GRACO INC. S10595
Reactor Heated Hose, 25 ft, 3/8 w/o Cable
GG 261328
REACTOR HEATED HOSE, 25', 3/8, W/O CABLE
Graco 261328 25 ft (7.6 m) Heated 2 Component Low Pressure Hose with 3/8 in (9.5 mm) Inside Diameter and Ground Wire
Graco's heated hoses are designed specifically for use with Reactor Equipment. Hoses are a key component to the total system, making it important to achieve accurate and uniform heating for the best application possible.
Application: For Reactor proportioners.- New multi-strand copper heating element has greatly increased hose quality:
- Copper-heated hoses are designed specifically for use with Graco proportioners
- Covered with proprietary butyl cover for protection against moisture sensitive isocyanate
- Different fitting sizes on the isocyanate and resin hoses prevent accidentally connecting the wrong hoses together
- Hoses use custom designed splice kit to electrically connect hoses without having to run copper under the fittings
- Helix-design whip hose uses braided copper wires for added flexibility and longer life
Provides 10-times* the flex life compared to previous flat copper heating element
Long-term, even heating without hot spots
Backwards compatible with existing Reactor heated hoses
- Model: Reactor Heated Hoses
- Series: No Scuff
- Hose Heating Type: External Heated
- Hose Length (ft): 25
- Hose Length (m): 7.6
- Maximum Working Pressure (bar): 138
- Maximum Working Pressure (kPa): 13800
- Maximum Working Pressure (MPa): 13.8
- Maximum Working Pressure (psi): 2000
Hose, Heated, 1/4x3/8, Dual Cable
GG 261337
REACTOR HEATED HOSE, 1/4X3/8, DUAL CABLE
Graco 261337 50 ft (15 m) Heated Custom Application 2 Component Hose with 3/8 (9.5 mm) and 1/4 in (6.3 mm) Inside Diameter
Graco's heated hoses are designed specifically for use with Reactor Equipment. Hoses are a key component to the total system, making it important to achieve accurate and uniform heating for the best application possible.
Application: For Reactor proportioners.- New multi-strand copper heating element has greatly increased hose quality:
- Copper-heated hoses are designed specifically for use with Graco proportioners
- Covered with proprietary butyl cover for protection against moisture sensitive isocyanate
- Different fitting sizes on the isocyanate and resin hoses prevent accidentally connecting the wrong hoses together
- Hoses use custom designed splice kit to electrically connect hoses without having to run copper under the fittings
- Helix-design whip hose uses braided copper wires for added flexibility and longer life
Provides 10-times* the flex life compared to previous flat copper heating element
Long-term, even heating without hot spots
Backwards compatible with existing Reactor heated hoses
- Model: Reactor Heated Hoses
- Series: Specialty
- For Use With: Plural Component Proportioners
- Hose Inside Diameter (in): 1/4
- Hose Inside Diameter (mm): 6.35
- Hose Length (ft): 50
- Hose Length (m): 15.2
- Maximum Working Pressure (bar): 241
- Maximum Working Pressure (kPa): 24100
- Maximum Working Pressure (MPa): 24.1
- Maximum Working Pressure (psi): 3500
Linedriver Module, 160Cc
GG 262004
LINEDRIVER MODULE, 160CC
Graco 262004 LineDriver Ride-On Attachment
Why walk when you can ride? Graco LineDriver Systems provide the most innovative, user-friendly ride-on systems in the industry. The LineDriver is the industry standard ride-on system that will help you maximize productivity on any striping, thermoplastic and scarifying application.
