MERKUR SYSTEM, PUMP, 3:1, 125CC, WALL, STD
GG G03W03
GG G03W03
MERKUR SYSTEM, PUMP, 3:1, 125CC, WALL, STD
Graco G03W03 3:1 Merkur Air Spray Package, 125cc, Wall, Pump/Gun Air Controls, Siphon Kit, Fluid Filter, No Applicator
Make the right choice for your finishing applications with Merkur Low Pressure Packages. The Merkur low-pressure piston pump comes with advanced air spray technology.
- The pump lower has the best solution for smooth, low pulsation operation.
- The air motor operates efficiently with low air consumption.
- Wall mount configuration offers easy access to data monitoring and controls.
- Model: Merkur
- Fluid Inlet Size (cm): 2.54
- Fluid Inlet Size (in): 1
- Fluid Inlet Size (mm): 25.4
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (cm): 1.27
- Fluid Outlet Size (in): 1/2
- Fluid Outlet Size (mm): 12.7
- Fluid Outlet Thread Type: NPT
- Gun Included: 0
- Gun Model: No Applicator
- Gun Technology: Bare Package
- Gun Type: No Applicator
- Includes: Pump and Gun Air Controls, Siphon Kit, Fluid Filter
- Maximum Air Pressure (bar): 6.9
- Maximum Air Pressure (kPa): 690
- Maximum Air Pressure (psi): 100
- Maximum Flow Rate (GPM): 2
- Maximum Flow Rate (L/min): 7.5
- Maximum Operating Temperature (°C): 49
- Maximum Operating Temperature (°F): 120
- Maximum Working Pressure (bar): 8.3
- Maximum Working Pressure (MPa): 0.8
- Maximum Working Pressure (psi): 120
- Mount Type: Wall Mount
- Power Source: Air
- Pressure Type: Low Pressure
- Product Type: Bare Package
- Pump Ratio: 3:1
- Pump Type: Pneumatic Piston Pump
$8,060.00
MERKUR SYSTEM, PUMP, 3:1, 125CC, WALL, STD
GG G03W15
GG G03W15
MERKUR SYSTEM, PUMP, 3:1, 125CC, WALL, STD
Graco G03W15 3:1 Merkur Air Spray Package, 125cc, Wall, No Applicator
Make the right choice for your finishing applications with Merkur Low Pressure Packages. The Merkur low-pressure piston pump comes with advanced air spray technology.
- Wall mount configuration offers easy access to data monitoring and controls.
- The air motor operates efficiently with low air consumption.
- The pump lower has the best solution for smooth, low pulsation operation.
- Model: Merkur
- Fluid Inlet Size (cm): 2.54
- Fluid Inlet Size (in): 1
- Fluid Inlet Size (mm): 25.4
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (cm): 1.27
- Fluid Outlet Size (in): 1/2
- Fluid Outlet Size (mm): 12.7
- Fluid Outlet Thread Type: NPT
- Gun Included: 0
- Gun Model: No Applicator
- Gun Technology: Bare Package
- Gun Type: No Applicator
- Maximum Air Pressure (bar): 6.9
- Maximum Air Pressure (kPa): 690
- Maximum Air Pressure (psi): 100
- Maximum Flow Rate (GPM): 2
- Maximum Flow Rate (L/min): 7.5
- Maximum Operating Temperature (°C): 49
- Maximum Operating Temperature (°F): 120
- Maximum Working Pressure (bar): 8.3
- Maximum Working Pressure (MPa): 0.8
- Maximum Working Pressure (psi): 120
- Mount Type: Wall Mount
- Power Source: Air
- Pressure Type: Low Pressure
- Product Type: Bare Package
- Pump Ratio: 3:1
- Pump Type: Pneumatic Piston Pump
$6,100.00
MERKUR BELLOWS SYSTEM, PUMP, 150CC, STD
GG G05B01
GG G05B01
MERKUR BELLOWS SYSTEM, PUMP, 150CC, STD
Merkur Bellows 5:1 Ratio Pump Package with V-Packing Seal, Wall Mount, Fluid Filter Graco’s Merkur bellows piston pumps provide low maintenance with no seals exposed to the atmosphere. These pumps are designed to eliminate conventional throat seals, providing high reliability for moisture-sensitive materials. Highest technology air motor on the market Low air consumption for increased efficiency Simple air motor design and minimal parts reduces repair time Easy-to-flush design allows for fast color changes and reduced material waste 300 series stainless steel pump construction provides long-lasting durability
$11,340.00
MERKUR BELLOWS SYSTEM, PUMP, 150CC, SMT
GG G05B02
GG G05B02
MERKUR BELLOWS SYSTEM, PUMP, 150CC, SMT
