GRACO INC. S10595

GG 24W498

GT 750 PUMP, GREASE, 36:1, STUBBY

Graco 24W498 GT 750 36:1 Universal Grease Transfer Pump with Bung Adapter- NPT

The GT 750 pump was engineered to perform in challenging applications and changing environments. The large 7.5-inch (190 mm) air motor and pump lower combination allows the GT 750 pump to move the same amount of grease with up to four times fewer pump strokes.

• Efficient Air Motor - Use less air to move more grease.
• High Flow Rates - Up to 32 lb/min (13.6 kg/min) of grease.
• High Volume Per Stroke - Pump more grease without having to drive pump too quickly to damage seals.
• Multiple Tank Options - Available in 35, 120 and 400 lb (16, 54 and 181 kg) down tube lengths.

• Model: GT 750

• Air Inlet Size (in): 0.5
• Air Inlet Size (mm): 12.7
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT
• Air Motor Effective Diameter (in): 7.5

• Application: Grease

• Compatible Material: Grease

• Fluid Inlet Thread Type: NPT
• Fluid Inlet Type: NPT

• Fluid Outlet Size (in): 1
• Fluid Outlet Size (mm): 25.4
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT

• For Use With: Grease up to NLGI 2

• Includes: 2 Inch (51 mm) Bung Adapter and Lift Ring, Universal Lower

• Maximum Air Consumption (SCFM): 130
• Maximum Air Inlet Pressure (bar): 6.9
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Continuous Cycle Rate (CPM): 60

• Maximum Working Pressure (bar): 248.2
• Maximum Working Pressure (kPa): 24820
• Maximum Working Pressure (MPa): 24.8
• Maximum Working Pressure (psi): 3600

• Output Per Cycle (cm cu ): 180

• Pump Ratio: 36:1

GG 24W599

GG 24W617

KIT, REPLACEMENT, PISTON ROD, PC

Graco 24W617 ProConnect Replacement Rod Paint Sprayer Pump Kit for Pro210ES

Replace your pump rod with genuine Graco parts.Replacement part for rebuilding ProConnect pump. kit includes rod with installed piston valve. ProConnect pump is for Pro 210ES cart or stand model sprayers. Refer to the parts manual for your sprayer to ensure part compatibility

• Rod and piston are part of the sprayer pump for pumping fluid
• Sprayer does not prime or spray, it may be from high pressure cuts, scratches and wear from not repacking the pump
• Graco tech support can further assist with troubleshooting sprayer operation
• Genuine Graco parts kit includes rod with installed piston valve

• For Use With: Pro210ES Stand, Pro210ES Cart

GG 24W619

KIT, REPLACEMENT, CYLINDER, PC

Graco 24W619 Pump Cylinder

Airless Priston Pump Replacement Cylinder

• Pump Cylinder

GG 24W633

RESERVOIR, 4 PINT, 118:1, RH

Graco 24W633 Manzel MB118 Series Lubricator - 4 Pint (1.9 Liter) Reservoir (4 Pump Stations Max), No Pumps Installed, 118:1 drive on right hand end

Graco Manzel box lubricators - when quality and delivery matter! Made with Graco quality for long life and durability, the Manzel MB118 is the right size for triplex and quintuplex mud pump applications.

• Provide a proven, cost-effective way to assemble customized oil systems that meet specific requirements by using standard modular components
• Increase opportunities to standardize lube system components and reduce lube maintenance and service costs
• 4 pint (1.9 liter) reservoir (4 pump stations max), no pumps installed, 118:1 drive on RH end

• Model: Manzel
• Series: MB

• Cam Type: Single Lobe

• Compatible Material: Oil

• Drive Location: Right Hand Mount
• Drive Option: Internal Gear Reduction

• Lubricator Gear Ratio: 118:1

• Maximum Drive Speed (RPM): 1800

• Maximum Fluid Viscosity (SUS): 5000

• Maximum Number of Pump Stations: 4
• Maximum Number of Strokes (SPM): 15

• Maximum Operating Temperature ( degree C): 60
• Maximum Operating Temperature ( degree F): 140

• Maximum Reservoir Capacity (gal): 0.5
• Maximum Reservoir Capacity (L): 1.9

• Maximum Reservoir Capacity (pt): 4
• Maximum Reservoir Capacity (qt): 2

• Maximum Working Pressure (bar): 517.1
• Maximum Working Pressure (kPa): 51710
• Maximum Working Pressure (psi): 7500

• Minimum Fluid Viscosity (SUS): 80

• Minimum Operating Temperature ( degree C): -29
• Minimum Operating Temperature ( degree F): -20

• Number of Pumps: 0

• Overall Depth (cm): 36.2
• Overall Depth (in): 14.25
• Overall Depth (mm): 362

• Overall Width (cm): 13.97
• Overall Width (in): 5.5
• Overall Width (mm): 139.7

GG 24W758

HUSKY PUMP, 1050HP, A01AS1SSSPSSPT

Graco 24W758 Husky 1050HP 1 in. (25.4 mm) NPT SS Pump, AL Center Section, SS Seats, SP Balls & SP Diaphragm

The Husky 1050HP air-operated diaphragm pump is the first pump on the market that allows users to choose between low pressure and high pressure operating modes with Graco's low-high pressure mode valve. High pressure operation isn't always required, so switch to the low pressure mode to reduce air consumption up to 50%. These features combined with the quality and reliability of our standard Husky diaphragm pump design make this one of the most unique high pressure diaphragm pumps on the market.

• Benefits of the Husky 1050HP Double Diaphragm Pump

  Increased fluid pressure without sacrificing flow

  Low-high pressure mode valve lets you operate the pump as a standard AODD or a high pressure AODD

  Reduce air consumption up to 50% with the low pressure mode

  Same repair parts as the Husky 1050 diaphragm pump

  • External Pilots

    Ease of maintenance

    Reduced down-time (quick change time)

    Spring loaded for faster change over

    • Modular Air Valve

      Ease of maintenance

      Stall and lube free

      • Additional Diaphragm

        For high pressure operation

        • Low/High Pressure Operation Valve

          Selectable operating setting

          Reduces air consumption

          Only use high pressure when required

          • Wetted Components

            Utilizes same parts as Husky 1050 which reduces repair part inventory




            • Model: Husky
            • Series: 1050HP
            • Air Exhaust Port Size (in): 3/4
            • Air Exhaust Port Thread Gender: Female
            • Air Exhaust Port Thread Type: NPT
            • Air Inlet Size (in): 3/4
            • Air Inlet Thread Gender: Female
            • Air Inlet Thread Type: NPT
            • Application: Industrial
            • Ball Material: Santoprene
            • Center Section Material: Aluminum
            • Compatible Material: Antifreeze, Detergent, Gel-Coat, Asphalt, Polyurethane, Polymer, Fibers, Alkyds, Resin, Motor Oil, Grease & Oil, Used Oil, Hydraulic Fluid, Transmission Fluid, Cutting Oil, Oil, Windshield Washer Fluid, Diesel Exhaust Fluid, Water, Water - Wastewater Treatment, Water - Wastewater Transfer, Water, Automotive Undercoating
            • Connection Type: Threaded
            • Diaphragm Compatible Material: Santoprene
            • Diaphragm Material: Santoprene
            • Fluid Inlet Size (cm): 2.54
            • Fluid Inlet Size (in): 1
            • Fluid Inlet Size (mm): 25.4
            • Fluid Inlet Thread Gender: Female
            • Fluid Inlet Thread Type: NPT
            • Fluid Outlet Size (cm): 2.54
            • Fluid Outlet Size (in): 1
            • Fluid Outlet Size (mm): 25.4
            • Fluid Outlet Thread Gender: Female
            • Fluid Outlet Thread Type: NPT
            • Fluid Section Material: Stainless Steel
            • Manifold Configuration: End Port
            • Manifold O-Ring Material: PTFE
            • Material: Stainless Steel
            • Maximum Air Consumption (SCFM): 95
            • Maximum Air Pressure (bar): 8.62
            • Maximum Air Pressure (kPa): 862
            • Maximum Air Pressure (MPa): 0.862
            • Maximum Air Pressure (psi): 125
            • Maximum Cycle Rate (CPM): 140
            • Maximum Flow Rate (GPM): 50
            • Maximum Flow Rate (L/min): 189
            • Maximum Fluid Pressure (bar): 17.2
            • Maximum Fluid Pressure (kPa):

GG 24W762

HUSKY PUMP, 1050HP, SP/SP/SP/A

Graco 24W762 Husky 1050HP 1 in. (25.4 mm) NPT AL Pump, AL Center Section, SP Seats, SP Balls & SP Diaphragm

The Husky 1050HP air-operated diaphragm pump is the first pump on the market that allows users to choose between low pressure and high pressure operating modes with Graco's low-high pressure mode valve. High pressure operation isn't always required, so switch to the low pressure mode to reduce air consumption up to 50%. These features combined with the quality and reliability of our standard Husky diaphragm pump design make this one of the most unique high pressure diaphragm pumps on the market.

