INGERSOLL-RAND IR TOOL S12880

IR 134M2AA61B

IR 13SR-9

IR 131965

IR 140-502

Nose for Ingersoll Rand 140EP Engraving Pen

Product Application and Uses:

For use with Ingersoll Rand 140EP Engraving Pen

• Includes: 1 Nose

• For Use With: 140EP

IR 135MAXK

Vibration Reduced Quick Change Air Hammer 5-Piece Chisel Set, 2600 BPM, 3" Stroke, Round Shank

Description: The 135MAX HD Air Hammer is the next generation air hammer that builds on the foundation set by 119MAX - incredible performance and power at an accessible cost - while leveraging a fine-tuned feather-able trigger, inspired by legendary Ingersoll Rand impact wrenches, for more precision and even better results. Featuring an optimized combination of power and speed to achieve best-in-class 2600 BPM, the 135MAX can breeze through any job, from heavy duty front-end applications to the jobs that call for a lighter touch. And it's all backed by a two-year warranty. Send your productivity soaring with the 135MAX HD Air Hammer.

Features And Benefits:

• MAX Power: Break at lightspeed with the most powerful air hammer available- 15% more powerful to get your job done 15% faster than the leading competitive air hammer.
• MAX Productivity: Quick-Change retainer provides fast chisel changeovers (included with tool).
• MAX Control: Feather-able trigger to give you the ultimate control over every job- from jobs that require the lightest touch to the hardest hitting applications, we've got you covered.
• MAX Assurance: The 135MAX is backed by a two-year warranty, giving you peace of mind that your tool will work when you need it, every time.
• MAX Comfort: Shock reduction and anti-slip grip.

Product Application and Uses:

Vehicle Repair, Exhaust Front End Jobs, Bolt Cutting

• Includes: Quick Change Retainer, 5 Assorted Chisels, Plastic Blow Molded Case
• Actuation/Throttle Type/Switch Type: Feather-touch Trigger
• Air Consumption @ Load (cfm): 2.66
• Air Consumption @ Load (l/min): 75.36
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90

• Blows per Min: 2600
• Bore Diameter (in): 3/4

• Collar Type: Round
• Color: Grey
• Configuration/Handle Type: Pistol Grip
• Duty Rating: Heavy Duty

• Exhaust Location: Handle

• Housing Material: Aluminum Alloy

• Max Pressure (bar): 6.2
• Min Hose Size (in): 3/8

• Power Source: Air Powered
• Product Length (in): 8.66

• Product Width (in): 2.22
• Product Height (in): 6.91
• Product Weight (lb): 4.5
• Retainer Type: Quick Change

• Shank SIze (in): .401
• Shank Type: Round

• Sound Pressure/Power Db(A): 98 / 107
• Standards/Certifications: CE, UKCA
• Stroke Length (in): 3

• Vibration Level (m/s2): 5.4
• Warranty: 2-year

• Accessories: 401B07
• Accessories: 401B09
• Accessories: 401FC347
• Accessories: 401MP7
• Accessories: 9500
• Accessories: 9510

• Lubrication: 10G
• Lubrication: 10P
• Lubrication: 10Z4
• Parts: 135MAX-59A

IR 135MAX

Vibration Reduced Heavy Duty Quick Change Air Hammer, 2600 BPM, 3" Stroke, Round Shank

Description: The 135MAX HD Air Hammer is the next generation air hammer that builds on the foundation set by 119MAX - incredible performance and power at an accessible cost - while leveraging a fine-tuned feather-able trigger, inspired by legendary Ingersoll Rand impact wrenches, for more precision and even better results. Featuring an optimized combination of power and speed to achieve best-in-class2600 BPM, the 135MAX can breeze through any job, from heavy duty front-end applications to the jobs that call for a lighter touch. And it's all backed by a two-year warranty. Send your productivity soaring with the 135MAX HD Air Hammer.

Features And Benefits:

• MAX Power: Break at lightspeed with the most powerful air hammer available - 15% more powerful to get your job done 15% faster than the leading competitive air hammer.
• MAX Productivity: Quick-Change retainer provides fast chisel changeovers (included with tool).
• MAX Control: Feather-able trigger to give you the ultimate control over every job- from jobs that require the lightest touch to the hardest hitting applications, we've got you covered.
• MAX Assurance: The 135MAX is backed by a two-year warranty, giving you peace of mind that your tool will work when you need it, every time.
• MAX Comfort: Shock reduction and anti-slip grip.

