GRACO INC. S10595

GG 185111

GG 186069

GG 186447

GG 187265

GG 187266

GG 185103

GG 185378

GG 187858

GG 187740

GG 184554

GG 187190

GG 186995

GG 188610

GG 188609

GG 188617

GG 188615

GG 188608

GG 188607

GG 188512

GG 18F889

GG 190979

GG 190926

GG 190927

GG 190985

GG 190986

GG 246190

METER, HELI. GEAR AMB W/SENSOR

GG 246240

GUN, SILVER

Graco 246240 Silver Plus Airless Spray Gun, 2 Finger Trigger, RAC X 517 SwitchTip

The Silver Plus Gun is known for its durability, long life, spraying performance and comfortable design. Rated at 5000 psi (345 bar, 34.5 MPa), this is the preferred gun for high-pressure applications. Includes a 2-finger trigger and a RAC X 517 SwitchTip and Guard.

• Rugged Design
  • Durable forged aluminum withstands harsh work environments
  • Lighter weight than competitive guns Polished body is easy to clean
• Exclusive Needle Design
  • Factory set needle needs no trigger adjustments
  • Guaranteed for life against breakage
  • Maximum performance and long life
• Stainless Steel Fluid Tube
  • Fluid flows directly to the tip through the gun fluid tube
  • Provides the ability to spray heavier materials
  • Including high solid coatings and mastics

• Model: Silver Plus
• Series: Airless Spray Gun

• Air Inlet Size (cm): 0.635
• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35
• Air Inlet Thread Gender: Male
• Air Inlet Thread Type: NPSM

• Applicator Type: Manual

• Body Material: Aluminum

• Compatible Material: Paint, Coating
• Component A Inlet Size (cm): 0.635

• Component A Inlet Size (in): 1/4
• Component A Inlet Size (mm): 6.35
• Component A Inlet Thread Type: NPSM
• Component Type: Single Component

• Fluid Orifice Size (cm): 0.229
• Fluid Orifice Size (in): 0.090
• Fluid Orifice Size (mm): 2.29

• For Use With: High Pressure Application

• Gun Activation: Manual
• Gun Included: 1
• Gun Type: Airless Gun
• Gun Weight (g): 510
• Gun Weight (kg): 0.51
• Gun Weight (lb): 1.125
• Gun Weight (oz): 18

• Includes: RAC X 517 SwitchTip, RAC X HandTite Guard

• Maximum Fluid Pressure (bar): 345
• Maximum Fluid Pressure (kPa): 34500
• Maximum Fluid Pressure (MPa): 34.5
• Maximum Fluid Pressure (psi): 5000
• Maximum Fluid Temperature ( degree C): 50
• Maximum Fluid Temperature ( degree F): 120

• Maximum Fluid Pressure (bar): 345
• Maximum Fluid Pressure (kPa): 34500
• Maximum Fluid Pressure (MPa): 34.5
• Maximum Fluid Pressure (psi): 5000
• Maximum Fluid Temperature ( degree C): 50
• Maximum Fluid Temperature ( degree F): 120

• Product Type: Spray Gun

• Purge Method: Liquid

GG 246915

FIREBALL 225 PUMP, BASE, 50:1, 120#

Graco 246915 Mini Fire-Ball 225 50:1 120 lb. (54 kg) Grease Pump - Portable Package Caster Base

You cant afford down time, especially when your shop is small and your work force depends on equipment performance. The Mini Fire-Ball 225 is an engineered design with fewer moving parts, which means less wear out, and reduced downtime and more profit for your business.

• Durable - Thick cast aluminum air motor housing offers unmatched durability.
• Fewer Repairs - Fewer moving parts in the air motor assembly means less downtime and low repair cost.
• Extended Seal Life - In-line pump design aligns the air motor piston and fluid piston rods to maximize seal life.
• Superior Sealing - Non-metallic poppet valves offer positive sealing performance, even with contaminated dirtyair environments for long life without repair.
• Reduced Icing - Large air porting design provides efficient use of compressed air supply for continuous pump operation and reduced icing.
• Corrosion-Resistant - Corrosion-resistant design utilizes liquid salt nitriding, nickel plating, stainless steel, aluminum and chrome on key components for longer life.

