INGERSOLL-RAND IR TOOL S12880

IR 2145-11

Front End Plate for Ingersoll Rand 2145 Series Impact Wrench

• For Use With: 2145QIMAX-3
• For Use With: 2145QIMAX-6

IR 2141-A40

IR 2141-A93

Trigger Assembly for Ingersoll Rand 2141, 2145 Series Impact Wrench

IR 2145-11X

Wear Plate for Ingersoll Rand 2145 Series Impact Wrench

Product Application and Uses:

For use with Ingersoll Rand 2145QIMAX, 2145QIMAX-3, 2145QIMAX-6, and 2155QIMAX Impacts

• For Use With: 2145QIMAX
• For Use With: 2145QIMAX-3
• For Use With: 2145QIMAX-6
• For Use With: 2155QIMAX

IR 2141-A626

IR 2141-K303

Inlet Kit Replacement Part

Product Application and Uses:

For Use with Ingersoll Rand 2145QiMAX and 2155QiMAX Series Impact Wrenches

• Includes: O-ring Seal, Throttle Spring, Throttle Valve, Valve Seat, Seat Support, Retainer

• For Use With: 2145QIMAX-3
• For Use With: 2145QIMAX-3-AP
• For Use With: 2145QIMAX-6
• For Use With: 2145QIMAX-6-AP
• For Use With: 2145QIMAX-AP
• For Use With: 2145QIMAX-SP
• For Use With: 2155QIMAX

IR 2145QIMAX-6-A40

IR 2146-A3

Cylinder Rotor Pressure Gauge Assembly for Ingersoll Rand 2146 Series Impact Wrench

Product Application and Uses:

For use with Ingersoll Rand 2146Q1MAX, 2146Q1MAX-3, 2146Q1MAX-6 and 2146Q2MAX Impact Wrenches

• Includes: Ball Bearing Cylinder, Spacer, Cylinder, Rotor

• For Use With: 2146Q1MAX
• For Use With: 2146Q1MAX-3
• For Use With: 2146Q1MAX-6
• For Use With: 2146Q2MAX

IR 2146Q1MAX

3/4" Air Impact Wrench, Quiet, 2000 ft-lb Torque, Friction Ring-Thru-hole Retainer, Pistol

Description: The 2146MAX Series Impact Wrenches- including the 2146Q1MAX, is the most powerful 3/4" impact in its class. These tools have been engineered with an innovative pressure gauge that ensures optimized air flow and pressure. These quiet impact wrenches help you maximize productivity across a range of jobs and tackle anything that comes your way. And because you can avoid operating below and above the recommended 90 PSI air pressure, your tool will last longer and perform more reliably. Work more and spend less, the 2146MAX Series helps you do what you do best.

Features And Benefits:

• Cold-forged twin hammer impact mechanism and motor deliver 2,000 ft-lbs of Nut Busting Torque, durability, and efficiency
• Steel hammer case stands up to drops and everyday abuse
• Patented one-hand forward/reverse and feather-touch trigger provides maximum control
• Ingersoll Rand's Quiet Technology reduces the sound of the tool, sparing your ears without sacrificing a single ounce of power
• Pressure gauge improves productivity and prolongs product life
• A lightweight, balanced, air impact wrench that weighs just 7.8 lbs
• Standard 3/4" drive size and length for access to confined bolt locations
• Impact and chemical-resistant housing protects against repeated drops and exposure to shop fluids
• Optimized for the vehicle repair industry, heavy trucks, tire lanes, fleet maintenance, body shops, general industrial use, MRO, rail, heavy machinery, oil and gas, shipbuilding and construction

Product Application and Uses:

Vehicle Repair, General Industrial, Facility Maintenance

• Includes: Bare Tool
• Actuation/Throttle Type/Switch Type: Trigger
• Air Consumption @ Load (cfm): 36
• Air Consumption @ Load (l/min): 1090
• Air Inlet: 1/2in NPT
• Air Pressure (psi): 90
• Anvil Length: Standard
• Average Air Consumption (cfm): 14
• Average Air Consumption (l/min): 396

• Blows per Min: 1075

• Color: Grey
• Configuration/Handle Type: Pistol Grip
• Drive Size (in): 3/4
• Drive Type: Square
• Duty Rating: Maintenance Duty

• End Plates: Steel
• Exhaust Location: Bottom
• Free Speed Sound Pressure/Power Db(A): 88.8 / 99.8

• Hammer Case: Steel
• Handle Material: Composite
• Housing Material: Impact and chemical-resistant composite housing and patented steel reinforced frame
• Impact Mechanism: Twin Hammer
• Impacting Sound Pressure/Power Db(A): 94.3 /105.3

• Max Bolt Diameter (in): 1
• Max Free Speed (rpm): 5500
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 1453
• Max Torque (in-lb): 17436
• Max Torque (nm): 1970
• Min Hose Size (in): 1/2
• Motor: Reverse Bias

• Number of Power Settings: 4
• Nut-busting/Breakaway Torque (ft-lb): 2000
• Nut-busting/Breakaway Torque (in-lb): 24003
• Nut-busting/Breakaway Torque (nm): 2712
• Power Source: Air Powered
• Power to Weight Ratio (Nut-busting Torque/Weight) (ft-lb/lb): 256.4
• Product Length (in): 8.47

• Product Width (in): 3.5
• Product Height (in): 8.19
• Product Weight (lb): 7.8
• Quiet Tool: Yes
• Recommended Forward Torque Range (ft-lb): 200-900
• Recommended Forward Torque Range (in-lb): 2390-10798
• Recommended Forward Torque Range (nm): 27

IR 2146Q2MAX

1" Air Impact Wrench, Quiet, 2000 ft-lb Torque, Friction Ring-Thru-hole Retainer, Pistol

Description: The 2146MAX Series Impact Wrenches - including the 2146Q2MAX, is the most powerful impact in its class. These quiet impact wrenches help you maximize productivity across a range of jobs and tackle anything that comes your way. And because you can avoid operating below and above the recommended 90 PSI air pressure, your tool will last longer and perform more reliably. Work more and spend less - the 2146MAX Series helps you do what you do best.

