Finishing Packages

GG G35B09

MERKUR BELLOWS SYSTEM, PUMP, 100CC, STD

Merkur Bellows 35:1 Ratio Pump Package with V-Packing Seal, Wall MountGraco’s Merkur bellows piston pumps provide low maintenance with no seals exposed to the atmosphere. These pumps are designed to eliminate conventional throat seals, providing high reliability for moisture-sensitive materials.Highest technology air motor on the marketLow air consumption for increased efficiencySimple air motor design and minimal parts reduces repair timeEasy-to-flush design allows for fast color changes and reduced material waste300 series stainless steel pump construction provides long-lasting durability

GG G35B35

MERKUR BELLOWS SYSTEM, PUMP, 100CC, STD

Graco G35B35 Merkur Bellows 35:1 Ratio Airless Package with Cart Mount, V-Packing & XTR Gun

The gentle pumping action of the Merkur Bellows Pump, combined with reduced sealing surfaces, provides superior handling of shear-sensitive materials, including UV coatings and waterborne materials.

• Highest technology air motor on the market
• Low air consumption for increased efficiency
• Simple air motor design and minimal parts reduces repair time
• 300 series stainless steel pump construction provides long-lasting durability
• Fewer parts and online replacement bellows seal means improved serviceability, lower cost of ownership and reduced downtime

• Model: Merkur
• Series: Bellows

• Application: Supply

• Compatible Material: Waterborne, Solvent borne, High Solids, Xirallic, CARC, Metallics, Topcoats, Stains, Varnish, UV Coating

• Convertible: Non-Convertible

• Fluid Inlet Size (in): 3/4
• Fluid Inlet Size (mm): 19.05
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (in): 3/8
• Fluid Outlet Size (mm): 3.75
• Fluid Outlet Thread Type: NPT

• Frame Configuration: Cart

• Includes: Pump Air controls, XTR Gun, Fluid Hose, Gun Fluid Hose, Suction Hose and Tube, Drain Valves, Fluid Filter

• Maximum Flow Rate (GPM): 1.6
• Maximum Flow Rate (L/min): 6.0

• Maximum Hose Length (ft): 25
• Maximum Hose Length (m): 7.5

• Maximum Working Pressure (bar): 241
• Maximum Working Pressure (kPa): 24100
• Maximum Working Pressure (MPa): 24.1
• Maximum Working Pressure (psi): 3500

• Motor Type: Pneumatic

• Number of Guns: 1

• Outlet Paint Filter: 60 Mesh Stainless Steel Screen

• Power Source: Air

• Pump Type: Piston

GG G36C03

MERKUR SYSTEM, PUMP, 36:1, 100CC, CART, STD

Merkur 36:1 Cart-Mount Airless Spray Package, XTR-5 Gun, 519 XHD Tip, 25 ft (7.6 m) Fluid Hose, Fluid Filter

The Merkur Airless Sprayer for protective coatings is ideal for touch-ups or other smaller projects. Its light weight and portability make it a great mobile auxiliary system to finish up a job in tight areas. Ideal for coatings that don’t require the pressure and flow of a larger sprayer.

Compact – fits into tight areasSprays medium to higher solids coatings – up to 4800 psi (331 bar)Ideal for applications such as steel fabrication, marine, rail, industrial and structural steelEasy to use, easy to cleanStainless steel option allows for waterborne coatings

GG G36C09

MERKUR SYSTEM PUMP 36:1 100CC CART STD

36:1 Merkur AA Package, 1.6 gpm (6 lpm) fluid flow, Cart Mount, PerformAA 50 Gun, Pump Air Controls, Gun Air/Fluid Hose, Fluid FilterDesigned to improve productivity, reduce costs, lower emissions and provide consistent, high quality finishes for all of your demanding applications.Proven to outperform and outlast other pumps in their classHighest technology air motor on the marketLow air consumption for increased efficiencyExternal valve access allows for easy servicing and online replacement to minimize downtime

GG G36C13

MERKUR SYSTEM, PUMP, 36:1, 100CC CART, STD

36:1 Merkur AA Package, 1.6 gpm (6 lpm) fluid flow, Cart Mount, PerformAA 50 Gun, Pump Air Controls, Gun Air/Fluid Hose, Fluid Filter, Drain ValveDesigned to improve productivity, reduce costs, lower emissions and provide consistent, high quality finishes for all of your demanding applications.Proven to outperform and outlast other pumps in their classHighest technology air motor on the marketLow air consumption for increased efficiencyExternal valve access allows for easy servicing and online replacement to minimize downtime

