GRACO INC. S10595

GG 269315

CONTRACTOR FLAT TIP, SPRAY

Graco 269315 Contractor Flat Tip, 315

The 315 Contractor Flat Tip is designed for narrow surfaces. The 315 Flat Tip has a 0.015 inch orifice and produces a 6 to 8 inch fan.

• Model: Contractor
• Series: Flat Tip

• Compatible Material: Architectural Coating

• For Use With: Silver Plus Airless Spray Gun

• Maximum Fan Width (cm): 15
• Maximum Fan Width (in): 6
• Maximum Fan Width (mm): 203

• Maximum Flow Rate (GPM): 0.24
• Maximum Flow Rate (L/min): 0.91

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (psi): 5000

• Minimum Fan Width (in): 6
• Minimum Fan Width (mm): 152

• Orifice Diameter (in): 0.015

• Pattern Size (in): 6 to 8
• Pattern Size (mm): 152.4 to 203.2

GG 269317

CONTRACTOR FLAT TIP, SPRAY 317

Graco 269317 Contractor Flat Tip, 317

The 317 Contractor Flat Tip is designed for narrow surfaces. The 317 Flat Tip has a 0.017 inch orifice and produces a 6 to 8 inch fan.

• Model: Contractor
• Series: Flat Tip

• Compatible Material: Architectural Coating

• For Use With: Silver Plus Airless Spray Gun

• Maximum Fan Width (cm): 15
• Maximum Fan Width (in): 6
• Maximum Fan Width (mm): 203

• Maximum Flow Rate (GPM): 0.31
• Maximum Flow Rate (L/min): 1.17

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (psi): 5000

• Minimum Fan Width (in): 6
• Minimum Fan Width (mm): 152

• Orifice Diameter (in): 0.017

• Pattern Size (in): 6 to 8
• Pattern Size (mm): 152.4 to 203.2

GG 269619

CONTRACTOR FLAT TIP, SPRAY

Graco 269619 Contractor Flat Tip, 619

The 619 Contractor Flat Tip produces a 12 to 14 inch fan and has a 0.019 inch orifice.

• Model: Contractor
• Series: Flat Tip

• Compatible Material: Architectural Coating

• For Use With: Silver Plus Airless Spray Gun

• Maximum Fan Width (cm): 30
• Maximum Fan Width (in): 12
• Maximum Fan Width (mm): 356

• Maximum Flow Rate (GPM): 0.38
• Maximum Flow Rate (L/min): 1.44

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (psi): 5000

• Minimum Fan Width (in): 12
• Minimum Fan Width (mm): 305

• Orifice Diameter (in): 0.019

• Pattern Size (in): 12 to 14
• Pattern Size (mm): 304.8 to 355.6

GG 269325

CONTRACTOR FLAT TIP, SPRAY

Graco 269325 Contractor Flat Tip, 325

The 325 Contractor Flat Tip is designed for narrow surfaces and thicker materials. The 325 Flat Tip has a 0.025 inch orifice and produces a 6 to 8 inch fan.

• Model: Contractor
• Series: Flat Tip

• Compatible Material: Architectural Coating

• For Use With: Silver Plus Airless Spray Gun

• Maximum Fan Width (cm): 15
• Maximum Fan Width (in): 6
• Maximum Fan Width (mm): 203

• Maximum Flow Rate (GPM): 0.67
• Maximum Flow Rate (L/min): 2.54

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (psi): 5000

• Minimum Fan Width (in): 6
• Minimum Fan Width (mm): 152

• Orifice Diameter (in): 0.025

• Pattern Size (in): 6 to 8
• Pattern Size (mm): 152.4 to 203.2

GG 269417

CONTRACTOR FLAT TIP, SPRAY

Graco 269417 Contractor Flat Tip, 417

The 417 Contractor Flat Tip produces an 8 to 10 inch fan and has a 0.017 inch orifice.

• Model: Contractor
• Series: Flat Tip

• Compatible Material: Architectural Coating

• For Use With: Silver Plus Airless Spray Gun

• Maximum Fan Width (cm): 20
• Maximum Fan Width (in): 8
• Maximum Fan Width (mm): 254

• Maximum Flow Rate (GPM): 0.31
• Maximum Flow Rate (L/min): 1.17

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (psi): 5000

• Minimum Fan Width (in): 8
• Minimum Fan Width (mm): 203

• Orifice Diameter (in): 0.017

• Pattern Size (in): 8 to 10
• Pattern Size (mm): 203.2 to 254

GG 269515

CONTRACTOR FLAT TIP, SPRAY

Graco 269515 Contractor Flat Tip, 515

The 515 Contractor Flat Tip produces a 10 to 12 inch fan and has a 0.015 inch orifice.

