GRACO INC. S10595

GG H85M10

PRO XP GUN, ES, 85KV, AA, SMART

Graco H85M10 Pro Xp85 Air Assist Manual Electrostatic Gun, 85 kV, with smart display, standard coatings, includes AEM or AEF tip of choice

Pro Xp85 kV air-assist gun maximizes transfer efficiency and lowers cost of ownership. Pro Xp85 AA gun line includes Standard and Smart models.

• High quality spray performance with a one-piece aircap and variety of spray tips
• Alternator speed indicator light ensures your turbine speed is running at the correct level
• Smart Controls help you analyze performance, adapt to your voltage needs and make troubleshooting easier
• Internal power supply reduces operator fatigue with no heavy cords to slow you done
• Rugged, dependable design supported by a three year warranty
• Every gun is tested and delivered with a certificate indicating the spray pattern, mechanical performance and electrical performance meets Gracos requirements

• Model: Pro Xp
• Series: 85

• Air Inlet Size (cm): 0.635
• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35
• Air Inlet Thread Gender: Male
• Air Inlet Thread Type: NPSM

• Application: Electrostatic, Standard
• Applicator Type: Manual

• Coating Type: Standard

• Compatible Paint Type: Epoxy, High Solids, Lacquers, Plural Component Materials, Polyurethanes, Solvent borne, Urethanes, UV Curing, Varnishes,

• Display Type: Smart

• Fluid Inlet Size (in): 1/4
• Fluid Inlet Thread Gender: Male
• Fluid Inlet Thread Type: NPSM

• Gun Activation: Manual
• Gun Type: Electrostatic
• Gun Weight (g): 728
• Gun Weight (kg): 0.73
• Gun Weight (lb): 1.6
• Gun Weight (oz): 25.68

• Includes: Smart Display, Tip Guard Air Cap, Tip of Choice, Tool Kit, Gun Cover, Exhaust Tube,

• Maximum Fluid Pressure (bar): 210
• Maximum Fluid Pressure (kg/cm 2): 214.14
• Maximum Fluid Pressure (kPa): 21000
• Maximum Fluid Pressure (MPa): 21
• Maximum Fluid Pressure (psi): 3000
• Maximum Fluid Temperature ( degree C): 48
• Maximum Fluid Temperature ( degree F): 120

• Maximum Fluid Pressure (bar): 210
• Maximum Fluid Pressure (kg/cm 2): 214.14
• Maximum Fluid Pressure (kPa): 21000
• Maximum Fluid Pressure (MPa): 21
• Maximum Fluid Pressure (psi): 3000
• Maximum Fluid Temperature ( degree C): 48
• Maximum Fluid Temperature ( degree F): 120

• Maximum Paint Resistivity (megohm/cm): Infinity

• Minimum Paint Resistivity (megohm/cm): 3

• Overall Length (cm): 27.18
• Overall Length (in): 10.7
• Overall Length (mm): 271.8

GG HE30-0009

QUANTM PUMP, QHC-FGFF5SSPTPSPTS130021

Graco HE30-0009 QUANTM h30, 1" FG SST Electric Diaphragm Pump, 100-120 V, FEP AL Center, SS Seat, PT Ball, PS Diaphragm

QUANTM isn't just another electric pump: it's a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It's time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump.

Application: Graco food-grade pumps are our most popular series for general food transfer. With their all-stainless-steel construction and 125 Ra surface finish, the groundbreaking new QUANTM food-grade electric pumps are certified to handle a wide range of food and beverage products and meet certification requirements for some personal care applications as well. From dressings, sauces, oils, syrups to soaps, creams and solvents, QUANTM electric food-grade pumps are a workhorse for almost any hygienic food-grade application. The powerful new electric motor delivers up to 8x more continuous torque at low speeds than conventional motors and the fast, easy plug-and-play installation allows you to easily replace existing pumps without additional investment or infrastructure rework.

• Revolutionary Design
  • Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature
  • Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump
  • Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback
  • Quiet operation reduces plant noise and improves employee safety and health
  • Smart pump control provides more accurate flow set points and built-in I/O
• Efficient Electric Motor
  • FEP coated aluminum electric drive
  • 120 VAC 1Ph motor with 15 ft cord and NEMA 5-15 plug
  • Non-hazardous
  • Materials of Construction
    • 125 Ra surface finish 316 stainless steel fluid section with tri-clamp center port
    • Internal components include 316L stainless steel seat, PTFE ball, PTFE/Santoprene 2-Piece diaphragm and PTFE manifold o-ring
    • EN 2.1 material certification
  • Model: QUANTM
  • Series: h30
  • Application: Food, Beverage, Personal Care, Pharmaceutical
  • Ball Material: PTFE
  • Center Section Material: FEP Coated Aluminum
  • Connection Type: Tri-Clamp
  • Cord Length (ft): 15
  • Cord Length (m): 4.57
  • Diaphragm Material: PTFE/Santoprene 2-Piece
  • Fluid Inlet Size (in): 1.5
  • Fluid Inlet Size (mm): 38
  • Fluid Inlet Thread Type: Tri-Clamp
  • Fluid Outlet Size (in): 1.5
  • Fluid Outlet Size (mm): 38
  • Fluid Outlet Thread Type: Tri-Clamp
  • Fluid Section: 316 Stainless Steel, End Port, Tri-Clamp
  • Fluid Section Material: 316 Stainless Steel
  • Hazardous Location Approval:

GG HSDD5B

XD SERIES 30 REEL, HOSE, 3/4 X 50, DEF, BLUE

Graco HSDD5B XD30, DEF, 3/4 in. (19 mm) Inlet, 3/4 in. X 50 ft. (19 mm X 15 m) Hose, NPT, Truck/Bench Mount, Metallic Blue

Graco's XD30 Series Hose Reels are used in applications requiring longer-range dispense and higher capacity than the standard XD10 and XD20 Series. The Compact pedestal and spool fits into tight spaces and can accommodate 30-75 foot (9.1-22.8 meters) hose capacity for a wide variety of applications. Typical fluids handled include: Petroleum- and synthetic-based oils, diesel fuel, air, water, antifreeze, windshield washer fluid, pressure wash, waste oil and diesel exhaust fluid (DEF).

Application: Ideal for rugged indoor and outdoor use in heavy-duty truck dealerships, fleet maintenance, mining maintenance, public works garages, construction vehicle maintenance, agriculture and service trucks.

• Spring Adjustment - Increase or decrease spring tension while reel is pressurized with fluid
• Full-Flow Swivel - Maximize material flow with minimal pressure drop for faster fills to get more vehicles through your shop
• Optional Adjustable Arm - Easily change the arm position for your application, order with arm (HS models) or without (HN models)
• Large Hose Capacity with Small Profile - Compact pedestal and spool fits into tight spaces and can accommodate 30-75 foot (91-228 meters) hose capacity for a wide variety of applications

• Model: XD
• Series: 30

• Application: Diesel Fuel

• Color: Metallic Blue

• Frame Type: Dual Pedestal

• Hose Inside Diameter (in): 3/4
• Hose Inside Diameter (mm): 19.05
• Hose Length (ft): 50
• Hose Length (m): 15

• Hose Reel Type: Reel with Hose
• Includes Hose: Yes
• Inlet Size (in): 3/4
• Inlet Size (mm): 19.05

• Inlet Thread Type: BSPP

• Maximum Working Pressure (psi): 50

• Mount Location: Truck Mount, Bench Mount

• Outlet Size (in): 3/4
• Outlet Size (mm): 19.05

• Overall Height (in): 23.10
• Overall Height (mm): 588
• Overall Length (in): 22.12
• Overall Length (mm): 561.73
• Overall Width (in): 9.0
• Overall Width (mm): 229

• Recommended Environment: Indoor, Outdoor
• Recommended Fluid Type: DEF

GG HSDDDB

XD SERIES 30 REEL, HOSE, BARE, DEF, BLUE

Graco HSDDDB XD30, DEF, 3/4 in. (19 mm) Inlet, Bare Reel (3/4 in. X 50 ft. (19 mm X 15 m) Capacity), NPT, Truck/Bench Mount, Metallic Blue

Graco's XD30 Series Hose Reels are used in applications requiring longer-range dispense and higher capacity than the standard XD10 and XD20 Series. The Compact pedestal and spool fits into tight spaces and can accommodate 30-50 foot (9.1-15 meters) hose capacity for a wide variety of applications. Typical fluids handled include: Petroleum- and synthetic-based oils, diesel fuel, air, water, antifreeze, windshield washer fluid, pressure wash, waste oil and diesel exhaust fluid (DEF).

Application: Ideal for rugged indoor and outdoor use in heavy-duty truck dealerships, fleet maintenance, mining maintenance, public works garages, construction vehicle maintenance, agriculture and service trucks.