Features And Benefits:

• Cold-forged twin hammer impact mechanism and motor deliver 2,000 ft-lbs of Nut Busting Torque, durability, and efficiency
• Steel hammer case stands up to drops and everyday abuse
• Patented one-hand forward/reverse and feather-touch trigger provides maximum control
• Ingersoll Rand's Quiet Technology reduces the sound of the tool, sparing your ears without sacrificing a single ounce of power
• Pressure gauge improves productivity and prolongs product life
• A lightweight, balanced, air impact wrench that weighs just 8.0 lbs
• 1" Drive Square for larger socket sizes
• Impact and chemical-resistant housing protects against repeated drops and exposure to shop fluids
• Optimized for the vehicle repair industry, heavy trucks, tire lanes, fleet maintenance, body shops, general industrial use, MRO, rail, heavy machinery, oil and gas, shipbuilding and construction

Product Application and Uses:

Vehicle Repair, General Industrial, Facility Maintenance

• Includes: Bare Tool
• Actuation/Throttle Type/Switch Type: Trigger
• Air Consumption @ Load (cfm): 36
• Air Consumption @ Load (l/min): 1090
• Air Inlet: 1/2" NPT
• Air Pressure (psi): 90
• Anvil Length: Standard
• Average Air Consumption (cfm): 14
• Average Air Consumption (l/min): 396

• Blows per Min: 1075

• Color: Grey
• Configuration/Handle Type: Pistol Grip
• Drive Size (in): 1
• Drive Type: Square
• Duty Rating: Maintenance Duty

• End Plates: Steel
• Exhaust Location: Bottom
• Free Speed Sound Pressure/Power Db(A): 88.8 / 99.8

• Hammer Case: Steel
• Handle Material: Composite
• Housing Material: Impact and chemical-resistant composite housing and patented steel reinforced frame
• Impact Mechanism: Twin Hammer
• Impacting Sound Pressure/Power Db(A): 94.3 /105.3

• Max Bolt Diameter (in): 1
• Max Free Speed (rpm): 5500
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 1453
• Max Torque (in-lb): 17436
• Max Torque (nm): 1970
• Min Hose Size (in): 1/2
• Motor: Reverse Bias

• Number of Power Settings: 4
• Nut-busting/Breakaway Torque (ft-lb): 2000
• Nut-busting/Breakaway Torque (in-lb): 24003
• Nut-busting/Breakaway Torque (nm): 2712
• Power Source: Air Powered
• Power to Weight Ratio (Nut-busting Torque/Weight) (ft-lb/lb): 250
• Product Length (in): 8.5

• Product Width (in): 3.5
• Product Height (in): 8.2
• Product Weight (lb): 8
• Quiet Tool: Yes
• Recommended Forward Torque Range (ft-lb): 200-900
• Recommended Forward Torque Range (in-lb): 2390-10798
• Recommended Forward Torque Range (nm): 270-1220
• Recommended Reverse Torque (ft-lb): 199-1003
• Recommended Reverse Torque (nm): 270-1360
• Retainer Type: Fricti

IR 2145QIMAX-A40

Housing Assembly for Ingersoll Rand 2145QiMAX Impact Wrench

• For Use With: 2145QIMAX

IR 2146-638

IR 2146-TK2

Tune Up Kit for Ingersoll Rand 2146 Series Impact Wrench

Product Application and Uses:

For use with Ingersoll Rand 2146Q1MAX, 2146Q1MAX-3, 2146Q1MAX-6 and 2146Q2MAX Impact Wrenches

• Includes: Motor Gasket, O-Ring (Front-Black), O-Ring (Back-Red), (6) Vanes, (4) M4 Motor Screws, Hammer Case Gasket, O-Ring, Reverse Valve O-Ring (Black-Top), Reverse Valve O-Ring (Bottom-Blue), Inlet Parts Kit (O-Ring Seal, Throttle Spring, Throttle Valve, Valve Seat, Seat Support, Retainer)

• For Use With: 2146Q1MAX
• For Use With: 2146Q1MAX-3
• For Use With: 2146Q1MAX-6
• For Use With: 2146Q2MAX

IR 2145-A626

Anvil Assembly for Ingersoll Rand 2145TIMAX Impact Wrench

Product Application and Uses:

For use with Ingersoll Rand 2145QIMAX Standard Anvil

• For Use With: 2145QIMAX-AP
• For Use With: 2146Q1MAX

IR 2145-K75RD

Button Kit for Ingersoll Rand 2145, 2155 Series Impact Wrench

Product Application and Uses:

For use with 2145 and 2155 Series Impact Wrench

• Includes: Forward, Reverse Buttons

• For Use With: 2145QIMAX-3
• For Use With: 2145QIMAX-6
• For Use With: 2155QIMAX