GG G36W05

MERKUR SYSTEM PUMP 36:01 100CC WA STD

36:1 Merkur Pump, 1.6 gpm (6 lpm) fluid flow, Wall Mount, Pump Air Controls, Suction Hose, Fluid FilterDesigned to improve productivity, reduce costs, lower emissions and provide consistent, high quality finishes for all of your demanding applications.Proven to outperform and outlast other pumps in their classHighest technology air motor on the marketLow air consumption for increased efficiencyExternal valve access allows for easy servicing and online replacement to minimize downtime

GG G45C15

MERKUR SYSTEM PUMP 45:1 50CC CART STD

45:1 Merkur AA Package, 0.8 gpm (3 lpm) fluid flow, Cart Mount, PerformAA 50 Gun, Pump Air Controls, Gun Air/Fluid Hose, Fluid FilterDesigned to improve productivity, reduce costs, lower emissions and provide consistent, high quality finishes for all of your demanding applications.Proven to outperform and outlast other pumps in their classHighest technology air motor on the marketLow air consumption for increased efficiencyExternal valve access allows for easy servicing and online replacement to minimize downtime

GG G45C17

MERKUR SYSTEM, PUMP 45:1, 50CC CART, STD

45:1 Merkur AA Package, 0.8 gpm (3 lpm) fluid flow, Cart Mount, PerformAA 50 RAC Gun, Pump Air Controls, Gun Air/Fluid Hose, Fluid FilterDesigned to improve productivity, reduce costs, lower emissions and provide consistent, high quality finishes for all of your demanding applications.Proven to outperform and outlast other pumps in their classHighest technology air motor on the marketLow air consumption for increased efficiencyExternal valve access allows for easy servicing and online replacement to minimize downtime

GG G45W01

MERKUR SYSTEM PUMP 45:1 50CC WA STD

45:1 Merkur Pump, 0.8 gpm (3 lpm) fluid flow, Wall MountDesigned to improve productivity, reduce costs, lower emissions and provide consistent, high quality finishes for all of your demanding applications.Proven to outperform and outlast other pumps in their classHighest technology air motor on the marketLow air consumption for increased efficiencyExternal valve access allows for easy servicing and online replacement to minimize downtime

GG G48C01

MERKUR SYSTEM, PUMP, 48:1, 75CC CT, STD

48:1 Merkur Pump, 1.2 gpm (4.5 lpm) fluid flow, Cart Mount, Pump Air Controls, Suction Hose, Fluid FilterDesigned to improve productivity, reduce costs, lower emissions and provide consistent, high quality finishes for all of your demanding applications.Proven to outperform and outlast other pumps in their classHighest technology air motor on the marketLow air consumption for increased efficiencyExternal valve access allows for easy servicing and online replacement to minimize downtime

GG G48C05

MERKUR SYSTEM, PUMP, 48:1, 75CC, CART, STD

Merkur 48:1 Cart-Mount Airless Spray Package, XTR-5 Gun, 519 XHD Tip, 25 ft (7.6 m) Fluid Hose, Fluid Filter, Drain Valve

The Merkur Airless Sprayer for protective coatings is ideal for touch-ups or other smaller projects. Its light weight and portability make it a great mobile auxiliary system to finish up a job in tight areas. Ideal for coatings that don’t require the pressure and flow of a larger sprayer.

Compact – fits into tight areasSprays medium to higher solids coatings – up to 4800 psi (331 bar)Ideal for applications such as steel fabrication, marine, rail, industrial and structural steelEasy to use, easy to cleanStainless steel option allows for waterborne coatings

GG G48C06

MERKUR SYSTEM, PUMP, 48:1, 75CC, CART, SMT

Graco G48C06 Merkur 48:1 Cart-Mount Airless Spray Package, XTR-5 Gun, 519 XHD Tip, 25 ft (7.6 m) Fluid Hose, Fluid Filter, DataTrak, Drain Valve

The Merkur Airless Sprayer for protective coatings is ideal for touch-ups or other smaller projects. Its light weight and portability make it a great mobile auxiliary system to finish up a job in tight areas. Ideal for coatings that don't require the pressure and flow of a larger sprayer.

