GRACO INC. S10595

GG 235468

GG 235483

GG 235534

AGITATOR, HELIX

Graco 235534 Twistork Drum Agitator, reversible, non-siphon, air driven, 1-1/2 HP, 37.25 in (95 cm) in length, 304 stainless steel material

• Helix blade effectively mixes higher viscosity materials
• Mounts directly to 2-inch drum bung
• Comes in stainless steel or carbon steel
• Sealed agitator drive prevents material contamination and evaporation
• Approved by ATEX for use in hazardous locations
• Maximum viscosity is 10,000 cps

• Model: Twistork

• Air Inlet Size (cm): 0.3175
• Air Inlet Size (in): 1/8
• Air Inlet Size (mm): 3.175
• Air Inlet Thread Type: NPT

• For Use With: 55 Gallon (208 Liter) Drum

• Maximum Speed (RPM): 800

• Maximum Viscosity (cP): 10000

• Maximum Working Pressure (bar): 7
• Maximum Working Pressure (kPa): 700
• Maximum Working Pressure (psi): 100

• Motor Type: Pneumatic - Rotary Vane

• Power Rating (HP): 1.5

GG 235486

KIT, NOZZLE, SPRAY, ANGLE 180

Graco 235486 180 Degree Easy Turn Directional Spray Adapter

Attach to a Graco extension to spray at a variety of angles.

• Model: Graco

• Inlet Size (cm): 2.2225
• Inlet Size (in): 7/8-14
• Inlet Size (mm): 22.225

• Maximum Working Pressure (bar): 248
• Maximum Working Pressure (kPa): 24800
• Maximum Working Pressure (MPa): 24.8
• Maximum Working Pressure (psi): 3600

• Outlet Size (cm): 2.2225
• Outlet Size (in): 7/8-14
• Outlet Size (mm): 22.225
• Outlet Thread Type: UNC

• Overall Height (cm): 4.445
• Overall Height (in): 1.75
• Overall Height (mm): 44.45
• Overall Length (cm): 2.54
• Overall Length (in): 1
• Overall Length (mm): 25.4

GG 235634

GG 235658

KIT, REPAIR

KIT INCLUDES: NUT [QTY. 1], SEAL, BLOCK VEE, .375 ODX.125 ID [QTY. 1], PACKING, O-RING [QTY. 1], STEM, VALVE [QTY. 1], NUT, SEAT [QTY. 1], RING, RETAINING [QTY. 2], ROD, [QTY. 1]

GG 235838

CUP,WET

GG 235855

GG 235870

PUMP, EXTRUDER, SST, 190

Graco 235870 DynaMite Pump Assembly

The Graco DynaMite Pump utilizes the NXT air motor to provide the power necessary to move viscous materials.

• Application: Bonding, Sealing, Gasketing, Thermal Management

• Material: Stainless Steel

• Maximum Air Inlet Pressure (bar): 7
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Operating Temperature ( degree C): 60
• Maximum Operating Temperature ( degree F): 140

• Maximum Working Pressure (bar): 83
• Maximum Working Pressure (kPa): 8300
• Maximum Working Pressure (MPa): 8.3
• Maximum Working Pressure (psi): 1200

• Overall Depth (cm): 20.96
• Overall Depth (in): 8.25
• Overall Depth (mm): 209.6

• Overall Width (cm): 43.2128
• Overall Width (in): 17.0129
• Overall Width (mm): 431.8

• Power Type: Pneumatic

• Pump Ratio: 12:1

GG 235877

GG 23592-00

GG 235992

GG 236061

GG 235209

GG 236081

REGULATOR, PRESS, FLUID

Graco 236081 Fluid Pressure Regulator for Low Pressure Systems, Acetal Material, Waterbase Compatible, Spring-Operated, No Pressure Guage, Series A

GG 236087

GG 236092

GG 236135

GG 236143

TANK, LOW PRESSURE 5 GAL

Graco 236143 5 Gallon Low Pressure (HVLP) Pot, Regulated to 15 psi, ASME Rated, 30.5 in (77.5 cm), 65 lbs (30 kg), SST

Designed with electroplated surfaces that

prevent debris build-up and keep your

operation free of contaminants, Graco

pressure pots are precision welded and

surfaced.

• ASME rated to ensure it meets factory standards
• High quality stainless steel design is compatible with many materials
• Use in stand-alone spraying, material/catalyst supply, or as a moisture sensitive material reservoir

• Inlet Size (cm): 0.635
• Inlet Size (in): 1/4
• Inlet Size (mm): 6.35

• Inlet Thread Gender: Male
• Inlet Thread Type: NPT

• Maximum Volume Capacity (gal): 5
• Maximum Volume Capacity (L): 19

• Maximum Working Pressure (bar): 1
• Maximum Working Pressure (kPa): 100
• Maximum Working Pressure (MPa): 0.1
• Maximum Working Pressure (psi): 15

• Outlet Size (cm): 0.9525
• Outlet Size (in): 3/8
• Outlet Size (mm): 9.525
• Outlet Thread Gender: Male
• Outlet Thread Type: NPSM

• Overall Height (cm): 77.5
• Overall Height (in): 30.5
• Overall Height (mm): 775
• Overall Width (cm): 48.3
• Overall Width (in): 19
• Overall Width (mm): 483

GG 235207

GG 235474

GG 236145

TANK, LOW PRESSURE 15 GAL

Graco 236145 15 Gallon Low Pressure (HVLP) Pot, Regulated to 15 psi, ASME Rated, 44.6 in (113.2 cm), 92 lbs (42 kg), SST

Designed with electroplated surfaces that

prevent debris build-up and keep your

operation free of contaminants, Graco

pressure pots are precision welded and

surfaced.

• ASME rated to ensure it meets factory standards
• High quality stainless steel design is compatible with many materials
• Use in stand-alone spraying, material/catalyst supply, or as a moisture sensitive material reservoir

• Inlet Size (cm): 0.635
• Inlet Size (in): 1/4
• Inlet Size (mm): 6.35

• Inlet Thread Gender: Male
• Inlet Thread Type: NPT

• Maximum Volume Capacity (gal): 15
• Maximum Volume Capacity (L): 57

• Maximum Working Pressure (bar): 1
• Maximum Working Pressure (kPa): 100
• Maximum Working Pressure (MPa): 0.1
• Maximum Working Pressure (psi): 15

• Outlet Size (cm): 0.9525
• Outlet Size (in): 3/8
• Outlet Size (mm): 9.525
• Outlet Thread Gender: Male
• Outlet Thread Type: NPSM

• Overall Height (cm): 113.2
• Overall Height (in): 44.57
• Overall Height (mm): 1132
• Overall Width (cm): 48.3
• Overall Width (in): 19
• Overall Width (mm): 483

GG 236144

TANK, LOW PRESSURE 10 GAL

Graco 236144 10 Gallon Low Pressure (HVLP) Pot, Regulated to 15 psi, ASME Rated, 33.9 in (88 cm), 76 lbs (35 kg), SST

Designed with electroplated surfaces that

prevent debris build-up and keep your

operation free of contaminants, Graco

pressure pots are precision welded and

surfaced.

• ASME rated to ensure it meets factory standards
• High quality stainless steel design is compatible with many materials
• Use in stand-alone spraying, material/catalyst supply, or as a moisture sensitive material reservoir

• Inlet Size (cm): 0.635
• Inlet Size (in): 1/4
• Inlet Size (mm): 6.35

• Inlet Thread Gender: Male
• Inlet Thread Type: NPT

• Maximum Volume Capacity (gal): 10
• Maximum Volume Capacity (L): 38

• Maximum Working Pressure (bar): 1
• Maximum Working Pressure (kPa): 100
• Maximum Working Pressure (MPa): 0.1
• Maximum Working Pressure (psi): 15

• Outlet Size (cm): 0.9525
• Outlet Size (in): 3/8
• Outlet Size (mm): 9.525
• Outlet Thread Gender: Male
• Outlet Thread Type: NPSM

• Overall Height (cm): 86.0
• Overall Height (in): 33.87
• Overall Height (mm): 860
• Overall Width (cm): 48.3
• Overall Width (in): 19
• Overall Width (mm): 483

GG 236147

TANK, LOW PRESS, AGIT. 10 GAL

Graco 236147 10 Gallon Low Pressure (HVLP) Pot with Agitator, Regulated to 15 psi, ASME Rated, 33.9 in (88 cm), 85 lbs (39 kg), SST

Designed with electroplated surfaces that

prevent debris build-up and keep your

operation free of contaminants, Graco

pressure pots are precision welded and

surfaced.

