MOTOR
IR M0V075AA
IR M0V075AA
Direct Drive Air Motor, 1-3/8" Keyed Shaft, 5600 RPM, 10.5 HP, 40.7 NM, Reversible
Air Consumption at Max HP (scfm): 260Air Inlet: 1-1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 1-3/8
Drive Type: Round Keyed
Exhaust Location: Side
Finish: Paint
Gear Ratio: 1:1
Gear Reduction: Direct Drive
Gear Train: Gearless
Housing Material: Steel
Max Free Speed (rpm): 5600
Max Pressure (bar): 6.2
Max Torque (ft-lb): 30
Max Torque (in-lb): 360
Max Torque (nm): 40.7
Motor: Rotary Vane
Motor: Direct Drive
Mounting Type: Foot and Face
Number of Mounting Holes: 6
Power Source: Air Powered
Product Weight (lb): 64
Rated Power (hp): 10.5
Rated Power (kW): 7.8
Reversible: Reversible
Speed at Max Power (rpm): 2600
Starting Torque (ft-lb): 22
Starting Torque (nm): 30.5
Warranty: 1-year
$4,719.75
DIE GRINDER, 1 HP, 25K, STRAIGHT, 1/4 C
IR M2H250RG4
IR M2H250RG4
Air Die Grinder, 25,000 RPM, 1 HP, 1/4" and 6mm Collets, Rear Exhaust
You can count on the M2 Series Die Grinders to meet all your industrial, heavy machinery, construction and metal fabrication needs. These die grinders contain an internal contamination-free air controller that maintains the tool’s speed to maximize material removal- so you can trust it to work through your most important jobs.Features And Benefits
- Power: With a powerful, lube-free 1 HP 25,000 rpm motor, you can remove materials quickly and with ease. Suited for heavier-duty grinding, cutting, cleaning, and polishing applications.
- Productivity: Speed-governed motor on this grinder help maximize the life of abrasives, increasing grinder efficiency and improving productivity.
- Durable: Built to last, these grinders have an aluminum-core housing with a composite sleeve and can withstand harsh environments and repeated drops.
- Ergonomic: Low-profile throttle lever and ergonomic handle designed for enhanced operator comfort, to reduce fatigue, and to improve productivity while using this die grinder.
- Efficient: Quick-change spindle-lock eliminates the need for additional tools. Easy disassembly for motor access. Back cap and muffler with easy rear access for cleaning.
Includes: Tool, (2) Collet Wrenches, Manuals
Product Application and Uses: Cleaning Rough Castings, Cleaning Up Welds, Deburring Parts, Finishing Tasks, Ideal For Light Material Removal
Actuation/Throttle Type/Switch Location: Handle
Actuation/Throttle Type/Switch Type: Safety Lever
Air Consumption @ Free Speed (cfm): 25
Air Consumption @ Free Speed (l/min): 708
Air Consumption @ Load (cfm): 40
Air Consumption @ Load (l/min): 1133
Air Inlet: 3/8" NPT
Air Pressure (psi): 90
Arbor/Collet: 1/4"
Arbor/Collet: 6mm
Bearing Type: Ball Bearing
Bearing Type: Needle Bearing
Color: Grey
Configuration/Handle Type: Straight
Duty Rating: Industrial Duty
Exhaust Location: Rear
Grinder Type: Die Grinder
Handle Material: Composite
Housing Material: Aluminum core with composite sleeve
Lock Mechanism: Lever lock in off position
Max Free Speed (rpm): 25000
Max Pressure (bar): 6.2
Min Hose Size (in): 3/8
Power Source: Air Powered
Product Length (in): 8.38
Product Width (in): 7.01
Product Height (in): 2.83
Product Weight (lb): 1.69
Rated Power (hp): 1
Side to Center Distance (in): 0.89
Side to Center Distance (mm): 23
Sound Pressure/Power Db(A): 88.2
Speed Setting: Variable Speed
Standards/Certifications: En Iso 28927-12, En Iso 15744, En Iso 11148-9
Vibration Level (m/s2): 2.3
Warranty: 1-year
Wheel Type: Burr
Similar IR
- G1H250RG4
- G1H250FG4
- M2H200RG4
$527.85
MERCURY EXT.ANG.GRINDER
IR M2L135RP64
IR M2L135RP64
Extended Angle Air Grinder, 4" Type 27 Wheel, 13,500 RPM, 1 HP, 3/8"-24 Thread, Rear Exhaust
Get fast material removal from a powerful tool that does more, is easier to use, and needs less maintenance. The M2 Series angle grinders feature more-powerful, lube-free motors and are available in various speeds and configurations to match virtually any job.Features And Benefits
- Power: With a powerful, lube-free 1 HP 13,500 rpm motor, you can remove materials quickly and with ease. Suited for heavier-duty grinding, cutting, cleaning, and polishing applications.