Product Application and Uses:

Vehicle Repair, Exhaust Front End Jobs, Bolt Cutting

• Includes: Quick Change Retainer. Chisels sold separately or with 135MAXK kit.
• Actuation/Throttle Type/Switch Type: Feather-touch Trigger
• Air Consumption @ Load (cfm): 2.66
• Air Consumption @ Load (l/min): 75.36
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90

• Blows per Min: 2600
• Bore Diameter (in): 3/4

• Collar Type: Round
• Color: Grey
• Configuration/Handle Type: Pistol Grip
• Duty Rating: Heavy Duty

• Exhaust Location: Handle

• Housing Material: Aluminum Alloy

• Max Pressure (bar): 6.2
• Min Hose Size (in): 3/8

• Power Source: Air Powered
• Product Length (in): 8.67

• Product Width (in): 2.22
• Product Height (in): 6.89
• Product Weight (lb): 4.5
• Retainer Type: Quick Change

• Shank SIze (in): .401
• Shank Type: Round

• Sound Pressure/Power Db(A): 98 / 107
• Standards/Certifications: CE, UKCA
• Stroke Length (in): 3

• Vibration Level (m/s2): 5.4
• Warranty: 2-year

• Accessories: 401B07
• Accessories: 401B09
• Accessories: 401FC347
• Accessories: 401MP7
• Accessories: 9500
• Accessories: 9510

• Complete Tool Kits: 135MAXK

• Lubrication: 10G
• Lubrication: 10P
• Lubrication: 10Z4
• Parts: 135MAX-59A

IR 140-507

Piston for Ingersoll Rand 140EP Engraving Pen

Product Application and Uses:

For use with Ingersoll Rand 140EP Engraving Pen

• Includes: 1 piston

• Product Length (in): 0.71

• Product Width (in): 0.31
• Product Height (in): 0.31
• Product Weight (lb): 0.01

• For Use With: 140EP

IR 140SR-115

IR 140-501

Housing for Ingersoll Rand 140EP Engraving Pen

Product Application and Uses:

For use with Ingersoll Rand 140EP Engraving Pen

• Includes: 1 housing

• Product Length (in): 3.77

• Product Width (in): 0.67
• Product Height (in): 0.67
• Product Weight (lb): 0.15

• For Use With: 140EP

IR 131982

IR 132022

IR 140SR-116

IR 131-A927

Hammer Case Assembly for Ingersoll Rand 231 Series Impact Wrench

IR 132

Super Duty Air Hammer, 1725 BPM, 4" Stroke

Description: Professionals who want the best choose the 132 Super Duty Air Hammer for front end work, heavy exhaust work, riveting, king pin removal, bushing driving, and bolt shearing.

Features And Benefits:

• Up to 1,725 blows per minute
• Alloyed steel barrel and heat-treated piston for longer life
• Built-in power regulator and trigger control

Product Application and Uses:

These Air Percussive Hammers are designed for hammering, punching, cutting, chipping and scrapping material through repetitive application of linear impacts of a tool steel that is retained and driven by the hammer. Great for front end work, heavy exhaust work, riveting, king pin removal, bushing driving, and bolt shearing.

• Actuation/Throttle Type/Switch Type: Trigger
• Air Consumption @ Load (cfm): 11
• Air Consumption @ Load (l/min): 311
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Average Air Consumption (cfm): 3
• Average Air Consumption (l/min): 85

• Blows per Min: 1725
• Bore Diameter (in): 0.56

• Color: Yellow
• Configuration/Handle Type: Pistol Grip
• Duty Rating: Super Duty

• Max Pressure (bar): 6.2
• Min Hose Size (in): 5/16

• Power Source: Air Powered
• Product Length (in): 8.5

• Product Weight (lb): 3.4
• Retainer Type: Spring

• Shank SIze (in): 0.401
• Shank Type: Round

• Stroke Length (in): 4

• Warranty: 1-year

• Accessories: 9512

• Lubrication: 10P
• Parts: AV1-255

IR 131980

IR 132017

IR 140-516

Stylus for Ingersoll Rand 140EP Engraving Pen

Product Application and Uses:

For use with Ingersoll Rand 140EP Engraving Pen

• Includes: 1 stylus

• Product Length (in): 2.19

• Product Width (in): 0.34
• Product Height (in): 0.34
• Product Weight (lb): 0.01

• For Use With: 140EP

IR 140SR-122

IR 140EP

Air Engraving Pen, 11400 BPM, Slide Throttle

Description: When it's time to make a lasting mark without breaking the bank, Ingersoll Rand's easy-to-use 140EPEngraving Pen is the time-saving tool you've been looking for. It's been ergonomically designed fortop-notch precision on any surface - from alloys to brittle ceramics and everything in between. In fact, itsability to engrave even the hardest materials makes it one of the most efficient and reliable tools in yourarsenal. And, because comfort is king, the 140EP comes equipped with a soft rubber grip and slender bodydesign, making it ideal for extended use.