• Model: Contractor
• Series: Flat Tip

• Compatible Material: Architectural Coating

• For Use With: Silver Plus Airless Spray Gun

• Maximum Fan Width (cm): 25
• Maximum Fan Width (in): 10
• Maximum Fan Width (mm): 305

• Maximum Flow Rate (GPM): 0.24
• Maximum Flow Rate (L/min): 0.91

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (psi): 5000

• Minimum Fan Width (in): 10
• Minimum Fan Width (mm): 254

• Orifice Diameter (in): 0.015

• Pattern Size (in): 10 to 12
• Pattern Size (mm): 254 to 304.8

GG 269613

CONTRACTOR FLAT TIP, SPRAY 613

Graco 269613 Contractor Flat Tip, 613

The 613 Contractor Flat Tip produces a 12 to 14 inch fan and has a 0.013 inch orifice.

• Model: Contractor
• Series: Flat Tip

• Compatible Material: Architectural Coating

• For Use With: Silver Plus Airless Spray Gun

• Maximum Fan Width (cm): 30
• Maximum Fan Width (in): 12
• Maximum Fan Width (mm): 356

• Maximum Flow Rate (GPM): 0.18
• Maximum Flow Rate (L/min): 0.68

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (psi): 5000

• Minimum Fan Width (in): 12
• Minimum Fan Width (mm): 305

• Orifice Diameter (in): 0.013

• Pattern Size (in): 12 to 14
• Pattern Size (mm): 304.8 to 355.6

GG 269525

CONTRACTOR FLAT TIP, SPRAY 525

Graco 269525 Contractor Flat Tip, 525

The 525 Contractor Flat Tip produces a 10 to 12 inch fan and has a 0.025 inch orifice.

• Model: Contractor
• Series: Flat Tip

• Compatible Material: Architectural Coating

• For Use With: Silver Plus Airless Spray Gun

• Maximum Fan Width (cm): 25
• Maximum Fan Width (in): 10
• Maximum Fan Width (mm): 305

• Maximum Flow Rate (GPM): 0.67
• Maximum Flow Rate (L/min): 2.54

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (psi): 5000

• Minimum Fan Width (in): 10
• Minimum Fan Width (mm): 254

• Orifice Diameter (in): 0.025

• Pattern Size (in): 10 to 12
• Pattern Size (mm): 254 to 304.8

GG 269415

CONTRACTOR FLAT TIP, SPRAY

Graco 269415 Contractor Flat Tip, 415

The 415 Contractor Flat Tip produces an 8 to 10 inch fan and has a 0.015 inch orifice.

• Model: Contractor
• Series: Flat Tip

• Compatible Material: Architectural Coating

• For Use With: Silver Plus Airless Spray Gun

• Maximum Fan Width (cm): 20
• Maximum Fan Width (in): 8
• Maximum Fan Width (mm): 254

• Maximum Flow Rate (GPM): 0.24
• Maximum Flow Rate (L/min): 0.91

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (psi): 5000

• Minimum Fan Width (in): 8
• Minimum Fan Width (mm): 203

• Orifice Diameter (in): 0.015

• Pattern Size (in): 8 to 10
• Pattern Size (mm): 203.2 to 254

GG 269523

CONTRACTOR FLAT TIP, SPRAY

Graco 269523 Contractor Flat Tip, 523

The 523 Contractor Flat Tip produces a 10 to 12 inch fan and has a 0.023 inch orifice.

• Model: Contractor
• Series: Flat Tip

• Compatible Material: Architectural Coating

• For Use With: Silver Plus Airless Spray Gun

• Maximum Fan Width (cm): 25
• Maximum Fan Width (in): 10
• Maximum Fan Width (mm): 305

• Maximum Flow Rate (GPM): 0.57
• Maximum Flow Rate (L/min): 2.16

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (psi): 5000

• Minimum Fan Width (in): 10
• Minimum Fan Width (mm): 254

• Orifice Diameter (in): 0.023

• Pattern Size (in): 10 to 12
• Pattern Size (mm): 254 to 304.8

GG 269217

CONTRACTOR FLAT TIP, SPRAY 217

Graco 269217 Contractor Flat Tip, 217

The 217 Contractor Flat Tip is designed for narrower surfaces. The 217 Flat Tip has a 0.017 inch orifice and produces a 4 to 6 inch fan.

