GRACO INC. S10595

GG 24D238

GG 24D240

GG 24D299

GG 24D280

KIT,NEEDLE AND NOZZLE

Graco 24D280 Needle/Nozzle Kit for AirPro EFX LVMP Guns with 0.043 inch (1.1 mm) Nozzle

• Compatible Material: Motor Oil, Gear Oil, Automatic Transmission Fluid, Oil

GG 24D302

GG 24D303

KIT,NEEDLE,NOZZLE,.028,HVLP

Graco 24D303 Needle/Nozzle Kit for AirPro EFX HiTEch Guns with 0.028 inch (0.7 mm) Nozzle

GG 24D314

GG 24D320

GG 24D322

GG 24D436

GG 24D437

GG 24D438

KIT,G15 RETAINING RING

Graco 24D438 G15 Spray Gun Retaining Ring Kit

GG 24D439

KIT,G40 RETAINING RING

Graco 24D439 G40 Spray Gun Retaining Ring/ Tip Guard Kit. Includes retaining ring with guard, PTFE O-Ring, and PTFE Washer

GG 24D472

AIRPRO GUN, PRESSURE, CONV

Graco 24D472 AirPro Air Spray Pressure Feed Gun, Conventional, 0.042 inch (1.1 mm) Nozzle, for Automotive Applications

The AirPro air spray gun delivers exceptional spray performance while addressing your environmental and operator concerns - whether you're a custom shop or a high volume manufacturing facility.

• Even material distribution through the spray pattern for optimum coverage
• Improved transfer efficiency through reduced air consumption
• Enhanced atomization through material-specific aircaps
• Ultra-light trigger pull reduces operator muscle stress
• Ergonomic gun handle provides a comfortable grip
• Rounded control knobs for operator comfort
• Optimize spray performance with our cutting edge aircap and nozzle design
• Choose from a wide range of gun models to meet the needs of your specific application

• Model: AirPro

• Air Inlet Size (cm): 0.635
• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35
• Air Inlet Thread Type: NPSM

• Application: Automotive
• Applicator Type: Manual

• Bleed Type: Non-Bleeder

• Compatible Material: Adhesives, Ceramics, Fast-Set, High Solids, Sealants, Solvent borne, Stains, UV Coating, Waterborne

• Feed Type: Pressure Feed

• Fluid Inlet Size (cm): 0.9525
• Fluid Inlet Size (in): 3/8
• Fluid Inlet Size (mm): 9.525
• Fluid Inlet Thread Type: NPSM
• Fluid Orifice Size (cm): 0.11
• Fluid Orifice Size (in): 0.042
• Fluid Orifice Size (mm): 1.1

• Gun Activation: Manual
• Gun Included: 1
• Gun Type: Conventional Gun
• Gun Weight (g): 410

• Includes: Air Cap, Needle Assembly, Nozzle, Tool Kit

• Maximum Air Inlet Pressure (bar): 7
• Maximum Air Inlet Pressure (kPa): 700
• Maximum Air Inlet Pressure (MPa): 0.7
• Maximum Air Inlet Pressure (psi): 100
• Maximum Air Pressure (bar): 7

• Maximum Air Pressure (kPa): 700
• Maximum Air Pressure (MPa): 0.7
• Maximum Air Pressure (psi): 100

• Maximum Fluid Pressure (bar): 21
• Maximum Fluid Pressure (kPa): 2100
• Maximum Fluid Pressure (MPa): 2.1
• Maximum Fluid Pressure (psi): 300
• Maximum Fluid Temperature ( degree C): 43
• Maximum Fluid Temperature ( degree F): 109

• Maximum Fluid Pressure (bar): 21
• Maximum Fluid Pressure (kPa): 2100
• Maximum Fluid Pressure (MPa): 2.1
• Maximum Fluid Pressure (psi): 300
• Maximum Fluid Temperature ( degree C): 43
• Maximum Fluid Temperature ( degree F): 109

• Product Type: Spray Gun

GG 24D500

APPLICATOR,MD2,1:1,SOFT,CS

Graco 24D500 MD2 Valve Applicator Kit (1:1 with Soft Seats) with Stainless Steel Chemical Connection Kit

• Adjustable Snuff-back Control

  • Dispenses material only where you need it

• Independent Air Cylinder

  • Improves mean time to repair (MTTR)

• Chromex Shafts

  • Extends shaft life to better handle abrasive materials

  Grease Isolation Chamber

  • Ideal for moisture-sensitive materials
  • Accessible grease fittings for easy maintenance

• Adjustable Inlet Position

  • Flexibility during system installation
  • Minimizes dead spaces in fluid path

• All-SST Wetted Section

  • Maximizes material compatibility

• Two Nose Options

  • Customizes material mixing

• Minimizes maintenance time and costs while maximizing dispense time

• Designed with fewer parts and is easy to clean

• Streamlines maintenance and service

• Complete modular design adapts to different installation needs

• No unique tools required

• Model: MD2

GG 24D565

MODULE,TANK,75L,LV

GG 24D569

MODULE,TANK,38L,LV

GG 24D682

GG 24D570

MODULE,TANK,38L,AGT

GG 24E243

GL-43 INJECTOR, 3 INJECTOR MANIFOLD

Graco 24E243 GL-43 Carbon Steel Oil 3-Injector Manifold, 1/4 NPT

With its one piece design, Gracos GL-43 oil injector systems are easy to design, fast to set up and allow you to add or subtract lube points without having to redesign your lubrication system. Handles low viscosity lubricants.

• Longer lasting seal design for trouble-free performance
• Precision-honed components for reliable operation in challenging environments
• Adjustable output volume from .001 - .008 in cu (0.02 - 0.13 cm cu ) to custom fit the system to meet the needs of each lube point
• Operating pressures from 750-1000 psi (52-69 bar) for optimal performance with low viscosity lubricants (#10 weight minimum)
• Offered both as a stand-alone injector and replacement injector for manifold systems, allowing you to custom fit the injectors to your applications

• Model: GL-43

• Compatible Material: Oil

• Maximum Working Pressure (bar): 68.9
• Maximum Working Pressure (kPa): 6890
• Maximum Working Pressure (psi): 1000

• Minimum Working Pressure (bar): 51.7
• Minimum Working Pressure (kPa): 5170

• Minimum Working Pressure (psi): 750

GG 24D705

GG 24E212

GG 24D687

GG 24D678

GG 24E245

GL-43 INJECTOR, REPL, CS, 1/8" OD TUBE

Graco 24E245 GL-43 Carbon Steel Oil Replacement Injector, 1/8 in. Outlet

With its one piece design, Gracos GL-43 oil injector systems are easy to design, fast to set up and allow you to add or subtract lube points without having to redesign your lubrication system. Handles low viscosity lubricants.

• Longer lasting seal design for trouble-free performance
• Precision-honed components for reliable operation in challenging environments
• Adjustable output volume from .001 - .008 in cu (0.02 - 0.13 cm cu ) to custom fit the system to meet the needs of each lube point
• Operating pressures from 750-1000 psi (52-69 bar) for optimal performance with low viscosity lubricants (#10 weight minimum)
• Offered both as a stand-alone injector and replacement injector for manifold systems, allowing you to custom fit the injectors to your applications

• Model: GL-43

GG 24E166

HUSKY SYSTEM, EVACUATION, GM

Graco 24E166 Evacuation Pump Package - Husky 1050A (1 in) UL-Listed, Wall Mount

The Husky 1050 air-operated diaphragm pump features a stall-free low pulsation air valve which provides a smooth and rapid changeover. The one-piece center section eliminates leaks and reduces maintenance on Husky pumps when compared to other diaphragm pumps.

