Fluid Regulators

GG 246688

GG 25R487

REGULATOR, BP, AIRPILOT, LOW-FLOW

Graco 25R487 Low Shear Fluid Back Pressure Regulator, 300 Max psi, 10 gpm Max flow rate, SST, Pneumatic, high wear, sanitary inlet/outlet

Graco's low shear back pressure regulator (BPR) minimizes shear and prevents paint degradation so that manufacturers produce consistent finish quality.

• Air operated model works with Intelligent Paint Kitchen (IPK) control to reduce energy consumption and paint shear
• Ultralife series ceramic coated parts resist wear and increase service life
• Low profile, compact design and backwards compatibility mean easy installation and replacement

• Compatible Material: Waterborne, Solvent borne

• Gauge Port Size (cm): 0.635
• Gauge Port Size (in): 1/4
• Gauge Port Size (mm): 6.35

• Gauge Port Type: NPT

• Inlet Size (cm): 3.8
• Inlet Size (in): 1.5
• Inlet Size (mm): 38

• Inlet Thread Type: Sanitary Flange

• Maximum Air Inlet Pressure (bar): 7
• Maximum Air Inlet Pressure (kg/cm 2): 7
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Flow Rate (GPM): 10
• Maximum Flow Rate (L/min): 38

• Maximum Operating Temperature ( degree C): 50
• Maximum Operating Temperature ( degree F): 122

• Maximum Regulated Pressure (bar): 17.6
• Maximum Regulated Pressure (kg/cm 2): 17.6
• Maximum Regulated Pressure (kPa): 1724
• Maximum Regulated Pressure (psi): 250

• Maximum Viscosity (cP): 1000

• Maximum Working Pressure (bar): 21.1
• Maximum Working Pressure (kg/cm 2): 21.1
• Maximum Working Pressure (kPa): 2068
• Maximum Working Pressure (psi): 300

• Minimum Operating Temperature ( degree C): 0
• Minimum Operating Temperature ( degree F): 32

• Minimum Regulated Pressure (bar): 1.8
• Minimum Regulated Pressure (kg/cm 2): 1.8
• Minimum Regulated Pressure (kPa): 172
• Minimum Regulated Pressure (MPa): 0.17
• Minimum Regulated Pressure (psi): 25

• Outlet Size (cm): 3.8
• Outlet Size (in): 1.5
• Outlet Size (mm): 38
• Outlet Thread Type: Sanitary Flange

GG 25T477

REGULATOR, BACK PRESS, MP, 20:1

Graco 25T477 Medium Pressure Fluid Back Pressure Regulator, 2000 Max psi, 5 gpm Max flow rate, SST, Pneumatic

Improve finishing process control with this medium pressure, pneumatic back pressure regulator (BPR).

• Gain better resolution than other BPR brands, adjusting more accurately to keep fluid pressure at desired levels.
• Interface with Graco's Intelligent Paint Kitchen (IPK), controlling pressure and flow without human intervention.

• Compatible Material: Waterborne, Solvent borne

• Gauge Port Size (cm): 0.635
• Gauge Port Size (in): 1/4
• Gauge Port Size (mm): 6.35

• Gauge Port Type: NPT

• Inlet Size (cm): 0.95
• Inlet Size (in): 0.375
• Inlet Size (mm): 9.5

• Inlet Thread Type: NPT

• Maximum Air Inlet Pressure (bar): 7
• Maximum Air Inlet Pressure (kg/cm 2): 7
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Flow Rate (GPM): 5
• Maximum Flow Rate (L/min): 19

• Maximum Operating Temperature ( degree C): 50
• Maximum Operating Temperature ( degree F): 122

• Maximum Regulated Pressure (bar): 138
• Maximum Regulated Pressure (kg/cm 2): 138
• Maximum Regulated Pressure (kPa): 13800
• Maximum Regulated Pressure (psi): 2000

• Maximum Viscosity (cP): 250

• Maximum Working Pressure (bar): 211
• Maximum Working Pressure (kg/cm 2): 211
• Maximum Working Pressure (kPa): 20680
• Maximum Working Pressure (psi): 3000

• Minimum Operating Temperature ( degree C): 0
• Minimum Operating Temperature ( degree F): 32

• Minimum Regulated Pressure (bar): 17
• Minimum Regulated Pressure (kg/cm 2): 17
• Minimum Regulated Pressure (kPa): 1720
• Minimum Regulated Pressure (psi): 250

• Outlet Size (cm): 0.95
• Outlet Size (in): 0.375
• Outlet Size (mm): 9.5
• Outlet Thread Type: NPT

GG 289208

REGULATOR, HEATED FLUID

RR 74151-03

BB 107754-C-C

BB 845003

BB 845004

BB 845011

BB 845020

DD HGB-509-5-R38

DD HGB-510-R4-CO

DD HGB-609-5-B38

DD HGB-609-5-R38

DD HGS-5113

DD HGS-5122

DD HGS-5132

DD HGS-5242

GG 112795

GG 116521

REGULATOR, FILTER, AIR

Graco 116521 Air Filter/Regulator, 3/4 npt(f) outlet and 3/4 npsm(f) inlet, 5 125 psi (0.3 8.6 bar) pressure range, 40 micron polypropylene filter

• Air Inlet Size (cm): 1.905
• Air Inlet Size (in): 3/4
• Air Inlet Size (mm): 19.05
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPSM

• Air Outlet Size (cm): 1.905
• Air Outlet Size (in): 3/4
• Air Outlet Size (mm): 19.05
• Air Outlet Thread Gender: Female
• Air Outlet Thread Type: NPT

GG 120010

REGULATOR, I/P

GG 120435

GG 120897

GG 15W017

GG 17L324
