INGERSOLL-RAND IR TOOL S12880
INGERSOLL-RAND IR TOOL S12880 branded products
O-Ring 74-3M Non-Returnable Part
IR 5823-5129
IR 5823-5129
O-Ring 74-3M Non-Returnable Part Call for pricing
O-Ring 92-3M Non-Returnable Part
IR 5823-5229
IR 5823-5229
O-Ring 92-3M Non-Returnable Part Call for pricing
1 1/2 Inch Impacttool
IR 5980A1
IR 5980A1
1-1/2" Air Impact Wrench, Super Duty, 10,000 ft-lb Torque, Thru-hole Retainer, T-handle
The 5980 series is not only one of the most powerful impacts in the industry, they are also one of the most durable and reliable.Features And Benefits
- Durability: With an aluminum hammer case, metal housing, and bronze end-plate, this series is corrosion resistant. It will last through just about anything.
- Reliability: Ingersoll Rand products are built to last, and this series is no different. These tools will deliver the right amount of power every time you pull the trigger.
- Power: This series has a high torque output of 10,000 ft.-lbs. max. torque and the planetary gear drive delivers smooth constant speed from the motor, so you never have to worry about power.
- Built-in lubricator
Product Application and Uses: Engineered to withstand the harshest working conditions in oilfields, mines, and shipyards
Actuation/Throttle Type/Switch Type: Lever
Air Inlet: 3/4" NPT
Air Pressure (psi): 90
Anvil Length: Standard
Average Air Consumption (cfm): 138
Average Air Consumption (l/min): 3908
Blows per Min: 1000
Color: Grey
Configuration/Handle Type: T-handle
Drive Size (in): 1-1/2
Drive Type: Square
Duty Rating: Super Duty
End Plates: Bronze
Exhaust Location: Bottom
Free Speed Sound Pressure/Power Db(A): 103.1 / 114.1
Gear Train: Planetary
Hammer Case: Aluminum
Handle Material: Composite
Housing Material: Impact and chemical-resistant composite housing and patented steel reinforced frame
Impact Mechanism: Ball and Cam
Max Bolt Diameter (in): 2
Max Free Speed (rpm): 830
Max Pressure (bar): 6.2
Max Torque (ft-lb): 10000
Max Torque (in-lb): 119998
Max Torque (nm): 13558
Min Hose Size (in): 1
Motor: Non-Biased
Number of Power Settings: Continuous
Power Source: Air Powered
Product Length (in): 23
Product Weight (lb): 88
Recommended Forward Torque Range (ft-lb): 5500
Recommended Forward Torque Range (in-lb): 66000
Recommended Forward Torque Range (nm): 7457
Retainer Type: Thru-hole
Side to Center Distance (in): 3.06
Side to Center Distance (mm): 78
Speed Setting: Variable Speed
Standards/Certifications: CE
Tool Type: Full-size
Vanes: 5
Vibration Level (m/s2): 20.5
Warranty: 1-year
Similar IR
- 588A1
- 5982A1
$16,111.50
GREASE
IR 67-4T
IR 67-4T
Grease for Ingersoll Rand Angle Head Tool, 4 oz. Tube
It goes without saying that proper lubrication of any tool is essential if you want the tool to last. By lubricating your air tools, you’ll prolong the life of tool motors, mechanisms, gearing, and other vital parts. Ingersoll Rand offers a complete line of specialized oils and greases that are engineered specifically for use with our air tools. Grease guns are also available for your convenience to dispense the line of lubricants.Similar IR
- 67-LBK1
$25.00
TRIGGER (402-93)
IR 705-93
IR 705-93
Trigger for Ingersoll Rand 2705P1, 2705P1, 231C
For Use With- 231C
- 2705P1
- 2707P1
$15.00
Kit, Retainer+Pin(Item No. 137 & 138) For Automatic Brake Assy
IR 71467690
IR 71467690
Kit, Retainer+Pin(Item No. 137 & 138) For Automatic Brake Assy $68.00
GRINDER
IR 77A60P107
IR 77A60P107
Air Angle Grinder, 7" Type 27/28 Wheel, 6000 RPM, 1.5 HP, 5/8"-11 Thread, Side Exhaust
Air Pressure (psi): 90Configuration/Handle Type: Right Angle
Max Pressure (bar): 6.2
Power Source: Air Powered
Warranty: 1-year
$1,566.30
GRINDER
IR 77H120H84
IR 77H120H84
Air Grinder, 4" Type 1 Wheel, 12,000 RPM, 1.5 HP, 1/2"-13 Thread
Ingersoll Rand Pro Series are tough, easy to handle, and ready to tackle any project you need them for. They are specially designed for heavy duty applications. With their superior power output, they are best suited for big tasks involving heavy material removal in foundries, welding shops, fabrication facilities, steel mills or shipyards.Features And Benefits
- Reliability: With a built-in mist lubricator and motor controller to extend tool life and regulate performance, you can count on these grinders to work the way you want them to any time you pull the trigger.