- FlexBeam LED Light System
LED light for improved brightness with long life and less amp draw
Retractable, breakaway design prevents damage and keeps you striping
- Patented Dual Foot Pedal System
For forward and reverse
Easily move between jobs without having to push
- ProStart Engine Starting System
Easy Starting
Up to 50% less pulling effort to start the engine - no more broken recoils
Outperforms manual pull and electric start systems when the weather starts turning cooler
- Cool-Comfort Seat
Gray color stays cool in direct sunlight
High-back seat for added support
Extra padding for all-day comfort
- Model: LineDriver
- Engine Brand: Honda
- Engine Model: GX Engine
- For Use With: GrindLazer, ThermoLazer 300TC, ThermoLazer ProMelt, LineLazer 130HS, LineLazer ES 1000, LineLazer V 200HS, LineLazer V 250DC, LineLazer V 250SPS, LineLazer V 3900, LineLazer V 5900
- Fuel Tank Capacity (gal): 0.95
- Fuel Tank Capacity (L): 3.6
- Maximum Operating Speed (km/h): 16
- Maximum Operating Speed (mph): 10
- Maximum Reverse Speed (km/h): 10
- Maximum Reverse Speed (mph): 6
- Power Rating (cc): 160
- Power Rating (HP): 5.5
- Power Rating (kW): 4.1
Linedriver HD Ride - On Attachment
GG 262005
LINEDRIVER MODULE, HD 200CC
Graco 262005 LineDriver HD Ride-On Attachment
Why walk when you can ride? Graco LineDriver Systems provide the most innovative, user-friendly ride-on systems in the industry. The LineDriver HD provides the higher power and performance you need to maximize your productivity on any striping, thermoplastic and scarifying application.
- FlexBeam LED Light System
LED light for improved brightness with long life and less amp draw
Retractable, breakaway design prevents damage and keeps you striping
- Patented Dual Foot Pedal System
For forward and reverse
Easily move between jobs without having to push
- ProStart Engine Starting System
Easy Starting
Up to 50% less pulling effort to start the engine - no more broken recoils
Outperforms manual pull and electric start systems when the weather starts turning cooler
- Cool-Comfort Seat
Gray color stays cool in direct sunlight
High-back seat for added support
Extra padding for all-day comfort
- Model: LineDriver
- Series: HD
- Engine Brand: Honda
- Engine Model: GX Engine
- For Use With: LineLazer, GrindLazer, ThermoLazer
- Fuel Tank Capacity (gal): 0.95
- Fuel Tank Capacity (L): 3.6
- Maximum Operating Speed (km/h): 16
- Maximum Operating Speed (mph): 10
- Maximum Reverse Speed (km/h): 10
- Maximum Reverse Speed (mph): 6
- Power Rating (cc): 200
- Power Rating (HP): 6.5
Hose, A, 5 ft, 1/4in, Moisture-Lok, SS
GG 262236
Hose, A, 5 ft, 1/4in, Moisture-Lok, SS
Hose, A, 25 ft, 1/4in, Moisture-Lok, SS
GG 262240
Hose, A, 25 ft, 1/4in, Moisture-Lok, SS
Hose, B, 25 ft, 1/2in Moisture-Lok, SS
GG 262257
Hose, B, 25 ft, 1/2in Moisture-Lok, SS
Proportioner, Promi, Remte, 1KS
GG 262381
PROCONTROL 1KS PROPORTIONER, PROMX, REMTE
Graco 262381 ProControl 1KS with G3000 Meter
Maintain a closed loop flow control system for a superior finish with the same proven technology as the ProMix 2KS
- Single Component Flow Control
- Integrated Flushing
- Optional Color Change Modules
- Model: ProControl
- Series: 1KS
- Air Inlet Size (cm): 0.9525
- Air Inlet Size (in): 3/8
- Air Inlet Size (mm): 9.525
- Air Inlet Thread Gender: Female
- Air Inlet Thread Type: NPT
- Amperage (A): 2
- Fluid Inlet Size (cm): 0.635
- Fluid Inlet Size (in): 1/4
- Fluid Inlet Size (mm): 6.35
- Fluid Inlet Thread Gender: Female
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (in): 1/4
- Fluid Outlet Thread Gender: Female
- Fluid Outlet Thread Type: NPT
- Frequency (Hz): 50/60
- Includes: ProControl 1KS Module, G3000 Meter
- Maximum Air Inlet Pressure (bar): 6.9
- Maximum Air Inlet Pressure (kPa): 690
- Maximum Air Inlet Pressure (psi): 100
- Maximum Flow Rate (cc/min): 3790
- Maximum Flow Rate (GPM): 1
- Maximum Flow Rate (L/min): 3.79
- Maximum Fluid Viscosity (cP): 5000
- Maximum Fluid Viscosity (cP): 5000
- Maximum Number of Colors: Up to 30
- Maximum Operating Temperature ( degree C): 50