Features And Benefits:

• PERFORMANCE: Designed with durability in mind, the 140EP accurately engraves even the hardest surfaces with ease. This versatile pen is great for marking tools and other pieces of equipment, allowing for easier identification and reduced cycle times.
• COMFORT: Ergonomically designed with a soft rubber grip and slender body, the comfort of the lightweight 140EP makes it ideal for extended use - all without sacrificing legibility.
• VALUE: It's possible to enjoy the performance of a well-made product without breaking the bank, and the 140EP is a prime example. Its price point provides a great value to the customer, making it an affordable yet reliable tool for even the tightest budgets.

Product Application and Uses:

Marking any surface from hard alloys to brittle ceramics.

• Includes: Engraving Pen and One Standard Stylus, Hose Assembly
• Actuation/Throttle Type/Switch Type: Slide/Zoom
• Air Consumption @ Load (cfm): 1
• Air Consumption @ Load (l/min): 30
• Air Inlet: 1/8" NPT
• Air Pressure (psi): 90

• Bit Material: Carbide
• Blows per Min: 11400

• Configuration/Handle Type: Straight
• Duty Rating: Maintenance Duty

• Handle Material: Brass with TPU Grip
• Hose Length (ft): 5
• Housing Material: Brass

• Max Pressure (bar): 6.2
• Min Hose Size (in): 3/16

• Pencil Diameter (in): 0.67
• Power Source: Air Powered
• Product Length (in): 5.5

• Product Width (in): 0.67
• Product Height (in): 0.67
• Product Weight (lb): 0.43

• Side to Center Distance (in): 0.33
• Side to Center Distance (mm): 8

• Sound Pressure/Power Db(A): 75 / 86
• Speed Setting: Variable Speed
• Spindle Offset (in): 0.33
• Standards/Certifications: CE, EAC, UKCA

• Vibration Level (m/s2): <5
• Warranty: 1-year

• Accessories: 140-516

• Lubrication: 10G
• Lubrication: 10P
• Parts: 140-130
• Parts: 140-501

• Parts: 140-502
• Parts: 140-507
• Parts: 140-747

IR 131966

IR 140-747

Grip for Ingersoll Rand 140EP Engraving Pen

Product Application and Uses:

For use with Ingersoll Rand 140EP Engraving Pen

• Includes: 1 grip

• Product Length (in): 1.61

• Product Width (in): 0.63
• Product Height (in): 0.63
• Product Weight (lb): 0.01

• For Use With: 140EP

IR 131K-LA

1/2" Air Impact Wrench 4 Socket Set, 600 ft-lb

• Includes: 131S 1/2" Air Impact, 4 Sockets (11/16" , 3/4" , 13/16" , 7/8" ), Carrying Case
• Actuation/Throttle Type/Switch Type: Trigger
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Anvil Length: Standard

• Blows per Min: 1150

• Color: Silver
• Configuration/Handle Type: Pistol Grip
• Drive Size (in): 1/2
• Drive Type: Square

• Exhaust Location: Bottom

• Handle Material: Aluminum
• Housing Material: Aluminum
• Impact Mechanism: Twin Hammer

• Max Free Speed (rpm): 8000
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 600
• Max Torque (in-lb): 7196
• Max Torque (nm): 813
• Min Hose Size (in): 3/8
• Motor: Reverse Bias

• Number of Power Settings: 6
• Power Source: Air Powered
• Product Length (in): 7.3

• Product Width (in): 2.75
• Product Height (in): 7.9
• Product Weight (lb): 5.8
• Quiet Tool: Yes
• Recommended Forward Torque Range (ft-lb): 25-300
• Recommended Forward Torque Range (in-lb): 301-3602
• Recommended Forward Torque Range (nm): 34-407
• Retainer Type: Friction Ring