• Spring Adjustment - Increase or decrease spring tension while reel is pressurized with fluid
• Full-Flow Swivel - Maximize material flow with minimal pressure drop for faster fills to get more vehicles through your shop
• Optional Adjustable Arm - Easily change the arm position for your application, order with arm (HS models) or without (HN models)
• Large Hose Capacity with Small Profile - Compact pedestal and spool fits into tight spaces and can accommodate 30-75 foot (91-228 meters) hose capacity for a wide variety of applications

• Model: XD
• Series: 30

• Application: Diesel Fuel

• Bare Reel: 1

• Color: Metallic Blue

• Frame Type: Enclosed

• Hose Inside Diameter (in): 3/4
• Hose Inside Diameter (mm): 19.05
• Hose Length (ft): 50
• Hose Length (m): 15

• Hose Reel Type: Bare Reel
• Includes Hose: No
• Inlet Size (in): 3/4
• Inlet Size (mm): 19.05

• Inlet Thread Type: BSPP

• Maximum Working Pressure (psi): 50

• Mount Location: Truck Mount, Bench Mount

• Outlet Size (in): 3/4
• Outlet Size (mm): 19.05

• Overall Height (in): 23.10
• Overall Height (mm): 588
• Overall Length (in): 22.12
• Overall Length (mm): 561.73
• Overall Width (in): 9.0
• Overall Width (mm): 229

• Recommended Environment: Indoor, Outdoor
• Recommended Fluid Type: DEF

GG HSHFFB

XD SERIES 30 REEL, 3/8 X BARE, P/W, BLUE

Graco HSHFFB XD30, Pressure Wash, 1/2 in. (13 mm) Inlet, Bare Reel (3/8 in. X 75 ft. (10 mm X 23 m) Capacity), NPT, Truck/Bench Mount, Metallic Blue

Graco's XD30 Series Hose Reels are used in applications requiring longer-range dispense and higher capacity than the standard XD10 and XD20 Series. The Compact pedestal and spool fits into tight spaces and can accommodate 30-75 foot (9.1-22.8 meters) hose capacity for a wide variety of applications. Typical fluids handled include: Petroleum- and synthetic-based oils, diesel fuel, air, water, antifreeze, windshield washer fluid, pressure wash, waste oil and diesel exhaust fluid (DEF).

Application: Ideal for rugged indoor and outdoor use in heavy-duty truck dealerships, fleet maintenance, mining maintenance, public works garages, construction vehicle maintenance, agriculture and service trucks.

• Spring Adjustment - Increase or decrease spring tension while reel is pressurized with fluid
• Full-Flow Swivel - Maximize material flow with minimal pressure drop for faster fills to get more vehicles through your shop
• Optional Adjustable Arm - Easily change the arm position for your application, order with arm (HS models) or without (HN models)
• Large Hose Capacity with Small Profile - Compact pedestal and spool fits into tight spaces and can accommodate 30-75 foot (91-228 meters) hose capacity for a wide variety of applications

• Model: XD
• Series: 30

• Application: Pressure Wash

• Bare Reel: 1

• Color: Metallic Blue

• Dry Weight (lb): 98

• Frame Type: Dual Pedestal

• Hose Inside Diameter (in): 3/8
• Hose Inside Diameter (mm): 9.525
• Hose Length (ft): 75
• Hose Length (m): 23

• Hose Reel Type: Bare Reel
• Includes Hose: No
• Inlet Size (in): 1/2
• Inlet Size (mm): 12.7

• Inlet Thread Type: NPSM

• Maximum Working Pressure (psi): 5000

• Mount Location: Truck Mount, Bench Mount

• Outlet Size (in): 3/8
• Outlet Size (mm): 9.525

• Overall Height (in): 23.10
• Overall Height (mm): 588.00
• Overall Length (in): 22.12
• Overall Length (mm): 561.73
• Overall Width (in): 9.0
• Overall Width (mm): 229

• Recommended Environment: Indoor, Outdoor
• Recommended Fluid Type: Pressure Wash

GG HA1T10

PRO XP GUN, ES, AUTO REAR, AA

Graco HA1T10 Pro Xp Auto Air-Assist Electrostatic Spray Gun, standard model, with rear manifold, 85 kV, includes AEM or AEF tip of choice

Pro Xp Auto Air-Assist has an 85 kV power supply and internal power so there's no electrical cord to damage or replace. Standard gun models always run at 85 kV power and include an alternator speed indicator to display electrostatic performance. Ideal for high pressure spraying designed to improve transfer efficiency and deliver a high quality finish.

• Versatile product line gives you more models to choose from and greater spraying flexibility with air spray, air assist and waterborne guns
• Manifold style fits almost any systems requirement - back manifold is ideal for stationary and reciprocator systems and bottom manifold is ideal for robot mounting
• 85 kV power supply and internal power so theres no electrical cord to worry about damaging or replacing
• Durable components reduce cost of ownership, supported by a three year warranty

• Model: Pro Xp
• Series: Auto

• Air Inlet Size (cm): 0.635
• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35
• Air Inlet Thread Gender: Male
• Air Inlet Thread Type: NPSM

• Application: Electrostatic, Standard
• Applicator Type: Automatic

• Coating Type: Standard

• Compatible Paint Type: Solvent borne

• Display Type: Standard

• Fluid Inlet Size (in): 1/4
• Fluid Inlet Thread Gender: Male
• Fluid Inlet Thread Type: NPSM

• For Use With: Pro Xp Auto Control Module

• Gun Activation: Automatic
• Gun Type: Electrostatic
• Gun Weight (g): 1197
• Gun Weight (kg): 1.2
• Gun Weight (lb): 2.64
• Gun Weight (oz): 42.24

• Manifold Type: Rear

• Maximum Fluid Pressure (bar): 210
• Maximum Fluid Pressure (kPa): 21000
• Maximum Fluid Pressure (MPa): 21
• Maximum Fluid Pressure (psi): 3000
• Maximum Fluid Temperature ( degree C): 48
• Maximum Fluid Temperature ( degree F): 120

• Maximum Fluid Pressure (bar): 210
• Maximum Fluid Pressure (kPa): 21000
• Maximum Fluid Pressure (MPa): 21
• Maximum Fluid Pressure (psi): 3000
• Maximum Fluid Temperature ( degree C): 48
• Maximum Fluid Temperature ( degree F): 120

• Maximum Paint Resistivity (megohm/cm): Infinity

• Minimum Paint Resistivity (megohm/cm): 3

• Overall Length (cm): 27.94
• Overall Length (in): 11
• Overall Length (mm): 279.4

GG HEM004

LDX SERIES REEL, HOSE, 1/2in X 50', OIL

Graco HEM004 LDX Series, Oil, 1/2 in (13 mm) Inlet, 1/2 in X 50 ft (13 mm X 15 m) Hose, NPT

Graco's industrial-grade LDX hose reel offers incredible value for cost-conscious workshops. Its all-metal frame and specially crafted, long-lasting components provide consistent release and retraction.

Application: Designed for smaller garages, independent repair facilities and industrial manufacturing environments.

• Dual Pedestal Frame - Ribbed metal for increased stability and robustness.
• External Swivel Housing - Quickly access swivel seal for faster repairs.
• Ball Bearing Swivel - Swivel designed with internal ball bearings reduces friction and ensures smooth operation.
• Large Hose Capacity with Small Profile - Compact design accommodates up to a 50 foot (15 meter) hose to meet a wide variety of application requirements.

• Model: LDX

• Application: Oil

• Color: Grey

• Dry Weight (lb): 48

• Frame Type: Dual Pedestal

• Hose Inside Diameter (in): 1/2
• Hose Inside Diameter (mm): 12.7
• Hose Length (ft): 50
• Hose Length (m): 15

• Hose Reel Type: Reel with Hose
• Includes Hose: Yes
• Inlet Size (in): 1/2
• Inlet Size (mm): 12.7

• Inlet Thread Gender: Male
• Inlet Thread Type: NPT

• Maximum Temperature ( degree C): 100
• Maximum Temperature ( degree F): 212

• Maximum Working Pressure (psi): 1500

• Minimum Temperature ( degree C): -40
• Minimum Temperature ( degree F): -40

• Mount Location: Truck Mount, Bench Mount

• Outlet Size (in): 1/2
• Outlet Size (mm): 12.7
• Outlet Thread Gender: Male
• Outlet Thread Type: NPT

• Overall Height (in): 19
• Overall Height (mm): 483
• Overall Length (in): 17.5
• Overall Length (mm): 445
• Overall Width (in): 9.4
• Overall Width (mm): 239

• Recommended Environment: Indoor
• Recommended Fluid Type: Oil

GG HSHB7B

XD SERIES 30 REEL, 3/8 X 75, GREASE, BLUE

Graco HSHB7B XD30, Grease, 1/2 in. (13 mm) Inlet, 3/8 in. X 75 ft. (10 mm X 23 m) Hose, NPT, Truck/Bench Mount, Metallic Blue

Graco's XD30 Series Hose Reels are used in applications requiring longer-range dispense and higher capacity than the standard XD10 and XD20 Series. The Compact pedestal and spool fits into tight spaces and can accommodate 30-75 foot (9.1-22.8 meters) hose capacity for a wide variety of applications. Typical fluids handled include: Petroleum- and synthetic-based oils, diesel fuel, air, water, antifreeze, windshield washer fluid, pressure wash, waste oil and diesel exhaust fluid (DEF).

Application: Ideal for rugged indoor and outdoor use in heavy-duty truck dealerships, fleet maintenance, mining maintenance, public works garages, construction vehicle maintenance, agriculture and service trucks.

• Spring Adjustment - Increase or decrease spring tension while reel is pressurized with fluid
• Full-Flow Swivel - Maximize material flow with minimal pressure drop for faster fills to get more vehicles through your shop
• Optional Adjustable Arm - Easily change the arm position for your application, order with arm (HS models) or without (HN models)
• Large Hose Capacity with Small Profile - Compact pedestal and spool fits into tight spaces and can accommodate 30-75 foot (91-228 meters) hose capacity for a wide variety of applications

• Model: XD
• Series: 30

• Application: Grease

• Color: Metallic Blue

• Dry Weight (lb): 98

• Frame Type: Dual Pedestal

• Hose Inside Diameter (in): 3/8
• Hose Inside Diameter (mm): 9.525
• Hose Length (ft): 75
• Hose Length (m): 23

• Hose Reel Type: Reel with Hose
• Includes Hose: Yes
• Inlet Size (in): 1/2
• Inlet Size (mm): 12.7

• Inlet Thread Type: NPSM

• Maximum Working Pressure (psi): 5000

• Mount Location: Truck Mount, Bench Mount

• Outlet Size (in): 3/8
• Outlet Size (mm): 9.525

• Overall Height (in): 23.10
• Overall Height (mm): 588.00
• Overall Length (in): 22.12
• Overall Length (mm): 561.73
• Overall Width (in): 9.0
• Overall Width (mm): 229

• Recommended Environment: Indoor, Outdoor
• Recommended Fluid Type: Grease

GG HA2M10

PRO XP GUN, ES, AUTO BOTTOM, SMT, AA

Graco HA2M10 Pro Xp Auto Air-Assist Electrostatic Spray Gun, smart model, with bottom manifold, 85 kV, includes AEM or AEF tip of choice

Pro Xp Auto Air-Assist has an 85 kV power supply and internal power so there's no electrical cord to damage or replace. Smart gun models connect to a control module for kV control and displaying gun performance. Ideal for high pressure spraying designed to improve transfer efficiency and deliver a high quality finish.