• ASME rated to ensure it meets factory standards
• High quality stainless steel design is compatible with many materials
• Use in stand-alone spraying, material/catalyst supply, or as a moisture sensitive material reservoir

• Includes: Agitator
• Inlet Size (cm): 0.635
• Inlet Size (in): 1/4
• Inlet Size (mm): 6.35

• Inlet Thread Gender: Male
• Inlet Thread Type: NPT

• Maximum Volume Capacity (gal): 10
• Maximum Volume Capacity (L): 38

• Maximum Working Pressure (bar): 1
• Maximum Working Pressure (kPa): 100
• Maximum Working Pressure (MPa): 0.1
• Maximum Working Pressure (psi): 15

• Outlet Size (cm): 0.9525
• Outlet Size (in): 3/8
• Outlet Size (mm): 9.525
• Outlet Thread Gender: Male
• Outlet Thread Type: NPSM

• Overall Height (cm): 86.0
• Overall Height (in): 33.87
• Overall Height (mm): 860
• Overall Width (cm): 48.3
• Overall Width (in): 19
• Overall Width (mm): 483

GG 236148

TANK, LOW PRESS, AGIT. 15 GAL

Graco 236148 15 Gallon Low Pressure (HVLP) Pot with Agitator, Regulated to 15 psi, ASME Rated, 44.6 in (113.2 cm), 101 lbs (46 kg), SST

Designed with electroplated surfaces that

prevent debris build-up and keep your

operation free of contaminants, Graco

pressure pots are precision welded and

surfaced.

• ASME rated to ensure it meets factory standards
• High quality stainless steel design is compatible with many materials
• Use in stand-alone spraying, material/catalyst supply, or as a moisture sensitive material reservoir

• Includes: Agitator
• Inlet Size (cm): 0.635
• Inlet Size (in): 1/4
• Inlet Size (mm): 6.35

• Inlet Thread Gender: Male
• Inlet Thread Type: NPT

• Maximum Volume Capacity (gal): 15
• Maximum Volume Capacity (L): 57

• Maximum Working Pressure (bar): 1
• Maximum Working Pressure (kPa): 100
• Maximum Working Pressure (MPa): 0.1
• Maximum Working Pressure (psi): 15

• Outlet Size (cm): 0.9525
• Outlet Size (in): 3/8
• Outlet Size (mm): 9.525
• Outlet Thread Gender: Male
• Outlet Thread Type: NPSM

• Overall Height (cm): 113.2
• Overall Height (in): 44.57
• Overall Height (mm): 1132
• Overall Width (cm): 48.3
• Overall Width (in): 19
• Overall Width (mm): 483

GG 235635

KIT, REPAIR

Graco 235635 30:1 President, 15:1 Monark, Severe Duty Steel Pump Repair Kit

GG 236149

TANK, HIGH PRESSURE 5 GAL

Graco 236149 5 Gallon High Pressure (HVLP) Pot, Regulated to 100 psi, ASME Rated, 30.5 in (77.5 cm), 65 lbs (30 kg), SST

Designed with electroplated surfaces that

prevent debris build-up and keep your

operation free of contaminants, Graco

pressure pots are precision welded and

surfaced.

• ASME rated to ensure it meets factory standards
• High quality stainless steel design is compatible with many materials
• Use in stand-alone spraying, material/catalyst supply, or as a moisture sensitive material reservoir

• Inlet Size (cm): 0.635
• Inlet Size (in): 1/4
• Inlet Size (mm): 6.35

• Inlet Thread Gender: Male
• Inlet Thread Type: NPT

• Maximum Volume Capacity (gal): 5
• Maximum Volume Capacity (L): 19

• Maximum Working Pressure (bar): 7
• Maximum Working Pressure (kPa): 700
• Maximum Working Pressure (MPa): 0.7
• Maximum Working Pressure (psi): 100

• Outlet Size (cm): 0.9525
• Outlet Size (in): 3/8
• Outlet Size (mm): 9.525
• Outlet Thread Gender: Male
• Outlet Thread Type: NPSM

• Overall Height (cm): 77.5
• Overall Height (in): 30.5
• Overall Height (mm): 775
• Overall Width (cm): 48.3
• Overall Width (in): 19
• Overall Width (mm): 483

GG 235829

KIT, REPAIR

Graco 235829 Ultra-Lite 6000 Repair Kit- Includes Carbide Seat and Urethane Seal

KIT INCLUDES: NUT [QTY. 1], SEAL, BLOCK VEE, .375 ODX.125 ID [QTY. 1], PACKING, O RING [QTY. 1], STEM, VALVE, ASSEMBLY [QTY. 1], SEAT, VALVE [QTY. 1], RING, RETAINING [QTY. 2], ROD, [QTY. 1]

GG 236150

TANK, HIGH PRESSURE 10 GAL

Graco 236150 10 Gallon High Pressure (HVLP) Pot, Regulated to 100 psi, ASME Rated, 33.9 in (88.0 cm), 76 lbs (35 kg), SST

Designed with electroplated surfaces that

prevent debris build-up and keep your

operation free of contaminants, Graco

pressure pots are precision welded and

surfaced.

• ASME rated to ensure it meets factory standards
• High quality stainless steel design is compatible with many materials
• Use in stand-alone spraying, material/catalyst supply, or as a moisture sensitive material reservoir

• Inlet Size (cm): 0.635
• Inlet Size (in): 1/4
• Inlet Size (mm): 6.35

• Inlet Thread Gender: Male
• Inlet Thread Type: NPT

• Maximum Volume Capacity (gal): 10
• Maximum Volume Capacity (L): 38

• Maximum Working Pressure (bar): 7
• Maximum Working Pressure (kPa): 700
• Maximum Working Pressure (MPa): 0.7
• Maximum Working Pressure (psi): 100

• Outlet Size (cm): 0.9525
• Outlet Size (in): 3/8
• Outlet Size (mm): 9.525
• Outlet Thread Gender: Male
• Outlet Thread Type: NPSM

• Overall Height (cm): 86.0
• Overall Height (in): 33.87
• Overall Height (mm): 860
• Overall Width (cm): 48.3
• Overall Width (in): 19
• Overall Width (mm): 483

GG 236151

TANK, HIGH PRESSURE 15 GAL

Graco 236151 15 Gallon High Pressure (HVLP) Pot, Regulated to 100 psi, ASME Rated, 44.6 in (113.2 cm), 92 lbs (42 kg), SST

Designed with electroplated surfaces that

prevent debris build-up and keep your

operation free of contaminants, Graco

pressure pots are precision welded and

surfaced.

• ASME rated to ensure it meets factory standards
• High quality stainless steel design is compatible with many materials
• Use in stand-alone spraying, material/catalyst supply, or as a moisture sensitive material reservoir

• Inlet Size (cm): 0.635
• Inlet Size (in): 1/4
• Inlet Size (mm): 6.35

• Inlet Thread Gender: Male
• Inlet Thread Type: NPT

• Maximum Volume Capacity (gal): 15
• Maximum Volume Capacity (L): 57

• Maximum Working Pressure (bar): 7
• Maximum Working Pressure (kPa): 700
• Maximum Working Pressure (MPa): 0.7
• Maximum Working Pressure (psi): 100

• Outlet Size (cm): 0.9525
• Outlet Size (in): 3/8
• Outlet Size (mm): 9.525
• Outlet Thread Gender: Male
• Outlet Thread Type: NPSM

• Overall Height (cm): 113.2
• Overall Height (in): 44.57
• Overall Height (mm): 1132
• Overall Width (cm): 48.3
• Overall Width (in): 19
• Overall Width (mm): 483

GG 236152

TANK, HIGH PRESS, AGIT 5 GAL

Graco 236152 5 Gallon High Pressure (HVLP) Pot with Agitator, Regulated to 100 psi, ASME Rated, 30.5 in (77.5 cm), 74 lbs (34 kg), SST

Designed with electroplated surfaces that

prevent debris build-up and keep your

operation free of contaminants, Graco

pressure pots are precision welded and

surfaced.

