525
• Air Inlet Size (in): 3/8
• Air Inlet Size (mm): 9.525
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Amperage (A): 2

• Component Type: Two Component

• Flush Type: Solvent

• Frequency (Hz): 50/60

• Gun Activation: Manual

• Includes: 2KE Meter-Based Proportioner, G3000 (A), G3000A (B), 1 Color, 1 Catalyst, Intrinsically Safe Alternator Power

• Material Type: Two Component

• Maximum Air Inlet Pressure (bar): 6.9
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Fluid Viscosity (cP): 5000

• Maximum Fluid Viscosity (cP): 5000

• Maximum Number of Colors: Up to 3

• Maximum Working Pressure (bar): 206.8
• Maximum Working Pressure (kPa): 20680
• Maximum Working Pressure (MPa): 20.7
• Maximum Working Pressure (psi): 3000
• Measuring Type: Meter

• Minimum Fluid Viscosity (cP): 20
• Minimum Mix Ratio: 0.1:1

• Mix Accuracy (%): 1

• Number of Catalysts: 1
• Number of Color Valves: N/A
• Number of Colors: 1

• Number of Resin Colors: 1

• Power Source: Electric

• Proportioning Type: Manual Electronic

• Pump Ratio: Meter only

GG 24Z014

PROMIX 2KE PROPORTIONER, METER, ACID

Graco 24Z014 ProMix 2KE Acid Catalyst Meter, 3 color/1 catalyst, IS, intrinsically safe alternator power

The ProMix 2KE meter-based system manages tough acid catalyst materials, such as conversion varnish for cabinetry and bar counter tops. The compact, entry-level proportioner easily handles strong acid catalysts with its corrosion resistant fluid section and smart fluid plate.

• Made with durable, high grade, stainless steel components like gears with ceramic bearings, the G3000A meter gauges the exact mix ratio while withstanding corrosion.
• Choose between pump-based or meter-based plural component systems with mix ratios up to 30:1
• Stay on ratio within predefined tolerance limits, down to plus/minus 02% with the pump version, plus/minus 01% with meter
• Easy-to-use LCD display allows you to track material usage, display mix ratio, program maintenance reminders operate, control operation functions and more

• Model: ProMix
• Series: 2KE

• Air Inlet Size (cm): 0.9525
• Air Inlet Size (in): 3/8
• Air Inlet Size (mm): 9.525
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Amperage (A): 2

• Component Type: Two Component

• Flush Type: Solvent

• Frequency (Hz): 50/60

• Gun Activation: Manual

• Includes: 2KE Meter-Based Proportioner, G3000 (A), G3000A (B), 3 Color, 1 Catalyst, Intrinsically Safe Alternator Power

• Material Type: Two Component

• Maximum Air Inlet Pressure (bar): 6.9
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Fluid Viscosity (cP): 5000

• Maximum Fluid Viscosity (cP): 5000

• Maximum Number of Colors: Up to 3

• Maximum Working Pressure (bar): 206.8
• Maximum Working Pressure (kPa): 20680
• Maximum Working Pressure (MPa): 20.7
• Maximum Working Pressure (psi): 3000
• Measuring Type: Meter

• Minimum Fluid Viscosity (cP): 20
• Minimum Mix Ratio: 0.1:1

• Mix Accuracy (%): 1

• Number of Catalysts: 1
• Number of Color Valves: N/A
• Number of Colors: 3

• Number of Resin Colors: 3

• Power Source: Electric

• Proportioning Type: Manual Electronic

• Pump Ratio: Meter only

GG 262381

PROCONTROL 1KS PROPORTIONER, PROMX, REMTE

Graco 262381 ProControl 1KS with G3000 Meter

Maintain a closed loop flow control system for a superior finish with the same proven technology as the ProMix 2KS

• Single Component Flow Control
• Integrated Flushing
• Optional Color Change Modules

• Model: ProControl
• Series: 1KS

• Air Inlet Size (cm): 0.9525
• Air Inlet Size (in): 3/8
• Air Inlet Size (mm): 9.525
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Amperage (A): 2

• Fluid Inlet Size (cm): 0.635
• Fluid Inlet Size (in): 1/4
• Fluid Inlet Size (mm): 6.35
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (in): 1/4
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT

• Frequency (Hz): 50/60

• Includes: ProControl 1KS Module, G3000 Meter

• Maximum Air Inlet Pressure (bar): 6.9
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Flow Rate (cc/min): 3790

• Maximum Flow Rate (GPM): 1
• Maximum Flow Rate (L/min): 3.79

• Maximum Fluid Viscosity (cP): 5000

• Maximum Fluid Viscosity (cP): 5000

• Maximum Number of Colors: Up to 30

• Maximum Operating Temperature ( degree C): 50
• Maximum Operating Temperature ( degree F): 122

• Maximum Working Pressure (bar): 275.8
• Maximum Working Pressure (kPa): 27580
• Maximum Working Pressure (MPa): 27.6
• Maximum Working Pressure (psi): 4000

• Minimum Flow Rate (cc/min): 75
• Minimum Flow Rate (GPM): 0.02
• Minimum Flow Rate (L/min): 0.075

• Minimum Fluid Viscosity (cP): 20

GG 262572

REACTOR A-25 PROPORTIONER, BARE

Graco 262572 Reactor A-25 Bare Proportioner

The Reactor A-25 is a Graco-engineered spray foam proportioner that gives you the reliability you expect on the jobsite. It maintains consistent temperature control, even when you're spraying at maximum flow rates - resulting in better quality foam.