Merkur Bellows 5:1 Ratio Pump Package with V-Packing Seal, Wall Mount, Fluid Filter, DataTrak Graco’s Merkur bellows piston pumps provide low maintenance with no seals exposed to the atmosphere. These pumps are designed to eliminate conventional throat seals, providing high reliability for moisture-sensitive materials. Highest technology air motor on the market Low air consumption for increased efficiency Simple air motor design and minimal parts reduces repair time Easy-to-flush design allows for fast color changes and reduced material waste 300 series stainless steel pump construction provides long-lasting durability
$12,520.00
MERKUR BELLOWS SYSTEM, PUMP, 150CC, STD
GG G05B09
GG G05B09
MERKUR BELLOWS SYSTEM, PUMP, 150CC, STD
Merkur Bellows 5:1 Ratio Pump Package with U-Cup Seal, Wall Mount, Fluid Filter Graco’s Merkur bellows piston pumps provide low maintenance with no seals exposed to the atmosphere. These pumps are designed to eliminate conventional throat seals, providing high reliability for moisture-sensitive materials. Highest technology air motor on the market Low air consumption for increased efficiency Simple air motor design and minimal parts reduces repair time Easy-to-flush design allows for fast color changes and reduced material waste 300 series stainless steel pump construction provides long-lasting durability
$11,730.00
MERKUR SYSTEM, PUMP, 10:1, 75CC, CART, STD
GG G10C03
GG G10C03
MERKUR SYSTEM, PUMP, 10:1, 75CC, CART, STD
Graco G10C03 10:1 Merkur Pump, 1.2 gpm (4.5 lpm) fluid flow, Cart Mount, Pump/Gun Air Controls, Suction Hose
Designed to improve productivity, reduce costs, lower emissions and provide consistent, high quality finishes for all of your demanding applications.
- Proven to outperform and outlast other pumps in their class
- Highest technology air motor on the market
- Low air consumption for increased efficiency
- Model: Merkur
- Compatible Material: Waterborne, Solvent borne, High Solids, Single Components, Topcoats, Varnish, Lacquer, Acid Catalysts, Enamel, UV Coating
- Fluid Inlet Size (cm): 1.905
- Fluid Inlet Size (in): 3/4
- Fluid Inlet Size (mm): 19.05
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (cm): 0.9525
- Fluid Outlet Size (in): 3/8
- Fluid Outlet Size (mm): 9.525
- Fluid Outlet Thread Type: NPT
- Gun Included: 0
- Gun Model: No Applicator
- Gun Technology: Bare Package
- Gun Type: No Applicator
- Hose Inlet Diameter (cm): 0.476
- Hose Inlet Diameter (in): 3/16
- Hose Inlet Diameter (mm): 4.76
- Includes: Pump and Gun Air Controls, Suction Hose
- Maximum Air Inlet Pressure (bar): 7
- Maximum Air Inlet Pressure (kPa): 700
- Maximum Air Inlet Pressure (psi): 100
- Maximum Flow Rate (GPM): 1.2
- Maximum Flow Rate (L/min): 4.5
- Maximum Working Pressure (bar): 69
- Maximum Working Pressure (kPa): 6900
- Maximum Working Pressure (psi): 1000
- Mount Type: Cart Mount
- Power Source: Air
- Pressure Type: High Pressure
- Product Type: Bare Package
- Pump Ratio: 10:1
- Pump Type: Pneumatic Piston Pump
$6,260.00
MERKUR SYSTEM, PUMP, 10:1, 75CC, CART, STD
GG G10C09
GG G10C09
MERKUR SYSTEM, PUMP, 10:1, 75CC, CART, STD
10:1 Merkur AA Package, 1.2 gpm (4.5 lpm) fluid flow, Cart Mount, PerformAA 15 Gun, Pump Air Controls, Gun Air/Fluid Hose, Fluid Filter Designed to improve productivity, reduce costs, lower emissions and provide consistent, high quality finishes for all of your demanding applications. Proven to outperform and outlast other pumps in their class Highest technology air motor on the market Low air consumption for increased efficiency External valve access allows for easy servicing and online replacement to minimize downtime
$8,640.00
MERKUR SYSTEM PUMP 10:01 75CC WA STD
GG G10W01
GG G10W01
MERKUR SYSTEM PUMP 10:01 75CC WA STD
Graco G10W01 10:1 Merkur Pump, 1.2 gpm (4.5 lpm) fluid flow, Wall Mount, Pump/Gun Air Controls
Designed to improve productivity, reduce costs, lower emissions and provide consistent, high quality finishes for all of your demanding applications.