- Maximum Operating Temperature ( degree F): 122
- Maximum Working Pressure (bar): 275.8
- Maximum Working Pressure (kPa): 27580
- Maximum Working Pressure (MPa): 27.6
- Maximum Working Pressure (psi): 4000
- Minimum Flow Rate (cc/min): 75
- Minimum Flow Rate (GPM): 0.02
- Minimum Flow Rate (L/min): 0.075
- Minimum Fluid Viscosity (cP): 20
Manifold, Mix, Plural Component
GG 262398
MANIFOLD, MIX, PLURAL COMPONENT
Graco 262398 Fluid Mix Manifold for ProMix 2KE Proportioner, Sequential Dosing
Manifold, Mix Plural Component
GG 262399
MANIFOLD, MIX PLURAL COMPONENT
- Compatible Material: Waterborne, Solventborne, High Solids, Xirallic, CARC, Metallics, Topcoats, Stains, Varnish, UV Coating
Reactor A-25 Bare Proportioner
GG 262572
REACTOR A-25 PROPORTIONER, BARE
Graco 262572 Reactor A-25 Bare Proportioner
The Reactor A-25 is a Graco-engineered spray foam proportioner that gives you the reliability you expect on the jobsite. It maintains consistent temperature control, even when you're spraying at maximum flow rates - resulting in better quality foam.
Application: For spraying foam insulation - applies up to 25 lb (11.4 kg) per minute.- Maintains temperature setpoints for better yield
- Maintains consistent output pressure for uniform spray pattern
- Easy to operate and maintain
- DataTrak Control
- Resettable counter tracks material usage
- Three Heat Zones
- Three independent heat zones - ISO, resin and hose heat
- Provide accurate heat control for reliable spraying to handle different chemical viscosities
- Digital temperature controls
- Recirculation Manifold
- A quick, easy way to balance system pressures
- NXT Air Motor
- Low air consumption for increased efficiency
- Muffler provides low operating noise levels
- Air valve provides smooth and rapid changeover
- Quick Knockdown Lower Pumps
- For easy disassembly and maintenance
- ISO Pump Lube System
- Prevents isocyanate crystallization on the pump seal and shaft
- ISO Pump Lube System
- Prevents isocyanate crystallization on the pump seal and shaft
- Model: Reactor
- Series: A-25
- Air Inlet Size (cm): 1.27
- Air Inlet Size (in): 1/2
- Air Inlet Size (mm): 12.7
- Air Inlet Thread Gender: Female
- Air Inlet Thread Type: NPT
- Amperage (A): 18.5 @ 380 V ac (3-Phase WYE), 32 @ 230 V ac (3-Phase Delta), 40 @ 230 V ac (1-Phase)
- Application: Spray Foam
- Applicator Type: Manual
- Compatible Material: Plural-Component
- Component A Inlet Size (in): 3/4
- Component A Inlet Size (mm): 19.05
- Component A Thread Gender: Female
- Component A Thread Type: NPT
- Component B Inlet Size (in): 3/4
- Component B Inlet Size (mm): 19.05
- Component B Thread Gender: Female
- Component B Thread Type: NPT
- Component Type: Two Component
- Flush Type: Solvent
- Frequency (Hz): 50/60
- Gun Type: No Gun
- Includes: Proportioner, Heated Hose
- Material Application: Polyurethane Foam
- Maximum Air Consumption (SCFM): 28 scfm at 1500 psi
- Maximum Air Inlet Pressure (bar): 8.62
- Maximum Air Inlet Pressure (kPa): 862
- Maximum Air Inlet Pressure (psi): 125
- Maximum Flow Rate (kg/min): 11.34
- Maximum Flow Rate (lb/min): 25
- Maximum Fluid Temperature ( degree C): 88
- Maximum Fluid Temperature ( degree F): 190
- Maximum Fluid Viscosity (cP): 1500
- Maximum Fluid Temperature ( degree C): 88
- Maximum Fluid Temperature ( degree F): 190
- Maximum Fluid Viscosity (cP): 1500
- Maximum Hose Length (ft): 210
- Maximum Hose Length (m): 64
- Maximum Mix Ratio: 1:1
- Maximum Working Pressure (bar): 138
- Maximum Working Pressure (kPa): 13800
- Maximum Working Pressure (MPa): 14
- Maximum Working Pressure (psi): 2000
- Minimum Fluid Viscosity (cP): 250
- Overall Depth (cm): 62.2
Reactor Proportioner, A-25, Wheels, and Datatrak
GG 262614
REACTOR A-25 PROPORTIONER, WHEELS, CYCLE COUNT
Graco 262614 Reactor A-25 Proportioner with Wheels, DataTrak
The Reactor A-25 is a Graco-engineered spray foam proportioner that gives you the reliability you expect on the jobsite. It maintains consistent temperature control, even when youre spraying at maximum flow rates - resulting in better quality foam.