• Model: Mini Fire-Ball
• Series: 225

• Air Inlet Size (in): 0.375
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Industrial

• Compatible Material: Grease

• Container Size (lb): 120

• Fluid Inlet Type: Slotted

• Fluid Outlet Size (cm): 0.635
• Fluid Outlet Size (in): 1/4
• Fluid Outlet Size (mm): 6.35
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT

• Includes: Mini Fireball 50:1 225 Pump, Dispense Kit, Cover, Follow Plate, Holster, Portable Base, Shim

• Maximum Air Working Pressure: 140

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (MPa): 35
• Maximum Working Pressure (psi): 5000

• Motor Type: Pneumatic

• Mount Location: Drum Mount

• Power Type: Pneumatic

• Pump Ratio: 50:1
• Pump Weight (lb): 15

GG 246907

FIREBALL 225 PUMP, 3:1 , BUNG MT, 55/275 GAL

Graco 246907 Mini Fire-Ball 225 3:1 55 Gallon (200 Liter) Oil Pump - Bung Mounted Package

You cant afford down time, especially when your shop is small and your work force depends on equipment performance. The Mini Fire-Ball 225 is an engineered design with fewer moving parts, which means less wear out, and reduced downtime and more profit for your business.

• Durable - Thick cast aluminum air motor housing offers unmatched durability.
• Fewer Repairs - Fewer moving parts in the air motor assembly means less downtime and low repair cost.
• Extended Seal Life - In-line pump design aligns the air motor piston and fluid piston rods to maximize seal life.
• Superior Sealing - Non-metallic poppet valves offer positive sealing performance, even with contaminated dirtyair environments for long life without repair.
• Reduced Icing - Large air porting design provides efficient use of compressed air supply for continuous pump operation and reduced icing.
• Corrosion-Resistant - Corrosion-resistant design utilizes liquid salt nitriding, nickel plating, stainless steel, aluminum and chrome on key components for longer life.

• Model: Mini Fire-Ball
• Series: 225

• Air Inlet Size (in): 3/8
• Air Inlet Size (mm): 9.525
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT
• Air Motor Effective Diameter (in): 2.25

• Application: Industrial

• Compatible Material: Oil

• Cycles Per Gallon: 43.5

• Fluid Inlet Size (in): 1-1/2
• Fluid Inlet Size (mm): 38.1
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (in): 1/2
• Fluid Outlet Size (mm): 12.7
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT

• For Use With: Petroleum- and synthetic-based oils (motor, gear and ATF)

• Includes: Hose Installation Kit

• Maximum Air Consumption (SCFM): 20
• Maximum Air Inlet Pressure (bar): 12.41
• Maximum Air Inlet Pressure (kPa): 1241
• Maximum Air Inlet Pressure (psi): 180

• Maximum Continuous Cycle Rate (CPM): 100

• Maximum Working Pressure (bar): 37
• Maximum Working Pressure (kPa): 3700
• Maximum Working Pressure (MPa): 3.7
• Maximum Working Pressure (psi): 540

• Power Type: Pneumatic

• Pump Ratio: 3:1

GG 246910

DISPENSER, PORT, FB 225, 50:1, 35#

Graco 246910 Mini Fire-Ball 225 50:1 35 lb. and 50 lb. (16 kg and 23 kg) Grease Pump - Portable Pail Dispenser Package

You cant afford down time, especially when your shop is small and your work force depends on equipment performance. The Mini Fire-Ball 225 is an engineered design with fewer moving parts, which means less wear out, and reduced downtime and more profit for your business.

• Durable Casting - Thick cast aluminum air motor housing offers unmatched durability.
• Fewer Repairs - Fewer moving parts in the air motor assembly means less downtime and low repair cost.
• Extended Seal Life - In-line pump design aligns the air motor piston and fluid piston rods to maximize seal life.
• Superior Sealing - Non-metallic poppet valves offer positive sealing performance, even with contaminated dirtyair environments for long life without repair.
• Reduced Icing - Large air porting design provides efficient use of compressed air supply for continuous pump operation and reduced icing.
• Corrosion-Resistant - Corrosion-resistant design utilizes liquid salt nitriding, nickel plating, stainless steel, aluminum and chrome on key components for longer life.