• Benefits of the Husky 1050HP Double Diaphragm Pump

  Increased fluid pressure without sacrificing flow

  Low-high pressure mode valve lets you operate the pump as a standard AODD or a high pressure AODD

  Reduce air consumption up to 50% with the low pressure mode

  Same repair parts as the Husky 1050 diaphragm pump

  • External Pilots

    Ease of maintenance

    Reduced down-time (quick change time)

    Spring loaded for faster change over

    • Modular Air Valve

      Ease of maintenance

      Stall and lube free

      • Additional Diaphragm

        For high pressure operation

        • Low/High Pressure Operation Valve

          Selectable operating setting

          Reduces air consumption

          Only use high pressure when required

          • Wetted Components

            Utilizes same parts as Husky 1050 which reduces repair part inventory




            • Model: Husky
            • Series: 1050HP
            • Air Exhaust Port Size (in): 3/4
            • Air Exhaust Port Thread Gender: Female
            • Air Exhaust Port Thread Type: NPT
            • Air Inlet Size (in): 3/4
            • Air Inlet Thread Gender: Female
            • Air Inlet Thread Type: NPT
            • Application: Industrial
            • Ball Material: Santoprene
            • Center Section Material: Aluminum
            • Compatible Material: Antifreeze, Detergent, Gel-Coat, Asphalt, Polyurethane, Polymer, Fibers, Alkyds, Resin, Motor Oil, Grease & Oil, Used Oil, Hydraulic Fluid, Transmission Fluid, Cutting Oil, Oil, Windshield Washer Fluid, Diesel Exhaust Fluid, Water, Water - Wastewater Treatment, Water - Wastewater Transfer, Water, Automotive Undercoating
            • Connection Type: Threaded
            • Diaphragm Compatible Material: Santoprene
            • Diaphragm Material: Santoprene
            • Fluid Inlet Size (cm): 2.54
            • Fluid Inlet Size (in): 1
            • Fluid Inlet Size (mm): 25.4
            • Fluid Inlet Thread Gender: Female
            • Fluid Inlet Thread Type: NPT
            • Fluid Outlet Size (cm): 2.54
            • Fluid Outlet Size (in): 1
            • Fluid Outlet Size (mm): 25.4
            • Fluid Outlet Thread Gender: Female
            • Fluid Outlet Thread Type: NPT
            • Fluid Section Material: Aluminum
            • Manifold Configuration: End Port
            • Manifold O-Ring Material: PTFE
            • Material: Aluminum
            • Maximum Air Consumption (SCFM): 95
            • Maximum Air Pressure (bar): 8.62
            • Maximum Air Pressure (kPa): 862
            • Maximum Air Pressure (MPa): 0.862
            • Maximum Air Pressure (psi): 125
            • Maximum Cycle Rate (CPM): 140
            • Maximum Flow Rate (GPM): 50
            • Maximum Flow Rate (L/min): 189
            • Maximum Fluid Pressure (bar): 17.2
            • Maximum Fluid Pressure (kPa): 1720
            • M

GG 24W812

GG 24W830

KIT, REPLACEMENT, HOSE, CPLD, QD

Graco 24W830 Hose Replacement Kit

Piston pump to filter manifold hose, 1/4QD

• Piston pump to filter manifold hose

GG 24W849

GG 24W863

GG 24W913

KIT, OVERHAUL, CS, GL-33

Graco 24W913 GL-33 and GL-42 Injectors and Accessories - GL33 Overhaul Kit, Carbon Steel

• GL33 overhaul kit, carbon steel

• For Use With: GL-33 Grease Injectors

• Includes: GL-33 Piston, Lubricant, Hardware

• Kit Type: Overhaul Kit

• Number of Pieces: 9

GG 24W920

GG 24W923

GH 130 SPRAYER, STD

Graco 24W923 GH 130 Convertible Standard Series Gas Hydraulic Airless Sprayer

The GH 130 Convertible is the clear choice for entry level contractors who demand maximum power in a small package. With the ability to change out the pump lower and convert to electric power without tools, you can be assured that you have the most versatile sprayer on the market today.

• Endurance Chromex Piston Pump
  • Lasts 2X longer than the next leading brand
  • QuikChange pump design allows you to swap the pump easily on the job
  • Faster cleaning with the QuikAccess intake foot valve
• High-Efficiency Hydraulic Motor
  • Rock-solid performance time after time keeps you up and running
  • Faster, more responsive changeover
  • O-ring sealed fittings and form-fitted hydraulic lines prevent leaks
  • Fewer moving parts mean less maintenance and longer life
• High-Capacity Cooling System
  • Innovative design allows the pump to run cooler and more efficiently
  • Hydraulic reservoir is tapered on the bottom
  • Provides easier and more thorough fluid changes
  • Cooling fins on reservoir deflect heat away from sprayer
• Easy Out Pump Filter
  • Easy maintenance & less clogging
  • Exclusive inside-out filter design won't collapse to ensure a quality finish
  • Vertical design for less mess
• Heavy-Duty Prime Valve
  • Maintenance-free design withstands high-pressure dumping
• Rugged, Durable Cart Design
  • Thick chrome over welded steel withstands rugged environments
  • Full pneumatic wheels absorb impacts and vibrations
  • Retractable handle doubles as coiled hose storage
  • Tilts on its nose for service in the field
• Electric Motor Capability
  • Indoor and outdoor use
  • Quickly swap the gas engine for an electric motor in seconds - without tools
  • Electric motor kit sold separately
• Ready to Work
  Includes everything you need to get spraying:
  • Contractor Airless Spray Gun
  • RAC X SwitchTips and Guard
  • 50 feet of BlueMax II Airless Hose

• Model: GH
• Series: 130
• Product Series: Standard

• Compatible Electric Motor Kits: 288473, 288474 (CSA)
• Compatible Material: Acrylics, Paint, Primer
• Compatible Replacement Pump: 24B748

• Convertible: Yes

• Engine Brand: Honda
• Engine Size (HP): 4

• Features: Endurance Chromex Pump, High-Capacity Cooling System, Honda Engine, Easy Out Filter, Heavy-Duty Prime Valve, Durable Cart Design, Convertible

• Fluid Inlet Size (in): 3/4
• Fluid Inlet Size (mm): 19.05
• Fluid Inlet Thread Type: MNPT

• Fluid Outlet Size (in): 3/8
• Fluid Outlet Size (mm): 3.75
• Fluid Outlet Thread Type: FNPT

• Frame Configuration: Cart

• Includes: Contractor Gun, RAC X LP 517 Spray Tip, RAC X WideRAC 1231 Spray Tip, RAC X Guard, 1/4 in x 50 ft BlueMax II Airless Hose, TSL 4 oz

• Maximum Flow Rate (GPM): 1.30
• Maximum Flow Rate (L/min): 4.9

• Maximum Hose Length (ft): 300
• Maximum Hose Length (m): 92

• Maximum Sound Pressure Level (dB(A)): 88

• Maximum Tip Size (in): 0.037
• Maximum Tip Size 1 Gun - Electric Motor (in): 0.031
• Maximum Tip Size 2 Guns - Electric Motor (in): 0.017
• Maximum Tip Size Gun 1 (in): 0.037
• Maximum Tip Size Gun 2 (in): 0.023

• Maximum Working Pressure (bar): 228
• Maximum Working Pressure (kPa): 2

GG 24W929

GH 230 SPRAYER, STD

Graco 24W929 GH 230 Convertible Standard Series Gas Hydraulic Airless Sprayer

The GH 230 Convertible is the most versatile sprayer for the professional contractor looking for workhorse hydraulic performance for large commercial and residential construction jobs. Superior versatility with the ability to change out the pump lower and convert to electric power without tools.

• Endurance Chromex Piston Pump


  Lasts 2X longer than the next leading brand

  QuikChange pump design allows you to swap the pump easily on the job

  Faster cleaning with the QuikAccess intake foot valve

• High-Efficiency Hydraulic Motor


  Rock-solid performance time after time keeps you up and running

  Faster, more responsive changeover

  O-ring sealed fittings and form-fitted hydraulic lines prevent leaks

  Fewer moving parts mean less maintenance and longer life

• High-Capacity Cooling System


  Innovative design allows the pump to run cooler and more efficiently

  Hydraulic reservoir is tapered on the bottom

  Provides easier and more thorough fluid changes

  Cooling fins on reservoir deflect heat away from sprayer

• Easy Out Pump Filter


  Easy maintenance & less clogging

  Exclusive inside-out filter design wont collapse to ensure a quality finish

  Vertical design for less mess

• Heavy-Duty Prime Valve


  Maintenance-free design withstands high-pressure dumping

• Rugged, Durable Cart Design


  Thick chrome over welded steel withstands rugged environments

  Full pneumatic wheels absorb impacts and vibrations

  Retractable handle doubles as coiled hose storage

  Tilts on its nose for service in the field

• Electric Motor Capability


  Indoor and outdoor use

  Quickly swap the gas engine for an electric motor in seconds - without tools

  Electric motor kit sold separately

• Ready to Work
  Includes everything you need to get spraying:

  Silver Plus Airless Spray Gun

  RAC X SwitchTips and Guard

  50 feet of BlueMax II Airless Hose

• Model: GH
• Series: 230
• Product Series: Standard

• Compatible Electric Motor Kits: 248949, 248950 (CSA)
• Compatible Material: Acrylics, Dry Fall, Drywall Mud, Elastomer, Gypsum, Paint, Primer
• Compatible Replacement Pump: 24W997

• Convertible: Yes

• Engine Brand: Honda
• Engine Size (HP): 6.5

• Features: Endurance Chromex Pump, High-Capacity Cooling System, Honda Engine, Easy Out Filter, Heavy-Duty Prime Valve, Durable Cart Design, Convertible

• Fluid Inlet Size (in): 1-5/16
• Fluid Inlet Size (mm): 33.34
• Fluid Inlet Thread Type: UN-2A

• Fluid Outlet Size (in): 3/8
• Fluid Outlet Size (mm): 3.75
• Fluid Outlet Thread Type: FNPT

• Frame Configuration: Cart

• Includes: Silver Plus Gun, RAC X LP 517 Spray Tip, RAC X WideRAC 1231 Spray Tip, RAC X Guard, 3/8 in x 50 ft BlueMax II Airless Hose, 1/4 in x 3 ft BlueMax II Airless Whip Hose, TSL 4 oz

• Maximum Flow Rate (GPM): 2.35
• Maximum Flow Rate (L/min): 8.9

• Maximum Hose Length (ft): 300
• Maximum Hose Length (m): <

GG 24X003

GG 24W350

ENDURA-FLO PUMP, 4:1 AODD, 150, BSP, ADV

Graco 24W350 Endura-Flo 4D150, 4:1 Air Operated Diaphragm Pump, 150cc, BSPP, DataTrak

The Endura-Flo 4D offers the industry's highest-pressure ratio at 4:1. This easy to install pump is ideal for fluid transfer and supply, paint circulation, and piggable paint systems. Low pulsation output and smooth changeover for quick color changes ultimately save you time and money.