• Side to Center Distance (in): 1.4
• Side to Center Distance (mm): 36

• Tool Type: Full-size
• Vanes: 6
• Warranty: 1-year

IR 140SR-311

IR 140SR-117

IR 14SR-41

IR 14SR-40

IR 14SR-43

IR 14SR-45

IR 14SR-83R-2 3/8

IR 15016

IR 15077

IR 15084

IR 150BM-3

IR 150BM-A674

IR 150BMGE21RH-6

IR 150BMP-1051B

IR 150BMP-1064L

IR 150BMP-607

IR 150BMP-283

IR 150BMP-284

IR 150BMP-703

IR 150BMPD88R54-020

IR 150BMPE88R54-200

IR 150LF-12A

IR 150LF-284

IR 150LFPE88R54-020

IR 150SR-262

IR 150SR-302

IR 150SR-503

IR 150TMF-10B

IR 150TMF-24

IR 150TMFl-A53

IR 150TMGF21RH6-POS

IR 150TMFR-A53

IR 150TMP-TK1

IR 15E4-K48

IR 15QMAX

3/8" Air Impact Wrench, Quiet, Ultra Compact, 475 ft-lb Torque, Friction Ring Retainer, Pistol

Description: The 35MAX Ultra-Compact Impact Wrench is as versatile as it is reliable. With its twin hammer impact mechanism, aluminum hammer case and composite housing, this tool will deliver the power you need.

Features And Benefits:

• Access: Thanks to its small size and easy handling, the 35MAX Ultra-Compact Impact Wrench can be used in even the tightest of spaces.
• User Experience: The 35MAX Ultra-Compact Impact Wrench comes with improved operator comfort and safety, so you'll never have to worry while doing your job.
• Power-to-Weight: At 2.4 lbs., the 15QMAX is the lightest on the market and it still manages to produce 380 ft.-lbs. of max torque.
• Patented Quiet Technology: Ingersoll Rand's patented Quiet Tool Technology reduces sound levels without compromising best-in-class power performance.

Product Application and Uses:

Vehicle Maintence And Industrial Mro For Resctricted Areas

• Includes: Bare Tool
• Actuation/Throttle Type/Switch Type: Trigger
• Air Consumption @ Load (cfm): 17
• Air Consumption @ Load (l/min): 481
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Anvil Length: Standard
• Average Air Consumption (cfm): 4
• Average Air Consumption (l/min): 113

• Blows per Min: 1350

• Color: Grey
• Configuration/Handle Type: Pistol Grip
• Drive Size (in): 3/8
• Drive Type: Square
• Duty Rating: Maintenance Duty

• End Plates: Aluminum with Hard-coating
• Exhaust Location: Bottom
• Free Speed Sound Pressure/Power Db(A): 83.7 / 94.7

• Hammer Case: Aluminum
• Handle Material: Composite
• Impact Mechanism: Twin Hammer
• Impacting Sound Pressure/Power Db(A): 89.7 / 100.7

• Max Bolt Diameter (in): 7/16
• Max Free Speed (rpm): 6000
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 384
• Max Torque (in-lb): 4602
• Max Torque (nm): 520
• Min Hose Size (in): 3/8
• Motor: Reverse Bias

• Number of Power Settings: 3
• Nut-busting/Breakaway Torque (ft-lb): 475
• Nut-busting/Breakaway Torque (in-lb): 5700
• Nut-busting/Breakaway Torque (nm): 644
• Power Source: Air Powered
• Power to Weight Ratio (Nut-busting Torque/Weight) (ft-lb/lb): 158.3
• Product Length (in): 4.6

• Product Width (in): 2.4
• Product Height (in): 7.1
• Product Weight (lb): 2.4
• Quiet Tool: Yes
• Recommended Forward Torque Range (ft-lb): 310
• Recommended Forward Torque Range (in-lb): 3717
• Recommended Forward Torque Range (nm): 420
• Retainer Type: Friction Ring

• Side to Center Distance (in): 1.2
• Side to Center Distance (mm): 30

• Special Features: Quiet, Ultra Compact
• Speed Setting: Variable Speed
• Standards/Certifications: Iso 11148-6, Cagi B186, Iso 28927-2, Iso 15744

• Tool Type: Compact
• Vanes: 7
• Vibration Level (m/s2): 5.5
• Warranty: 2-year

• Accessories: SK3H8N
• Accessories: SK3M8N

• Lubrication: 105-LBK1
• Lubrication: 10G
• Lubrication: 10P
• Lubrication: 10Z4
• Parts: 15-A626
• Parts: 35-TK1