• Maintains temperature setpoints for better yield
• Maintains consistent output pressure for uniform spray pattern
• Easy to operate and maintain
• DataTrak Control
  • Resettable counter tracks material usage
• Three Heat Zones
  • Three independent heat zones - ISO, resin and hose heat
  • Provide accurate heat control for reliable spraying to handle different chemical viscosities
  • Digital temperature controls
• Recirculation Manifold
  • A quick, easy way to balance system pressures
• NXT Air Motor
  • Low air consumption for increased efficiency
  • Muffler provides low operating noise levels
  • Air valve provides smooth and rapid changeover
• Quick Knockdown Lower Pumps
  • For easy disassembly and maintenance
• ISO Pump Lube System
  • Prevents isocyanate crystallization on the pump seal and shaft
• ISO Pump Lube System
  • Prevents isocyanate crystallization on the pump seal and shaft

• Model: Reactor
• Series: A-25

• Air Inlet Size (cm): 1.27
• Air Inlet Size (in): 1/2
• Air Inlet Size (mm): 12.7
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Amperage (A): 18.5 @ 380 V ac (3-Phase WYE), 32 @ 230 V ac (3-Phase Delta), 40 @ 230 V ac (1-Phase)
• Application: Spray Foam
• Applicator Type: Manual

• Compatible Material: Plural-Component

• Component A Inlet Size (in): 3/4
• Component A Inlet Size (mm): 19.05
• Component A Thread Gender: Female
• Component A Thread Type: NPT
• Component B Inlet Size (in): 3/4
• Component B Inlet Size (mm): 19.05
• Component B Thread Gender: Female
• Component B Thread Type: NPT
• Component Type: Two Component

• Flush Type: Solvent

• Frequency (Hz): 50/60

• Gun Type: No Gun

• Includes: Proportioner, Heated Hose

• Material Application: Polyurethane Foam

• Maximum Air Consumption (SCFM): 28 scfm at 1500 psi
• Maximum Air Inlet Pressure (bar): 8.62
• Maximum Air Inlet Pressure (kPa): 862
• Maximum Air Inlet Pressure (psi): 125

• Maximum Flow Rate (kg/min): 11.34
• Maximum Flow Rate (lb/min): 25

• Maximum Fluid Temperature ( degree C): 88
• Maximum Fluid Temperature ( degree F): 190
• Maximum Fluid Viscosity (cP): 1500

• Maximum Fluid Temperature ( degree C): 88
• Maximum Fluid Temperature ( degree F): 190
• Maximum Fluid Viscosity (cP): 1500

• Maximum Hose Length (ft): 210
• Maximum Hose Length (m): 64

• Maximum Mix Ratio: 1:1

• Maximum Working Pressure (bar): 138
• Maximum Working Pressure (kPa): 13800
• Maximum Working Pressure (MPa): 14
• Maximum Working Pressure (psi): 2000

• Minimum Fluid Viscosity (cP): 250

• Overall Depth (cm): 62.2

GG 262573

GG 272010

REACTOR 2 E-30 PROPORTIONER, 10KW

Graco 272010 Reactor 2 E-30 Proportioner, 10 kW

Each feature in the Reactor 2 was strategically designed to help your business, with innovations that help your operation run smoothly. Software and hardware enhancements for better spray performance. And new technologies that add to your bottom line.

• Reactor 2 E-30 gives you:

  Compact footprint - more room in your spray rig

  Ergonomic design - easier to service

  Advanced control modules

  Better spraying performance compared to traditional electric Reactor systems

  Troubleshooting made quick and easy with QR codes

• Reactor Connect : Communication and Control at your Fingertips

  Control your Reactor using your phone

  Improve productivity and yield by optimizing spray parameters and never having to go back to your rig

  Monitor your rigs/crews using the multi-system dashboard

  Troubleshoot an issue quickly using real-time data

  Provide documentation to a customer

  Use reports to better manage your business

  Saves all your spray data to the cloud

  Utilize account management to better manage your equipment and crews

  Reactor Connect comes standard with all Reactor 2 models

• Advanced control technology

  Tracks, monitors and saves project data

  Data can be saved and downloaded onto a USB drive

  Stores up to 24 chemical recipes

  Drum level indicators

• Easy to reach, conveniently-placed electronics
• Advanced control modules

  Handles power fluctuations

• Sacrificial surge protector

  Protects your electronics against excessive power spikes

• Smooth, consistent spray performance - similar to hydraulic systems
• Three-year warranty

  Covers user display module, control modules and electric motor

  One of the best in the industry

• Model: Reactor 2
• Series: E-30
• Product Series: Non-Elite

• Amperage (A): 34 @ 350 to 415 V ac (3-Phase WYE), 50 @ 200 to 240 V ac (3-Phase Delta), 78 @ 200 to 240 V ac (1-Phase)
• Application: Spray Foam
• Applicator Type: Manual