• Versatile product line gives you more models to choose from and greater spraying flexibility with air spray, air assist and waterborne guns
• Manifold style fits almost any systems requirement - back manifold is ideal for stationary and reciprocator systems and bottom manifold is ideal for robot mounting
• 85 kV power supply and internal power so theres no electrical cord to worry about damaging or replacing
• Durable components reduce cost of ownership, supported by a three year warranty

• Model: Pro Xp
• Series: Auto

• Air Inlet Size (cm): 0.635
• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35
• Air Inlet Thread Gender: Male
• Air Inlet Thread Type: NPSM

• Application: Electrostatic, Standard
• Applicator Type: Automatic

• Coating Type: Standard

• Compatible Paint Type: Solvent borne

• Display Type: Smart

• Fluid Inlet Size (in): 1/4
• Fluid Inlet Thread Gender: Male
• Fluid Inlet Thread Type: NPSM

• For Use With: Pro Xp Auto Control Module

• Gun Activation: Automatic
• Gun Type: Electrostatic
• Gun Weight (g): 1197
• Gun Weight (kg): 1.2
• Gun Weight (lb): 2.64
• Gun Weight (oz): 42.24

• Manifold Type: Bottom

• Maximum Fluid Pressure (bar): 210
• Maximum Fluid Pressure (kPa): 21000
• Maximum Fluid Pressure (MPa): 21
• Maximum Fluid Pressure (psi): 3000
• Maximum Fluid Temperature ( degree C): 48
• Maximum Fluid Temperature ( degree F): 120

• Maximum Fluid Pressure (bar): 210
• Maximum Fluid Pressure (kPa): 21000
• Maximum Fluid Pressure (MPa): 21
• Maximum Fluid Pressure (psi): 3000
• Maximum Fluid Temperature ( degree C): 48
• Maximum Fluid Temperature ( degree F): 120

• Maximum Paint Resistivity (megohm/cm): Infinity

• Minimum Paint Resistivity (megohm/cm): 3

• Overall Length (cm): 27.94
• Overall Length (in): 11
• Overall Length (mm): 279.4

GG HSLD5B

XD SERIES 30 REEL, 3/4 X 50, A/W, BLUE

Graco HSLD5B XD30, Air/Water/Antifreeze/WWS, 3/4 in. (19 mm) Inlet, 3/4 in. X 50 ft. (19 mm X 15 m) Hose, NPT, Truck/Bench Mount, Metallic Blue

Graco's XD30 Series Hose Reels are used in applications requiring longer-range dispense and higher capacity than the standard XD10 and XD20 Series. The Compact pedestal and spool fits into tight spaces and can accommodate 30-75 foot (9.1-22.8 meters) hose capacity for a wide variety of applications. Typical fluids handled include: Petroleum- and synthetic-based oils, diesel fuel, air, water, antifreeze, windshield washer fluid, pressure wash, waste oil and diesel exhaust fluid (DEF).

Application: Ideal for rugged indoor and outdoor use in heavy-duty truck dealerships, fleet maintenance, mining maintenance, public works garages, construction vehicle maintenance, agriculture and service trucks.

• Spring Adjustment - Increase or decrease spring tension while reel is pressurized with fluid
• Full-Flow Swivel - Maximize material flow with minimal pressure drop for faster fills to get more vehicles through your shop
• Optional Adjustable Arm - Easily change the arm position for your application, order with arm (HS models) or without (HN models)
• Large Hose Capacity with Small Profile - Compact pedestal and spool fits into tight spaces and can accommodate 30-75 foot (91-228 meters) hose capacity for a wide variety of applications

• Model: XD
• Series: 30

• Application: Air, Water, Antifreeze, WWS

• Color: Metallic Blue

• Dry Weight (lb): 98

• Frame Type: Dual Pedestal

• Hose Inside Diameter (in): 3/4
• Hose Inside Diameter (mm): 19.05
• Hose Length (ft): 50
• Hose Length (m): 15

• Hose Reel Type: Reel with Hose
• Includes Hose: Yes
• Inlet Size (in): 3/4
• Inlet Size (mm): 19.05

• Inlet Thread Type: NPSM

• Maximum Working Pressure (psi): 300

• Mount Location: Truck Mount, Bench Mount

• Outlet Size (in): 3/4
• Outlet Size (mm): 19.05

• Overall Height (in): 23.10
• Overall Height (mm): 588.00
• Overall Length (in): 22.12
• Overall Length (mm): 561.73
• Overall Width (in): 9.0
• Overall Width (mm): 229

• Recommended Environment: Indoor, Outdoor
• Recommended Fluid Type: Air, Water, Antifreeze, WWS

GG HE80-0003

QUANTM PUMP, QHD-FGFF1SSCWSPEPS130021

Graco HE80-0003 QUANTM h80, 1.5" FG SST Electric Diaphragm Pump, 200-240 V, FEP AL Center, SS Seat, CW Ball, SP Diaphragm

QUANTM isn't just another electric pump: it's a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It's time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump.

Application: Graco food-grade pumps are our most popular series for general food transfer. With their all-stainless-steel construction and 125 Ra surface finish, the groundbreaking new QUANTM food-grade electric pumps are certified to handle a wide range of food and beverage products and meet certification requirements for some personal care applications as well. From dressings, sauces, oils, syrups to soaps, creams and solvents, QUANTM electric food-grade pumps are a workhorse for almost any hygienic food-grade application. The powerful new electric motor delivers up to 8x more continuous torque at low speeds than conventional motors and the fast, easy plug-and-play installation allows you to easily replace existing pumps without additional investment or infrastructure rework.

• Revolutionary Design
  • Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature
  • Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump
  • Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback
  • Quiet operation reduces plant noise and improves employee safety and health
  • Smart pump control provides more accurate flow set points and built-in I/O
• Efficient Electric Motor
  • FEP coated aluminum electric drive
  • 240 VAC 1Ph motor with 15 ft cord and NEMA L15-20plug
  • Non-hazardous
• Materials of Construction
  • 125 Ra surface finish 316 stainless steel fluid section with tri-clamp center port
  • Internal components include 316L stainless steel seat, polychloroprene weighted ball, Santoprene diaphragm and EPDM manifold o-ring
  • EN 2.1 material certification

• Model: QUANTM
• Series: h80

• Application: Food, Beverage, Personal Care, Pharmaceutical

• Ball Material: Polychloroprene Weighted

• Center Section Material: FEP Coated Aluminum

• Connection Type: Tri-Clamp

• Cord Length (ft): 15
• Cord Length (m): 4.57

• Diaphragm Material: Santoprene

• Fluid Inlet Size (in): 2
• Fluid Inlet Size (mm): 51
• Fluid Inlet Thread Type: Tri-Clamp

• Fluid Outlet Size (in): 2
• Fluid Outlet Size (mm): 51
• Fluid Outlet Thread Type: Tri-Clamp
• Fluid Section: 316 Stainless Steel, End Port, Tri-Clamp
• Fluid Section Material: 316 Stainless Steel

• Hazardous Locat

GG H60T18

PRO XP GUN, ES, 60KV, AA, WB

Graco H60T18 Pro Xp60 AA WB Manual Air-Assist Spray Gun, 60 kV, standard display, for waterborne coatings

Excellent, air assisted pattern control eliminates defects for a fine finish with waterborne material.

Application: For spraying conductive, waterborne fluids with an isolation system

• This 60 kV model is the smallest and lightest air assist gun on the market.
• Air-assist aircaps use less air, lowering your energy bill.
• Made in the USA
• Fan adjust pattern control reduces overspray by changing the fan pattern width according to the size of the part - improving quality and saving you money
• Every gun is tested and delivered with a certificate indicating the spray pattern, mechanical performance and electrical performance meets Gracos requirements

• Model: Pro Xp
• Series: 60

• Air Inlet Size (cm): 0.635
• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35
• Air Inlet Thread Gender: Male
• Air Inlet Thread Type: NPSM

• Application: Electrostatic, Waterborne
• Applicator Type: Manual

• Coating Type: Waterborne

• Compatible Paint Type: Epoxy, High Solids, Lacquers, Latex, Plural Component Materials, Polyurethanes, Urethanes, UV Curing, Varnishes, Waterborne

• Display Type: Standard

• Fluid Inlet Size (in): 1/4
• Fluid Inlet Thread Gender: Male
• Fluid Inlet Thread Type: NPSM

• Gun Activation: Manual
• Gun Type: Electrostatic
• Gun Weight (g): 660
• Gun Weight (kg): 0.66
• Gun Weight (lb): 1.46
• Gun Weight (oz): 23.28

• Includes: Tip Guard Air Cap, Tip of Choice, Tool Kit, Gun Cover, Exhaust Tube

• Maximum Fluid Pressure (bar): 210
• Maximum Fluid Pressure (kg/cm 2): 214.14
• Maximum Fluid Pressure (kPa): 21000
• Maximum Fluid Pressure (MPa): 21
• Maximum Fluid Pressure (psi): 3000
• Maximum Fluid Temperature ( degree C): 48
• Maximum Fluid Temperature ( degree F): 120

• Maximum Fluid Pressure (bar): 210
• Maximum Fluid Pressure (kg/cm 2): 214.14
• Maximum Fluid Pressure (kPa): 21000
• Maximum Fluid Pressure (MPa): 21
• Maximum Fluid Pressure (psi): 3000
• Maximum Fluid Temperature ( degree C): 48
• Maximum Fluid Temperature ( degree F): 120

• Maximum Paint Resistivity (megohm/cm): 1

• Minimum Paint Resistivity (megohm/cm): 0

• Overall Length (cm): 24.64
• Overall Length (in): 9.7
• Overall Length (mm): 246.4

GG H60T10

PRO XP GUN,ES,60KV,AA

Graco H60T10 Pro Xp60 Air Assist Manual Electrostatic Gun, 60 kV, with standard display, standard coatings, includes AEM or AEF tip of choice

Pro Xp60 kV air-assist gun is the smallest and lightest electrostatic air-assist gun on the market - delivering a consistent, high quality finish every time you spray. Pro Xp60 AA gun line includes Standard, Smart and Waterborne models.

