GRACO INC. S10595

GG 25A106

GG 25A116

GG 25B000

GG 25B007

GG 25B009

GG 25B018

GG 25C216

GG 25C478

GG 25F172

GUN, AUTO, HVLP, .055

Graco 25F172 Stellair Automatic Air Spray Gun, HVLP, 0.055 in (1.4 mm) Nozzle for General Industry

High volume low pressure (HVLP) air spray gun produces stellar results on an automated paint line or in a robotic spray booth.

• High volume low pressure (HVLP) air spray produces a controlled, low velocity spray pattern that reduces bounce back and overspray, while meeting environmental regulations.
• General industry air caps and nozzles produce a uniform, high quality spray pattern with low atomizing pressure.
• Patented spray pattern alignment and pathing tool ensures accurate and repeatable spray angle. It is easily attached and detached from the gun to keep production moving.
• Small and light size does not weigh down or wear out robot arms, reciprocators or flat line machines.
• Direct stainless steel fluid path cuts the amount of solvent needed to flush the gun, reducing VOC (volatile organic compound) emissions.

• Application: General Industry
• Applicator Type: Automatic

• Body Material: Metal

• Compatible Material: Adhesives, Ceramics, Fast-Set, High Solids, Sealants, Solventborne Paints, Stain, UV Coating, Waterborne

• Fluid Adjustment Knob: N/A
• Fluid Orifice Size (in): 0.055
• Fluid Orifice Size (mm): 1.4

• Gun Model: Stellair
• Gun Series: Automatic
• Gun Type: HVLP Gun
• Gun Weight (g): 430
• Gun Weight (lb): 1

• Manifold Type: Not Included

• Maximum Air Pressure (bar): 7

• Maximum Air Pressure (MPa): 0.7
• Maximum Air Pressure (psi): 100

• Maximum Flow Rate (oz/min): 18

• Maximum Fluid Temperature ( degree C): 49
• Maximum Fluid Temperature ( degree F): 120

• Maximum Fluid Temperature ( degree C): 49
• Maximum Fluid Temperature ( degree F): 120

• Maximum Fluid Working Pressure (bar): 21
• Maximum Fluid Working Pressure (MPa): 2.1
• Maximum Fluid Working Pressure (psi): 300

• Minimum Air Inlet Pressure (bar): 3.4
• Minimum Air Inlet Pressure (MPa): 0.34
• Minimum Air Inlet Pressure (psi): 50

• Needle Tip Material: PEEK
• Nozzle Size (in): 0.055
• Nozzle Size (mm): 1.4

• Overall Height (in): 1.9
• Overall Height (mm): 48.3
• Overall Length (in): 5.10
• Overall Length (mm): 129.5
• Overall Width (in): 1.63
• Overall Width (mm): 41.4

GG 25N362

GG 25P394

KIT, DATA TRAK, AGITATOR

Graco 25P394 DataTrak, Air Motor Speed Monitoring Kit

GG 25U346

EGP TRANSFER PUMP, 115V, 8GPM, 120PSI

Graco 25U346 EGP Transfer Pump, 115 VAC, 8 gpm (30.3 lpm), 120 psi (8.3 bar)

Choose cost-saving convenience with the all-new Graco EGP electric pumps. Attach the EGP transfer pump directly to roll-around barrels for more mobility in more places. These pumps offer the same powerful, high-quality performance you've come to expect from Graco - only for less operating cost and more convenience.

• Electrical Flexibility - Available in 12 VDC and 115 VAC power options.
• Smooth Fluid Flow 8 gpm (30 lpm) - Output flow is continuous and non-pulsating up to 8 gpm (30 lpm).
• Heavy-Duty Motor with Long Life - Industrial-grade electric motors with over-temperature protection on 115 VAC models.
• Pump Protection - Includes inlet strainer to keep larger debris out of pump housing and extend pump life.
• Plug and Play - Self-priming, precision machined pump design.