• Compatible Material: Plural Components

• Component Type: Two Component

• Flush Type: Solvent

• Frequency (Hz): 50/60

• Gun Type: No Gun

• Hose Package: No Hose

• Material Application: Polyurethane Foam

• Maximum Flow Rate (kg/min): 13.61
• Maximum Flow Rate (lb/min): 30

• Maximum Fluid Temperature ( degree C): 88
• Maximum Fluid Temperature ( degree F): 190

• Maximum Fluid Temperature ( degree C): 88
• Maximum Fluid Temperature ( degree F): 190

• Maximum Hose Length (ft): 310
• Maximum Hose Length (m): 94.5

• Maximum Mix Ratio: 1:1

• Maximum Working Pressure (bar): 138
• Maximum Working Pressure (kPa): 13800
• Maximum Working Pressure (MPa): 13.8
• Maximum Working Pressure (psi): 2000

• Overall Depth (cm): 38.1
• Overall Depth (in): 15
• Overall Depth (mm): 381

• Overall Height (cm): 160
• Overall Height (in): 63
• Overall Height (mm): 1600
• Overall Width (cm): 66.8
• Overall Width (in): 26.3
• Overall Width (mm): 668

GG 272012

REACTOR 2 E-XP2 PROPORTIONER

Graco 272012 Reactor 2 E-XP2 Proportioner

Count on the Reactor 2 E-XP2 proportioner for advanced technology in applying fast-curing polyurea coatings. Because its a Reactor 2 series proportioner, it offers software and hardware enhancements for better spray performance, plus technologies that add to your bottom line. The Reactor 2 E-XP2 is engineered to process and spray polyurea and other coatings that require high pressures. The hybrid heater and heated hose condition the materials to the right viscosity prior to mixing. Quick knockdown lower pump for easy maintenance, easy-to-use controls, and rugged design make the Reactor the preferred choice for coatings applications.

• Reactor 2 E-XP2 gives you:

  Compact footprint - more room in your spray rig

  Ergonomic design - easier to service

  Advanced control modules

  Better spraying performance compared to traditional electric Reactor systems

  Troubleshooting made quick and easy with QR codes

• Reactor Connect : Communication and Control at your Fingertips

  Control your Reactor using your phone

  Improve productivity and yield by optimizing spray parameters and never having to go back to your rig

  Monitor your rigs/crews using the multi-system dashboard

  Troubleshoot an issue quickly using real-time data

  Provide documentation to a customer

  Use reports to better manage your business

  Saves all your spray data to the cloud

  Utilize account management to better manage your equipment and crews

  Reactor Connect comes standard with all Reactor 2 models

• Advanced control technology

  Tracks, monitors and saves project data

  Data can be saved and downloaded onto a USB drive

  Stores up to 24 chemical recipes

  Drum level indicators

• Easy to reach, conveniently-placed electronics
• Advanced control modules

  Handles power fluctuations

• Sacrificial surge protector

  Protects your electronics against excessive power spikes

• Smooth, consistent spray performance - similar to hydraulic systems
• Three-year warranty

  Covers user display module, control modules and electric motor

  One of the best in the industry

• Reactor Elite models include:

  Inlet pressure and temperature sensor

  Xtreme-Wrap Scuff Guard on heated hoses for Reactor 2 packages

• Model: Reactor 2
• Series: E-XP2
• Product Series: Non-Elite

• Amperage (A): 35 @ 350 to 415 V ac (3-Phase WYE), 62 @ 200 to 240 V ac (3-Phase Delta), 100 @ 200 to 240 V ac (1-Phase)
• Application: Protective Coatings
• Applicator Type: Manual

• Compatible Material: Plural Components

• Component Type: Two Component

• Flush Type: Solvent

• Frequency (Hz): 50/60

• Gun Type: No Gun

• Hose Length (ft): 50, 10
• Hose Length (m): 15, 3

• Hose Package: No Hose

• Material Application: Polyurea

• Maximum Flow Rate (cc/min): 7570

• Maximum Flow Rate (GPM): 2
• Maximum Flow Rate (L/min): 7.57

• Maximum Fluid Temperature ( degree C): 88
• Maximum Fluid Temperature ( degree F): 190

• Maximum Fluid Temperature ( degree C): 88
• Maximum Fluid Temperature ( degree F): 190

• Maximum Hose Length (ft): 310
• Max

GG 272112

REACTOR 2 E-XP2 PROPORTIONER, ELITE

Graco 272112 Reactor 2 E-XP2 Elite Proportioner

Count on the Reactor 2 E-XP2 proportioner for advanced technology in applying fast-curing polyurea coatings. Because its a Reactor 2 series proportioner, it offers software and hardware enhancements for better spray performance, plus technologies that add to your bottom line. The Reactor 2 E-XP2 is engineered to process and spray polyurea and other coatings that require high pressures. The hybrid heater and heated hose condition the materials to the right viscosity prior to mixing. Quick knockdown lower pump for easy maintenance, easy-to-use controls, and rugged design make the Reactor the preferred choice for coatings applications.