- Productivity: Speed-governed motor on this angle grinder help maximize the life of abrasives, increasing grinder efficiency and improving productivity.
- Durable: Built to last, these grinders have a steel angle head, aluminum-core housing with composite sleeve, and can withstand harsh environments and repeated drops.
- Ergonomic: Low profile throttle lever and ergonomic extended reach handle design reduces hand fatigue, increases comfort, and improves productivity.
- Efficient: Multi-position guard easily adjusts to four different positions without tools. Spindle lock allows faster, easier accessory changes. Easy disassembly for motor access. Back cap and muffler with easy rear access for cleaning.
- Reliable: You can count on this tool to perform reliably, especially thanks to a motor controller that helps maintain tool speed and prevents over speeding.
Actuation/Throttle Type/Switch Location: Handle
Actuation/Throttle Type/Switch Type: Safety Lever
Air Consumption @ Free Speed (cfm): 22
Air Inlet: 3/8" NPT
Air Pressure (psi): 90
Arbor/Collet: 3/8"-24 Thread
Bearing Type: Ball Bearing
Bearing Type: Needle Bearing
Color: Grey
Configuration/Handle Type: Right Angle
Duty Rating: Industrial Duty
Exhaust Location: Rear
Grinder Type: Angle Grinder
Guard Material: Steel
Handle Material: Composite
Height Over Spindle (in): 3.39
Housing Material: Aluminum core with composite sleeve
Lock Mechanism: Lever lock in off position
Max Free Speed (rpm): 13500
Max Pressure (bar): 6.2
Min Hose Size (in): 3/8
Power Source: Air Powered
Product Length (in): 12.4
Product Weight (lb): 4.55
Rated Power (hp): 1
Sound Pressure/Power Db(A): 87 / 98.7
Speed Setting: Variable Speed
Vibration Level (m/s2): 4.4
Warranty: 1-year
Wheel Diameter (in): 4
Wheel Thickness (in): 1/4
Wheel Type: Type 27
$1,007.40
EXT HOR DIE GRINDER, 1HP, 18K, 3/8X24, 3" WHEEL
IR M2X180RH63
IR M2X180RH63
Extended Air Grinder, 3" Type 1 Wheel, 18,000 RPM, 1 HP, 3/8"-24 Thread, Rear Exhaust
The M2-Series industrial Grinders is offering high durability with a powerful motor and less maintenance, more productivity with the speed governor helping to maximize life time of the abrasive, an adjustable guard and a spindle lock feature. For sure with the M2-Series from Ingersoll Rand you will get more time to work and less time in maintenance.Features And Benefits
- Power: With a powerful, lube-free 1 HP 18,000 rpm motor, you can remove materials quickly and with ease. Suited for heavier-duty grinding, cutting, cleaning, and polishing applications.
- Productivity: Speed-governed motor on this grinder help maximize the life of abrasives, increasing grinder efficiency and improving productivity.