• Model: EGP

• Compatible Material: Oil

• Fluid Pressure Control Type: Internal Bypass

• Inlet Thread Gender: Female
• Inlet Thread Size (in): 1
• Inlet Thread Type: NPT

• Maximum Current (A): 9.1

• Maximum Working Pressure (bar): 8.3
• Maximum Working Pressure (psi): 120

• Outlet Thread Gender: Female

• Power Rating (HP): 1
• Power Type: Electric

GG 26B560

E-FLO IQ SYSTEM, IQU, TDM, 1H20, 2H20

Graco 26B560 Tandem E-Flo iQ System for Urethanes, Check-Mate 200cc, Heated 55 Gal., D200s, two 20 ft hoses, 20 ft hose (WIP)

The E-Flo iQ Metering & Dispensing System our tank-to-tip metering system for single component urethanes. This dispensing solution was designed to meter directly from the drum, making it an intelligent system that delivers sustained in-plant performance, minimizes maintenance costs and reduces system complexity.

• Tandem Heated E-Flo iQ Urethane Supply Sytem
  • Delivers consistent control and accurate performance
  • Quiet electric servo-driven motor for lower sound levels
  • Provides continuous dispensing without the need to reload
  • Check-Mate Severe Duty lower for long life and reliable material movement
• High-Quality Hoses
  • Graco heated hoses are insulated for an accurate and uniform material temperature.
  • Equipped with a total of 60 ft of hose (two 20 ft hoses for pumps to manifold and one 20 ft hose from manifold to valve)
• Axial Rotating Dispense Valves Suited for Urethane Dispense
  • Triangular head ideal for urethane and sealant dispense for automotive window and windshield glazing
  • Delivers reliable and consistent beads in high flow applications
  • Compact and lightweight design allows for lower payload
  • Rotating valve prevents twining and reduces wear
  • Remote mounted solenoid

• Air Inlet Size (in): 1
• Air Inlet Size (mm): 25

• Ambient/Warm Melt/Hot Melt: Warm Melt
• Applicator Type: Rotating Ball/Seat

• Configuration: Tandem

• Container Size: Drum

• Fluid Outlet Size (cm): 2.54
• Fluid Outlet Size (in): 1.0
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT

• Gateway: EtherNet/IP User Interface, PROFINET User Interface, PROFIBUS User Interface, DeviceNet User Interface

• Input Cycle Rate (Hz): 50/60

• Material Container Volume (gal): 55
• Material Container Volume (l): 200

• Maximum Air Inlet Pressure (bar): 9
• Maximum Air Inlet Pressure (kPa): 900
• Maximum Air Inlet Pressure (MPa): 0.9
• Maximum Air Inlet Pressure (psi): 125

• Maximum Ambient Temperature ( degree C): 49
• Maximum Ambient Temperature ( degree F): 120

• Maximum Flow Rate (cc/min): 5000

• Maximum Flow Rate (L/min): 5.0

• Maximum Fluid Temperature ( degree C): 70
• Maximum Fluid Temperature ( degree F): 158
• Maximum Fluid Viscosity (cP): 3000000

• Maximum Fluid Temperature ( degree C): 70
• Maximum Fluid Temperature ( degree F): 158
• Maximum Fluid Viscosity (cP): 3000000

• Maximum Fluid Working Pressure (bar): 240
• Maximum Fluid Working Pressure (MPa): 28
• Maximum Fluid Working Pressure (psi): 3500
• Maximum Hose Length (ft): 40

• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (MPa): 28
• Maximum Working Pressure (psi): 4000

• Minimum Ambient Temperature ( degree C): 0
• Minimum Ambient Temperature ( degree F): 32

• Minimum Flow Rate (cc/min): 10
• Minimum Flow Rate (L/min): 0.01

• Minimum Fluid Viscosity (cP): 100000

• Minimum Voltage (V ac): 200

• Phase: 1, 3

• Power Rating (HP): 2.5 hp
• Power Type: Electric, Pneumatic

• Ram Post Di

GG 26C507

GG 279006

KING SPRAYER, CONTRACTOR, 45:1, COMP

Graco 279006 Contractor King 45:1 Air Powered Airless Sprayer, Complete (2-F Gun)

Introducing the newest member of the King family " The Contractor King 45:1" . Designed around single-person mobility and high performance, this affordable line of air-powered sprayers is the perfect addition to every Contractor's fleet.