• Model: Contractor
• Series: Flat Tip

• Compatible Material: Architectural Coating

• For Use With: Silver Plus Airless Spray Gun

• Maximum Fan Width (cm): 10
• Maximum Fan Width (in): 4
• Maximum Fan Width (mm): 152

• Maximum Flow Rate (GPM): 0.31
• Maximum Flow Rate (L/min): 1.17

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (psi): 5000

• Minimum Fan Width (in): 4
• Minimum Fan Width (mm): 102

• Orifice Diameter (in): 0.017

• Pattern Size (in): 4 to 6
• Pattern Size (mm): 101.6 to 152.4

GG 269215

CONTRACTOR FLAT TIP, SPRAY 215

Graco 269215 Contractor Flat Tip, 215

The 215 Contractor Flat Tip is designed for narrower surfaces. The 215 Flat Tip has a 0.015 inch orifice and produces a 4 to 6 inch fan.

• Model: Contractor
• Series: Flat Tip

• Compatible Material: Architectural Coating

• For Use With: Silver Plus Airless Spray Gun

• Maximum Fan Width (cm): 10
• Maximum Fan Width (in): 4
• Maximum Fan Width (mm): 152

• Maximum Flow Rate (GPM): 0.24
• Maximum Flow Rate (L/min): 0.91

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (psi): 5000

• Minimum Fan Width (in): 4
• Minimum Fan Width (mm): 102

• Orifice Diameter (in): 0.015

• Pattern Size (in): 4 to 6
• Pattern Size (mm): 101.6 to 152.4

GG 269617

CONTRACTOR FLAT TIP, SPRAY

Graco 269617 Contractor Flat Tip, 617

The 617 Contractor Flat Tip produces a 12 to 14 inch fan and has a 0.017 inch orifice.

• Model: Contractor
• Series: Flat Tip

• Compatible Material: Architectural Coating

• For Use With: Silver Plus Airless Spray Gun

• Maximum Fan Width (cm): 30
• Maximum Fan Width (in): 12
• Maximum Fan Width (mm): 356

• Maximum Flow Rate (GPM): 0.31
• Maximum Flow Rate (L/min): 1.17

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (psi): 5000

• Minimum Fan Width (in): 12
• Minimum Fan Width (mm): 305

• Orifice Diameter (in): 0.017

• Pattern Size (in): 12 to 14
• Pattern Size (mm): 304.8 to 355.6

GG 269635

CONTRACTOR FLAT TIP, SPRAY 635

Graco 269635 Contractor Flat Tip, 635

The 635 Contractor Flat Tip produces a 12 to 14 inch fan and has a 0.035 inch orifice.

• Model: Contractor
• Series: Flat Tip

• Compatible Material: Architectural Coating

• For Use With: Silver Plus Airless Spray Gun

• Maximum Fan Width (cm): 30
• Maximum Fan Width (in): 12
• Maximum Fan Width (mm): 356

• Maximum Flow Rate (GPM): 1.31
• Maximum Flow Rate (L/min): 4.96

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (psi): 5000

• Minimum Fan Width (in): 12
• Minimum Fan Width (mm): 305

• Orifice Diameter (in): 0.035

• Pattern Size (in): 12 to 14
• Pattern Size (mm): 304.8 to 355.6

GG 269631

CONTRACTOR FLAT TIP, SPRAY 631

Graco 269631 Contractor Flat Tip, 631

The 631 Contractor Flat Tip produces a 12 to 14 inch fan and has a 0.031 inch orifice.

• Model: Contractor
• Series: Flat Tip

• Compatible Material: Architectural Coating

• For Use With: Silver Plus Airless Spray Gun

• Maximum Fan Width (cm): 30
• Maximum Fan Width (in): 12
• Maximum Fan Width (mm): 356

• Maximum Flow Rate (GPM): 1.03
• Maximum Flow Rate (L/min): 3.90

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (psi): 5000

• Minimum Fan Width (in): 12
• Minimum Fan Width (mm): 305

• Orifice Diameter (in): 0.031

• Pattern Size (in): 12 to 14
• Pattern Size (mm): 304.8 to 355.6

GG 269413

CONTRACTOR FLAT TIP, SPRAY

Graco 269413 Contractor Flat Tip, 413

The 413 Contractor Flat Tip produces an 8 to 10 inch fan and has a 0.013 inch orifice.