• High quality spray performance with a one-piece aircap and variety of spray tips
• Transfer efficiency is improved over conventional air-assist guns
• Made in the USA The smallest profile gun with internal power supply on the market - 1 inch (2.5 cm) shorter and 4 oz (110 g) lighter
• Fan adjust pattern control reduces overspray by changing the fan pattern width according to the size of the part - improving quality and saving you money
• Every gun is tested and delivered with a certificate indicating the spray pattern, mechanical performance and electrical performance meets Graco's requirements

• Model: Pro Xp
• Series: 60

• Air Inlet Size (cm): 0.635
• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35
• Air Inlet Thread Gender: Male
• Air Inlet Thread Type: NPSM

• Application: Electrostatic, Standard
• Applicator Type: Manual

• Coating Type: Standard

• Compatible Paint Type: Epoxy, High Solids, Lacquers, Latex, Plural Component Materials, Polyurethanes, Urethanes, UV Curing, Varnishes, Waterborne

GG HA1M18

PRO XP GUN, ES, AUTO REAR, SMT, AA, WB

Graco HA1M18 Pro Xp Auto Waterborne Air-Assist Electrostatic Spray Gun, smart model, with rear manifold, 60 kV. Use with isolation systems.

Pro Xp Auto waterborne air-assist guns are ideal for high pressure spraying with an isolation system including the WB3000.

• Versatile product line gives you more models to choose from and greater spraying flexibility
• Back manifold is ideal for a variety of systems
• 60 kV power supply and internal power so there's no electrical cord to worry about damaging or replacing
• Made in the USA
• Durable components reduce cost of ownership, supported by a three year warranty

• Model: Pro Xp
• Series: Auto

• Air Inlet Size (cm): 0.635
• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35
• Air Inlet Thread Gender: Male
• Air Inlet Thread Type: NPSM

• Application: Electrostatic, Waterborne
• Applicator Type: Automatic

• Coating Type: Waterborne

• Compatible Paint Type: Waterborne

• Display Type: Smart

• Fluid Inlet Size (in): 1/4
• Fluid Inlet Thread Gender: Male
• Fluid Inlet Thread Type: NPSM

• For Use With: Pro Xp Auto Control Module

• Gun Activation: Automatic
• Gun Type: Electrostatic
• Gun Weight (g): 1197
• Gun Weight (kg): 1.2
• Gun Weight (lb): 2.64
• Gun Weight (oz): 42.24

• Manifold Type: Rear

• Maximum Fluid Pressure (bar): 7
• Maximum Fluid Pressure (kPa): 700
• Maximum Fluid Pressure (MPa): 0.7
• Maximum Fluid Pressure (psi): 100
• Maximum Fluid Temperature ( degree C): 48
• Maximum Fluid Temperature ( degree F): 120

• Maximum Fluid Pressure (bar): 7
• Maximum Fluid Pressure (kPa): 700
• Maximum Fluid Pressure (MPa): 0.7
• Maximum Fluid Pressure (psi): 100
• Maximum Fluid Temperature ( degree C): 48
• Maximum Fluid Temperature ( degree F): 120

• Maximum Paint Resistivity (megohm/cm): 1

• Minimum Paint Resistivity (megohm/cm): 3

• Nozzle Size (cm): 0.15
• Nozzle Size (in): 0.055
• Nozzle Size (mm): 1.5

• Overall Length (cm): 27.94
• Overall Length (in): 11
• Overall Length (mm): 279.4

GG HE80-0102

QUANTM H80, 1.5" Tri-clamp, 3A SST Electric Diaphragm Pump 200-240 V FEP AL SS PT PS

GG HSMD5B

XD SERIES 30 REEL, 3/4 X 50, OIL, BLUE

Graco HSMD5B XD30, Oil, 3/4 in. (19 mm) Inlet, 3/4 in. X 50 ft. (19 mm X 15 m) Hose, NPT, Truck/Bench Mount, Metallic Blue

Graco's XD30 Series Hose Reels are used in applications requiring longer-range dispense and higher capacity than the standard XD10 and XD20 Series. The Compact pedestal and spool fits into tight spaces and can accommodate 30-75 foot (9.1-22.8 meters) hose capacity for a wide variety of applications. Typical fluids handled include: Petroleum- and synthetic-based oils, diesel fuel, air, water, antifreeze, windshield washer fluid, pressure wash, waste oil and diesel exhaust fluid (DEF).

Application: Ideal for rugged indoor and outdoor use in heavy-duty truck dealerships, fleet maintenance, mining maintenance, public works garages, construction vehicle maintenance, agriculture and service trucks.

• Spring Adjustment - Increase or decrease spring tension while reel is pressurized with fluid
• Full-Flow Swivel - Maximize material flow with minimal pressure drop for faster fills to get more vehicles through your shop
• Optional Adjustable Arm - Easily change the arm position for your application, order with arm (HS models) or without (HN models)
• Large Hose Capacity with Small Profile - Compact pedestal and spool fits into tight spaces and can accommodate 30-75 foot (91-228 meters) hose capacity for a wide variety of applications

• Model: XD
• Series: 30

• Application: Oil

• Color: Metallic Blue

• Dry Weight (lb): 98

• Frame Type: Dual Pedestal

• Hose Inside Diameter (in): 3/4
• Hose Inside Diameter (mm): 19.05
• Hose Length (ft): 50
• Hose Length (m): 15

• Hose Reel Type: Reel with Hose
• Includes Hose: Yes
• Inlet Size (in): 3/4
• Inlet Size (mm): 19.05

• Inlet Thread Type: NPSM

• Maximum Working Pressure (psi): 1250

• Mount Location: Truck Mount, Bench Mount

• Outlet Size (in): 3/4
• Outlet Size (mm): 19.05

• Overall Height (in): 23.10
• Overall Height (mm): 588.00
• Overall Length (in): 22.12
• Overall Length (mm): 561.73
• Overall Width (in): 9.0
• Overall Width (mm): 229

• Recommended Environment: Indoor, Outdoor
• Recommended Fluid Type: Oil

GG HV-2000C-S102

Control Box, 2000C, Mikron

GG HV-2000

ADVANJET VALVE, HV-2000

Graco HV-2000 Advanjet HV-2000 Jet Valve

The Advanjet HV-2000 jet valve provides non-contact jet dispensing for the successful application of fluids in the electronic, semiconductor, industrial and life science markets. A single, easily replaceable diaphragm eliminates dynamic fluid seals common in all other jets. No need to disassemble, clean and replace worn seals, saving time and money. The diaphragm allows fast cycle rates because of its very small mass. There is no large sliding valve stem slowing down the process. With this novel diaphragm design, the energy needed to eject a drop can be adjusted providing wider process windows.

Application: The Easiest to Clean Non-Contact Jet Dispenser

• Easy to Clean
  Only two parts contact the fluid making it easy to exchange and replace parts.
• Easy to Maintain
  Unlike complicated piezo jets, the jet valve can be maintained within your factory with low-cost maintenance kits.
• Easy to Integrate
  The HV-9500 valve is a drop in replacement for existing operations. No external controller box required.
• Features:

  Up to 300 drops/sec

  Outstanding repeatability

  Viscosities up to 400K cps

  Drops as small as 10 nl

  No fluid seals to clean or replace

  Integral heater with minimal fluid heated

  Tungsten carbide internal components for long life

• Model: AdvanJet

• Application: Bonding, Sealing, Gasketing, Potting, Encapsulation, Spray, Underfill, Metering

• Component Type: Single Component

• Container Type: Cartridge

• Maximum Working Pressure (bar): 6
• Maximum Working Pressure (kg/cm 2): 6
• Maximum Working Pressure (kPa): 620
• Maximum Working Pressure (MPa): 0.6
• Maximum Working Pressure (psi): 90

• Power Type: Pneumatic

GG J6900040

Adapter, Jic(04)X3/8Npt, M, Ss

GG HXD525

HXD Rac 5 Switch Tip .525

GG JC40M9

HIGH-FLO PUMP, 2200/1000, LOW DT, OPN, NPT

Graco JC40M9 High-Flo 4-Ball Pump, CS, 4:1, Low Noise Exhaust, DataTrak, Open Wet Cup Lower, NPT Fittings, Ultralife Rod/Cylinder

Pneumatic High-Flo 4-ball piston pumps provide high output per cycle to reduce pump wear and maintenance. Ideal for low pressure, high flow applications and inherently safe for hazardous locations.