• Proven King quality with Anti-icing technology
  • Field-proven design virtually eliminates icing to keep you spraying
  • Durable aluminum, steel and composite construction for years of service
  • Delivers superior finish with no pulsation, even with multiple guns
  • Simple design for easy serviceability
  • Oversized porting for maximum air flow
• Easy to move and transport
  • Nearly 38 kg lighter than comparable models for easy, one-person handling
  • Chrome-plated, welded-steel frame for years of service
  • Integrated lifting points for easy positioning on any jobsite
  • Flat proof tires resist jobsite debris for maximum convenience
• Simple maintenance with proven design and performance
  • QuickChange Endurance pump, for quick and for easy on-the-job pump removal and maintenance
  • Chromex Rod and Stainless Steel cylinder for maximum life and performance
  • Fleet-friendly design uses the same wear parts as your other King sprayers
  • Xtreme Seal UHMWPE & Leather packings for ultimate durability with most materials
  • QuickAccess intake valve for easy access to lower ball check
• Complete package includes:
  • 2-Finger Silver Plus Gun
  • XHD 417 and XHD 519 SwitchTips with XHD guard
  • 1/4" x 1.8m Extreme Duty Airless whip hose
  • 3/8" x 15m Extreme Duty Airless hose
• Complete Package Includes:
  • Silver Plus Gun OR Silver Plus HP Gun (2 Finger Model)
  • XHD 417, XHD 519 SwitchTips and Guard
  • 1/4 in x 6 ft Extreme Duty Airless Whip Hose
  • 3/8 in x 50 ft Extreme Duty Airless Hose

• Model: Contractor King
• Series: 45:1
• Product Series: Complete

• Approved for Hazardous Locations: Yes

• Gun Included: 1
• Gun Model: Silver Plus Gun

• Includes: Silver Plus Gun, 3/8 in x 50 ft Hose, 1/4 in x 6 fit Whip Hose, XHD RAC 417 SwitchTip, XHD RAC 519 SwitchTip, XHD RAC Tip Guard

• Maximum Working Pressure (psi): 4500

• Package Options: Complete
• Package Pressure Ratio (Motor/Lower): 45:1 XL6500 motor/290cc Lower

• Pump Ratio: 45:1 (4500 psi)
• Pump Type: Endurance

GG 279035

PUMP, FTB100, 1:1, UNIVERSAL

Graco 279035 Fast-Ball 100 Universal Pump

Redesigned for enhanced quality, durability and reliability, the Fast-Ball 100 air-operated piston pump is easy to install, easy to operate, and simple design allows for efficient serviceability when necessary to minimize downtime and keep your operations running.

• In-line design with fewer parts for less pump wear
• Double-acting pump provides reliable fluid flow
• Differential air motor ensures smooth pumping

• Model: Fast-Ball
• Series: 100

• Air Inlet Size (in): 1/4
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Fast Lube and Service Centers

• Compatible Material: ATF, Gear Lube, Oil

• Cycles Per Gallon: 31

• Fluid Inlet Size (in): 1
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (in): 0.75
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT

• Maximum Air Inlet Pressure (psi): 150

• Maximum Continuous Cycle Rate (CPM): 170

• Maximum Working Pressure (psi): 150

• Power Type: Pneumatic

• Pump Ratio: 1:1

GG 2HV042

GG 346-TB

GG 47200-5-2

GG 5133-62MD

GG 552007

GG 552008

GG 555685

GG 556511

GG 557286

MOTOR, 115 VAC MMF

Graco 557286 Miniature Meter-Flo Spare Parts - Motor, 115 VAC

• Motor, 115 VAC
• Lubriquip part number 493-040-065

• For Use With: Miniature Meter-Flo
• Frequency (Hz): 60

• Power Rating (HP): 0.125

• Rated Speed (RPM): 1500

GG 557395

FITTING, ELB STREET 1/8 NPTF X 45

Graco 557395 Tube Fitting - 45 degree Street Elbow - 1/8 NPT Male x 1/8 NPT Female

• 45 degree street elbows - steel
• 1/8 female, 1/8 male threads
• Lubriquip part number 509-111-000

• Angle ( degree ): 45

• Connection Type: Threaded

• Finish/Coating: Zinc, Nickel

• For Use With: Pipe

• Material: Steel

GG 557936

GG 562653

GG 562905

GG 563153

SWIVEL, BEARING, 90DEG, 3/8 NPT

Graco 563153 Ball Bearing 90 degree Angle Swivel - 3/8 inch

• 90 degree Angle Swivel - 3/8 inch
• Lubriquip part number 503-704-002

• Angle ( degree ): 90

• Connection Type: Threaded

• For Use With: Pipe

• Maximum Working Pressure (bar): 207
• Maximum Working Pressure (kPa): 20700
• Maximum Working Pressure (MPa): 20.7
• Maximum Working Pressure (psi): 3000

GG 563158

VALVE, RELIEF, 1/4 NPT, 1500 PSI

Graco 563158 Automatic Relief Indicator for MX Divider Valves, 1500 psi (103 bar)

Keep your machine running while lubrication gets to critical points. These performance indicators pinpoint lube line blockages but allow the lube system to continue to supply lubrication to points that are not blocked.

• No time or effort required for reset after blockage is cleared
• Easy information on blocked lines, high system pressure or blocked bearings
• Works with MSP, MX, MXP, MJ and MHH divider valves

• Model: Trabon

• Application: In-Plant Machinery, Off-Road Equipment, Compressor Equipment

• Compatible Material: Oil, Grease

• Connection Size (in): 0.25

• Indicator Type: Automatic Relief Indicators

• Maximum Working Pressure (bar): 103
• Maximum Working Pressure (kPa): 10300
• Maximum Working Pressure (MPa): 10
• Maximum Working Pressure (psi): 1500

• Overall Length (cm): 3
• Overall Length (in): 1.37
• Overall Length (mm): 35

GG 563164

GG 563166

GG 563201

VALVE, CHECK, 1/8 NPT, REV, 5000

Graco 563201 Single Ball Check Valve - 60 psi Nominal Cracking Pressure, 1/8 in NPSF (F) x 1/8 in NPTF (M), Steel, 5,000 psi

• Single Ball Check Valve
• 60 psi nominal cracking pressure
• 1/8 inch (3.2 mm) NPSF (F) x 1/8 inch (3.2 mm) NPTF (M)
• 5,000 psi max
• Lubriquip part number 509-355-060

• Application: Compressor Equipment

• Ball Material: Steel

• Body Material: Steel

• Compatible Material: Oil, Grease

• Inlet Size (cm): 0.3175
• Inlet Size (in): 1/8
• Inlet Size (mm): 3.175

• Inlet Thread Type: NPTF

• Maximum Cracking Pressure (bar): 4.14
• Maximum Cracking Pressure (kPa): 414
• Maximum Cracking Pressure (MPa): 0.414
• Maximum Cracking Pressure (psi): 60

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (MPa): 34.5
• Maximum Working Pressure (psi): 5000

• Number of Balls: Single Ball

• Outlet Size (cm): 0.3175
• Outlet Size (in): 1/8
• Outlet Size (mm): 3.175
• Outlet Thread Type: NPSF