• Endure-Flo diaphragms last longer against extreme operating conditions
• Easy access to critical components for fast online maintenance
• Pumps offer low pulsation output and smooth changeover for quick color changes, saving you time and money
• Custom mounting options include rotatable fluid manifolds, mounting brackets and spring loaded check cartridges
• DataTrek option prevents runaway and tracks material usage

• Model: Endura-Flo
• Series: 4D150

• Air Inlet Size (in): 1/4
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Circulation

• Compatible Material: High Solids, Xirallic, CARC, Metallics, Stains, Varnish, Fast-Set

• Connection Type: Threaded

• Fluid Inlet Size (cm): 1.27
• Fluid Inlet Size (in): 1/2
• Fluid Inlet Size (mm): 12.7
• Fluid Inlet Thread Type: BSPP

• Fluid Outlet Size (cm): 1.27
• Fluid Outlet Size (in): 1/2
• Fluid Outlet Size (mm): 12.7
• Fluid Outlet Thread Type: BSPP

• Includes: BSPP Fittings, DataTrak

• Material: Stainless Steel

• Maximum Air Pressure (bar): 7

• Maximum Air Pressure (kPa): 700
• Maximum Air Pressure (MPa): 0.7
• Maximum Air Pressure (psi): 100

• Maximum Cycle Rate (CPM): 20

• Maximum Flow Rate (GPM): 2.4
• Maximum Flow Rate (L/min): 9.1

• Maximum Fluid Pressure (bar): 28
• Maximum Fluid Pressure (kPa): 2800
• Maximum Fluid Pressure (MPa): 2.8
• Maximum Fluid Pressure (psi): 400

• Maximum Fluid Pressure (bar): 28
• Maximum Fluid Pressure (kPa): 2800
• Maximum Fluid Pressure (MPa): 2.8
• Maximum Fluid Pressure (psi): 400

• Maximum Operating Temperature ( degree C): 50
• Maximum Operating Temperature ( degree F): 122

• Minimum Operating Temperature ( degree C): 0
• Minimum Operating Temperature ( degree F): 32

• Power Source: Air

• Pump Ratio: 4:1

GG 24X026

GG 24X004

GG 24X038

KIT, SOLENOID

Graco 24X038 Quick Disconnect Solenoid Kit

KIT INCLUDES: SOLENOID, QUICK DISCONNECT [QTY. 1], LUBRICANT, GREASE, 3GRAM [QTY. 1], FITTING, M6 PUSH-2-CON, M7 [QTY. 1], FITTING, TUBE, UNEQUAL 3/8 TO 1/4 [QTY. 1], TUBE, POLYURETHANE, RD [QTY. 1]

GG 24X055

GG 24X089

KIT, PRESSURE, SENSOR, SANITARY

GG 24X056

GG 24X156

GG 24X167

LSR F4-55 SYSTEM, 55GAL/55GAL, CASTERS

Graco 24X167 1:1 Ratio 55 gal (200 liter) F4 Fluid Automation System with Casters

In the manufacturing of liquid silicone rubber products, precision is paramount. Material waste is an expensive problem and substandard products are an intolerable failure. Minimize both with the Graco Fluid Automation F4-55.

• Precise ratio control, minimal material waste

  The F4-55 system takes the ability to meter material flow to an almost microscopic level. Its helical gear uses multiple gear teeth to measure flow in very small increments. The increased number of measurements offers more assurance the machine remains on-ratio.

  The result: More precise mixing, a better end product and less wasted material.

  • Easier operation with Graco Control Architecture

    The Graco Fluid Automation F4-55 system features intuitive user interfaces based on the Graco Control Architecture (GCA), a modular system of processing and control components. GCA makes maintenance and service easy, thanks to built-in troubleshooting tools

    • Better Color Control

      Mix two additive streams at ratios ranging from 0.5 to 6%

      • Maintains Material Integrity

        Stainless steel components meet the standard for clean room applications to prevent contamination, and cure inhibition and discoloration of material

        • Cleanroom Convenience

          A smaller footprint and casters (optional on F4-55) allow for system movement and maintenance




          • Model: LSR
          • Air Inlet Size (cm): 1.27
          • Air Inlet Size (in): 1/2
          • Air Inlet Size (mm): 12.7
          • Air Inlet Thread Gender: Female
          • Air Inlet Thread Type: NPT
          • Amperage (A): 4
          • Applicator Type: Automatic
          • Frequency (Hz): 50/60
          • Maximum Flow Rate (kg/min): 2.27
          • Maximum Flow Rate (lb/min): 5
          • Maximum Working Pressure (bar): 207
          • Maximum Working Pressure (kPa): 20700
          • Maximum Working Pressure (MPa): 21
          • Maximum Working Pressure (psi): 3000
          • Minimum Flow Rate (GPM): 10

GG 24X160

LSR F4-5 SYSTEM, 5GAL/5GAL

Graco 24X160 1:1 Ratio 5 gal (20 liter) F4 Fluid Automation System with Casters

In the manufacturing of liquid silicone rubber products, precision is paramount. Material waste is an expensive problem and substandard products are an intolerable failure. Minimize both with the Graco Fluid Automation F4-5.

• Precise ratio control, minimal material waste

  The F4-5 system takes the ability to meter material flow to an almost microscopic level. Its helical gear uses multiple gear teeth to measure flow in very small increments. The increased number of measurements offers more assurance the machine remains on-ratio.

  The result: More precise mixing, a better end product and less wasted material.

  • Easier operation with Graco Control Architecture

    The Graco Fluid Automation F4-5 system features intuitive user interfaces based on the Graco Control Architecture (GCA), a modular system of processing and control components. GCA makes maintenance and service easy, thanks to built-in troubleshooting tools

    • Better Color Control

      Mix two additive streams at ratios ranging from 0.5 to 6%

      • Maintains Material Integrity

        Stainless steel components meet the standard for clean room applications to prevent contamination, and cure inhibition and discoloration of material

        • Cleanroom Convenience

          A smaller footprint and casters (optional on F4-5) allow for system movement and maintenance




          • Model: LSR
          • Air Inlet Size (in): 1/2
          • Air Inlet Thread Gender: Female
          • Air Inlet Thread Type: NPT
          • Amperage (A): 4
          • Applicator Type: Automatic
          • Frequency (Hz): 50/60
          • Maximum Flow Rate (kg/min): 2.3
          • Maximum Flow Rate (lb/min): 5
          • Maximum Working Pressure (bar): 207
          • Maximum Working Pressure (kPa): 20700
          • Maximum Working Pressure (MPa): 21
          • Maximum Working Pressure (psi): 3000
          • Minimum Flow Rate (GPM): 10

GG 24X166

LSR F4-55-5 SYSTEM, LSR55-5GAL/55-5GAL, CSTERS

Graco 24X166 1:1 Ratio 5 gal (20 liter) F4 Fluid Automation System with Casters

In the manufacturing of liquid silicone rubber products, precision is paramount. Material waste is an expensive problem and substandard products are an intolerable failure. Minimize both with the Graco Fluid Automation F4-55.

• Precise ratio control, minimal material waste

  The F4-55 system takes the ability to meter material flow to an almost microscopic level. Its helical gear uses multiple gear teeth to measure flow in very small increments. The increased number of measurements offers more assurance the machine remains on-ratio.

  The result: More precise mixing, a better end product and less wasted material.

  • Easier operation with Graco Control Architecture

    The Graco Fluid Automation F4-55 system features intuitive user interfaces based on the Graco Control Architecture (GCA), a modular system of processing and control components. GCA makes maintenance and service easy, thanks to built-in troubleshooting tools

    • Better Color Control

      Mix two additive streams at ratios ranging from 0.5 to 6%

      • Maintains Material Integrity

        Stainless steel components meet the standard for clean room applications to prevent contamination, and cure inhibition and discoloration of material

        • Cleanroom Convenience

          A smaller footprint and casters (optional on F4-55) allow for system movement and maintenance




          • Model: LSR
          • Air Inlet Size (cm): 1.27
          • Air Inlet Size (in): 1/2
          • Air Inlet Size (mm): 12.7
          • Air Inlet Thread Gender: Female
          • Air Inlet Thread Type: NPT
          • Amperage (A): 4
          • Applicator Type: Automatic
          • Frequency (Hz): 50/60
          • Maximum Flow Rate (kg/min): 2.27
          • Maximum Flow Rate (lb/min): 5
          • Maximum Working Pressure (bar): 207
          • Maximum Working Pressure (kPa): 20700
          • Maximum Working Pressure (MPa): 21
          • Maximum Working Pressure (psi): 3000
          • Minimum Flow Rate (GPM): 10

GG 24X169

LSR F4-55 SYSTEM, 55GAL/55GAL

Graco 24X169 1:1 Ratio 55 gal (200 liter) F4-55 Fluid Automation System

In the manufacturing of liquid silicone rubber products, precision is paramount. Material waste is an expensive problem and substandard products are an intolerable failure. Minimize both with the Graco Fluid Automation F4-55.

• Precise ratio control, minimal material waste

  The F4-55 system takes the ability to meter material flow to an almost microscopic level. Its helical gear uses multiple gear teeth to measure flow in very small increments. The increased number of measurements offers more assurance the machine remains on-ratio.

  The result: More precise mixing, a better end product and less wasted material.

  • Easier operation with Graco Control Architecture

    The Graco Fluid Automation F4-55 system features intuitive user interfaces based on the Graco Control Architecture (GCA), a modular system of processing and control components. GCA makes maintenance and service easy, thanks to built-in troubleshooting tools

    • Better Color Control

      Mix two additive streams at ratios ranging from 0.5 to 6%

      • Maintains Material Integrity

        Stainless steel components meet the standard for clean room applications to prevent contamination, and cure inhibition and discoloration of material

        • Cleanroom Convenience

          A smaller footprint and casters (optional on F4-55) allow for system movement and maintenance




          • Model: LSR
          • Air Inlet Size (in): 1/2
          • Air Inlet Thread Gender: Female
          • Air Inlet Thread Type: NPT
          • Amperage (A): 4
          • Applicator Type: Automatic
          • Frequency (Hz): 50/60
          • Maximum Flow Rate (kg/min): 2.3
          • Maximum Flow Rate (lb/min): 5
          • Maximum Working Pressure (bar): 207
          • Maximum Working Pressure (kPa): 20700
          • Maximum Working Pressure (MPa): 21
          • Maximum Working Pressure (psi): 3000
          • Minimum Flow Rate (GPM): 10

GG 24X384

GG 24X573

GG 24X764

KIT, REPLACEMENT, PP, POP-UP HEA

This item is no longer available. Please contact Graco Customer Service for replacement options.

GG 24X663

HEAD, MOLSA, 100-1.04MM/4-.041IN

Graco 24X663 MOLSA Head, 4 inches (100 mm) wide, 0.041 inch (1.04 mm) orifice diameter

Multi-Orifice Linear Stream Applicator (MOLSA) gives you faster cycle rates, more accurate dispensing and longer production life compared to competitive offerings.

