GRACO INC. S10595

GG 23768-01

GG 238157

AGITATOR, HEAVY DUTY, SST

Graco 238157 Heavy Duty Back-Geared Drum Agitator, air driven, 1/2 HP, 32 inches (81.25 cm) tall. Drum Cover (238283) and Siphon Kit (238250) not included

• Drum cover and siphon kit are not included, but they can be ordered separately as these part numbers: 238283 (drum cover), 238250 (siphon kit)
• Leak-free and oil-less gearbox prevents material contamination
• Stainless steel agitator is corrosion resistant and waterborne compatible
• Access port for easy sampling and inspection of material during operation

• Air Inlet Size (cm): 0.635
• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35
• Air Inlet Thread Type: NPT

• For Use With: 55 Gallon (208 Liter) Drum

• Maximum Air Inlet Pressure (bar): 7
• Maximum Air Inlet Pressure (kPa): 700
• Maximum Air Inlet Pressure (psi): 100

• Maximum Speed (RPM): 1200

• Maximum Viscosity (cP): 3000

• Maximum Working Pressure (bar): 7
• Maximum Working Pressure (kPa): 700
• Maximum Working Pressure (psi): 100

• Motor Type: Pneumatic - Rotary Vane

• Power Rating (HP): 0.25

GG 237608

GG 238049

TSL FLUID, 4 OZ

Graco 238049 TSL Throat Seal Liquid, 4 oz

Throat Seal Liquid (TSL) prevents paint and coatings from drying onto the displacement rod and packings, extending the life of the pump.

• Model: TSL
• Series: Throat Seal Liquid

• For Use With: Airless Sprayer, Magnum A100 ProPlus

GG 237649

ULTRA-LITE 4000 GUN, FLOW, SWIVEL INLET

Graco 237649 Ultra-Lite 4000 SD with Swivel

The operator-friendly Ultra-Lite 4000 combines ergonomic design with high-operating pressure for dispensing low-to-medium viscosity industrial and automotive sealants and adhesives.

• Operating pressures to 4000 psi (276 bar, 27.6 MPa).
• 150 degree head/handle angle is more comfortable for operator
• Changeable tips for a variety of dispensing needs

• Model: Ultra-Lite
• Series: 4000

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kg/cm 2): 281
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (MPa): 28
• Maximum Working Pressure (psi): 4000

• Nozzle Size (cm): 0.508
• Nozzle Size (in): 0.2
• Nozzle Size (mm): 5.08

GG 23764-00

GG 237799

GG 238161

TUBE, SIPHON, HD AGITATOR

Graco 238161 Siphon Tube for Siphon Kit Model 238250 for Heavy Duty Statinless Steel Drum Agitator

GG 237746

ELEVATOR, ASSY, FIXED MOUNTING

Graco 237746 Elevator Assembly, Series A

GG 237710

GG 238250

KIT, SIPHON

Graco 238250 Siphon Tube Kit for Heavy Duty Stainless Steel Drun Agitator, Series A

GG 237906

KIT,REPAIR,PISTON

KIT INCLUDES: SEAT, PISTON, SST [QTY. 1], SEAT, PISTON [QTY. 1], BEARING, PISTON [QTY. 1], GUIDE, PISTON, 200 [QTY. 1], PACKING, O-RING [QTY. 2], LUBRICANT, TUBE, 1 OZ [QTY. 1], ADHESIVE, ANAEROBIC [QTY. 1], BEARING, PISTON GUIDE CM200 [QTY. 1]

GG 238225

GG 238283

COVER,DRUM,HD AGITATOR

Graco 238283 Drum Cover for 238157 Agitators, Series A

GG 238358

HOSE, COUPLED, 3/16" X 3'

Graco 238358 BlueMax II Airless Whip Hose, 3/16 in x 3 ft

The BlueMax II Whip Hose provides more flexibility and increased operator control at the gun. This BlueMax II Whip Hose has a 3/16 inch diameter and is 3 feet long.

• Lighter Weight

  Over 10% lighter weight and increased hose flexibility improves under pressure

• Highest Safety Standards

  Conductive core meets the highest worldwide safety standards unlike competitive ground wire hose designs

• Minimal Hose Coil Memory

  BlueMax II Hose has superior flexibility and reduced coil memory providing ease of use during coiling and uncoiling

• Model: BlueMax II
• Series: Whip Hose

• For Use With: Graco spray guns and airless paint hose

• Hose Diameter (in): 3/16
• Hose Length (cm): 91
• Hose Length (ft): 3
• Hose Length (in): 36
• Hose Length (m): 0.9
• Hose Length (mm): 912

• Inside Diameter (cm): 0.476
• Inside Diameter (in): 3/16
• Inside Diameter (mm): 4.76

• Maximum Working Pressure (bar): 231
• Maximum Working Pressure (kPa): 2310
• Maximum Working Pressure (psi): 3300

GG 238359

Hose, Coupled, 3/16in X 6ft

Graco 238359 BlueMax II Airless Whip Hose, 3/16 in x 6 ft (1.8 m)

The BlueMax II Whip Hose provides more flexibility and increased operator control at the gun. This BlueMax II Whip Hose has a 3/16 inch diameter and is 6 feet long.