• Model: Mini Fire-Ball
• Series: 225

• Air Inlet Size (in): 0.375
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Industrial

• Compatible Material: Grease

• Container Size (lb): 35 and 50

• Fluid Inlet Type: Slotted

• Fluid Outlet Size (cm): 0.635
• Fluid Outlet Size (in): 1/4
• Fluid Outlet Size (mm): 6.35
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT

• Includes: Dispense Kit, Cover, Follow Plate, Handle

• Maximum Air Working Pressure: 140

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (MPa): 35
• Maximum Working Pressure (psi): 5000

• Motor Type: Pneumatic

• Power Type: Pneumatic

• Pump Ratio: 50:1
• Pump Weight (lb): 15

GG 246775

FIREBALL 225 PUMP, 3:1, (UNIVERSAL)

Graco 246775 Mini Fire-Ball 225 3:1 Universal Size Oil Pump

You cant afford down time, especially when your shop is small and your work force depends on equipment performance. The Mini Fire-Ball 225 is an engineered design with fewer moving parts, which means less wear out, and reduced downtime and more profit for your business.

• Durable - Thick cast aluminum air motor housing offers unmatched durability.
• Fewer Repairs - Fewer moving parts in the air motor assembly means less downtime and low repair cost.
• Extended Seal Life - In-line pump design aligns the air motor piston and fluid piston rods to maximize seal life.
• Superior Sealing - Non-metallic poppet valves offer positive sealing performance, even with contaminated dirtyair environments for long life without repair.
• Reduced Icing - Large air porting design provides efficient use of compressed air supply for continuous pump operation and reduced icing.
• Corrosion-Resistant - Corrosion-resistant design utilizes liquid salt nitriding, nickel plating, stainless steel, aluminum and chrome on key components for longer life.

• Model: Mini Fire-Ball
• Series: 225

• Air Inlet Size (in): 3/8
• Air Inlet Size (mm): 9.525
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT
• Air Motor Effective Diameter (in): 2.25

• Application: Industrial

• Compatible Material: Oil

• Cycles Per Gallon: 43.5

• Fluid Inlet Size (in): 1-1/2
• Fluid Inlet Size (mm): 38.1
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (in): 1/2
• Fluid Outlet Size (mm): 12.7
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT

• For Use With: Petroleum- and synthetic-based oils (motor, gear and ATF)

• Maximum Air Consumption (SCFM): 20
• Maximum Air Inlet Pressure (bar): 12.41
• Maximum Air Inlet Pressure (kPa): 1241
• Maximum Air Inlet Pressure (psi): 180

• Maximum Continuous Cycle Rate (CPM): 100

• Maximum Working Pressure (bar): 37
• Maximum Working Pressure (kPa): 3700
• Maximum Working Pressure (MPa): 3.7
• Maximum Working Pressure (psi): 540

• Power Type: Pneumatic

• Pump Ratio: 3:1

GG 246946

GG 246687

REGULATOR, MASTIC

Graco 246687 Air Operated Mastic Fluid Pressure Regulator

• Actuation Type: Air

• Flow Control Type: Regulation

• Gauge Port Size (cm): 1.905
• Gauge Port Size (in): 3/4
• Gauge Port Size (mm): 19.05

• Gauge Port Type: NPT

• Inlet Size (cm): 1.905
• Inlet Size (in): 3/4
• Inlet Size (mm): 19.05

• Inlet Thread Type: NPT

• Maximum Regulated Pressure (bar): 310
• Maximum Regulated Pressure (kPa): 31000
• Maximum Regulated Pressure (MPa): 31.0
• Maximum Regulated Pressure (psi): 4500

• Maximum Viscosity (cP): 80000

• Maximum Working Pressure (bar): 344
• Maximum Working Pressure (kPa): 34400
• Maximum Working Pressure (MPa): 34.4
• Maximum Working Pressure (psi): 5000

• Minimum Regulated Pressure (bar): 7
• Minimum Regulated Pressure (kPa): 700
• Minimum Regulated Pressure (MPa): 0.7
• Minimum Regulated Pressure (psi): 100

• Outlet Size (cm): 1.905
• Outlet Size (in): 3/4
• Outlet Size (mm): 19.05
• Outlet Thread Type: NPT

GG 246948

KIT, ACCY, AIR FLTR/REG. 3/4NPT

Graco 246948 Regulator / Filter Assembly 3/4" npt(f) (19.5 mm) for Husky 3300 pump

• 3/4 NPT

• 250 psi Working Pressure

• Air Inlet Size (cm): 1.905
• Air Inlet Size (in): 3/4
• Air Inlet Size (mm): 19.05
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Air Outlet Size (cm): 1.905
• Air Outlet Size (in): 3/4
• Air Outlet Size (mm): 19.05
• Air Outlet Thread Gender: Female
• Air Outlet Thread Type: NPT

GG 246831

GG 246919

GG 246920

GG 246728

GG 246963

GG 246809

GG 246786

GG 246360

GG 246376

KIT, COMPL., H1050 (AIR/FLUID)

Graco 246376 Complete Husky 1050 Supply Pump System

The Husky 1050 air-operated diaphragm pump features a stall-free low pulsation air valve which provides a smooth and rapid changeover. The one-piece center section eliminates leaks and reduces maintenance on Husky pumps when compared to other diaphragm pumps.

