GRACO INC. S10595

GG 26D601

GG 26D603

GG 26D604

GG 26D609

GG 26D767

GG 272010

REACTOR 2 E-30 PROPORTIONER, 10KW

Graco 272010 Reactor 2 E-30 Proportioner, 10 kW

Each feature in the Reactor 2 was strategically designed to help your business, with innovations that help your operation run smoothly. Software and hardware enhancements for better spray performance. And new technologies that add to your bottom line.

• Reactor 2 E-30 gives you:

  Compact footprint - more room in your spray rig

  Ergonomic design - easier to service

  Advanced control modules

  Better spraying performance compared to traditional electric Reactor systems

  Troubleshooting made quick and easy with QR codes

• Reactor Connect : Communication and Control at your Fingertips

  Control your Reactor using your phone

  Improve productivity and yield by optimizing spray parameters and never having to go back to your rig

  Monitor your rigs/crews using the multi-system dashboard

  Troubleshoot an issue quickly using real-time data

  Provide documentation to a customer

  Use reports to better manage your business

  Saves all your spray data to the cloud

  Utilize account management to better manage your equipment and crews

  Reactor Connect comes standard with all Reactor 2 models

• Advanced control technology

  Tracks, monitors and saves project data

  Data can be saved and downloaded onto a USB drive

  Stores up to 24 chemical recipes

  Drum level indicators

• Easy to reach, conveniently-placed electronics
• Advanced control modules

  Handles power fluctuations

• Sacrificial surge protector

  Protects your electronics against excessive power spikes

• Smooth, consistent spray performance - similar to hydraulic systems
• Three-year warranty

  Covers user display module, control modules and electric motor

  One of the best in the industry

• Model: Reactor 2
• Series: E-30
• Product Series: Non-Elite

• Amperage (A): 34 @ 350 to 415 V ac (3-Phase WYE), 50 @ 200 to 240 V ac (3-Phase Delta), 78 @ 200 to 240 V ac (1-Phase)
• Application: Spray Foam
• Applicator Type: Manual

• Compatible Material: Plural Components

• Component Type: Two Component

• Flush Type: Solvent

• Frequency (Hz): 50/60

• Gun Type: No Gun

• Hose Package: No Hose

• Material Application: Polyurethane Foam

• Maximum Flow Rate (kg/min): 13.61
• Maximum Flow Rate (lb/min): 30

• Maximum Fluid Temperature ( degree C): 88
• Maximum Fluid Temperature ( degree F): 190

• Maximum Fluid Temperature ( degree C): 88
• Maximum Fluid Temperature ( degree F): 190

• Maximum Hose Length (ft): 310
• Maximum Hose Length (m): 94.5

• Maximum Mix Ratio: 1:1

• Maximum Working Pressure (bar): 138
• Maximum Working Pressure (kPa): 13800
• Maximum Working Pressure (MPa): 13.8
• Maximum Working Pressure (psi): 2000

• Overall Depth (cm): 38.1
• Overall Depth (in): 15
• Overall Depth (mm): 381

• Overall Height (cm): 160
• Overall Height (in): 63
• Overall Height (mm): 1600
• Overall Width (cm): 66.8
• Overall Width (in): 26.3
• Overall Width (mm): 668

GG 272012

REACTOR 2 E-XP2 PROPORTIONER

Graco 272012 Reactor 2 E-XP2 Proportioner

Count on the Reactor 2 E-XP2 proportioner for advanced technology in applying fast-curing polyurea coatings. Because its a Reactor 2 series proportioner, it offers software and hardware enhancements for better spray performance, plus technologies that add to your bottom line. The Reactor 2 E-XP2 is engineered to process and spray polyurea and other coatings that require high pressures. The hybrid heater and heated hose condition the materials to the right viscosity prior to mixing. Quick knockdown lower pump for easy maintenance, easy-to-use controls, and rugged design make the Reactor the preferred choice for coatings applications.