- Durable: Built to last, these grinders have an aluminum-core housing with a composite sleeve and can withstand harsh environments and repeated drops.
- Ergonomic: Low-profile throttle lever and ergonomic handle designed for enhanced operator comfort, to reduce fatigue, and to improve productivity while using this grinder.
- Efficient: Quick-change spindle-lock eliminates the need for additional tools. Easy disassembly for motor access. Back cap and muffler with easy rear access for cleaning.
Includes: 3/8" spindle; Piped Exhaust; Wrenches
Actuation/Throttle Type/Switch Location: Handle
Actuation/Throttle Type/Switch Type: Safety Lever
Air Consumption @ Free Speed (cfm): 14
Air Consumption @ Free Speed (l/min): 396
Air Inlet: 3/8" NPT
Air Pressure (psi): 90
Arbor/Collet: 3/8"-24 Thread
Bearing Type: Ball Bearing
Bearing Type: Needle Bearing
Color: Grey
Configuration/Handle Type: Straight
Duty Rating: Industrial Duty
Exhaust Location: Rear
Grinder Type: Angle Grinder
Guard Material: Steel
Handle Material: Composite
Housing Material: Aluminum core with composite sleeve
Lock Mechanism: Lever lock in off position
Max Free Speed (rpm): 18000
Max Pressure (bar): 6.2
Min Hose Size (in): 3/8
Power Source: Air Powered
Product Length (in): 13.35
Product Weight (lb): 3.26
Rated Power (hp): 1
Sound Pressure/Power Db(A): 85.3 / 96.3
Speed Setting: Variable Speed
Vibration Level (m/s2): 2.3
Warranty: 1-year
Wheel Diameter (in): 3
Wheel Thickness (in): 1/2
Wheel Type: Type 1
$727.95
EXT DIE GRINDER, 1HP, 25K, STRAIGHT, 1/4" C
IR M2X250RG4
IR M2X250RG4
Extended Air Die Grinder, 25,000 RPM, 1 HP, 1/4" and 6mm Collets, Rear Exhaust
You can count on the M2 Series Die Grinders to meet all your industrial, heavy machinery, construction and metal fabrication needs. These die grinders contain an internal contamination-free air controller that maintains the tool’s speed to maximize material removal- so you can trust it to work through your most important jobs.Features And Benefits
- Power: With a powerful, lube-free 1 HP 25,000 rpm motor, you can remove materials quickly and with ease. Suited for heavier-duty grinding, cutting, cleaning, and polishing applications.
- Productivity: Speed-governed motor on this grinder help maximize the life of abrasives, increasing grinder efficiency and improving productivity.
- Durable: Built to last, these grinders have an aluminum-core housing with a composite sleeve and can withstand harsh environments and repeated drops.
- Ergonomic: Low-profile throttle lever and ergonomic handle designed for enhanced operator comfort, to reduce fatigue, and to improve productivity while using this die grinder.
- Efficient: Quick-change spindle-lock eliminates the need for additional tools. Easy disassembly for motor access. Back cap and muffler with easy rear access for cleaning.