• Benefits of the Husky 1050 Double Diaphragm Pump

  Up to 5 times longer diaphragm life compared to other air-operated diaphragm pumps in its class

  Expanded material offering to handle endless applications

  Spring loaded, externally serviceable pilot valves for faster change over and reduced pulsation.

  Offered in ATEX configuration.

  • 30% more efficient than the market leader
  • 20% increase in fluid flow compared to the Husky 1050
  • Expanded material offering to handle endless applications




  • Model: Husky
  • Series: 1050
  • Air Exhaust Port Size (in): 3/4
  • Air Exhaust Port Thread Gender: Female
  • Air Exhaust Port Thread Type: NPT
  • Air Inlet Size (in): 1/2
  • Air Inlet Thread Gender: Female
  • Air Inlet Thread Type: NPT
  • Compatible Material: Antifreeze, Detergent, Motor Oil, Hydraulic Fluid, Cutting Oil, Water - Wastewater Transfer
  • Fluid Inlet Size (cm): 2.54
  • Fluid Inlet Size (in): 1
  • Fluid Inlet Size (mm): 25.4
  • Fluid Outlet Size (cm): 2.54
  • Fluid Outlet Size (in): 1
  • Fluid Outlet Size (mm): 25.4
  • Maximum Air Pressure (bar): 8.62
  • Maximum Air Pressure (kPa): 862
  • Maximum Air Pressure (MPa): 0.862
  • Maximum Air Pressure (psi): 125
  • Maximum Cycle Rate (CPM): 280
  • Maximum Flow Rate (GPM): 50
  • Maximum Flow Rate (L/min): 189
  • Maximum Fluid Pressure (bar): 8
  • Maximum Fluid Pressure (kPa): 80
  • Maximum Fluid Pressure (MPa): 0.8
  • Maximum Fluid Pressure (psi): 115
  • Maximum Fluid Pressure (bar): 8
  • Maximum Fluid Pressure (kPa): 80
  • Maximum Fluid Pressure (MPa): 0.8
  • Maximum Fluid Pressure (psi): 115
  • Maximum Solid Size (cm): 0.3175
  • Maximum Solid Size (in): 0.125
  • Maximum Solid Size (mm): 3.175
  • Power Source: Air

GG 246358

GG 246381

GG 246484

HUSKY PUMP, 515AC-PP01AAC3-2ACBNBNPT

Graco 246484 Husky 515 Diaphragm Pump

The Husky 515 air-operated double diaphragm pump features a stall-free low pulsation air valve which provides a smooth and rapid changeover.

The bolt through fluid cover design eliminates leaks and makes the Husky safer with higher reliability.

• Center and end porting options.
• No mechanical seals to cause fluid leaks or failures
• Runs quietly at less than 85 dBa with easy-to-use remote muffler capability for even lower noise levels
• Operates on as little as 20 psi (1.4 bar, 0.14 MPa)
• Split manifold option to pump multiple fluids without mixing
• Delivery up to 15 gpm (56.7 lpm)
• Easy-to-service air valve and ball checks
• Reliable air valve for years of dependable performance

• Model: Husky
• Series: 515

• Air Exhaust Port Size (in): 3/8
• Air Exhaust Port Thread Gender: Female
• Air Exhaust Port Thread Type: NPT
• Air Inlet Size (in): 1/4
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Compatible Material: Antifreeze, Detergent, Resin, Polymer, Motor Oil, Gear Oil, Hydraulic Fluid, Automatic Transmission Fluid, Cutting Oil, Water - Wastewater Treatment, Ink and Colorant

• Fluid Section Material: Carbon Steel

• Material: Carbon Steel

• Maximum Air Consumption (SCFM): 28
• Maximum Air Pressure (bar): 7

• Maximum Air Pressure (kPa): 700
• Maximum Air Pressure (MPa): 0.7
• Maximum Air Pressure (psi): 100