• Lighter Weight

  Over 10% lighter weight and increased hose flexibility improves under pressure

• Highest Safety Standards

  Conductive core meets the highest worldwide safety standards unlike competitive ground wire hose designs

• Minimal Hose Coil Memory

  BlueMax II Hose has superior flexibility and reduced coil memory providing ease of use during coiling and uncoiling

• Model: BlueMax II
• Series: Whip Hose

• Hose Diameter (in): 3/16
• Hose Length (cm): 183
• Hose Length (ft): 6
• Hose Length (in): 72
• Hose Length (m): 1.8
• Hose Length (mm): 1824

• Maximum Working Pressure (bar): 231
• Maximum Working Pressure (kPa): 2310
• Maximum Working Pressure (psi): 3300

GG 238377

ROADLAZER GUN, SPRAY, PAINT

Graco 238377 Single Acting Paint Spray Gun for RoadLazer RoadPak

• Model: RoadLazer
• Series: RoadPak

• Compatible Material: Road-Marking Paint
• Compatible Spray Guard: RAC

• For Use With: RoadLazer RoadPak Line Striping System

• Gun Type: Single-Acting Gun

• Maximum Working Pressure (bar): 206.84
• Maximum Working Pressure (kg/cm 2): 210.92
• Maximum Working Pressure (kPa): 21000
• Maximum Working Pressure (psi): 3000

GG 238431

GG 238433

GG 238436

GG 237795

CHECK-MATE 800 PUMP, SHOVEL, 8CM HOTMELT, 55GL

Graco 237795 55 gal (200 liter) Hot Melt Pump with 8 cm Shovel

• Model: Check-Mate

• Application: Bonding, Sealing, Gasketing, Potting, Encapsulation, Molding, Spray, Fluid Transfer, Unloading, Underfill

• Extended Rod Height (in): 31.25

• Fluid Outlet Size (in): 1
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT

• Maximum Flow Rate (GPM): 3

• Maximum Operating Temperature ( degree F): 400

• Maximum Working Pressure (psi): 5850

GG 237907

KIT,REPAIR,LOWER CHECK

KIT INCLUDES: VALVE, INTAKE [QTY. 1], GLAND, PACKING MALE [QTY. 1], NUT, SEAL [QTY. 1], PACKING, U-CUP [QTY. 1], WASHER, RETAINER [QTY. 1], RING, RETAINER [QTY. 1], SEAT, VALVE [QTY. 1], PACKING, O-RING [QTY. 1], LUBRICANT, TUBE, 1 OZ [QTY. 1], PACKING, VEE [QTY. 4 ], GLAND, PACKING FEMALE [QTY. 1]

GG 238618

METER, ELECTRONIC, PULSE

Graco 238618 In-Line Meter with Pulse Output (Pints, Quarts, Gallons, Liters)

Accurately measure dispenses of petroleum- and synthetic-based oils (motor, gear and ATF.)

• Provide pulse signal output.
• Measures in pints, quarts, or gallons.

• Inlet Size (cm): 1.27
• Inlet Size (in): 0.5
• Inlet Size (mm): 12.7

• Inlet Thread Type: NPT

• Maximum Flow Rate (GPM): 12
• Maximum Flow Rate (L/min): 45.6

• Maximum Working Pressure (bar): 103
• Maximum Working Pressure (kPa): 10300
• Maximum Working Pressure (MPa): 10.3
• Maximum Working Pressure (psi): 1500

GG 238635

GG 238708

GG 238286

GG 238751

GG 238782

GG 238866

CART, DRAIN, ROLL AROUND

Graco 238866 25 gal (95 l) Used-Oil Receiver with Used-Filter Tray, Tool Holders, Sight Gauge

Oil King is designed with the busy shop in mind. With oversized tires and push-pull handles it allows for smooth maneuvering. The large funnel can collect fluids from both a drain plug and a filter port at the same time.

• Large Offset Collection Pan - This funnel can be raised to a maximum height of 72 in. (183 cm) and is equipped with a filter screen to prevent debris from entering the tank.
• Filter Drain Tray - Used filters are able to drain separately from the collection pan.
• Convenient Tool Tray - Built-in holding bins for new or used filters, wrenches, and rags all at your fingertips.
• Large 25 Gallon (94.6L) Capacity Receiver - Made from a heavy-duty, durable UV stabilized polymer. Dent-, rust-, and corrosion-resistant.
• Oversized Tires - Easily maneuver over hose and rough floors.
• Two Evacuation Port Options - Choose from the gravity drain valve at the bottom or suction-evacuation from the top.

• Color: Black

• Compatible Fluid: Oil

• Fluid Inlet Size (cm): 7.62
• Fluid Inlet Size (in): 3
• Fluid Inlet Size (mm): 76.2

• Fluid Outlet Size (cm): 1.905
• Fluid Outlet Size (in): 3/4
• Fluid Outlet Size (mm): 19.05
• Fluid Outlet Thread Type: NPT

• Overall Height (cm): 175.26
• Overall Height (ft): 5.75
• Overall Height (in): 69
• Overall Height (m): 1.75
• Overall Height (mm): 1752.6
• Overall Width (cm): 60.96
• Overall Width (ft): 2
• Overall Width (in): 24
• Overall Width (m): 0.61
• Overall Width (mm): 609.6

GG 238892

REGULATOR, PRESSURE, FLUID

Graco 238892 Corrosion Resistant High Fluid Pressure Regulator, 3000-5000 psi Range, 1.0 gpm, SST, Spring, 3/8(f) x 3/8(f), 1/4(f) Port, with gauge

• Stainless steel wetted materials are compatible with catalyst and waterborne materials
• Tungsten and carbide materials ensure low wear and long life
• Valve cartridge for quick cleaning and replacement - reduce downtime

• Actuation Type: Spring

• Gauge Port Size (cm): 0.635
• Gauge Port Size (in): 1/4
• Gauge Port Size (mm): 6.35

• Gauge Port Type: NPT

• Includes: Gauge
• Inlet Size (cm): 0.9525
• Inlet Size (in): 3/8
• Inlet Size (mm): 9.525