IR 16360

IR 16400

IR 16610875

IR 161A32-105

IR 16570806

IR 160E4S8

IR 16M4JB6B

IR 170-27

IR 16922

IR 1702-706

IR 1702-A626

Anvil for Ingersoll Rand 211 Series, 212 Series, 1702 Series, 2902 Series, 215G Series Impact Wrench

IR 1702P-329

Valve for Ingersoll Rand 1702P, 212, 215, 2902P Series Impact Wrenches

IR 1702P-666

Knob Replacement Part for Ingersoll Rand 1702P, 212, 215, 2902P Series Impact Wrench

IR 1702-P726

Anvil Replacement Part for Ingersoll Rand 211, 212, 1702, 2902 Series Impact Wrench

IR 1702P-TK2

Tune-Up Kit for Ingersoll Rand 1702 Series Air Impact Wrench

Product Application and Uses:

For use with Ingersoll Rand 1702P1 and 1702P4 Air Impact Wrench

• Includes: (2) Reverse Valve O-rings, Detent Ball, Detent Ball Spring, Throttle Valve Face, Large Bushing O-ring, (2) Small Bushing O-rings, Bushing O-ring, Deflector Gasket, Exhaust Silencer, End Plate Gasket, Rear Rotor Bearing Retainer, Rear Rotor Bearing, Vane Packet (set of 6 Vanes), Front Rotor Bearing, Hammer Case Gasket, Socket Retaining Plunger, Retaining Plunger Spring

• For Use With: 1702P1
• For Use With: 1702P4

IR 1702SB1

3/8" Air Impact Wrench, 105 ft-lb Torque, Pin Retainer, Inline

Description: The 1702 Series Impact Wrench's steel hammer case and metal housing ensure a tough, durable tool that'll help you breeze through any job without having to worry about your tools giving up.

Features And Benefits:

• Power: With a jumbo hammer impact mechanism and power regulation, the 1702 Series is powerful and easy to control.
• Reliable: No matter how often you use it, the 1702 Series Impact Wrench will deliver the same high-quality output every time. Comes with a 1-year warranty.

Product Application and Uses:

These air impact wrenches are designed to remove and install threaded fasteners.

• Actuation/Throttle Type/Switch Type: Lever
• Air Consumption @ Load (cfm): 13
• Air Consumption @ Load (l/min): 368
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90
• Anvil Length: Standard

• Blows per Min: 1500

• Color: Black
• Configuration/Handle Type: Straight
• Drive Size (in): 3/8
• Drive Type: Square
• Duty Rating: General Duty

• End Plates: Cast Iron
• Exhaust Location: Bottom
• Free Speed Sound Pressure/Power Db(A): 83.6 / 94.6

• Hammer Case: Steel
• Handle Material: Composite
• Housing Material: Aluminum core with composite sleeve
• Impact Mechanism: Jumbo Hammer
• Impacting Sound Pressure/Power Db(A): 86.8 / 97.8

• Max Bolt Diameter (in): 0.375
• Max Free Speed (rpm): 10000
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 105
• Max Torque (in-lb): 1257
• Max Torque (nm): 142
• Min Hose Size (in): 5/16
• Motor: Non-Biased

• Number of Power Settings: 5
• Power Source: Air Powered
• Product Length (in): 6.6

• Product Width (in): 2
• Product Height (in): 3.6
• Product Weight (lb): 2.5
• Recommended Forward Torque Range (ft-lb): 13-85
• Recommended Forward Torque Range (in-lb): 159-1018
• Recommended Forward Torque Range (nm): 18-115
• Retainer Type: Pin Detent

• Side to Center Distance (in): 1
• Side to Center Distance (mm): 25

• Speed Setting: Variable Speed
• Standards/Certifications: CE

• Tool Type: Full-size
• Vanes: 6
• Vibration Level (m/s2): 4.2
• Warranty: 1-year

• Lubrication: 105-LBK1
• Lubrication: 10G
• Lubrication: 10P
• Lubrication: 10Z4
• Parts: 1702SB-TK2
• Parts: 401-42A-6

IR 170-36

Drive Bushing for Ingersoll Rand 170G, 1770G,R3000, 1207MAX, 107, 109 Series Air Ratchet

IR 170-TK

Throttle Valve Kit for Ingersoll Rand 170G, 1770G, 107 Series Air Ratchet

IR 1710B-329

IR 1720P-23

Exhaust Deflector for Ingersoll Rand 271, 261, 1720P Impact Wrench

• For Use With: 1720P1
• For Use With: 1720P3
• For Use With: 261
• For Use With: 261-3
• For Use With: 261-6
• For Use With: 271

IR 1720P-TK2

IR 170-97

IR 170-42-4

Vane Pack Set of 4 for Ingersoll Rand 1207MAX, 107 Series Air Ratchet

IR 170PG

Air Needle Scaler, 3000 BPM, 1.4" Stroke

Description: This pistol grip needle scaler is designed with both power and ergonomics in mind. With a rubber over mold grip for maximum comfort, you can use this tool for hours with minimal fatigue.