• ASME rated to ensure it meets factory standards
• High quality stainless steel design is compatible with many materials
• Use in stand-alone spraying, material/catalyst supply, or as a moisture sensitive material reservoir

• Includes: Agitator
• Inlet Size (cm): 0.635
• Inlet Size (in): 1/4
• Inlet Size (mm): 6.35

• Inlet Thread Gender: Male
• Inlet Thread Type: NPT

• Maximum Volume Capacity (gal): 5
• Maximum Volume Capacity (L): 19

• Maximum Working Pressure (bar): 7
• Maximum Working Pressure (kPa): 700
• Maximum Working Pressure (MPa): 0.7
• Maximum Working Pressure (psi): 100

• Outlet Size (cm): 0.9525
• Outlet Size (in): 3/8
• Outlet Size (mm): 9.525
• Outlet Thread Gender: Male
• Outlet Thread Type: NPSM

• Overall Height (cm): 77.5
• Overall Height (in): 30.5
• Overall Height (mm): 775
• Overall Width (cm): 48.3
• Overall Width (in): 19
• Overall Width (mm): 483

GG 236153

TANK, HIGH PRESS, AGIT 10 GAL

Graco 236153 10 Gallon High Pressure (HVLP) Pot with Agitator, Regulated to 100 psi, ASME Rated, 33.9 in (88 cm), 85 lbs (39 kg), SST

Designed with electroplated surfaces that

prevent debris build-up and keep your

operation free of contaminants, Graco

pressure pots are precision welded and

surfaced.

• ASME rated to ensure it meets factory standards
• High quality stainless steel design is compatible with many materials
• Use in stand-alone spraying, material/catalyst supply, or as a moisture sensitive material reservoir

• Includes: Agitator
• Inlet Size (cm): 0.635
• Inlet Size (in): 1/4
• Inlet Size (mm): 6.35

• Inlet Thread Gender: Male
• Inlet Thread Type: NPT

• Maximum Volume Capacity (gal): 10
• Maximum Volume Capacity (L): 38

• Maximum Working Pressure (bar): 7
• Maximum Working Pressure (kPa): 700
• Maximum Working Pressure (MPa): 0.7
• Maximum Working Pressure (psi): 100

• Outlet Size (cm): 0.9525
• Outlet Size (in): 3/8
• Outlet Size (mm): 9.525
• Outlet Thread Gender: Male
• Outlet Thread Type: NPSM

• Overall Height (cm): 86.0
• Overall Height (in): 33.87
• Overall Height (mm): 860
• Overall Width (cm): 48.3
• Overall Width (in): 19
• Overall Width (mm): 483

GG 236154

TANK, HIGH PRESS, AGIT 15 GAL

Graco 236154 15 Gallon High Pressure (HVLP) Pot with Agitator, Regulated to 100 psi, ASME Rated, 44.6 in (113.2 cm) 101 lbs (46 kg), SST

Designed with electroplated surfaces that

prevent debris build-up and keep your

operation free of contaminants, Graco

pressure pots are precision welded and

surfaced.

• ASME rated to ensure it meets factory standards
• High quality stainless steel design is compatible with many materials
• Use in stand-alone spraying, material/catalyst supply, or as a moisture sensitive material reservoir

• Includes: Agitator
• Inlet Size (cm): 0.635
• Inlet Size (in): 1/4
• Inlet Size (mm): 6.35

• Inlet Thread Gender: Male
• Inlet Thread Type: NPT

• Maximum Volume Capacity (gal): 15
• Maximum Volume Capacity (L): 57

• Maximum Working Pressure (bar): 7
• Maximum Working Pressure (kPa): 700
• Maximum Working Pressure (MPa): 0.7
• Maximum Working Pressure (psi): 100

• Outlet Size (cm): 0.9525
• Outlet Size (in): 3/8
• Outlet Size (mm): 9.525
• Outlet Thread Gender: Male
• Outlet Thread Type: NPSM

• Overall Height (cm): 113.2
• Overall Height (in): 44.57
• Overall Height (mm): 1132
• Overall Width (cm): 48.3
• Overall Width (in): 19
• Overall Width (mm): 483

GG 236155

TANK, LOW PRESS, 2 GALLON SST

Graco 236155 2 Gallon Low Pressure (HVLP) Pot, Regulated to 15 psi, ASME Rated, 25.4 in (64.5 cm) 30 lbs (14 kg), SST

Designed with electroplated surfaces that

prevent debris build-up and keep your

operation free of contaminants, Graco

pressure pots are precision welded and

surfaced.

• ASME rated to ensure it meets factory standards
• High quality stainless steel design is compatible with many materials
• Use in stand-alone spraying, material/catalyst supply, or as a moisture sensitive material reservoir

• Inlet Size (cm): 0.635
• Inlet Size (in): 1/4
• Inlet Size (mm): 6.35

• Inlet Thread Gender: Male
• Inlet Thread Type: NPT

• Maximum Volume Capacity (gal): 2
• Maximum Volume Capacity (L): 8

• Maximum Working Pressure (bar): 1
• Maximum Working Pressure (kPa): 100
• Maximum Working Pressure (MPa): 0.1
• Maximum Working Pressure (psi): 15

• Outlet Size (cm): 0.9525
• Outlet Size (in): 3/8
• Outlet Size (mm): 9.525
• Outlet Thread Type: NPSM

• Overall Height (cm): 64.5
• Overall Height (in): 25.4
• Overall Height (mm): 645
• Overall Width (cm): 33.3
• Overall Width (in): 13.125
• Overall Width (mm): 333

GG 236156

TANK, LOW PRESS, AGIT, 2 GALLON

Graco 236156 2 Gallon Low Pressure (HVLP) Pot with Agitator, Regulated to 15 psi, ASME Rated, 26.0 in (66 cm), 38 lbs (17 kg), SST

Designed with electroplated surfaces that

prevent debris build-up and keep your

operation free of contaminants, Graco

pressure pots are precision welded and

surfaced.

• ASME rated to ensure it meets factory standards
• High quality stainless steel design is compatible with many materials
• Use in stand-alone spraying, material/catalyst supply, or as a moisture sensitive material reservoir

• Includes: Agitator
• Inlet Size (cm): 0.635
• Inlet Size (in): 1/4
• Inlet Size (mm): 6.35

• Inlet Thread Gender: Male
• Inlet Thread Type: NPT

• Maximum Volume Capacity (gal): 2
• Maximum Volume Capacity (L): 8

• Maximum Working Pressure (bar): 1
• Maximum Working Pressure (kPa): 100
• Maximum Working Pressure (MPa): 0.1
• Maximum Working Pressure (psi): 15

• Outlet Size (cm): 0.9525
• Outlet Size (in): 3/8
• Outlet Size (mm): 9.525
• Outlet Thread Type: NPSM

• Overall Height (cm): 66.0
• Overall Height (in): 26
• Overall Height (mm): 660
• Overall Width (cm): 33.3
• Overall Width (in): 13.125
• Overall Width (mm): 333

GG 236157

TANK, HIGH PRESS, 2 GALLON SST

Graco 236157 2 Gallon High Pressure (HVLP) Pot, Regulated to 100 psi, ASME Rated, 25.4 in (64.5 cm), 30 lbs (14 kg), SST

Designed with electroplated surfaces thatprevent debris build-up and keep youroperation free of contaminants, Gracopressure pots are precision welded andsurfaced.

• ASME rated to ensure it meets factory standards
• High quality stainless steel design is compatible with many materials
• Use in stand-alone spraying, material/catalyst supply, or as a moisture sensitive material reservoir

GG 236158

TANK, HIGH PRESS, AGIT, 2 GAL.

Graco 236158 2 Gallon High Pressure (HVLP) Pot with Agitator, Regulated to 100 psi, ASME Rated, 26 in (66 cm), 38 lbs (17 kg), SST

Designed with electroplated surfaces that

prevent debris build-up and keep your

operation free of contaminants, Graco

pressure pots are precision welded and

surfaced.