- Proven to outperform and outlast other pumps in their class
- Highest technology air motor on the market
- Low air consumption for increased efficiency
- Model: Merkur
- Compatible Material: Waterborne, Solvent borne, High Solids, Single Components, Topcoats, Varnish, Lacquer, Acid Catalysts, Enamel, UV Coating
- Fluid Inlet Size (cm): 1.905
- Fluid Inlet Size (in): 3/4
- Fluid Inlet Size (mm): 19.05
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (cm): 0.9525
- Fluid Outlet Size (in): 3/8
- Fluid Outlet Size (mm): 9.525
- Fluid Outlet Thread Type: NPT
- Gun Included: 0
- Gun Model: No Applicator
- Gun Technology: Bare Package
- Gun Type: No Applicator
- Hose Inlet Diameter (cm): 0.476
- Hose Inlet Diameter (in): 3/16
- Hose Inlet Diameter (mm): 4.76
- Includes: Pump and Gun Air Controls
- Maximum Air Inlet Pressure (bar): 7
- Maximum Air Inlet Pressure (kPa): 700
- Maximum Air Inlet Pressure (psi): 100
- Maximum Flow Rate (GPM): 1.2
- Maximum Flow Rate (L/min): 4.5
- Maximum Working Pressure (bar): 69
- Maximum Working Pressure (kPa): 6900
- Maximum Working Pressure (psi): 1000
- Mount Type: Wall Mount
- Power Source: Air
- Pressure Type: High Pressure
- Product Type: Bare Package
- Pump Ratio: 10:1
- Pump Type: Pneumatic Piston Pump
$5,280.00
MERKUR SYSTEM PUMP 10:01 75CC WALL STD
GG G10W05
GG G10W05
MERKUR SYSTEM PUMP 10:01 75CC WALL STD
Graco G10W05 10:1 Merkur AA Package, 1.2 gpm (4.5 lpm) fluid flow, Wall Mount, PerformAA 15 Gun, Pump Air Controls, Gun Air/Fluid Hose, Suction Hose
Designed to improve productivity, reduce costs, lower emissions and provide consistent, high quality finishes for all of your demanding applications.
- Proven to outperform and outlast other pumps in their class
- Highest technology air motor on the market
- Low air consumption for increased efficiency
- Model: Merkur
- Convertible: Non-Convertible
- Fluid Inlet Size (cm): 1.905
- Fluid Inlet Size (in): 3/4
- Fluid Inlet Size (mm): 19.05
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (cm): 0.9525
- Fluid Outlet Size (in): 3/8
- Fluid Outlet Size (mm): 9.525
- Fluid Outlet Thread Type: NPT
- Gun Included: 1
- Gun Model: PerformAA 15 Air Assist
- Gun Technology: Air-Assisted
- Gun Type: Air-Assisted
- Hose Inlet Diameter (cm): 0.4763
- Hose Inlet Diameter (in): 0.1875
- Hose Inlet Diameter (mm): 5
- Includes: Pump and Gun Air Controls, Gun Hose, Suction Hose
- Maximum Flow Rate (GPM): 1.2
- Maximum Hose Length (ft): 25
- Maximum Hose Length (m): 7.6
- Maximum Working Pressure (bar): 69
- Maximum Working Pressure (kPa): 6900
- Maximum Working Pressure (MPa): 6.9
- Maximum Working Pressure (psi): 1000
- Motor Type: Pneumatic
- Mount Type: Wall Mount
- Number of Guns: 1
- Power Source: Air
- Pressure Type: High Pressure
- Product Type: Spray Package
- Pump Ratio: 10:1
- Pump Type: Pneumatic Piston Pump
$7,300.00
MERKUR SYSTEM PUMP 10:1 75CC WALL STD
GG G10W07
GG G10W07
MERKUR SYSTEM PUMP 10:1 75CC WALL STD
Graco G10W07 10:1 Merkur AA Package, 1.2 gpm (4.5 lpm) fluid flow, Wall Mount, PerformAA 15 Gun, Pump Air Controls, Gun Air/Fluid Hose, Filter
Designed to improve productivity, reduce costs, lower emissions and provide consistent, high quality finishes for all of your demanding applications.