• Reactor 2 E-XP2 gives you:

  Compact footprint - more room in your spray rig

  Ergonomic design - easier to service

  Advanced control modules

  Better spraying performance compared to traditional electric Reactor systems

  Troubleshooting made quick and easy with QR codes

• Reactor Connect : Communication and Control at your Fingertips

  Control your Reactor using your phone

  Improve productivity and yield by optimizing spray parameters and never having to go back to your rig

  Monitor your rigs/crews using the multi-system dashboard

  Troubleshoot an issue quickly using real-time data

  Provide documentation to a customer

  Use reports to better manage your business

  Saves all your spray data to the cloud

  Utilize account management to better manage your equipment and crews

  Reactor Connect comes standard with all Reactor 2 models

• Advanced control technology

  Tracks, monitors and saves project data

  Data can be saved and downloaded onto a USB drive

  Stores up to 24 chemical recipes

  Drum level indicators

• Easy to reach, conveniently-placed electronics
• Advanced control modules

  Handles power fluctuations

• Sacrificial surge protector

  Protects your electronics against excessive power spikes

• Smooth, consistent spray performance - similar to hydraulic systems
• Three-year warranty

  Covers user display module, control modules and electric motor

  One of the best in the industry

• Reactor Elite models include:

  Inlet pressure and temperature sensor

  Xtreme-Wrap Scuff Guard on heated hoses for Reactor 2 packages

• Model: Reactor 2
• Series: E-XP2
• Product Series: Elite

• Amperage (A): 35 @ 350 to 415 V ac (3-Phase WYE), 62 @ 200 to 240 V ac (3-Phase Delta), 100 @ 200 to 240 V ac (1-Phase)
• Application: Protective Coatings
• Applicator Type: Manual

• Compatible Material: Plural Components

• Component Type: Two Component

• Flush Type: Solvent

• Frequency (Hz): 50/60

• Gun Type: No Gun

• Hose Package: No Hose

• Material Application: Polyurea

• Maximum Flow Rate (cc/min): 7570

• Maximum Flow Rate (GPM): 2
• Maximum Flow Rate (L/min): 7.57

• Maximum Fluid Temperature ( degree C): 88
• Maximum Fluid Temperature ( degree F): 190

• Maximum Fluid Temperature ( degree C): 88
• Maximum Fluid Temperature ( degree F): 190

• Maximum Hose Length (ft): 310
• Maximum Hose Length (m): 94.5

• Maximum Mix Ratio: 1:1<

GG 282404

XP SYSTEM, 4:1, 220/54, BF, CH, HS

Graco 282404 XP50 Hazardous Location Spray Package, Cart, 4:1 Mix Ratio, Hopper, Solvent Pump, Heaters, XTR Gun, 240V

Two-component spraying made easy and affordable. Graco XP50 Plural-Component Sprayers are designed to pump, mix and atomize medium to high solid coatings with superior results. When you upgrade from hand mixing, youll find that the XP provides excellent return on investment, by reducing material waste and by using less clean-up solvent. Flexible options for mix ratio, pressure and flow rate - choose the right system for the application. If you occasionally change materials, the Graco XP Sprayers are the right choice. That's because you can change the ratio by simply changing out one or two pump lowers. Available in 1:1, 1.5:1, 2:1, 2.5:1, 3:1 and 4:1 mix ratios.

• Reduced material waste
• No more throwing away unused mixed material at the end of the day
• Save money by using less clean-up solvent
• Easy to operate - minimal training required
• Reduced maintenance costs
• Rated for 5000 psi (345 bar) to handle viscous materials and long hose lengths

• Series: XP50

• Air Inlet Size (in): 3/4
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPSM

• Applicator Type: Automatic Airless, Manual Airless

• Compatible Material: Protective Coatings, Primer, Epoxies, Polyurethane, Two-Component Coating, Solvents

• Component Type: Plural-Component
• Configuration: Cart Mount with 7 gallon (26.5 Liter) Hopper

• Fluid Inlet Size (in): 1-1/4
• Fluid Inlet Thread Gender: Male
• Fluid Inlet Thread Type: NPSM

• Fluid Outlet Size (in): 1/2
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT
• Flush Type: Solvent

• Hose Length (ft): 35
• Hose Length (m): 10.7

• Includes: Cart, Material Hoses, XTR-5 Gun, NXT 6500 Air Motor, Hoppers, IS Fluid Heater, Flush Pump

• Material Application: Coatings, Paints, Primers

• Maximum Air Consumption (SCFM): 60 scfm/gpm at 100 psi
• Maximum Air Inlet Pressure (bar): 12.07
• Maximum Air Inlet Pressure (kPa): 1207
• Maximum Air Inlet Pressure (MPa): 1.21
• Maximum Air Inlet Pressure (psi): 175

• Maximum Cycle Rate (CPM): 40

• Maximum Flow Rate (cc/min): 10970

• Maximum Flow Rate (GPM): 2.9
• Maximum Flow Rate (L/min): 10.97

• Maximum Fluid Temperature ( degree C): 71
• Maximum Fluid Temperature ( degree F): 160
• Maximum Fluid Viscosity (cP): 20000

• Maximum Fluid Temperature ( degree C): 71
• Maximum Fluid Temperature ( degree F): 160
• Maximum Fluid Viscosity (cP): 20000

• Maximum Hose Length (ft): 300
• Maximum Hose Length (m): 91.4

• Maximum Operating Temperature ( degree C): 54
• Maximum Operating Temperature ( degree F): 130