Includes: Tools, Large Wrench, Small Wrench, Piped away exhaust
Product Application and Uses: Heavier-duty grinding, cutting, cleaning, and polishing applications
Actuation/Throttle Type/Switch Location: Handle
Actuation/Throttle Type/Switch Type: Safety Lever
Air Consumption @ Free Speed (cfm): 30
Air Consumption @ Free Speed (l/min): 849
Air Consumption @ Load (cfm): 40
Air Consumption @ Load (l/min): 1133
Air Inlet: 3/8" NPT
Air Pressure (psi): 90
Arbor/Collet: 1/4"
Arbor/Collet: 6mm
Bearing Type: Ball Bearing
Bearing Type: Needle Bearing
Color: Grey
Configuration/Handle Type: Straight
Duty Rating: Industrial Duty
Exhaust Location: Rear
Grinder Type: Die Grinder
Handle Material: Composite
Height Over Spindle (in): 2.15
Housing Material: Aluminum core with composite sleeve
Lock Mechanism: Lever lock in off position
Max Free Speed (rpm): 25000
Max Pressure (bar): 6.2
Min Hose Size (in): 3/8
Power Source: Air Powered
Product Length (in): 13.08
Product Weight (lb): 2.68
Rated Power (hp): 1
Sound Pressure/Power Db(A): 88.2 / 99.2
Speed Setting: Variable Speed
Vibration Level (m/s2): 1.9
Warranty: 1-year
Wheel Type: Burr
Similar IR
- M2X200RG4
$727.95
PAVING BREAKER 1 X 4 1/4
IR PB35AL8
IR PB35AL8
Pavement Breaker, 1 X 4-1/4" Hex Shank, 6.25" Stroke Length, 1250 BPM, 1-3/4" Bore
Ingersoll Rand has a unique heritage in construction that dates back to the company’s founding in 1871. Simon Ingersoll invented the world’s first rock drill and revolutionized productivity on the jobsite with the wide array of compressors, tools, and related products that came later. Today, Ingersoll Rand offers one of the most comprehensive lines of construction tools on the market, as well as portable air compressors that have become industry standards. The PB35 pavement breakers are ideal for a variety of projects, from bridge deck resurfacing to general demolition. The standard flex handle provides maximum operator comfort and productivity, while the one-piece housing eliminates the need for costly side rods and springs.Features And Benefits
- Power: With 1250 blows per minute and a 6.25" stroke, the Power-stroke piston delivers more energy to the work surface improving productivity.
- Maintenance: One-piece housing eliminates costly side rods and springs. Drop in valve cartridge simplifies maintenance and reduces overall operating costs.
- Built-in lubricator helps ensure adequate lubrication.
- Ergonomic: Ergonomically designed handles, grips, throttle lever, and breaker housing provide maximum operator comfort and productivity.
- 360 Variable Exhaust Deflector: Allows the operator to choose the direction of the exhaust air.
Product Application and Uses: Ideal for a variety of projects, from bridge deck resurfacing to general demolition
Actuation/Throttle Type/Switch Type: Trigger
Air Consumption @ Load (cfm): 49
Air Consumption @ Load (l/min): 1388
Air Inlet: 3/4" NPT
Air Pressure (psi): 90
Blows per Min: 1250
Bore Diameter (in): 1 3/4
Bushing: Spring Loaded Anvil
Collar Type: Round
Color: Beige
Configuration/Handle Type: T-handle
Duty Rating: Industrial Duty
Exhaust Location: Side
Height Over Spindle (in): 25
Housing Material: Steel
Inline Oilers: Yes
Max Pressure (bar): 6.2
Min Hose Size (in): 3/4
Muffler: No
Power Source: Air Powered
Product Length (in): 25
Product Width (in): 19
Product Weight (lb): 40
Retainer Type: Latch
Shank SIze (in): 1 X 4-1/4
Shank Type: Hex
Steels: Yes
Stroke Length (in): 6.25
Warranty: 1-year
Similar IR
- PB50AS1
$1,276.80
PAVING BREAKER 1X41/4
IR PB35AS8
IR PB35AS8
Pavement Breaker, 1 X 4-1/4" Hex Shank, 6.25" Stroke Length, 1250 BPM, 1-3/4" Bore
Ingersoll Rand has a unique heritage in construction that dates back to the company’s founding in 1871. Simon Ingersoll invented the world’s first rock drill and revolutionized productivity on the jobsite with the wide array of compressors, tools, and related products that came later. Today, Ingersoll Rand offers one of the most comprehensive lines of construction tools on the market, as well as portable air compressors that have become industry standards. The PB35 pavement breakers are ideal for a variety of projects, from bridge deck resurfacing to general demolition. The standard flex handle provides maximum operator comfort and productivity, while the one-piece housing eliminates the need for costly side rods and springs.Features And Benefits
- Power: With 1250 blows per minute and a 6.25" stroke, the Power-stroke piston delivers more energy to the work surface improving productivity.
