BLOCK, BSPLT INTERM MXP 1/4 NPSF

GG 563519

BLOCK, BSPLT INTERM MXP 1/4 NPSF

Graco 563519 Trabon® MXP Divider Valve - Intermediate Base Plate - NPSF

Application: For use with Trabon® MXP Divider Valves.

Intermediate Base
Must be ordered in multiples of 2
1/4-18 NPSF

Model: Trabon
Series: MXP

Application: In-Plant Machinery
Inlet Size (cm): 0.635
Inlet Size (in): 1/4
Inlet Size (mm): 6.35
Inlet Thread Type: NPSF
Outlet Size (cm): 0.635
Outlet Size (in): 1/4
Outlet Size (mm): 6.35
Outlet Thread Type: NPSF

$116.00

SWIVEL, BEARING, 90DEG, 1/2 NPT

GG 564350

SWIVEL, BEARING, 90DEG, 1/2 NPT

Ball Bearing 90º Angle Swivel - 1/2 inch (12.7 mm)

90º Angle Swivel - 1/2 inch (12.7 mm)

Lubriquip part number 503-706-001

$725.00

ADAPTER, OUTLET TO HAND PUMP

GG 571167

ADAPTER, OUTLET TO HAND PUMP

Pump Outlet Adapter For use with G-Series Pumps and G3 Grease Gun.

$65.25

Adapter, Seat

GG 617479

Adapter, Seat

$2,120.00

MODULE, INJ, 24V, HP, 60#, TANK, F, LL

GG 77X104

MODULE, INJ, 24V, HP, 60#, TANK, F, LL

Graco 77X104 Electric Dyna-Star® HP 24 VDC Injector Module with Pump, Tube-in-Tube, Vent Valve, Follower Plate, LL Kit, Cover, Tank for 60 lb (27 kg). Reservoir

The Dyna-Star HP and HF 24VDC Electric Lubrication Pumps complement our Dyna-Star 10:1 Hydraulic and Fire-Ball 300 50:1 Pneumatic pump offering. For heavy-duty construction and mining equipment, rely on the Electric Dyna-star to supply fresh lubricant and flush contaminants from critical pivot points. An automatic lubrication system from Graco provides continuous lube replenishment, reducing expensive component failures to keep your equipment working.

Application: For use in mining operations, milling and crushing, heavy-duty construction, well services, and industrial.

High-quality helical hardened steel gears are lubricated for life and sealed to keep contaminants out for longer lasting performance.
Ability to adjust motor controls like power input, motor speed, current control and signal input to perfectly match the pump to your application and environmental changes.
Mechanical auto-fill shutoff and remote-mounted fill port ensures clean and efficient refills.
IP69K rated
Built-in pressure relief for safety and compact, efficient installations.
Cavitation-free fill and vent path provides simple and direct venting and filling to the foot of the pump.
Built-in lift ring is rated to 500 lbs (226 kg).
Strong 12 gauge steel reservoir, 60 lb (27 kg) size.
AC to DC Converter Box for fixed and in-plant applications.

Model: Dyna-Star

Air Inlet Size (in): 1/4
Air Inlet Size (mm): 6.35
Air Inlet Thread Type: NPT
Application: In-Plant Machinery, Off-Road Equipment
Compatible Material: Grease
Compatible Metering Device: Single Line Parallel
Fluid Outlet Size (in): 0.375
Fluid Outlet Size (mm): 9.5250
Fluid Outlet Thread Gender: Female
Fluid Outlet Thread Type: NPT
Includes: HP Pump 24 VDC, tube-in-tube, Vent Valve, cover, 60 lb. reservoir
IP Rating: IP69K
Maximum Working Pressure (bar): 241
Maximum Working Pressure (kPa): 24100
Maximum Working Pressure (MPa): 24.1
Maximum Working Pressure (psi): 3500
Minimum cST Grade (cST): 40
Overall Height (cm): 77.5
Overall Height (in): 30.5
Overall Height (mm): 775
Overall Width (cm): 36.8
Overall Width (in): 14.5
Overall Width (mm): 368
Power Connection Type: M12
Power Type: Pneumatic