• Ideal for applying liquid applied sound deadener (LASD) using the Graco 1K Ultra-Lite dispense valve.
• Port Plug Model
• 4.00 inches (102 mm) wide

• Model: MOLSA

• Check Valve Assemblies: No

• Maximum Working Pressure (bar): 207
• Maximum Working Pressure (kg/cm 2): 211
• Maximum Working Pressure (kPa): 20700
• Maximum Working Pressure (MPa): 20.7
• Maximum Working Pressure (psi): 3000

• Port Plugs: Yes

GG 24X812

GL-1 XL INJECTOR, 2 POINT

Graco 24X812 GL-1 XL Grease Injector, Two Point

Custom fit your system with Gracos adjustable GL-1 series grease injectors. Designed to meet the needs of each lube point, these systems provide years of reliable operation in the harshest operating environments.

• The GL-1 XL injectors are offered both as a stand-alone and a replacement injector for manifold systems for easy customization to a variety of applications
• Includes an adjustable hex head nut to make adjusting the output simple
• No vent holes and fully enclosed press fittings to prevent leaking lubricant
• Rugged, single piece uni-body design built for the harshest environments

• Model: GL-1
• Series: XL
• Adjustable: Adjustable

• Application: In-Plant Machinery, Off-Road Equipment

• Compatible Material: Grease
• Compatible Metering Device: Single Line Parallel

• Cycle Indicator: Visual

• Dispense Outlet Size (cm): 0.33
• Dispense Outlet Size (in): 0.13
• Dispense Outlet Size (mm): 3.3
• Dispense Outlet Thread Type: NPT

• For Use With: Single Line Parallel Automatic Lubrication Systems

• Inlet Size (cm): 0.9525
• Inlet Size (in): 3/8
• Inlet Size (mm): 9.525

• Inlet Thread Type: NPT

• Maximum NLGI Grade: #2

• Maximum Operating Pressure (psi): 6000

• Maximum Output Volume (in cu ): 0.315

• Maximum Reset Pressure (psi): 1000

• Maximum Working Pressure (bar): 414
• Maximum Working Pressure (kPa): 41400
• Maximum Working Pressure (MPa): 41.4
• Maximum Working Pressure (psi): 6000

• Minimum Operating Pressure (psi): 1850
• Minimum Output Volume (in cu ): 0.035

• Outlet Size (cm): 0.9525
• Outlet Size (in): 3/8
• Outlet Size (mm): 9.525
• Outlet Thread Type: NPT

GG 24X827

KIT, GUN, CABLE

Graco 24X827 Pro Xpc Auto Spray Head Kit for models LC1020 and LC2020

GG 24X425

CHEMSAFE PUMP, 515PT-P01A-PT3-PT-PT-PO-P

Graco 24X425 ChemSafe 515 Air Operated Double Diaphragm Plastic Pump with PTFE Seat, PTFE Ball, Overmolded PTFE Diaphragm, PTFE Fluid Path & NPT Port

Gracos ChemSafe pumps feature PTFE or UHMWPE (ultra high molecular weight polyethylene) corrosion-resistant fluid paths, which make them ideal for corrosive and abrasive chemicals. Theres no exposed metals and they can be configured in various materials to meet most abrasion, temperature, and chemical compatibility requirements. Plus theyre dead-head capable and achieve high flow rates while minimizing air consumption and operational noise.

• Max flow rate of 16.6 gpm (63 lpm)
• High quality machined design provides a precision fit and superior chemical containment compared to molded pumps
• Corrosion-resistant exterior with no exposed metal reduces maintenance, extends pump life and offers clean, safe operation
• Ideal for corrosive and abrasive liquids such as acids, fuels, glues, paints, resins, inks, or wastewater

• Model: ChemSafe
• Series: 515

• Air Inlet Size (in): 1/4
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Industrial

• Ball Material: PTFE

• Center Section Material: Polypropylene

• Compatible Material: Antifreeze, Detergent, Gel-Coat, Asphalt, Polyurethane, Windshield Washer Fluid, Diesel Exhaust Fluid, Water - Wastewater Treatment, Water - Wastewater Transfer, Food and Personal Care, Ink

• Connection Type: Threaded

• Diaphragm Compatible Material: PTFE
• Diaphragm Material: PTFE Overmold

• Fluid Inlet Size (cm): 1.27
• Fluid Inlet Size (in): 1/2
• Fluid Inlet Size (mm): 12.7
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (cm): 1.27
• Fluid Outlet Size (in): 1/2
• Fluid Outlet Size (mm): 12.7
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT
• Fluid Section Material: PTFE

• Manifold Configuration: Center Port
• Manifold O-Ring Material: PTFE
• Material: PTFE

• Maximum Air Consumption (SCFM): 29
• Maximum Air Pressure (bar): 7

• Maximum Air Pressure (kPa): 700
• Maximum Air Pressure (MPa): 0.7
• Maximum Air Pressure (psi): 100

• Maximum Cycle Rate (CPM): 381

• Maximum Flow Rate (GPM): 16
• Maximum Flow Rate (L/min): 60.6

• Maximum Fluid Pressure (bar): 7
• Maximum Fluid Pressure (kPa): 700
• Maximum Fluid Pressure (MPa): 0.7
• Maximum Fluid Pressure (psi): 100

• Maximum Fluid Pressure (bar): 7
• Maximum Fluid Pressure (kPa): 700
• Maximum Fluid Pressure (MPa): 0.7
• Maximum Fluid Pressure (psi): 100

• Maximum Operating Temperature ( degree C): 100
• Maximum Operating Temperature ( degree F): 212

• Maximum Solid Size (cm): 0.4
• Maximum Solid Size (in): 0.16
• Maximum Solid Size (mm): 4

• Maximum Storage Temperature ( degree C): 27
• Maximum Storage Temperature ( degree F): 80

• Minimum Operating Temperature ( degree C): 0
• Minimum Operating Temperature ( degree F): 32

• Minimum Storage Temperature ( degree C): 16
• Minimum Storage Temperature ( degree F): 60

• Power Source

GG 24X817

GL-1 XL INJECTOR, REPLACEMENT

Graco 24X817 GL-1 XL Grease Injector, Replacement

Custom fit your system with Gracos adjustable GL-1 series grease injectors. Designed to meet the needs of each lube point, these systems provide years of reliable operation in the harshest operating environments.

• The GL-1 XL injectors are offered both as a stand-alone and a replacement injector for manifold systems for easy customization to a variety of applications
• Includes an adjustable hex head nut to make adjusting the output simple
• No vent holes and fully enclosed press fittings to prevent leaking lubricant
• Rugged, single piece uni-body design built for the harshest environments

• Model: GL-1
• Series: XL
• Adjustable: Adjustable

• Application: In-Plant Machinery, Off-Road Equipment

• Compatible Material: Grease
• Compatible Metering Device: Single Line Parallel

• Cycle Indicator: Visual

• Dispense Outlet Size (cm): 0.33
• Dispense Outlet Size (in): 0.13
• Dispense Outlet Size (mm): 3.3
• Dispense Outlet Thread Type: NPT

• For Use With: Single Line Parallel Automatic Lubrication Systems

• Maximum NLGI Grade: #2

• Maximum Operating Pressure (psi): 6000

• Maximum Output Volume (in cu ): 0.305

• Maximum Reset Pressure (psi): 1000

• Maximum Working Pressure (bar): 414
• Maximum Working Pressure (kPa): 41400
• Maximum Working Pressure (MPa): 41.4
• Maximum Working Pressure (psi): 6000

• Minimum Operating Pressure (psi): 1850
• Minimum Output Volume (in cu ): 0.035

• Outlet Size (cm): 0.9525
• Outlet Size (in): 3/8
• Outlet Size (mm): 9.525
• Outlet Thread Type: NPT

GG 24X427

CHEMSAFE PUMP, 307PT-P01A-PT3-PT-PT-PO

Graco 24X427 ChemSafe 307 Air Operated Double Diaphragm Plastic Pump with PTFE Seat, PTFE Ball, Overmolded PTFE Diaphragm, PTFE Fluid Path & NPT Port

Gracos ChemSafe pumps feature PTFE or UHMWPE (ultra high molecular weight polyethylene) corrosion-resistant fluid paths, which make them ideal for corrosive and abrasive chemicals. Theres no exposed metals and they can be configured in various materials to meet most abrasion, temperature, and chemical compatibility requirements. Plus theyre dead-head capable and achieve high flow rates while minimizing air consumption and operational noise.

• Max flow rate of 7.9 gpm (30 lpm)
• High quality machined design provides a precision fit and superior chemical containment compared to molded pumps
• Corrosion-resistant exterior with no exposed metal reduces maintenance, extends pump life and offers clean, safe operation
• Ideal for corrosive and abrasive liquids such as acids, fuels, glues, paints, resins, inks, or wastewater

• Model: ChemSafe
• Series: 307

• Air Inlet Size (in): 1/8
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Industrial

• Ball Material: PTFE

• Center Section Material: Polypropylene

• Compatible Material: Antifreeze, Detergent, Gel-Coat, Asphalt, Polyurethane, Windshield Washer Fluid, Diesel Exhaust Fluid, Water - Wastewater Treatment, Water - Wastewater Transfer, Food and Personal Care, Ink

• Connection Type: Threaded

• Diaphragm Compatible Material: PTFE
• Diaphragm Material: PTFE Overmold

• Fluid Inlet Size (cm): 0.9525
• Fluid Inlet Size (in): 3/8
• Fluid Inlet Size (mm): 9.525
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (cm): 0.9525
• Fluid Outlet Size (in): 3/8
• Fluid Outlet Size (mm): 9.525
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT
• Fluid Section Material: PTFE

• Manifold Configuration: Center Port
• Manifold O-Ring Material: PTFE
• Material: PTFE

• Maximum Air Consumption (SCFM): 9.3
• Maximum Air Pressure (bar): 7

• Maximum Air Pressure (kPa): 700
• Maximum Air Pressure (MPa): 0.7
• Maximum Air Pressure (psi): 100

• Maximum Cycle Rate (CPM): 610

• Maximum Flow Rate (GPM): 6.7
• Maximum Flow Rate (L/min): 25.4

• Maximum Fluid Pressure (bar): 7
• Maximum Fluid Pressure (kPa): 700
• Maximum Fluid Pressure (MPa): 0.7
• Maximum Fluid Pressure (psi): 100

• Maximum Fluid Pressure (bar): 7
• Maximum Fluid Pressure (kPa): 700
• Maximum Fluid Pressure (MPa): 0.7
• Maximum Fluid Pressure (psi): 100

• Maximum Operating Temperature ( degree C): 100
• Maximum Operating Temperature ( degree F): 212

• Maximum Solid Size (cm): 0.2
• Maximum Solid Size (in): 0.08
• Maximum Solid Size (mm): 2

• Minimum Operating Temperature ( degree C): 0
• Minimum Operating Temperature ( degree F): 32

• Minimum Storage Temperature ( degree C): 0
• Minimum Storage Temperature ( degree F): 32

• Power Source: Air

GG 24X770

GG 24X821

GG 24X429

CHEMSAFE PUMP, 205PT-P01A-PT3-PT-PT-PO

Graco 24X429 ChemSafe 205 Air Operated Double Diaphragm Plastic Pump with PTFE Seat, PTFE Ball, Overmolded PTFE Diaphragm, PTFE Fluid Path & NPT Port

Gracos ChemSafe pumps feature PTFE or UHMWPE (ultra high molecular weight polyethylene) corrosion-resistant fluid paths, which make them ideal for corrosive and abrasive chemicals. Theres no exposed metals and they can be configured in various materials to meet most abrasion, temperature, and chemical compatibility requirements. Plus theyre dead-head capable and achieve high flow rates while minimizing air consumption and operational noise.