• Reactor 2 E-XP2 gives you:

  Compact footprint - more room in your spray rig

  Ergonomic design - easier to service

  Advanced control modules

  Better spraying performance compared to traditional electric Reactor systems

  Troubleshooting made quick and easy with QR codes

• Reactor Connect : Communication and Control at your Fingertips

  Control your Reactor using your phone

  Improve productivity and yield by optimizing spray parameters and never having to go back to your rig

  Monitor your rigs/crews using the multi-system dashboard

  Troubleshoot an issue quickly using real-time data

  Provide documentation to a customer

  Use reports to better manage your business

  Saves all your spray data to the cloud

  Utilize account management to better manage your equipment and crews

  Reactor Connect comes standard with all Reactor 2 models

• Advanced control technology

  Tracks, monitors and saves project data

  Data can be saved and downloaded onto a USB drive

  Stores up to 24 chemical recipes

  Drum level indicators

• Easy to reach, conveniently-placed electronics
• Advanced control modules

  Handles power fluctuations

• Sacrificial surge protector

  Protects your electronics against excessive power spikes

• Smooth, consistent spray performance - similar to hydraulic systems
• Three-year warranty

  Covers user display module, control modules and electric motor

  One of the best in the industry

• Reactor Elite models include:

  Inlet pressure and temperature sensor

  Xtreme-Wrap Scuff Guard on heated hoses for Reactor 2 packages

• Model: Reactor 2
• Series: E-XP2
• Product Series: Non-Elite

• Amperage (A): 35 @ 350 to 415 V ac (3-Phase WYE), 62 @ 200 to 240 V ac (3-Phase Delta), 100 @ 200 to 240 V ac (1-Phase)
• Application: Protective Coatings
• Applicator Type: Manual

• Compatible Material: Plural Components

• Component Type: Two Component

• Flush Type: Solvent

• Frequency (Hz): 50/60

• Gun Type: No Gun

• Hose Length (ft): 50, 10
• Hose Length (m): 15, 3

• Hose Package: No Hose

• Material Application: Polyurea

• Maximum Flow Rate (cc/min): 7570

• Maximum Flow Rate (GPM): 2
• Maximum Flow Rate (L/min): 7.57

• Maximum Fluid Temperature ( degree C): 88
• Maximum Fluid Temperature ( degree F): 190

• Maximum Fluid Temperature ( degree C): 88
• Maximum Fluid Temperature ( degree F): 190

• Maximum Hose Length (ft): 310
• Max

GG 272112

REACTOR 2 E-XP2 PROPORTIONER, ELITE

Graco 272112 Reactor 2 E-XP2 Elite Proportioner

Count on the Reactor 2 E-XP2 proportioner for advanced technology in applying fast-curing polyurea coatings. Because its a Reactor 2 series proportioner, it offers software and hardware enhancements for better spray performance, plus technologies that add to your bottom line. The Reactor 2 E-XP2 is engineered to process and spray polyurea and other coatings that require high pressures. The hybrid heater and heated hose condition the materials to the right viscosity prior to mixing. Quick knockdown lower pump for easy maintenance, easy-to-use controls, and rugged design make the Reactor the preferred choice for coatings applications.

• Reactor 2 E-XP2 gives you:

  Compact footprint - more room in your spray rig

  Ergonomic design - easier to service

  Advanced control modules

  Better spraying performance compared to traditional electric Reactor systems

  Troubleshooting made quick and easy with QR codes

• Reactor Connect : Communication and Control at your Fingertips

  Control your Reactor using your phone

  Improve productivity and yield by optimizing spray parameters and never having to go back to your rig

  Monitor your rigs/crews using the multi-system dashboard

  Troubleshoot an issue quickly using real-time data

  Provide documentation to a customer

  Use reports to better manage your business

  Saves all your spray data to the cloud

  Utilize account management to better manage your equipment and crews

  Reactor Connect comes standard with all Reactor 2 models

• Advanced control technology

  Tracks, monitors and saves project data

  Data can be saved and downloaded onto a USB drive

  Stores up to 24 chemical recipes

  Drum level indicators

• Easy to reach, conveniently-placed electronics
• Advanced control modules

  Handles power fluctuations

• Sacrificial surge protector

  Protects your electronics against excessive power spikes

• Smooth, consistent spray performance - similar to hydraulic systems
• Three-year warranty