• Longer Diaphragm Life - Up to 5x longer diaphragm life for less maintenance and downtime
• Modular Air Valve - Stall-free, low pulsation operation provides smooth and rapid changeover
• One-Piece Center Section - Eliminates air leaks for more efficient operation
• Multiple Ports - Increased number of ports for installation flexibility
• Optional Features - DataTrak (Runaway protection and tracks material usage), Pulse Output (Cycle count capability)
• Spring loaded, externally serviceable pilot valves for faster change over and reduced pulsation
• 30% more efficient than the market leader
• 20% increase in fluid flow compared to the Husky 1040

• Model: Husky
• Series: 1050

• Fluid Inlet Size (cm): 2.5400
• Fluid Inlet Size (in): 1
• Fluid Inlet Size (mm): 25.4000
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (cm): 2.5400
• Fluid Outlet Size (in): 1
• Fluid Outlet Size (mm): 25.4000
• Fluid Outlet Thread Type: NPT

• Includes: 1050A Diaphragm Pump, Wall Bracket, Air Installation Kits, Fluid Installation Kits, Drum Style Adapter Kits

GG 24D827

GG 24E252

GG 24E244

GL-43 INJECTOR, 4 INJECTOR MANIFOLD

Graco 24E244 GL-43 Carbon Steel Oil 4-Injector Manifold, 1/4 NPT

With its one piece design, Gracos GL-43 oil injector systems are easy to design, fast to set up and allow you to add or subtract lube points without having to redesign your lubrication system. Handles low viscosity lubricants.

• Longer lasting seal design for trouble-free performance
• Precision-honed components for reliable operation in challenging environments
• Adjustable output volume from .001 - .008 in cu (0.02 - 0.13 cm cu ) to custom fit the system to meet the needs of each lube point
• Operating pressures from 750-1000 psi (52-69 bar) for optimal performance with low viscosity lubricants (#10 weight minimum)
• Offered both as a stand-alone injector and replacement injector for manifold systems, allowing you to custom fit the injectors to your applications

• Model: GL-43

• Compatible Material: Oil

• Maximum Working Pressure (bar): 68.9
• Maximum Working Pressure (kPa): 6890
• Maximum Working Pressure (psi): 1000

• Minimum Working Pressure (bar): 51.7
• Minimum Working Pressure (kPa): 5170

• Minimum Working Pressure (psi): 750

GG 24E242

GL-43 INJECTOR, 2 INJECTOR MANIFOLD

Graco 24E242 GL-43 Carbon Steel Oil 2-Injector Manifold, 1/4 NPT

With its one piece design, Gracos GL-43 oil injector systems are easy to design, fast to set up and allow you to add or subtract lube points without having to redesign your lubrication system. Handles low viscosity lubricants.

• Longer lasting seal design for trouble-free performance
• Precision-honed components for reliable operation in challenging environments
• Adjustable output volume from .001 - .008 in cu (0.02 - 0.13 cm cu ) to custom fit the system to meet the needs of each lube point
• Operating pressures from 750-1000 psi (52-69 bar) for optimal performance with low viscosity lubricants (#10 weight minimum)
• Offered both as a stand-alone injector and replacement injector for manifold systems, allowing you to custom fit the injectors to your applications

• Model: GL-43

• Compatible Material: Oil

• Maximum Working Pressure (bar): 68.9
• Maximum Working Pressure (kPa): 6890
• Maximum Working Pressure (psi): 1000

• Minimum Working Pressure (bar): 51.7
• Minimum Working Pressure (kPa): 5170

• Minimum Working Pressure (psi): 750

• Number of Injectors: 2

GG 24E248

KIT,SEAL,SPOOL,H.V.,PD44

KIT INCLUDES: PACKING, QUAD RING [QTY. 4 ], PACKING, O-RING [QTY. 4 ], PACKING, O-RING [QTY. 6 ], SEAL, POSIPAK, .250IDX.437OD, ZAP [QTY. 2], LUBRICANT, GREASE, KRYTOX [QTY. 1]

GG 24E391

GL-32 INJECTOR, 1 INJ MANIFOLD, SST

Graco 24E391 GL-32 Grease Injector, 304 Stainless Steel, 1-Injector Manifold, 1/4 NPT

With its one piece design, Gracos GL-32 grease injector systems are easy to design, fast to set up and allow you to add or subtract lube points without having to redesign your lubrication system. Easily handles up to NLGI #2 grease.

• Longer lasting seal design for trouble-free performance
• Precision-honed components for reliable operation in challenging environments
• Adjustable output volume from .001 - .008 in cu (0.02 - 0.13 cm cu ) to custom fit the system to meet the needs of each lube point
• Operating pressures from 1200 - 3500 psi (83 - 241 bar) for optimal performance with up to NLGI #2 grease
• Offered both as a stand-alone injector and replacement injector for manifold systems, allowing you to custom fit the injectors to your applications

• Model: GL-32
• Adjustable: Adjustable

• Application: On-Road Vehicles, Off-Road Equipment

• Compatible Material: Grease
• Compatible Metering Device: Single Line Parallel

• Cycle Indicator: Visual Pin

• Inlet Size (cm): 0.635
• Inlet Size (in): 1/4
• Inlet Size (mm): 6.35

• Inlet Thread Type: NPT

• Material: Stainless Steel

• Maximum NLGI Grade: #2

• Maximum Working Pressure (bar): 241
• Maximum Working Pressure (kPa): 24100
• Maximum Working Pressure (MPa): 24.1
• Maximum Working Pressure (psi): 3500

• Minimum Working Pressure (bar): 53
• Minimum Working Pressure (kPa): 5300
• Minimum Working Pressure (MPa): 5.3

• Minimum Working Pressure (psi): 750

• Outlet Size (cm): 0.32
• Outlet Size (in): 0.125
• Outlet Size (mm): 3.2

GG 24E308

GG 24E392

GL-32 INJECTOR, 2 INJ MANIFOLD, SST

Graco 24E392 GL-32 Grease Injector, 304 Stainless Steel, 2-Injector Manifold, 1/4 NPT

With its one piece design, Gracos GL-32 grease injector systems are easy to design, fast to set up and allow you to add or subtract lube points without having to redesign your lubrication system. Easily handles up to NLGI #2 grease.

• Longer lasting seal design for trouble-free performance
• Precision-honed components for reliable operation in challenging environments
• Adjustable output volume from .001 - .008 in cu (0.02 - 0.13 cm cu ) to custom fit the system to meet the needs of each lube point
• Operating pressures from 1200 - 3500 psi (83 - 241 bar) for optimal performance with up to NLGI #2 grease
• Offered both as a stand-alone injector and replacement injector for manifold systems, allowing you to custom fit the injectors to your applications

• Model: GL-32
• Adjustable: Adjustable

• Application: On-Road Vehicles, Off-Road Equipment

• Compatible Material: Grease
• Compatible Metering Device: Single Line Parallel

• Cycle Indicator: Visual Pin

• Inlet Size (cm): 0.635
• Inlet Size (in): 1/4
• Inlet Size (mm): 6.35

• Inlet Thread Type: NPT

• Material: Stainless Steel

• Maximum NLGI Grade: #2

• Maximum Working Pressure (bar): 241
• Maximum Working Pressure (kPa): 24100
• Maximum Working Pressure (MPa): 24.1
• Maximum Working Pressure (psi): 3500

• Minimum Working Pressure (bar): 53
• Minimum Working Pressure (kPa): 5300
• Minimum Working Pressure (MPa): 5.3

• Minimum Working Pressure (psi): 750

• Outlet Size (cm): 0.32
• Outlet Size (in): 0.125
• Outlet Size (mm): 3.2

GG 24E394

GL-32 INJECTOR, 4 INJ MANIFOLD, SST

Graco 24E394 GL-32 Grease Injector, 304 Stainless Steel, 4-Injector Manifold, 1/4 NPT

With its one piece design, Gracos GL-32 grease injector systems are easy to design, fast to set up and allow you to add or subtract lube points without having to redesign your lubrication system. Easily handles up to NLGI #2 grease.