GG 24X283

GG 24X881

GG 24Y304

GG 24Y426

GG 253547

GG 253553

GG 253603

GG 255527

GG 255528

GG 255534

GG 255566

GG 255572

GG 255594

GG 255676

GG 256806

GG 257770

GG 258334

GG 258530

GG 258704

GG 25C590

GG 25D293

KIT,SENSOR,RADAR,HAZ,FM

Graco 25D293 Radar Sensor Kit, contains an Endress+Hauser FMP50 wave-guided radar sensor with FM approval

GG 25D529

GG 25P874

GG 25R086

GG 25T780

GG 25U311

GG 262184

GG 262402

GG 262416

GG 26C882

GG 273136

GG 287553

GG 288505

GG 288970

AIRPRO GUN, WB, COMPLIANT, .030

Graco 288970 AirPro Air Spray Pressure Feed Gun, Compliant, 0.030 inch (0.8 mm) Nozzle, for Waterborne Applications

The AirPro air spray gun delivers exceptional spray performance while addressing your environmental and operator concerns - whether you're a custom shop or a high volume manufacturing facility.

• Even material distribution through the spray pattern for optimum coverage
• Improved transfer efficiency through reduced air consumption
• Enhanced atomization through material-specific aircaps
• Ultra-light trigger pull reduces operator muscle stress
• Ergonomic gun handle provides a comfortable grip
• Rounded control knobs for operator comfort
• Optimize spray performance with our cutting edge aircap and nozzle design
• Choose from a wide range of gun models to meet the needs of your specific application

• Model: AirPro

• Air Inlet Size (cm): 0.635
• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35
• Air Inlet Thread Type: NPSM

• Application: Waterborne
• Applicator Type: Manual

• Bleed Type: Non-Bleeder

• Compatible Material: Enamel, Epoxies, High Solids, Latex, Lacquer, Plural Component Materials, Sealants, Urethane, UV Coating, Waterborne

• Feed Type: Pressure Feed

• Fluid Inlet Size (cm): 0.9525
• Fluid Inlet Size (in): 3/8
• Fluid Inlet Size (mm): 9.525
• Fluid Inlet Thread Type: NPSM
• Fluid Orifice Size (cm): 0.08
• Fluid Orifice Size (in): 0.030
• Fluid Orifice Size (mm): 0.8

• Gun Activation: Manual
• Gun Included: 1
• Gun Type: Compliant Gun
• Gun Weight (g): 410

• Includes: Air Cap, Needle Assembly, Nozzle, Tool Kit

• Maximum Air Inlet Pressure (bar): 7
• Maximum Air Inlet Pressure (kPa): 700
• Maximum Air Inlet Pressure (MPa): 0.7
• Maximum Air Inlet Pressure (psi): 100
• Maximum Air Pressure (bar): 7

• Maximum Air Pressure (kPa): 700
• Maximum Air Pressure (MPa): 0.7
• Maximum Air Pressure (psi): 100

• Maximum Fluid Pressure (bar): 21
• Maximum Fluid Pressure (kPa): 2100
• Maximum Fluid Pressure (MPa): 2.1
• Maximum Fluid Pressure (psi): 300
• Maximum Fluid Temperature ( degree C): 43
• Maximum Fluid Temperature ( degree F): 109

• Maximum Fluid Pressure (bar): 21
• Maximum Fluid Pressure (kPa): 2100
• Maximum Fluid Pressure (MPa): 2.1
• Maximum Fluid Pressure (psi): 300
• Maximum Fluid Temperature ( degree C): 43
• Maximum Fluid Temperature ( degree F): 109

• Product Type: Spray Gun

GG 289320

GG 289490

GG 295671

GG 295686

GG 295687

GG 295688

GG 295689

GG 295690

GG 295692

GG 296226

GG 296595

GG 296717

GG 296907

GG 296971

GG 297841

GG 248927

GG 249036

GG 249112

GG 249256

GG 24A230

GG 24A360

GG 24A439

GG 24A580

GG 24A620

GG 24A632

GG 24A637

GG 24A796

GG 24A839

GG 24A915

GG 24B332

GG 24B536

GG 24B618