Features And Benefits:

• Comfort: Ergonomic handle and low vibration provides operator comfort.
• Power: 3,000 blows per minute maximize material removal.

Product Application and Uses:

Designed for removing weld splatter or other unwanted surface deposits from metal

• Includes: Tool, (19) flat tip 7" (3mm) carbon steel needles
• Actuation/Throttle Type/Switch Type: Lever
• Air Consumption @ Load (cfm): 5.5
• Air Consumption @ Load (l/min): 15.6
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90

• Blows per Min: 3000
• Bore Diameter (in): 0.93

• Color: Black
• Configuration/Handle Type: Pistol Grip
• Duty Rating: Industrial Duty

• Lock Mechanism: Bayonet Needle

• Max Pressure (bar): 6.2
• Min Hose Size (in): 5/16
• Needle Length: 7"
• Needle Qty: 19

• Power Source: Air Powered
• Product Length (in): 12.4

• Product Weight (lb): 6.6

• Shank SIze (in): .5
• Shank Type: Ingersoll Rand Shank

• Standards/Certifications: Vibration : ISO 28927-9:2009Sound : ISO 15744:2008Safety : ISO 11148-4:2012
• Stroke Length (in): 1.4

• Warranty: 1-year

• Accessories: NS11-122-19

• Lubrication: 10P
• Parts: 22038194

IR 17RB078

Spur Gear Air Motor, 1-1/2" Keyed Shaft, 69 RPM, 2.2 HP, 739 NM, Reversible

• Air Consumption at Max HP (scfm): 100
• Air Inlet: 3/8" NPT
• Air Pressure (psi): 90

• Drive Size (in): 1-1/2
• Drive Type: Round Keyed

• Exhaust Location: Side
• Finish: Paint, Yellow
• Gear Reduction: Double
• Gear Train: Spur Gear

• Housing Material: Steel Motor, Aluminum Gear Housing

• Max Free Speed (rpm): 69
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 545
• Max Torque (in-lb): 6541
• Max Torque (nm): 739
• Motor: Rotary Vane
• Motor: Spur Gear
• Mounting Type: Foot and Face

• Power Source: Air Powered

• Product Weight (lb): 72
• Rated Power (hp): 2.2
• Rated Power (kW): 1.64
• Reversible: Reversible

• Speed at Max Power (rpm): 36
• Starting Torque (ft-lb): 327
• Starting Torque (nm): 443

• Warranty: 1-year

IR 1710-A626A

IR 17M13B195

IR 182A53-685

IR 182A13-CXRSN50

IR 182A53-689

IR 182A53-593

IR 182A83-606

IR 182A83-593

IR 182A83-A602

IR 182L

Air Chisel Scaler, 4000 BPM, 1-1/16" Stroke

Description: With 4000 blows-per-minute and 1" stroke, the 182 is our most powerful and chisel durable scaler. The 'swan' neck grip option add an extra level of comfort for both vertical and horizontal operation

Features And Benefits:

• Easy Adjustment: The adjustable bayonet-type needle housing lock allows for easy adjustment without special tools.
• Durability: These scalers feature a rubber faced throttle valve to ensure positive sealing of internal components, and they're durable enough to withstand repeated drops and harsh conditions with ease.
• Comfort: Compact, well balanced and low vibration maximize operators comfort
• Power: The powerful motor featured in the 182 Series makes work easier and more efficient.