• Longer lasting seal design for trouble-free performance
• Precision-honed components for reliable operation in challenging environments
• Adjustable output volume from .001 - .008 in cu (0.02 - 0.13 cm cu ) to custom fit the system to meet the needs of each lube point
• Operating pressures from 1200 - 3500 psi (83 - 241 bar) for optimal performance with up to NLGI #2 grease
• Offered both as a stand-alone injector and replacement injector for manifold systems, allowing you to custom fit the injectors to your applications

• Model: GL-32
• Adjustable: Adjustable

• Application: On-Road Vehicles, Off-Road Equipment

• Compatible Material: Grease
• Compatible Metering Device: Single Line Parallel

• Cycle Indicator: Visual Pin

• Inlet Size (cm): 0.635
• Inlet Size (in): 1/4
• Inlet Size (mm): 6.35

• Inlet Thread Type: NPT

• Material: Stainless Steel

• Maximum NLGI Grade: #2

• Maximum Working Pressure (bar): 241
• Maximum Working Pressure (kPa): 24100
• Maximum Working Pressure (MPa): 24.1
• Maximum Working Pressure (psi): 3500

• Minimum Working Pressure (bar): 53
• Minimum Working Pressure (kPa): 5300
• Minimum Working Pressure (MPa): 5.3

• Minimum Working Pressure (psi): 750

• Outlet Size (cm): 0.32
• Outlet Size (in): 0.125
• Outlet Size (mm): 3.2

GG 24D581

FUSION AP GUN, WIDE, RND 00

Graco 24D581 Wide Round Pattern Fusion Air-Purge Gun with 00 Mix Chamber

With long-life mix chamber and durable side seals, Fusion guns are designed to reduce maintenance and downtime, and provide a better mix.

• Easy air-blast tip cleaning reduces build-up and tip clogging.
• Long-lasting side seals means less downtime for maintenance
• Quick-release fluid housing - lets you easily change the mix chambers without tools
• Ergonomic handle

• Model: Fusion AP
• Series: Wide

• Air Inlet Size (cm): 0.635
• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35

• Compatible Material: Adhesives, Polyurethane, Polyurea, Polyurethane Coating, Spray Polyurethane Foam

• Fluid Orifice Size (cm): 0.074
• Fluid Orifice Size (in): 0.029
• Fluid Orifice Size (mm): 0.74

• Gun Type: Air Purge Gun
• Gun Weight (kg): 1.1
• Gun Weight (lb): 2.5

• Maximum Air Inlet Pressure (bar): 9
• Maximum Air Inlet Pressure (kPa): 900
• Maximum Air Inlet Pressure (MPa): 0.9
• Maximum Air Inlet Pressure (psi): 130
• Maximum Air Pressure (bar): 9

• Maximum Air Pressure (kPa): 900
• Maximum Air Pressure (MPa): 0.9
• Maximum Air Pressure (psi): 130

• Maximum Flow Rate @ PSI (lb/min): 50

• Maximum Fluid Pressure (bar): 245
• Maximum Fluid Pressure (kPa): 24500
• Maximum Fluid Pressure (MPa): 24.5
• Maximum Fluid Pressure (psi): 3500
• Maximum Fluid Temperature ( degree C): 94
• Maximum Fluid Temperature ( degree F): 200

• Maximum Fluid Pressure (bar): 245
• Maximum Fluid Pressure (kPa): 24500
• Maximum Fluid Pressure (MPa): 24.5
• Maximum Fluid Pressure (psi): 3500
• Maximum Fluid Temperature ( degree C): 94
• Maximum Fluid Temperature ( degree F): 200

• Minimum Air Inlet Pressure (bar): 5.6
• Minimum Air Inlet Pressure (kPa): 560
• Minimum Air Inlet Pressure (MPa): 0.56
• Minimum Air Inlet Pressure (psi): 80

• Mix Chamber: 00 (.029)

• Overall Height (cm): 20.6
• Overall Height (in): 8.1
• Overall Height (mm): 206
• Overall Length (cm): 19.1
• Overall Length (in): 7.5
• Overall Length (mm): 191
• Overall Width (cm): 8.4
• Overall Width (in): 3.3
• Overall Width (mm): 84

• Pattern Size (in): 15 in @ 24 in from target

GG 24E393

GL-32 INJECTOR, 3 INJ MANIFOLD, SST

Graco 24E393 GL-32 Grease Injector, 304 Stainless Steel, 3-Injector Manifold, 1/4 NPT

With its one piece design, Gracos GL-32 grease injector systems are easy to design, fast to set up and allow you to add or subtract lube points without having to redesign your lubrication system. Easily handles up to NLGI #2 grease.

• Longer lasting seal design for trouble-free performance
• Precision-honed components for reliable operation in challenging environments
• Adjustable output volume from .001 - .008 in cu (0.02 - 0.13 cm cu ) to custom fit the system to meet the needs of each lube point
• Operating pressures from 1200 - 3500 psi (83 - 241 bar) for optimal performance with up to NLGI #2 grease
• Offered both as a stand-alone injector and replacement injector for manifold systems, allowing you to custom fit the injectors to your applications

• Model: GL-32
• Adjustable: Adjustable

• Application: On-Road Vehicles, Off-Road Equipment

• Compatible Material: Grease
• Compatible Metering Device: Single Line Parallel

• Cycle Indicator: Visual Pin

• Inlet Size (cm): 0.635
• Inlet Size (in): 1/4
• Inlet Size (mm): 6.35

• Inlet Thread Type: NPT

• Material: Stainless Steel

• Maximum NLGI Grade: #2

• Maximum Working Pressure (bar): 241
• Maximum Working Pressure (kPa): 24100
• Maximum Working Pressure (MPa): 24.1
• Maximum Working Pressure (psi): 3500

• Minimum Working Pressure (bar): 53
• Minimum Working Pressure (kPa): 5300
• Minimum Working Pressure (MPa): 5.3

• Minimum Working Pressure (psi): 750

• Outlet Size (cm): 0.32
• Outlet Size (in): 0.125
• Outlet Size (mm): 3.2

GG 24D571

GG 24E427

KIT,FRNT HD,EXT MIX,VERT

Graco 24E427 External Mix Vertical Front Head Kit

KIT INCLUDES: HEAD, ASM, EXT MIX, VERT [QTY. 1], KIT INCLUDES: SEAL, NEEDLE, SEAT [QTY. 6 ],

GG 24E421

GG 24E415

GG 24E426

KIT,FRNT HD,EXT MIX,HORIZ

KIT INCLUDES: HEAD, ASM, EXT MIX, HORIZ [QTY. 1], KIT INCLUDES: HEAD, ASM, EXT MIX, VERT [QTY. 1],

GG 24D699

GG 24E417

KIT,NEEDLE ASSY

Graco 24E417 Complete Needle Assembly Kit

KIT INCLUDES: NEEDLE, ASSEMBLY [QTY. 1], KIT INCLUDES: PACKING, DISK [QTY. 1], RETAINER, PACKING [QTY. 1], CLIP, RETAINER [QTY. 1], O-RING, 111, VITON EXTREME [QTY. 1], RETAINER, PACKING [QTY. 1]

• Compatible Material: Gel Coat, Polyester Resin

GG 24E424

GG 24E429

GG 24E432

GG 24E428

GG 24E431

GG 24E247

GG 24E433

GG 24E436

KIT,NEEDLE,ASSY,6 PACK

Graco 24E436 6-Pack Needle Assembly Kit

KIT INCLUDES: NEEDLE, ASSEMBLY [QTY. 6 ], KIT INCLUDES: PACKING, O-RING [QTY. 6 ],

GG 24E442

GG 24E437

GG 24E447

GG 24E472

REGULATOR, FLUID, 3:1 RATIO

Graco 24E472 1:3 Precision Flow Fluid Pressure Regulator, 30 psi (2.0 bar) max pressure, black ratio spacer

Fluid regulators keep your system functioning more productively.