- Power: High powered 1.5 HP and 12,000 RPM motor allow for quick and easy material removal without breaking a sweat.
- Durability: Ingersoll Rand tools are built to withstand harsh conditions and repeated drops, and this series is no different.
Product Application and Uses: Specially designed for heavy duty applications best suited for big tasks involving heavy material removal in foundries, welding shops, fabrication facilities, steel mills or shipyards.
Actuation/Throttle Type/Switch Type: Safety Lever
Air Inlet: 3/8" NPT
Air Pressure (psi): 90
Arbor/Collet: 1/2"-13 Thread
Configuration/Handle Type: Straight
Duty Rating: Industrial Duty
Guard Material: Steel
Lock Mechanism: Lever lock in off position
Max Free Speed (rpm): 12000
Max Pressure (bar): 6.2
Min Hose Size (in): 1/2
Mounting Type: Arbor
Power Source: Air Powered
Rated Power (hp): 1.5
Rated Power (kW): 1.12
Sound Pressure/Power Db(A): 82.4 / 93.4
Vibration Level (m/s2): 2.8
Vibration Uncertainy K* (m/s2): 1.2
Warranty: 1-year
Wheel Diameter (in): 4
Wheel Thickness (in): 1
Wheel Type: Type 1
$1,738.80
GRINDER
IR 77H90L10
IR 77H90L10
Cone and Plug Air Grinder, 9000 RPM, 1.5 HP, 5/8 in-11 Thread, Side Exhaust
Ingersoll Rand Pro Series are tough, easy to handle, and ready to tackle any project you need them for. They are specially designed for heavy duty applications. With their superior power output, they are best suited for big tasks involving heavy material removal in foundries, welding shops, fabrication facilities, steel mills or shipyards.Features And Benefits
- Reliability: With a built-in mist lubricator and motor controller to extend tool life and regulate performance, you can count on these grinders to work the way you want them to any time you pull the trigger.
- Versatile: Compatible with piped-away exhaust kits to make your job easier.
Product Application and Uses: Specially designed for heavy duty applications best suited for big tasks involving heavy material removal in foundries, welding shops, fabrication facilities, steel mills or shipyards.