• Maximum Spray Pressure (bar): 344

• Maximum Spray Pressure (kPa): 34400
• Maximum Spray Pressure (MPa): 34
• Maximum Spray Pressure (psi): 5000

• Maximum Working Pressure (bar): 331
• Maximum Working Pressure (kPa): 33100
• Maximum Working Pressure (MPa): 33
• Maximum Working Pressure (psi): 4800
• Measuring Type: Fixed Mechanical Positive Displacement

• Minimum Flu

GG 287655

GG 575206

XP SYSTEM, 2:1, 180/90, COMPLETE, HAZ

Graco 575206 XP50 Cart System, Hazardous Location, 2:1 With Primary Heaters & Hose Heat, 240V

Two-component spraying made easy and affordable. Graco XP50 Plural-Component Sprayers are designed to pump, mix and atomize medium to high solid coatings with superior results. When you upgrade from hand mixing, you'll find that the XP provides excellent return on investment, by reducing material waste and by using less clean-up solvent. Flexible options for mix ratio, pressure and flow rate - choose the right system for the application. If you occasionally change materials, the Graco XP Sprayers are the right choice. That's because you can change the ratio by simply changing out one or two pump lowers. Available in 1:1, 1.5:1, 2:1, 2.5:1, 3:1 and 4:1 mix ratios.

• Reduced material waste
• No more throwing away unused mixed material at the end of the day
• Save money by using less clean-up solvent
• Easy to operate - minimal training required
• Reduced maintenance costs
• Rated for 5000 psi (345 bar) to handle viscous materials and long hose lengths

• Series: XP50

• Air Inlet Size (in): 3/4
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPSM

• Applicator Type: Automatic Airless, Manual Airless

• Compatible Material: Protective Coating, Primer, Epoxy, Polyurethane, Two-Component Coating, Solvents

• Component Type: Plural-Component
• Configuration: With Primary Heaters & Hose Heat

• Fluid Inlet Size (in): 1-1/4
• Fluid Inlet Thread Gender: Male
• Fluid Inlet Thread Type: NPSM

• Fluid Outlet Size (in): 1/2
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT
• Flush Type: Solvent

• Hose Length (ft): 35
• Hose Length (m): 10.7

• Includes: 7 Gallon Hoppers, XTR+ Gun, 35 ft integration Hose and Static Mixer, Merkur Flush Pump, Viscon HP Heaters, Hose Heat Circulation Kit, Remote Carriage, PressureTrak

• Location Category: Hazardous Location

• Material Application: Coatings, Paints, Primers

• Maximum Air Consumption (SCFM): 60 scfm/gpm at 100 psi
• Maximum Air Inlet Pressure (bar): 12.07
• Maximum Air Inlet Pressure (kPa): 1207
• Maximum Air Inlet Pressure (MPa): 1.21
• Maximum Air Inlet Pressure (psi): 175

• Maximum Cycle Rate (CPM): 40

• Maximum Flow Rate (cc/min): 10970

• Maximum Flow Rate (GPM): 2.9
• Maximum Flow Rate (L/min): 10.97

• Maximum Fluid Temperature ( degree C): 71
• Maximum Fluid Temperature ( degree F): 160
• Maximum Fluid Viscosity (cP): 20000

• Maximum Fluid Temperature ( degree C): 71
• Maximum Fluid Temperature ( degree F): 160
• Maximum Fluid Viscosity (cP): 20000

• Maximum Hose Length (ft): 300
• Maximum Hose Length (m): 91.4

• Maximum Operating Temperature ( degree C): 54
• Maximum Operating Temperature ( degree F): 130

• Maximum Spray Pressure (bar): 344

• Maximum Spray Pressure (kPa): 34400
• Maximum Spray Pressure (MPa): 34
• Maximum Spray Pressure (psi): 5000

• Maximum Working Pressure (bar): 331
• Maximum Working Pressure (kPa): 33100
• Maximum Working Pressure (MPa): 33
• Maximum Working Pressure (psi): 4800
• Measurin

GG 576205

XP SYSTEM, 2:1, 115/58, BF, CH, HS, JB

Graco 576205 XP70 Non-Hazardous Spray Package, Cart, 2:1 Mix Ratio, Hopper, Solvent Pump, Heaters, Junction Box, XTR Gun, 240V

Two-component spraying made easy and affordable. The Graco XP70 Plural-Component Sprayer is designed to pump, mix and atomize high to 100% solid coatings with superior results. In addition, the XP70's design allows you to gravity feed, which may eliminate the need for feed pumps, saving you money. When you upgrade from hand mixing, youll find that the XP70 provides excellent return on investment, by reducing material waste and by using less clean-up solvent. Flexible options for mix ratio, pressure and flow rate - choose the right system for the application. If you occasionally change materials, the Graco XP Sprayers are the right choice. That's because you can change the ratio by simply changing out one or two pump lowers. Available in 1:1, 1.5:1, 2:1, 2.5:1, 3:1 and 4:1 mix ratios.