Product Application and Uses:

Remove Paint, Rust, Dirt, Weld Slags

• Includes: Bare Tool
• Actuation/Throttle Type/Switch Type: Lever
• Air Consumption @ Load (cfm): 13
• Air Consumption @ Load (l/min): 368
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90

• Blows per Min: 4000
• Bore Diameter (in): 0.94

• Color: Silver
• Configuration/Handle Type: Straight
• Duty Rating: Heavy Duty

• Max Pressure (bar): 6.2
• Min Hose Size (in): 5/16

• Non Sparking: No
• Power Source: Air Powered
• Product Length (in): 9

• Product Width (in): 6.93
• Product Height (in): 2.76
• Product Weight (lb): 4.1

• Shank SIze (in): .5
• Shank Type: Ingersoll Rand Shank

• Sound Pressure/Power Db(A): 107.2 / 118.2
• Stroke Length (in): 1.06

• Vibration Level (m/s2): 12.7
• Warranty: 1-year

• Accessories: WF-14-12
• Accessories: WF-14A-007
• Accessories: WF-14B-007
• Accessories: WF-14B-012
• Accessories: WF-14C-007
• Accessories: WF-14C-012
• Accessories: WF-14C-018
• Accessories: WF-14D-007
• Accessories: WF-14D-012
• Accessories: WF-14D-018
• Accessories: WF-14F-12
• Accessories: WF-14F-18
• Accessories: WF-14F-7

• Complete Tool Kits: 182K1

• Lubrication: 10G
• Lubrication: 10P
• Parts: NS11-27
• Parts: NS11-A24

IR 182LNA1

Air Needle Scaler, 4000 BPM, 1-1/16" Stroke

Description: With 4000 blows-per-minute and 1" stroke, the 182 is our most powerful and chisel durable scaler.

Features And Benefits:

• Easy Adjustment: The adjustable bayonet-type needle housing lock allows for easy adjustment without special tools.
• Durability: These scalers feature a rubber faced throttle valve to ensure positive sealing of internal components, and they're durable enough to withstand repeated drops and harsh conditions with ease.
• Comfort: Compact, well balanced and low vibration maximize operators comfort
• Power: The powerful motor featured in the 182 Series makes work easier and more efficient.
• Tested and approved in accordance with MIL-S-23492A (Ships).
• Includes (19) steel precision heat-treated needles for maximum performance. (1/8" diameter, 5" length)

Product Application and Uses:

Remove Paint, Rust, Dirt, Weld Slags

• Includes: 19 steel precision heat-treated needles (1/8" diameter, 5" length)
• Actuation/Throttle Type/Switch Type: Lever
• Air Consumption @ Load (cfm): 13
• Air Consumption @ Load (l/min): 368
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90

• Blows per Min: 4000
• Bore Diameter (in): 0.94

• Color: Black
• Configuration/Handle Type: Straight
• Duty Rating: Heavy Duty

• Max Pressure (bar): 6.2
• Min Hose Size (in): 5/16
• Needle Qty: 19 Needles

• Non Sparking: No
• Power Source: Air Powered
• Product Length (in): 15

• Product Width (in): 6.6
• Product Height (in): 2.7
• Product Weight (lb): 5.8

• Shank SIze (in): .5
• Shank Type: Ingersoll Rand Shank

• Sound Pressure/Power Db(A): 107.2 / 118.2
• Stroke Length (in): 1.06

• Vibration Level (m/s2): 10.1
• Warranty: 1-year

• Accessories: NS11-122-19
• Accessories: NS11-22-19

• Lubrication: 10G
• Lubrication: 10P
• Parts: NS11-A24
• Parts: NS11A

IR 1841N

Inline Multi-Vane Air Motor, 5/8" Keyed Shaft, 1700 RPM, 1.2 HP, 17 NM, Reversible

• Air Consumption at Max HP (scfm): 43
• Air Inlet: 3/8" NPT
• Air Pressure (psi): 90

• Drive Size (in): 5/8
• Drive Type: Round Keyed

• Exhaust Location: Rear
• Finish: Black Oxide
• Gear Train: Planetary

• Housing Material: Steel

• Max Free Speed (rpm): 1700
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 13
• Max Torque (in-lb): 150
• Max Torque (nm): 17
• Motor: Rotary Vane
• Motor: In line
• Mounting Type: Face

• Number of Mounting Holes: 2
• Power Source: Air Powered

• Product Weight (lb): 5.5
• Rated Power (hp): 1.2
• Rated Power (kW): 0.89
• Reversible: Reversible

• Speed at Max Power (rpm): 800
• Starting Torque (ft-lb): 9.3
• Starting Torque (nm): 12.6

• Warranty: 1-year

• Parts: R1801-A123

IR 182G

Air Chisel Scaler, 4000 BPM, 1-1/16" Stroke

Description: With 4,000 blows-per-minute and a 1-1/16 inch stroke, the 182G is our most powerful and durable chisel scaler. The 'swan' neck grip option adds an extra level of comfort for both vertical and horizontal operation.