• Compact - fits into tight areas
• Sprays medium to higher solids coatings - up to 4800 psi (331 bar)
• Ideal for applications such as steel fabrication, marine, rail, industrial and structural steel
• Stainless steel option allows for waterborne coatings

• Model: Merkur
• Series: Standard

• Air Inlet Size (in): 1/2
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Compatible Material: Protective Coating
• Compatible Replacement Pump: W48CAS

• Control Type: Fixed Ratio
• Convertible: Non-Convertible

• Fluid Inlet Size (in): 3/4
• Fluid Inlet Size (mm): 19.05
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (in): 3/8, 1/4
• Fluid Outlet Size (mm): 9.525, 6.35
• Fluid Outlet Thread Gender: Male
• Fluid Outlet Thread Type: NPT

• Frame Configuration: Cart Mount

• Hose Inlet Diameter (cm): 0.635
• Hose Inlet Diameter (in): 1/4
• Hose Inlet Diameter (mm): 6.35

• Includes: XTR-5 Spray Gun, 512 XHD Tip, Fluid Hose, Fluid Filter
• Inlet Paint Strainer: 8 Mesh, 16 Mesh

• Lower Configuration: Stainless Steel, 3/4 in. Inlet, Fluid Filter,Drain Valve

• Material Application: Paints, Primers

• Maximum Air Inlet Pressure (psi): 100

• Maximum Flow Rate (GPM): 1.2
• Maximum Flow Rate (L/min): 4.5

• Maximum Fluid Working Pressure (psi): 4800

• Maximum Sound Pressure Level (dB(A)): 68.9

• Maximum Tip Size (in): 0.025

• Maximum Working Pressure (bar): 331
• Maximum Working Pressure (kPa): 33100
• Maximum Working Pressure (MPa): 33.1
• Maximum Working Pressure (psi): 4800

• Mix Ratio: 48:1
• Motor Type: Pneumatic Motor

• Mount Type: Cart Mount

• Number of Guns: 1

• Outlet Paint Filter: 60 Mesh Stainless Steel Screen

• Package Options: XTR-5 Gun, 1/4 in. x 25 ft. (7.6 m) Hose

• Power Source: Air
• Pressure Control Type: Air Regulator

• Product Type: Single Leg

• Pump Pressure Ratio: 48:1
• Pump Rod Type: Carbon Steel
• Pump Sleeve Material: Stainless Steel
• Pump Type: Displacement Pump, Pneumatic Piston Pump

GG HFRB-21AQARANN

HFR SYSTEM

GG LB150A

Merkur Bellows 303 SST Displacement Pump, 150 cc, 3 Uhmwpe / 2 Ptfe V-Packings

GG P2H153

Reactor 2 H-50 Elite Proportioner Package

PC CX2017HC-A2M0T25

Century Gel Coat System

RR A13901-011300027

Evolver 560 Se

RR RM2-11127

RM2 LP STD GEAR 300 7R 1H PKG

RR RM2-21158

Pkg Rm2 Mp Std Gear Pls 3R 2H

GG 2009106

SPRAYER, 40:1, E-MAX, 230V, PC COMPLETE

King E-Max XT 40:1 Electric Airless Sprayer, Protective Coatings CompleteIntroducing the industry’s most powerful line of electric airless sprayers, the King E-Max XT 40:1! Designed for big jobs, this lineup delivers unmatched performance with the toughest coatings and is equipped with groundbreaking features that reduce downtime while saving you money.Built for your job: perfect for protective coatings application.Electric XT Motor

• High-torque, low RPM design for maximum performance
• 230V-30A input power - equipped with common L6-30P Plug
• Zero-maintenance brushless design

Precision Drive

• Offers precise linear action for long pump life and no side loading
• Long stroke design with hardened steel construction is built to last
• Worry-free design requires little to no maintenance
Heavy-Duty Cart
• Designed for the toughest job site conditions
• Heavy-duty painted steel construction
• Flat-proof tires for maximum convenience
Direct-Immersion Endurance Pump With ProConnect
• Chromex rod and stainless steel cylinder for maximum life and performance
• ProConnect pump removal and replacement keeps you spraying
• Versatile design allows you to select different performance lowers for different jobs - like having 3 sprayers in one
• Included in Endurance Advantage Program
SmartControl
• Advanced control offers consistent spray fan without fluctuations/li>
• Single-knob pressure adjustment — nothing is easier
• WatchDog pump protection system automatically shuts down the pump when material runs out