IR 2145-THK2

Hammer Mechanism Replacement Part for Ingersoll Rand 2145 and 2155 Series Impact Wrench

Product Application and Uses:

For use with Ingersoll Rand 2145 and 2155 Series Impact Wrench

• Includes: (2) Hammer, Hammer Frame, (2) Hammer pins

• For Use With: 2145QIMAX-3
• For Use With: 2145QIMAX-3-AP
• For Use With: 2145QIMAX-6
• For Use With: 2145QIMAX-6-AP
• For Use With: 2145QIMAX-AP
• For Use With: 2145QIMAX-SP
• For Use With: 2155QIMAX

IR 2146-K75

Button Kit for Ingersoll Rand 2146 Series Impact Wrench

Product Application and Uses:

For use with Ingersoll Rand 2146Q1MAX, 2146Q1MAX-3, 2146Q1MAX-6 and 2146Q2MAX Impact Wrenches

• Includes: Forward and Reverse Buttons

• For Use With: 2146Q1MAX
• For Use With: 2146Q1MAX-3
• For Use With: 2146Q1MAX-6
• For Use With: 2146Q2MAX

IR 2155-K425

Socket Retainer Kit for Ingersoll Rand W8000 Series Impact Wrench

Product Application and Uses:

For use with Ingersoll Rand W8000 Series Air Impact Wrenches.

• Includes: Socket Retainer Spring and O-Ring

• For Use With: W8171
• For Use With: W8171-K2
• For Use With: W8191
• For Use With: W8191-K2
• For Use With: W8571
• For Use With: W8571-K2
• For Use With: W8591
• For Use With: W8591-K2

IR 2145-D727

Hammer Case Assembly for Ingersoll Rand 2145, 2155 Series Impact Wrench

Product Application and Uses:

For use with Ingersoll Rand 2145, 2155 Series Impact Wrench

• For Use With: 2145QIMAX-3
• For Use With: 2145QIMAX-6
• For Use With: 2155QIMAX

IR 2145-42-7

Vane Pack for Ingersoll Rand 2145 Series Impact Wrench, 7-Pack

Product Application and Uses:

For use with Ingersoll Rand 2145 Series Impact Wrench

• Includes: (7) vanes

• For Use With: 2145QIMAX-3
• For Use With: 2145QIMAX-6

IR 2145QIMAX-300

IR 2145-TK2

Tune-up Kit for Ingersoll Rand 2145 Series Impact Wrench

• For Use With: 2145QIMAX-AP
• For Use With: 2155QIMAX

IR 2146-42-6

IR 2145-36RD

Hammer Case Gasket for Ingersoll Rand 2145 Series Impact Wrench

• For Use With: 2145QIMAX-3
• For Use With: 2145QIMAX-6

IR 2145QIMAX

IR 2145-53

Rotor for Ingersoll Rand 2145 Series Impact Wrench

• For Use With: 2145QIMAX-3
• For Use With: 2145QIMAX-6

IR 2146-A11

End Plate for Ingersoll Rand 2146 Series Impact Wrench

Product Application and Uses:

For use with Ingersoll Rand 2146Q1MAX, 2146Q1MAX-3, 2146Q1MAX-6 and 2146Q2MAX Impact Wrenches

• Includes: Front Endplate, Bearing

• For Use With: 2146Q1MAX
• For Use With: 2146Q1MAX-3
• For Use With: 2146Q1MAX-6
• For Use With: 2146Q2MAX

IR 2146Q1MAX-3

3/4" Air Impact Wrench, 3" Ext Anvil, Quiet, 2,000 ft-lb Torque, Friction Ring-Thru-hole Retainer, Pistol

Description: The 2146MAX Series Impact Wrenches- including the 2146Q1MAX-3, is the most powerful 3/4" impact in its class. These tools have been engineered with an innovative pressure gauge that ensures optimized air flow and pressure. These quiet impact wrenches help you maximize productivity across a range of jobs and tackle anything that comes your way. And because you can avoid operating below and above the recommended 90 PSI air pressure, your tool will last longer and perform more reliably. Work more and spend less, the 2146MAX Series helps you do what you do best.

Features And Benefits:

• Cold-forged twin hammer impact mechanism and motor deliver 2,000 ft-lbs of Nut Busting Torque, durability, and efficiency
• Steel hammer case stands up to drops and everyday abuse
• Patented one-hand forward/reverse and feather-touch trigger provides maximum control
• Ingersoll Rand's Quiet Technology reduces the sound of the tool, sparing your ears without sacrificing a single ounce of power
• Pressure gauge improves productivity and prolongs product life
• A lightweight, balanced, air impact wrench that weighs just 8.8 lbs
• Extended reach 3" anvil provides better accessibility to bolts
• Impact and chemical-resistant housing protects against repeated drops and exposure to shop fluids
• Optimized for the vehicle repair industry, heavy trucks, tire lanes, fleet maintenance, body shops, general industrial use, MRO, rail, heavy machinery, oil and gas, shipbuilding and construction

Product Application and Uses:

Vehicle Repair, General Industrial, Facility Maintenance

• Includes: Bare Tool
• Actuation/Throttle Type/Switch Type: Trigger
• Air Consumption @ Load (cfm): 36
• Air Consumption @ Load (l/min): 1090
• Air Inlet: 1/2" NPT
• Air Pressure (psi): 90
• Anvil Length: 3" Extended
• Average Air Consumption (cfm): 14
• Average Air Consumption (l/min): 396