- Maintains temperature setpoints for better yield
- Maintains consistent output pressure for uniform spray pattern
- Easy-to-service fluid section reduces maintenance and increases productivity
- DataTrak Control
Resettable counter tracks material usage
- Three Heat Zones
- Recirculation Manifold
A quick, easy way to balance system pressures
- NXT Air Motor
- Quick Knockdown Lower Pumps
For easy disassembly and maintenance
- ISO Pump Lube System
Prevents isocyanate crystallization on the pump seal and shaft
- ISO Pump Lube System
Prevents isocyanate crystallization on the pump seal and shaft
Low air consumption for increased efficiency
Muffler provides low operating noise levels
Air valve provides smooth and rapid changeover
- Model: Reactor
- Series: A-25
- Air Inlet Size (cm): 1.27
- Air Inlet Size (in): 1/2
- Air Inlet Size (mm): 12.7
- Air Inlet Thread Gender: Female
- Air Inlet Thread Type: NPT
- Amperage (A): 18.5 @ 380 V ac (3-Phase WYE), 32 @ 230 V ac (3-Phase Delta), 40 @ 230 V ac (1-Phase)
- Application: Spray Foam
- Applicator Type: Manual
- Compatible Material: Plural Components
- Component A Inlet Size (in): 3/4
- Component A Inlet Size (mm): 19.05
- Component A Thread Gender: Female
- Component A Thread Type: NPT
- Component B Inlet Size (in): 3/4
- Component B Inlet Size (mm): 19.05
- Component B Thread Gender: Female
- Component B Thread Type: NPT
- Component Type: Two Component
- Flush Type: Solvent
- Frequency (Hz): 50/60
- Gun Type: No Gun
- Includes: Proportioner, Heated Hose, Wheels, DataTrak
- Material Application: Polyurethane Foam
- Maximum Air Consumption (SCFM): 28 scfm at 1500 psi
- Maximum Air Inlet Pressure (bar): 8.62
- Maximum Air Inlet Pressure (kPa): 862
- Maximum Air Inlet Pressure (MPa): 0.86
- Maximum Air Inlet Pressure (psi): 125
- Maximum Flow Rate (kg/min): 11.34
- Maximum Flow Rate (lb/min): 25
- Maximum Fluid Temperature ( degree C): 88
- Maximum Fluid Temperature ( degree F): 190
- Maximum Fluid Viscosity (cP): 1500
- Maximum Fluid Temperature ( degree C): 88
- Maximum Fluid Temperature ( degree F): 190
- Maximum Fluid Viscosity (cP): 1500
- Maximum Hose Length (ft): 210
- Maximum Hose Length (m): 64
- Maximum Mix Ratio: 1:1
- Maximum Working Pressure (bar): 138
- Maximum Working
- Quick Knockdown Lower Pumps
Three independent heat zones - ISO, resin and hose heat
Provide accurate heat control for reliable spraying to handle different chemical viscosities
Digital temperature controls
- Recirculation Manifold
Kit, Air Cap, Horizontal
GG 262700
KIT,AIR CAP,HORIZONTAL
Graco 262700 Horizontal Air Cap Kit
KIT INCLUDES: AIR CAP, ASM, HORIZ, EXTERNAL MIX [QTY. 1], KIT INCLUDES: AIR CAP, ASM, INTERNAL MIX [QTY. 1],
Magnum Sprayer, X7
GG 262805
MAGNUM SPRAYER, X7
Graco 262805 Magnum X7 Electric TrueAirless Sprayer
DIY homeowners and handymen will save time and money with the Magnum X7 with built-in cart. Tackle any interior project, exterior houses, fences and decks. The X7 supports a larger tip size for spraying heavier coatings and the convenient cart makes any painting project faster and easier.
