GG 262381
PROCONTROL 1KS PROPORTIONER, PROMX, REMTE
Graco 262381 ProControl 1KS with G3000 Meter
Maintain a closed loop flow control system for a superior finish with the same proven technology as the ProMix 2KS
- Single Component Flow Control
- Integrated Flushing
- Optional Color Change Modules
- Model: ProControl
- Series: 1KS
- Air Inlet Size (cm): 0.9525
- Air Inlet Size (in): 3/8
- Air Inlet Size (mm): 9.525
- Air Inlet Thread Gender: Female
- Air Inlet Thread Type: NPT
- Fluid Inlet Size (cm): 0.635
- Fluid Inlet Size (in): 1/4
- Fluid Inlet Size (mm): 6.35
- Fluid Inlet Thread Gender: Female
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (in): 1/4
- Fluid Outlet Thread Gender: Female
- Fluid Outlet Thread Type: NPT
- Includes: ProControl 1KS Module, G3000 Meter
- Maximum Air Inlet Pressure (bar): 6.9
- Maximum Air Inlet Pressure (kPa): 690
- Maximum Air Inlet Pressure (psi): 100
- Maximum Flow Rate (cc/min): 3790
- Maximum Flow Rate (GPM): 1
- Maximum Flow Rate (L/min): 3.79
- Maximum Fluid Viscosity (cP): 5000
- Maximum Fluid Viscosity (cP): 5000
- Maximum Number of Colors: Up to 30
- Maximum Operating Temperature ( degree C): 50
- Maximum Operating Temperature ( degree F): 122
- Maximum Working Pressure (bar): 275.8
- Maximum Working Pressure (kPa): 27580
- Maximum Working Pressure (MPa): 27.6
- Maximum Working Pressure (psi): 4000
- Minimum Flow Rate (cc/min): 75
- Minimum Flow Rate (GPM): 0.02
- Minimum Flow Rate (L/min): 0.075
- Minimum Fluid Viscosity (cP): 20