- Maintenance: One-piece housing eliminates costly side rods and springs. Drop in valve cartridge simplifies maintenance and reduces overall operating costs.
- Built-in lubricator helps ensure adequate lubrication.
- Ergonomic: Ergonomically designed handles, grips, throttle lever, and breaker housing provide maximum operator comfort and productivity.
- 360 Variable Exhaust Deflector: Allows the operator to choose the direction of the exhaust air.
- Muffler Reduces Noise
Product Application and Uses: These paving breakers are suitable for breaking concrete, asphalt and stone paving in road construction work; breaking large boulders in mines, quarries and general demolition work.
Actuation/Throttle Type/Switch Type: Trigger
Air Consumption @ Load (cfm): 49
Air Consumption @ Load (l/min): 1388
Air Inlet: 3/4" NPT
Air Pressure (psi): 90
Blows per Min: 1250
Bore Diameter (in): 1 3/4
Bushing: Spring Loaded Anvil
Collar Type: Round
Color: Beige
Configuration/Handle Type: T-handle
Duty Rating: Industrial Duty
Exhaust Location: Side
Housing Material: Steel
Inline Oilers: Yes
Max Pressure (bar): 6.2
Min Hose Size (in): 3/4
Muffler: Yes
Power Source: Air Powered
Product Length (in): 25
Product Weight (lb): 43
Retainer Type: Latch
Shank SIze (in): 1 X 4-1/4
Shank Type: Hex
Steels: Yes
Stroke Length (in): 6.25
Warranty: 1-year
Similar IR
- PB35AL8
$1,299.60
NARROW SCALER - 7" CLECO SHK, QTY 5
IR PF2200-392
IR PF2200-392
Narrow CLECO Scaler Chisel Steels 7"L
Ingersoll Rand offers a complete line of construction tool steels and accessories for countless applications. Our construction heritage dates back to 1871 with the invention of the world’s first rockdrill. Drawing on our long and successful history in the construction industry, we use top-grade materials to manufacture a line of tough, durable products that are versatile enough to be used in virtually every tool brand. Ingersoll Rand chisel and needle scalers are your best solution for removing unwanted surface coatings and deposits. They’re ideal for removing paint, rust, weld splatter and slag, and other materials.Includes: (5) Scaler Chisel Steels
Product Application and Uses: Designed for removing unwanted surface coatings and deposits. They’re ideal for removing paint, rust, weld splatter and slag, and other materials. For use with CLECO style chisels including Ingersoll Rand 125CI-A, 125CI, 125-A, 125.
Chisel Style: Narrow
Housing Material: Steel
Product Length (in): 7
Product Weight (lb): 0.5
Shank SIze (in): 0.68
Shank Type: CLECO
For Use With
- 125CI-A
$24.00
2" WIDE SCALER - 7" CLECO SHK, QTY 5
IR PF2200-390
IR PF2200-390
2" Wide CLECO Scaler Chisel Steels 7"L
Ingersoll Rand offers a complete line of construction tool steels and accessories for countless applications. Our construction heritage dates back to 1871 with the invention of the world’s first rockdrill. Drawing on our long and successful history in the construction industry, we use top-grade materials to manufacture a line of tough, durable products that are versatile enough to be used in virtually every tool brand. Ingersoll Rand chisel and needle scalers are your best solution for removing unwanted surface coatings and deposits. They’re ideal for removing paint, rust, weld splatter and slag, and other materials.Includes: (5) Scaler Chisel Steels
Product Application and Uses: Designed for removing unwanted surface coatings and deposits. They’re ideal for removing paint, rust, weld splatter and slag, and other materials. For use with CLECO style chisels including Ingersoll Rand 125CI-A, 125CI, 125-A, 125.