• Slow-moving reciprocating motion does not damage paint like other rotary pumping technologies
• Rugged body armor, won't rust or dent
• De-icing controls eliminate stalling
• DataTrak tracks material usage, monitors and protects your pump

• Model: High-Flo
• Series: 4-Ball

• Application: Circulation

• Compatible Material: Waterborne, Solvent borne, High Solids, Xirallic, Metallics, Topcoats, Stains, Varnish, CARC

• Fluid Outlet Size (in): 1-1/2
• Fluid Outlet Size (mm): 38.1
• Fluid Outlet Thread Type: NPT
• Fluid Section Type: Open Wet Cup

• Includes: Carbon Steel Pump, Low Noise Exhaust, DataTrak Monitor, NPT Fittings, Ultralife Rods, Ultralife Cylinder

• Material: Carbon Steel

• Maximum Air Inlet Pressure (bar): 6.9
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Continuous Cycle Rate (CPM): 12

• Maximum Flow Rate (GPM): 16.9
• Maximum Flow Rate (L/min): 63.97

• Maximum Operating Temperature ( degree C): 66
• Maximum Operating Temperature ( degree F): 150

• Maximum Working Pressure (bar): 31
• Maximum Working Pressure (kPa): 3100
• Maximum Working Pressure (MPa): 3.1
• Maximum Working Pressure (psi): 450

• Motor Type: Low Noise NXT with DataTrak

• Portable: Non-Portable

• Pump Ratio: 4:1

GG JK-2001

KIT,REPAIR,JET

KIT INCLUDES: BEARING, PIN, DIAPHRAGM [QTY. 1], SEAL, HEATER [QTY. 1], LEVER, [QTY. 1], SOLENOID, MAIN AIR [QTY. 1], SPRING, COMP, .296ODX.246ID, 5.4LB/ [QTY. 1], SCREW, SHC, SHLDR, .25ODX.652L [QTY. 1], MUFFLER, AIR, #10-32, BRONZE [QTY. 1], WASHER, FLAT, #12, NYLON, BLACK [QTY. 1], CYLINDER, ASSEMBLY, HAMMER [QTY. 1]

GG JS17A8

HIGH-FLO PUMP, 4000, LN, SLD, TRI

Graco JS17A8 High-Flo 4-Ball Pump, SST, 1.7:1, Low Noise XL, Sealed SST Lower, Ultralife Rod/Cylinder, Tri-Clamp

Pneumatic High-Flo 4-ball piston pumps provide high output per cycle to reduce pump wear and maintenance. Ideal for low pressure, high flow applications and inherently safe for hazardous locations.

• Slow-moving reciprocating motion does not damage paint like other rotary pumping technologies
• Completely sealed fluid section can be used almost anywhere, including catalyst and moisture sensitive materials
• Ultralife Series ceramic coating holds up to the harshest materials, including waterborne paints
• Rugged body armor, won't rust or dent

• Model: High-Flo
• Series: 4-Ball

• Application: Circulation

• Compatible Material: Waterborne, Solvent borne, High Solids, Xirallic, Metallics, Topcoats, Stains, Varnish, CARC

• Fluid Outlet Size (in): 1.5
• Fluid Outlet Size (mm): 38.1
• Fluid Section Type: Sealed

• Includes: Stainless Steel Pump, Low Noise Exhaust, Tri-Clamp Fittings, Ultralife Rod, Ultralife Cylinder

• Material: Stainless Steel

• Maximum Air Inlet Pressure (bar): 6.9
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Continuous Cycle Rate (CPM): 20

• Maximum Flow Rate (GPM): 21.1
• Maximum Flow Rate (L/min): 80

• Maximum Operating Temperature ( degree C): 60
• Maximum Operating Temperature ( degree F): 140

• Maximum Working Pressure (bar): 11.7
• Maximum Working Pressure (kPa): 1170
• Maximum Working Pressure (MPa): 1.2
• Maximum Working Pressure (psi): 170

• Motor Type: Low Noise XL

• Portable: Non-Portable

• Pump Ratio: 1.7:1

GG JS33A8

HIGH-FLO PUMP, 4000, LN, SLD, TRI

Graco JS33A8 High-Flo 4-Ball Pump, SST, 3.3:1, Low Noise XL, Sealed SST Lower, Ultralife Rod/Cylinder, Tri-Clamp

Pneumatic High-Flo 4-ball piston pumps provide high output per cycle to reduce pump wear and maintenance. Ideal for low pressure, high flow applications and inherently safe for hazardous locations.

• Slow-moving reciprocating motion does not damage paint like other rotary pumping technologies
• Completely sealed fluid section can be used almost anywhere, including catalyst and moisture sensitive materials
• Ultralife Series ceramic coating holds up to the harshest materials, including waterborne paints
• Rugged body armor, won't rust or dent

• Model: High-Flo
• Series: 4-Ball

• Application: Circulation

• Compatible Material: Waterborne, Solvent borne, High Solids, Xirallic, Metallics, Topcoats, Stains, Varnish, CARC

• Fluid Outlet Size (in): 1.5
• Fluid Outlet Size (mm): 50.8
• Fluid Section Type: Sealed

• Includes: Stainless Steel Pump, Low Noise Exhaust, Tri-Clamp Fittings, Ultralife Rod, Ultralife Cylinder

• Material: Stainless Steel

• Maximum Air Inlet Pressure (bar): 6.9
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Continuous Cycle Rate (CPM): 20

• Maximum Flow Rate (GPM): 21.1
• Maximum Flow Rate (L/min): 80

• Maximum Operating Temperature ( degree C): 60
• Maximum Operating Temperature ( degree F): 140

• Maximum Working Pressure (bar): 22.7
• Maximum Working Pressure (kPa): 2275
• Maximum Working Pressure (MPa): 2.3
• Maximum Working Pressure (psi): 330

• Motor Type: Low Noise XL

• Portable: Non-Portable

• Pump Ratio: 3.3:1

GG JS33B8

HIGH-FLO PUMP, 4000, LN DT, SLD, TRI

Graco JS33B8 High-Flo 4-Ball Pump, SST, 3.3:1, Low Noise, DataTrak, Sealed SST Lower, Ultralife Rod/Cylinder, Tri-Clamp

Pneumatic High-Flo 4-ball piston pumps provide high output per cycle to reduce pump wear and maintenance. Ideal for low pressure, high flow applications and inherently safe for hazardous locations.

• Slow-moving reciprocating motion does not damage paint like other rotary pumping technologies
• Completely sealed fluid section can be used almost anywhere, including catalyst and moisture sensitive materials
• Ultralife Series ceramic coating holds up to the harshest materials, including waterborne paints
• Rugged body armor, won't rust or dent
• DataTrak tracks material usage, monitors and protects your pump

• Model: High-Flo
• Series: 4-Ball

• Application: Circulation

• Compatible Material: Waterborne, Solvent borne, High Solids, Xirallic, Metallics, Topcoats, Stains, Varnish, CARC

• Fluid Outlet Size (in): 1.5
• Fluid Outlet Size (mm): 50.8
• Fluid Section Type: Sealed

• Includes: Stainless Steel Pump, Low Noise Exhaust, DataTrak Monitor, Tri-Clamp Fittings, Ultralife Rod, Ultralife Cylinder

• Material: Stainless Steel

• Maximum Air Inlet Pressure (bar): 6.9
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Continuous Cycle Rate (CPM): 20

• Maximum Flow Rate (GPM): 21.1
• Maximum Flow Rate (L/min): 80

• Maximum Operating Temperature ( degree C): 60
• Maximum Operating Temperature ( degree F): 140

• Maximum Working Pressure (bar): 22.7
• Maximum Working Pressure (kPa): 2275
• Maximum Working Pressure (MPa): 2.3
• Maximum Working Pressure (psi): 330

• Motor Type: Low Noise with DataTrak

• Portable: Non-Portable

• Pump Ratio: 3.3:1

GG JS35A8

HIGH-FLO PUMP, XL34/2000, LN, SLD, TRI

Graco JS35A8 High-Flo 4-Ball Pump, SST, 3.5:1, Low Noise XL, Sealed SST Lower, Ultralife Rod/Cylinder, Tri-Clamp

Pneumatic High-Flo 4-ball piston pumps provide high output per cycle to reduce pump wear and maintenance. Ideal for low pressure, high flow applications and inherently safe for hazardous locations.

• Slow-moving reciprocating motion does not damage paint like other rotary pumping technologies
• Completely sealed fluid section can be used almost anywhere, including catalyst and moisture sensitive materials
• Ultralife Series ceramic coating holds up to the harshest materials, including waterborne paints
• Rugged body armor, won't rust or dent

• Model: High-Flo
• Series: 4-Ball

• Application: Circulation

• Compatible Material: Waterborne, Solvent borne, High Solids, Xirallic, Metallics, Topcoats, Stains, Varnish, CARC

• Fluid Outlet Size (in): 1.5
• Fluid Outlet Size (mm): 38.1
• Fluid Section Type: Sealed

• Includes: Stainless Steel Pump, Low Noise Exhaust, Tri-Clamp Fittings, Ultralife Rod, Ultralife Cylinder

• Material: Stainless Steel

• Maximum Air Inlet Pressure (bar): 6.9
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Continuous Cycle Rate (CPM): 20

• Maximum Flow Rate (GPM): 10.6
• Maximum Flow Rate (L/min): 40

• Maximum Operating Temperature ( degree C): 60
• Maximum Operating Temperature ( degree F): 140

• Maximum Working Pressure (bar): 24.1
• Maximum Working Pressure (kPa): 2410
• Maximum Working Pressure (MPa): 2.4
• Maximum Working Pressure (psi): 350

• Motor Type: Low Noise XL

• Portable: Non-Portable

• Pump Ratio: 3.5:1

GG JS35B8

HIGH-FLO PUMP, XL34/2000, LN, DT, SLD, TRI

Graco JS35B8 High-Flo 4-Ball Pump, SST, 3.5:1, Low Noise, DataTrak, Sealed SST Lower, Ultralife Rod/Cylinder, Tri-Clamp

Pneumatic High-Flo 4-ball piston pumps provide high output per cycle to reduce pump wear and maintenance. Ideal for low pressure, high flow applications and inherently safe for hazardous locations.