- Hardened Stainless Steel Piston Pump - Delivers high pressure power to spray unthinned paints
- Flexible Suction Hose - Spray directly from 1 or 5 gallon paint container
- Convenient Cart - Easily move sprayer around on the job
- TrueAirless Spray Tip with SoftSpray Technology - greater control and less overspray with a wide range of coatings
- Power Flush Adapter - Connects to a garden hose for fast and easy cleaning
- PushPrime - Fast and reliable start-up every time
- Adjustable Pressure Control - Easy control of paint flow
- Model: Magnum
- Series: X7
- Product Series: Project
- Amperage (A): 9.0
- Compatible Tip Size (in): 0.009, 0.011, 0.013, 0.015, 0.017
- Engine Size (HP): 0.625
- Fluid Outlet Size (in): 1/4
- Fluid Outlet Size (mm): 6.35
- Fluid Outlet Thread Type: NPSM
- Frame Configuration: Cart
- Includes: SG2 Spray Gun, TrueAirless 515 Spray Tip, Spray Tip Guard, 1/4 in x 25 ft DuraFlex Hose, Pump Armor Storage Fluid (8 oz), Quick Start-Up Guide
- Inlet Paint Strainer: 35 Mesh Stainless Steel Screen
- Maximum Flow Rate (GPM): 0.31
- Maximum Flow Rate (L/min): 1.2
- Maximum Hose Length (ft): 100
- Maximum Hose Length (m): 30
- Maximum Tip Size (in): 0.017
- Maximum Tip Size Gun 1 (in): 0.017
- Maximum Working Pressure (bar): 207
- Maximum Working Pressure (kPa): 20700
- Maximum Working Pressure (MPa): 20.7
- Maximum Working Pressure (psi): 3000
- Minimum Generator Power (W): 2500
- Motor Type: Universal
- Number of Guns: 1
- Overall Height (cm): 94.0
- Overall Height (in): 37.0
- Overall Height (mm): 940
- Overall Length (cm): 49
- Overall Length (in): 19.3
- Overall Length (mm): 490
- Overall Width (cm): 38.9
- Overall Width (in): 15.3
- Overall Width (mm): 389
- Phase: 1
- Power Rating (HP): 0.625
- Power Rating (kW): 0.47
- Power Rating (W): 466
- Power Source: Electric
- Pressure Control Type: Adjustable
- Pump Rod Type: Hardened Stainless Steel
- Pump Sleeve Material: Stainless Steel
- Recommended Annual Usage (gal): 125
GB Gun, Spray
GG 262854
XHF GUN, SPRAY
Graco 262854 XHF Airless Spray Gun, XHD RAC Tip
Designed to spray high viscosity materials, the XHF Gun is rugged, reliable and easy to maintain.
Application: For epoxy intumescent fireproofing coatings- High-flow, high pressure gun
- Handles epoxy intumescent materials, high-viscosity coatings, fiber filled materials
- Reduced clogging means more productivity and uptime
- Applicator Type: Manual
- Compatible Material: Epoxy Intumescent Fireproofing
- Fluid Inlet Size (cm): 0.9525
- Fluid Inlet Size (in): 3/8
- Fluid Inlet Size (mm): 9.525
- Fluid Inlet Thread Gender: Male
- Fluid Inlet Thread Type: NPT
- Fluid Orifice Size (cm): 0.32
- Fluid Orifice Size (in): 0.125
- Fluid Orifice Size (mm): 3.2
- For Use With: Protective Coating High-Pressure Equipment
- Gun Activation: Manual
- Gun Included: 1
- Gun Type: Airless Gun
- Gun Weight (g): 720
- Gun Weight (kg): 0.72
- Gun Weight (lb): 1.6
- Gun Weight (oz): 25
- Includes: XHD RAC Guard, XHD429 SwitchTip
- Maximum Fluid Pressure (bar): 500
- Maximum Fluid Pressure (kPa): 50000
- Maximum Fluid Pressure (MPa): 50
- Maximum Fluid Pressure (psi): 7250
- Maximum Fluid Pressure (bar): 500
- Maximum Fluid Pressure (kPa): 50000
- Maximum Fluid Pressure (MPa): 50
- Maximum Fluid Pressure (psi): 7250
- Maximum Fluid Working Pressure (bar): 500
- Maximum Fluid Working Pressure (MPa): 50
- Maximum Fluid Working Pressure (psi): 7250
- Overall Height (cm): 17.8
- Overall Height (in): 7.0
- Overall Height (mm): 178
- Overall Length (cm): 21
- Overall Length (in): 8.25
- Overall Length (mm): 210
- Product Type: Spray Gun
- Purge Method: Liquid
G40 Gun, Assembly, Aa, Rac Tip
GG 262929
G40 GUN, ASSY, AA, RAC TIP
Graco 262929 G40 Air-Assisted Airless Gun
Designed to maximize efficiency and quality, G40 air-assist spray guns use the highest quality components for long lasting reliable performance. The AAF tip line is designed for soft spray and improved transfer efficiency.