• ASME rated to ensure it meets factory standards
• High quality stainless steel design is compatible with many materials
• Use in stand-alone spraying, material/catalyst supply, or as a moisture sensitive material reservoir

• Includes: Agitator
• Inlet Size (cm): 0.635
• Inlet Size (in): 1/4
• Inlet Size (mm): 6.35

• Inlet Thread Gender: Male
• Inlet Thread Type: NPT

• Maximum Volume Capacity (gal): 2
• Maximum Volume Capacity (L): 8

• Maximum Working Pressure (bar): 7
• Maximum Working Pressure (kPa): 700
• Maximum Working Pressure (MPa): 0.7
• Maximum Working Pressure (psi): 100

• Outlet Size (cm): 0.9525
• Outlet Size (in): 3/8
• Outlet Size (mm): 9.525
• Outlet Thread Type: NPSM

• Overall Height (cm): 66.0
• Overall Height (in): 26
• Overall Height (mm): 660
• Overall Width (cm): 33.3
• Overall Width (in): 13.125
• Overall Width (mm): 333

GG 236234

STEM, VALVE

GG 236235

GG 236281

REGULATOR, PRESS, FLUID

Graco 236281 Low Pressure Lightweight Fluid Regulator, Gauge, 3-100 psi (0.2-7 bar), 0.5 gpm, Acetal, Spring, 1/4(f) x 1/4(m), 1/4(f) Port

Fluid pressure regulators control pressure of the downstream fluid, allowing operators to accurately control the pressure to guns, applicators and dispense valves

• Lightweight composite material is compatible with waterborne materials
• PTFE, stainless steel seat, and carbide ball provide wear resistance
• Pressure adjustment key with locking mechanism protects production settings

• Actuation Type: Air

• Gauge Port Size (cm): 0.635
• Gauge Port Size (in): 1/4
• Gauge Port Size (mm): 6.35

• Gauge Port Type: NPT

• Includes: Gauge
• Inlet Size (cm): 0.635
• Inlet Size (in): 1/4
• Inlet Size (mm): 6.35

• Inlet Thread Type: NPT

• Maximum Flow Rate (GPM): 0.5
• Maximum Flow Rate (L/min): 1.89

• Maximum Regulated Pressure (bar): 7.0
• Maximum Regulated Pressure (kPa): 700
• Maximum Regulated Pressure (MPa): 0.7
• Maximum Regulated Pressure (psi): 100

• Maximum Viscosity (cP): 1000

• Maximum Working Pressure (bar): 7
• Maximum Working Pressure (kPa): 700
• Maximum Working Pressure (MPa): 0.7
• Maximum Working Pressure (psi): 100

• Minimum Regulated Pressure (bar): 0.2
• Minimum Regulated Pressure (kPa): 20
• Minimum Regulated Pressure (MPa): 0.02
• Minimum Regulated Pressure (psi): 3

• Outlet Size (cm): 0.635
• Outlet Size (in): 1/4
• Outlet Size (mm): 6.35

GG 236410

GG 236449

REGULATOR, PRESS, FLUID

Graco 236449 Low Pressure Lightweight Fluid Regulator, Gauge, 3-30 psi (0.2-2 bar), 0.5 gpm, Acetal, Spring, 1/4(f) x 1/4(f), 1/4(f) Port

Fluid pressure regulators control pressure of the downstream fluid, allowing operators to accurately control the pressure to guns, applicators and dispense valves

• Lightweight composite material is compatible with waterborne materials
• PTFE, stainless steel seat, and carbide ball provide wear resistance
• Pressure adjustment key with locking mechanism protects production settings

• Actuation Type: Spring

• Gauge Port Size (cm): 0.635
• Gauge Port Size (in): 1/4
• Gauge Port Size (mm): 6.35

• Gauge Port Type: NPT

• Includes: Gauge
• Inlet Size (cm): 0.635
• Inlet Size (in): 1/4
• Inlet Size (mm): 6.35

• Inlet Thread Type: NPT

• Maximum Flow Rate (GPM): 0.5
• Maximum Flow Rate (L/min): 1.89

• Maximum Regulated Pressure (bar): 2.1
• Maximum Regulated Pressure (kPa): 210
• Maximum Regulated Pressure (MPa): 0.2
• Maximum Regulated Pressure (psi): 30

• Maximum Viscosity (cP): 1000

• Maximum Working Pressure (bar): 7
• Maximum Working Pressure (kPa): 700
• Maximum Working Pressure (MPa): 0.7
• Maximum Working Pressure (psi): 100

• Minimum Regulated Pressure (bar): 0.2
• Minimum Regulated Pressure (kPa): 20
• Minimum Regulated Pressure (MPa): 0.02
• Minimum Regulated Pressure (psi): 3

• Outlet Size (cm): 0.635
• Outlet Size (in): 1/4
• Outlet Size (mm): 6.35

GG 236452

GG 236598

GG 236859

GG 236860

GG 236873

GG 236588

GG 236611

CHECK-MATE PUMP, SHOVEL

Graco 236611 8 cm Carbon Steel Pump Shovel

• Model: Check-Mate

• Application: Bonding, Sealing, Gasketing, Potting, Encapsulation, Molding, Spray, Fluid Transfer, Unloading, Underfill

• Fluid Outlet Size (in): 1
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT

• For Use With: 65:1 King Pump

• Maximum Flow Rate (GPM): 2.8

• Maximum Operating Temperature ( degree F): 180

• Maximum Pump Speed (CPM): 60

• Maximum Working Pressure (psi): 5850

GG 236789

GG 236893

GG 236763

METER, ELECTRONIC PULSE, EFC

Graco 236763 In-Line Meter with Pulse Output (Pints, Quarts, Gallons)

Accurately measure dispenses of petroleum- and synthetic-based oils (motor, gear and ATF.)

• Provide pulse signal output.
• Measures in pints, quarts, or gallons.

• For Use With: Fluid Commander

• Inlet Size (cm): 1.27
• Inlet Size (in): 0.5
• Inlet Size (mm): 12.7

• Inlet Thread Type: NPT

• Maximum Flow Rate (GPM): 12
• Maximum Flow Rate (L/min): 45.6

• Maximum Working Pressure (bar): 103
• Maximum Working Pressure (kPa): 10300
• Maximum Working Pressure (MPa): 10.3
• Maximum Working Pressure (psi): 1500

GG 236719

GG 236677

KIT

Graco 236677 Bottom Outlet Kit for 5, 10 and 15 gallon (19, 38, 57 liter) pressure pots

GG 236987

SWIVEL, HOSE

Graco 236987 High Pressure Fluid Line Swivel, 1/4 npsm(f) x 1/4 npsm(m) thread size, PTFE seals, 7400 psi max working pressure, Series B

• 1/4 NPS (m) x 1/4 NPS (f)

• 7400 psi

• Straight Swivel

  Stainless Steel

GG 236663

AGITATOR, HEAVY DUTY, 15 GAL

Graco 236663 15 Gallon (57 L) Heavy Duty Pressure Tank Agitator, air driven, 1/2 HP, 15 inches (38 cm) in length, gear reduced

Waterborne compatible

• 20:1 gear reduction to mix high viscosity materials, even at low speeds
• Sealed agitator shaft to prevent air leakage and contamination
• Built-in baffle and support for efficient mixing

• For Use With: 15 Gallon (57 Litre) Pressure Tank

• Maximum Air Inlet Pressure (bar): 7
• Maximum Air Inlet Pressure (kPa): 700
• Maximum Air Inlet Pressure (psi): 100

• Maximum Speed (RPM): 3000

• Maximum Viscosity (cP): 800

• Maximum Working Pressure (bar): 7
• Maximum Working Pressure (kPa): 700
• Maximum Working Pressure (psi): 100

• Motor Type: Pneumatic - Rotary Vane

• Power Rating (HP): 0.50

GG 236698

KIT, REPAIR

Graco 236698 Repair Kit for Viscount I Hydraulic Motor

GG 236662

AGITATOR, HEAVY DUTY, 10 GAL

Graco 236662 10 Gallon (38 L) Heavy Duty Pressure Tank Agitator, air driven, 1/2 HP, 15 inches (38 cm) in length, gear reduced

Waterborne compatible

• 20:1 gear reduction to mix high viscosity materials, even at low speeds
• Sealed agitator shaft to prevent air leakage and contamination
• Built-in baffle and support for efficient mixing

• For Use With: 10 Gallon (38 Litre) Pressure Tank

• Maximum Air Inlet Pressure (bar): 7
• Maximum Air Inlet Pressure (kPa): 700
• Maximum Air Inlet Pressure (psi): 100

• Maximum Speed (RPM): 3000

• Maximum Viscosity (cP): 800

• Maximum Working Pressure (bar): 7
• Maximum Working Pressure (kPa): 700
• Maximum Working Pressure (psi): 100

• Motor Type: Pneumatic - Rotary Vane

• Power Rating (HP): 0.50

GG 236661

AGITATOR, HEAVY DUTY, 5 GAL

Graco 236661 5 Gallon (18 L) Heavy Duty Pressure Tank Agitator, air driven, 1/2 HP, 15 inches (38 cm) in length, gear reduced

Waterborne compatible

• 20:1 gear reduction to mix high viscosity materials, even at low speeds
• Sealed agitator shaft to prevent air leakage and contamination
• Built-in baffle and support for efficient mixing