• Slow-moving reciprocating motion does not damage paint like other rotary pumping technologies
• Completely sealed fluid section can be used almost anywhere, including catalyst and moisture sensitive materials
• Ultralife Series ceramic coating holds up to the harshest materials, including waterborne paints
• Rugged body armor, won't rust or dent
• DataTrak tracks material usage, monitors and protects your pump

• Model: High-Flo
• Series: 4-Ball

• Application: Circulation

• Compatible Material: Waterborne, Solvent borne, High Solids, Xirallic, Metallics, Topcoats, Stains, Varnish, CARC

• Fluid Outlet Size (in): 1.5
• Fluid Outlet Size (mm): 38.1
• Fluid Section Type: Sealed

• Includes: Stainless Steel Pump, Low Noise Exhaust, DataTrak Monitor, Tri-Clamp Fittings, Ultralife Rod, Ultralife Cylinder

• Material: Stainless Steel

• Maximum Air Inlet Pressure (bar): 6.9
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Continuous Cycle Rate (CPM): 20

• Maximum Flow Rate (GPM): 10.6
• Maximum Flow Rate (L/min): 40

• Maximum Operating Temperature ( degree C): 60
• Maximum Operating Temperature ( degree F): 140

• Maximum Working Pressure (bar): 24.1
• Maximum Working Pressure (kPa): 2410
• Maximum Working Pressure (MPa): 2.4
• Maximum Working Pressure (psi): 350

• Motor Type: Low Noise with DataTrak

• Portable: Non-Portable

• Pump Ratio: 3.5:1

GG JS40L8

HIGH-FLO PUMP, 2200/1000, LOW N, SLD, TRI

Graco JS40L8 High-Flo 4-Ball Pump, SST, 4:1, Low Noise Exhaust, Sealed SST Lower, Tri-Clamp Fittings, Ultralife Rod/Cylinder

Pneumatic High-Flo 4-ball piston pumps provide high output per cycle to reduce pump wear and maintenance. Ideal for low pressure, high flow applications and inherently safe for hazardous locations.

• Slow-moving reciprocating motion does not damage paint like other rotary pumping technologies
• Completely sealed fluid section can be used almost anywhere, including catalyst and moisture sensitive materials
• Ultralife Series ceramic coating holds up to the harshest materials, including waterborne paints
• Rugged body armor, won't rust or dent

• Model: High-Flo
• Series: 4-Ball

• Application: Circulation

• Compatible Material: Waterborne, Solvent borne, High Solids, Xirallic, Metallics, Topcoats, Stains, Varnish, CARC

• Fluid Outlet Size (in): 1-1/2
• Fluid Outlet Size (mm): 38.1
• Fluid Section Type: Sealed

• Includes: Stainless Steel Pump, Low Noise Exhaust, Tri-Clamp Fittings, Ultralife Rod, Ultralife Cylinder

• Material: Stainless Steel

• Maximum Air Inlet Pressure (bar): 6.9
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Continuous Cycle Rate (CPM): 20

• Maximum Flow Rate (GPM): 16.9
• Maximum Flow Rate (L/min): 63.97

• Maximum Operating Temperature ( degree C): 66
• Maximum Operating Temperature ( degree F): 150

• Maximum Working Pressure (bar): 28
• Maximum Working Pressure (kPa): 2800
• Maximum Working Pressure (MPa): 2.8
• Maximum Working Pressure (psi): 400

• Motor Type: Low Noise NXT

• Portable: Non-Portable

• Pump Ratio: 4:1

GG JS40M8

HIGH-FLO PUMP, 2200/1000, LOW DT, SLD, TRI

Graco JS40M8 High-Flo 4-Ball Pump, SST, 4:1, Low Noise Exhaust, DataTrak, Sealed SST Lower, Tri-Clamp Fittings, Ultralife Rod/Cylinder

Pneumatic High-Flo 4-ball piston pumps provide high output per cycle to reduce pump wear and maintenance. Ideal for low pressure, high flow applications and inherently safe for hazardous locations.

• Slow-moving reciprocating motion does not damage paint like other rotary pumping technologies
• Completely sealed fluid section can be used almost anywhere, including catalyst and moisture sensitive materials
• Ultralife Series ceramic coating holds up to the harshest materials, including waterborne paints
• Rugged body armor, won't rust or dent
• DataTrak tracks material usage, monitors and protects your pump

• Model: High-Flo
• Series: 4-Ball

• Application: Circulation

• Compatible Material: Waterborne, Solvent borne, High Solids, Xirallic, Metallics, Topcoats, Stains, Varnish, CARC

• Fluid Outlet Size (in): 1-1/2
• Fluid Outlet Size (mm): 38.1
• Fluid Section Type: Sealed

• Includes: Stainless Steel Pump, Low Noise Exhaust, DataTrak Monitor, Tri-Clamp Fittings, Ultralife Rod, Ultralife Cylinder

• Material: Stainless Steel

• Maximum Air Inlet Pressure (bar): 6.9
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Continuous Cycle Rate (CPM): 20

• Maximum Flow Rate (GPM): 16.9
• Maximum Flow Rate (L/min): 63.97

• Maximum Operating Temperature ( degree C): 66
• Maximum Operating Temperature ( degree F): 150

• Maximum Working Pressure (bar): 28
• Maximum Working Pressure (kPa): 2800
• Maximum Working Pressure (MPa): 2.8
• Maximum Working Pressure (psi): 400

• Motor Type: Low Noise NXT with DataTrak

• Portable: Non-Portable

• Pump Ratio: 4:1

GG JS44A8

HIGH-FLO PUMP, 3000, LN, SLD, TRI

Graco JS44A8 High-Flo 4-Ball Pump, SST, 4.4:1, Low Noise XL, Sealed SST Lower, Ultralife Rod/Cylinder, Tri-Clamp

Pneumatic High-Flo 4-ball piston pumps provide high output per cycle to reduce pump wear and maintenance. Ideal for low pressure, high flow applications and inherently safe for hazardous locations.

• Slow-moving reciprocating motion does not damage paint like other rotary pumping technologies
• Completely sealed fluid section can be used almost anywhere, including catalyst and moisture sensitive materials
• Ultralife Series ceramic coating holds up to the harshest materials, including waterborne paints
• Rugged body armor, won't rust or dent

• Model: High-Flo
• Series: 4-Ball

• Application: Circulation

• Compatible Material: Waterborne, Solvent borne, High Solids, Xirallic, Metallics, Topcoats, Stains, Varnish, CARC

• Fluid Outlet Size (in): 1.5
• Fluid Outlet Size (mm): 38.1
• Fluid Section Type: Sealed

• Includes: Stainless Steel Pump, Low Noise Exhaust, Tri-Clamp Fittings, Ultralife Rod, Ultralife Cylinder

• Material: Stainless Steel

• Maximum Air Inlet Pressure (bar): 6.9
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Continuous Cycle Rate (CPM): 20

• Maximum Flow Rate (GPM): 15.9
• Maximum Flow Rate (L/min): 60

• Maximum Operating Temperature ( degree C): 60
• Maximum Operating Temperature ( degree F): 140

• Maximum Working Pressure (bar): 30.3
• Maximum Working Pressure (kPa): 3030
• Maximum Working Pressure (MPa): 3
• Maximum Working Pressure (psi): 440

• Motor Type: Low Noise XL

• Portable: Non-Portable

• Pump Ratio: 4.4:1

GG JS44B8

HIGH-FLO PUMP, 3000, LN DT, SLD, TRI

Graco JS44B8 High-Flo 4-Ball Pump, SST, 4.4:1, Low Noise, DataTrak, Sealed SST Lower, Ultralife Rod/Cylinder, Tri-Clamp

Pneumatic High-Flo 4-ball piston pumps provide high output per cycle to reduce pump wear and maintenance. Ideal for low pressure, high flow applications and inherently safe for hazardous locations.

• Slow-moving reciprocating motion does not damage paint like other rotary pumping technologies
• Completely sealed fluid section can be used almost anywhere, including catalyst and moisture sensitive materials
• Ultralife Series ceramic coating holds up to the harshest materials, including waterborne paints
• Rugged body armor, won't rust or dent
• DataTrak tracks material usage, monitors and protects your pump

• Model: High-Flo
• Series: 4-Ball

• Application: Circulation

• Compatible Material: Waterborne, Solvent borne, High Solids, Xirallic, Metallics, Topcoats, Stains, Varnish, CARC

• Fluid Outlet Size (in): 1.5
• Fluid Outlet Size (mm): 38.1
• Fluid Section Type: Sealed

• Includes: Stainless Steel Pump, Low Noise Exhaust, DataTrak Monitor, Tri-Clamp Fittings, Ultralife Rod, Ultralife Cylinder

• Material: Stainless Steel

• Maximum Air Inlet Pressure (bar): 6.9
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Continuous Cycle Rate (CPM): 20

• Maximum Flow Rate (GPM): 15.9
• Maximum Flow Rate (L/min): 60

• Maximum Operating Temperature ( degree C): 60
• Maximum Operating Temperature ( degree F): 140

• Maximum Working Pressure (bar): 30.3
• Maximum Working Pressure (kPa): 3030
• Maximum Working Pressure (MPa): 3
• Maximum Working Pressure (psi): 440

• Motor Type: Low Noise with DataTrak

• Portable: Non-Portable

• Pump Ratio: 4.4:1

GG JS44D8

High-Flo Pump, 3000, Rem Dt, Sld, Tri

GG JS45A9

HIGH-FLO PUMP, XL34/1500, LN, OPN, NPT

Graco JS45A9 High-Flo 4-Ball Pump, SST, 4.5:1, Low Noise XL, Open Wet Cup SST Lower, Ultralife Rod/Cylinder, NPT

Pneumatic High-Flo 4-ball piston pumps provide high output per cycle to reduce pump wear and maintenance. Ideal for low pressure, high flow applications and inherently safe for hazardous locations.