• Inlet Thread Type: NPT

• Maximum Flow Rate (GPM): 1
• Maximum Flow Rate (L/min): 3.8

• Maximum Regulated Pressure (bar): 345
• Maximum Regulated Pressure (kPa): 34500
• Maximum Regulated Pressure (MPa): 34
• Maximum Regulated Pressure (psi): 5000

• Maximum Viscosity (cP): 15000

• Maximum Working Pressure (bar): 414
• Maximum Working Pressure (kPa): 41400
• Maximum Working Pressure (MPa): 41
• Maximum Working Pressure (psi): 6000

• Minimum Regulated Pressure (bar): 207
• Minimum Regulated Pressure (kPa): 20700
• Minimum Regulated Pressure (MPa): 21
• Minimum Regulated Pressure (psi): 3000

• Outlet Size (cm): 0.9525
• Outlet Size (in): 3/8
• Outlet Size (mm): 9.525

GG 238893

REGULATOR, PRESSURE, FLUID

Graco 238893 High Fluid Pressure Regulator, Corrosion Resistant, 6000 Max psi, 500-4000 psi Range, 1.0 gpm, SST, Air, 3/8(f) x 3/8(f), 1/4(f) Port

• Stainless steel wetted materials are compatible with catalyst and waterborne materials
• Tungsten and carbide materials ensure low wear and long life
• Valve cartridge for quick cleaning and replacement - reduce downtime

• Actuation Type: Air

• Gauge Port Size (cm): 0.635
• Gauge Port Size (in): 1/4
• Gauge Port Size (mm): 6.35

• Gauge Port Type: NPT

• Includes: Gauge
• Inlet Size (cm): 0.9525
• Inlet Size (in): 3/8
• Inlet Size (mm): 9.525

• Inlet Thread Type: NPT

• Maximum Flow Rate (GPM): 1
• Maximum Flow Rate (L/min): 3.8

• Maximum Regulated Pressure (bar): 276
• Maximum Regulated Pressure (kPa): 27600
• Maximum Regulated Pressure (MPa): 28
• Maximum Regulated Pressure (psi): 4000

• Maximum Viscosity (cP): 15000

• Maximum Working Pressure (bar): 414
• Maximum Working Pressure (kPa): 41400
• Maximum Working Pressure (MPa): 41
• Maximum Working Pressure (psi): 6000

• Minimum Regulated Pressure (bar): 34
• Minimum Regulated Pressure (kPa): 3400
• Minimum Regulated Pressure (MPa): 3.4
• Minimum Regulated Pressure (psi): 500

• Outlet Size (cm): 0.9525
• Outlet Size (in): 3/8
• Outlet Size (mm): 9.525

GG 238894

REGULATOR, PRESSURE, FLUID

Graco 238894 Corrosion Resistant High Fluid Pressure Regulator, 500-4000 psi Range, 1.0 gpm, SST, Air, 3/8(f) x 3/8(f), 1/4(f) Port, with gauge

• Stainless steel wetted materials are compatible with catalyst and waterborne materials
• Tungsten and carbide materials ensure low wear and long life
• Valve cartridge for quick cleaning and replacement - reduce downtime

• Actuation Type: Air

• Gauge Port Size (cm): 0.635
• Gauge Port Size (in): 1/4
• Gauge Port Size (mm): 6.35

• Gauge Port Type: NPT

• Includes: Gauge
• Inlet Size (cm): 0.9525
• Inlet Size (in): 3/8
• Inlet Size (mm): 9.525

• Inlet Thread Type: NPT

• Maximum Flow Rate (GPM): 1
• Maximum Flow Rate (L/min): 3.8

• Maximum Regulated Pressure (bar): 276
• Maximum Regulated Pressure (kPa): 27600
• Maximum Regulated Pressure (MPa): 28
• Maximum Regulated Pressure (psi): 4000

• Maximum Viscosity (cP): 15000

• Maximum Working Pressure (bar): 414
• Maximum Working Pressure (kPa): 41400
• Maximum Working Pressure (MPa): 41
• Maximum Working Pressure (psi): 6000

• Minimum Regulated Pressure (bar): 34
• Minimum Regulated Pressure (kPa): 3400
• Minimum Regulated Pressure (MPa): 3.4
• Minimum Regulated Pressure (psi): 500

• Outlet Size (cm): 0.9525
• Outlet Size (in): 3/8
• Outlet Size (mm): 9.525

GG 238909

GG 238926

VALVE, BACK PRESSURE

Graco 238926 High Pressure Fluid Back Pressure Regulator, 3000 Max psi, SST, Spring Type, 1/4(f) x 1/4(f) inlet/outlet, gauge not included

• Tungsten and carbide materials ensure low wear and long life
• Plated carbon steel housing is compatible with solvent-borne materials
• Laser-marked indication lines for easy pressure adjustment and process control

• Compatible Material: Solvent borne

• Gauge Port Size (cm): 0.635
• Gauge Port Size (in): 1/4
• Gauge Port Size (mm): 6.35

• Gauge Port Type: NPT

• Inlet Size (cm): 0.635
• Inlet Size (in): 1/4
• Inlet Size (mm): 6.35

• Inlet Thread Type: NPT

• Maximum Flow Rate (GPM): 3.5
• Maximum Flow Rate (L/min): 13.25

• Maximum Regulated Pressure (bar): 207
• Maximum Regulated Pressure (kPa): 20700
• Maximum Regulated Pressure (psi): 3000

• Maximum Viscosity (cP): 500

• Maximum Working Pressure (bar): 207
• Maximum Working Pressure (kPa): 21000
• Maximum Working Pressure (psi): 3000