• Max flow rate of 3.6 gpm (14 lpm)
• High quality machined design provides a precision fit and superior chemical containment compared to molded pumps
• Corrosion-resistant exterior with no exposed metal reduces maintenance, extends pump life and offers clean, safe operation
• Ideal for corrosive and abrasive liquids such as acids, fuels, glues, paints, resins, inks, or wastewater

• Model: ChemSafe
• Series: 205

• Air Inlet Size (in): 1/8
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Industrial

• Ball Material: PTFE

• Center Section Material: Polypropylene

• Compatible Material: Antifreeze, Detergent, Gel-Coat, Asphalt, Polyurethane, Windshield Washer Fluid, Diesel Exhaust Fluid, Water - Wastewater Treatment, Water - Wastewater Transfer, Food and Personal Care, Ink

• Connection Type: Threaded

• Diaphragm Compatible Material: PTFE
• Diaphragm Material: PTFE Overmold

• Fluid Inlet Size (cm): 0.635
• Fluid Inlet Size (in): 1/4
• Fluid Inlet Size (mm): 6.35
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (cm): 0.635
• Fluid Outlet Size (in): 1/4
• Fluid Outlet Size (mm): 6.35
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT
• Fluid Section Material: PTFE

• Manifold Configuration: Center Port
• Manifold O-Ring Material: PTFE
• Material: PTFE

• Maximum Air Consumption (SCFM): 4.8
• Maximum Air Pressure (bar): 7

• Maximum Air Pressure (kPa): 700
• Maximum Air Pressure (MPa): 0.7
• Maximum Air Pressure (psi): 100

• Maximum Cycle Rate (CPM): 375

• Maximum Flow Rate (GPM): 2.5
• Maximum Flow Rate (L/min): 9.5

• Maximum Fluid Pressure (bar): 7
• Maximum Fluid Pressure (kPa): 700
• Maximum Fluid Pressure (MPa): 0.7
• Maximum Fluid Pressure (psi): 100

• Maximum Fluid Pressure (bar): 7
• Maximum Fluid Pressure (kPa): 700
• Maximum Fluid Pressure (MPa): 0.7
• Maximum Fluid Pressure (psi): 100

• Maximum Operating Temperature ( degree C): 100
• Maximum Operating Temperature ( degree F): 212

• Maximum Solid Size (cm): 0.15
• Maximum Solid Size (in): 0.06
• Maximum Solid Size (mm): 1.5

• Minimum Operating Temperature ( degree C): 0
• Minimum Operating Temperature ( degree F): 32

• Minimum Storage Temperature ( degree C): 0
• Minimum Storage Temperature ( degree F): 32

• Power Source: Air

GG 24X421

CHEMSAFE PUMP, 1590PT-P01A-PT3-PT-PT-PO

Graco 24X421 ChemSafe 1590 Air Operated Double Diaphragm Plastic Pump with NPT Port

Graco's ChemSafe pumps feature PTFE or UHMWPE (ultra high molecular weight polyethylene) corrosion-resistant fluid paths, which make them ideal for corrosive and abrasive chemicals. There's no exposed metals and they can be configured in various materials to meet most abrasion, temperature, and chemical compatibility requirements. Plus they're dead-head capable and achieve high flow rates while minimizing air consumption and operational noise.

• Max flow rate of 85.2 gpm (322 lpm)
• High quality machined design provides a precision fit and superior chemical containment compared to molded pumps
• Corrosion-resistant exterior with no exposed metal reduces maintenance, extends pump life and offers clean, safe operation
• Ideal for corrosive and abrasive liquids such as acids, fuels, glues, paints, resins, inks, or wastewater

• Model: ChemSafe
• Series: 1590

• Air Inlet Size (in): 1/4
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Industrial

• Ball Material: PTFE

• Center Section Material: Polypropylene

• Compatible Material: Antifreeze, Detergent, Gel-Coat, Asphalt, Polyurethane, Windshield Washer Fluid, Diesel Exhaust Fluid, Water - Wastewater Treatment, Water - Wastewater Transfer, Food and Personal Care, Ink

• Connection Type: Threaded

• Diaphragm Compatible Material: PTFE
• Diaphragm Material: PTFE Overmold

• Fluid Inlet Size (cm): 3.81
• Fluid Inlet Size (in): 1-1/2
• Fluid Inlet Size (mm): 38.1
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (cm): 3.81
• Fluid Outlet Size (in): 1-1/2
• Fluid Outlet Size (mm): 38.1
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT
• Fluid Section Material: PTFE

• Manifold Configuration: Center Port
• Manifold O-Ring Material: PTFE
• Material: PTFE

• Maximum Air Consumption (SCFM): 46
• Maximum Air Pressure (bar): 7

• Maximum Air Pressure (kPa): 700
• Maximum Air Pressure (MPa): 0.7
• Maximum Air Pressure (psi): 100

• Maximum Cycle Rate (CPM): 230

• Maximum Flow Rate (GPM): 100
• Maximum Flow Rate (L/min): 379

• Maximum Fluid Pressure (bar): 7
• Maximum Fluid Pressure (kPa): 700
• Maximum Fluid Pressure (MPa): 0.7
• Maximum Fluid Pressure (psi): 100

• Maximum Fluid Pressure (bar): 7
• Maximum Fluid Pressure (kPa): 700
• Maximum Fluid Pressure (MPa): 0.7
• Maximum Fluid Pressure (psi): 100

• Maximum Operating Temperature ( degree C): 100
• Maximum Operating Temperature ( degree F): 212

• Maximum Solid Size (cm): 203
• Maximum Solid Size (in): 80
• Maximum Solid Size (mm): 2030

• Minimum Operating Temperature ( degree C): 0
• Minimum Operating Temperature ( degree F): 32

• Minimum Storage Temperature ( degree C): 0
• Minimum Storage Temperature ( degree F): 32

• Power Source: Air

GG 24X485

CHEMSAFE PUMP, 1590UH-P01A-UH3-UH-PT-PO

Graco 24X485 ChemSafe 1590 Air Operated Double Diaphragm Plastic Pump

• Model: ChemSafe
• Series: 1590

• Air Inlet Size (in): 1/4
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Industrial

• Ball Material: PTFE

• Center Section Material: Polypropylene

• Compatible Material: Antifreeze, Detergent, Gel-Coat, Asphalt, Polyurethane, Windshield Washer Fluid, Diesel Exhaust Fluid, Water - Wastewater Treatment, Water - Wastewater Transfer, Food and Personal Care, Ink

• Connection Type: Threaded

• Diaphragm Compatible Material: PTFE
• Diaphragm Material: PTFE Overmold

• Fluid Inlet Size (cm): 3.81
• Fluid Inlet Size (in): 1-1/2
• Fluid Inlet Size (mm): 38.1
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (cm): 3.81
• Fluid Outlet Size (in): 1-1/2
• Fluid Outlet Size (mm): 38.1
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT
• Fluid Section Material: UHMWPE

• Manifold Configuration: Center Port
• Manifold O-Ring Material: PTFE
• Material: UHMWPE

• Maximum Air Consumption (SCFM): 46
• Maximum Air Pressure (bar): 7

• Maximum Air Pressure (kPa): 700
• Maximum Air Pressure (MPa): 0.7
• Maximum Air Pressure (psi): 100

• Maximum Cycle Rate (CPM): 230

• Maximum Flow Rate (GPM): 100
• Maximum Flow Rate (L/min): 379

• Maximum Fluid Pressure (bar): 7
• Maximum Fluid Pressure (kPa): 700
• Maximum Fluid Pressure (MPa): 0.7
• Maximum Fluid Pressure (psi): 100

• Maximum Fluid Pressure (bar): 7
• Maximum Fluid Pressure (kPa): 700
• Maximum Fluid Pressure (MPa): 0.7
• Maximum Fluid Pressure (psi): 100

• Maximum Operating Temperature ( degree C): 70
• Maximum Operating Temperature ( degree F): 158

• Maximum Solid Size (cm): 203
• Maximum Solid Size (in): 80
• Maximum Solid Size (mm): 2030

• Minimum Operating Temperature ( degree C): 0
• Minimum Operating Temperature ( degree F): 32

• Minimum Storage Temperature ( degree C): 0
• Minimum Storage Temperature ( degree F): 32

• Power Source: Air

GG 24X636

P2 EXTREME GUN,AUTOMATIC

Graco 24X636 Automatic Probler P2 Extreme Dispense Gun

The Probler P2 Extreme Gun is lightweight and easy to mount to automation platforms - even in difficult spraying positions. Its double piston design provides more than 300 pounds (136 kg) of mix chamber movement. The Probler P2 Extreme reduces maintenance, increases spraying uptime and is easy to use in high production environments.