$9,260.00

KIT, STDRUM, 24VDC, HF, 400#

GG 77X122

KIT, STDRUM, 24VDC, HF, 400#

Graco 77X122 Standard Drum Kits - 24 VDC HF Pump and Cover for 400 lb (180 kg). Reservoir

The Dyna-Star HP and HF 24VDC Electric Lubrication Pumps complement our Dyna-Star 10:1 Hydraulic and Fire-Ball 300 50:1 Pneumatic pump offering. Now you have three power source options for automatic lubrication systems and transfer applications. Heavy-duty construction and mining equipment rely on fresh lubricant to flush contaminants from critical pivot points. An automatic lubrication system from Graco provides continuous lube replenishment, reducing expensive component failures to keep your equipment working.

Application: Electric pumps for heavy duty automatic lubrication and transfer systems.

Auto Fill Shut Off - mechanical shut off of fill pump for clean and efficient refill
Graco Advantage Drive™ - heavy duty gear drive-lubed for life
Tube-in-tube vent and fill path - convert drum to injector system instantly
Motor control - speed and AMP control
Cold weather performance (-40º C)
More efficient seal replacement

Air Inlet Size (in): 1/4
Air Inlet Size (mm): 6.35
Air Inlet Thread Type: NPT

Application: In-Plant Machinery, Off-Road Equipment
Compatible Material: Grease
Compatible Metering Device: Single Line Parallel
Fluid Outlet Size (in): 0.375
Fluid Outlet Size (mm): 9.5250
Fluid Outlet Thread Type: NPT
Includes: HF Pump 24 VDC, Cover for 120 lb (54 kg) reservoir
IP Rating: IP69K
Maximum Working Pressure (bar): 241
Maximum Working Pressure (kPa): 24100
Maximum Working Pressure (MPa): 24.1
Maximum Working Pressure (psi): 3500
Minimum cST Grade (cST): 40
Overall Height (cm): 112.5
Overall Height (in): 44.3
Overall Height (mm): 1125
Overall Width (cm): 27.9
Overall Width (in): 11
Overall Width (mm): 279
Power Connection Type: M23
Power Type: Pneumatic

$7,580.00

G-FORCE II TIP, SPRAY, Q-TYPE

GG 805538

G-FORCE II TIP, SPRAY, Q-TYPE

Washer Spray Tip, 4003 Maximize your cleaning power by selecting the tip that best matches the maximum pressure and flow of your pressure washer. For lower pressure spraying, choose a larger size tip to maximize your flow and cleaning power.

40 Degree Washing Tip

Wide spray for washing or rinsing a large area.

$7.25

G-FORCE II TIP, SPRAY, Q-TYPE

GG 805549

G-FORCE II TIP, SPRAY, Q-TYPE

Graco 805549 Washer Spray Tip, 25045

Maximize your cleaning power by selecting the tip that best matches the maximum pressure and flow of your pressure washer. For lower pressure spraying, choose a larger size tip to maximize your flow and cleaning power.

25 Degree Flushing Tip
Color: Green
Connection Size (in): 0.25
Connection Type: Quick Disconnect
For Use With: AquaMax, G-Force, G-Force II, Hydra-Clean
Material: Stainless Steel
Maximum Working Pressure (bar): 345
Maximum Working Pressure (kPa): 34500
Maximum Working Pressure (psi): 5000
Nominal Size: 25045
Orifice Diameter (in): 0.045

$7.25

PROMIX PD2K PROPORTIONER, SYS, PD1K, AUTO, DP

GG AC0502

PROMIX PD2K PROPORTIONER, SYS, PD1K, AUTO, DP

Graco AC0502 ProMix PD2K Automatic Proportioner, Dual Panel, Control Module Only

100% Positive Displacement Technology for accurate mix ratios and consistent performance. Great for short pot life materials, the ProMix PD mixes the material close to the gun so the flush zone is significantly smaller. This allows for faster color changes, less material usage and disposal costs overall.