- Proven to outperform and outlast other pumps in their class
- Highest technology air motor on the market
- Low air consumption for increased efficiency
- Model: Merkur
- Convertible: Non-Convertible
- Fluid Inlet Size (cm): 1.905
- Fluid Inlet Size (in): 3/4
- Fluid Inlet Size (mm): 19.05
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (cm): 0.9525
- Fluid Outlet Size (in): 3/8
- Fluid Outlet Size (mm): 9.525
- Fluid Outlet Thread Type: NPT
- Gun Included: 1
- Gun Model: PerformAA 15 Air Assist
- Gun Technology: Air-Assisted
- Gun Type: Air-Assisted
- Hose Inlet Diameter (cm): 0.4763
- Hose Inlet Diameter (in): 0.1875
- Hose Inlet Diameter (mm): 5
- Includes: Pump and Gun Air Controls, Gun Hose, Suction Hose, Fluid Filter
- Maximum Flow Rate (GPM): 1.2
- Maximum Hose Length (ft): 25
- Maximum Hose Length (m): 7.6
- Maximum Working Pressure (bar): 69
- Maximum Working Pressure (kPa): 6900
- Maximum Working Pressure (MPa): 6.9
- Maximum Working Pressure (psi): 1000
- Motor Type: Pneumatic
- Mount Type: Wall Mount
- Number of Guns: 1
- Power Source: Air
- Pressure Type: High Pressure
- Product Type: Spray Package
- Pump Ratio: 10:1
- Pump Type: Pneumatic Piston Pump
$7,120.00
MERKUR BELLOWS SYSTEM, PUMP, 50CC, STD
GG G15B01
GG G15B01
MERKUR BELLOWS SYSTEM, PUMP, 50CC, STD
Merkur Bellows 15:1 Ratio Pump Package with V-Packing Seal, Wall Mount, Fluid Filter Graco’s Merkur bellows piston pumps provide low maintenance with no seals exposed to the atmosphere. These pumps are designed to eliminate conventional throat seals, providing high reliability for moisture-sensitive materials. Highest technology air motor on the market Low air consumption for increased efficiency Simple air motor design and minimal parts reduces repair time Easy-to-flush design allows for fast color changes and reduced material waste 300 series stainless steel pump construction provides long-lasting durability
$8,400.00
MERKUR BELLOWS SYSTEM, PUMP, 50CC, SMT
GG G15B04
GG G15B04
MERKUR BELLOWS SYSTEM, PUMP, 50CC, SMT
Graco G15B04 Merkur Bellows 15:1 Ratio Air-Assisted Airless Package with V-Packing, Wall Mount, Fluid Filter, Hoses, PerformAA 15 Spray Gun, DataTrak
Graco’s Merkur bellows piston pumps provide low maintenance with no seals exposed to the atmosphere. These pumps are designed to eliminate conventional throat seals, providing high reliability for moisture-sensitive materials.
- Highest technology air motor on the market
- Low air consumption for increased efficiency
- Simple air motor design and minimal parts reduces repair time
- 300 series stainless steel pump construction provides long-lasting durability
- Model: Merkur
- Series: Bellows
- Application: Supply
- Compatible Material: Waterborne, Solvent borne, High Solids, Xirallic, CARC, Metallics, Topcoats, Stains, Varnish, UV Coating
- Convertible: Non-Convertible
- Fluid Inlet Size (cm): 1.905
- Fluid Inlet Size (in): 3/4
- Fluid Inlet Size (mm): 19.05
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (cm): 0.9525
- Fluid Outlet Size (in): 3/8
- Fluid Outlet Size (mm): 9.525
- Fluid Outlet Thread Type: NPT
- Frame Configuration: Wall
- Gun Included: 1
- Gun Model: G15
- Gun Technology: Air-Assisted
- Gun Type: Air-Assisted
- Includes: Pump and Gun Air Controls, Drain Valves, Fluid Filter, DataTrak, V-Packing
- Maximum Flow Rate (GPM): 0.8
- Maximum Hose Length (ft): 25
- Maximum Hose Length (m): 7.6
- Maximum Working Pressure (bar): 103
- Maximum Working Pressure (kPa): 10300
- Maximum Working Pressure (MPa): 10.3
- Maximum Working Pressure (psi): 1500
- Motor Type: Pneumatic
- Mount Type: Wall Mount
- Number of Guns: 1
- Outlet Paint Filter: 60 Mesh Stainless Steel Screen
- Power Source: Air
- Pressure Type: High Pressure
- Product Type: Spray Package
- Pump Ratio: 15:1
- Pump Type: Pneumatic Piston Pump
$11,140.00
MERKUR BELLOWS SYSTEM, PUMP, 50CC, STD
GG G15B17
GG G15B17
MERKUR BELLOWS SYSTEM, PUMP, 50CC, STD
Merkur Bellows 15:1 Ratio Pump Package with U-Cup Seal, Wall Mount, Fluid Filter Graco’s Merkur bellows piston pumps provide low maintenance with no seals exposed to the atmosphere. These pumps are designed to eliminate conventional throat seals, providing high reliability for moisture-sensitive materials. Highest technology air motor on the market Low air consumption for increased efficiency Simple air motor design and minimal parts reduces repair time Easy-to-flush design allows for fast color changes and reduced material waste 300 series stainless steel pump construction provides long-lasting durability
$8,650.00
MERKUR BELLOWS SYSTEM, PUMP, 150CC, SMT
GG G15B52
GG G15B52
MERKUR BELLOWS SYSTEM, PUMP, 150CC, SMT
Graco G15B52 Merkur™ Bellows 15:1 Ratio Pump Package with Wall Mount, V-Packing & DataTrak
The gentle pumping action of the Merkur Bellows Pump, combined with reduced sealing surfaces, provides superior handling of shear-sensitive materials, including UV coatings and waterborne materials.