• Minimum Regulated Pressure (bar): 70
• Minimum Regulated Pressure (kPa): 7000
• Minimum Regulated Pressure (MPa): 7
• Minimum Regulated Pressure (psi): 1000

• Outlet Size (cm): 0.635
• Outlet Size (in): 1/4
• Outlet Size (mm): 6.35
• Outlet Thread Type: NPT

GG 238932

GG 238928

GG 238933

GG 239154

GG 239005

GG 239326

PRESIDENT PUMP, 10:1

Graco 239326 10:1 Ratio President Hydra-Clean Pump

• Reliable, low maintenance air motor

• Positive displacement, 2-ball piston design provides uniform and easily controlled delivery

• Carbon Steel Model

  Drum Length

• Model: President

• Air Inlet Size (in): 0.5
• Air Inlet Size (mm): 12.7
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Industrial

GG 238938

GG 239121

SUPPRESSOR, SURGE, HUSKY, 750

Graco 239121 Husky 750 PP Surge Suppressor with PTFE Bellows

Reduces pulsation for consistent material delivery and uniform spray pattern.

• Reduces pulsation for consistent material delivery and uniform spray pattern
• Reduces maintenance and charge pressure refills
• Flushes easily, making color changes quick and easy
• Limits the pressure change of your fluid system

• Inlet Size (cm): 0.635
• Inlet Size (in): 1/4
• Inlet Size (mm): 6.35

• Inlet Thread Type: NPT

• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Outlet Thread Type: NPT

GG 239096

SUPPRESSOR, SURGE, HUSKY, 750

Graco 239096 Husky 750 PP Surge Suppressor with BN Bladder

Reduces pulsation for consistent material delivery and uniform spray pattern.

• Reduces pulsation for consistent material delivery and uniform spray pattern
• Reduces maintenance and charge pressure refills
• Flushes easily, making color changes quick and easy
• Limits the pressure change of your fluid system

• Inlet Size (cm): 0.635
• Inlet Size (in): 1/4
• Inlet Size (mm): 6.35

• Inlet Thread Type: NPT

• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Outlet Thread Type: NPT

GG 239639

GG 238986

SUPPRESSOR, SURGE, 2" NPT

Graco 238986 High Volume Surge Tank, stainless steel, inlet/outlet: 2 npt(f)

Reduces pulsation for consistent material delivery and uniform spray pattern. Ideal for large, high flow rate systems.

• Stainless steel and PTFE materials are compatible with a variety of finishing materials
• In-line flow configuration is easy to flush, making color changes quick and easy
• Multiple fluid connection options accommodate global system requirements

• Inlet Size (cm): 5.08
• Inlet Size (in): 2
• Inlet Size (mm): 50.8

• Inlet Thread Type: NPT

• Maximum Flow Rate (GPM): 20
• Maximum Flow Rate (L/min): 76

• Maximum Fluid Pressure (bar): 21
• Maximum Fluid Pressure (kPa): 2100
• Maximum Fluid Pressure (MPa): 2.1
• Maximum Fluid Pressure (psi): 300

• Maximum Fluid Pressure (bar): 21
• Maximum Fluid Pressure (kPa): 2100
• Maximum Fluid Pressure (MPa): 2.1
• Maximum Fluid Pressure (psi): 300

• Outlet Size (cm): 5.08
• Outlet Size (in): 2
• Outlet Size (mm): 50.8
• Outlet Thread Type: NPT

GG 239320

GG 239328

KIT, REPAIR, 46:1 PRES, SST

Graco 239328 PTFE and Leather Conversion Kit- for 46:1 President Pump

GG 239000

GG 239007

GG 239092

SUPPRESSOR, SURGE, HUSKY, 2000

Graco 239092 Husky 2000 PP Surge Suppressor with BN Bladder

Reduces pulsation for consistent material delivery and uniform spray pattern

• Reduces pulsation for consistent material delivery and uniform spray pattern
• Reduces maintenance and charge pressure refills
• Flushes easily, making color changes quick and easy
• Limits the pressure change of your fluid system

• Inlet Size (cm): 0.635
• Inlet Size (in): 1/4
• Inlet Size (mm): 6.35

• Inlet Thread Type: NPT

• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Outlet Thread Type: NPT

GG 238959

HOSE, CPLD, 3/16" X 4.5', H.P.

Graco 238959 BlueMax II Airless Whip Hose, 3/16 in x 4.5 ft (1.4 m)

The BlueMax II Whip Hose provides more flexibility and increased operator control at the gun. This BlueMax II Whip Hose has a 3/16 inch diameter and is 4.5 feet long.

• Lighter Weight

  Over 10% lighter weight and increased hose flexibility improves under pressure

• Highest Safety Standards

  Conductive core meets the highest worldwide safety standards unlike competitive ground wire hose designs

• Minimal Hose Coil Memory

  BlueMax II Hose has superior flexibility and reduced coil memory providing ease of use during coiling and uncoiling

• Model: BlueMax II
• Series: Whip Hose

• Connection Type: Male x Female

• Hose Diameter (in): 3/16
• Hose Length (cm): 137
• Hose Length (ft): 4.5
• Hose Length (in): 54
• Hose Length (m): 1.4
• Hose Length (mm): 1368

• Inside Diameter (cm): 0.4763
• Inside Diameter (in): 3/16
• Inside Diameter (mm): 4.7625

• Material: Nylon

• Maximum Working Pressure (bar): 207
• Maximum Working Pressure (kPa): 20700
• Maximum Working Pressure (MPa): 20.7
• Maximum Working Pressure (psi): 3300

GG 239634

HOSE, FLUID,3/16 I.D.