• Reduced material waste
• No more throwing away unused mixed material at the end of the day
• Save money by using less clean-up solvent
• Easy to operate - minimal training required
• Reduced maintenance costs
• Rated for 7250 psi (500 bar, 50 MPa) to handle viscous materials and long hose lengths

• Series: XP70

• Air Inlet Size (in): 3/4
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPSM

• Applicator Type: Automatic Airless, Manual Airless

• Compatible Material: Protective Coatings, Primer, Epoxies, Polyurethane, Two-Component Coating, Solvents

• Component Type: Plural-Component
• Configuration: Cart Mount with 7 gallon (26.5 Liter) Hopper

• Fluid Inlet Size (in): 1-1/4
• Fluid Inlet Thread Gender: Male
• Fluid Inlet Thread Type: NPSM

• Fluid Outlet Size (in): 1/2
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT
• Flush Type: Solvent

• Hose Length (ft): 35
• Hose Length (m): 10.7

• Includes: Heaters, Solvent Flush Pump, Hoppers

• Material Application: Coatings, Paints, Primers

• Maximum Air Consumption (SCFM): 75 scfm/gpm at 100 psi
• Maximum Air Inlet Pressure (bar): 12.07
• Maximum Air Inlet Pressure (kPa): 1207
• Maximum Air Inlet Pressure (MPa): 1.21
• Maximum Air Inlet Pressure (psi): 175

• Maximum Cycle Rate (CPM): 40

• Maximum Flow Rate (cc/min): 6800

• Maximum Flow Rate (GPM): 1.8
• Maximum Flow Rate (L/min): 6.8

• Maximum Fluid Temperature ( degree C): 71
• Maximum Fluid Temperature ( degree F): 160
• Maximum Fluid Viscosity (cP): 20000

• Maximum Fluid Temperature ( degree C): 71
• Maximum Fluid Temperature ( degree F): 160
• Maximum Fluid Viscosity (cP): 20000

• Maximum Hose Length (ft): 300
• Maximum Hose Length (m): 91.4

• Maximum Operating Temperature ( degree C): 54
• Maximum Operating Temperature ( degree F): 130

• Maximum Spray Pressure (bar): 500

• Maximum Spray Pressure (kPa): 50000
• Maximum Spray Pressure (MPa): 50
• Maximum Spray Pressure (psi): 7250

• Maximum Working Pressure (bar): 500
• Maximum Working Pressure (kPa): 50000
• Maximum Working Pressure (MPa): 50
• Maximum Working Pressure (psi):

GG AC0500

PROMIX PD1K PROPORTIONER, SYS, AUTO

Graco AC0500 ProMix PD2K Automatic Proportioner, Standard, Control Module Only

100% Positive Displacement Technology for accurate mix ratios and consistent performance. Great for short pot life materials, the ProMix PD mixes the material close to the gun so the flush zone is significantly smaller. This allows for faster color changes, less material usage and disposal costs overall.

• Up to 80% reduction in flushing waste over the most efficient traditional proportioning systems
• Faster color changes and less material to flush mean less waste and less downtime
• Stalls under pressure for consistent, on-ratio results (within 1% accuracy)
• Field serviceable in less than 20 minutes - no need for costly factory rebuilds like gear pumps

• Model: ProMix
• Series: PD2K

• Air Inlet Size (cm): 0.9525
• Air Inlet Size (in): 3/8
• Air Inlet Size (mm): 9.525
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Applicator Type: Automatic

• Component Type: Single Component

• Flush Type: Solvent

• Frequency (Hz): 50/60

• Gun Activation: Automatic

• Material Type: Single Component

• Maximum Mix Ratio: 50:1
• Maximum Number of Colors: Up to 30

• Maximum Working Pressure (bar): 7
• Maximum Working Pressure (kPa): 700
• Maximum Working Pressure (MPa): 0.7
• Maximum Working Pressure (psi): 100
• Measuring Type: Meter

• Minimum Mix Ratio: 0.1:1

• Mix Accuracy (%): 1

• Number of Catalysts: Up to 4
• Number of Color Valves: N/A

• Number of Resin Colors: Up to 30

• Power Source: Electric

• Pressure Type: Low or High Pressure
• Proportioner Type: Automatic
• Proportioning Type: Automatic Electronic

GG AC1000

PROMIX PD2K PROPORTIONER, SYS, AUTO, LP

Graco AC1000 ProMix PD2K Automatic Proportioner, Standard, Low Pressure, 70 cc Resin Pump, 35 cc Catalyst Pump

100% Positive Displacement Technology for accurate mix ratios and consistent performance. Great for short pot life materials, the ProMix PD mixes the material close to the gun so the flush zone is significantly smaller. This allows for faster color changes, less material usage and disposal costs overall.

• Up to 80% reduction in flushing waste over the most efficient traditional proportioning systems
• Faster color changes and less material to flush mean less waste and less downtime
• Stalls under pressure for consistent, on-ratio results (within 1% accuracy)
• Field serviceable in less than 20 minutes - no need for costly factory rebuilds like gear pumps

• Model: ProMix
• Series: PD2K

• Air Inlet Size (cm): 0.9525
• Air Inlet Size (in): 3/8
• Air Inlet Size (mm): 9.525
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Applicator Type: Automatic

• Component Type: Two Component

• Flush Type: Solvent

• Frequency (Hz): 50/60

• Gun Activation: Automatic

• Material Type: Plural Component

• Maximum Mix Ratio: 50:1
• Maximum Number of Colors: Up to 30

• Maximum Working Pressure (bar): 7
• Maximum Working Pressure (kPa): 700
• Maximum Working Pressure (MPa): 0.7
• Maximum Working Pressure (psi): 100
• Measuring Type: Meter