- Highest technology air motor on the market
- Low air consumption for increased efficiency
- Simple air motor design and minimal parts reduces repair time
- 300 series stainless steel pump construction provides long-lasting durability
- Fewer parts and online replacement bellows seal means improved serviceability, lower cost of ownership and reduced downtime
- Model: Merkur
- Series: Bellows
- Application: Supply
- Compatible Material: Waterborne, Solvent borne, High Solids, Xirallic, CARC, Metallics, Topcoats, Stains, Varnish, UV Coating
- Fluid Inlet Size (cm): 2.5400
- Fluid Inlet Size (in): 1
- Fluid Inlet Size (mm): 25.4000
- Fluid Inlet Thread Gender: Male
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (cm): 1.905
- Fluid Outlet Size (in): 3/4
- Fluid Outlet Size (mm): 19.05
- Fluid Outlet Thread Gender: Male
- Fluid Outlet Thread Type: NPT
- Includes: Pump Only Air Controls, Fluid Filter, DataTrak Monitor
- Material: Stainless Steel
- Maximum Flow Rate (gpm @ 60 cpm): 2.4
- Maximum Operating Temperature (°F): 120
- Maximum Working Pressure (bar): 103
- Maximum Working Pressure (kPa): 10300
- Maximum Working Pressure (MPa): 10.3
- Maximum Working Pressure (psi): 1500
- Motor Type: Pneumatic
- Mount Location: Wall Mount
- Number of Pieces: 3
$12,910.00
MERKUR BELLOWS SYSTEM, PUMP, 150CC, STD
GG G15B59
GG G15B59
MERKUR BELLOWS SYSTEM, PUMP, 150CC, STD
Merkur™ Bellows 15:1 Ratio Pump Package with Wall Mount & V-Packing The gentle pumping action of the Merkur Bellows Pump, combined with reduced sealing surfaces, provides superior handling of shear-sensitive materials, including UV coatings and waterborne materials. Highest technology air motor on the market Low air consumption for increased efficiency Simple air motor design and minimal parts reduces repair time Easy-to-flush design allows for fast color changes and reduced material waste 300 series stainless steel pump construction provides long-lasting durability Fewer parts and online replacement bellows seal means improved serviceability, lower cost of ownership and reduced downtime
$9,780.00
MERKUR SYSTEM, PUMP, 15:1, 25CC, CART, STD
GG G15C07
GG G15C07
MERKUR SYSTEM, PUMP, 15:1, 25CC, CART, STD
Graco G15C07 15:1 Merkur AA Package, 0.4 gpm (1.5 lpm) fluid flow, Cart Mount, PerformAA 15 Gun, Pump Air Controls, Gun Air/Fluid Hose, Suction Hose
Designed to improve productivity, reduce costs, lower emissions and provide consistent, high quality finishes for all of your demanding applications.
- Proven to outperform and outlast other pumps in their class
- Highest technology air motor on the market
- Low air consumption for increased efficiency
- Model: Merkur
- Convertible: Non-Convertible
- Fluid Inlet Size (cm): 1.27
- Fluid Inlet Size (in): 1/2
- Fluid Inlet Size (mm): 12.7
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (cm): 0.9525
- Fluid Outlet Size (in): 3/8
- Fluid Outlet Size (mm): 9.525
- Fluid Outlet Thread Type: NPT
- Gun Included: 1
- Gun Model: PerformAA 15 Air Assist
- Gun Technology: Air-Assisted
- Gun Type: Air-Assisted
- Hose Inlet Diameter (cm): 0.4763
- Hose Inlet Diameter (in): 0.1875
- Hose Inlet Diameter (mm): 5
- Includes: Pump and Gun Air Controls, Gun Hose, Suction Hose
- Maximum Flow Rate (GPM): 0.4
- Maximum Hose Length (ft): 25
- Maximum Hose Length (m): 7.6
- Maximum Working Pressure (bar): 103
- Maximum Working Pressure (kPa): 10300
- Maximum Working Pressure (MPa): 10.3
- Maximum Working Pressure (psi): 1500
- Motor Type: Pneumatic
- Mount Type: Cart Mount
- Number of Guns: 1
- Power Source: Air
- Pressure Type: High Pressure
- Product Type: Spray Package
- Pump Ratio: 15:1
- Pump Type: Pneumatic Piston Pump
$5,520.00
MERKUR SYSTEM, PUMP, 15:1, 25CC, CART, STD
GG G15C09
GG G15C09
MERKUR SYSTEM, PUMP, 15:1, 25CC, CART, STD
15:1 Merkur AA Package, 0.4 gpm (1.5 lpm) fluid flow, Cart Mount, PerformAA 15 Gun, Pump/Gun Air Controls, Gun Air/Fluid Hose, Fluid Filter Designed to improve productivity, reduce costs, lower emissions and provide consistent, high quality finishes for all of your demanding applications. Proven to outperform and outlast other pumps in their class Highest technology air motor on the market Low air consumption for increased efficiency External valve access allows for easy servicing and online replacement to minimize downtime
$6,050.00
MERKUR SYSTEM, PUMP, 15:1, 25CC, CART, STD
GG G15C13
GG G15C13
MERKUR SYSTEM, PUMP, 15:1, 25CC, CART, STD
Graco G15C13 15:1 Merkur AA Package, 0.4 gpm (1.5 lpm) flow, Cart Mount, PerformAA 15 Gun, Pump/Gun Air Controls, Gun Air/Fluid Hose, Fluid Filter, Hopper
Designed to improve productivity, reduce costs, lower emissions and provide consistent, high quality finishes for all of your demanding applications.