• For Use With: 5 Gallon (19 Litre) Pressure Tank

• Maximum Air Inlet Pressure (bar): 7
• Maximum Air Inlet Pressure (kPa): 700
• Maximum Air Inlet Pressure (psi): 100

• Maximum Speed (RPM): 3000

• Maximum Viscosity (cP): 800

• Maximum Working Pressure (bar): 7
• Maximum Working Pressure (kPa): 700
• Maximum Working Pressure (psi): 100

• Motor Type: Pneumatic - Rotary Vane

• Power Rating (HP): 0.50

GG 236629

AGITATOR, SUCTION TWISTORK

Graco 236629 Twistork Drum Agitator, Siphon, Air, 3/4 HP, 47.5 in long, 304 SST, Adjustable Depth for 31.5-35.5 in Drums

• Helix blade effectively mixes higher viscosity materials
• Mounts directly to 2 inch drum bung
• Stainless and carbon steel material options
• Sealed agitator drive prevents material contamination and evaporation
• ATEX approval for hazardous locations
• Max viscosity 10,000 cps

• Model: Twistork

• Air Inlet Size (cm): 0.3175
• Air Inlet Size (in): 1/8
• Air Inlet Size (mm): 3.175
• Air Inlet Thread Type: NPT

• For Use With: 55 Gallon (208 Liter) Drum

• Maximum Speed (RPM): 800

• Maximum Viscosity (cP): 10000

• Maximum Working Pressure (bar): 7
• Maximum Working Pressure (kPa): 700
• Maximum Working Pressure (psi): 100

• Motor Type: Pneumatic - Rotary Vane

• Power Rating (HP): 0.75

GG 236760

AGITATOR, SUCTON, REVERSIBLE, TWISTRK

Graco 236760 Twistork Drum Agitator, Oil-less, Reversible, Siphon, Air, 3/4 HP, 47.5 in long, 304 SST, Adjustable for 31.5-35.5 in Drums

• Helix blade effectively mixes higher viscosity materials
• Mounts directly to 2 inch drum bung
• Stainless and carbon steel material options
• Sealed agitator drive prevents material contamination and evaporation
• ATEX approval for hazardous locations
• Max viscosity 10,000 cps

• Model: Twistork

• Air Inlet Size (cm): 0.3175
• Air Inlet Size (in): 1/8
• Air Inlet Size (mm): 3.175
• Air Inlet Thread Type: NPT

• For Use With: 55 Gallon (208 Liter) Drum

• Maximum Speed (RPM): 800

• Maximum Viscosity (cP): 10000

• Maximum Working Pressure (bar): 7
• Maximum Working Pressure (kPa): 700
• Maximum Working Pressure (psi): 100

• Motor Type: Pneumatic - Rotary Vane

• Power Rating (HP): 0.75

GG 237008

GLUTTON PUMP, (4:1 CS)

Graco 237008 Glutton 4:1 Bellows Pump, CS, Series A

The Glutton plunger pump is ideal for air assisted and airless spray applications. It features a bellows seal that virtually eliminates the possibility of air or moisture contaminating the fluid. Pump ratios include 4:1, 12:1 and 25:1

• Bellows seal design provides low maintenance with no seals exposed to the atmosphere and eliminates conventional throat seals, providing high reliability for moisture-sensitive materials
• Designed to handle a broad range of applications, including abrasive materials
• Reversible outlet manifold simplifies plumbing installations

• Model: Glutton
• Series: Bellows

• Air Inlet Size (in): 0.5
• Air Inlet Size (mm): 12.7
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Circulation

• Compatible Material: Waterborne, Solvent borne, High Solids, Xirallic, Metallics, UV Coating, Stains, Varnish, CARC

• Fluid Outlet Size (in): 1
• Fluid Outlet Size (mm): 25.4
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT
• Fluid Section Type: Sealed

• Material: Carbon Steel

• Maximum Air Inlet Pressure (bar): 6.9
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Continuous Cycle Rate (CPM): 60

• Maximum Flow Rate (GPM): 5.6
• Maximum Flow Rate (L/min): 21.2

• Maximum Operating Temperature ( degree C): 66
• Maximum Operating Temperature ( degree F): 150

• Maximum Working Pressure (bar): 28
• Maximum Working Pressure (kPa): 2800
• Maximum Working Pressure (MPa): 2.8
• Maximum Working Pressure (psi): 400

• Portable: Non-Portable

• Pump Ratio: 4:1

GG 237009

GLUTTON PUMP, (12:1 CS)

Graco 237009 Glutton 12:1 Bellows Pump, CS, Series A

The Glutton plunger pump is ideal for air assisted and airless spray applications. It features a bellows seal that virtually eliminates the possibility of air or moisture contaminating the fluid. Pump ratios include 4:1, 12:1 and 25:1

• Bellows seal design provides low maintenance with no seals exposed to the atmosphere and eliminates conventional throat seals, providing high reliability for moisture-sensitive materials
• Designed to handle a broad range of applications, including abrasive materials
• Reversible outlet manifold simplifies plumbing installations

• Model: Glutton
• Series: Bellows

• Air Inlet Size (in): 0.5
• Air Inlet Size (mm): 12.7
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Circulation

• Compatible Material: Waterborne, Solvent borne, High Solids, Xirallic, Metallics, UV Coating, Stains, Varnish, CARC

• Fluid Outlet Size (in): 1
• Fluid Outlet Size (mm): 25.4
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT
• Fluid Section Type: Sealed

• Material: Carbon Steel

• Maximum Air Inlet Pressure (bar): 6.9
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Continuous Cycle Rate (CPM): 60

• Maximum Flow Rate (GPM): 2
• Maximum Flow Rate (L/min): 7.57

• Maximum Operating Temperature ( degree C): 66
• Maximum Operating Temperature ( degree F): 150

• Maximum Working Pressure (bar): 83
• Maximum Working Pressure (kPa): 8300
• Maximum Working Pressure (MPa): 8.3
• Maximum Working Pressure (psi): 1200

• Portable: Non-Portable

• Pump Ratio: 12:1

GG 237011

GLUTTON PUMP, (4:1 SST)

Graco 237011 Glutton 4:1 Bellows Pump, SST, Series A

The Glutton plunger pump is ideal for air assisted and airless spray applications. It features a bellows seal that virtually eliminates the possibility of air or moisture contaminating the fluid. Pump ratios include 4:1, 12:1 and 25:1

• Bellows seal design provides low maintenance with no seals exposed to the atmosphere and eliminates conventional throat seals, providing high reliability for moisture-sensitive materials
• Designed to handle a broad range of applications, including abrasive materials
• Reversible outlet manifold simplifies plumbing installations

• Model: Glutton
• Series: Bellows

• Air Inlet Size (in): 0.5
• Air Inlet Size (mm): 12.7
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Circulation

• Compatible Material: Waterborne, Solvent borne, High Solids, Xirallic, Metallics, UV Coating, Stains, Varnish, CARC

• Fluid Outlet Size (in): 1
• Fluid Outlet Size (mm): 25.4
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT
• Fluid Section Type: Sealed

• Material: Stainless Steel

• Maximum Air Inlet Pressure (bar): 6.9
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Continuous Cycle Rate (CPM): 60

• Maximum Flow Rate (GPM): 5.6
• Maximum Flow Rate (L/min): 21.2

• Maximum Operating Temperature ( degree C): 66
• Maximum Operating Temperature ( degree F): 150

• Maximum Working Pressure (bar): 28
• Maximum Working Pressure (kPa): 2800
• Maximum Working Pressure (MPa): 2.8
• Maximum Working Pressure (psi): 400

• Portable: Non-Portable

• Pump Ratio: 4:1

GG 237013

GLUTTON PUMP, (25:1 SST)

Graco 237013 Glutton 25:1 Bellows Pump, SST, Series A

The Glutton plunger pump is ideal for air assisted and airless spray applications. It features a bellows seal that virtually eliminates the possibility of air or moisture contaminating the fluid. Pump ratios include 4:1, 12:1 and 25:1

• Bellows seal design provides low maintenance with no seals exposed to the atmosphere and eliminates conventional throat seals, providing high reliability for moisture-sensitive materials
• Designed to handle a broad range of applications, including abrasive materials
• Reversible outlet manifold simplifies plumbing installations

• Model: Glutton
• Series: Bellows

• Air Inlet Size (in): 0.5
• Air Inlet Size (mm): 12.7
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Supply

• Compatible Material: Waterborne, Solvent borne, High Solids, Xirallic, Metallics, UV Coating, Stains, Varnish, CARC

• Fluid Outlet Size (in): 3/4
• Fluid Outlet Size (mm): 19.05
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT
• Fluid Section Type: Sealed

• Material: Stainless Steel

• Maximum Air Inlet Pressure (bar): 6.9
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Continuous Cycle Rate (CPM): 60

• Maximum Flow Rate (GPM): 0.9
• Maximum Flow Rate (L/min): 3.41

• Maximum Operating Temperature ( degree C): 66
• Maximum Operating Temperature ( degree F): 150

• Maximum Working Pressure (bar): 172
• Maximum Working Pressure (kPa): 17200
• Maximum Working Pressure (MPa): 17.2
• Maximum Working Pressure (psi): 2500

• Portable: Non-Portable

• Pump Ratio: 25:1

GG 237129

FAST-FLO PUMP, (1:1)

Graco 237129 1:1 Ratio Fast-Flo Air Operated Piston Transfer Stainless Steel Drum Pump with T Packing

Fast Flo 1:1 pumps are designed to operate at air input pressures up to 180 psi (12 bar, 1.2 MPa) and deliver a smooth, reliable flow. Drum length and stubby models are available for either drum transfer or wall mount siphon feed applications. Ideal for lower viscosity fluids with plate (flat) check options.