  Covers user display module, control modules and electric motor

  One of the best in the industry

• Reactor Elite models include:

  Inlet pressure and temperature sensor

  Xtreme-Wrap Scuff Guard on heated hoses for Reactor 2 packages

• Model: Reactor 2
• Series: E-XP2
• Product Series: Elite

• Amperage (A): 35 @ 350 to 415 V ac (3-Phase WYE), 62 @ 200 to 240 V ac (3-Phase Delta), 100 @ 200 to 240 V ac (1-Phase)
• Application: Protective Coatings
• Applicator Type: Manual

• Compatible Material: Plural Components

• Component Type: Two Component

• Flush Type: Solvent

• Frequency (Hz): 50/60

• Gun Type: No Gun

• Hose Package: No Hose

• Material Application: Polyurea

• Maximum Flow Rate (cc/min): 7570

• Maximum Flow Rate (GPM): 2
• Maximum Flow Rate (L/min): 7.57

• Maximum Fluid Temperature ( degree C): 88
• Maximum Fluid Temperature ( degree F): 190

• Maximum Fluid Temperature ( degree C): 88
• Maximum Fluid Temperature ( degree F): 190

• Maximum Hose Length (ft): 310
• Maximum Hose Length (m): 94.5

• Maximum Mix Ratio: 1:1<

GG 273109

GG 273134

GG 273137

GG 273158

PM SERIES VALVE, PM8, NPT, GEAR LUBE

Graco 273158 PM 8 Electronic Preset Gear Lube Meter - Rigid Extension - 1/2 in. (13 mm) Inlet - NPT

Use Graco's PM8 and PM20 electronic preset meters to dispense fluids quickly, reliably and accurately to vehicles, trucks, yellow iron machines and more in the most challenging, extreme environments.

• Proven in Harsh Conditions - Sealed electronics (IP69K) are protected against direct pressure washing and dust.
• Twist-Close Nozzle Prevents Leaking - Multiple extensions available including rigid, flexible and gear lube.
• Long-Life Valve Design - Poppet design offers exceptional valve life for heavy usage applications.
• Durable Cast Body - Designed for heavy duty and harsh applications.
• High-Flow Rates - Capable of up to 8 gpm (30.3 lpm).
• Long Battery Life - Features four easily-replaceable AA batteries.

• Series: 8

• Calibration Type: Factory Calibrated

• Compatible Material: Petroleum-Based Oil, Synthetic-Based Oil, Antifreeze

• Dispense Type: Preset

• Display Type: Electronic

• Extension Type: Rigid

• Fluid Inlet Thread Gender: Female

• Fluid Outlet Thread Gender: Female

• Includes: Nozzle, Extension
• Inlet Size (cm): 1.27
• Inlet Size (in): 1/2
• Inlet Size (mm): 12.7

• Inlet Thread Type: NPT

• IP Rating: 69K

• Maximum Flow Rate (cc/min): 30283

• Maximum Flow Rate (cc/sec): 505
• Maximum Flow Rate (GPM): 8
• Maximum Flow Rate (L/min): 30.3

• Maximum Operating Temperature ( degree C): 52
• Maximum Operating Temperature ( degree F): 125

• Maximum Recorded Dispense: 19999

• Maximum Storage Temperature ( degree C): 85
• Maximum Storage Temperature ( degree F): 185

• Maximum Totalizer: 19999

• Maximum Working Pressure (bar): 102
• Maximum Working Pressure (kPa): 10340
• Maximum Working Pressure (MPa): 10
• Maximum Working Pressure (psi): 1500
• Meter Accuracy: plus/minus 00.5
• Meter Accuracy (%): plus/minus 00.5
• Meter Pressure Loss (bar): 4.1 Bar at 6 GPM
• Meter Pressure Loss (psi): 60 PSI at 6 GPM
• Meter Technology: Oval Gear