• Model: Contractor
• Series: Flat Tip

• Compatible Material: Architectural Coating

• For Use With: Silver Plus Airless Spray Gun

• Maximum Fan Width (cm): 20
• Maximum Fan Width (in): 8
• Maximum Fan Width (mm): 254

• Maximum Flow Rate (GPM): 0.18
• Maximum Flow Rate (L/min): 0.68

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (psi): 5000

• Minimum Fan Width (in): 8
• Minimum Fan Width (mm): 203

• Orifice Diameter (in): 0.013

• Pattern Size (in): 8 to 10
• Pattern Size (mm): 203.2 to 254

GG 269519

CONTRACTOR FLAT TIP, SPRAY

Graco 269519 Contractor Flat Tip, 519

The 519 Contractor Flat Tip produces a 10 to 12 inch fan and has a 0.019 inch orifice.

• Model: Contractor
• Series: Flat Tip

• Compatible Material: Architectural Coating

• For Use With: Silver Plus Airless Spray Gun

• Maximum Fan Width (cm): 25
• Maximum Fan Width (in): 10
• Maximum Fan Width (mm): 305

• Maximum Flow Rate (GPM): 0.38
• Maximum Flow Rate (L/min): 1.44

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (psi): 5000

• Minimum Fan Width (in): 10
• Minimum Fan Width (mm): 254

• Orifice Diameter (in): 0.019

• Pattern Size (in): 10 to 12
• Pattern Size (mm): 254 to 304.8

GG 269621

CONTRACTOR FLAT TIP, SPRAY

Graco 269621 Contractor Flat Tip, 621

The 621 Contractor Flat Tip produces a 12 to 14 inch fan and has a 0.021 inch orifice.

• Model: Contractor
• Series: Flat Tip

• Compatible Material: Elastomer, Latex Paint, Latex Stain, Oil-Based Paint, Oil-Based Stain

• For Use With: Airless Spray Gun

• Maximum Fan Width (cm): 30
• Maximum Fan Width (in): 12

• Orifice Diameter (in): 0.021

GG 269427

CONTRACTOR FLAT TIP, SPRAY

Graco 269427 Contractor Flat Tip, 427

The 427 Contractor Flat Tip produces an 8 to 10 inch fan and has a 0.027 inch orifice.

• Model: Contractor
• Series: Flat Tip

• Compatible Material: Architectural Coating

• For Use With: Silver Plus Airless Spray Gun

• Maximum Fan Width (cm): 20
• Maximum Fan Width (in): 8
• Maximum Fan Width (mm): 254

• Maximum Flow Rate (GPM): 0.74
• Maximum Flow Rate (L/min): 2.80

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (psi): 5000

• Minimum Fan Width (in): 8
• Minimum Fan Width (mm): 203

• Orifice Diameter (in): 0.027

• Pattern Size (in): 8 to 10
• Pattern Size (mm): 203.2 to 254

GG 269627

CONTRACTOR FLAT TIP, SPRAY 627

Graco 269627 Contractor Flat Tip, 627

The 627 Contractor Flat Tip produces a 12 to 14 inch fan and has a 0.027 inch orifice.

• Model: Contractor
• Series: Flat Tip

• Compatible Material: Architectural Coating

• For Use With: Silver Plus Airless Spray Gun

• Maximum Fan Width (cm): 30
• Maximum Fan Width (in): 12
• Maximum Fan Width (mm): 356

• Maximum Flow Rate (GPM): 0.74
• Maximum Flow Rate (L/min): 2.80

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (psi): 5000

• Minimum Fan Width (in): 12
• Minimum Fan Width (mm): 305

• Orifice Diameter (in): 0.027

• Pattern Size (in): 12 to 14
• Pattern Size (mm): 304.8 to 355.6

GG 269623

CONTRACTOR FLAT TIP, SPRAY 623

Graco 269623 Contractor Flat Tip, 623

The 623 Contractor Flat Tip produces a 12 to 14 inch fan and has a 0.023 inch orifice.