• Blows per Min: 1075

• Color: Grey
• Configuration/Handle Type: Pistol Grip
• Drive Size (in): 3/4
• Drive Type: Square
• Duty Rating: Maintenance Duty

• End Plates: Steel
• Exhaust Location: Bottom
• Free Speed Sound Pressure/Power Db(A): 88.8 / 99.8

• Hammer Case: Steel
• Handle Material: Composite
• Housing Material: Impact and chemical-resistant composite housing and patented steel reinforced frame
• Impact Mechanism: Twin Hammer
• Impacting Sound Pressure/Power Db(A): 94.3 /105.3

• Max Bolt Diameter (in): 1
• Max Free Speed (rpm): 5500
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 1453
• Max Torque (in-lb): 17436
• Max Torque (nm): 1970
• Min Hose Size (in): 1/2
• Motor: Reverse Bias

• Number of Power Settings: 4
• Nut-busting/Breakaway Torque (ft-lb): 2000
• Nut-busting/Breakaway Torque (in-lb): 24003
• Nut-busting/Breakaway Torque (nm): 2712
• Power Source: Air Powered
• Power to Weight Ratio (Nut-busting Torque/Weight) (ft-lb/lb): 227.3
• Product Length (in): 11.5

• Product Width (in): 3.5
• Product Height (in): 8.2
• Product Weight (lb): 8.8
• Quiet Tool: Yes
• Recommended Forward Torque Range (ft-lb): 200-900
• Recommended Forward Torque Range (in-lb): 2390-10798
• Recommended Forward Torque Range (n

IR 2146-K3

Cylinder for Ingersoll Rand 2146 Series Impact Wrench

Product Application and Uses:

For use with Ingersoll Rand 2146Q1MAX, 2146Q1MAX-3, 2146Q1MAX-6 and 2146Q2MAX Impact Wrenches

• For Use With: 2146Q1MAX
• For Use With: 2146Q1MAX-3
• For Use With: 2146Q1MAX-6
• For Use With: 2146Q2MAX

IR 2145-D565

Inlet Bushing Assembly for Ingersoll Rand 2145 Series Impact Wrench

Product Application and Uses:

For use with Ingersoll Rand 2145 Series Impact Wrench

• Includes: Inlet bushing, Inlet Pre-screen, Inlet Clip, Inlet Parts Kit

• For Use With: 2145QIMAX-3
• For Use With: 2145QIMAX-6

IR 2145-D93BK

Trigger Assembly for Ingersoll Rand 2145, 2155 Series Impact Wrench

Product Application and Uses:

For use with 2145 and 2155 Series Impact Wrench

• Includes: Trigger, O-ring

• For Use With: 2145QIMAX-3
• For Use With: 2145QIMAX-6
• For Use With: 2155QIMAX

IR 2146Q1MAX-6

3/4" Air Impact Wrench, 6" Ext Anvil, Quiet, 2,000 ft-lb Torque, Friction Ring-Thru-hole Retainer, Pistol

Description: The 2146MAX Series Impact Wrenches- including the 2146Q1MAX-6, is the most powerful 3/4" impact in its class. These tools have been engineered with an innovative pressure gauge that ensures optimized air flow and pressure. These quiet impact wrenches help you maximize productivity across a range of jobs and tackle anything that comes your way. And because you can avoid operating below and above the recommended 90 PSI air pressure, your tool will last longer and perform more reliably. Work more and spend less, the 2146MAX Series helps you do what you do best.

Features And Benefits:

• Cold-forged twin hammer impact mechanism and motor deliver 2,000 ft-lbs of Nut Busting Torque, durability, and efficiency
• Steel hammer case stands up to drops and everyday abuse
• Patented one-hand forward/reverse and feather-touch trigger provides maximum control
• Ingersoll Rand's Quiet Technology reduces the sound of the tool, sparing your ears without sacrificing a single ounce of power
• Pressure gauge improves productivity and prolongs product life
• A lightweight, balanced, air impact wrench that weighs just 10.1 lbs
• Long reach 6" extended anvil for improved access to bolts
• Impact and chemical-resistant housing protects against repeated drops and exposure to shop fluids
• Optimized for the vehicle repair industry, heavy trucks, tire lanes, fleet maintenance, body shops, general industrial use, MRO, rail, heavy machinery, oil and gas, shipbuilding and construction

Product Application and Uses:

Vehicle Repair, General Industrial, Facility Maintenance

• Includes: Bare Tool
• Actuation/Throttle Type/Switch Type: Trigger
• Air Consumption @ Load (cfm): 36
• Air Consumption @ Load (l/min): 1090
• Air Inlet: 1/2" NPT
• Air Pressure (psi): 90
• Anvil Length: 6" Extended
• Average Air Consumption (cfm): 14
• Average Air Consumption (l/min): 396

• Blows per Min: 1075

• Color: Grey
• Configuration/Handle Type: Pistol Grip
• Drive Size (in): 3/4
• Drive Type: Square
• Duty Rating: Maintenance Duty

• End Plates: Steel
• Exhaust Location: Bottom
• Free Speed Sound Pressure/Power Db(A): 88.8 / 99.8