Up to 80% reduction in flushing waste over the most efficient traditional proportioning systems
Faster color changes and less material to flush mean less waste and less downtime
Stalls under pressure for consistent, on-ratio results (within 1% accuracy)
Field serviceable in less than 20 minutes - no need for costly factory rebuilds like gear pumps

Model: ProMix
Series: PD2K

Air Inlet Size (cm): 0.9525
Air Inlet Size (in): 3/8
Air Inlet Size (mm): 9.525
Air Inlet Thread Gender: Female
Air Inlet Thread Type: NPT
Applicator Type: Automatic
Component Type: Single Component
Flush Type: Solvent
Frequency (Hz): 50/60
Gun Activation: Automatic
Material Type: Single Component
Maximum Mix Ratio: 50:1
Maximum Number of Colors: Up to 16
Maximum Working Pressure (bar): 7
Maximum Working Pressure (kPa): 700
Maximum Working Pressure (MPa): 0.7
Maximum Working Pressure (psi): 100
Measuring Type: Meter
Minimum Mix Ratio: 0.1:1
Mix Accuracy (%): 1
Number of Catalysts: Up to 4
Number of Color Valves: N/A
Number of Resin Colors: Up to 30
Power Source: Electric
Pressure Type: Low or High Pressure
Proportioner Type: Automatic
Proportioning Type: Automatic Electronic

$39,470.00

RAC X FFLP TIP, SPRAY, (108)

GG FFLP108

RAC X FFLP TIP, SPRAY, (108)

Graco FFLP108 Fine Finish Low Pressure RAC X FF LP SwitchTip, 108

Spray at up to 50% lower pressure with the Reverse-A-Clean (RAC) 108 Fine Finish Low Pressure (FF LP) RAC X SwitchTip. This fine finish tip produces a 2 to 4 inch fann pattern and has a 0.008 inch orifice, ideal for finishing materials. Reverse the SwitchTip to easily clear clogs.

Application: For fine finish applications

Less Prep & Cleanup Time
Less mess with less overspray
Put the paint where you want it
Easiest Pattern Overlap
Softer spray fan pattern
Easy to apply any material to any surfance
Consistent blended finish quality
Extended Life
Spraying at half pressure doubles tip life
Reduced sprayer maintenance – up to 2X life
Best Tip on the Market
Works with any airless sprayer
Longest lasting fann pattern
Highest quality finish with a consistent spray pattern
Easy to Identify Tip Size
Large raised tip size numbers are always legible – even when covered with paint
Superior Tip Design
Locking tab ensures tip stays securely in guard
Snaps tip in spray or reverse position
OneSeal tip gasket installs with no tools
Solvent seal available when using extremely hot solvents

Model: RAC X
Series: FF LP SwitchTip

Compatible Material: Primer, Stains, Varnish, Water-Based Paint, Enamel, Latex, Solvent borne Paints
For Use With: RAC X HandTite Tip Guard
Material: Tungsten Carbide
Maximum Fan Width (cm): 5
Maximum Fan Width (in): 2
Maximum Fan Width (mm): 102
Maximum Flow Rate (GPM): 0.07
Maximum Flow Rate (L/min): 0.26
Maximum Working Pressure (bar): 280
Maximum Working Pressure (kPa): 28000
Maximum Working Pressure (psi): 4050
Minimum Fan Width (in): 2
Minimum Fan Width (mm): 51
Orifice Diameter (in): 0.008
Pattern Size (in): 2 to 4
Pattern Size (mm): 50.8 to 101.6

$82.00

RAC X FFLP TIP, SPRAY, (110)

GG FFLP110

RAC X FFLP TIP, SPRAY, (110)

Fine Finish Low Pressure RAC X FF LP SwitchTip, 110 Spray at up to 50% lower pressure with the Reverse-A-Clean (RAC) 110 Fine Finish Low Pressure (FF LP) RAC X SwitchTip. This fine finish tip produces a 2 to 4 inch Fan pattern and has a 0.010 inchorifice, ideal for finishing materials. Reverse the SwitchTip to easily clear clogs. For fine finish applications Less Prep & Cleanup Time

Less mess with less overspray
Put the paint where you want it

Easiest Pattern Overlap

Softer spray fan pattern
Easy to apply any material to any surfance
Consistent blended finish quality

Extended Life

Spraying at half pressure doubles tip life
Reduced sprayer maintenance – up to 2X life