• Model: Contractor
• Series: Flat Tip

• Compatible Material: Architectural Coating

• For Use With: Silver Plus Airless Spray Gun

• Maximum Fan Width (cm): 30
• Maximum Fan Width (in): 12
• Maximum Fan Width (mm): 356

• Maximum Flow Rate (GPM): 0.57
• Maximum Flow Rate (L/min): 2.16

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (psi): 5000

• Minimum Fan Width (in): 12
• Minimum Fan Width (mm): 305

• Orifice Diameter (in): 0.023

• Pattern Size (in): 12 to 14
• Pattern Size (mm): 304.8 to 355.6

GG 269625

CONTRACTOR FLAT TIP, SPRAY

Graco 269625 Contractor Flat Tip, 625

The 625 Contractor Flat Tip produces a 12 to 14 inch fan and has a 0.025 inch orifice.

• Model: Contractor
• Series: Flat Tip

• Compatible Material: Architectural Coating

• For Use With: Silver Plus Airless Spray Gun

• Maximum Fan Width (cm): 30
• Maximum Fan Width (in): 12
• Maximum Fan Width (mm): 356

• Maximum Flow Rate (GPM): 0.67
• Maximum Flow Rate (L/min): 2.54

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (psi): 5000

• Minimum Fan Width (in): 12
• Minimum Fan Width (mm): 305

• Orifice Diameter (in): 0.025

• Pattern Size (in): 12 to 14
• Pattern Size (mm): 304.8 to 355.6

GG 269715

CONTRACTOR FLAT TIP, SPRAY 715

Graco 269715 Contractor Flat Tip, 715

The 715 Contractor Flat Tip produces a 14 to 16 inch fan and has a 0.015 inch orifice.

• Model: Contractor
• Series: Flat Tip

• Compatible Material: Architectural Coating

• For Use With: Silver Plus Airless Spray Gun

• Maximum Fan Width (cm): 35
• Maximum Fan Width (in): 14
• Maximum Fan Width (mm): 406

• Maximum Flow Rate (GPM): 0.24
• Maximum Flow Rate (L/min): 0.91

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (psi): 5000

• Minimum Fan Width (in): 14
• Minimum Fan Width (mm): 356

• Orifice Diameter (in): 0.015

• Pattern Size (in): 14 to 16
• Pattern Size (mm): 355.6 to 406.4

GG 269717

CONTRACTOR FLAT TIP, SPRAY 717

Graco 269717 Contractor Flat Tip, 717

The 717 Contractor Flat Tip produces a 14 to 16 inch fan and has a 0.017 inch orifice.

• Model: Contractor
• Series: Flat Tip

• Compatible Material: Architectural Coating

• For Use With: Silver Plus Airless Spray Gun

• Maximum Fan Width (cm): 35
• Maximum Fan Width (in): 14
• Maximum Fan Width (mm): 406

• Maximum Flow Rate (GPM): 0.31
• Maximum Flow Rate (L/min): 1.17

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (psi): 5000

• Minimum Fan Width (in): 14
• Minimum Fan Width (mm): 356

• Orifice Diameter (in): 0.017

• Pattern Size (in): 14 to 16
• Pattern Size (mm): 355.6 to 406.4

GG 269719

CONTRACTOR FLAT TIP, SPRAY 719

Graco 269719 Contractor Flat Tip, 719

The 719 Contractor Flat Tip produces a 14 to 16 inch fan and has a 0.019 inch orifice.

• Model: Contractor
• Series: Flat Tip

• Compatible Material: Architectural Coating

• For Use With: Silver Plus Airless Spray Gun

• Maximum Fan Width (cm): 35
• Maximum Fan Width (in): 14
• Maximum Fan Width (mm): 406

• Maximum Flow Rate (GPM): 0.38
• Maximum Flow Rate (L/min): 1.44

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (psi): 5000

• Minimum Fan Width (in): 14
• Minimum Fan Width (mm): 356

• Orifice Diameter (in): 0.019

• Pattern Size (in): 14 to 16
• Pattern Size (mm): 355.6 to 406.4

GG 269513

CONTRACTOR FLAT TIP, SPRAY

Graco 269513 Contractor Flat Tip, 513

The 513 Contractor Flat Tip produces a 10 to 12 inch fan and has a 0.013 inch orifice.