• Available with mechanical control or pneumatic control
• Suitable for fluids with low and high viscosities
• Models available with wetted parts made of stainless steel

• Actuation Type: Air

• Includes: Regulator Only
• Inlet Size (cm): 0.635
• Inlet Size (in): 1/4
• Inlet Size (mm): 6.35

• Inlet Thread Type: NPT

• Maximum Regulated Pressure (bar): 7
• Maximum Regulated Pressure (kPa): 700
• Maximum Regulated Pressure (MPa): 0.7
• Maximum Regulated Pressure (psi): 100

• Maximum Working Pressure (bar): 2.1
• Maximum Working Pressure (kPa): 210
• Maximum Working Pressure (MPa): 0.2
• Maximum Working Pressure (psi): 30

• Minimum Working Pressure (bar): 0.069
• Minimum Working Pressure (kg/cm 2): 0.07
• Minimum Working Pressure (kPa): 6.9

• Minimum Working Pressure (psi): 1

• Outlet Size (cm): 0.3175
• Outlet Size (in): 1/8
• Outlet Size (mm): 3.175

GG 24D703

KIT,AIR CAP, HITECH

Graco 24D703 Air Cap (Black), includes pin, for AirPro EFX HiTEch Guns, 0.028-0.039 inch (0.7-1.0 mm) Nozzle

GG 24E505

KIT,ORIFICE BLOCK

Graco 24E505 MD2 Orifice Adapter Kit without MD2 Valve

KIT INCLUDES: HOUSING, ORIFICE, ASSY [QTY. 1], KIT, ORIFICE BLOCK PLUG [QTY. 1], LUBRICANT, GREASE [QTY. 1], TOOL, WRENCH, HEX [QTY. 1]

GG 24E511

KIT, MOTOR, AIR

KIT INCLUDES: MOTOR, AIR [QTY. 1], PACKING, O-RING, PTFE [QTY. 1], FITTING, ELBOW, 1/8NPT, 3/8TUBE, BRAS [QTY. 1], PLUG, PIPE [QTY. 1], TUBE, POLYURETHANE, RND [QTY. 0.7 ]

GG 24E512

KIT, BLADE, CUTTER ASSY

KIT INCLUDES: BLADE, CUTTER ASSY [QTY. 1], TOOL, NUT DRIVER, 5/16 in. [QTY. 1], KIT, BLADE, CUTTER [QTY. 1], FITTING, ELBOW, 1/8NPT, 3/8TUBE, BRAS [QTY. 1], PLUG, PIPE [QTY. 1], TUBE, POLYURETHANE, RND [QTY. 0.7 ]

GG 24E566

GG 24E565

GG 24D642

GG 24E691

GG 24E746

GG 24E631

KIT, U-CUP, 100CC, BELLOWS

Graco 24E631 U-Cup Repair or Conversion Kit for Merkur Bellows LB100A and LB100B

GG 24E764

KIT, BELLOWS, 100-150CC

Graco 24E764 Standard Bellows Pumps for Merkur Bellows Pumps (100 cc and 150 cc)

GG 24E766

GG 24E504

KIT, REBUILD, LF REGULATOR

Graco 24E504 Low Pressure Regulator Seal Kit

GG 24E826

KIT,REPAIR,SHAFT,GEAR,PGM06

GG 24E769

GG 24E611

GG 24E503

GG 24E837

SANIFORCE PISTON PUMP, 6:1 DB ST

Graco 24E837 6:1 Ratio SaniForce Stubby Double Ball Piston Pump with PTFE Packings

Gracos SaniForce 6:1 quick knockdown piston pumps are constructed of 300 series stainless steel. The air motor improves serviceability, increases efficiency and offers a lower cost of ownership. Our sanitary piston pumps are ideal for most food-related, cosmetic and personal care applications.

• Most advanced air motor on the market
• Available in double-ball and priming piston designs
• Fluid transfer and supply of low to medium viscosity fluids
• FDA-Compliant Shroud:

  Easily removable FDA-compliant shroud to clean and access modular air valve - reducing downtime

  Quick knockdown lowers are made with 300 series stainless steel for long-lasting durability




  • Model: SaniForce
  • Application: Sanitary
  • Maximum Working Pressure (bar): 44.8
  • Maximum Working Pressure (kPa): 4480
  • Maximum Working Pressure (MPa): 4.5
  • Maximum Working Pressure (psi): 650
  • Pump Ratio: 6:1

GG 24E827

GG 24E862

GG 24E840

SANIFORCE PISTON PUMP, 6:1 DB DL

Graco 24E840 6:1 Ratio SaniForce Drum Length Double Ball Piston Pump with Bun-N, Nylon, Nitrile & Polychloroprene Packings

Gracos SaniForce 6:1 quick knockdown piston pumps are constructed of 300 series stainless steel. The air motor improves serviceability, increases efficiency and offers a lower cost of ownership. Our sanitary piston pumps are ideal for most food-related, cosmetic and personal care applications.

• Most advanced air motor on the market
• Available in double-ball and priming piston designs
• Fluid transfer and supply of low to medium viscosity fluids
• FDA-Compliant Shroud:

  Easily removable FDA-compliant shroud to clean and access modular air valve - reducing downtime

  Quick knockdown lowers are made with 300 series stainless steel for long-lasting durability




  • Model: SaniForce
  • Air Inlet Size (in): 0.5
  • Air Inlet Size (mm): 12.7
  • Air Inlet Thread Gender: Female
  • Air Inlet Thread Type: NPSM
  • Application: Sanitary
  • Compatible Material: Food, Personal Care
  • Fluid Outlet Size (in): 1-1/2
  • Fluid Outlet Size (mm): 38.1
  • For Use With: Food, Personal Care, & Pharmaceutical
  • Maximum Air Consumption (SCFM): 29
  • Maximum Air Inlet Pressure (bar): 6.9
  • Maximum Air Inlet Pressure (kPa): 690
  • Maximum Air Inlet Pressure (psi): 100
  • Maximum Continuous Cycle Rate (CPM): 60
  • Maximum Flow Rate (GPM): 4
  • Maximum Flow Rate (L/min): 15.14
  • Maximum Intermittent Cycle Rate (CPM): 60
  • Maximum Working Pressure (bar): 44.8
  • Maximum Working Pressure (kPa): 4480
  • Maximum Working Pressure (MPa): 4.5
  • Maximum Working Pressure (psi): 650
  • Portable: Non-Portable
  • Pump Ratio: 6:1

GG 24E898

GG 24E864

GG 24E876

DISPENSER,GX-16,NVH,STRAIGHT,BASIC

GG 24F081

PROMIX 2KE PROPORTIONER, SYSTEM, METER

Graco 24F081 ProMix 2KE Proportioner, electric, G3000 meter, 3 color/1 catalyst, screen reporting, for non-hazardous location

The ProMix 2KE is an entry level, compact, easy to use plural component system allowing you to mix on-demand for all spray technologies.