SmartTip Technology

Exclusive internal tip geometry
Reduces energy required to atomize paints, stains, and other materials
Delivers a superior finish with less pressure
Works with SmartControl on select Graco sprayers

Best Tip on the Market

Works with any airless sprayer
Longest lasting Fan pattern
Highest quality finish with a consistent spray pattern

Easy to Identify Tip Size

Large raised tip size numbers are always legible – even when covered with paint

Superior Tip Design

Locking tab ensures tip stays securely in guard
Snaps tip in spray or reverse position
OneSeal tip gasket installs with no tools
Solvent seal available when using extremely hot solvents

$82.00

RAC X FFLP TIP, SPRAY, (112)

GG FFLP112

RAC X FFLP TIP, SPRAY, (112)

Graco FFLP112 Fine Finish Low Pressure RAC X FF LP SwitchTip, 112

Spray at up to 50% lower pressure with the Reverse-A-Clean (RAC) 112 Fine Finish Low Pressure (FF LP) RAC X SwitchTip. This fine finish tip produces a 2 to 4 inch Fan pattern and has a 0.012 inch orifice, ideal for finishing materials. Reverse the SwitchTip to easily clear clogs.

Application: For fine finish applications

Less Prep & Cleanup Time
Less mess with less overspray
Put the paint where you want it
Easiest Pattern Overlap
Softer spray fan pattern
Easy to apply any material to any surfance
Consistent blended finish quality
Extended Life
Spraying at half pressure doubles tip life
Reduced sprayer maintenance – up to 2X life
Best Tip on the Market
Works with any airless sprayer
Longest lasting Fan pattern
Highest quality finish with a consistent spray pattern
Easy to Identify Tip Size
Large raised tip size numbers are always legible – even when covered with paint
Superior Tip Design
Locking tab ensures tip stays securely in guard
Snaps tip in spray or reverse position
OneSeal tip gasket installs with no tools
Solvent seal available when using extremely hot solvents

Model: RAC X
Series: FF LP SwitchTip

Compatible Material: Primer, Stains, Varnish, Water-Based Paint, Enamel, Latex, Solvent borne Paints
For Use With: RAC X HandTite Tip Guard
Material: Tungsten Carbide
Maximum Fan Width (cm): 5
Maximum Fan Width (in): 2
Maximum Fan Width (mm): 102
Maximum Flow Rate (GPM): 0.15
Maximum Flow Rate (L/min): 0.57
Maximum Working Pressure (bar): 280
Maximum Working Pressure (kPa): 28000
Maximum Working Pressure (psi): 4050
Minimum Fan Width (in): 2
Minimum Fan Width (mm): 51
Orifice Diameter (in): 0.012
Pattern Size (in): 2 to 4
Pattern Size (mm): 50.8 to 101.6

$82.00

RAC X FFLP TIP, SPRAY, (208)

GG FFLP208

RAC X FFLP TIP, SPRAY, (208)

Fine Finish Low Pressure RAC X FF LP SwitchTip, 208 Spray at up to 50% lower pressure with the Reverse-A-Clean (RAC) 208 Fine Finish Low Pressure (FF LP) RAC X SwitchTip. This fine finish tip produces a 4 to 6 inch Fan pattern and has a 0.008 inch orifice, ideal for finishing materials. Reverse the SwitchTip to easily clear clogs. For fine finish applications Less Prep & Cleanup Time

Less mess with less overspray
Put the paint where you want it

Easiest Pattern Overlap

Softer spray fan pattern
Easy to apply any material to any surfance
Consistent blended finish quality

Extended Life

Spraying at half pressure doubles tip life
Reduced sprayer maintenance – up to 2X life

SmartTip Technology

Exclusive internal tip geometry
Reduces energy required to atomize paints, stains, and other materials
Delivers a superior finish with less pressure
Works with SmartControl on select Graco sprayers

Best Tip on the Market

Works with any airless sprayer
Longest lasting Fan pattern
Highest quality finish with a consistent spray pattern