- Proven to outperform and outlast other pumps in their class
- Highest technology air motor on the market
- Low air consumption for increased efficiency
- Model: Merkur
- Convertible: Non-Convertible
- Fluid Inlet Size (cm): 1.27
- Fluid Inlet Size (in): 1/2
- Fluid Inlet Size (mm): 12.7
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (cm): 0.9525
- Fluid Outlet Size (in): 3/8
- Fluid Outlet Size (mm): 9.525
- Fluid Outlet Thread Type: NPT
- Gun Included: 1
- Gun Model: PerformAA 15 Air Assist
- Gun Technology: Air-Assisted
- Gun Type: Air-Assisted
- Hose Inlet Diameter (cm): 0.4763
- Hose Inlet Diameter (in): 0.1875
- Hose Inlet Diameter (mm): 5
- Includes: Pump and Gun Air Controls, Gun Hose, Fluid Filter, Hopper
- Maximum Flow Rate (GPM): 0.4
- Maximum Hose Length (ft): 25
- Maximum Hose Length (m): 7.6
- Maximum Working Pressure (bar): 103
- Maximum Working Pressure (kPa): 10300
- Maximum Working Pressure (MPa): 10.3
- Maximum Working Pressure (psi): 1500
- Motor Type: Pneumatic
- Mount Type: Cart Mount
- Number of Guns: 1
- Power Source: Air
- Pressure Type: High Pressure
- Product Type: Spray Package
- Pump Ratio: 15:1
- Pump Type: Pneumatic Piston Pump
$7,250.00
MERKUR SYSTEM, PUMP, 15:1, 50CC, CART, STD
GG G15C23
GG G15C23
MERKUR SYSTEM, PUMP, 15:1, 50CC, CART, STD
Graco G15C23 15:1 Merkur Pump, 0.8 gpm (3 lpm) fluid flow, Cart Mount, Pump/Gun Air Controls, Suction Hose
Designed to improve productivity, reduce costs, lower emissions and provide consistent, high quality finishes for all of your demanding applications.
- Proven to outperform and outlast other pumps in their class
- Highest technology air motor on the market
- Low air consumption for increased efficiency
- Model: Merkur
- Compatible Material: Waterborne, Solvent borne, High Solids, Single Components, Topcoats, Varnish, Lacquer, Acid Catalysts, Enamel, UV Coating
- Fluid Inlet Size (cm): 1.905
- Fluid Inlet Size (in): 3/4
- Fluid Inlet Size (mm): 19.05
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (cm): 0.9525
- Fluid Outlet Size (in): 3/8
- Fluid Outlet Size (mm): 9.525
- Fluid Outlet Thread Type: NPT
- Gun Included: 0
- Gun Model: No Applicator
- Gun Technology: Bare Package
- Gun Type: No Applicator
- Hose Inlet Diameter (cm): 0.476
- Hose Inlet Diameter (in): 3/16
- Hose Inlet Diameter (mm): 4.76
- Includes: Pump and Gun Air Controls, Suction Hose
- Maximum Air Inlet Pressure (bar): 7
- Maximum Air Inlet Pressure (kPa): 700
- Maximum Air Inlet Pressure (psi): 100
- Maximum Flow Rate (GPM): 0.8
- Maximum Flow Rate (L/min): 3.0
- Maximum Working Pressure (bar): 103
- Maximum Working Pressure (kPa): 10300
- Maximum Working Pressure (psi): 1500
- Mount Type: Cart Mount
- Power Source: Air
- Pressure Type: High Pressure
- Product Type: Bare Package
- Pump Ratio: 15:1
- Pump Type: Pneumatic Piston Pump
$5,800.00
MERKUR SYSTEM, PUMP, 15:1, 50CC, CART, STD
GG G15C27
GG G15C27
MERKUR SYSTEM, PUMP, 15:1, 50CC, CART, STD
15:1 Merkur AA Package, 0.8 gpm (3 lpm) fluid flow, Cart Mount, PerformAA 15 Gun, Pump Air Controls, Gun Air/Fluid Hose, Suction Hose Designed to improve productivity, reduce costs, lower emissions and provide consistent, high quality finishes for all of your demanding applications. Proven to outperform and outlast other pumps in their class Highest technology air motor on the market Low air consumption for increased efficiency External valve access allows for easy servicing and online replacement to minimize downtime
$6,260.00
MERKUR SYSTEM, PUMP, 15:1, 50CC, CART, STD
GG G15C29
GG G15C29
MERKUR SYSTEM, PUMP, 15:1, 50CC, CART, STD
Graco G15C29 15:1 Merkur AA Package, 0.8 gpm (3 lpm) fluid flow, Cart Mount, PerformAA 15 Gun, Pump Air Controls, Gun Air/Fluid Hose, Fluid Filter
Designed to improve productivity, reduce costs, lower emissions and provide consistent, high quality finishes for all of your demanding applications.