Application: For high output spray polyurethane foam and polyurea applications

• The P2 Extreme elite:

  • Extreme wear stainless steal side blox and mix chamber housings
  • Alternate side block hose routings
  • Allows filters to be easily removed

• Easy daily maintenance

• Easy-to-replace mix chamber insert

  Anti-crossover design virtually eliminates possibility of material entering the air piston

• Application: Foam, Polyurea

• Compatible Material: Solventborne, High Solids, Xirallic, Metallics, Varnish, CARC

GG 24X822

GG 24X828

GG 24X423

CHEMSAFE PUMP, 1040PT-P01A-PT3-PT-PT-PO

Graco 24X423 ChemSafe 1040 Air Operated Double Diaphragm Pump with PTFE Seat, PTFE Ball, Overmolded PTFE Diaphragm, PTFE Fluid Path & NPT Port

Gracos ChemSafe pumps feature PTFE or UHMWPE (ultra high molecular weight polyethylene) corrosion-resistant fluid paths, which make them ideal for corrosive and abrasive chemicals. Theres no exposed metals and they can be configured in various materials to meet most abrasion, temperature, and chemical compatibility requirements. Plus theyre dead-head capable and achieve high flow rates while minimizing air consumption and operational noise.

• Max flow rate of 37.5 gpm (142 lpm)
• High quality machined design provides a precision fit and superior chemical containment compared to molded pumps
• Corrosion-resistant exterior with no exposed metal reduces maintenance, extends pump life and offers clean, safe operation
• Ideal for corrosive and abrasive liquids such as acids, fuels, glues, paints, resins, inks, or wastewater

• Model: ChemSafe
• Series: 1040

• Air Inlet Size (in): 1/4
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Industrial

• Ball Material: PTFE

• Center Section Material: Polypropylene

• Compatible Material: Antifreeze, Detergent, Gel-Coat, Asphalt, Polyurethane, Windshield Washer Fluid, Diesel Exhaust Fluid, Water - Wastewater Treatment, Water - Wastewater Transfer, Food and Personal Care, Ink

• Connection Type: Threaded

• Diaphragm Compatible Material: PTFE
• Diaphragm Material: PTFE Overmold

• Fluid Inlet Size (cm): 2.54
• Fluid Inlet Size (in): 1
• Fluid Inlet Size (mm): 25.4
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (cm): 2.54
• Fluid Outlet Size (in): 1
• Fluid Outlet Size (mm): 25.4
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT
• Fluid Section Material: PTFE

• Manifold Configuration: Center Port
• Manifold O-Ring Material: PTFE
• Material: PTFE

• Maximum Air Consumption (SCFM): 46
• Maximum Air Pressure (bar): 7

• Maximum Air Pressure (kPa): 700
• Maximum Air Pressure (MPa): 0.7
• Maximum Air Pressure (psi): 100

• Maximum Cycle Rate (CPM): 260

• Maximum Flow Rate (GPM): 39
• Maximum Flow Rate (L/min): 148

• Maximum Fluid Pressure (bar): 7
• Maximum Fluid Pressure (kPa): 700
• Maximum Fluid Pressure (MPa): 0.7
• Maximum Fluid Pressure (psi): 100

• Maximum Fluid Pressure (bar): 7
• Maximum Fluid Pressure (kPa): 700
• Maximum Fluid Pressure (MPa): 0.7
• Maximum Fluid Pressure (psi): 100

• Maximum Operating Temperature ( degree C): 100
• Maximum Operating Temperature ( degree F): 212

• Maximum Solid Size (cm): 203
• Maximum Solid Size (in): 80
• Maximum Solid Size (mm): 2030

• Minimum Operating Temperature ( degree C): 0
• Minimum Operating Temperature ( degree F): 32

• Minimum Storage Temperature ( degree C): 0
• Minimum Storage Temperature ( degree F): 32

• Power Source: Air

GG 24X561

GG 24X829

GG 24X568

GG 24X482

GG 24X448

KIT, ENCODER, 1000PPR, 10MM

Graco 24X448 Encoder 1000Ppr 10Mm Kit

KIT INCLUDES: ENCODER, INCREMENTAL [QTY. 1], CABLE, M12, 8-PIN, 10.0M [QTY. 1], SCREW, MACHINE [QTY. 3], BRACKET, MOUNTING, ENCODER [QTY. 1]

GG 24X570

GG 24X834

GG 24X832

KIT, CASCADE

GG 24X856

GG 24X840

GG 24X885

GG 24X882

GG 24X890

GG 24Y192

DURA-FLO XL PUMP,34:1,(24 CM SST),LH

Graco 24Y192 35:1 - 580cc Dura-Flo Pump with XL 10000 Air Motor, Severe Duty Stainless Steel Construction

Graco Supply Pumps reliably deliver one-component sealants, adhesives and other low to medium-viscosity materials to metering and dispensing systems. Maximize your plant's production capacity.

Application: Long-lasting durability - Dura-Flo pumps are a time-tested, proven performer

• XL 1000 Air Motor

  • Modular design for easier maintenance
  • Rugged body armor won't rust or dent
  • Highest technology air motor on the market
• 580cc Dura-Flo Lower

  • Severe Duty coatings on rods and cylinder Extends production time

• Standard Threaded Coupler -

Replaceable 1 1/2" -11 1/2 NPT Male Outlet Fitting

• Reduces repair costs

GG 24Y207

DURA-FLO 2400 PUMP, XL, 34:1, (24 CM CS)

Graco 24Y207 35:1 - 580cc Dura-Flo Pump with XL 10000 Air Motor, Severe Duty Carbon Steel Construction

Graco Supply Pumps reliably deliver one-component sealants, adhesives and other low to medium-viscosity materials to metering and dispensing systems. Maximize your plants production capacity.

• XL 1000 Air Motor


  Modular design for easier maintenance

  Rugged body armor wont rust or dent

  Highest technology air motor on the market

• 580cc Dura-Flo Lower


  Severe Duty coatings on rods and cylinder Extends production time

• Standard Threaded Coupler -

• Replaceable Seat

  Minimizes service costs

• Cast Outlet and Inlet Housing

  Improves structural integrity




  • Model: Dura-Flo
  • Series: XL 2400
  • Air Inlet Size (in): 1
  • Air Inlet Size (mm): 25.4000
  • Air Inlet Thread Gender: Female
  • Air Inlet Thread Type: NPT
  • Application: Bonding, Sealing, Gasketing, Potting, Encapsulation, Molding, Spray, Fluid Transfer, Unloading, Underfill
  • Fluid Outlet Size (in): 1-1/2
  • Fluid Outlet Thread Gender: Male
  • Fluid Outlet Thread Type: NPT
  • Material: Carbon Steel
  • Maximum Air Inlet Pressure (bar): 7
  • Maximum Air Inlet Pressure (kPa): 690
  • Maximum Air Inlet Pressure (psi): 100
  • Maximum Continuous Cycle Rate (CPM): 60
  • Maximum Flow Rate (GPM): 9.2
  • Maximum Flow Rate (L/min): 34.8
  • Maximum Operating Temperature ( degree C): 82
  • Maximum Operating Temperature ( degree F): 180
  • Maximum Working Pressure (bar): 234
  • Maximum Working Pressure (kPa): 23400
  • Maximum Working Pressure (MPa): 23.4
  • Maximum Working Pressure (psi): 3400
  • Power Type: Pneumatic
  • Pump Ratio: 35:1

GG 24Y206

DURA-FLO 2400 PUMP,XL,34:1,(24 CM SST),RH

Graco 24Y206 35:1 - 580cc Dura-Flo Pump with XL 10000 Air Motor, Severe Duty, Right Hand Stainless Steel Construction

Graco Supply Pumps reliably deliver one-component sealants, adhesives and other low to medium-viscosity materials to metering and dispensing systems. Maximize your plant's production capacity.

Application: Long-lasting durability - Dura-Flo pumps are a time-tested, proven performer

• XL 1000 Air Motor

  • Modular design for easier maintenance
  • Rugged body armor won't rust or dent
  • Highest technology air motor on the market
• 580cc Dura-Flo Lower

  • Severe Duty coatings on rods and cylinder Extends production time

• Standard Threaded Coupler -

Replaceable 1 1/2" -11 1/2 NPT Male Outlet Fitting

• Reduces repair costs

GG 24Y212

DURA-FLO XL PUMP, 47:1, (18 CM CSTL)

Graco 24Y212 47:1 - 430cc Dura-Flo Pump with XL 10000 Air Motor, Severe Duty, Right Hand Carbon Steel Construction

Graco Supply Pumps reliably deliver one-component sealants, adhesives and other low to medium-viscosity materials to metering and dispensing systems. Maximize your plants production capacity.

• XL 1000 Air Motor


  Modular design for easier maintenance

  Rugged body armor wont rust or dent

  Highest technology air motor on the market

• 430cc Dura-Flo Lower


  Severe Duty coatings on rods and cylinder Extends production time

• Standard Threaded Coupler -

• Replaceable Seat

  Minimizes service costs

• Cast Outlet and Inlet Housing

  Improves structural integrity




  • Model: Dura-Flo
  • Series: XL 1800
  • Air Inlet Size (in): 1
  • Air Inlet Size (mm): 25.4
  • Air Inlet Thread Gender: Female
  • Air Inlet Thread Type: NPT
  • Application: Bonding, Sealing, Gasketing, Potting, Encapsulation, Molding, Spray, Fluid Transfer, Unloading, Underfill
  • Fluid Outlet Size (in): 1-1/2
  • Fluid Outlet Size (mm): 38.1
  • Fluid Outlet Thread Gender: Male
  • Fluid Outlet Thread Type: NPT
  • Material: Carbon Steel
  • Maximum Air Inlet Pressure (bar): 6.9
  • Maximum Air Inlet Pressure (kPa): 690
  • Maximum Air Inlet Pressure (psi): 100
  • Maximum Continuous Cycle Rate (CPM): 60
  • Maximum Flow Rate (GPM): 6.9
  • Maximum Flow Rate (L/min): 26.12
  • Maximum Operating Temperature ( degree C): 66
  • Maximum Operating Temperature ( degree F): 150
  • Maximum Working Pressure (bar): 310
  • Maximum Working Pressure (kPa): 31000
  • Maximum Working Pressure (MPa): 31
  • Maximum Working Pressure (psi): 4500
  • Portable: Non-Portable
  • Power Type: Pneumatic
  • Pump Ratio: 47:1

GG 24Y211

DURA-FLO 1800 PUMP, XL, 47:1, (18 CM CSTL)

Graco 24Y211 47:1 - 430cc Dura-Flo Pump with XL 10000 Air Motor, Severe Duty, Long Carbon Steel Construction

Graco Supply Pumps reliably deliver one-component sealants, adhesives and other low to medium-viscosity materials to metering and dispensing systems. Maximize your plants production capacity.