• Metering Gun Weight (kg): 2.4
• Metering Gun Weight (lb): 5.2

• Minimum Flow Rate (GPM): 0.25

• Minimum Operating Temperature ( degree C): -29
• Minimum Operating Temperature ( degree F): -20

• Nozzle Type: Manual

• Outlet Size (cm): 1.905
• Outlet Size (in): 3/4
• Outlet Size (mm): 19.05
• Outlet Thread Type: ORB

• Overall Height (cm): 18.3
• Overall Height (in): 7.2
• Overall Height (mm): 183
• Overall Length (cm): 57.5
• Overall Length (in): 22.6
• Overall Length (mm): 575
• Overall Width (cm): 10.4
• Overall Width (in): 4.1
• Overall Width (mm): 103.5

• Recommended Environment: Indoor/Outdoor

GG 273165

PM SERIES VALVE, PM20, 1/2in NPT, RIGID

Graco 273165 PM 20 Electronic Preset Oil Meter - Rigid Extension - 1/2 in. (13 mm) Inlet - NPT

Use Graco's PM8 and PM20 electronic preset meters to dispense fluids quickly, reliably and accurately to vehicles, trucks, yellow iron machines and more in the most challenging, extreme environments.

• Proven in Harsh Conditions - Sealed electronics (IP69K) are protected against direct pressure washing and dust.
• Twist-Close Nozzle Prevents Leaking - Multiple extensions available including rigid, flexible and gear lube.
• Long-Life Valve Design - Poppet design offers exceptional valve life for heavy usage applications.
• Durable Cast Body - Designed for heavy duty and harsh applications.
• High-Flow Rates - Capable of up to 20 gpm (75.7 lpm).
• Long Battery Life - Features four easily-replaceable AA batteries.

• Series: 20

• Calibration Type: Factory Calibrated

• Compatible Material: Petroleum-Based Oil, Synthetic-Based Oil, Antifreeze

• Dispense Type: Preset

• Display Type: Electronic

• Extension Type: Rigid

• Fluid Inlet Thread Gender: Female

• Fluid Outlet Thread Gender: Female

• Includes: Nozzle, Extension
• Inlet Size (cm): 1.27
• Inlet Size (in): 1/2
• Inlet Size (mm): 12.7

• Inlet Thread Type: NPT

• IP Rating: 69K

• Maximum Flow Rate (cc/min): 75708

• Maximum Flow Rate (cc/sec): 1262
• Maximum Flow Rate (GPM): 20
• Maximum Flow Rate (L/min): 75.7

• Maximum Operating Temperature ( degree C): 52
• Maximum Operating Temperature ( degree F): 125

• Maximum Recorded Dispense: 19999

• Maximum Storage Temperature ( degree C): 85
• Maximum Storage Temperature ( degree F): 185

• Maximum Totalizer: 19999

• Maximum Working Pressure (bar): 102
• Maximum Working Pressure (kPa): 10340
• Maximum Working Pressure (MPa): 10
• Maximum Working Pressure (psi): 1500
• Meter Accuracy: plus/minus 00.5
• Meter Accuracy (%): plus/minus 00.5
• Meter Pressure Loss (bar): 10.3 Bar at 12 GPM
• Meter Pressure Loss (psi): 150 PSI at 12 GPM
• Meter Technology: Oval Gear

• Metering Gun Weight (kg): 2.4
• Metering Gun Weight (lb): 5.2

• Minimum Flow Rate (GPM): 0.25

• Minimum Operating Temperature ( degree C): -29
• Minimum Operating Temperature ( degree F): -20

• Nozzle Type: Manual

• Outlet Size (cm): 1.905
• Outlet Size (in): 3/4
• Outlet Size (mm): 19.05
• Outlet Thread Type: ORB

• Overall Height (cm): 18.3
• Overall Height (in): 7.2
• Overall Height (mm): 183
• Overall Length (cm): 54.4
• Overall Length (in): 21.4
• Overall Length (mm): 544
• Overall Width (cm): 10.4
• Overall Width (in): 4.1
• Overall Width (mm): 103.5

• Recommended Environment: Indoor/Outdoor

GG 273295

KIT, PUMP LOWER, PRO-CONNECT, CS, W/O BUNG ADAPTER

Graco 273295 Pump Lower, Kit, (Carbon Steel)

Transfer Pumps are required to move A and B materials to the Reactor Spray Systems. The T4 Transfer Pump combines Graco's proven Merkur air-motor and carbon steel lower. The T4 is a 3:1 ratio pump with ProConnect technology - allowing you to quickly connect and disconnect the air motor from the pump lower.