• Designed for multi-color, two component, in-booth applications
• Choose between pump-based or meter-based plural component systems with mix ratios up to 30:1
• Stay on ratio within predefined tolerance limits, down to plus/minus 02% with the pump version, plus/minus 01% with meter
• Easy-to-use LCD display allows you to track material usage, display mix ratio, program maintenance reminders operate, control operation functions and more

• Model: ProMix
• Series: 2KE

• Air Inlet Size (cm): 0.9525
• Air Inlet Size (in): 3/8
• Air Inlet Size (mm): 9.525
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Amperage (A): 2
• Applicator Type: Manual Air Spray, Air-Assist

• Component Type: Two Component

• Flush Type: Solvent

• Frequency (Hz): 50/60

• Gun Activation: Manual

• Includes: 2KE Meter-Based Proportioner, G3000 Meter, 3 Color, 1 Catalyst

• Material Type: Two Component

• Maximum Air Inlet Pressure (bar): 6.9
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Flow Rate (cc/min): 3790

• Maximum Flow Rate (GPM): 1
• Maximum Flow Rate (L/min): 3.79

• Maximum Fluid Viscosity (cP): 5000

• Maximum Fluid Viscosity (cP): 5000

• Maximum Mix Ratio: 30:1
• Maximum Number of Colors: Up to 3

• Maximum Operating Temperature ( degree C): 50
• Maximum Operating Temperature ( degree F): 122

• Maximum Working Pressure (bar): 206.8
• Maximum Working Pressure (kPa): 20680
• Maximum Working Pressure (MPa): 20.7
• Maximum Working Pressure (psi): 3000
• Measuring Type: Meter

• Minimum Flow Rate (cc/min): 75
• Minimum Flow Rate (GPM): 0.02
• Minimum Flow Rate (L/min): 0.075

• Minimum Fluid Viscosity (cP): 20
• Minimum Mix Ratio: 0.1:1

• Mix Accuracy (%): 1

• Number of Catalysts: 1
• Number of Color Valves: N/A
• Number of Colors: 3

• Number of Resin Colors: 3

• Overall Depth (cm): 37.6
• Overall Depth (in): 14.8
• Overall Depth (mm): 376

• Overall Height (cm): 91.7
• Overall Height (in): 36.1
• Overall Height (mm): 917
• Overall Width (cm): 51.1
• Overall Width (in): 20.1
• Overall Width (mm): 511

• Power Source: Electric

• Proportioning Type: Manual Electronic

• Pump Ratio: Meter only

GG 24F088

PROMIX 2KE PROPORTIONER, SYSTEM, PUMP

Graco 24F088 ProMix 2KE Proportioner, electric, 3:1 Air Spray Merkur pumps, screen reporting, for non-hazardous location

The ProMix 2KE is an entry level, compact, easy to use plural component system allowing you to mix on-demand for all spray technologies.

• Designed for multi-color, two component, in-booth applications
• Choose between pump-based or meter-based plural component systems with mix ratios up to 30:1
• Stay on ratio within predefined tolerance limits, down to plus/minus 02% with the pump version, plus/minus 01% with meter
• Easy-to-use LCD display allows you to track material usage, display mix ratio, program maintenance reminders operate, control operation functions and more

• Model: ProMix
• Series: 2KE

• Air Inlet Size (cm): 0.9525
• Air Inlet Size (in): 3/8
• Air Inlet Size (mm): 9.525
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Amperage (A): 2
• Applicator Type: Manual Air Spray

• Component Type: Two Component

• Flush Type: Solvent

• Frequency (Hz): 50/60

• Gun Activation: Manual

• Includes: Adaptor Plate, Air Motor, A-Lower, A-Tie Rod, B-Lower, B-Tie Rod, Coupling, Lower Adapter, TSL Reservoir

• Material Type: Two Component

• Maximum Air Inlet Pressure (bar): 6.9
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Fluid Viscosity (cP): 5000

• Maximum Fluid Viscosity (cP): 5000

• Maximum Mix Ratio: 30:1
• Maximum Number of Colors: Up to 3

• Maximum Working Pressure (bar): 21
• Maximum Working Pressure (kPa): 2100
• Maximum Working Pressure (MPa): 2.1
• Maximum Working Pressure (psi): 300
• Measuring Type: Pump

• Minimum Fluid Viscosity (cP): 20
• Minimum Mix Ratio: 0.1:1

• Mix Accuracy (%): 1

• Number of Catalysts: 1
• Number of Color Valves: N/A
• Number of Colors: 1

• Number of Resin Colors: 1

• Power Source: Electric

• Proportioning Type: Manual Electronic

• Pump Ratio: 3:1
• Pump Type: Air Spray

GG 24E915

GG 24F007

GG 24F092

PROMIX 2KE PROPORTIONER, SYSTEM, PUMP

Graco 24F092 ProMix 2KE Proportioner, electric, 3:1 Air Spray Merkur & Merkur Bellows pumps, screen reporting, for non-hazardous location

The ProMix 2KE is an entry level, compact, easy to use plural component system allowing you to mix on-demand for all spray technologies.

• Designed for multi-color, two component, in-booth applications
• Choose between pump-based or meter-based plural component systems with mix ratios up to 30:1
• Stay on ratio within predefined tolerance limits, down to plus/minus 02% with the pump version, plus/minus 01% with meter
• Easy-to-use LCD display allows you to track material usage, display mix ratio, program maintenance reminders operate, control operation functions and more

• Model: ProMix
• Series: 2KE

• Air Inlet Size (cm): 0.9525
• Air Inlet Size (in): 3/8
• Air Inlet Size (mm): 9.525
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Amperage (A): 2
• Applicator Type: Manual Air Spray

• Component Type: Two Component

• Flush Type: Solvent

• Frequency (Hz): 50/60

• Gun Activation: Manual

• Includes: Adaptor Plate, Air Motor, A-Lower, A-Tie Rod, B-Lower, B-Tie Rod, Coupling, Lower Adapter, TSL Reservoir

• Material Type: Two Component

• Maximum Air Inlet Pressure (bar): 6.9
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Fluid Viscosity (cP): 5000

• Maximum Fluid Viscosity (cP): 5000

• Maximum Mix Ratio: 30:1
• Maximum Number of Colors: Up to 3

• Maximum Working Pressure (bar): 21
• Maximum Working Pressure (kPa): 2100
• Maximum Working Pressure (MPa): 2.1
• Maximum Working Pressure (psi): 300
• Measuring Type: Pump

• Minimum Fluid Viscosity (cP): 20
• Minimum Mix Ratio: 0.1:1

• Mix Accuracy (%): 1

• Number of Catalysts: 1
• Number of Color Valves: N/A
• Number of Colors: 1

• Number of Resin Colors: 1

• Power Source: Electric

• Proportioning Type: Manual Electronic

• Pump Ratio: 3:1
• Pump Type: Air Spray Bellows

GG 24E974

GG 24F089

PROMIX 2KE PROPORTIONER, SYSTEM, PUMP

Graco 24F089 ProMix 2KE Proportioner, electric, 23:1 Air Assist Merkur pumps, screen reporting, for non-hazardous location

The ProMix 2KE is an entry level, compact, easy to use plural component system allowing you to mix on-demand for all spray technologies.