Chisel Style: 2" Wide
Housing Material: Steel
Product Length (in): 7
Product Width (in): 2
Product Weight (lb): 0.5
Shank SIze (in): 0.68
Shank Type: CLECO
For Use With
- 125CI-A
$78.00
ELK 1/8T 1 Phase Single Speed Electric HoistHoist
ELK25-1NS25-1PHH-10-6-1CF30
ELK25-1NS25-1PHH-10-6-1CF30
ELK 1/8T 1 Phase Single Speed Electric HoistHoist Call for pricing
SPRING
IR 125-A-227
IR 125-A-227
Spring Replacement Part for Ingersoll Rand 125 Series Scalers
Product Application and Uses: For use with Ingersoll Rand 125-A and 125CI-A ScalersFor Use With
- 125-A
Supersedes
- PF2219-27
$15.00
Ring, For Air Winch I-Rand Fa25A Lmk 1Gp
IR 22028
IR 22028
Ring, For Air Winch I-Rand Fa25A Lmk 1Gp $182.00
BEARING, SINGLE ROW DEEP GROOVE BALL
IR 26A19X2052RSHABEC1
IR 26A19X2052RSHABEC1
BEARING, SINGLE ROW DEEP GROOVE BALL $19.00
SUPER DUTY IMPACTOOL
IR 2950B7
IR 2950B7
1-1/2" Air Impact Wrench, Heavy Duty, 3000 ft-lb Torque, Thru-hole Retainer, D-Handle Inside Trigger
With a finely tuned motor and excellent power regulation, the 2950 Series is ready to assist you on even the toughest of jobs.Features And Benefits
- Durability: The 2950 Series features a steel hammer case and metal housing, tough enough to last through any drops or harsh weather conditions.
- Reliability: This tool's twin hammer impact mechanism provides an even blow that delivers every time. Comes with a 1-year warranty.
- Great for Outdoor Environments: This wrench contains a bronze end-plate that increases durability and is corrosion resistant.
Product Application and Uses: Engineered to withstand the harshest working conditions in oilfields, mines, and shipyards
Actuation/Throttle Type/Switch Type: Inside Trigger
Air Inlet: 1/2" NPT
Air Pressure (psi): 90
Anvil Length: Standard
Average Air Consumption (cfm): 70
Average Air Consumption (l/min): 1982
Blows per Min: 650
Color: Grey
Configuration/Handle Type: D-Handle
Drive Size (in): 1-1/2
Drive Type: Square
Duty Rating: Heavy Duty
End Plates: Bronze
Exhaust Location: Bottom
Free Speed Sound Pressure/Power Db(A): 94.9 / 105.9
Hammer Case: Steel
Handle Material: Composite
Housing Material: Aluminum
Impact Mechanism: Twin Hammer
Max Bolt Diameter (in): 1.5
Max Free Speed (rpm): 3750
Max Pressure (bar): 6.2
Max Torque (ft-lb): 3000
Max Torque (in-lb): 35996
Max Torque (nm): 4067
Min Hose Size (in): 3/4
Motor: Reverse Bias
Number of Power Settings: Continuous
Power Source: Air Powered
Product Length (in): 14.5
Product Weight (lb): 32.6
Recommended Forward Torque Range (ft-lb): 2500
Recommended Forward Torque Range (in-lb): 30004
Recommended Forward Torque Range (nm): 3390
Recommended Reverse Torque (ft-lb): 1601-2500
Recommended Reverse Torque (nm): 2170-3390
Retainer Type: Thru-hole
Side to Center Distance (in): 2.5
Side to Center Distance (mm): 64
Speed Setting: Variable Speed