• Quick Transfer Between Drums - quickly change to a new drum of material without the mess of dripping chemical by using multiple pump lowers.
• Easier to Maneuver - easily transfer the T4 pump between drums by quickly disconnecting the air motor from the lower before transferring. This makes the pump lighter weight and reduces the necessary ceiling height of your rig.
• Eliminate Downtime - get up and running quickly when your pump lower requires maintenance by having a spare pump lower that can easily be installed.

• Model: Pump Lower

• Material: Carbon Steel

• Package Options: Bare

GG 27420-2-160

GG 27421

GG 276025

GG 276733

GG 276741

GG 277007

GG 277070

GG 277241

GG 277249

HOSE, CPLD, 1/4" X 3', 4000 WPR

Graco 277249 BlueMax II HP Airless Whip Hose, 1/4 in x 3 ft (0.9 m), 4000 psi

The BlueMax II HP Whip Hose provides more flexibility and increased operator control at the gun. This BlueMax II Whip Hose has a 1/4 inch diameter and is 3 feet long and rated for up to 4000 psi.

• Lighter Weight

  Over 10% lighter weight and increased hose flexibility improves under pressure

• Highest Safety Standards

  Conductive core meets the highest worldwide safety standards unlike competitive ground wire hose designs

• Minimal Hose Coil Memory

  BlueMax II Hose has superior flexibility and reduced coil memory providing ease of use during coiling and uncoiling

• Model: BlueMax II
• Series: Whip Hose

• Hose Diameter (in): 1/4
• Hose Length (ft): 3
• Hose Length (m): 0.9150

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 2800
• Maximum Working Pressure (psi): 4000

GG 277250

HOSE, CPLD, 1/4" X 50', 4000WPR

Graco 277250 BlueMax II HP Airless Hose, 1/4 in x 50 ft, 4000 psi

To maximize performance, choose BlueMax II high performance airless hose rated up to 4000 psi. With superior flexibility and durability, BlueMax II is designed to ensure you get the best results from your airless sprayer.

• Lighter Weight

  Over 10% lighter weight and increased hose flexibility improves usability while spraying under pressure

• Highest Safety Standards

  Conductive core meets the highest worldwide safety standards unlike competitive ground wire hose designs

• Minimal Hose Coil Memory

  BlueMax II Hose has superior flexibility and reduced coil memory providing ease of use during coiling and uncoiling

• Model: BlueMax II
• Series: Hose

• Connection Type: FBE

• Hose Diameter (in): 1/4
• Hose Length (cm): 1524
• Hose Length (ft): 50
• Hose Length (in): 600
• Hose Length (m): 15.2
• Hose Length (mm): 15200

• Inside Diameter (cm): 0.635
• Inside Diameter (in): 1/4
• Inside Diameter (mm): 6.35

• Material: Nylon

• Maximum Working Pressure (bar): 276
• Maximum Working Pressure (kPa): 27600
• Maximum Working Pressure (MPa): 27.6
• Maximum Working Pressure (psi): 4000

GG 277251

HOSE, CPLD, 3/8" X 50', 4000 WPR

Graco 277251 BlueMax II HP Airless Hose, 3/8 in x 50 ft, 4000 psi

To maximize performance, choose BlueMax II high performance airless hose rated up to 4000 psi. With superior flexibility and durability, BlueMax II is designed to ensure you get the best results from your airless sprayer.