Features And Benefits:

• Easy Adjustment: The adjustable bayonet-type needle housing lock allows for easy adjustment without special tools.
• Durability: These scalers feature a rubber faced throttle valve to ensure positive sealing of internal components, and they're durable enough to withstand repeated drops and harsh conditions with ease.
• Power: With 4,000 blows-per-minute and a 1-1/16 inch stroke, the 182G is our most powerful and durable chisel scaler.
• Comfort: Compact, well balanced and low vibration maximize operators comfort.

Product Application and Uses:

Designed for removal of unwanted deposits from metal and other hardened materials through repetitive application of linear impacts of a tool steel that is retained and driven by the scaler. Such deposits include weld splatter, paint, coatings and other surface materials.

• Actuation/Throttle Type/Switch Type: Outside Trigger
• Air Consumption @ Load (cfm): 13
• Air Consumption @ Load (l/min): 368
• Air Inlet: 1/4" NPT
• Air Pressure (psi): 90

• Blows per Min: 4000
• Bore Diameter (in): .94

• Color: Silver
• Configuration/Handle Type: Swan Neck

• Max Pressure (bar): 6.2
• Min Hose Size (in): 5/16

• Power Source: Air Powered
• Product Length (in): 12.8

• Product Weight (lb): 5.3

• Shank SIze (in): .5
• Shank Type: Ingersoll Rand Shank

• Sound Pressure/Power Db(A): 107.2 / 118.2
• Stroke Length (in): 1.06

• Vibration Level (m/s2): 8.5
• Vibration Uncertainy K* (m/s2): 1.2
• Warranty: 1-year

• Accessories: WF-14-12
• Accessories: WF-14A-007
• Accessories: WF-14B-007
• Accessories: WF-14B-012
• Accessories: WF-14C-007
• Accessories: WF-14C-012
• Accessories: WF-14C-018
• Accessories: WF-14D-007
• Accessories: WF-14D-012
• Accessories: WF-14D-018
• Accessories: WF-14F-12
• Accessories: WF-14F-18
• Accessories: WF-14F-7

IR 1841P

Inline Multi-Vane Air Motor, 5/8" Keyed Shaft, 900 RPM, 1.1 HP, 27.1 NM, Reversible

• Air Consumption at Max HP (scfm): 43
• Air Inlet: 3/8" NPT
• Air Pressure (psi): 90

• Drive Size (in): 5/8
• Drive Type: Round Keyed

• Exhaust Location: Rear
• Finish: Black Oxide
• Gear Train: Planetary

• Housing Material: Steel

• Max Free Speed (rpm): 900
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 20
• Max Torque (in-lb): 240
• Max Torque (nm): 27.1
• Motor: Rotary Vane
• Motor: In line
• Mounting Type: Face

• Number of Mounting Holes: 2
• Power Source: Air Powered

• Product Weight (lb): 5.88
• Rated Power (hp): 1.1
• Rated Power (kW): 0.82
• Reversible: Reversible

• Speed at Max Power (rpm): 430
• Starting Torque (ft-lb): 15
• Starting Torque (nm): 20.3

• Warranty: 1-year

• Parts: R1801-A123

IR 1841Q

Inline Multi-Vane Air Motor, 5/8" Keyed Shaft, 550 RPM, 1.1 HP, 48.8 NM, Reversible

• Air Consumption at Max HP (scfm): 43
• Air Inlet: 3/8" NPT
• Air Pressure (psi): 90

• Drive Size (in): 5/8
• Drive Type: Round Keyed

• Exhaust Location: Rear
• Finish: Black Oxide
• Gear Train: Planetary

• Housing Material: Steel

• Max Free Speed (rpm): 550
• Max Pressure (bar): 6.2
• Max Torque (ft-lb): 36
• Max Torque (in-lb): 432
• Max Torque (nm): 48.8
• Motor: Rotary Vane
• Motor: In line
• Mounting Type: Face

• Number of Mounting Holes: 2
• Power Source: Air Powered
• Product Length (in): 8.5

• Product Weight (lb): 5.88
• Rated Power (hp): 1.1
• Rated Power (kW): 0.82
• Reversible: Reversible

• Speed at Max Power (rpm): 260
• Starting Torque (ft-lb): 27
• Starting Torque (nm): 36.6

• Warranty: 1-year

• Parts: R1801-A123

IR 18602

IR 1LL1A1

IR 1RLMC1