• Maximum Cycle Rate (CPM): 400

• Maximum Flow Rate (GPM): 15
• Maximum Flow Rate (L/min): 56.8

• Maximum Fluid Pressure (bar): 7
• Maximum Fluid Pressure (kPa): 700
• Maximum Fluid Pressure (MPa): 0.7
• Maximum Fluid Pressure (psi): 100

• Maximum Fluid Pressure (bar): 7
• Maximum Fluid Pressure (kPa): 700
• Maximum Fluid Pressure (MPa): 0.7
• Maximum Fluid Pressure (psi): 100

• Maximum Solid Size (cm): 0.2383
• Maximum Solid Size (in): 0.09375
• Maximum Solid Size (mm): 2.4

• Maximum Working Pressure (bar): 7
• Maximum Working Pressure (kPa): 70
• Maximum Working Pressure (MPa): 0.7
• Maximum Working Pressure (psi): 100

• Overall Height (in): 10.63

• Power Source: Air

GG 246485

HUSKY PUMP, 716A-PP01AA1-4SSSSPTPT

Graco 246485 Husky 716 Diaphragm Pump

The Husky 716 air operated diaphragm pump features an external controller for remote control capabilities.

• Center- and end-porting
• No mechanical seals which causes fluid leaks or failures
• Runs quietly at less than 85 dBa with easy-to-use remote muffler capability for even lower noise levels
• 3/4 in (19.05 mm) center- and end-porting
• No seals to leak or fail
• Quiet running less than 85 dBa with easy-to-use remote muffler capability for even lower noise levels
• Easy-to-service air valve and ball checks

• Model: Husky
• Series: 716

• Air Exhaust Port Size (in): 3/8
• Air Exhaust Port Thread Gender: Female
• Air Exhaust Port Thread Type: NPT
• Air Inlet Size (in): 1/4
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Compatible Material: Antifreeze, Detergent, Motor Oil, Gear Oil, Hydraulic Fluid, Cutting Oil, Water - Wastewater Treatment, Water - Freshwater Treatment, Ink and Colorant

• Fluid Inlet Size (cm): 1.905
• Fluid Inlet Size (in): 3/4
• Fluid Inlet Size (mm): 19.05
• Fluid Inlet Thread Gender: Female

• Fluid Outlet Size (cm): 1.905
• Fluid Outlet Size (in): 3/4
• Fluid Outlet Size (mm): 19.05
• Fluid Outlet Thread Gender: Female
• Fluid Section Material: Carbon Steel

• Material: Carbon Steel

• Maximum Air Consumption (SCFM): 28
• Maximum Air Pressure (bar): 7

• Maximum Air Pressure (kPa): 700
• Maximum Air Pressure (MPa): 0.7
• Maximum Air Pressure (psi): 100

• Maximum Cycle Rate (CPM): 400

• Maximum Flow Rate (GPM): 16
• Maximum Flow Rate (L/min): 60.6

• Maximum Fluid Pressure (bar): 7
• Maximum Fluid Pressure (kPa): 700
• Maximum Fluid Pressure (MPa): 0.7
• Maximum Fluid Pressure (psi): 100

• Maximum Fluid Pressure (bar): 7
• Maximum Fluid Pressure (kPa): 700
• Maximum Fluid Pressure (MPa): 0.7
• Maximum Fluid Pressure (psi): 100

• Maximum Solid Size (cm): 0.2383
• Maximum Solid Size (in): 0.09375
• Maximum Solid Size (mm): 2.4

• Maximum Working Pressure (bar): 7
• Maximum Working Pressure (kPa): 70
• Maximum Working Pressure (MPa): 0.7
• Maximum Working Pressure (psi): 100

• Overall Height (in): 10.43

• Power Source: Air

GG 246678

REACTOR HEATED HOSE, 2000PSI, 3/8ID W/SGRD

Graco 246678 50 ft x 3/8 in Heated Hose, 2000 psi, Thermocouple, Mesh Scuff, Reactor 1

Graco's heated hoses are designed specifically for use with Reactor Equipment. Hoses are a key component to the total system, making it important to achieve accurate and uniform heating for the best application possible.