Actuation/Throttle Type/Switch Type: Safety Lever
Air Consumption @ Load (cfm): 37
Air Consumption @ Load (l/min): 1048
Air Inlet: 3/8" NPT
Air Pressure (psi): 90
Arbor/Collet: 5/8"-11 Thread
Color: Black
Configuration/Handle Type: Straight
Exhaust Location: Side
Lock Mechanism: Lever lock in off position
Max Free Speed (rpm): 9000
Max Pressure (bar): 6.2
Min Hose Size (in): 1/2
Power Source: Air Powered
Product Length (in): 16.44
Product Weight (lb): 6
Rated Power (hp): 1.5
Rated Power (kW): 1.1
Vibration Level (m/s2): 4.2
Vibration Uncertainy K* (m/s2): 3.5
Warranty: 1-year
Wheel Type: Cone
$1,428.30
RAMMER
IR 130A1M
IR 130A1M
Pneumatic Bench Sand Rammer, 2-1/2" Round Malleable Butt, 2.5" Stroke, 1" Bore
With dual-action sand wipers, a built-in muffler and a side exhaust, this tool is built for heavy use. Ideal for compacting small sand molds in a foundry or casting facility. Its shorter height and light weight allow this unit to be used on smaller molds that are set up waist high.Features And Benefits
- Reliability: Thanks to a built-in lubricator, these tools will run smoothly and last.
- Durability: With a plated piston and front-end seal to protect your tool, this Backfill Tamper can be used in the toughest environments. The sand-wiper seal prevents dirt and grit from getting inside the tool.
- Access: This tool is as lightweight as it is powerful, making compact spaces easy to reach.
Product Application and Uses: Ideal for compacting small sand molds in a foundry or casting facility
Actuation/Throttle Type/Switch Type: Lever
Air Consumption @ Load (cfm): 14
Air Consumption @ Load (l/min): 396
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Blows per Min: 870
Bore Diameter (in): 1
Butt Diameter (in): 2.5
Butt Material: Malleable/ Steel
Butt Shape: Round
Color: Beige
Configuration/Handle Type: Straight
Duty Rating: Super Duty
Exhaust Location: Side
Housing Material: Steel
Inline Oilers: Yes
Max Pressure (bar): 6.2
Min Hose Size (in): 3/8
Muffler: Built In
Power Source: Air Powered
Product Length (in): 21.5
Product Weight (lb): 11.56
Retainer Type: Latch
Shank Opening: 1/2" Tapered Rod
Special Features: Time Tested Valve Design, Round Piston Rod, Built In Muffler, Optional Front End Butts Available.
Steels: Yes
Stroke Length (in): 2.5
Warranty: 1-year
$1,350.90
3" SURFACE PREP.MPQ=25 DISC-MED, MAROON BOX=25
IR 03A-MEDBR-25
IR 03A-MEDBR-25
3" SURFACE PREP.MPQ=25 DISC-MED, MAROON BOX=25 $81.00
SCALER - CHISEL
IR 170PG-CS
IR 170PG-CS
Air Chisel Scaler, 3000 BPM, 1.4" Stroke
This pistol grip chisel scaler is designed with both power and ergonomics in mind. With a rubber over mold grip for maximum comfort, you can use this tool for hours with minimal fatigue.Features And Benefits
- Comfort: Ergonomic handle and low vibration provides operator comfort.
- Power: 3,000 blows per minute maximize material removal.
