G3 Max Full Featured Grease Lubrication Pump, 90-240 VAC, 16 Liter Reservoir

GG 96G562

PUMP, G3-G-ACM2-160L00-RMCD0A0VP

Graco 96G562 G3 Max Full-Featured Grease Lubrication Pump, 90-240 VAC, 16 liter reservoir with low level paddle, DIN Form-A connectors for power input and alarm relay output, M12 connectors for vent valve, one pressure sensor (analog or digital), machine count and one cycle switch

Extend machinery life, reduce operating costs and increase productivity! The G3 Max has a flexible design that works with injector-based or series progressive systems. The ultimate in flexibility - for a high value, custom fit on your application.

• LCD screen provides detailed view of pump status and operation. Alarm screens include troubleshooting tips and a QR code links to the G3 Education Center for Training-on-Demand. Bright LEDs with nearly 180 degree viewing angle allow users to confirm pump status from a distance.
• Low level indicator provides low alert and shut-down alarm
• Manual run initiates lubrication on-demand (remote option also available)
• Pre-lube function can initiate lube cycle on start-up
• One pump works with either a cycle switch or pressure sensor for custom installations and feedback. Cycle input is compatible with PNP, NPN, and dry contact switches, Pressure input is compatible with analog transducers/sensors and normally open switches.
• Machine count input - ideally suited for inconsistently used equipment
• DIN alarm relay connection can connect to a stack light to indicate pump status from a distance.
• Compatible with Normally Open Vent Valves - simplifies pump programming, with the added benefit of venting whenever the pump is not running.

• Model: G3
• Series: Max

• Compatible Material: Grease
• Compatible Metering Device: Series Progressive, Single Line Parallel

• Display Type: LCD

• Fluid Outlet Thread Type: NPSF

• For Use With: Injector-Based Systems, Series Progressive Systems

• Includes: Wiper Arm, Low Level Paddle, DIN Form-A connectors for power input and alarm relay output, M12 connectors for vent valve, one pressure sensor (analog or digital), machine count and one cycle switch

• Maximum Flow Rate (ci/min): 0.25

• Maximum NLGI Grade: #2

• Maximum Operating Temperature (°C): 70
• Maximum Operating Temperature (°F): 158

• Maximum Voltage (V ac): 264

• Maximum Working Pressure (bar): 351.6
• Maximum Working Pressure (psi): 5100

• Minimum Voltage (V ac): 88

• Number of Pump Elements: Up to 3

• Phase: 1

• Power Type: Electric