• Designed for multi-color, two component, in-booth applications
• Choose between pump-based or meter-based plural component systems with mix ratios up to 30:1
• Stay on ratio within predefined tolerance limits, down to plus/minus 02% with the pump version, plus/minus 01% with meter
• Easy-to-use LCD display allows you to track material usage, display mix ratio, program maintenance reminders operate, control operation functions and more

• Model: ProMix
• Series: 2KE

• Air Inlet Size (cm): 0.9525
• Air Inlet Size (in): 3/8
• Air Inlet Size (mm): 9.525
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Amperage (A): 2
• Applicator Type: Manual Air-Assist

• Component Type: Two Component

• Flush Type: Solvent

• Frequency (Hz): 50/60

• Gun Activation: Manual

• Includes: Air Motor, A-Lower, B-Lower, A-Tie Rod, B-Tie Rod, Lower Adapter, TSL Reservoir

• Material Type: Two Component

• Maximum Air Inlet Pressure (bar): 6.9
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Fluid Viscosity (cP): 5000

• Maximum Fluid Viscosity (cP): 5000

• Maximum Mix Ratio: 30:1
• Maximum Number of Colors: Up to 3

• Maximum Working Pressure (bar): 158
• Maximum Working Pressure (kPa): 15800
• Maximum Working Pressure (MPa): 15.8
• Maximum Working Pressure (psi): 2300
• Measuring Type: Pump

• Minimum Fluid Viscosity (cP): 20
• Minimum Mix Ratio: 0.1:1

• Mix Accuracy (%): 1

• Number of Catalysts: 1
• Number of Color Valves: N/A
• Number of Colors: 1

• Number of Resin Colors: 1

• Power Source: Electric

• Proportioning Type: Manual Electronic

• Pump Ratio: 23:1
• Pump Type: Air-Assisted

GG 24F061

GG 24E921

GG 24E899

GG 24F080

PROMIX 2KE PROPORTIONER, SYSTEM, METER

Graco 24F080 ProMix 2KE Proportioner, electric, G3000 meter, 1 color/1 catalyst, screen reporting, for non-hazardous location

The ProMix 2KE is an entry level, compact, easy to use plural component system allowing you to mix on-demand for all spray technologies.

• Designed for multi-color, two component, in-booth applications
• Choose between pump-based or meter-based plural component systems with mix ratios up to 30:1
• Stay on ratio within predefined tolerance limits, down to plus/minus 02% with the pump version, plus/minus 01% with meter
• Easy-to-use LCD display allows you to track material usage, display mix ratio, program maintenance reminders operate, control operation functions and more

• Model: ProMix
• Series: 2KE

• Air Inlet Size (cm): 0.9525
• Air Inlet Size (in): 3/8
• Air Inlet Size (mm): 9.525
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Amperage (A): 2
• Applicator Type: Manual Air Spray, Air-Assist

• Component Type: Two Component

• Flush Type: Solvent

• Frequency (Hz): 50/60

• Gun Activation: Manual

• Includes: 2KE Meter-Based Proportioner, G3000 Meter, 1 Color, 1 Catalyst

• Material Type: Two Component

• Maximum Air Inlet Pressure (bar): 6.9
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Flow Rate (cc/min): 3790

• Maximum Flow Rate (GPM): 1
• Maximum Flow Rate (L/min): 3.79

• Maximum Fluid Viscosity (cP): 5000

• Maximum Fluid Viscosity (cP): 5000

• Maximum Mix Ratio: 30:1
• Maximum Number of Colors: Up to 3

• Maximum Operating Temperature ( degree C): 50
• Maximum Operating Temperature ( degree F): 122

• Maximum Working Pressure (bar): 206.8
• Maximum Working Pressure (kPa): 20680
• Maximum Working Pressure (MPa): 20.7
• Maximum Working Pressure (psi): 3000
• Measuring Type: Meter

• Minimum Flow Rate (cc/min): 75
• Minimum Flow Rate (GPM): 0.02
• Minimum Flow Rate (L/min): 0.075

• Minimum Fluid Viscosity (cP): 20
• Minimum Mix Ratio: 0.1:1

• Mix Accuracy (%): 1

• Number of Catalysts: 1
• Number of Color Valves: N/A
• Number of Colors: 1

• Number of Resin Colors: 1

• Overall Depth (cm): 37.6
• Overall Depth (in): 14.8
• Overall Depth (mm): 376

• Overall Height (cm): 91.7
• Overall Height (in): 36.1
• Overall Height (mm): 917
• Overall Width (cm): 51.1
• Overall Width (in): 20.1
• Overall Width (mm): 511

• Power Source: Electric

• Proportioning Type: Manual Electronic

• Pump Ratio: Meter only

GG 24F082

PROMIX 2KE PROPORTIONER, SYSTEM, METER

Graco 24F082 ProMix 2KE Proportioner, electric, G3000 meter, 1 color/1 catalyst, USB reporting, for non-hazardous location

The ProMix 2KE is an entry level, compact, easy to use plural component system allowing you to mix on-demand for all spray technologies.

• Designed for multi-color, two component, in-booth applications
• Choose between pump-based or meter-based plural component systems with mix ratios up to 30:1
• Stay on ratio within predefined tolerance limits, down to plus/minus 02% with the pump version, plus/minus 01% with meter
• Easy-to-use LCD display allows you to track material usage, display mix ratio, program maintenance reminders operate, control operation functions and more

• Model: ProMix
• Series: 2KE

• Air Inlet Size (cm): 0.9525
• Air Inlet Size (in): 3/8
• Air Inlet Size (mm): 9.525
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Amperage (A): 2
• Applicator Type: Manual Air Spray, Air-Assist

• Component Type: Two Component

• Flush Type: Solvent

• Frequency (Hz): 50/60

• Gun Activation: Manual

• Includes: 2KE Meter-Based Proportioner, G3000 Meter, 1 Color, 1 Catalyst, USB Module

• Material Type: Two Component

• Maximum Air Inlet Pressure (bar): 6.9
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Flow Rate (cc/min): 3790

• Maximum Flow Rate (GPM): 1
• Maximum Flow Rate (L/min): 3.79

• Maximum Fluid Viscosity (cP): 5000

• Maximum Fluid Viscosity (cP): 5000

• Maximum Mix Ratio: 30:1
• Maximum Number of Colors: Up to 3

• Maximum Operating Temperature ( degree C): 50
• Maximum Operating Temperature ( degree F): 122

• Maximum Working Pressure (bar): 206.8
• Maximum Working Pressure (kPa): 20680
• Maximum Working Pressure (MPa): 20.7
• Maximum Working Pressure (psi): 3000
• Measuring Type: Meter

• Minimum Flow Rate (cc/min): 75
• Minimum Flow Rate (GPM): 0.02
• Minimum Flow Rate (L/min): 0.075

• Minimum Fluid Viscosity (cP): 20
• Minimum Mix Ratio: 0.1:1

• Mix Accuracy (%): 1

• Number of Catalysts: 1
• Number of Color Valves: N/A
• Number of Colors: 1

• Number of Resin Colors: 1

• Overall Depth (cm): 37.6
• Overall Depth (in): 14.8
• Overall Depth (mm): 376

• Overall Height (cm): 91.7
• Overall Height (in): 36.1
• Overall Height (mm): 917
• Overall Width (cm): 51.1
• Overall Width (in): 20.1
• Overall Width (mm): 511

• Power Source: Electric

• Proportioning Type: Manual Electronic

• Pump Ratio: Meter only

GG 24F083

PROMIX 2KE PROPORTIONER, SYSTEM, METER

Graco 24F083 ProMix 2KE Proportioner, electric, G3000 meter, 3 color/1 catalyst, USB reporting, for non-hazardous location

The ProMix 2KE is an entry level, compact, easy to use plural component system allowing you to mix on-demand for all spray technologies.