Includes: Scaler Tool with 1/2" square shank bushing, 7" x 3/4" straight steel chisel
Product Application and Uses: Designed for removing weld splatter or other unwanted surface deposits from metal
Actuation/Throttle Type/Switch Type: Lever
Air Consumption @ Load (cfm): 5.5
Air Consumption @ Load (l/min): 15.6
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Blows per Min: 3000
Bore Diameter (in): 0.93
Color: Black
Configuration/Handle Type: Pistol Grip
Duty Rating: Industrial Duty
Lock Mechanism: Retaining Ball
Max Pressure (bar): 6.2
Min Hose Size (in): 5/16
Power Source: Air Powered
Product Length (in): 12.4
Product Weight (lb): 5.3
Shank SIze (in): 1/2
Shank Type: Square
Standards/Certifications: Vibration : ISO 28927-9:2009Sound : ISO 15744:2008Safety : ISO 11148-4:2012
Stroke Length (in): 1.4
Warranty: 1-year
Similar IR
- 180PG-CS
- 180PG-KIT
- 170PG
$393.30
HEAVY DUTY IMPACTOOL
IR 1712B2
IR 1712B2
1" Air Impact Wrench, Heavy Duty, 1400 ft-lb Torque, Thru-hole Retainer, D-handle Inside Trigger
The 1712B2 Impact Wrench features a jumbo hammer impact mechanism and a square thru hole anvil. Paired with its steel hammer case and metal housing, this tool is ready for even the toughest jobs.Features And Benefits
- Power: Vane motor and jumbo hammer
- Durability: Steel hammercase
- Productivity: Thru-hole 1" square drive and D-handle with auxiliary handle
Includes: Bare Tool
Product Application and Uses: General Industrial, Facility Maintenance
Actuation/Throttle Type/Switch Type: Inside Trigger
Air Consumption @ Load (cfm): 47
Air Consumption @ Load (l/min): 1331
Air Inlet: 1/2" NPT
Air Pressure (psi): 90
Anvil Length: Standard
Blows per Min: 800
Color: Black
Configuration/Handle Type: D-Handle
Drive Size (in): 1
Drive Type: Square
Duty Rating: Heavy Duty
End Plates: Bronze
Exhaust Location: Bottom
Free Speed Sound Pressure/Power Db(A): 107.7 / 118.7
Hammer Case: Steel
Housing Material: Aluminum
Impact Mechanism: Jumbo Hammer
Impacting Sound Pressure/Power Db(A): 103.0 / 114.0
Max Bolt Diameter (in): 1-1/4
Max Free Speed (rpm): 6000
Max Pressure (bar): 6.2
Max Torque (ft-lb): 1400
Max Torque (in-lb): 16800
Max Torque (nm): 1898
Min Hose Size (in): 3/4
Motor: Non-Biased
Number of Power Settings: Continuous
Power Source: Air Powered
Power to Weight Ratio (Nut-busting Torque/Weight) (ft-lb/lb): 73.7
Product Length (in): 11.25
Product Width (in): 10.24
Product Height (in): 6.3
Product Weight (lb): 18.25
Recommended Forward Torque Range (ft-lb): 451-1003
Recommended Forward Torque Range (in-lb): 5417-12037
Recommended Forward Torque Range (nm): 612-1360
Retainer Type: Thru-hole
Side to Center Distance (in): 5.1
Side to Center Distance (mm): 130
Standards/Certifications: Iso 11148-6, Cagi B186, Iso 28927-2, Iso 15744
Tool Type: Full-size
Vanes: 6
Vibration Level (m/s2): 19.7
Warranty: 1-year
$2,339.10
MOTOR
IR 1801W
IR 1801W
Inline Multi-Vane Air Motor, 5/8" Keyed Shaft, 370 RPM, 1.35 HP, 94.9 NM, Non-reversible
Air Consumption at Max HP (scfm): 46Air Inlet: 3/8" NPT
Air Pressure (psi): 90
Drive Size (in): 5/8
Drive Type: Round Keyed
Exhaust Location: Rear
Finish: Black Oxide
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 370
Max Pressure (bar): 6.2
Max Torque (ft-lb): 70
Max Torque (in-lb): 840
Max Torque (nm): 94.9
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 2
Power Source: Air Powered
Product Weight (lb): 5.75
Rated Power (hp): 1.35
Rated Power (kW): 1.01