• Model: Contractor
• Series: Flat Tip

• Compatible Material: Architectural Coating

• For Use With: Silver Plus Airless Spray Gun

• Maximum Fan Width (cm): 25
• Maximum Fan Width (in): 10
• Maximum Fan Width (mm): 305

• Maximum Flow Rate (GPM): 0.18
• Maximum Flow Rate (L/min): 0.68

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (psi): 5000

• Minimum Fan Width (in): 10
• Minimum Fan Width (mm): 254

• Orifice Diameter (in): 0.013

• Pattern Size (in): 10 to 12
• Pattern Size (mm): 254 to 304.8

GG 269725

CONTRACTOR FLAT TIP, SPRAY

Graco 269725 Contractor Flat Tip, 725

The 725 Contractor Flat Tip produces a 14 to 16 inch fan and has a 0.025 inch orifice.

• Model: Contractor
• Series: Flat Tip

• Compatible Material: Architectural Coating

• For Use With: Silver Plus Airless Spray Gun

• Maximum Fan Width (cm): 35
• Maximum Fan Width (in): 14
• Maximum Fan Width (mm): 406

• Maximum Flow Rate (GPM): 0.67
• Maximum Flow Rate (L/min): 2.54

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (psi): 5000

• Minimum Fan Width (in): 14
• Minimum Fan Width (mm): 356

• Orifice Diameter (in): 0.025

• Pattern Size (in): 14 to 16
• Pattern Size (mm): 355.6 to 406.4

GG 269819

CONTRACTOR FLAT TIP, SPRAY 819

Graco 269819 Contractor Flat Tip, 819

The 819 Contractor Flat Tip produces a 16 to 18 inch fan and has a 0.019 inch orifice.

• Model: Contractor
• Series: Flat Tip

• Compatible Material: Architectural Coating

• For Use With: Silver Plus Airless Spray Gun

• Maximum Fan Width (cm): 40
• Maximum Fan Width (in): 16
• Maximum Fan Width (mm): 457

• Maximum Flow Rate (GPM): 0.38
• Maximum Flow Rate (L/min): 1.44

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (psi): 5000

• Minimum Fan Width (in): 16
• Minimum Fan Width (mm): 406

• Orifice Diameter (in): 0.019

• Pattern Size (in): 16 to 18
• Pattern Size (mm): 406.4 to 457.2

GG 269721

CONTRACTOR FLAT TIP, SPRAY 721

Graco 269721 Contractor Flat Tip, 721

The 721 Contractor Flat Tip produces a 14 to 16 inch fan and has a 0.021 inch orifice.

• Model: Contractor
• Series: Flat Tip

• Compatible Material: Architectural Coating

• For Use With: Silver Plus Airless Spray Gun

• Maximum Fan Width (cm): 35
• Maximum Fan Width (in): 14
• Maximum Fan Width (mm): 406

• Maximum Flow Rate (GPM): 0.47
• Maximum Flow Rate (L/min): 1.78

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (psi): 5000

• Minimum Fan Width (in): 14
• Minimum Fan Width (mm): 356

• Orifice Diameter (in): 0.021

• Pattern Size (in): 14 to 16
• Pattern Size (mm): 355.6 to 406.4

GG 269827

CONTRACTOR FLAT TIP, SPRAY

Graco 269827 Contractor Flat Tip, 827

The 827 Contractor Flat Tip produces a 16 to 18 inch fan and has a 0.027 inch orifice.

• Model: Contractor
• Series: Flat Tip

• Compatible Material: Architectural Coating

• For Use With: Silver Plus Airless Spray Gun

• Maximum Fan Width (cm): 40
• Maximum Fan Width (in): 16
• Maximum Fan Width (mm): 457

• Maximum Flow Rate (GPM): 0.74
• Maximum Flow Rate (L/min): 2.80

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (psi): 5000

• Minimum Fan Width (in): 16
• Minimum Fan Width (mm): 406

• Orifice Diameter (in): 0.027

• Pattern Size (in): 16 to 18
• Pattern Size (mm): 406.4 to 457.2

GG 269815

CONTRACTOR FLAT TIP, SPRAY 815

Graco 269815 Contractor Flat Tip, 815

The 815 Contractor Flat Tip produces a 16 to 18 inch fan and has a 0.015 inch orifice.

• Model: Contractor
• Series: Flat Tip

• Compatible Material: Architectural Coating

• For Use With: Silver Plus Airless Spray Gun

• Maximum Fan Width (cm): 40
• Maximum Fan Width (in): 16
• Maximum Fan Width (mm): 457

• Maximum Flow Rate (GPM): 0.24
• Maximum Flow Rate (L/min): 0.91

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (psi): 5000

• Minimum Fan Width (in): 16
• Minimum Fan Width (mm): 406

• Orifice Diameter (in): 0.015

• Pattern Size (in): 16 to 18
• Pattern Size (mm): 406.4 to 457.2

GG 269821

CONTRACTOR FLAT TIP, SPRAY 821

Graco 269821 Contractor Flat Tip, 821

The 821 Contractor Flat Tip produces a 16 to 18 inch fan and has a 0.021 inch orifice.