Graco 239634 25 ft Fluid Hose Assembly (3/16 in)

• Bleed Type: Non-Bleeder

• Compatible Material: CARC, Enamel, Epoxies, Fast-Set, High Solids, Latex, Plural Component Materials, Sealants, Solventborne, Urethane, Waterborne

GG 239394

FILTER, SWIVEL

Graco 239394 Filter/ Swivel for Cart Mounted Air Assisted Gun Package, includes replacement element filter, 100 mesh sst

• Provides free movement of hose sections and guns without kinking.

• Swivels maintain a high pressure seal while providing fully rotational movement between hoses, guns, siphon tubes and other equipment.

GG 239128

SUPPRESSOR, SURGE, HUSKY, 2000

Graco 239128 Husky 2000 PP Surge Suppressor with PTFE Bellows

Reduces pulsation for consistent material delivery and uniform spray pattern.

• Reduces pulsation for consistent material delivery and uniform spray pattern
• Reduces maintenance and charge pressure refills
• Flushes easily, making color changes quick and easy
• Limits the pressure change of your fluid system

• Inlet Size (cm): 0.635
• Inlet Size (in): 1/4
• Inlet Size (mm): 6.35

• Inlet Thread Type: NPT

• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Outlet Thread Type: NPT

GG 239060

GG 239637

GG 239663

GG 239126

SUPPRESSOR, SURGE, HUSKY, 2000

Graco 239126 Husky 2000 Automatic SS Surge Suppressor with BN Bladder

Reduces pulsation for consistent material delivery and uniform spray pattern.

• Reduces pulsation for consistent material delivery and uniform spray pattern
• Reduces maintenance and charge pressure refills
• Flushes easily, making color changes quick and easy
• Limits the pressure change of your fluid system

• Inlet Size (cm): 0.635
• Inlet Size (in): 1/4
• Inlet Size (mm): 6.35

• Inlet Thread Type: NPT

• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Maximum Fluid Pressure (bar): 8
• Maximum Fluid Pressure (kPa): 800
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120

• Outlet Thread Type: NPT

GG 239734

GG 239781

AIR CAP

Graco 239781 Model AA Plus Spray Gun Air Cap, included with Gun 238402, 238852 and 238883 only

GG 239730

FIREBALL 425 PUMP, 75:1, 400 LB

Graco 239730 Fire-Ball 425 Series 75:1 350-400 lb (160-180 kg). Container Bare Grease Pump

The Fire-Ball 425 features a large air motor to supply the power you need for long pipe runs and higher-volume dispensing. An ideal choice for applications where multiple dispenses happen at the same time.

• Durable - Thick cast aluminum air motor housing offers unmatched durability.
• Fewer Repairs - Fewer moving parts in the air motor assembly means less downtime and low repair cost.
• Superior Sealing - Non-metallic poppet valves offer positive sealing performance, even with contaminated dirtyair environments for long life without repair.
• Corrosion-Resistant - Corrosion-resistant design utilizes liquid salt nitriding, nickel plating, stainless steel, aluminum and chrome on key components for longer life.

• Model: Fire-Ball
• Series: 425

• Air Inlet Size (in): 0.5
• Air Inlet Size (mm): 12.7
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT
• Air Motor Effective Diameter (in): 4.25

• Application: Industrial

• Compatible Material: Grease

• Cycles Per Gallon: 165

• Fluid Inlet Type: Slotted

• Fluid Outlet Size (in): 3/8
• Fluid Outlet Size (mm): 9.525
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT

• For Use With: Grease

• Maximum Air Inlet Pressure (bar): 6.9
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Continuous Cycle Rate (CPM): 60

• Maximum Flow Rate (GPM): 0.33
• Maximum Flow Rate (L/min): 1.25

• Maximum Intermittent Cycle Rate (CPM): 60

• Maximum Working Pressure (bar): 517
• Maximum Working Pressure (kPa): 51700
• Maximum Working Pressure (MPa): 51.7
• Maximum Working Pressure (psi): 7500

• Power Type: Pneumatic

• Pump Ratio: 75:1

GG 239794

GG 239789

KIT, REPAIR, REGULATOR

Graco 239789 Stainless Steel Waterbase Compatible Fluid Pressure Regulator

• Color: Grey

GG 239800

FILTER, FLUID

Graco 239800 Fluid Outlet Fliter, Stainless Steel Bowl, Polyethylene Support, 1/4 npt, 5000 psi (35 Mpa, 350 bar)

GG 239862

GG 239866

KIT, REPAIR,THROAT,PTFE

Graco 239866 PTFE High-Flo Throat Packing Kit

GG 239883

GG 239877

FIREBALL 300 PUMP, 50:1, 35 LB

Graco 239877 Fire-Ball 300 Series 50:1 35 or 70 lb (16 or 32 kg). Pail Grease Pump

As the mainstay pump in the industry for decades, the reputation of Fire-Ball is unrivaled. Built to withstand the test of time with fewer moving parts, our flagship pump is built to extend uptime so customers can be more productive. The durable pumps are renowned for their durability, with pumps built decades ago still operating efficiently.

• Reliable Flow - A 3 inch (76.2 mm) differential air motor and the double-acting pump design provides reliable fluid flow and accurate dispense.
• Durable - Thick cast aluminum air motor housing offers unmatched durability.
• Fewer Repairs - Fewer moving parts in the air motor assembly means less downtime and low repair cost.
• Reduce Downtime - Displacement rods have minimal wear due to a proprietary Graco manufacturing process.
• Superior Sealing - Non-metallic poppet valves offer positive sealing performance, even with contaminated dirtyair environments for long life without repair.
• Reduced Icing - Large air porting design provides efficient use of compressed air supply for continuous pump operation and reduced icing.
• Corrosion-Resistant - Corrosion-resistant design utilizes liquid salt nitriding, nickel plating, stainless steel, aluminum and chrome on key components for longer life.