• Hammer Case: Steel
• Handle Material: Composite
• Housing Material: Impact and chemical-resistant composite housing and patented steel reinforced frame
• Impact Mechanism: Twin Hammer
• Impacting Sound Pressure/Power Db(A): 94.3 /105.3

• Max Bolt Diameter (in): 1
• Max Free Speed (rpm): 5500
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 1453
• Max Torque (in-lb): 17436
• Max Torque (nm): 1970
• Min Hose Size (in): 1/2
• Motor: Reverse Bias

• Number of Power Settings: 4
• Nut-busting/Breakaway Torque (ft-lb): 2000
• Nut-busting/Breakaway Torque (in-lb): 24003
• Nut-busting/Breakaway Torque (nm): 2712
• Power Source: Air Powered
• Power to Weight Ratio (Nut-busting Torque/Weight) (ft-lb/lb): 198
• Product Length (in): 14.5

• Product Width (in): 3.5
• Product Height (in): 8.2
• Product Weight (lb): 10.1
• Quiet Tool: Yes
• Recommended Forward Torque Range (ft-lb): 200-900
• Recommended Forward Torque Range (in-lb): 2390-10798
• Recommended Forward Torque Range (nm): <

IR 2161-11

IR 2161-12

IR 2161-207

Motor Clamp Washer Service Part for Ingersoll Rand Power Tools

IR 2161-36

Hammer Case Gasket for Ingersoll Rand 2161, 2171 Series Impact Wrench

• For Use With: 2161P
• For Use With: 2161XP
• For Use With: 2161XP-6
• For Use With: 2171P
• For Use With: 2171XP

IR 2161-366

Vertical Hanger Kit Service Part for Ingersoll Rand Impact Wrench

• For Use With: 2161P
• For Use With: 2925P1TI

IR 2161-638

IR 2161-739

Backcap Gasket for Ingersoll Rand 2161 and 2171 Series Impact Wrench

• For Use With: 2161P
• For Use With: 2161XP
• For Use With: 2161XP-6
• For Use With: 2171P
• For Use With: 2171XP

IR 2161-A465A

IR 2161-A93

IR 2161-TK2

Tune-up Kit for Ingersoll Rand 2161 Series Impact Wrench

• For Use With: 2161P
• For Use With: 2161XP
• For Use With: 2161XP-6
• For Use With: 2171P
• For Use With: 2171XP

IR 2161XP-626

3/4" Drive Anvil for 2161XP Air Impact Wrench

• For Use With: 2161XP

IR 216B-53

IR 0031.1008

IR 03619772B

IR 03H-500AO-50

IR 03H-PAD-HL

3" Hook & Loop Backing Pad for Ingersoll Rand 3128 Mini Orbital Sander and 3129 Mini Polisher

IR 04648739

Pad Wrench Service Part for IR Sander

• For Use With: R035C-C1
• For Use With: R035C-C1-HL
• For Use With: R035C-C2
• For Use With: R035C-C2-HL
• For Use With: R035C-S1
• For Use With: R035C-S1-HL
• For Use With: R035C-S2
• For Use With: R035C-S2-HL
• For Use With: R036C-C1
• For Use With: R036C-C1-HL
• For Use With: R036C-C2
• For Use With: R036C-C2-HL
• For Use With: R036C-C3
• For Use With: R036C-C3-HL
• For Use With: R036C-S1
• For Use With: R036C-S1-HL
• For Use With: R036C-S2
• For Use With: R036C-S2-HL
• For Use With: R036C-S3
• For Use With: R036C-S3-HL

IR 04648770

Valve Stem Replacement Part

IR 04648796

Valve Tip for Ingersoll Rand Orbital Sander

IR 04648820

IR 0-TK1

IR 101BMPD-17

IR 10084-20

IR 10200

IR 10403

IR 10202

IR 102A60-241

IR 103A-718

Spring Replacement Part for Ingersoll Rand Qi Series Impact Drivers

Product Application and Uses:

For use with QIS20Q4, QIS08Q4, QIP20Q4, QIP08Q4, QIP14Q4,QIP30Q4 Screwdrivers

IR 10415

IR 10416

IR 10417

IR 105-1LB

IR 10548774

IR 105-4T

#105 Grease for Ingersoll Rand Impact Wrench, 4 oz. Tube

IR 10598258

IR 10560944

IR 10598266

IR 10598282

IR 1099XPA-D44

IR 105-L2

1/4" Air Mini Ratchet Wrench, 25 ft-lb Torque, 250 RPM

Description: The 105 Series of air ratchet wrenches are small, durable, and easy to handle for vehicle repair technicians. The low profile forward/reverse control has a wide diameter for easy gripping and increased control in confined spaces.

Features And Benefits:

• Power & Speed: With 25 ft-lb max torque and 250 rpm free speed, you can count on the 105 Series to deliver impressive power.
• Greater Access & Reach: The 105 Series mini ratchet wrenches are small and nimble enough to tackle jobs in both tight and hard to reach places.
• Durable: With an aluminum housing and steel head construction, the 105 Series has improved durability and consistent performance.
• Increased Safety: The ball dent anvil found on each member of the 105 Series provides a more secure link to the socket, increasing operator safety.

Product Application and Uses:

To remove and install threaded fasteners.