• New multi-strand copper heating element has greatly increased hose quality:

  Provides 10-times* the flex life compared to previous flat copper heating element

  Long-term, even heating without hot spots

  Backwards compatible with existing Reactor heated hoses

  • Copper-heated hoses are designed specifically for use with Graco proportioners
  • Covered with proprietary butyl cover for protection against moisture sensitive isocyanate
  • Different fitting sizes on the isocyanate and resin hoses prevent accidentally connecting the wrong hoses together
  • Hoses use custom designed splice kit to electrically connect hoses without having to run copper under the fittings
  • Helix-design whip hose uses braided copper wires for added flexibility and longer life




  • Model: Reactor 1
  • Series: Mesh Scuff
  • Compatible Sprayer: Reactor 1
  • For Use With: Plural Component Proportioners
  • Hose Heating Type: External Heated
  • Hose Inside Diameter (in): 3/8
  • Hose Inside Diameter (mm): 9.525
  • Hose Length (ft): 50
  • Hose Length (m): 15.2
  • Inside Diameter (in): 3/8
  • Maximum Working Pressure (bar): 138
  • Maximum Working Pressure (kPa): 13800
  • Maximum Working Pressure (MPa): 13.8
  • Maximum Working Pressure (psi): 2000

GG 246643

REGULATOR, MASTIC, HEATED

Graco 246643 Air Operated Heated Mastic Fluid Pressure Regulator

The heated mastic regulator is ideal for low to high viscosity warm-melt and hot-melt sealants or adhesives

• Actuation Type: Air

• Flow Control Type: Regulation

• Inlet Size (cm): 1.905
• Inlet Size (in): 3/4
• Inlet Size (mm): 19.05

• Inlet Thread Gender: Female
• Inlet Thread Type: NPT

• Maximum Regulated Pressure (bar): 241
• Maximum Regulated Pressure (kPa): 24100
• Maximum Regulated Pressure (MPa): 24.1
• Maximum Regulated Pressure (psi): 3500

• Maximum Working Pressure (bar): 344
• Maximum Working Pressure (kPa): 34400
• Maximum Working Pressure (MPa): 35
• Maximum Working Pressure (psi): 5000

• Minimum Regulated Pressure (bar): 7
• Minimum Regulated Pressure (kPa): 700
• Minimum Regulated Pressure (MPa): 0.7
• Minimum Regulated Pressure (psi): 100

• Outlet Size (cm): 1.905
• Outlet Size (in): 3/4
• Outlet Size (mm): 19.05
• Outlet Thread Gender: Female

GG 246679

REACTOR HEATED HOSE, 3500PSI, 3/8 W/SCFGRD

Graco 246679 50 ft x 3/8 in Heated Hose, 3500 psi, Thermocouple, Mesh Scuff, Reactor 1

Graco's heated hoses are designed specifically for use with Reactor Equipment. Hoses are a key component to the total system, making it important to achieve accurate and uniform heating for the best application possible.

• New multi-strand copper heating element has greatly increased hose quality:

  Provides 10-times* the flex life compared to previous flat copper heating element

  Long-term, even heating without hot spots

  Backwards compatible with existing Reactor heated hoses

  • Copper-heated hoses are designed specifically for use with Graco proportioners
  • Covered with proprietary butyl cover for protection against moisture sensitive isocyanate
  • Different fitting sizes on the isocyanate and resin hoses prevent accidentally connecting the wrong hoses together
  • Hoses use custom designed splice kit to electrically connect hoses without having to run copper under the fittings
  • Helix-design whip hose uses braided copper wires for added flexibility and longer life




  • Model: Reactor 1
  • Series: Mesh Scuff
  • Compatible Sprayer: Reactor 1
  • For Use With: Plural Component Proportioners
  • Hose Heating Type: External Heated
  • Hose Inside Diameter (in): 3/8
  • Hose Inside Diameter (mm): 9.525
  • Hose Length (ft): 50
  • Hose Length (m): 15.2
  • Inside Diameter (in): 3/8
  • Maximum Working Pressure (bar): 241
  • Maximum Working Pressure (kPa): 24100
  • Maximum Working Pressure (MPa): 24.1
  • Maximum Working Pressure (psi): 3500

GG 246629

GG 246384

KIT, REPAIR, FILTER, 60 MESH

Graco 246384 Easy Out Pump Manifold Filter, Short, 60 mesh

Using an Easy Out Pump Manifold Filter is the easiest way to maximize spray performance while also saving time and money by extending the life of your equipment and reducing down time. Use 60 mesh for materials such as latex primers, latex, and latex enamels.