Standards/Certifications: CE
Tool Type: Full-size
Vanes: 6
Vibration Level (m/s2): 18.1
Warranty: 1-year
Similar IR
- 2955B2
$11,850.00
MOTOR -- MULTI-VANE
IR 34RA011
IR 34RA011
Spur Gear Air Motor, 1-1/2" Keyed Shaft, 490 RPM, 4.1 HP, 206 NM, Reversible
Air Consumption at Max HP (scfm): 183Air Inlet: 1/2" NPT
Air Pressure (psi): 90
Drive Size (in): 1-1/2
Drive Type: Round Keyed
Exhaust Location: Side
Finish: Paint, Yellow
Gear Reduction: Single
Gear Train: Spur Gear
Housing Material: Steel Motor, Aluminum Gear Housing
Max Free Speed (rpm): 490
Max Pressure (bar): 6.2
Max Torque (ft-lb): 152
Max Torque (in-lb): 1823
Max Torque (nm): 206
Motor: Rotary Vane
Motor: Spur Gear
Mounting Type: Foot and Face
Power Source: Air Powered
Product Weight (lb): 43
Rated Power (hp): 4.1
Rated Power (kW): 3.06
Reversible: Reversible
Speed at Max Power (rpm): 255
Starting Torque (ft-lb): 98
Starting Torque (nm): 133
Warranty: 1-year
$7,450.00
MOTOR -- MULTI-VANE
IR 34RA017
IR 34RA017
Spur Gear Air Motor, 1-1/2" Keyed Shaft, 325 RPM, 4.1 HP, 311 NM, Reversible
Air Consumption at Max HP (scfm): 183Air Inlet: 1/2" NPT
Air Pressure (psi): 90
Drive Size (in): 1-1/2
Drive Type: Round Keyed
Exhaust Location: Side
Finish: Paint, Yellow
Gear Reduction: Single
Gear Train: Spur Gear
Housing Material: Steel Motor, Aluminum Gear Housing
Max Free Speed (rpm): 325
Max Pressure (bar): 6.2
Max Torque (ft-lb): 229
Max Torque (in-lb): 2753
Max Torque (nm): 311
Motor: Rotary Vane
Motor: Spur Gear
Mounting Type: Foot and Face
Power Source: Air Powered
Product Weight (lb): 43
Rated Power (hp): 4.1
Rated Power (kW): 3.06
Reversible: Reversible
Speed at Max Power (rpm): 168
Starting Torque (ft-lb): 148
Starting Torque (nm): 201
Warranty: 1-year
$7,400.00
MOTOR -- MULTI-VANE
IR 34RA022
IR 34RA022
Spur Gear Air Motor, 1-1/2" Keyed Shaft, 245 RPM, 4.1 HP, 408 NM, Reversible
Air Consumption at Max HP (scfm): 183Air Inlet: 1/2" NPT
Air Pressure (psi): 90
Drive Size (in): 1-1/2
Drive Type: Round Keyed
Exhaust Location: Side
Finish: Paint, Yellow
Gear Reduction: Single
Gear Train: Spur Gear
Housing Material: Steel Motor, Aluminum Gear Housing
Max Free Speed (rpm): 245
Max Pressure (bar): 6.2
Max Torque (ft-lb): 301
Max Torque (in-lb): 3611
Max Torque (nm): 408
Motor: Rotary Vane
Motor: Spur Gear
Mounting Type: Foot and Face
Power Source: Air Powered
Product Weight (lb): 43
Rated Power (hp): 4.1
Rated Power (kW): 3.06
Reversible: Reversible
Speed at Max Power (rpm): 128
Starting Torque (ft-lb): 195
Starting Torque (nm): 264
Warranty: 1-year
$7,500.00
EXHAUST DEFLECTOR
IR 3940-123
IR 3940-123
Exhaust Deflector for Ingersoll Rand 3940, 3942, 3955 Series Impact Wrench
Product Application and Uses: For use with Ingersoll Rand 3942A2TI, 3942B1TI, 3942B2TI, 3942B2TIEX Air Impact WrenchFor Use With
- 3942A2TI
- 3942B1TI
- 3942B2TI
- 3942B2TIEX
$90.00