• Actuation/Throttle Type/Switch Type: Lever
• Air Consumption @ Load (cfm): 18
• Air Consumption @ Load (l/min): 510
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90

• Color: Silver
• Configuration/Handle Type: Right Angle
• Drive Size (in): 1/4
• Drive Type: Square
• Duty Rating: Industrial Duty

• Exhaust Location: Rear

• Housing Material: Aluminum

• Max Bolt Capacity Sae Grade 5 Bolt Diameter (in): 3/8
• Max Free Speed (rpm): 250
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 25
• Max Torque (in-lb): 301
• Max Torque (nm): 34
• Min Hose Size (in): 3/8

• Number of Power Settings: Continuous
• Power Source: Air Powered
• Product Length (in): 8.41

• Product Weight (lb): 1.56
• Recommended Forward Torque Range (ft-lb): 5.2-20
• Recommended Forward Torque Range (in-lb): 62-239
• Recommended Forward Torque Range (nm): 7-27
• Retainer Type: Ball
• Reversible: Reversible

• Side to Center Distance (in): 0.77
• Side to Center Distance (mm): 20

• Sound Pressure/Power Db(A): 81.6 / 92.6
• Speed Setting: Variable Speed
• Standards/Certifications: All Government Regulations and FDA Certified

• Vibration Level (m/s2): 3.7
• Warranty: 1-year

• Accessories: 103-BOOT

• Lubrication: 10G
• Lubrication: 10P
• Parts: 1105-D2-TRK1
• Parts: JQ2-201

IR 105-LK

Lever Kit for Ingersoll Rand 105 Series Air Ratchet Wrench

IR 1099XPA-TRK1

Ratchet Head Repair Kit for Ingersoll Rand 1099XPA 1/2" Drive Ratchet Wrench

Product Application and Uses:

For use with 1099XPA 1/2" Air Ratchet Wrench

• For Use With: 1099XPA

IR 1077XPA

1/2 inch Air Ratchet Wrench, 54 ft-lb Torque, 160 RPM

Description: The advanced head design of the 1077XPA 1/2 inch ratchet wrench provides increased durability to one of the industry's most popular ratchets.

Features And Benefits:

• 360-Degree Exhaust: Adjustable 360-degree exhaust capabilities of the 1077XPA standard ratchet wrenches direct exhaust away from the operator, ensuring a better workspace.
• Increased Control: The power regulator you'll find on this ratchet wrench provides increased control on every job.
• Access Hard to Reach Spaces: With greater access and reach, you can more easily work in deep, hard to reach areas.
• Ideal Choice: Ideal choice for work in close quarters. Provides 54 ft.-lbs. of max torque and 160 rpms. Variable speed lever style throttle.

Product Application and Uses:

To remove and install threaded fasteners.

• Includes: Bare Tool
• Actuation/Throttle Type/Switch Type: Lever
• Air Consumption (cfm): 19
• Air Consumption (l/min): 530
• Air Inlet: 1/4 inch NPT
• Air Pressure (psi): 90
• Average Air Consumption (cfm): 4
• Average Air Consumption (l/min): 113

• Color: Silver
• Configuration/Handle Type: Straight
• Drive Size (in): 1/2
• Duty Rating: Industrial Duty

• Exhaust Location: Side - Adjustable

• Handle Material: Aluminum
• Housing Material: Aluminum

• Max Bolt Capacity Sae Grade 5 Bolt Diameter (in): 7/16
• Max Free Speed (rpm): 160
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 54
• Max Torque (in-lb): 646
• Max Torque (nm): 73
• Min Hose Size (in): 3/8

• Number of Power Settings: Continuous
• Power Source: Air Powered
• Product Length (in): 11

• Product Width (in): 1.91
• Product Height (in): 1.9
• Product Weight (lb): 2.75
• Recommended Forward Torque Range (ft-lb): 10-45
• Recommended Forward Torque Range (in-lb): 124-540
• Recommended Forward Torque Range (nm): 14-61
• Retainer Type: Ball
• Reversible: Reversible

• Side to Center Distance (in): 0.96
• Side to Center Distance (mm): 24

• Sound Pressure/Power Db(A): 94.4 / 105.4
• Speed Setting: Variable Speed
• Standards/Certifications: All Gov Regulations And Fda Certified

• Vibration Level (m/s2): 2.4
• Warranty: 1-year

• Accessories: 107-BOOT

• Lubrication: 10G
• Lubrication: 10P
• Parts: 1077XPA-TRK1
• Parts: 107XPA-TK1

IR 105-D2

1/4" Air Ratchet Wrench, 25 ft-lb Torque, 250 RPM

Description: The 105 Series of air ratchet wrenches are small, durable, and easy to handle for vehicle repair technicians. The low profile forward/reverse control has a wide diameter for easy gripping and increased control in confined spaces.

Features And Benefits:

• Power & Speed: With 25 ft-lb max torque and 250 rpm free speed, you can count on the 105 Series to deliver impressive power.
• Greater Access & Reach: The 105 Series mini ratchet wrenches are small and nimble enough to tackle jobs in both tight and hard to reach places.
• Durable: With an aluminum housing and steel head construction, the 105 Series has improved durability and consistent performance.
• Increased Safety: The ball dent anvil found on each member of the 105 Series provides a more secure link to the socket, increasing operator safety.

Product Application and Uses:

To remove and install threaded fasteners.