• Model: Contractor
• Series: Flat Tip

• Compatible Material: Architectural Coating

• For Use With: Silver Plus Airless Spray Gun

• Maximum Fan Width (cm): 40
• Maximum Fan Width (in): 16
• Maximum Fan Width (mm): 457

• Maximum Flow Rate (GPM): 0.47
• Maximum Flow Rate (L/min): 1.78

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (psi): 5000

• Minimum Fan Width (in): 16
• Minimum Fan Width (mm): 406

• Orifice Diameter (in): 0.021

• Pattern Size (in): 16 to 18
• Pattern Size (mm): 406.4 to 457.2

GG 269925

CONTRACTOR FLAT TIP, SPRAY

Graco 269925 Contractor Flat Tip, 925

The 925 Contractor Flat Tip produces an 18 to 20 inch (46 to 51 cm) fan and has a 0.025 inch orifice.

• Model: Contractor
• Series: Flat Tip

• Compatible Material: Architectural Coating

• For Use With: Silver Plus Airless Spray Gun

• Maximum Fan Width (cm): 45
• Maximum Fan Width (in): 18
• Maximum Fan Width (mm): 508

• Maximum Flow Rate (GPM): 0.67
• Maximum Flow Rate (L/min): 2.54

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (psi): 5000

• Minimum Fan Width (in): 18
• Minimum Fan Width (mm): 457

• Orifice Diameter (in): 0.025

• Pattern Size (in): 18 to 20
• Pattern Size (mm): 457.2 to 508

GG 269831

CONTRACTOR FLAT TIP, SPRAY 831

Graco 269831 Contractor Flat Tip, 831

The 831 Contractor Flat Tip produces a 16 to 18 inch fan and has a 0.031 inch orifice.

• Model: Contractor
• Series: Flat Tip

• Compatible Material: Architectural Coating

• For Use With: Silver Plus Airless Spray Gun

• Maximum Fan Width (cm): 40
• Maximum Fan Width (in): 16
• Maximum Fan Width (mm): 457

• Maximum Flow Rate (GPM): 1.03
• Maximum Flow Rate (L/min): 3.90

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (psi): 5000

• Minimum Fan Width (in): 16
• Minimum Fan Width (mm): 406

• Orifice Diameter (in): 0.031

• Pattern Size (in): 16 to 18
• Pattern Size (mm): 406.4 to 457.2

GG 26A029

GG 26A078

GG 26A079

GG 26A083

GG 26A119

METER,GEAR, ASSY, G3000A

Graco 26A119 G3000A High Pressure Fluid Meters, 0.02 to 1.0 gpm (75 to 3800 cc/min) flow range

GG 26A118

BODY,GEARMETER, G3000A

GG 26A129

PANEL, FLUID, OIL/LUBRICANT

Graco 26A129 ProDispense Fluid Panel Kit, Oil Meter, 10 wt oil to #2 grease

This fluid panel kit for the ProDispense Electronic Preset Dispense System is ideal for oil and lubricant applications.

• Oil meter dispenses 10 wt oil to #2 grease.

• Model: ProDispense

• For Use With: Oil and gear lube applications

GG 26A123

KIT,CONTROL,AIR,PD2K

GG 26A130

PANEL, FLUID, WATER/ANTIFREEZE

Graco 26A130 ProDispense Fluid Panel Kit, Water Meter, light viscosity, average resolution

This fluid panel kit for the ProDispense Electronic Preset Dispense System is ideal for water and antifreeze applications.

• Turbine meter is compatible with water and antifreeze.

• Model: ProDispense

GG 26A134

KIT, FCM, FLUIDCTRL, PRODISPENSE

Graco 26A134 ProDispense Fluid Control Module

Fluid Control Module (FCM) expands the base ProDispense system by 2 fluid panels.

• A mounting plate makes attachment to the fluid panel easy.
• Up to 3 modules can be used on each system.
• Additional FCM is required only if more than 2 fluid panels need to be controlled.