• Maximize spray performance with Easy Out manifold filter
• Save time and money by extending the life of your equipment and reducing down time
• Filter keeps dirt, debris and contaminants out of the spray system for smooth, professional quality finish
• Designed to filter the paint from the inside out for most effective filtering and easier clean up
• Use 60 mesh for materials such as latex primers, latex, and latex enamels

• Model: Easy Out
• Series: Manifold Filter

• For Use With: ST, STX, 390, Ultra 395/495/595 Airless Sprayers

• Mesh Size: 60

• Number of Pieces: 1

GG 246626

GG 246453

GASKET, RAC X, 5 PACK

Graco 246453 RAC X One Seal, 5 pack

Compatible with most materials. Easy installation withtools. Use only with RAC X SwitchTips and Guards.

• Model: RAC X
• Series: Tip Gasket

• Compatible Tip Type: RAC X

• Material: Steel, Rubber

GG 246501

GG 246596

KIT,REPAIR, GEARS

KIT INCLUDES: SHAFT, SUB-ASSY, HELICAL GEAR [QTY. 1], SHAFT, SUB-ASSY, HELICAL GEAR [QTY. 1], O-RING, SEAL, HELICAL GEAR METER [QTY. 2], SPACER, SHAFT, GEAR [QTY. 1]

GG 246628

GG 246386

GG 246422

GG 246627

GG 246630

GG 244909

ENDURE VALVE, HTD, 240V, 400 DG F

Graco 244909 Endure Valve, 240V Electric Heat Model, temperatures to 400 degree F (204c)

The EnDure Valve offers high reliability for high pressure, high flow sealant and adhesive dispensing applications.

• Dual seal design
• Air operated with spring-assisted closing
• Used in heat-only applications
• Replaces 243694, 243696 hot melt valves where operating temperature is between 200 degree and 400 degree F (95c and 204c)

• Model: EnDure

• Air Inlet Size (in): 1/8
• Air Inlet Thread Type: NPT

• Ambient/Warm Melt/Hot Melt: Ambient, Warm Melt, Hot Melt
• Application: Bonding, Sealing, Gasketing

• Compatible Material: Sealants, Adhesives

• Component Type: Single Component

• Fluid Inlet Size (cm): 1.27
• Fluid Inlet Size (in): 1/2
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (in): 5/8
• Fluid Outlet Thread Gender: Male

• Gun Activation: Automatic

• Includes: Heater Cartridge

• Maximum Working Pressure (bar): 241
• Maximum Working Pressure (kg/cm 2): 246.1
• Maximum Working Pressure (kPa): 24100
• Maximum Working Pressure (psi): 3500

• Metering Valve Orifice Size (in): 1/8

• Mount Hole Size (mm): M6 x 1

• Orifice Diameter (in): 0.03

GG 244856

GG 244951

ENDURE VALVE, HTD, 240V, 1/2NPT, 400

Graco 244951 Endure Valve, 240V Electric Heat Model, temperatures to 200 degree F (95c)

The EnDure Valve offers high reliability for high pressure, high flow sealant and adhesive dispensing applications.

• Dual seam design
• Air operated with spring-assisted closing
• 240 volt electrically heated, 8 pin square connection

• Model: EnDure

• Air Inlet Size (in): 1/8
• Air Inlet Thread Type: NPT

• Ambient/Warm Melt/Hot Melt: Ambient, Warm Melt, Hot Melt
• Application: Bonding, Sealing, Gasketing

• Compatible Material: Sealants, Adhesives

• Component Type: Single Component

• Fluid Inlet Size (cm): 1.27
• Fluid Inlet Size (in): 1/2
• Fluid Inlet Thread Gender: Male
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (in): 1/2
• Fluid Outlet Thread Gender: Male
• Fluid Outlet Thread Type: NPT

• Gun Activation: Automatic

• Includes: Heater Cartridge
• Inlet Size (in): 1/2

• Maximum Working Pressure (bar): 241
• Maximum Working Pressure (kg/cm 2): 246
• Maximum Working Pressure (kPa): 24100
• Maximum Working Pressure (psi): 3500

• Mount Hole Size (mm): M6 x 1

• Orifice Diameter (in): 0.5
• Outlet Size (in): 1/2

GG 244164

EXTENSION, POLE GUN, 6FT

Graco 244164 Pole Gun Extension, 6 ft

Eliminate the hassles of ladders and scaffolding to safely spray hard-to-reach areas like high walls, vaulted ceilings, stairways, and soffits. Complete the job faster with less setup time with a pole gun and extension.