• Model: Fire-Ball
• Series: 300

• Air Inlet Size (in): 3/8
• Air Inlet Size (mm): 9.525
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT
• Air Motor Effective Diameter (in): 3

• Application: Industrial

• Compatible Material: Grease

• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT
• Fluid Inlet Type: Slotted

• Fluid Outlet Size (in): 1/4
• Fluid Outlet Size (mm): 6.35
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT

• For Use With: Grease

• Maximum Air Consumption (SCFM): 22.8
• Maximum Air Inlet Pressure (bar): 9.65
• Maximum Air Inlet Pressure (kPa): 965
• Maximum Air Inlet Pressure (psi): 140

• Maximum Continuous Cycle Rate (CPM): 76

• Maximum Intermittent Cycle Rate (CPM): 76

• Maximum Working Pressure (bar): 580
• Maximum Working Pressure (kPa): 58000
• Maximum Working Pressure (MPa): 58
• Maximum Working Pressure (psi): 8400

• Power Type: Pneumatic

• Pump Ratio: 50:1

GG 239888

FIREBALL 300 PUMP, 50:1, 400 LB

Graco 239888 Fire-Ball 300 Series 50:1 400 lb (180 kg). Grease Pump

As the mainstay pump in the industry for decades, the reputation of Fire-Ball is unrivaled. Built to withstand the test of time with fewer moving parts, our flagship pump is built to extend uptime so customers can be more productive. The durable pumps are renowned for their durability, with pumps built decades ago still operating efficiently.

• Reliable Flow - A 3 inch (76.2 mm) differential air motor and the double-acting pump design provides reliable fluid flow and accurate dispense.
• Durable - Thick cast aluminum air motor housing offers unmatched durability.
• Fewer Repairs - Fewer moving parts in the air motor assembly means less downtime and low repair cost.
• Reduce Downtime - Displacement rods have minimal wear due to a proprietary Graco manufacturing process.
• Superior Sealing - Non-metallic poppet valves offer positive sealing performance, even with contaminated dirtyair environments for long life without repair.
• Reduced Icing - Large air porting design provides efficient use of compressed air supply for continuous pump operation and reduced icing.
• Corrosion-Resistant - Corrosion-resistant design utilizes liquid salt nitriding, nickel plating, stainless steel, aluminum and chrome on key components for longer life.

• Model: Fire-Ball
• Series: 300

• Air Inlet Size (in): 3/8
• Air Inlet Size (mm): 9.525
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT
• Air Motor Effective Diameter (in): 3

• Application: Industrial

• Compatible Material: Grease

• Cycles Per Gallon: 345

• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT
• Fluid Inlet Type: Slotted

• Fluid Outlet Size (in): 1/4
• Fluid Outlet Size (mm): 6.35
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT

• For Use With: Grease

• Maximum Air Consumption (SCFM): 22.8
• Maximum Air Inlet Pressure (bar): 9.65
• Maximum Air Inlet Pressure (kPa): 965
• Maximum Air Inlet Pressure (psi): 140

• Maximum Continuous Cycle Rate (CPM): 76

• Maximum Intermittent Cycle Rate (CPM): 76

• Maximum Working Pressure (bar): 580
• Maximum Working Pressure (kPa): 58000
• Maximum Working Pressure (MPa): 58
• Maximum Working Pressure (psi): 8400

• Power Type: Pneumatic

• Pump Ratio: 50:1

GG 239887

FIREBALL 300 PUMP, 50:1, 120 LB

Graco 239887 Fire-Ball 300 Series 50:1 120 lb (55 kg). Pail Grease Pump

As the mainstay pump in the industry for decades, the reputation of Fire-Ball is unrivaled. Built to withstand the test of time with fewer moving parts, our flagship pump is built to extend uptime so customers can be more productive. The durable pumps are renowned for their durability, with pumps built decades ago still operating efficiently.

• Reliable Flow - A 3 inch (76.2 mm) differential air motor and the double-acting pump design provides reliable fluid flow and accurate dispense.
• Durable - Thick cast aluminum air motor housing offers unmatched durability.
• Fewer Repairs - Fewer moving parts in the air motor assembly means less downtime and low repair cost.
• Reduce Downtime - Displacement rods have minimal wear due to a proprietary Graco manufacturing process.
• Superior Sealing - Non-metallic poppet valves offer positive sealing performance, even with contaminated dirtyair environments for long life without repair.
• Reduced Icing - Large air porting design provides efficient use of compressed air supply for continuous pump operation and reduced icing.
• Corrosion-Resistant - Corrosion-resistant design utilizes liquid salt nitriding, nickel plating, stainless steel, aluminum and chrome on key components for longer life.