• Model: ProDispense

• For Use With: ProDispense Electronic Fluid Dispense and Meter System

• Includes: Mounting plate

GG 26A133

GG 26A187

GG 26A131

PANEL, FLUID, GREASE/PAINT, G3000

Graco 26A131 ProDispense Fluid Panel Kit, Grease/ Paint Meter, wide viscosity, high accuracy

This fluid panel kit for the ProDispense Electronic Preset Dispense System is ideal for grease and paint applications.

• Model: ProDispense

• Air Inlet Size (in): 5/32
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: Push

• Fluid Inlet Size (in): 1/4
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (in): 3/8
• Fluid Outlet Thread Gender: Male
• Fluid Outlet Thread Type: NPT

• For Use With: G3000 meter

• Maximum Air Pressure (bar): 7.03

• Maximum Air Pressure (kPa): 703
• Maximum Air Pressure (psi): 102

• Maximum Flow Rate (cc/min): 3800

• Maximum Flow Rate (GPM): 1
• Maximum Flow Rate (L/min): 3.8

• Maximum Working Pressure (bar): 207
• Maximum Working Pressure (psi): 3000

• Minimum Flow Rate (GPM): 0.02

GG 26A169

GG 26A165

PANEL, FLUID, SOLVENT

Graco 26A165 ProDispense Fluid Panel Kit, Solvent Meter, light viscosity, high accuracy

This fluid panel kit for the ProDispense Electronic Preset Dispense System is ideal for solvent applications.

• Use S3000 meter with solvents and clear light viscosity materials.

• Model: ProDispense

• For Use With: S3000 meter

GG 26A246

GG 26A304

T3 PUMP, TRANSFER, 3:1

Graco 26A304 T3 Supply Pump (Stainless Steel): 3:1 Fluid to Air Ratio

Transfer Pumps are required to move A and B materials to the Reactor Spray Systems. The T3 Transfer Pump combines Graco's proven Merkur air-motor and popular T2 stainless steel lower. The T3 is a 3:1 ratio pump - using less air pressure to provide the same fluid pressure required.

• Easier to maneuver - The overall height of the T3 is 3.7 inches (9.4 cm) shorter above the drum than the T2, making it easier to remove from the drum inside of a spray rig.
• More quiet - Studies show the T3 Transfer Pump is about 3x more quiet than the T2 Transfer Pump.
• Less maintenance - the Merkur air-motor is based on air pilot valve technology. The air-motor switching is purely pneumatic. This differs from T1 and T2 Transfer Pumps, which use a mechanical reversing mechanism in the air-motor.

• Model: T3
• Series: Stainless Steel

• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Industrial

• Compatible Material: Polyurethane Foam, Polyurea

• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT

• Includes: Fluid Supply Kit, Air Hose Kit

• Material: Stainless Steel

• Maximum Air Inlet Pressure (bar): 6.9
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (MPa): 0.69
• Maximum Air Inlet Pressure (psi): 100

• Maximum Working Pressure (bar): 21.7
• Maximum Working Pressure (kPa): 2170
• Maximum Working Pressure (MPa): 2.2
• Maximum Working Pressure (psi): 315

• Package Options: Bare

• Pump Ratio: 3:1

GG 26A312

GG 26A247

GG 24X284

GG 24Y627

GG 253029

GG 253030

GG 253131

GG 253132

GG 253367

GG 253546

GG 253783

GG 255463

GG 24E418

GG 24E825

GG 24E977

GG 24E979

GG 24E992

GG 24F248

GG 24F397

KIT, REPAIR, 1590 - PLASTIC

Graco 24F397 PTFE/Santoprene 2-Piece Diaphragm Kit for 1.5-inch Pump

GG 24F663

GG 24F664

GG 24G547

GG 24G549

GG 24G550

KIT, REPAIR, PUMP, 6:1 SANITARY

Graco 24G550 Lower Repair Kit 6:1 Priming Piston

GG 24G555

KIT, REPAIR, PUMP, 12:1 SANITARY

Graco 24G555 Lower Repair Kit 12:1 Priming Piston Pump

GG 24G556

GG 24G701

GG 24G853

GG 24J003

GG 24J886

GG 24J005

GG 24M830

GG 24R167

GG 24R168

GG 24T164

GG 24T874

GG 24U755

GG 24V029

GG 24V216

GG 24V554

GG 24W390

GG 24W391

GG 24W875

GG FTM438

GG FTM638

GG GC0638

GG GC0819

GG LC0154

GG NXT097