• Lighter Weight

  Over 10% lighter weight and increased hose flexibility improves usability while spraying under pressure

• Highest Safety Standards

  Conductive core meets the highest worldwide safety standards unlike competitive ground wire hose designs

• Minimal Hose Coil Memory

  BlueMax II Hose has superior flexibility and reduced coil memory providing ease of use during coiling and uncoiling

• Model: BlueMax II
• Series: Hose

• Connection Type: FBE

• Hose Diameter (in): 3/8
• Hose Length (cm): 1524
• Hose Length (ft): 50
• Hose Length (in): 600
• Hose Length (m): 15
• Hose Length (mm): 15200

• Inside Diameter (cm): 0.9525
• Inside Diameter (in): 3/8
• Inside Diameter (mm): 9.525

• Material: Nylon

• Maximum Working Pressure (bar): 276
• Maximum Working Pressure (kPa): 27600
• Maximum Working Pressure (MPa): 27.6
• Maximum Working Pressure (psi): 4000

GG 277253

HOSE, CPLD, 1/2" X50', 4000WPR

Graco 277253 BlueMax II HP Airless Hose, 1/2 in x 50 ft, 4000 psi

To maximize performance, choose BlueMax II high performance airless hose rated up to 4000 psi. With superior flexibility and durability, BlueMax II is designed to ensure you get the best results from your airless sprayer.

• Lighter Weight

  Over 10% lighter weight and increased hose flexibility improves under pressure

• Highest Safety Standards

  Conductive core meets the highest worldwide safety standards unlike competitive ground wire hose designs

• Minimal Hose Coil Memory

  BlueMax II Hose has superior flexibility and reduced coil memory providing ease of use during coiling and uncoiling

• Model: BlueMax II
• Series: Hose

• Connection Type: FBE

• Hose Diameter (in): 1/2
• Hose Length (cm): 1524
• Hose Length (ft): 50
• Hose Length (in): 600
• Hose Length (m): 15
• Hose Length (mm): 15200

• Inside Diameter (cm): 1.27
• Inside Diameter (in): 1/2
• Inside Diameter (mm): 12.7

• Material: Nylon

• Maximum Working Pressure (bar): 276
• Maximum Working Pressure (kPa): 27600
• Maximum Working Pressure (MPa): 27.6
• Maximum Working Pressure (psi): 4000

GG 277296

GG 273026

KIT, REPAIR

Graco 273026 Coupling Jaw Repair Kit for High-Flo Lowers

GG 276697

KIT, NEEDLE, ELECTRODE

Graco 276697 SnapBack Electrode Replacement Needle

GG 276049

SPACER

Graco 276049 5 Gallon Platens Spacer

• Compatible Material: Waterborne

GG 245128

GG 109301

GG 112182

GG 113020

GG 113355

GG 157277

GG 162718

GG 186995

GG 188006

GG H43810

GG 102774

GG 127476

GG 127482

GG 15C852

GG 15D564

GG 15D592

GG 15J647

GG 15U938

GG 15J821

GG 16P451

GG 16P452

GG 16U675

GG 16W462

GG 16W463

GG 16W508

GG 17A030

GG 17B186

GG 17D481

GG 17H258

GG 17H287

GG 17H288

GG 17H316

GG 17H323

GG 17H324

GG 17H327

GG 17H409

GG 17K162

KIT, REPAIR, PACKING

Graco 17K162 Pump Packing Repair Kit

Replace a worn or damaged pump with genuine Graco parts. Refer to the parts manual for your sprayer to ensure part compatibility

• Graco Tech Support can further assist with troubleshooting sprayer operation

GG 17K759

GG 17K763

GG 17K764

GG 17K766

GG 17K912

GG 17L034

GG 17M562

GG 17M566

GG 17N075

GG 17N356

GG 17W767

GG 17W869

GG 17X733

GG 197674

GG 198894

GG 20299-00

GG 206733

GG 206735

GG 206761

GG 206922

GG 206923

GG 206924

GG 207308

GG 207336

GG 207386

GG 207581

GG 207848

GG 207850

GG 207851

GG 208238

GG 208380

GG 210539

GG 210733