• Slow-moving reciprocating motion does not damage paint like other rotary pumping technologies
• Rugged body armor, won't rust or dent
• De-icing controls eliminate stalling

• Model: High-Flo
• Series: 4-Ball

• Application: Circulation

• Fluid Outlet Size (in): 1.5
• Fluid Outlet Size (mm): 38.1
• Fluid Section Type: Open Wet Cup

• Includes: Stainless Steel Pump, Low Noise Exhaust, NPT Fittings, Ultralife Rod, Ultralife Cylinder

• Material: Stainless Steel

• Maximum Air Inlet Pressure (bar): 6.9
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Continuous Cycle Rate (CPM): 12

• Maximum Flow Rate (GPM): 4.8
• Maximum Flow Rate (L/min): 18

• Maximum Operating Temperature ( degree C): 60
• Maximum Operating Temperature ( degree F): 140

• Maximum Working Pressure (bar): 31
• Maximum Working Pressure (kPa): 3100
• Maximum Working Pressure (MPa): 3.1
• Maximum Working Pressure (psi): 450

• Motor Type: Low Noise XL

• Portable: Non-Portable

• Pump Ratio: 4.5:1

GG K25FW0

KING SPRAYER, 25:1, H-P, BF, WALL, BARE

Graco K25FW0 Discontinued: King 25:1 Sprayer, Integrated Filter, Wall Mount, Air Controls, Siphon Kit

Product replaced by newer version, see part number K30FW0

Application: High-quality, high-volume, high-pressure. The Graco King pneumatic airless sprayers are the most powerful machines for protective coatings. The system provides the applicator output values, pressure ratios and pumping capacities never seen before. The Graco King units are designed to withstand the harshest environmental conditions and easily handle the toughest protective coatings and corrosion control applications. With 10 different ratios available, there is a sprayer with the correct pressure and flow characteristics for your application.

• Simple Maintenance

  This air motor has 50% less parts when compared to the NXT valve, making maintenance and troubleshooting easy.

  All motor parts are easily accessible and require simple maintenance.

  • Improved Icing Performance

    The newly designed poppets and external pilot lines virtually eliminate pilot valve freezing that can result in an instant stop.

    The icing potential has been reduced by up to 70%

    • Less Pulsation

      With more than 145% higher exhaust capacity in the air valve, youll achieve a faster, smoother changeover.

      Eliminating the winkin your pattern - it is a difference you will feel.

    • New Air Motor

      Multi gun capabilities Graco's powerful new air motor lets you use multiple guns with almost no perceivable pulsation. A new manifold has been designed to simplify the installation of multiple guns.




    • Model: King
    • Approved for Hazardous Locations: Yes
    • Frame Configuration: Wall Mount
    • Gun Model: No Applicator
    • Lower Type: Integrated Filter
    • Maximum Fluid Working Pressure (psi): 2375
    • Package Options: Air Controls, Siphon Kit
    • Package Pressure Ratio (Motor/Lower): 25:1 XL3400 / 290cc

GG K30FW0

KING SPRAYER, 30:1, H-P, BF, WALL, BARE

Graco K30FW0 King 30:1 Sprayer, Integrated Filter, Wall Mount, Air Controls, Siphon Kit

High-quality, high-volume, high-pressure. The Graco King pneumatic airless sprayers are the most powerful machines for protective coatings. The system provides the applicator output values, pressure ratios and pumping capacities never seen before. The Graco King units are designed to withstand the harshest environmental conditions and easily handle the toughest protective coatings and corrosion control applications. With 10 different ratios available, there is a sprayer with the correct pressure and flow characteristics for your application.

Application: Superior air-operated pumps for high-volume and high-pressure waterproofing, fireproofing and protective coatings

• Simple Maintenance

  This air motor has 50% less parts when compared to the NXT valve, making maintenance and troubleshooting easy.

  All motor parts are easily accessible and require simple maintenance.

  • Improved Icing Performance

    The newly designed poppets and external pilot lines virtually eliminate pilot valve freezing that can result in an instant stop.

    The icing potential has been reduced by up to 70%

    • Less Pulsation

      With more than 145% higher exhaust capacity in the air valve, youll achieve a faster, smoother changeover.

      Eliminating the winkin your pattern - it is a difference you will feel.

    • New Air Motor

      Multi gun capabilities Graco's powerful new air motor lets you use multiple guns with almost no perceivable pulsation. A new manifold has been designed to simplify the installation of multiple guns.




    • Model: King
    • Approved for Hazardous Locations: Yes
    • Compatible Material: Protective Coating
    • Control Type: Fixed Ratio
    • Convertible: Non-Convertible
    • Features: Exposed Thermally Isolated Poppets, De-Icing Valve, Tool Box, Trusted XL Motor, Protective Rod Guard, Robust Air Controls, Xtreme Lowers, Improved Siphon Hose, Cart With Wheels
    • Fluid Inlet Size (in): 1-1/4
    • Fluid Inlet Size (mm): 31.75
    • Fluid Inlet Thread Type: NPT
    • Fluid Outlet Size (in): 1/2
    • Fluid Outlet Size (mm): 12.7
    • Frame Configuration: Wall Mount
    • Gun Model: No Applicator
    • Includes: Pump, Lower, Motor, Standard Filter, Wall Mount Bracket, Air Controls, Siphon Kit
    • Lower Type: Integrated Filter
    • Material Application: Paints, Primers
    • Maximum Air Inlet Pressure (psi): 150
    • Maximum Fluid Working Pressure (psi): 3150
    • Maximum Sound Pressure Level (dB(A)): 81.48
    • Maximum Tip Size (in): Variable
    • Maximum Working Pressure (bar): 217
    • Maximum Working Pressure (kPa): 21700
    • Maximum Working Pressure (MPa): 21.7
    • Maximum Working Pressure (psi): 3150
    • Motor Type: XL High Performance
    • Number of Guns: 0
    • Package Options: Air Controls, Siphon Kit
    • Package Pressure Ratio (Motor/Lower): 30:1 XL3400 / 220cc
    • Power Source: Air
    • Product Type: Single Leg
    • Pump Mount Type: Wall Mount
    • Pump Rod Type: MaxLife
    • Pump Type: Pneumatic Piston Pump

GG K30FW1

KING SPRAYER, 30:1, H-P, BF, WALL, COMP

Graco K30FW1 King 30:1 Sprayer, Integrated Filter, Wall Mount, Air Controls, Siphon Kit, XTR-5+, 50 ft (15 m) Hose, 6 ft (1.8 m) Whip

High-quality, high-volume, high-pressure. The Graco King pneumatic airless sprayers are the most powerful machines for protective coatings. The system provides the applicator output values, pressure ratios and pumping capacities never seen before. The Graco King units are designed to withstand the harshest environmental conditions and easily handle the toughest protective coatings and corrosion control applications. With 10 different ratios available, there is a sprayer with the correct pressure and flow characteristics for your application.

Application: Superior air-operated pumps for high-volume and high-pressure waterproofing, fireproofing and protective coatings

• Simple Maintenance

  This air motor has 50% less parts when compared to the NXT valve, making maintenance and troubleshooting easy.

  All motor parts are easily accessible and require simple maintenance.

  • Improved Icing Performance

    The newly designed poppets and external pilot lines virtually eliminate pilot valve freezing that can result in an instant stop.

    The icing potential has been reduced by up to 70%

    • Less Pulsation

      With more than 145% higher exhaust capacity in the air valve, youll achieve a faster, smoother changeover.

      Eliminating the winkin your pattern - it is a difference you will feel.

    • New Air Motor

      Multi gun capabilities Graco's powerful new air motor lets you use multiple guns with almost no perceivable pulsation. A new manifold has been designed to simplify the installation of multiple guns.




    • Model: King
    • Approved for Hazardous Locations: Yes
    • Compatible Material: Protective Coating
    • Control Type: Fixed Ratio
    • Convertible: Non-Convertible
    • Features: Exposed Thermally Isolated Poppets, De-Icing Valve, Tool Box, Trusted XL Motor, Protective Rod Guard, Robust Air Controls, Xtreme Lowers, Improved Siphon Hose, Cart With Wheels
    • Fluid Inlet Size (in): 1-1/4
    • Fluid Inlet Size (mm): 31.75
    • Fluid Inlet Thread Type: NPT
    • Fluid Outlet Size (in): 1/2
    • Fluid Outlet Size (mm): 12.7
    • Frame Configuration: Wall Mount
    • Gun Model: XTR-5
    • Includes: Pump, Lower, Motor, Standard Filter, Wall Mount Bracket, Air Controls, Siphon Kit, Hose, Gun
    • Lower Type: Integrated Filter
    • Material Application: Paints, Primers
    • Maximum Air Inlet Pressure (psi): 150
    • Maximum Fluid Working Pressure (psi): 3150
    • Maximum Sound Pressure Level (dB(A)): 81.48
    • Maximum Tip Size (in): Variable
    • Maximum Working Pressure (bar): 217
    • Maximum Working Pressure (kPa): 21700
    • Maximum Working Pressure (MPa): 21.7
    • Maximum Working Pressure (psi): 3150
    • Motor Type: XL High Performance
    • Number of Guns: 1
    • Package Options: Air Controls, Siphon Kit, Hose, Gun
    • Package Pressure Ratio (Motor/Lower): 30:1 XL3400 / 220cc
    • Power Source: Air
    • Product Type: Single Leg
    • Pump Mount Type: Wall Mount
    • Pump Rod Type: MaxLife
    • Pump Type: Pneumatic Piston

GG K40FH1

KING SPRAYER, 40:1, H-P, BF, HD, COMP

Graco K40FH1 King 40:1 Sprayer, Integrated Filter, Heavy Duty Cart, Air Controls, Siphon Kit, XTR-5+, 50 ft (15 m) Hose, 6 ft (1.8 m) Whip

High-quality, high-volume, high-pressure. The Graco King pneumatic airless sprayers are the most powerful machines for protective coatings. The system provides the applicator output values, pressure ratios and pumping capacities never seen before. The Graco King units are designed to withstand the harshest environmental conditions and easily handle the toughest protective coatings and corrosion control applications. With 10 different ratios available, there is a sprayer with the correct pressure and flow characteristics for your application.