• Minimum Mix Ratio: 0.1:1

• Mix Accuracy (%): 1

• Number of Catalysts: Up to 4
• Number of Color Valves: N/A

• Number of Resin Colors: Up to 30

• Power Source: Electric

• Pressure Type: Low Pressure
• Proportioner Type: Automatic
• Proportioning Type: Automatic Electronic

GG AC2000

PROMIX PD2K PROPORTIONER, SYS, AUTO, HP

Graco AC2000 ProMix PD2K Automatic Proportioner, Standard, High Pressure, 70 cc Resin Pump, 35 cc Catalyst Pump

100% Positive Displacement Technology for accurate mix ratios and consistent performance. Great for short pot life materials, the ProMix PD mixes the material close to the gun so the flush zone is significantly smaller. This allows for faster color changes, less material usage and disposal costs overall.

• Up to 80% reduction in flushing waste over the most efficient traditional proportioning systems
• Faster color changes and less material to flush mean less waste and less downtime
• Stalls under pressure for consistent, on-ratio results (within 1% accuracy)
• Field serviceable in less than 20 minutes - no need for costly factory rebuilds like gear pumps

• Model: ProMix
• Series: PD2K

• Air Inlet Size (cm): 0.9525
• Air Inlet Size (in): 3/8
• Air Inlet Size (mm): 9.525
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Applicator Type: Automatic

• Component Type: Two Component

• Flush Type: Solvent

• Frequency (Hz): 50/60

• Gun Activation: Automatic

• Material Type: Plural Component

• Maximum Mix Ratio: 50:1
• Maximum Number of Colors: Up to 30

• Maximum Working Pressure (bar): 7
• Maximum Working Pressure (kPa): 700
• Maximum Working Pressure (MPa): 0.7
• Maximum Working Pressure (psi): 100
• Measuring Type: Meter

• Minimum Mix Ratio: 0.1:1

• Mix Accuracy (%): 1

• Number of Catalysts: Up to 4
• Number of Color Valves: N/A

• Number of Resin Colors: Up to 30

• Power Source: Electric

• Pressure Type: High Pressure
• Proportioner Type: Automatic
• Proportioning Type: Automatic Electronic

GG AD120N

PROMIX 2KS PROPORTIONER AUTO

Graco AD120N ProMix 2KS Automatic Wall Panel System, EasyKey with LCD display, G3000 meter, 4 color valves and single catalyst

Easy to use electronic proportioner for a broad range of Solvent borne, waterborne, and acid catalyzed materials. The ProMix 2KS offers the highest degree of ratio assurance for superior quality on both manual and automatic applications. Efficient tracking and reporting along with effective color changes reduces wasted material.

• Optional flow control is cleanly integrated without incorporating a mixed material line meter. Pressure and flow loops provide fast step changes with superior closed loop control.
• Fluid manifold design reduces material volume and streamlines fluid porting for cleaner flushing
• Intrinsically safe fluid panels easily integrate into hazardous areas
• Advanced web interface provides consolidated system management and reporting

• Model: ProMix
• Series: 2KS

• Air Inlet Size (cm): 0.9525
• Air Inlet Size (in): 3/8
• Air Inlet Size (mm): 9.525
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Amperage (A): 2
• Applicator Type: Automatic

• Component Type: Two Component

• Fluid Inlet Size (cm): 0.635
• Fluid Inlet Size (in): 1/4
• Fluid Inlet Size (mm): 6.35
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (in): 1/4
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT
• Flush Type: Air/Solvent

• Frequency (Hz): 50/60

• Gun Activation: Automatic

• Material Type: Two Component

• Maximum Flow Rate (cc/min): 3790

• Maximum Flow Rate (GPM): 1
• Maximum Flow Rate (L/min): 3.79

• Maximum Fluid Viscosity (cP): 3000

• Maximum Fluid Viscosity (cP): 3000

• Maximum Mix Ratio: 50:1
• Maximum Number of Colors: Up to 12

• Maximum Working Pressure (bar): 275.8
• Maximum Working Pressure (kPa): 27580
• Maximum Working Pressure (MPa): 27.6
• Maximum Working Pressure (psi): 4000
• Measuring Type: Meter
• Meter Type: G3000

• Minimum Flow Rate (cc/min): 75
• Minimum Flow Rate (GPM): 0.02
• Minimum Flow Rate (L/min): 0.075

• Minimum Fluid Viscosity (cP): 20
• Minimum Mix Ratio: 0.1:1

• Mix Accuracy (%): 1

• Number of Catalysts: 1
• Number of Color Valves: 4 Valves
• Number of Colors: 4

• Number of Resin Colors: 4

• Power Source: Electric

• Proportioner Type: Automatic Wall
• Proportioning Type: Automatic Electronic

GG AD141N

GG AE100N

PROMIX 2KS PROPORTIONER AUTO SYSTEM

Graco AE100N ProMix 2KS Auto Wall Panel System, EasyKey, G3000 (A, B) Meter, Single Catalyst

Easy to use electronic proportioner for a broad range of Solvent borne, waterborne, and acid catalyzed materials. The ProMix 2KS offers the highest degree of ratio assurance for superior quality on both manual and automatic applications. Efficient tracking and reporting along with effective color changes reduces wasted material.