• Model: Fire-Ball
• Series: 300

• Air Inlet Size (in): 3/8
• Air Inlet Size (mm): 9.525
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT
• Air Motor Effective Diameter (in): 3

• Application: Industrial

• Compatible Material: Grease

• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT
• Fluid Inlet Type: Slotted

• Fluid Outlet Size (in): 1/4
• Fluid Outlet Size (mm): 6.35
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT

• For Use With: Grease

• Maximum Air Consumption (SCFM): 22.8
• Maximum Air Inlet Pressure (bar): 9.65
• Maximum Air Inlet Pressure (kPa): 965
• Maximum Air Inlet Pressure (psi): 140

• Maximum Continuous Cycle Rate (CPM): 76

• Maximum Intermittent Cycle Rate (CPM): 76

• Maximum Working Pressure (bar): 580
• Maximum Working Pressure (kPa): 58000
• Maximum Working Pressure (MPa): 58
• Maximum Working Pressure (psi): 8400

• Power Type: Pneumatic

• Pump Ratio: 50:1

GG 239895

GG 239896

KIT, FLUID,REPAIR,AIRLESS

Graco 239896 Fluid Seal Repair Kit- for Airless Gun

• Bleed Type: Non-Bleeder
• Body Material: Metal

• Compatible Material: Epoxies, High Solids, Latex, Plural Component Materials, Sealants, Solventborne, Urethane, Waterborne

GG 239914

KIT, REPL, VALVE, DRAIN

Graco 239914 Replacement Drain Valve Kit

Replace your sprayers paint covered or worn out drain valve. Refer to the parts manual for your sprayer to ensure part compatibility

• For Use With: Pro210ES

GG 239937

GG 239945

GG 239951

GG 239718

GEAR, ASSEMBLY

Graco 239718 Gear Assembly

GG 240055

FRAME, ROLLER, 12"

Graco 240055 Geosperse Pressure Roller Frame, 12 in

Genuine Graco Geosperse Pressure Roller Frame. Refer to the parts manual for your sprayer to ensure part compatibility

• Graco Tech Support can further assist with troubleshooting sprayer operation

• Model: Graco

• Maximum Pole Length (in): 12

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (MPa): 34.5
• Maximum Working Pressure (psi): 5000

GG 239719

BODY, GEARMETER

Graco 239719 Gear Meter Assembly

GG 240183

FILTER, FLUID

Graco 240183 Fluid Outlet Filter, Series A, Stainless Steel Bowl, Polyethylene Support, 3/8 npt, 5000 psi

GG 240197

GG 240198

GG 240199

ULTRA-LITE IN-LINE GUN

Graco 240199 Palm Grip In-Line Dispense Gun

• Handles:

  PVC sealers with glass or plastic filler

  Low to high abrasive fluids

  Waterborne or Solvent borne materials

  Most fluids up to 150,000 centipoise

  • Well-suited for dispensing onto horizontal surfaces
  • Selectable trigger lock and hanger slot for operator convenience
  • Lowest trigger force and weight in its class




  • Model: Ultra-Lite
  • Application: Bonding, Sealing, Gasketing, Potting, Encapsulation
  • Connection Type: Threaded, Flange
  • Gun Activation: Manual
  • Inlet Size (in): 1/4
  • Inlet Thread Gender: Female
  • Inlet Thread Type: NPT
  • Maximum Working Pressure (bar): 234
  • Maximum Working Pressure (kg/cm 2): 239
  • Maximum Working Pressure (kPa): 23400
  • Maximum Working Pressure (MPa): 23.4
  • Maximum Working Pressure (psi): 3400
  • Nozzle Size (cm): 0.635
  • Nozzle Size (in): 0.25
  • Number of Outputs: 1

GG 240201

NEEDLE, 3/16 BALL

GG 240206

KIT, REPAIR

Graco 240206 Ultra-Lite Repair Kit for Ball End Gun- Includes Carbide Seat, Ball Needle, O-Ring and Seal

KIT INCLUDES: NEEDLE, 3/16 BALL [QTY. 1], SEAT, 3/16 BALL [QTY. 1], GASKET, COPPER [QTY. 1]

GG 240209

AGITATOR, SST with Siphon Kit

Graco 240209 Heavy Duty Back-Geared Drum Agitator with Siphon Kit, air driven, 1/2 HP, 32 inches (81.25 cm) tall. Drum Cover (238283) not included.

• Drum cover is not included, but can be ordered separately as part number 238283
• Leak-free and oil-less gearbox prevents material contamination
• Stainless steel agitator is corrosion resistant and waterborne compatible
• Siphon option allows material transfer through agitator shaft

• Air Inlet Size (cm): 0.635
• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35
• Air Inlet Thread Type: NPT

• For Use With: 55 Gallon (208 Liter) Drum

• Maximum Air Inlet Pressure (bar): 7
• Maximum Air Inlet Pressure (kPa): 700
• Maximum Air Inlet Pressure (psi): 100

• Maximum Speed (RPM): 1200

• Maximum Viscosity (cP): 3000

• Maximum Working Pressure (bar): 7
• Maximum Working Pressure (kPa): 700
• Maximum Working Pressure (psi): 100

• Motor Type: Pneumatic - Rotary Vane

• Power Rating (HP): 0.25

GG 240222

GG 240231

GG 239872

KIT, REPAIR, THROAT, UHMWPE/LEAT

Graco 239872 UHMWPE/Leather Throat Packing Kit for Pumps with 750 cc Lowers

GG 240265

GG 240273

GG 240417

GG 240418

GG 19Y486

GG 19Y496

GG 19Y499

GG 19Y509

KIT, MUFFLER, RADIAL PISTON AIR

Graco 19Y509 Radial Piston Air Motor Muffler kit, set of 3

GG 19Y592

KIT, RETRO, 5-10 GA PAIL, RP MTR

Graco 19Y592 Radial Piston Air Motor Retrofit Kit for 5 gallon (18 L) or 10 gallon (38 L) pail agitators. Pail cover, agitator shaft and blade not included.

This kit makes it easy to replace an existing rotary vane motor on a 5 gallon (18 liter) or 10 gallon (38 L) pail agitator with a radial piston air motor.