Application: Superior air-operated pumps for high-volume and high-pressure waterproofing, fireproofing and protective coatings

• Simple Maintenance

  This air motor has 50% less parts when compared to the NXT valve, making maintenance and troubleshooting easy.

  All motor parts are easily accessible and require simple maintenance.

  • Improved Icing Performance

    The newly designed poppets and external pilot lines virtually eliminate pilot valve freezing that can result in an instant stop.

    The icing potential has been reduced by up to 70%

    • Less Pulsation

      With more than 145% higher exhaust capacity in the air valve, youll achieve a faster, smoother changeover.

      Eliminating the winkin your pattern - it is a difference you will feel.

    • New Air Motor

      Multi gun capabilities Graco's powerful new air motor lets you use multiple guns with almost no perceivable pulsation. A new manifold has been designed to simplify the installation of multiple guns.




    • Model: King
    • Air Inlet Size (in): 1
    • Air Inlet Thread Gender: Female
    • Air Inlet Thread Type: NPT
    • Approved for Hazardous Locations: Yes
    • Compatible Material: Protective Coating
    • Control Type: Fixed Ratio
    • Convertible: Non-Convertible
    • Features: Exposed Thermally Isolated Poppets, De-Icing Valve, Tool Box, Trusted XL Motor, Protective Rod Guard, Robust Air Controls, Xtreme Lowers, Improved Siphon Hose, Cart With Wheels
    • Fluid Inlet Size (in): 1-1/4
    • Fluid Inlet Size (mm): 31.75
    • Fluid Inlet Thread Gender: Male
    • Fluid Inlet Thread Type: NPT
    • Fluid Outlet Size (in): 1/2
    • Fluid Outlet Size (mm): 12.7
    • Fluid Outlet Thread Gender: Female
    • Fluid Outlet Thread Type: NPT
    • Frame Configuration: Heavy-Duty Cart
    • Gun Model: XTR-5
    • Includes: Pump, Lower, Motor, Standard Filter, Heavy Duty Cart, Air Controls, Siphon Kit, Hose, Gun
    • Lower Type: Integrated Filter
    • Material Application: Paints, Primers
    • Maximum Air Inlet Pressure (psi): 150
    • Maximum Air Pressure (bar): 7
    • Maximum Air Pressure (kPa): 700
    • Maximum Air Pressure (psi): 100
    • Maximum Fluid Working Pressure (psi): 3800
    • Maximum Sound Pressure Level (dB(A)): 81.48
    • Maximum Tip Size (in): Variable
    • Maximum Working Pressure (bar): 262
    • Maximum Working Pressure (kPa): 26200
    • Maximum Working Pressure (MPa): 26.2
    • Maximum Working Pressure (psi): 3800
    • Motor Type: XL Hi

GG K40NH0

KING SPRAYER, 40:1, H-P, NF, HD, BARE

Graco K40NH0 Discontinued: King 40:1 Sprayer, Non-Filter, Heavy Duty Cart, Air Controls, Siphon Kit

Product replaced by newer version, see part number K40FH0

Application: Superior air-operated pumps for high-volume and high-pressure waterproofing, fireproofing and protective coatings

• Simple Maintenance

  This air motor has 50% less parts when compared to the NXT valve, making maintenance and troubleshooting easy.

  All motor parts are easily accessible and require simple maintenance.

  • Improved Icing Performance

    The newly designed poppets and external pilot lines virtually eliminate pilot valve freezing that can result in an instant stop.

    The icing potential has been reduced by up to 70%

    • Less Pulsation

      With more than 145% higher exhaust capacity in the air valve, youll achieve a faster, smoother changeover.

      Eliminating the winkin your pattern - it is a difference you will feel.

    • New Air Motor

      Multi gun capabilities Graco's powerful new air motor lets you use multiple guns with almost no perceivable pulsation. A new manifold has been designed to simplify the installation of multiple guns.




    • Model: King
    • Approved for Hazardous Locations: Yes
    • Compatible Material: Protective Coating
    • Control Type: Fixed Ratio
    • Convertible: Non-Convertible
    • Features: Exposed Thermally Isolated Poppets, De-Icing Valve, Tool Box, Trusted XL Motor, Protective Rod Guard, Robust Air Controls, Xtreme Lowers, Improved Siphon Hose, Cart With Wheels
    • Fluid Inlet Size (in): 1-1/4
    • Fluid Inlet Size (mm): 31.75
    • Fluid Inlet Thread Type: NPT
    • Fluid Outlet Size (in): 1/2
    • Fluid Outlet Size (mm): 12.7
    • Fluid Outlet Thread Type: NPT
    • Frame Configuration: Heavy-Duty Cart
    • Gun Model: No Applicator
    • Includes: Pump, Lower, Motor, Standard Non-Filter, Heavy Duty Cart, Air Controls, Siphon Kit
    • Lower Type: Non-Filter
    • Material Application: Paints, Primers
    • Maximum Air Inlet Pressure (psi): 150
    • Maximum Fluid Working Pressure (psi): 3800
    • Maximum Sound Pressure Level (dB(A)): 81.48
    • Maximum Tip Size (in): Variable
    • Maximum Working Pressure (bar): 262
    • Maximum Working Pressure (kPa): 26200
    • Maximum Working Pressure (MPa): 26.2
    • Maximum Working Pressure (psi): 3800
    • Motor Type: XL High Performance
    • Number of Guns: 0
    • Package Options: Air Controls, Siphon Kit
    • Package Pressure Ratio (Motor/Lower): 40:1 XL3400 / 180cc
    • Power Source: Air
    • Product Type: Single Leg
    • Pump Mount Type: Heavy-Duty Cart
    • Pump Rod Type: MaxLife
    • Pump Type: Pneumatic Piston Pump

GG K45FH0

KING SPRAYER, 45:1, H-P, BF, HD, BARE

Graco K45FH0 King 45:1 Sprayer, Integrated Filter, Heavy Duty Cart, Air Controls, Siphon Kit

High-quality, high-volume, high-pressure. The Graco King pneumatic airless sprayers are the most powerful machines for protective coatings. The system provides the applicator output values, pressure ratios and pumping capacities never seen before. The Graco King units are designed to withstand the harshest environmental conditions and easily handle the toughest protective coatings and corrosion control applications. With 10 different ratios available, there is a sprayer with the correct pressure and flow characteristics for your application.

Application: Superior air-operated pumps for high-volume and high-pressure waterproofing, fireproofing and protective coatings

• Simple Maintenance

  This air motor has 50% less parts when compared to the NXT valve, making maintenance and troubleshooting easy.

  All motor parts are easily accessible and require simple maintenance.

  • Improved Icing Performance

    The newly designed poppets and external pilot lines virtually eliminate pilot valve freezing that can result in an instant stop.

    The icing potential has been reduced by up to 70%

    • Less Pulsation

      With more than 145% higher exhaust capacity in the air valve, youll achieve a faster, smoother changeover.

      Eliminating the winkin your pattern - it is a difference you will feel.

    • New Air Motor

      Multi gun capabilities Graco's powerful new air motor lets you use multiple guns with almost no perceivable pulsation. A new manifold has been designed to simplify the installation of multiple guns.




    • Model: King
    • Approved for Hazardous Locations: Yes
    • Compatible Material: Protective Coating
    • Control Type: Fixed Ratio
    • Convertible: Non-Convertible
    • Features: Exposed Thermally Isolated Poppets, De-Icing Valve, Tool Box, Trusted XL Motor, Protective Rod Guard, Robust Air Controls, Xtreme Lowers, Improved Siphon Hose, Cart With Wheels
    • Fluid Inlet Size (in): 1-1/4
    • Fluid Inlet Size (mm): 31.75
    • Fluid Inlet Thread Type: NPT
    • Fluid Outlet Size (in): 1/2
    • Fluid Outlet Size (mm): 12.7
    • Fluid Outlet Thread Type: NPT
    • Frame Configuration: Heavy-Duty Cart
    • Gun Model: No Applicator
    • Includes: Pump, Lower, Motor, Standard Filter, Heavy Duty Cart, Air Controls, Siphon Kit
    • Lower Type: Integrated Filter
    • Material Application: Paints, Primers
    • Maximum Air Inlet Pressure (psi): 150
    • Maximum Fluid Working Pressure (psi): 4500
    • Maximum Sound Pressure Level (dB(A)): 81.48
    • Maximum Tip Size (in): Variable
    • Maximum Working Pressure (bar): 310
    • Maximum Working Pressure (kPa): 31000
    • Maximum Working Pressure (MPa): 31
    • Maximum Working Pressure (psi): 4500
    • Motor Type: XL High Performance
    • Number of Guns: 0
    • Package Options: Air Controls, Siphon Kit
    • Package Pressure Ratio (Motor/Lower): 45:1 XL6500 / 290cc
    • Power Source: Air
    • Product Type: Single Leg
    • Pump Mount Type: Heavy-Duty Cart
    • Pump Rod Type: MaxLife
    • Pump Type: Pneumatic Piston Pump