• Air-powered for high reliability and low cost
• Delivery up to 5 gpm (19 lpm)
• Available in stainless steel or carbon steel

• Model: Fast-Flo

• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Industrial

• Compatible Drum Height (in): 34.6

• Compatible Material: Antifreeze, Asphalt, Windshield Washer Fluid, Motor Oil, Used Oil, Hydraulic Fluid, Oil, Ink

• Fluid Outlet Size (in): 3/4
• Fluid Outlet Size (mm): 19.05
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT

• Material: Stainless Steel

• Maximum Air Inlet Pressure (bar): 12.41
• Maximum Air Inlet Pressure (kPa): 1241
• Maximum Air Inlet Pressure (psi): 180

• Maximum Continuous Cycle Rate (CPM): 100

• Maximum Flow Rate (GPM): 4
• Maximum Flow Rate (L/min): 15.1

• Maximum Intermittent Cycle Rate (CPM): 4

• Maximum Working Pressure (bar): 12.4
• Maximum Working Pressure (kPa): 1240
• Maximum Working Pressure (MPa): 1.2
• Maximum Working Pressure (psi): 180

• Minimum Flow Rate (GPM): 180

• Package Options: None

• Portable: Non-Portable

• Power Type: Pneumatic

• Pump Ratio: 1:1

GG 237131

FAST-FLO PUMP, (1:1)

Graco 237131 1:1 Ratio Fast-Flo Air Operated Stubby Piston Transfer Pump

Fast Flo 1:1 pumps are designed to operate at air input pressures up to 180 psi (12 bar, 1.2 MPa) and deliver a smooth, reliable flow. Drum length and stubby models are available for either drum transfer or wall mount siphon feed applications. Ideal for lower viscosity fluids with plate (flat) check options.

• Air-powered for high reliability and low cost
• Delivery up to 5 gpm (19 lpm)
• Available in stainless steel or carbon steel

• Model: Fast-Flo

• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Industrial

• Compatible Drum Height (in): 7.1

• Compatible Material: Antifreeze, Asphalt, Windshield Washer Fluid, Motor Oil, Used Oil, Hydraulic Fluid, Oil, Ink

• Fluid Outlet Size (in): 3/4
• Fluid Outlet Size (mm): 19.05
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT

• Material: Carbon Steel

• Maximum Air Inlet Pressure (bar): 12.41
• Maximum Air Inlet Pressure (kPa): 1241
• Maximum Air Inlet Pressure (psi): 180

• Maximum Continuous Cycle Rate (CPM): 100

• Maximum Flow Rate (GPM): 4
• Maximum Flow Rate (L/min): 15.1

• Maximum Intermittent Cycle Rate (CPM): 4

• Maximum Working Pressure (bar): 12.4
• Maximum Working Pressure (kPa): 1240
• Maximum Working Pressure (MPa): 1.2
• Maximum Working Pressure (psi): 180

• Minimum Flow Rate (GPM): 180

• Package Options: None

• Portable: Non-Portable

• Power Type: Pneumatic

• Pump Ratio: 1:1

GG 237132

FAST-FLO PUMP, (1:1)

Graco 237132 1:1 Ratio Fast-Flo Air Operated Piston Transfer Stainless Steel Stubby Pump with PTFE Packings

Fast Flo 1:1 pumps are designed to operate at air input pressures up to 180 psi (12 bar, 1.2 MPa) and deliver a smooth, reliable flow. Drum length and stubby models are available for either drum transfer or wall mount siphon feed applications. Ideal for lower viscosity fluids with plate (flat) check options.

• Air-powered for high reliability and low cost
• Delivery up to 5 gpm (19 lpm)
• Available in stainless steel or carbon steel

• Model: Fast-Flo

• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Industrial

• Compatible Drum Height (in): 9.8

• Compatible Material: Antifreeze, Asphalt, Windshield Washer Fluid, Motor Oil, Used Oil, Hydraulic Fluid, Oil, Ink

• Fluid Outlet Size (in): 3/4
• Fluid Outlet Size (mm): 19.05
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT

• Material: Stainless Steel

• Maximum Air Inlet Pressure (bar): 12.41
• Maximum Air Inlet Pressure (kPa): 1241
• Maximum Air Inlet Pressure (psi): 180

• Maximum Continuous Cycle Rate (CPM): 100

• Maximum Flow Rate (GPM): 4
• Maximum Flow Rate (L/min): 15.1

• Maximum Intermittent Cycle Rate (CPM): 4

• Maximum Working Pressure (bar): 12.4
• Maximum Working Pressure (kPa): 1240
• Maximum Working Pressure (MPa): 1.2
• Maximum Working Pressure (psi): 180

• Minimum Flow Rate (GPM): 180

• Package Options: None

• Portable: Non-Portable

• Power Type: Pneumatic

• Pump Ratio: 1:1

GG 237143

PRESIDENT PUMP

Graco 237143 President 3:1 Pneumatic 2-Ball Piston Pump, CS, Stubby, 3 Leather/ 2 PTFE Seals

2-ball pneumatic piston pumps for a wide range of applications.

• Reliable President air motor designed for low maintenance operation and long life
• Positive displacement, 2-ball piston design provides uniform and easily controlled delivery
• Stainless steel or carbon steel models available to handle various fluids, including catalyzed materials

• Model: President
• Series: 2-Ball

• Air Inlet Size (in): 3/8
• Air Inlet Size (mm): 12.7
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPSM

• Application: Supply

• Compatible Material: Waterborne, Solvent borne, High Solids, Xirallic, CARC, Metallics, Topcoats, Stains, Varnish

• Fluid Outlet Size (in): 3/4
• Fluid Outlet Size (mm): 19.05
• Fluid Outlet Thread Gender: Male
• Fluid Outlet Thread Type: NPT
• Fluid Section Type: 2-Ball

• Includes: Stubby Length

• Material: Carbon Steel

• Maximum Air Inlet Pressure (bar): 8.27
• Maximum Air Inlet Pressure (kPa): 827
• Maximum Air Inlet Pressure (psi): 120

• Maximum Continuous Cycle Rate (CPM): 60

• Maximum Flow Rate (GPM): 10
• Maximum Flow Rate (L/min): 37.85

• Maximum Operating Temperature ( degree C): 82
• Maximum Operating Temperature ( degree F): 180

• Maximum Working Pressure (bar): 248
• Maximum Working Pressure (kPa): 24800
• Maximum Working Pressure (MPa): 24.8
• Maximum Working Pressure (psi): 3600

• Portable: Non-Portable

• Pump Ratio: 3:1

GG 237145

PRESIDENT PUMP, 3:1, SST, 55 GL

Graco 237145 President 3:1 Pneumatic 2-Ball Piston Pump, SST, Drum, 5 PTFE Seals

2-ball pneumatic piston pumps for a wide range of applications.