Reversible: Non-reversible
Speed at Max Power (rpm): 175
Starting Torque (ft-lb): 52
Starting Torque (nm): 70.5
Warranty: 1-year
$3,240.75
MOTOR
IR 1801Q
IR 1801Q
Inline Multi-Vane Air Motor, 5/8" Keyed Shaft, 650 RPM, 1.35 HP, 54.2 NM, Non-reversible
Air Consumption at Max HP (scfm): 46Air Inlet: 3/8" NPT
Air Pressure (psi): 90
Drive Size (in): 5/8
Drive Type: Round Keyed
Exhaust Location: Rear
Finish: Black Oxide
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 650
Max Pressure (bar): 6.2
Max Torque (ft-lb): 40
Max Torque (in-lb): 480
Max Torque (nm): 54.2
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 2
Power Source: Air Powered
Product Weight (lb): 5.75
Rated Power (hp): 1.35
Rated Power (kW): 1.01
Reversible: Non-reversible
Speed at Max Power (rpm): 300
Starting Torque (ft-lb): 30
Starting Torque (nm): 40.7
Warranty: 1-year
$3,023.25
MOTOR
IR 1801P
IR 1801P
Inline Multi-Vane Air Motor, 5/8" Keyed Shaft, 1050 RPM, 1.35 HP, 31.2 NM, Non-reversible
Air Consumption at Max HP (scfm): 46Air Inlet: 3/8" NPT
Air Pressure (psi): 90
Drive Size (in): 5/8
Drive Type: Round Keyed
Exhaust Location: Rear
Finish: Black Oxide
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 1050
Max Pressure (bar): 6.2
Max Torque (ft-lb): 23
Max Torque (in-lb): 276
Max Torque (nm): 31.2
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 2
Power Source: Air Powered
Product Length (in): 8.5
Product Weight (lb): 5.75
Rated Power (hp): 1.35
Rated Power (kW): 1.01
Reversible: Non-reversible
Speed at Max Power (rpm): 500
Starting Torque (ft-lb): 17
Starting Torque (nm): 23.3
Warranty: 1-year
$2,871.00
MOTOR
IR 1801N
IR 1801N
Inline Multi-Vane Air Motor, 5/8" Keyed Shaft, 1990 RPM, 1.4 HP, 19 NM, Non-reversible
Air Consumption at Max HP (scfm): 46Air Inlet: 3/8" NPT
Air Pressure (psi): 90
Drive Size (in): 5/8
Drive Type: Round Keyed
Exhaust Location: Rear
Finish: Black Oxide
Gear Ratio: 1:1
Gear Reduction: Direct Drive
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 1990
Max Pressure (bar): 6.2
Max Torque (ft-lb): 14
Max Torque (in-lb): 168
Max Torque (nm): 19
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 2
Power Source: Air Powered
Product Weight (lb): 5.38
Rated Power (hp): 1.4
Rated Power (kW): 1.04
Reversible: Non-reversible
Speed at Max Power (rpm): 918
Starting Torque (ft-lb): 10
Starting Torque (nm): 14.2
Warranty: 1-year
$3,500.00
Motor
IR 1841U
IR 1841U
Inline Multi-Vane Air Motor, 5/8" Keyed Shaft, 380 RPM, 1.1 HP, 67.8 NM, Reversible
Air Consumption at Max HP (scfm): 43Air Inlet: 3/8" NPT
Air Pressure (psi): 90
Drive Size (in): 5/8
Drive Type: Round Keyed
Exhaust Location: Rear
Finish: Black Oxide
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 380
Max Pressure (bar): 6.2
Max Torque (ft-lb): 50
Max Torque (in-lb): 600
Max Torque (nm): 67.8
Motor: Rotary Vane
Motor: In line
Mounting Type: Face
Number of Mounting Holes: 2
Power Source: Air Powered
Product Weight (lb): 5.88
Rated Power (hp): 1.1
Rated Power (kW): 0.82
Reversible: Reversible
Speed at Max Power (rpm): 175
Starting Torque (ft-lb): 37
Starting Torque (nm): 50.2
Warranty: 1-year
$3,219.00
NEEDLE SCALER
IR 172LNA1
IR 172LNA1
Air Needle Scaler, 5500 BPM, 9/16" Stroke
At 5,500 blows per minute, this lever-operated needle scaler is not only fast, but extremely durable and efficient.Features And Benefits
- Easy Adjustment: The adjustable bayonet-type needle housing lock allows for easy adjustment without special tools.