Application: For wood (top coat, primer) and general finishing applications

• Radial piston air motor driven agitators are reliable, simple and cost-effective solutions for low to medium speed (<500 rpm), low to medium viscosity (<1000 cp) agitation applications.
• Air line lubrication not required
• Easy to maintain and service
• Pail cover, agitator shaft and blade sold separately

• Air Inlet Size (cm): 0.635
• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35
• Air Inlet Thread Type: NPT

• Maximum Air Inlet Pressure (bar): 5
• Maximum Air Inlet Pressure (kPa): 500
• Maximum Air Inlet Pressure (psi): 70

• Maximum Speed (RPM): 150

• Maximum Working Pressure (bar): 5
• Maximum Working Pressure (kPa): 500
• Maximum Working Pressure (psi): 70

• Motor Type: Pneumatic - Radial Piston

GG 19Z001

SOLOTECH ST10 PUMP, I10-MPM-NR-SS-A1-A1-0

Graco 19Z001 SoloTech i10 Natural Rubber Peristaltic Hose Pump with Natural Rubber Hose, 316 Stainless Steel Barb & BLDC Motor

Graco's SoloTech 10 Hose pump design utilizes a single roller that compresses an engineered hose through a full 360 degrees of rotation. This innovative design means longer hose life when pumping caustic, abrasive or sensitive materials for metering or transfer.

• More flow per revolution than conventional designs
• Inexpensive to maintain - no valves, seals or glands
• Pumps are reversible and can be used to empty lines or clear blockages

• Model: SoloTech
• Series: i10

• Application: Industrial

• Barb Material: Stainless Steel

• Flow Rate (GPM): 0.67

• Gear Ratio: 37.66:1

• Hose Diameter (cm): 1
• Hose Diameter (in): 0.4
• Hose Diameter (mm): 10
• Hose Material: Rubber

• Housing Material: Powder Coated Aluminum
• Inlet Size (cm): 0.95
• Inlet Size (in): 3/8
• Inlet Size (mm): 9.5

• Inlet Thread Type: Flange

• Maximum Flow Rate (GPM): 0.67
• Maximum Flow Rate (L/min): 2.5

• Maximum Fluid Pressure (bar): 9
• Maximum Fluid Pressure (kPa): 900
• Maximum Fluid Pressure (psi): 125

• Maximum Fluid Pressure (bar): 9
• Maximum Fluid Pressure (kPa): 900
• Maximum Fluid Pressure (psi): 125

• Maximum Storage Temperature ( degree C): 40
• Maximum Storage Temperature ( degree F): 104

• Minimum Flow Rate (GPM): 0.017

• Minimum Storage Temperature ( degree C): -10
• Minimum Storage Temperature ( degree F): 14

• Motor Type: Brushless DC

• Outlet Size (cm): 9
• Outlet Size (in): 3.54
• Outlet Size (mm): 90

• Overall Height (cm): 53
• Overall Height (in): 21
• Overall Height (mm): 533
• Overall Length (cm): 41
• Overall Length (in): 16.3
• Overall Length (mm): 414
• Overall Width (cm): 33
• Overall Width (in): 13
• Overall Width (mm): 330

• Power Rating (HP): 120
• Power Rating (kW): 89.48
• Power Rating (W): 89484

• Pump Speed (RPM): 2-93

GG 19Z012

SOLOTECH ST10 PUMP, I10-LAC-CS-HS-A1-A1-0

Graco 19Z012 SoloTech i10 Low Speed Hypalon Peristaltic Hose Pump with CSM Hose, Hastelloy-C Barb & AC Motor

Graco's SoloTech 10 Hose pump design utilizes a single roller that compresses an engineered hose through a full 360 degrees of rotation. This innovative design means longer hose life when pumping caustic, abrasive or sensitive materials for metering or transfer.

• More flow per revolution than conventional designs
• Inexpensive to maintain - no valves, seals or glands
• Pumps are reversible and can be used to empty lines or clear blockages

• Model: SoloTech
• Series: i10

• Application: Industrial

• Barb Material: Hastelloy

• Flow Rate (GPM): 0.08

• Gear Ratio: 157.43:1

• Hose Diameter (cm): 1
• Hose Diameter (in): 0.4
• Hose Diameter (mm): 10
• Hose Material: CSM

• Housing Material: Powder Coated Aluminum
• Inlet Size (cm): 0.95
• Inlet Size (in): 3/8
• Inlet Size (mm): 9.5

• Inlet Thread Type: Flange

• Maximum Flow Rate (GPM): 0.67
• Maximum Flow Rate (L/min): 2.5

• Maximum Fluid Pressure (bar): 9
• Maximum Fluid Pressure (kPa): 900
• Maximum Fluid Pressure (psi): 125

• Maximum Fluid Pressure (bar): 9
• Maximum Fluid Pressure (kPa): 900
• Maximum Fluid Pressure (psi): 125

• Maximum Storage Temperature ( degree C): 40
• Maximum Storage Temperature ( degree F): 104

• Minimum Flow Rate (GPM): 0.013

• Minimum Storage Temperature ( degree C): -10
• Minimum Storage Temperature ( degree F): 14

• Motor Type: Low Speed AC

• Outlet Size (cm): 9
• Outlet Size (in): 3.54
• Outlet Size (mm): 90

• Overall Height (cm): 42
• Overall Height (in): 16.7
• Overall Height (mm): 424
• Overall Length (cm): 41
• Overall Length (in): 16.2
• Overall Length (mm): 411
• Overall Width (cm): 33
• Overall Width (in): 13
• Overall Width (mm): 330

• Pump Speed (RPM): 2-11