• Includes: Bare Tool
• Actuation/Throttle Type/Switch Type: Lever
• Air Consumption (cfm): 18
• Air Consumption (l/min): 510
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Average Air Consumption (cfm): 3
• Average Air Consumption (l/min): 85

• Color: Silver
• Configuration/Handle Type: Straight
• Drive Size (in): 1/4
• Duty Rating: Industrial Duty

• Exhaust Location: Rear

• Handle Material: Aluminum
• Housing Material: Aluminum

• Max Bolt Capacity Sae Grade 5 Bolt Diameter (in): 3/8
• Max Free Speed (rpm): 280
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 25
• Max Torque (in-lb): 301
• Max Torque (nm): 34
• Min Hose Size (in): 3/8

• Number of Power Settings: Continuous
• Power Source: Air Powered
• Product Length (in): 7.29

• Product Width (in): 1.54
• Product Height (in): 1.35
• Product Weight (lb): 1.4
• Recommended Forward Torque Range (ft-lb): 5.2-20
• Recommended Forward Torque Range (in-lb): 62-239
• Recommended Forward Torque Range (nm): 7-27
• Retainer Type: Ball
• Reversible: Reversible

• Side to Center Distance (in): 0.77
• Side to Center Distance (mm): 20

• Sound Pressure/Power Db(A): 81.8 / 92.8
• Speed Setting: Variable Speed
• Standards/Certifications: All Gov Regulations And Fda Certified

• Vibration Level (m/s2): 5.1
• Warranty: 1-year

• Accessories: 103-BOOT

• Lubrication: 10G
• Lubrication: 10P
• Parts: 1105-D2-TRK1
• Parts: JQ2-201

IR 1077XPA-TRK1

Ratchet Head Kit for Ingersoll Rand 1077XPA 1/2" Drive Ratchet Wrench

Product Application and Uses:

For use with 1077XPA 1/2" Air Ratchet Wrench

• For Use With: 1077XPA

IR 107-97

Bearing Service Part for Ingersoll Rand Power Tools

IR 105-D3

3/8" Air Mini Ratchet Wrench, 25 ft-lb Torque, 250 RPM

Description: The 105 Series of air ratchet wrenches are small, durable, and easy to handle for vehicle repair technicians. The low profile forward/reverse control has a wide diameter for easy gripping and increased control in confined spaces.

Features And Benefits:

• Power & Speed: With 25 ft-lb max torque and 250 rpm free speed, you can count on the 105 Series to deliver impressive power.
• Greater Access & Reach: The 105 Series mini ratchet wrenches are small and nimble enough to tackle jobs in both tight and hard to reach places.
• Durable: With an aluminum housing and steel head construction, the 105 Series has improved durability and consistent performance.
• Increased Safety: The ball dent anvil found on each member of the 105 Series provides a more secure link to the socket, increasing operator safety.

Product Application and Uses:

To remove and install threaded fasteners.

• Includes: Bare Tool
• Actuation/Throttle Type/Switch Type: Lever
• Air Consumption (cfm): 18
• Air Consumption (l/min): 510
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Average Air Consumption (cfm): 3
• Average Air Consumption (l/min): 85

• Color: Silver
• Configuration/Handle Type: Straight
• Drive Size (in): 3/8
• Duty Rating: Industrial Duty

• Exhaust Location: Rear

• Handle Material: Aluminum
• Housing Material: Aluminum

• Max Bolt Capacity Sae Grade 5 Bolt Diameter (in): 3/8
• Max Free Speed (rpm): 280
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 25
• Max Torque (in-lb): 301
• Max Torque (nm): 34
• Min Hose Size (in): 3/8

• Number of Power Settings: Continuous
• Power Source: Air Powered
• Product Length (in): 7.29

• Product Width (in): 1.54
• Product Height (in): 1.46
• Product Weight (lb): 1.4
• Recommended Forward Torque Range (ft-lb): 5.2-20
• Recommended Forward Torque Range (in-lb): 62-239
• Recommended Forward Torque Range (nm): 7-27
• Retainer Type: Ball
• Reversible: Reversible

• Side to Center Distance (in): 0.77
• Side to Center Distance (mm): 20

• Sound Pressure/Power Db(A): 81.8 / 92.8
• Speed Setting: Variable Speed
• Standards/Certifications: All Gov Regulations And Fda Certified

• Vibration Level (m/s2): 5.1
• Warranty: 1-year

• Accessories: 103-BOOT

• Lubrication: 10G
• Lubrication: 10P
• Parts: 1105-D3-TRK1
• Parts: JQ2-201

IR 10885

IR 107XPA

3/8" Air Ratchet Wrench, 54 ft-lb Torque, 160 RPM

Description: The advanced head design of the 107XPA ratchet wrench provides increased durability to one of the industry's most popular ratchets.

Features And Benefits:

• 360-Degree Exhaust: The 360-degree exhaust capabilities of the 107XPA standard ratchet wrenches direct exhaust away from the operator, ensuring a better workspace.
• Increased Control: The power regulator you'll find on this ratchet wrench provides increased control on every job.
• Access Hard to Reach Spaces: With greater access and reach, you can more easily work in deep, hard to reach areas.
• Ideal choice: Ideal choice for work in close quarters. Provides 54 ft.-lbs. of max torque and 160 rpms. Variable speed Lever style throttle.

Product Application and Uses:

To remove and install threaded fasteners.