• Reliable President air motor designed for low maintenance operation and long life
• Positive displacement, 2-ball piston design provides uniform and easily controlled delivery
• Stainless steel or carbon steel models available to handle various fluids, including catalyzed materials

• Model: President
• Series: 2-Ball

• Air Inlet Size (in): 3/8
• Air Inlet Size (mm): 12.7
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPSM

• Application: Supply

• Compatible Material: Waterborne, Solvent borne, High Solids, Xirallic, CARC, Metallics, Topcoats, Stains, Varnish

• Fluid Outlet Size (in): 1
• Fluid Outlet Size (mm): 25.4
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT
• Fluid Section Type: 2-Ball

• Includes: Drum Length

• Material: Stainless Steel

• Maximum Air Inlet Pressure (bar): 8.27
• Maximum Air Inlet Pressure (kPa): 827
• Maximum Air Inlet Pressure (psi): 120

• Maximum Continuous Cycle Rate (CPM): 60

• Maximum Flow Rate (GPM): 10
• Maximum Flow Rate (L/min): 37.85

• Maximum Operating Temperature ( degree C): 82
• Maximum Operating Temperature ( degree F): 180

• Maximum Working Pressure (bar): 124
• Maximum Working Pressure (kPa): 12400
• Maximum Working Pressure (MPa): 12.4
• Maximum Working Pressure (psi): 1800

• Portable: Non-Portable

• Pump Ratio: 3:1

GG 237161

DISPENSER, WWS

Graco 237161 Husky 307 Series Pre-Mixed Windshield Wash Solvent and Coolant Dispense Diaphragm Pump Package

The Husky 307 air-operated diaphragm pump features a stall-free low pulsation air valve that provides a smooth and rapid changeover.

• Quick and easy assembly and disassembly design
• Easy to service air valve and ball checks
• Operates on as little as 20 psi (1.4 bar, 0.14 MPa)
• Every pump is tested prior to shipping
• 3/8 in (9.52 mm) end porting
• Delivery up to 7 gpm (26.5 lpm)
• Easy-to-service air valve and ball checks

• Model: Husky
• Series: 307

• Application: Industrial

• Compatible Material: Oil, Water, Antifreeze, Windshield Washer Fluid

• Fluid Inlet Size (cm): 0.9525
• Fluid Inlet Size (in): 3/8
• Fluid Inlet Size (mm): 9.525
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (cm): 0.9525
• Fluid Outlet Size (in): 3/8
• Fluid Outlet Size (mm): 9.525
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT

• For Use With: Windshield Wash Solvent and Coolant

• Includes: 307 Diaphragm Pump, Air Hose, Coupled Fluid Hose, Air Filter, Air Gauge, Air Line Fitting, Air Regulator, Elbow, Tube, Mounting Bracket, Adapter, Nipple, Suction Hose Kit, Coupled PVC Hose and Mesh Strainer, Wall Bracket

• Material: Acetal, TPE

• Maximum Air Pressure (bar): 7

• Maximum Air Pressure (kPa): 70
• Maximum Air Pressure (psi): 100

• Maximum Cycle Rate (CPM): 330

• Maximum Flow Rate (GPM): 7

• Maximum Fluid Pressure (bar): 7
• Maximum Fluid Pressure (kPa): 70
• Maximum Fluid Pressure (MPa): 0.7
• Maximum Fluid Pressure (psi): 100

• Maximum Fluid Pressure (bar): 7
• Maximum Fluid Pressure (kPa): 70
• Maximum Fluid Pressure (MPa): 0.7
• Maximum Fluid Pressure (psi): 100

• Maximum Solid Size (cm): 0.1524
• Maximum Solid Size (in): 0.06
• Maximum Solid Size (mm): 1.524

GG 237163

GG 237170

GG 237172

GG 237178

GG 237180

GG 237200

KIT, REPAIR

GG 237239

GG 237243

GG 237303

GG 237306

COVER, DRUM ASSEMBLY

Graco 237306 Drum Cover for President, Monark, Standard, and Fast-Flo Pumps (Standard and Fast-Flo require adaptor plate), Series A

GG 237449

GG 237469

GG 237481

GG 237503

REGULATOR, BACK PRESSURE

Graco 237503 Back Pressure Regulator, Bare, Low Pressure, 180 Max psi, SST, Manual, 3/8 npt(f) inlet x 1/2 npt(f) outlet

237503 is the back pressure regulator only. Part number 236770 includes the gauge, tube, inlet adapter and outlet swivel union. Graco back pressure regulators maintain the system pressure, regardless of flow demand

• Compact and lightweight design saves space and reduces payload for small circulation systems
• Tungsten and carbide materials ensure low wear and long life
• PTFE/Elastomer hybrid diaphragm withstands wear while maintaining accurate responsiveness

• Compatible Material: Catalyst, Waterborne

• Gauge Port Size (cm): 0.635
• Gauge Port Size (in): 1/4
• Gauge Port Size (mm): 6.35

• Gauge Port Type: NPT

• Inlet Size (cm): 0.9525
• Inlet Size (in): 3/8
• Inlet Size (mm): 9.525

• Inlet Thread Type: NPT

• Maximum Flow Rate (GPM): 4.3
• Maximum Flow Rate (L/min): 16.28

• Maximum Regulated Pressure (bar): 12.4
• Maximum Regulated Pressure (kPa): 1240
• Maximum Regulated Pressure (psi): 180

• Maximum Viscosity (cP): 1000

• Maximum Working Pressure (bar): 21
• Maximum Working Pressure (kPa): 2100
• Maximum Working Pressure (psi): 300

• Minimum Regulated Pressure (bar): 0.3
• Minimum Regulated Pressure (kPa): 30
• Minimum Regulated Pressure (MPa): 0.03
• Minimum Regulated Pressure (psi): 5

• Outlet Size (cm): 1.27
• Outlet Size (in): 1/2
• Outlet Size (mm): 12.7
• Outlet Thread Type: NPT

GG 237514

GG 237522

HOSE, COUPLED

Graco 237522 Nylon Coupled Hose, 6 ft (1.8 m) long, 1 in. (25 mm) ID for 10:1 Bulldog Portable Hydra-Clean Unit

GG 237524

GG 237526

FIREBALL 425 PUMP, 3:1

Graco 237526 Fire-Ball 425 Series 3:1 Universal Size Oil Pump

With a large 4.25 inch (107.9 mm) air motor to supply the power you need for long pipe runs and higher volume dispensing, the Fire-Ball 425 delivers field-proven durability for multiple fluid types and exceptional cost savings that are hard to beat!

• Durable - Thick cast aluminum air motor housing offers unmatched durability.
• Fewer Repairs - Fewer moving parts in the air motor assembly means less downtime and low repair cost.
• Extended Seal Life - In-line pump design aligns the air motor piston and fluid piston rods to maximize seal life.
• Superior Sealing - Non-metallic poppet valves offer positive sealing performance, even with contaminated dirtyair environments for long life without repair.
• Reduced Icing - Large air porting design provides efficient use of compressed air supply for continuous pump operation and reduced icing.
• Corrosion-Resistant - Corrosion-resistant design utilizes liquid salt nitriding, nickel plating, stainless steel, aluminum and chrome on key components for longer life.

• Model: Fire-Ball
• Series: 425

• Air Inlet Size (in): 0.5
• Air Inlet Size (mm): 12.7
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT
• Air Motor Effective Diameter (in): 4.25

• Application: Industrial

• Compatible Material: Oil

• Cycles Per Gallon: 6

• Fluid Inlet Size (in): 1-1/2
• Fluid Inlet Size (mm): 38.1
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (in): 3/4
• Fluid Outlet Size (mm): 19.05
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT

• For Use With: Petroleum- and synthetic-based oils (motor, gear and ATF)

• Maximum Air Inlet Pressure (bar): 12.41
• Maximum Air Inlet Pressure (kPa): 1241
• Maximum Air Inlet Pressure (psi): 180

• Maximum Continuous Cycle Rate (CPM): 66

• Maximum Intermittent Cycle Rate (CPM): 66

• Maximum Working Pressure (bar): 37
• Maximum Working Pressure (kPa): 3700
• Maximum Working Pressure (MPa): 3.7
• Maximum Working Pressure (psi): 540

• Power Type: Pneumatic

• Pump Ratio: 3:1

GG 237528

VALVE, BALL

Graco 237528 Low Pressure Ball Valve compatible with stainless steel, catalyst and waterborne materials, 1/4 in. npt(m) x 1/4 in. npt(m)

Use for on/off fluid control. Allows safer system operation by permitting relief of fluid pressure or isolation of components from pressure during maintenance. Ball vales must be used in the fully open or closed position. Do not throttle the valve - it could cause premature seal failure.

