Husky 1050E SS Pump, PTFE Balls & PO Diaphragm

GG 653027

HUSKY PUMP, 1050S-E, SS/PT/PO/4E

Graco 653027 Husky 1050e SS Pump, NEMA 56C Gearbox, SS Center Section, SS Seats, PTFE Balls & PO Diaphragm

Our Husky e-Series pumps are ideal for applications that require low pulsation and a smooth flow. The patented air charged drive allows for the elimination or reduction of pulsation WITHOUT expensive pulsation dampeners or surge tanks.

• Durable Pump Technology
  • Handles slurries and abrasives all without damage to the pump
  • Gentle on shear sensitive material
• Diaphragm Pump
  • Runs dry
  • No rotating or moving fluid seals
  • Self-priming
• Electric Drive
  • Reduce energy consumption and operating costs
  • Increase pump control
  • Accurately meter fluid
• Patent Pending Air Charged Drive
  • Increase diaphragm life without compromising your fluid
  • Ability to reduce pulsation on fluid outlet
  • Stalls under pressure without additional switches and controls
• Energy efficient electric drive reduces energy consumption up to 5x compared to traditional air operated diaphragm pumps
• Seal-less diaphragm pump design eliminates leaking and failures due to run-dry pump conditions

• Model: Husky
• Series: 1050e

• Air Inlet Size (in): 3/8
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Industrial

• Ball Material: PTFE

• Center Section Material: Stainless Steel

• Compatible Material: Antifreeze, Detergent, Gel-Coat, Polyurethane, Windshield Washer Fluid, Diesel Exhaust Fluid, Motor Oil, Grease & Oil, Used Oil, Hydraulic Fluid, Transmission Fluid, Cutting Oil, Oil, Water - Wastewater Treatment, Water - Wastewater Transfer, Water, Waterborne, Solventborne, High Solids, Plural Components, CARC, Metallics, Topcoats, Stains, Varnish, Lacquer, Ceramics, Enamel, Epoxies, Ink

• Connection Type: Threaded

• Diaphragm Compatible Material: PTFE
• Diaphragm Material: PTFE/EPDM Overmold

• Fluid Inlet Size (cm): 2.54
• Fluid Inlet Size (in): 1
• Fluid Inlet Size (mm): 25.4
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (cm): 2.54
• Fluid Outlet Size (in): 1
• Fluid Outlet Size (mm): 25.4
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT
• Fluid Section Material: Stainless Steel

• Manifold Configuration: End Port
• Manifold O-Ring Material: PTFE
• Material: Stainless Steel

• Maximum Air Pressure (bar): 5.5

• Maximum Air Pressure (kPa): 550
• Maximum Air Pressure (MPa): 0.55
• Maximum Air Pressure (psi): 80

• Maximum Cycle Rate (CPM): 280

• Maximum Flow Rate (GPM): 42
• Maximum Flow Rate (L/min): 159

• Maximum Fluid Pressure (bar): 4.8
• Maximum Fluid Pressure (kPa): 480
• Maximum Fluid Pressure (MPa): 0.48
• Maximum Fluid Pressure (psi): 70

• Maximum Fluid Pressure (bar): 4.8
• Maximum Fluid Pressure (kPa): 480
• Maximum Fluid Pressure (MPa): 0.48
• Maximum Fluid Pressure (psi): 70

• Maximum Operating Temperature (°C): 40
• Maximum Operating Temperature (°F): 104

• Maximum Solid Size (cm): 0.3175