• For unmatched spraying performance in high or recessed areas
• Use with Contractor In-Line Valve and the CleanShot Shut-Off Valve to create different length pole guns
• Balanced design with no excessive weight at the end of the pole

• Model: Graco

• Fluid Inlet Size (cm): 2.22
• Fluid Inlet Size (in): 7/8
• Fluid Inlet Size (mm): 22.23

• For Use With: Pole Gun

• Maximum Pole Length (ft): 6

• Maximum Working Pressure (bar): 279
• Maximum Working Pressure (kPa): 27900
• Maximum Working Pressure (MPa): 27.9
• Maximum Working Pressure (psi): 3600

• Pole Type: Extension Pole

GG 244433

GG 245827

GG 245848

GG 245191

GG 245372

PLUNGER, VALVE, ASSY

GG 245374

GG 245202

GG 245367

VALVE, SEAT, ASSM

GG 245265

GG 245280

HOUSING, SEAT

Graco 245280 Seat Housing

GG 245378

GG 245373

GG 245370

VALVE, SEAT, D7, ASSM

GG 245368

VALVE, SEAT, D5, ASSM

GG 243589

TANK, HIGH PRESSURE, 10 GAL

Graco 243589 10 Gallon High Pressure Stainless Steel Tank, without agitator

Industrial grade pressure tanks used to supply, agitate, and pressurize finishing liquids. For professional use only.

• 10 gallon (38 liters) High-Pressure Tank
• Maximum Air Inlet Pressure 100 psi (0.7 MPa, 7 bar)
• Maximum Working Fluid Pressure 100 psi (0.7 MPa, 7 bar)

• Inlet Size (cm): 0.635
• Inlet Size (in): 1/4
• Inlet Size (mm): 6.35

• Inlet Thread Gender: Male
• Inlet Thread Type: NPT

• Maximum Volume Capacity (gal): 10
• Maximum Volume Capacity (L): 38

• Maximum Working Pressure (bar): 7
• Maximum Working Pressure (kPa): 700
• Maximum Working Pressure (MPa): 0.7
• Maximum Working Pressure (psi): 100

• Outlet Size (cm): 0.9525
• Outlet Size (in): 3/8
• Outlet Size (mm): 9.525
• Outlet Thread Gender: Male
• Outlet Thread Type: NPSM

GG 243697

MANIFOLD,HTD,230V

GG 244969

HOSE, CPLD, COND, AIR, 100 FT

Graco 244969 AirFlex Flexible Grounded Air Hose (Grey)- 0.315 in. (8 mm) ID, 1/4 npsm(f) x 1/4 npsm(f) left-handthread, 100 ft (30.5 m) length

GG 245083

GG 245067

KIT, REPAIR, 085 BALL CHECK

Graco 245067 Triton 3D 150 Acetal Balls and Stainless Seats Kit

GG 245085

KIT, ACCY, SUCTION TUBE

Graco 245085 Suction Hose, Stainless Steel, 6 ft (1.8 m), with acetal bung adapter for 55 gal (200 l) drum

GG 245114

GG 244968

HOSE, CPLD, COND, AIR, 75 FT

Graco 244968 AirFlex Flexible Grounded Air Hose, Gray, 75 ft (23 m)

GG 245081

KIT, ACCY, AGITATOR

Graco 245081 SST Pail Agitator Kit for Triton Packages

GG 245084

GG 244927

RETAINER, RING ASSY, BLACK

Graco 244927 Air cap retaining ring

• Bleed Type: Bleeder

GG 245143

GG 245111

GG 244784

KIT, ACCY, GUN & WAND

Graco 244784 Professional Grade Gun with 36 in Wand

• Model: G-Force II
• Series: Wand

• For Use With: Direct Drive Pressure Washers, G-Force II Pressure Washer

• Includes: 36 in Wand

• Kit Type: Pressure Washer Grade Gun

GG 243814

GG 243340

KIT, ACCY, PAIL SST 5 GL

Graco 243340 Pail Cover with Agitator, SST, use to agitate material in a 5 gal (18.9 l) pail

GG 243729

KIT, REPAIR, 300 (PISTON SEAL)

Graco 243729 Seal Repair Kit for 4000 cc Lowers

GG 244911

GG 244915

KIT, GUN COVER,ES

Graco 244915 Manual Electrostatic Spray Gun Cover, box of 10

• Compatible Material: Sealants, Adhesives

GG 244914

GG 244432

HOSE, COUPLED, SUCTION

• Compatible Material: Solventborne