• Designed for multi-color, two component, in-booth applications
• Choose between pump-based or meter-based plural component systems with mix ratios up to 30:1
• Stay on ratio within predefined tolerance limits, down to plus/minus 02% with the pump version, plus/minus 01% with meter
• Easy-to-use LCD display allows you to track material usage, display mix ratio, program maintenance reminders operate, control operation functions and more

• Model: ProMix
• Series: 2KE

• Air Inlet Size (cm): 0.9525
• Air Inlet Size (in): 3/8
• Air Inlet Size (mm): 9.525
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Amperage (A): 2
• Applicator Type: Manual Air Spray, Air-Assist

• Component Type: Two Component

• Flush Type: Solvent

• Frequency (Hz): 50/60

• Gun Activation: Manual

• Includes: 2KE Meter-Based Proportioner, G3000 Meter, 3 Color, 1 Catalyst, USB Module

• Material Type: Two Component

• Maximum Air Inlet Pressure (bar): 6.9
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Flow Rate (cc/min): 3790

• Maximum Flow Rate (GPM): 1
• Maximum Flow Rate (L/min): 3.79

• Maximum Fluid Viscosity (cP): 5000

• Maximum Fluid Viscosity (cP): 5000

• Maximum Mix Ratio: 30:1
• Maximum Number of Colors: Up to 3

• Maximum Operating Temperature ( degree C): 50
• Maximum Operating Temperature ( degree F): 122

• Maximum Working Pressure (bar): 206.8
• Maximum Working Pressure (kPa): 20680
• Maximum Working Pressure (MPa): 20.7
• Maximum Working Pressure (psi): 3000
• Measuring Type: Meter

• Minimum Flow Rate (cc/min): 75
• Minimum Flow Rate (GPM): 0.02
• Minimum Flow Rate (L/min): 0.075

• Minimum Fluid Viscosity (cP): 20
• Minimum Mix Ratio: 0.1:1

• Mix Accuracy (%): 1

• Number of Catalysts: 1
• Number of Color Valves: N/A
• Number of Colors: 3

• Number of Resin Colors: 3

• Overall Depth (cm): 37.6
• Overall Depth (in): 14.8
• Overall Depth (mm): 376

• Overall Height (cm): 91.7
• Overall Height (in): 36.1
• Overall Height (mm): 917
• Overall Width (cm): 51.1
• Overall Width (in): 20.1
• Overall Width (mm): 511

• Power Source: Electric

• Proportioning Type: Manual Electronic

• Pump Ratio: Meter only

GG 24F086

PROMIX 2KE PROPORTIONER, SYSTEM, METER

Graco 24F086 ProMix 2KE Proportioner, air, G3000 meter, 1 color/1 catalyst, USB reporting, for hazardous location

The ProMix 2KE is an entry level, compact, easy to use plural component system allowing you to mix on-demand for all spray technologies.

• Designed for multi-color, two component, in-booth applications
• Choose between pump-based or meter-based plural component systems with mix ratios up to 30:1
• Stay on ratio within predefined tolerance limits, down to plus/minus 02% with the pump version, plus/minus 01% with meter
• Easy-to-use LCD display allows you to track material usage, display mix ratio, program maintenance reminders operate, control operation functions and more

• Model: ProMix
• Series: 2KE

• Air Inlet Size (cm): 0.9525
• Air Inlet Size (in): 3/8
• Air Inlet Size (mm): 9.525
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Amperage (A): 2
• Applicator Type: Manual Air Spray, Air-Assist

• Component Type: Two Component

• Flush Type: Solvent

• Frequency (Hz): 50/60

• Gun Activation: Manual

• Includes: 2KE Meter-Based Proportioner, G3000 Meter, 1 Color, 1 Catalyst, USB Module

• Material Type: Two Component

• Maximum Air Inlet Pressure (bar): 6.9
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Flow Rate (cc/min): 3790

• Maximum Flow Rate (GPM): 1
• Maximum Flow Rate (L/min): 3.79

• Maximum Fluid Viscosity (cP): 5000

• Maximum Fluid Viscosity (cP): 5000

• Maximum Mix Ratio: 30:1
• Maximum Number of Colors: Up to 3

• Maximum Operating Temperature ( degree C): 50
• Maximum Operating Temperature ( degree F): 122

• Maximum Working Pressure (bar): 206.8
• Maximum Working Pressure (kPa): 20680
• Maximum Working Pressure (MPa): 20.7
• Maximum Working Pressure (psi): 3000
• Measuring Type: Meter

• Minimum Flow Rate (cc/min): 75
• Minimum Flow Rate (GPM): 0.02
• Minimum Flow Rate (L/min): 0.075

• Minimum Fluid Viscosity (cP): 20
• Minimum Mix Ratio: 0.1:1

• Mix Accuracy (%): 1

• Number of Catalysts: 1
• Number of Color Valves: N/A
• Number of Colors: 1

• Number of Resin Colors: 1

• Overall Depth (cm): 37.6
• Overall Depth (in): 14.8
• Overall Depth (mm): 376

• Overall Height (cm): 91.7
• Overall Height (in): 36.1
• Overall Height (mm): 917
• Overall Width (cm): 51.1
• Overall Width (in): 20.1
• Overall Width (mm): 511

• Power Source: Air

• Proportioning Type: Manual Electronic

• Pump Ratio: Meter only

GG 24F096

PROMIX 2KE PROPORTIONER, SYSTEM, PUMP

Graco 24F096 ProMix 2KE Proportioner, electric, 23:1 Air Assist Merkur pumps, USB reporting, for non-hazardous location

The ProMix 2KE is an entry level, compact, easy to use plural component system allowing you to mix on-demand for all spray technologies.

• Designed for multi-color, two component, in-booth applications
• Choose between pump-based or meter-based plural component systems with mix ratios up to 30:1
• Stay on ratio within predefined tolerance limits, down to plus/minus 02% with the pump version, plus/minus 01% with meter
• Easy-to-use LCD display allows you to track material usage, display mix ratio, program maintenance reminders operate, control operation functions and more

• Model: ProMix
• Series: 2KE

• Air Inlet Size (cm): 0.9525
• Air Inlet Size (in): 3/8
• Air Inlet Size (mm): 9.525
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Amperage (A): 2
• Applicator Type: Manual Air-Assist

• Component Type: Two Component

• Flush Type: Solvent

• Frequency (Hz): 50/60

• Gun Activation: Manual

• Includes: Air Motor, A-Lower, B-Lower, A-Tie Rod, B-Tie Rod, Lower Adapter, TSL Reservoir

• Material Type: Two Component

• Maximum Air Inlet Pressure (bar): 6.9
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Fluid Viscosity (cP): 5000

• Maximum Fluid Viscosity (cP): 5000

• Maximum Mix Ratio: 30:1
• Maximum Number of Colors: Up to 3

• Maximum Working Pressure (bar): 158
• Maximum Working Pressure (kPa): 15800
• Maximum Working Pressure (MPa): 15.8
• Maximum Working Pressure (psi): 2300
• Measuring Type: Pump

• Minimum Fluid Viscosity (cP): 20
• Minimum Mix Ratio: 0.1:1

• Mix Accuracy (%): 1

• Number of Catalysts: 1
• Number of Color Valves: N/A
• Number of Colors: 1

• Number of Resin Colors: 1

• Power Source: Electric

• Proportioning Type: Manual Electronic

• Pump Ratio: 23:1
• Pump Type: Air-Assisted

GG 24F109

PROMIX 2KE PROPORTIONER, SYSTEM, PUMP

Graco 24F109 ProMix 2KE Proportioner, air, 3:1 Air Spray Merkur pumps, USB reporting, for hazardous location

The ProMix 2KE is an entry level, compact, easy to use plural component system allowing you to mix on-demand for all spray technologies.