• Optional flow control is cleanly integrated without incorporating a mixed material line meter. Pressure and flow loops provide fast step changes with superior closed loop control.
• Fluid manifold design reduces material volume and streamlines fluid porting for cleaner flushing
• Intrinsically safe fluid panels easily integrate into hazardous areas
• Advanced web interface provides consolidated system management and reporting

• Model: ProMix
• Series: 2KS

• Air Inlet Size (cm): 0.9525
• Air Inlet Size (in): 3/8
• Air Inlet Size (mm): 9.525
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Amperage (A): 2
• Applicator Type: Automatic

• Component Type: Two Component

• Fluid Inlet Size (cm): 0.635
• Fluid Inlet Size (in): 1/4
• Fluid Inlet Size (mm): 6.35
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (in): 1/4
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT
• Flush Type: Air/Solvent

• Frequency (Hz): 50/60

• Gun Activation: Automatic

• Material Type: Two Component

• Maximum Flow Rate (cc/min): 3790

• Maximum Flow Rate (GPM): 1
• Maximum Flow Rate (L/min): 3.79

• Maximum Fluid Viscosity (cP): 3000

• Maximum Fluid Viscosity (cP): 3000

• Maximum Mix Ratio: 50:1
• Maximum Number of Colors: Up to 3

• Maximum Working Pressure (bar): 275.8
• Maximum Working Pressure (kPa): 27580
• Maximum Working Pressure (MPa): 27.6
• Maximum Working Pressure (psi): 4000
• Measuring Type: Meter
• Meter Type: G3000

• Minimum Flow Rate (cc/min): 75
• Minimum Flow Rate (GPM): 0.02
• Minimum Flow Rate (L/min): 0.075

• Minimum Fluid Viscosity (cP): 20
• Minimum Mix Ratio: 0.1:1

• Mix Accuracy (%): 1

• Number of Catalysts: 1
• Number of Color Valves: No Valves
• Number of Colors: 1

• Number of Resin Colors: Up to 30

• Power Source: Electric

• Proportioner Type: Automatic Wall
• Proportioning Type: Automatic Electronic

GG AHH144

REACTOR 2 H-40 SYSTEM, 230V, 20KW, ELITE, AP

Graco AHH144 Reactor 2 H-40 Elite Proportioner Package, Fusion AP Gun, (6) Heated Hoses with Xtreme-Wrap, 20 kW, 230 V, 3PH

Gracos hydraulic Reactor H-40 brings increased yield and high output spraying. Ideal for in-plant OEMs or applicators that spray at high volumes.

• What a hydraulic system can do for you:


  Dependability - robust, durable, longest life spray system

  Reduce downtime - allows for longer time in between required maintenance

  Increase daily productivity - capable of extremely high duty cycle

• Reactor Connect : Communication and Control at your Fingertips


  Control your Reactor using your phone

  Improve productivity and yield by optimizing spray parameters and never having to go back to your rig

  Monitor your rigs/crews using the multi-system dashboard

  Troubleshoot an issue quickly using real-time data

  Provide documentation to a customer

  Use reports to better manage your business

  Saves all your spray data to the cloud

  Utilize account management to better manage your equipment and crews

  Reactor Connect comes standard with all Reactor 2 model

• Advanced control technology


  Tracks, monitors and saves project data

  Data can be saved and downloaded onto a USB drive

  Stores up to 24 chemical recipes

  Drum level indicators

• Sacrificial surge protector


  Protects your electronics against excessive power spikes

• Three-year warranty


  Covers user display and control modules

  One of the best in the industry

• Model: Reactor 2
• Series: H-40
• Product Series: Elite

• Amperage (A): 95
• Application: Spray Foam
• Applicator Type: Manual

• Compatible Material: Plural Components

• Component Type: Two Component

• Flush Type: Solvent

• Frequency (Hz): 50/60

• Gun Type: Fusion AP

• Hose Length (ft): 50, 10
• Hose Length (m): 15.2, 3

• Hose Package: Multi-Hose
• Includes: Proportioner, Fusion AP Gun, Heated Hose with Scuff Guard, Heated Whip Hose, Graco Insite, Fluid Inlet Sensors

• Material Application: Polyurethane Foam

• Maximum Flow Rate (kg/min): 20.41
• Maximum Flow Rate (lb/min): 45

• Maximum Fluid Temperature ( degree C): 88
• Maximum Fluid Temperature ( degree F): 190

• Maximum Fluid Temperature ( degree C): 88
• Maximum Fluid Temperature ( degree F): 190

• Maximum Mix Ratio: 1:1

• Overall Depth (cm): 53
• Overall Depth (in): 20.88
• Overall Depth (mm): 530

• Overall Height (cm): 160.8
• Overall Height (in): 63.3
• Overall Height (mm): 1608
• Overall Width (cm): 83.7
• Overall Width (in): 32.96
• Overall Width (mm): 837

• Phase: 3

• Power Rating (HP): 26.82
• Power Rating (kW): 20
• Power Rating (W): 20000
• Power Source: Hydraulic

• Pressure Type: High Pressure
• Product Type: Plural Component