• Includes: Bare Tool
• Actuation/Throttle Type/Switch Type: Lever
• Air Consumption (cfm): 19
• Air Consumption (l/min): 530
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Average Air Consumption (cfm): 4
• Average Air Consumption (l/min): 113

• Color: Silver
• Configuration/Handle Type: Straight
• Drive Size (in): 3/8
• Duty Rating: Industrial Duty

• Exhaust Location: Side - Adjustable

• Handle Material: Aluminum
• Housing Material: Aluminum

• Max Bolt Capacity Sae Grade 5 Bolt Diameter (in): 7/16
• Max Free Speed (rpm): 160
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 54
• Max Torque (in-lb): 646
• Max Torque (nm): 73
• Min Hose Size (in): 3/8

• Number of Power Settings: Continuous
• Power Source: Air Powered
• Product Length (in): 11

• Product Width (in): 1.91
• Product Height (in): 1.72
• Product Weight (lb): 2.75
• Recommended Forward Torque Range (ft-lb): 10-45
• Recommended Forward Torque Range (in-lb): 124-540
• Recommended Forward Torque Range (nm): 14-61
• Retainer Type: Ball
• Reversible: Reversible

• Side to Center Distance (in): 0.96
• Side to Center Distance (mm): 24

• Sound Pressure/Power Db(A): 94.4 / 105.4
• Speed Setting: Variable Speed
• Standards/Certifications: All Gov Regulations And Fda Certified

• Vibration Level (m/s2): 2.4
• Warranty: 1-year

• Accessories: 107-BOOT

• Lubrication: 10G
• Lubrication: 10P
• Parts: 107XPA-TK1
• Parts: 107XPA-TRK1

IR 107XPA-41

IR 107-24

Bearing (205,206-24/325 Service Part for Ingersoll Rand Power Tools

IR 107XPA-A44

Anvil Assembly for Ingersoll Rand 107 Ratchet

IR 107XPA-TK1

Tune-up Kit for Ingersoll Rand 107 Series Ratchet

• For Use With: 1077XPA
• For Use With: 107XPA

IR 107XPA-TRK1

Ratchet Head Repair Kit for Ingersoll Rand R3130 and 107XPA 3/8" Drive Ratchet Wrench

Product Application and Uses:

For use with R3130 and 107XPA 3/8" Air Ratchet Wrenches

• For Use With: 107XPA
• For Use With: R3130

IR 107XPA-35

Crank Shaft for Ingersoll Rand 107 and 1077 Series Ratchet Wrench

IR 107XPA-338

IR 109XPA-35

Crankshaft for Ingersoll Rand 109 Ratchet

IR 1099XPA-A123

IR 107XPA-SK

IR 1099XPA

1/2 inch Air Ratchet Wrench, 76 ft-lb Torque, 220 RPM

Description: The 1099XPA ratchet wrenches provide an optimized gear ratio and airflow for exceptional performance and durability with 76 ft-lb maximum torque. The 109 model offers a 3/8 inch drive, while the 1099 model sports a 1/2 inch version.

Features And Benefits:

• 360-Degree Exhaust: The adjustable exhaust on the 1099XPA high torque ratchet wrenches directs air flow away from you and your workspace.
• Low Profile Forward/Reverse Control: The 1099XPA forward/reverse control has a wide diameter for increased ease of use in confined spaces.
• Increased Reach: Enjoy easier access to deep, hard to reach spaces with these high torque ratchet wrenches.

Product Application and Uses:

To remove and install threaded fasteners.

• Includes: Bare Tool
• Actuation/Throttle Type/Switch Type: Button
• Air Consumption (cfm): 24
• Air Consumption (l/min): 680
• Air Inlet: 1/4 inch NPT
• Air Pressure (psi): 90
• Average Air Consumption (cfm): 4
• Average Air Consumption (l/min): 113

• Color: Silver
• Configuration/Handle Type: Straight
• Drive Size (in): 1/2
• Duty Rating: Industrial Duty

• Exhaust Location: Side - Adjustable

• Handle Material: Aluminum
• Housing Material: Aluminum

• Max Bolt Capacity Sae Grade 5 Bolt Diameter (in): 1/2
• Max Free Speed (rpm): 220
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 76
• Max Torque (in-lb): 912
• Max Torque (nm): 103
• Min Hose Size (in): 3/8

• Number of Power Settings: Continuous
• Power Source: Air Powered
• Product Length (in): 12

• Product Width (in): 2.16
• Product Height (in): 2.03
• Product Weight (lb): 3.3
• Recommended Forward Torque Range (ft-lb): 10-60
• Recommended Forward Torque Range (in-lb): 124-717
• Recommended Forward Torque Range (nm): 14-81
• Retainer Type: Ball
• Reversible: Reversible

• Side to Center Distance (in): 1.08
• Side to Center Distance (mm): 27

• Sound Pressure/Power Db(A): 92.4 / 103.4
• Speed Setting: Variable Speed
• Standards/Certifications: All Gov Regulations And Fda Certified

• Vibration Level (m/s2): 2.5
• Warranty: 1-year

• Accessories: 109-BOOT

• Lubrication: 10G
• Lubrication: 10P
• Parts: 1099XPA-TRK1
• Parts: 109XPA-TK

• Parts: 109XPA-TK1

IR 105-VK

Throttle Valve Kit for Ingersoll Rand 105 Series Air Ratchet Wrench

IR 109XPA-338

IR 107XPA-K43

IR 109XPA-37

Yoke for Ingersoll Rand 109 Ratchet

IR 109XPA-42-4

IR 109XPA-53

IR 109XPA-A11

IR 109XPA-A322