- Durability: These scalers feature a rubber faced throttle valve to ensure positive sealing of internal components, along with a strengthened head block that will hold up in tough conditions.
- Comfort: Compact, well balanced and low vibration maximize operators comfort
- Power: 9/16" stroke, 5500 blows per minute.
Includes: 19 steel precision heat-treated needles (1/8" diameter 5" length)
Product Application and Uses: Remove Paint, Rust, Dirt, Weld Slags
Actuation/Throttle Type/Switch Type: Lever
Air Consumption @ Load (cfm): 12
Air Consumption @ Load (l/min): 340
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Blows per Min: 5500
Bore Diameter (in): 0.94
Color: Black
Configuration/Handle Type: Straight
Duty Rating: Heavy Duty
Max Pressure (bar): 6.2
Min Hose Size (in): 5/16
Needle Qty: 19 Needles
Non Sparking: No
Power Source: Air Powered
Product Length (in): 13.75
Product Width (in): 6.8
Product Height (in): 2.7
Product Weight (lb): 5.25
Shank SIze (in): .5
Shank Type: Ingersoll Rand Shank
Sound Pressure/Power Db(A): 107.5 / 118.5
Stroke Length (in): 0.56
Vibration Level (m/s2): 12.5
Warranty: 1-year
Similar IR
- 182LNA1
- 172L
- 182L
$520.95
CHIPPER ROUND NOZZLEW/RETAINER
IR 1A2SA
IR 1A2SA
Air Chipping Hammer, 1" Stroke, 2500 BPM, Round Shank Oval Collar
Whether you’re working in construction or demolition, the A Series chipping hammers are great for any job. With its incredible power-to-weight ratio, these hammers will increase productivity and make working easy.Features And Benefits
- Durability: The A Series chipping hammers are equipped with a rubber buffer retainer and threaded barrels to extend the life of your product.
- Reliability: The A Series hammers have lock spring retainers that make sure the steel stays in place. Comes with a 1-year warranty.
Product Application and Uses: These Air Percussive Chipping Hammers are designed for chipping, cutting, chiseling and breaking of hardened materials through repetitive application of linear impacts of a tool steel that is retained and driven by the chipper.
Actuation/Throttle Type/Switch Type: Outside Trigger
Air Consumption @ Load (cfm): 28
Air Consumption @ Load (l/min): 793
Air Inlet: 3/8" NPT
Air Pressure (psi): 90
Blows per Min: 2500
Bore Diameter (in): 1.125
Collar Type: Oval
Color: Beige
Configuration/Handle Type: Swan Neck
Duty Rating: Industrial Duty
Exhaust Location: Side - Adjustable
Housing Material: Aluminum
Max Pressure (bar): 6.2
Min Hose Size (in): 1/2
Muffler: No
Power Source: Air Powered
Product Length (in): 16
Product Weight (lb): 14.75
Retainer Type: Grooved Barrel with Lock-spring (Plain Arrow)
Shank SIze (in): 0.68
Shank Type: Round
Stroke Length (in): 1
Warranty: 1-year
$555.75
50 PIECE GRINDER KIT
IR 23A-VAR-GR
IR 23A-VAR-GR
Surface Prep Accessory Kit, 50-Piece
Includes: (4) 1/4" Shank Carbide Burs; (5) 1/8" Shank Mounted Points; (5) 1/4" Shank Mounted Points; (1) 2" Quick Change Disc Backing Pad; (1) 3" Quick Change Disc Backing Pad; (6) 2" 36 Grit Sanding Discs; (9) 2" Various Grit Surface and Conditioning Discs; (2) 2" Paint and Corrosion Removal Discs; (2) 2" High Strength Buffing Discs; (5) 3" 36 Grit Sanding Discs; (9) 3" Various Grit Surface Conditioning Discs; (1) Carrying CaseProduct Application and Uses: For use with 1/4" Collet Die Grinders
Arbor/Collet: 1/4"
$325.00