- Proven to outperform and outlast other pumps in their class
- Highest technology air motor on the market
- Low air consumption for increased efficiency
- Model: Merkur
- Convertible: Non-Convertible
- Fluid Inlet Size (cm): 1.905
- Fluid Inlet Size (in): 3/4
- Fluid Inlet Size (mm): 19.05
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (cm): 0.9525
- Fluid Outlet Size (in): 3/8
- Fluid Outlet Size (mm): 9.525
- Fluid Outlet Thread Type: NPT
- Gun Included: 1
- Gun Model: PerformAA 15 Air Assist
- Gun Technology: Air-Assisted
- Gun Type: Air-Assisted
- Hose Inlet Diameter (cm): 0.4763
- Hose Inlet Diameter (in): 0.1875
- Hose Inlet Diameter (mm): 5
- Includes: Pump and Gun Air Controls, Gun Hose, Suction Hose, Fluid Filter
- Maximum Flow Rate (GPM): 0.8
- Maximum Hose Length (ft): 25
- Maximum Hose Length (m): 7.6
- Maximum Working Pressure (bar): 103
- Maximum Working Pressure (kPa): 10300
- Maximum Working Pressure (MPa): 10.3
- Maximum Working Pressure (psi): 1500
- Motor Type: Pneumatic
- Mount Type: Cart Mount
- Number of Guns: 1
- Power Source: Air
- Pressure Type: High Pressure
- Product Type: Spray Package
- Pump Ratio: 15:1
- Pump Type: Pneumatic Piston Pump
$6,790.00
MERKUR SYSTEM PUMP 15:01 150CC CT STD
GG G15C77
GG G15C77
MERKUR SYSTEM PUMP 15:01 150CC CT STD
Graco G15C77 15:1 Merkur Pump, 2.4 gpm (9 lpm) fluid flow, Cart Mount, Pump Air Controls
Designed to improve productivity, reduce costs, lower emissions and provide consistent, high quality finishes for all of your demanding applications.
- Proven to outperform and outlast other pumps in their class
- Highest technology air motor on the market
- Low air consumption for increased efficiency
- Model: Merkur
- Compatible Material: Waterborne, Solvent borne, High Solids, Single Components, Topcoats, Varnish, Lacquer, Acid Catalysts, Enamel, UV Coating
- Fluid Inlet Size (cm): 2.54
- Fluid Inlet Size (in): 1
- Fluid Inlet Size (mm): 25.4
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (cm): 1.905
- Fluid Outlet Size (in): 3/4
- Fluid Outlet Size (mm): 19.05
- Fluid Outlet Thread Type: NPT
- Gun Included: 0
- Gun Model: No Applicator
- Gun Technology: Bare Package
- Gun Type: No Applicator
- Hose Inlet Diameter (cm): 0.476
- Hose Inlet Diameter (in): 3/16
- Hose Inlet Diameter (mm): 4.76
- Includes: Pump Only Air Controls
- Maximum Air Inlet Pressure (bar): 7
- Maximum Air Inlet Pressure (kPa): 700
- Maximum Air Inlet Pressure (psi): 100
- Maximum Flow Rate (GPM): 2.4
- Maximum Flow Rate (L/min): 9.0
- Maximum Working Pressure (bar): 103
- Maximum Working Pressure (kPa): 10300
- Maximum Working Pressure (psi): 1500
- Mount Type: Cart Mount
- Power Source: Air
- Pressure Type: High Pressure
- Product Type: Bare Package
- Pump Ratio: 15:1
- Pump Type: Pneumatic Piston Pump
$8,510.00
MERKUR SYSTEM PUMP 15:01 150CC CT STD
GG G15C79
GG G15C79
MERKUR SYSTEM PUMP 15:01 150CC CT STD
Graco G15C79 15:1 Merkur Pump, 2.4 gpm (9 lpm) fluid flow, Cart Mount, Pump Air Controls, Suction Hose, Fluid Filter
Designed to improve productivity, reduce costs, lower emissions and provide consistent, high quality finishes for all of your demanding applications.