- High quality air-assisted spraying in a variety of applications
- All tips have a ring to retain the tip in the aircap
- Designed to minimize wear of replacement parts
- Trigger pull force is ultra-light, reducing operator fatigue and muscle stress
- Model: G40
- Air Inlet Size (cm): 0.635
- Air Inlet Size (in): 1/4
- Air Inlet Size (mm): 6.35
- Air Inlet Thread Type: NPSM
- Applicator Type: Manual
- Bleed Type: Non-Bleeder
- Compatible Material: Lacquer, Latex, Plural Component Materials, Polyurethane, Solvent borne, Urethane, UV Coating, Varnish, Waterborne
- Feed Type: Pressure Feed
- Gun Activation: Manual
- Gun Included: 1
- Gun Type: Air-Assisted Gun
- Gun Weight (g): 16
- Gun Weight (oz): 16
- Includes: RAC X FF LP Spray Tip
- Maximum Air Inlet Pressure (bar): 7
- Maximum Air Inlet Pressure (kPa): 700
- Maximum Air Inlet Pressure (MPa): 0.7
- Maximum Air Inlet Pressure (psi): 100
- Maximum Air Pressure (bar): 7
- Maximum Air Pressure (kPa): 700
- Maximum Air Pressure (MPa): 0.7
- Maximum Air Pressure (psi): 100
- Maximum Fluid Pressure (bar): 280
- Maximum Fluid Pressure (kPa): 28000
- Maximum Fluid Pressure (MPa): 28.0
- Maximum Fluid Pressure (psi): 4000
- Maximum Fluid Temperature ( degree C): 43
- Maximum Fluid Temperature ( degree F): 110
- Maximum Fluid Pressure (bar): 280
- Maximum Fluid Pressure (kPa): 28000
- Maximum Fluid Pressure (MPa): 28.0
- Maximum Fluid Pressure (psi): 4000
- Maximum Fluid Temperature ( degree C): 43
- Maximum Fluid Temperature ( degree F): 110
- Minimum Flow Rate @ PSI (oz/min): 5
- Product Type: Spray Gun
Kit, Accy, Air Fltr/Reg. 3/4Npt
GG 246948
KIT, ACCY, AIR FLTR/REG. 3/4NPT
Graco 246948 Regulator / Filter Assembly 3/4" npt(f) (19.5 mm) for Husky 3300 pump
Application: For use with Husky 3275 Pumps.3/4 NPT
250 psi Working Pressure
- Air Inlet Size (cm): 1.905
- Air Inlet Size (in): 3/4
- Air Inlet Size (mm): 19.05
- Air Inlet Thread Gender: Female
- Air Inlet Thread Type: NPT
- Air Outlet Size (cm): 1.905
- Air Outlet Size (in): 3/4
- Air Outlet Size (mm): 19.05
- Air Outlet Thread Gender: Female
- Air Outlet Thread Type: NPT
Manifold, Assembly, Cc, 6 Valve, Lp
GG 24Y944
Manifold, Assembly, Cc, 6 Valve, Lp
Manifold, Assembly, Cc, 9 Valve, Lp
GG 24Y950
Manifold, Assembly, Cc, 9 Valve, Lp
Payment options