Easy to Identify Tip Size

Large raised tip size numbers are always legible – even when covered with paint

Superior Tip Design

Locking tab ensures tip stays securely in guard
Snaps tip in spray or reverse position
OneSeal tip gasket installs with no tools
Solvent seal available when using extremely hot solvents

$82.00

RAC X FFLP TIP, SPRAY, (212)

GG FFLP212

RAC X FFLP TIP, SPRAY, (212)

Graco FFLP212 Fine Finish Low Pressure RAC X FF LP SwitchTip, 212

Spray at up to 50% lower pressure with the Reverse-A-Clean (RAC) 212 Fine Finish Low Pressure (FF LP) RAC X SwitchTip. This fine finish tip produces a 4 to 6 inch Fan pattern and has a 0.012 inch orifice, ideal for finishing materials. Reverse the SwitchTip to easily clear clogs.

Application: For fine finish applications

Less Prep & Cleanup Time
Less mess with less overspray
Put the paint where you want it
Easiest Pattern Overlap
Softer spray fan pattern
Easy to apply any material to any surfance
Consistent blended finish quality
Extended Life
Spraying at half pressure doubles tip life
Reduced sprayer maintenance – up to 2X life
Best Tip on the Market
Works with any airless sprayer
Longest lasting Fan pattern
Highest quality finish with a consistent spray pattern
Easy to Identify Tip Size
Large raised tip size numbers are always legible – even when covered with paint
Superior Tip Design
Locking tab ensures tip stays securely in guard
Snaps tip in spray or reverse position
OneSeal tip gasket installs with no tools
Solvent seal available when using extremely hot solvents

Model: RAC X
Series: FF LP SwitchTip

Compatible Material: Primer, Stains, Varnish, Water-Based Paint, Enamel, Latex, Solvent borne Paints
For Use With: RAC X HandTite Tip Guard
Material: Tungsten Carbide
Maximum Fan Width (cm): 10
Maximum Fan Width (in): 4
Maximum Fan Width (mm): 152
Maximum Flow Rate (GPM): 0.15
Maximum Flow Rate (L/min): 0.57
Maximum Working Pressure (bar): 280
Maximum Working Pressure (kPa): 28000
Maximum Working Pressure (psi): 4050
Minimum Fan Width (in): 4
Minimum Fan Width (mm): 102
Orifice Diameter (in): 0.012
Pattern Size (in): 4 to 6
Pattern Size (mm): 101.6 to 152.4

$82.00

RAC X FFLP TIP, SPRAY, (308)

GG FFLP308

RAC X FFLP TIP, SPRAY, (308)

Fine Finish Low Pressure RAC X FF LP SwitchTip, 308 Spray at up to 50% lower pressure with the Reverse-A-Clean (RAC) 308 Fine Finish Low Pressure (FF LP) RAC X SwitchTip. This fine finish tip produces a 6 to 8 inch Fan pattern and has a 0.008 inch orifice, ideal for finishing materials. Reverse the SwitchTip to easily clear clogs. For fine finish applications Less Prep & Cleanup Time

Less mess with less overspray
Put the paint where you want it

Easiest Pattern Overlap

Softer spray fan pattern
Easy to apply any material to any surfance
Consistent blended finish quality

Extended Life

Spraying at half pressure doubles tip life
Reduced sprayer maintenance – up to 2X life

SmartTip Technology

Exclusive internal tip geometry
Reduces energy required to atomize paints, stains, and other materials
Delivers a superior finish with less pressure
Works with SmartControl on select Graco sprayers

Best Tip on the Market

Works with any airless sprayer
Longest lasting Fan pattern
Highest quality finish with a consistent spray pattern

Easy to Identify Tip Size

Large raised tip size numbers are always legible – even when covered with paint

Superior Tip Design

Locking tab ensures tip stays securely in guard
Snaps tip in spray or reverse position
OneSeal tip gasket installs with no tools
Solvent seal available when using extremely hot solvents

$82.00

FITTING, QS, FEP, INIFLEX

GG FXFF01

FITTING, QS, FEP, INIFLEX

IniFlex Fitting, FEP Tube fitting style, quantity 1 Whether you’re setting up a new automated finishing system or upgrading a current installation, IniFlex makes accommodating diverse requirements and budgets more flexible than ever before. IniFlex fits into almost any industrial automation application that requires compact color change valves.