- Proven to outperform and outlast other pumps in their class
- Highest technology air motor on the market
- Low air consumption for increased efficiency
- Model: Merkur
- Compatible Material: Waterborne, Solvent borne, High Solids, Single Components, Topcoats, Varnish, Lacquer, Acid Catalysts, Enamel, UV Coating
- Fluid Inlet Size (cm): 2.54
- Fluid Inlet Size (in): 1
- Fluid Inlet Size (mm): 25.4
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (cm): 1.905
- Fluid Outlet Size (in): 3/4
- Fluid Outlet Size (mm): 19.05
- Fluid Outlet Thread Type: NPT
- Gun Included: 0
- Gun Model: No Applicator
- Gun Technology: Bare Package
- Gun Type: No Applicator
- Hose Inlet Diameter (cm): 0.476
- Hose Inlet Diameter (in): 3/16
- Hose Inlet Diameter (mm): 4.76
- Includes: Pump Only Air Controls, Suction Hose, Fluid Filter
- Maximum Air Inlet Pressure (bar): 7
- Maximum Air Inlet Pressure (kPa): 700
- Maximum Air Inlet Pressure (psi): 100
- Maximum Flow Rate (GPM): 2.4
- Maximum Flow Rate (L/min): 9.0
- Maximum Working Pressure (bar): 103
- Maximum Working Pressure (kPa): 10300
- Maximum Working Pressure (psi): 1500
- Mount Type: Cart Mount
- Power Source: Air
- Pressure Type: High Pressure
- Product Type: Bare Package
- Pump Ratio: 15:1
- Pump Type: Pneumatic Piston Pump
$9,070.00
MERKUR SYSTEM PUMP 15:1 150CC CART STD
GG G15C83
GG G15C83
MERKUR SYSTEM PUMP 15:1 150CC CART STD
15:1 Merkur Pump, 2.4 gpm (9 lpm) fluid flow, Cart Mount, PerformAA 15, Pump Air Controls, Gun Air/Fluid Hose, Suction Hose, Filter Designed to improve productivity, reduce costs, lower emissions and provide consistent, high quality finishes for all of your demanding applications. Proven to outperform and outlast other pumps in their class Highest technology air motor on the market Low air consumption for increased efficiency External valve access allows for easy servicing and online replacement to minimize downtime
$10,150.00
MERKUR SYSTEM, PUMP, 15:1, 25CC, 1LEG, STD
GG G15T03
GG G15T03
MERKUR SYSTEM, PUMP, 15:1, 25CC, 1LEG, STD
Graco G15T03 15:1 Merkur AA Package, 0.4 gpm (1.5 lpm) fluid flow, Stand Mount, PerformAA 15 Gun, Pump Air Controls, Gun Air/Fluid Hose, Suction Hose
Designed to improve productivity, reduce costs, lower emissions and provide consistent, high quality finishes for all of your demanding applications.
- Proven to outperform and outlast other pumps in their class
- Highest technology air motor on the market
- Low air consumption for increased efficiency
- Model: Merkur
- Convertible: Non-Convertible
- Fluid Inlet Size (cm): 1.27
- Fluid Inlet Size (in): 1/2
- Fluid Inlet Size (mm): 12.7
- Fluid Inlet Thread Type: NPT
- Fluid Outlet Size (cm): 0.9525
- Fluid Outlet Size (in): 3/8
- Fluid Outlet Size (mm): 9.525
- Fluid Outlet Thread Type: NPT
- Gun Included: 1
- Gun Model: PerformAA 15 Air Assist
- Gun Technology: Air-Assisted
- Gun Type: Air-Assisted
- Hose Inlet Diameter (cm): 0.4763
- Hose Inlet Diameter (in): 0.1875
- Hose Inlet Diameter (mm): 5
- Includes: Pump and Gun Air Controls, Gun Hose, Suction Hose
- Maximum Flow Rate (GPM): 0.4
- Maximum Hose Length (ft): 25
- Maximum Hose Length (m): 7.6
- Maximum Working Pressure (bar): 103
- Maximum Working Pressure (kPa): 10300
- Maximum Working Pressure (MPa): 10.3
- Maximum Working Pressure (psi): 1500
- Motor Type: Pneumatic
- Mount Type: Stand Mount
- Number of Guns: 1
- Power Source: Air
- Pressure Type: High Pressure
- Product Type: Spray Package
- Pump Ratio: 15:1
- Pump Type: Pneumatic Piston Pump
$5,780.00
Payment options