• XL 1000 Air Motor


  Modular design for easier maintenance

  Rugged body armor wont rust or dent

  Highest technology air motor on the market

• 430cc Dura-Flo Lower


  Severe Duty coatings on rods and cylinder Extends production time

• Standard Threaded Coupler -

• Replaceable Seat

  Minimizes service costs

• Cast Outlet and Inlet Housing

  Improves structural integrity




  • Air Inlet Size (in): 1
  • Air Inlet Size (mm): 25.4
  • Air Inlet Thread Gender: Female
  • Air Inlet Thread Type: NPT
  • Application: Bonding, Sealing, Gasketing, Potting, Encapsulation, Molding, Spray, Fluid Transfer, Unloading, Underfill
  • Fluid Outlet Size (in): 1-1/2
  • Fluid Outlet Size (mm): 38.1
  • Fluid Outlet Thread Gender: Male
  • Fluid Outlet Thread Type: NPT
  • Material: Carbon Steel
  • Maximum Air Inlet Pressure (bar): 6.9
  • Maximum Air Inlet Pressure (kPa): 690
  • Maximum Air Inlet Pressure (psi): 100
  • Maximum Continuous Cycle Rate (CPM): 60
  • Maximum Flow Rate (GPM): 6.9
  • Maximum Flow Rate (L/min): 26.12
  • Maximum Operating Temperature ( degree C): 66
  • Maximum Operating Temperature ( degree F): 150
  • Maximum Working Pressure (bar): 310
  • Maximum Working Pressure (kPa): 31000
  • Maximum Working Pressure (MPa): 31
  • Maximum Working Pressure (psi): 4500
  • Portable: Non-Portable
  • Power Type: Pneumatic
  • Pump Ratio: 47:1

GG 24Y240

REACTOR HEATED HOSE, X-WRAP, 3/8, 50', RT

Graco 24Y240 50 ft x 3/8 in Heated Hose, 2000 psi, RTD, Xtreme-Wrap, Reactor 2

Graco's heated hoses are designed specifically for use with Reactor Equipment. Hoses are a key component to the total system, making it important to achieve accurate and uniform heating for the best application possible.

• New multi-strand copper heating element has greatly increased hose quality:

  Provides 10-times* the flex life compared to previous flat copper heating element

  Long-term, even heating without hot spots

  Backwards compatible with existing Reactor heated hoses

  • New Xtreme-Wrap Scuff Guard

    Form fitting to the hose, no more baggy excess material

    Made from urethane coated ballistic nylon for puncture and tear resistance, abrasion protection, and oil and water resistance

    Sheds surface moisture and wont absorb water to weigh down the hose bundle, will not freeze solid in cold temperatures

    Hook and Loop enclosure used on the entire length of the hose for easy access to the hoses, fittings, and fluid temperature sensors

    • Joint Protectors

      Joint Protectors provide additional protection at the most vulnerable section of the hose: the electrical connections, hose fittings, and fluid temperature sensors. All 50 ft (15 m) hoses with the new Xtreme-Wrap will come with one Joint Protector.

      • Covered with proprietary butyl cover for protection against moisture sensitive isocyanate
      • Hoses are covered with foam insulation for heat retention
      • Different fitting sizes on the isocyanate and resin hoses prevent accidentally connecting the wrong hoses together
      • Hoses use custom designed splice kit to electrically connect hoses without having to run copper under the fittings
      • Helix-design whip hose uses braided copper wires for added flexibility and longer life
      • Resistance Temperature Detector (RTD)

        Graco's latest advanced controls on Reactor 2 and Integrated Reactor utilize RTD technology. RTDs offer the highest accuracy and the best day-to-day repeatability of material temperatures in your hose. RTD technology allows the machine to automatically shut down if the sensor is damaged, which saves wasted time and materials.




        • Model: Reactor 2
        • Series: Xtreme Wrap
        • Compatible Sprayer: Reactor 2
        • For Use With: Plural Component Proportioners
        • Hose Heating Type: External Heated
        • Hose Inside Diameter (in): 3/8
        • Hose Inside Diameter (mm): 9.525
        • Hose Length (ft): 50
        • Hose Length (m): 15.2
        • Inside Diameter (in): 3/8
        • Maximum Working Pressure (bar): 138
        • Maximum Working Pressure (kPa): 13800
        • Maximum Working Pressure (MPa): 13.8
        • Maximum Working Pressure (psi): 2000

GG 24Y241

REACTOR HEATED HOSE, X-WRAP, 3/8, 50', RT

Graco 24Y241 50 ft x 3/8 in Heated Hose, 3500 psi, RTD, Xtreme-Wrap, Reactor 2

Graco's heated hoses are designed specifically for use with Reactor Equipment. Hoses are a key component to the total system, making it important to achieve accurate and uniform heating for the best application possible.

• New multi-strand copper heating element has greatly increased hose quality:

  Provides 10-times* the flex life compared to previous flat copper heating element

  Long-term, even heating without hot spots

  Backwards compatible with existing Reactor heated hoses

  • New Xtreme-Wrap Scuff Guard

    Form fitting to the hose, no more baggy excess material

    Made from urethane coated ballistic nylon for puncture and tear resistance, abrasion protection, and oil and water resistance

    Sheds surface moisture and wont absorb water to weigh down the hose bundle, will not freeze solid in cold temperatures

    Hook and Loop enclosure used on the entire length of the hose for easy access to the hoses, fittings, and fluid temperature sensors

    • Joint Protectors

      Joint Protectors provide additional protection at the most vulnerable section of the hose: the electrical connections, hose fittings, and fluid temperature sensors. All 50 ft (15 m) hoses with the new Xtreme-Wrap will come with one Joint Protector.

      • Covered with proprietary butyl cover for protection against moisture sensitive isocyanate
      • Hoses are covered with foam insulation for heat retention
      • Different fitting sizes on the isocyanate and resin hoses prevent accidentally connecting the wrong hoses together
      • Hoses use custom designed splice kit to electrically connect hoses without having to run copper under the fittings
      • Helix-design whip hose uses braided copper wires for added flexibility and longer life
      • Resistance Temperature Detector (RTD)

        Graco's latest advanced controls on Reactor 2 and Integrated Reactor utilize RTD technology. RTDs offer the highest accuracy and the best day-to-day repeatability of material temperatures in your hose. RTD technology allows the machine to automatically shut down if the sensor is damaged, which saves wasted time and materials.




        • Model: Reactor 2
        • Series: Xtreme Wrap
        • Compatible Sprayer: Reactor 2
        • For Use With: Plural Component Proportioners
        • Hose Heating Type: External Heated
        • Hose Inside Diameter (in): 3/8
        • Hose Inside Diameter (mm): 9.525
        • Hose Length (ft): 50
        • Hose Length (m): 15.2
        • Inside Diameter (in): 3/8
        • Maximum Working Pressure (bar): 241
        • Maximum Working Pressure (kPa): 24100
        • Maximum Working Pressure (MPa): 24.1
        • Maximum Working Pressure (psi): 3500

GG 24Y262

GG 24Y263

GG 24Y264

GG 24Y307

KIT, CONTROLLER, SOLVENT-BORNE

Graco 24Y307 Pro Xpc Auto Controller, Solventborne

GG 24Y335

GG 24Y343

GG 24Y498

LUBEPRO H1900 PUMP

Graco 24Y498 LubePro H1900 Horizontal Oil Pump - NPT

Without proper lubrication your factory's machines can suffer from downtime and reduced life, which impacts your company's bottom line. Avoid the hassle. LubePro series leverages the same proven quality and leading technology as Graco's Fire-Ball pump - the leader in durability and quality for over 50 years.

• LubePro H1900 is compatible with GL-42 and GL-43 injectors
• Pressure Ratio of 19:1
• H1900 delivers a greater output than competitive models at 3.0 in cu (49.2 cm cu ) per stroke
• Pneumatic power makes it easy to install into existing air line
• Optional Low Level Detection available, factory installed
• Built with high-quality seals tested to outperform the competition
• Optimally lubricates while your machines are running
• Provides accurate, reliable lubrication for every lube point
• Provides higher lube output and faster lubrication cycle

• Model: LubePro
• Series: H1900

• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35
• Air Inlet Thread Type: NPT

• Application: In-Plant Machinery

• Compatible Material: Oil
• Compatible Metering Device: Series Progressive, Single Line Parallel

• Fluid Outlet Size (in): 0.25
• Fluid Outlet Size (mm): 6.3500
• Fluid Outlet Thread Type: NPT

• Maximum Air Inlet Pressure (bar): 12.76
• Maximum Air Inlet Pressure (kPa): 1276
• Maximum Air Inlet Pressure (psi): 185

• Maximum Fill Inlet Pressure (bar): 5.52
• Maximum Fill Inlet Pressure (kPa): 552
• Maximum Fill Inlet Pressure (psi): 80

• Maximum Working Pressure (bar): 241
• Maximum Working Pressure (kPa): 24100
• Maximum Working Pressure (MPa): 24.1
• Maximum Working Pressure (psi): 3500

• Minimum cST Grade (cST): 40

• Overall Width (cm): 39.4
• Overall Width (in): 15.5
• Overall Width (mm): 394

• Power Type: Pneumatic

GG 24Y472

KIT, REPAIR, PISTON, PUMP

Graco 24Y472 ProXChange Pump

On-the-job pump repairs are fast and easy with the ProXChange Pump Replacement System. In 4 simple steps, you can remove and replace the pump cartridge. With a spare ProXChange pump on-hand, youll never have a down day.

• Exceptional durability and long lasting piston pump
• Eliminate service center repair costs and travel time expenses
• Built-in hex nut slot on frame of sprayer for easy pump removal
• Modular in design for quick and easy repair
• Simply slide front plate up and remove entire pump to replace pump kit
• No tools required

• Model: ProXChange

• For Use With: Magnum A60 ProPlus, Magnum A80 ProPlus, Magnum ProS19 ProPlus, Magnum ProS21 ProPlus

• Includes: Labels (2), Manual, Module, Cap,

• Number of Pieces: 6

GG 24Y548

GG 24Y546

GG 24Y661

GG 24Y678

REACTOR HEATED HOSE, X-WRAP, 3/8, 50'

Graco 24Y678 50 ft x 3/8 in Heated Hose, 2000 psi, Thermocouple, Xtreme-Wrap, Reactor 1

Graco's heated hoses are designed specifically for use with Reactor Equipment. Hoses are a key component to the total system, making it important to achieve accurate and uniform heating for the best application possible.