• Stainless steel and PTFE materials are compatible with catalyst, waterborne, and other finishing materials
• Many different connection options to meet your specific needs

• Handle Type: Lever

• Inlet Size (cm): 0.635
• Inlet Size (in): 1/4
• Inlet Size (mm): 6.35

• Inlet Thread Gender: Male
• Inlet Thread Type: NPT

• Maximum Working Pressure (bar): 35
• Maximum Working Pressure (kPa): 3500
• Maximum Working Pressure (MPa): 3.5
• Maximum Working Pressure (psi): 500

• Outlet Size (cm): 0.635
• Outlet Size (in): 1/4
• Outlet Size (mm): 6.35
• Outlet Thread Gender: Male
• Outlet Thread Type: NPT

GG 237529

VALVE, BALL

Graco 237529 Low Pressure Ball Valve compatible with stainless steel, catalyst and waterborne materials, 1/4 in. npt(m) x 3/8 in. npsm(m)

Use for on/off fluid control. Allows safer system operation by permitting relief of fluid pressure or isolation of components from pressure during maintenance. Ball vales must be used in the fully open or closed position. Do not throttle the valve - it could cause premature seal failure.

• Stainless steel and PTFE materials are compatible with catalyst, waterborne, and other finishing materials
• Many different connection options to meet your specific needs

• Handle Type: Lever

• Inlet Size (cm): 0.635
• Inlet Size (in): 1/4
• Inlet Size (mm): 6.35

• Inlet Thread Type: NPT

• Maximum Working Pressure (bar): 35
• Maximum Working Pressure (kPa): 3500
• Maximum Working Pressure (MPa): 3.5
• Maximum Working Pressure (psi): 500

• Outlet Size (cm): 0.9525
• Outlet Size (in): 3/8
• Outlet Size (mm): 9.525
• Outlet Thread Gender: Male
• Outlet Thread Type: NPSM

GG 237530

VALVE, BALL

Graco 237530 Low Pressure Ball Valve compatible with stainless steel, catalyst and waterborne materials, 3/8 in. npt(m) x 1/4 in. npt(m)

Use for on/off fluid control. Allows safer system operation by permitting relief of fluid pressure or isolation of components from pressure during maintenance. Ball vales must be used in the fully open or closed position. Do not throttle the valve - it could cause premature seal failure.

• Stainless steel and PTFE materials are compatible with catalyst, waterborne, and other finishing materials
• Many different connection options to meet your specific needs

• Handle Type: Lever

• Inlet Size (cm): 0.9525
• Inlet Size (in): 3/8
• Inlet Size (mm): 9.525

• Inlet Thread Gender: Male
• Inlet Thread Type: NPT

• Maximum Working Pressure (bar): 35
• Maximum Working Pressure (kPa): 3500
• Maximum Working Pressure (MPa): 3.5
• Maximum Working Pressure (psi): 500

• Outlet Size (cm): 0.635
• Outlet Size (in): 1/4
• Outlet Size (mm): 6.35
• Outlet Thread Gender: Male
• Outlet Thread Type: NPT

GG 237531

VALVE, BALL

Graco 237531 Low Pressure Ball Valve compatible with stainless steel, catalyst and waterborne materials, 3/8 in. npt(m) x 3/8 in. npt(m)

Use for on/off fluid control. Allows safer system operation by permitting relief of fluid pressure or isolation of components from pressure during maintenance. Ball vales must be used in the fully open or closed position. Do not throttle the valve - it could cause premature seal failure.

• Stainless steel and PTFE materials are compatible with catalyst, waterborne, and other finishing materials
• Many different connection options to meet your specific needs

• Handle Type: Lever

• Inlet Size (cm): 0.9525
• Inlet Size (in): 3/8
• Inlet Size (mm): 9.525

• Inlet Thread Gender: Male
• Inlet Thread Type: NPT

• Maximum Working Pressure (bar): 35
• Maximum Working Pressure (kPa): 3500
• Maximum Working Pressure (MPa): 3.5
• Maximum Working Pressure (psi): 500

• Outlet Size (cm): 0.9525
• Outlet Size (in): 3/8
• Outlet Size (mm): 9.525
• Outlet Thread Gender: Male
• Outlet Thread Type: NPT

GG 237532

VALVE, BALL

Graco 237532 Low Pressure Ball Valve compatible with stainless steel, catalyst and waterborne materials, 3/8 in. npt(f) x 3/8 in. npt(f)

Use for on/off fluid control. Allows safer system operation by permitting relief of fluid pressure or isolation of components from pressure during maintenance. Ball vales must be used in the fully open or closed position. Do not throttle the valve - it could cause premature seal failure.

• Stainless steel and PTFE materials are compatible with catalyst, waterborne, and other finishing materials
• Many different connection options to meet your specific needs

• Handle Type: Lever

• Inlet Size (cm): 0.9525
• Inlet Size (in): 3/8
• Inlet Size (mm): 9.525

• Inlet Thread Gender: Female
• Inlet Thread Type: NPT

• Maximum Working Pressure (bar): 35
• Maximum Working Pressure (kPa): 3500
• Maximum Working Pressure (MPa): 3.5
• Maximum Working Pressure (psi): 500

• Outlet Size (cm): 0.9525
• Outlet Size (in): 3/8
• Outlet Size (mm): 9.525
• Outlet Thread Gender: Female
• Outlet Thread Type: NPT

GG 237533

VALVE, BALL

Graco 237533 Low Pressure Ball Valve compatible with stainless steel, catalyst and waterborne materials, 3/8 in. npsm(m) x 3/8 in. npt(m)

Use for on/off fluid control. Allows safer system operation by permitting relief of fluid pressure or isolation of components from pressure during maintenance. Ball vales must be used in the fully open or closed position. Do not throttle the valve - it could cause premature seal failure.

• Stainless steel and PTFE materials are compatible with catalyst, waterborne, and other finishing materials
• Many different connection options to meet your specific needs

• Handle Type: Lever

• Inlet Size (cm): 0.9525
• Inlet Size (in): 3/8
• Inlet Size (mm): 9.525

• Inlet Thread Gender: Male
• Inlet Thread Type: NPSM

• Maximum Working Pressure (bar): 35
• Maximum Working Pressure (kPa): 3500
• Maximum Working Pressure (MPa): 3.5
• Maximum Working Pressure (psi): 500

• Outlet Size (cm): 0.9525
• Outlet Size (in): 3/8
• Outlet Size (mm): 9.525
• Outlet Thread Gender: Male
• Outlet Thread Type: NPT

GG 237535

VALVE, BALL

Graco 237535 Low Pressure Ball Valve compatible with stainless steel, catalyst and waterborne materials, 3/8 in. npt(f) x 3/8 in. npsm(m)

Use for on/off fluid control. Allows safer system operation by permitting relief of fluid pressure or isolation of components from pressure during maintenance. Ball vales must be used in the fully open or closed position. Do not throttle the valve - it could cause premature seal failure.

• Stainless steel and PTFE materials are compatible with catalyst, waterborne, and other finishing materials
• Many different connection options to meet your specific needs

• Handle Type: Lever

• Inlet Size (cm): 0.9525
• Inlet Size (in): 3/8
• Inlet Size (mm): 9.525

• Inlet Thread Gender: Female
• Inlet Thread Type: NPT

• Maximum Working Pressure (bar): 35
• Maximum Working Pressure (kPa): 3500
• Maximum Working Pressure (MPa): 3.5
• Maximum Working Pressure (psi): 500

• Outlet Size (cm): 0.9525
• Outlet Size (in): 3/8
• Outlet Size (mm): 9.525
• Outlet Thread Gender: Male
• Outlet Thread Type: NPSM

GG 237537

VALVE, BALL

Graco 237537 Low Pressure Ball Valve compatible with stainless steel, catalyst and waterborne materials, 3/8 in. OD Tube x 3/8 in. OD Tube

Use for on/off fluid control. Allows safer system operation by permitting relief of fluid pressure or isolation of components from pressure during maintenance. Ball vales must be used in the fully open or closed position. Do not throttle the valve - it could cause premature seal failure.

• Stainless steel and PTFE materials are compatible with catalyst, waterborne, and other finishing materials
• Many different connection options to meet your specific needs

• Handle Type: Lever

• Inlet Size (cm): 0.9525
• Inlet Size (in): 3/8
• Inlet Size (mm): 9.525

• Inlet Thread Type: Tube End

• Maximum Working Pressure (bar): 35
• Maximum Working Pressure (kPa): 3500
• Maximum Working Pressure (MPa): 3.5
• Maximum Working Pressure (psi): 500

• Outlet Size (cm): 0.9525
• Outlet Size (in): 3/8
• Outlet Size (mm): 9.525
• Outlet Thread Type: Tube End

GG 237567

GG 237579

KIT, AIR CONTROL

GG 237574