• Designed for multi-color, two component, in-booth applications
• Choose between pump-based or meter-based plural component systems with mix ratios up to 30:1
• Stay on ratio within predefined tolerance limits, down to plus/minus 02% with the pump version, plus/minus 01% with meter
• Easy-to-use LCD display allows you to track material usage, display mix ratio, program maintenance reminders operate, control operation functions and more

• Model: ProMix
• Series: 2KE

• Air Inlet Size (cm): 0.9525
• Air Inlet Size (in): 3/8
• Air Inlet Size (mm): 9.525
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Amperage (A): 2
• Applicator Type: Manual Air Spray

• Component Type: Two Component

• Flush Type: Solvent

• Frequency (Hz): 50/60

• Gun Activation: Manual

• Includes: Air Motor, Adapter Plate, A-Lower, B-Lower, A-Tie Rod, B-Tie Rod, Coupling, Lower Adapter, TSL Reservoir

• Material Type: Two Component

• Maximum Air Inlet Pressure (bar): 6.9
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Fluid Viscosity (cP): 5000

• Maximum Fluid Viscosity (cP): 5000

• Maximum Mix Ratio: 30:1
• Maximum Number of Colors: Up to 3

• Maximum Working Pressure (bar): 21
• Maximum Working Pressure (kPa): 2100
• Maximum Working Pressure (MPa): 2.1
• Maximum Working Pressure (psi): 300
• Measuring Type: Pump

• Minimum Fluid Viscosity (cP): 20
• Minimum Mix Ratio: 0.1:1

• Mix Accuracy (%): 1

• Number of Catalysts: 1
• Number of Color Valves: N/A
• Number of Colors: 1

• Number of Resin Colors: 1

• Overall Depth (cm): 37.6
• Overall Depth (in): 14.8
• Overall Depth (mm): 376

• Overall Height (cm): 91.7
• Overall Height (in): 36.1
• Overall Height (mm): 917
• Overall Width (cm): 51.1
• Overall Width (in): 20.1
• Overall Width (mm): 511

• Power Source: Air

• Proportioning Type: Manual Electronic

• Pump Ratio: 3:1
• Pump Type: Air Spray

GG 24F102

PROMIX 2KE PROPORTIONER, SYSTEM, PUMP

Graco 24F102 ProMix 2KE Proportioner, air, 3:1 Air Spray Merkur pumps, screen reporting, for hazardous location

The ProMix 2KE is an entry level, compact, easy to use plural component system allowing you to mix on-demand for all spray technologies.

• Designed for multi-color, two component, in-booth applications
• Choose between pump-based or meter-based plural component systems with mix ratios up to 30:1
• Stay on ratio within predefined tolerance limits, down to plus/minus 02% with the pump version, plus/minus 01% with meter
• Easy-to-use LCD display allows you to track material usage, display mix ratio, program maintenance reminders operate, control operation functions and more

• Model: ProMix
• Series: 2KE

• Air Inlet Size (cm): 0.9525
• Air Inlet Size (in): 3/8
• Air Inlet Size (mm): 9.525
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Amperage (A): 2
• Applicator Type: Manual Air Spray

• Component Type: Two Component

• Flush Type: Solvent

• Frequency (Hz): 50/60

• Gun Activation: Manual

• Includes: Air Motor, Adapter Plate, A-Lower, B-Lower, A-Tie Rod, B-Tie Rod, Coupling, Lower Adapter, TSL Reservoir

• Material Type: Two Component

• Maximum Air Inlet Pressure (bar): 6.9
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Fluid Viscosity (cP): 5000

• Maximum Fluid Viscosity (cP): 5000

• Maximum Mix Ratio: 30:1
• Maximum Number of Colors: Up to 3

• Maximum Working Pressure (bar): 21
• Maximum Working Pressure (kPa): 2100
• Maximum Working Pressure (MPa): 2.1
• Maximum Working Pressure (psi): 300
• Measuring Type: Pump

• Minimum Fluid Viscosity (cP): 20
• Minimum Mix Ratio: 0.1:1

• Mix Accuracy (%): 1

• Number of Catalysts: 1
• Number of Color Valves: N/A
• Number of Colors: 1

• Number of Resin Colors: 1

• Overall Depth (cm): 37.6
• Overall Depth (in): 14.8
• Overall Depth (mm): 376

• Overall Height (cm): 91.7
• Overall Height (in): 36.1
• Overall Height (mm): 917
• Overall Width (cm): 51.1
• Overall Width (in): 20.1
• Overall Width (mm): 511

• Power Source: Air

• Proportioning Type: Manual Electronic

• Pump Ratio: 3:1
• Pump Type: Air Spray

GG 24E922

GG 24F084

PROMIX 2KE PROPORTIONER, SYSTEM, METER

Graco 24F084 ProMix 2KE Proportioner, air, G3000 meter, 1 color/1 catalyst, screen reporting, for hazardous location

The ProMix 2KE is an entry level, compact, easy to use plural component system allowing you to mix on-demand for all spray technologies.

• Designed for multi-color, two component, in-booth applications
• Choose between pump-based or meter-based plural component systems with mix ratios up to 30:1
• Stay on ratio within predefined tolerance limits, down to plus/minus 02% with the pump version, plus/minus 01% with meter
• Easy-to-use LCD display allows you to track material usage, display mix ratio, program maintenance reminders operate, control operation functions and more

• Model: ProMix
• Series: 2KE

• Air Inlet Size (cm): 0.9525
• Air Inlet Size (in): 3/8
• Air Inlet Size (mm): 9.525
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Amperage (A): 2
• Applicator Type: Manual Air Spray, Air-Assist

• Component Type: Two Component

• Flush Type: Solvent

• Frequency (Hz): 50/60

• Gun Activation: Manual

• Includes: 2KE Meter-Based Proportioner, G3000 Meter, 1 Color, 1 Catalyst

• Material Type: Two Component

• Maximum Air Inlet Pressure (bar): 6.9
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Flow Rate (cc/min): 3790

• Maximum Flow Rate (GPM): 1
• Maximum Flow Rate (L/min): 3.79

• Maximum Fluid Viscosity (cP): 5000

• Maximum Fluid Viscosity (cP): 5000

• Maximum Mix Ratio: 30:1
• Maximum Number of Colors: Up to 3

• Maximum Operating Temperature ( degree C): 50
• Maximum Operating Temperature ( degree F): 122

• Maximum Working Pressure (bar): 206.8
• Maximum Working Pressure (kPa): 20680
• Maximum Working Pressure (MPa): 20.7
• Maximum Working Pressure (psi): 3000
• Measuring Type: Meter

• Minimum Flow Rate (cc/min): 75
• Minimum Flow Rate (GPM): 0.02
• Minimum Flow Rate (L/min): 0.075

• Minimum Fluid Viscosity (cP): 20
• Minimum Mix Ratio: 0.1:1

• Mix Accuracy (%): 1

• Number of Catalysts: 1
• Number of Color Valves: N/A
• Number of Colors: 1

• Number of Resin Colors: 1

• Overall Depth (cm): 37.6
• Overall Depth (in): 14.8
• Overall Depth (mm): 376

• Overall Height (cm): 91.7
• Overall Height (in): 36.1
• Overall Height (mm): 917
• Overall Width (cm): 51.1
• Overall Width (in): 20.1
• Overall Width (mm): 511

• Power Source: Air

• Proportioning Type: Manual Electronic

• Pump Ratio: Meter only

GG 24f012