• New multi-strand copper heating element has greatly increased hose quality:

  Provides 10-times* the flex life compared to previous flat copper heating element

  Long-term, even heating without hot spots

  Backwards compatible with existing Reactor heated hoses

  • New Xtreme-Wrap Scuff Guard

    Form fitting to the hose, no more baggy excess material

    Made from urethane coated ballistic nylon for puncture and tear resistance, abrasion protection, and oil and water resistance

    Sheds surface moisture and wont absorb water to weigh down the hose bundle, will not freeze solid in cold temperatures

    Hook and Loop enclosure used on the entire length of the hose for easy access to the hoses, fittings, and fluid temperature sensors

    • Joint Protectors

      Joint Protectors provide additional protection at the most vulnerable section of the hose: the electrical connections, hose fittings, and fluid temperature sensors. All 50 ft (15 m) hoses with the new Xtreme-Wrap will come with one Joint Protector.

      • Covered with proprietary butyl cover for protection against moisture sensitive isocyanate
      • Hoses are covered with foam insulation for heat retention
      • Different fitting sizes on the isocyanate and resin hoses prevent accidentally connecting the wrong hoses together
      • Hoses use custom designed splice kit to electrically connect hoses without having to run copper under the fittings
      • Helix-design whip hose uses braided copper wires for added flexibility and longer life




      • Model: Reactor 1
      • Series: Xtreme Wrap
      • Compatible Sprayer: Reactor 1
      • For Use With: Plural Component Proportioners
      • Hose Heating Type: External Heated
      • Hose Inside Diameter (in): 3/8
      • Hose Inside Diameter (mm): 9.525
      • Hose Length (ft): 50
      • Hose Length (m): 15.2
      • Inside Diameter (in): 3/8
      • Maximum Working Pressure (bar): 138
      • Maximum Working Pressure (kPa): 13800
      • Maximum Working Pressure (MPa): 13.8
      • Maximum Working Pressure (psi): 2000

GG 24Y771

GG 24Y679

REACTOR HEATED HOSE, X-WRAP, 3/8, 50'

Graco 24Y679 50 ft x 3/8 in Heated Hose, 3500 psi, Thermocouple, Xtreme-Wrap, Reactor 1

Graco's heated hoses are designed specifically for use with Reactor Equipment. Hoses are a key component to the total system, making it important to achieve accurate and uniform heating for the best application possible.

• New multi-strand copper heating element has greatly increased hose quality:
  • Provides 10-times* the flex life compared to previous flat copper heating element
  • Long-term, even heating without hot spots
  • Backwards compatible with existing Reactor heated hoses
• New Xtreme-Wrap Scuff Guard
  • Form fitting to the hose, no more baggy excess material
  • Made from urethane coated ballistic nylon for puncture and tear resistance, abrasion protection, and oil and water resistance
  • Sheds surface moisture and won't absorb water to weigh down the hose bundle, will not freeze solid in cold temperatures
  • Hook and Loop enclosure used on the entire length of the hose for easy access to the hoses, fittings, and fluid temperature sensors
• Joint Protectors
  • Joint Protectors provide additional protection at the most vulnerable section of the hose: the electrical connections, hose fittings, and fluid temperature sensors. All 50 ft (15 m) hoses with the new Xtreme-Wrap will come with one Joint Protector.
• Covered with proprietary butyl cover for protection against moisture sensitive isocyanate
• Hoses are covered with foam insulation for heat retention
• Different fitting sizes on the isocyanate and resin hoses prevent accidentally connecting the wrong hoses together
• Hoses use custom designed splice kit to electrically connect hoses without having to run copper under the fittings
• Helix-design whip hose uses braided copper wires for added flexibility and longer life

• Model: Reactor 1
• Series: Xtreme Wrap

• Compatible Sprayer: Reactor 1

• For Use With: Plural Component Proportioners

• Hose Heating Type: External Heated
• Hose Inside Diameter (in): 3/8
• Hose Inside Diameter (mm): 9.525
• Hose Length (ft): 50
• Hose Length (m): 15.2

• Inside Diameter (in): 3/8

• Maximum Working Pressure (bar): 241
• Maximum Working Pressure (kPa): 24100
• Maximum Working Pressure (MPa): 24.1
• Maximum Working Pressure (psi): 3500

GG 24Y772

GG 24Y778

KIT,MODULE,GCA,MCM,SALEABLE

KIT INCLUDES: MODULE, GCA, MCM [QTY. 1], KIT INCLUDES: HEAD, RATIO, CATALYST [QTY. 1], KIT, AIR CAP, INTERNAL MIX [QTY. 1], RING, LOCKING [QTY. 1], SEAL, RATIO, CATALYST [QTY. 1], FITTING, 1/8 NPT X 1/4 TUBE, SS [QTY. 1], HOSE, TUBNG, P.E., .250OD NATURA [QTY. 2]

GG 24Y801

GG 24Y803

GG 24Y827

GG 24Y842

GG 24Y846

GG 24Y849

KIT, LEAK DETECTOR, SOLOTECH

Graco 24Y849 SoloTech Leak Detector Kit

GG 24Y864

SD SERIES 5 REEL, CORD, BLK, TRIPLUG, GFCI

Graco 24Y864 SD 5 Series 120 Volt Cord Reel - Tri-Plug GFCI Industrial Receptacle - 50 ft (15 m), 12 AWG, 15 Amp Cord - Black

Organize your work space for a safer, more productive work environment. Make Graco your single source for your entire reel bank.

• Heavy-duty steel construction, SD Series size 5.
• 50 foot cord and features a 5 foot lead-in cable.
• Duplex GFCI receptacle
• Heavy-Duty Pedestal - High-strength steel construction with rolled edges and ribbed stress points that wont flex or twist.

• Model: SD
• Series: 5

• Cord Length (ft): 50
• Cord Length (m): 15

• Includes: Tri-Plug GFCI Industrial Receptacle

• Insulation Type: SJOOW

• Maximum Current (A): 15

• Maximum Operating Temperature ( degree C): 50
• Maximum Operating Temperature ( degree F): 122

• Overall Height (cm): 37.59
• Overall Height (in): 14.8
• Overall Height (mm): 375.9
• Overall Length (cm): 35.2
• Overall Length (in): 13.84
• Overall Length (mm): 352
• Overall Width (cm): 11.938
• Overall Width (in): 4.7
• Overall Width (mm): 119.38

• Power Cord Connect Type: NEMA 5-15P

• Reel Color: Black

GG 24Y870

SD SERIES 5 REEL, LIGHT, BLK, LED (110V)

Graco 24Y870 SD 5 Series 120 Volt Light Reel - LED Light - 50 ft (15 m), 16 AWG, <1 Amp Cord - Black

The SD 5 and SD 10 Series Cord and Light Reels allow you to organize your work space for a safer, more productive work environment. Choose from 35, 50 and 95 foot (11, 15, 29 meter) options

to fit your shop perfectly. Make Graco your single source for your entire reel bank.

Application: Ideal for automotive dealerships, fast lube centers, service shops, heavy-duty dealerships, fleet service facilities, in-plant, lube truck, mining and more.

• Heavy-duty steel construction, SD Series size 5.
• 50 foot cord and features a 5 foot lead-in cable.
• LED light
• Heavy-Duty Pedestal

  High-strength steel construction with rolled edges and ribbed stress points that won't flex or twist.




  • Model: SD
  • Series: 5
  • Cord Length (ft): 50
  • Cord Length (m): 15
  • Includes: LED Light
  • Insulation Type: SJTOW
  • Maximum Current (A): 0.05
  • Maximum Operating Temperature ( degree C): 40
  • Maximum Operating Temperature ( degree F): 104
  • Overall Height (cm): 37.59
  • Overall Height (in): 14.8
  • Overall Height (mm): 375.9
  • Overall Length (cm): 35.2
  • Overall Length (in): 13.84
  • Overall Length (mm): 352
  • Overall Width (cm): 11.938
  • Overall Width (in): 4.7
  • Overall Width (mm): 119.38
  • Power Cord Connect Type: NEMA 5-15P
  • Reel Color: Black

GG 24Y937

MANIFOLD,ASSY,CC,2 VALVE,LP,CIRC

Graco 24Y937 2 Valve SST Low Pressure Circulating Valve

Low Pressure Non-Circulating Valve

• Compatible Material: CARC, High Solids, Metallics, Solventborne, Stains, Topcoats, Varnish, Waterborne, Xirallic

GG 24Y936

MANIFOLD, ASSY, CC, 2 VALVE, LP

Graco 24Y936 2 Valve SST Low Pressure Non-Circulating Valve

Low Pressure Non-Circulating Valve

GG 24Y938

MANIFOLD,ASSY,CC,3 VALVE,LP

Graco 24Y938 3 Valve SST Low Pressure Non-Circulating Valve

Low Pressure Non-Circulating Valve

GG 24Y939

MANIFOLD,ASSY,CC,3 VALVE,LP,CIRC

Graco 24Y939 3 Valve SST Low Pressure Circulating Valve

Low Pressure Non-Circulating Valve

GG 24Y940

MANIFOLD,ASSY,CC,4 VALVE,LP

Graco 24Y940 4 Valve SST Low Pressure Non-Circulating Valve

GG 24Y942

MANIFOLD,ASSY,CC,5 VALVE,LP

Graco 24Y942 5 Valve SST Low Pressure Non-Circulating Valve

GG 24Y943

MANIFOLD,ASSY,CC,5 VALVE,LP,CIRC

Graco 24Y943 5 Valve SST Low Pressure Circulating Valve

GG 24Z014

PROMIX 2KE PROPORTIONER, METER, ACID

Graco 24Z014 ProMix 2KE Acid Catalyst Meter, 3 color/1 catalyst, IS, intrinsically safe alternator power

The ProMix 2KE meter-based system manages tough acid catalyst materials, such as conversion varnish for cabinetry and bar counter tops. The compact, entry-level proportioner easily handles strong acid catalysts with its corrosion resistant fluid section and smart fluid plate.

• Made with durable, high grade, stainless steel components like gears with ceramic bearings, the G3000A meter gauges the exact mix ratio while withstanding corrosion.
• Choose between pump-based or meter-based plural component systems with mix ratios up to 30:1
• Stay on ratio within predefined tolerance limits, down to plus/minus 02% with the pump version, plus/minus 01% with meter
• Easy-to-use LCD display allows you to track material usage, display mix ratio, program maintenance reminders operate, control operation functions and more