$100.50

FITTING, QS, NPT, INIFLEX

GG FXFP01

FITTING, QS, NPT, INIFLEX

IniFlex Fitting, NPT fitting style, quantity 1 Whether you’re setting up a new automated finishing system or upgrading a current installation, IniFlex makes accommodating diverse requirements and budgets more flexible than ever before. IniFlex fits into almost any industrial automation application that requires compact color change valves.

$50.75

XD SERIES 30 REEL, HOSE, 3/4 X 50, DEF, BLUE

GG HSDD5B

XD SERIES 30 REEL, HOSE, 3/4 X 50, DEF, BLUE

Graco HSDD5B XD30™, DEF, 3/4 in. (19 mm) Inlet, 3/4 in. X 50 ft. (19 mm X 15 m) Hose, NPT, Truck/Bench Mount, Metallic Blue

Graco’s XD30 Series Hose Reels are used in applications requiring longer-range dispense and higher capacity than the standard XD10 and XD20 Series. The Compact pedestal and spool fits into tight spaces and can accommodate 30-75 foot (9.1-22.8 meters) hose capacity for a wide variety of applications. Typical fluids handled include: Petroleum- and synthetic-based oils, diesel fuel, air, water, antifreeze, windshield washer fluid, pressure wash, waste oil and diesel exhaust fluid (DEF).

Application: Ideal for rugged indoor and outdoor use in heavy-duty truck dealerships, fleet maintenance, mining maintenance, public works garages, construction vehicle maintenance, agriculture and service trucks.

Spring Adjustment - Increase or decrease spring tension while reel is pressurized with fluid
Full-Flow Swivel - Maximize material flow with minimal pressure drop for faster fills to get more vehicles through your shop
Optional Adjustable Arm - Easily change the arm position for your application, order with arm (HS models) or without (HN models)
Large Hose Capacity with Small Profile - Compact pedestal and spool fits into tight spaces and can accommodate 30-75 foot (91-228 meters) hose capacity for a wide variety of applications

Model: XD
Series: 30

Application: Diesel Fuel
Color: Metallic Blue
Frame Type: Dual Pedestal
Hose Inside Diameter (in): 3/4
Hose Inside Diameter (mm): 19.05
Hose Length (ft): 50
Hose Length (m): 15
Hose Reel Type: Reel with Hose
Includes Hose: Yes
Inlet Size (in): 3/4
Inlet Size (mm): 19.05
Inlet Thread Type: BSPP
Maximum Working Pressure (psi): 50
Mount Location: Truck Mount, Bench Mount
Outlet Size (in): 3/4
Outlet Size (mm): 19.05
Overall Height (in): 23.10
Overall Height (mm): 588
Overall Length (in): 22.12
Overall Length (mm): 561.73
Overall Width (in): 9.0
Overall Width (mm): 229
Recommended Environment: Indoor, Outdoor
Recommended Fluid Type: DEF

$2,700.00

XD SERIES 30 REEL, 3/4 X 50, A/W, BLUE

GG HSLD5B

XD SERIES 30 REEL, 3/4 X 50, A/W, BLUE

Graco HSLD5B XD30™, Air/Water/Antifreeze/WWS, 3/4 in. (19 mm) Inlet, 3/4 in. X 50 ft. (19 mm X 15 m) Hose, NPT, Truck/Bench Mount, Metallic Blue

Spring Adjustment - Increase or decrease spring tension while reel is pressurized with fluid
Full-Flow Swivel - Maximize material flow with minimal pressure drop for faster fills to get more vehicles through your shop
Optional Adjustable Arm - Easily change the arm position for your application, order with arm (HS models) or without (HN models)
Large Hose Capacity with Small Profile - Compact pedestal and spool fits into tight spaces and can accommodate 30-75 foot (91-228 meters) hose capacity for a wide variety of applications

Model: XD
Series: 30

Application: Air, Water, Antifreeze, WWS
Color: Metallic Blue
Dry Weight (lb): 98
Frame Type: Dual Pedestal
Hose Inside Diameter (in): 3/4
Hose Inside Diameter (mm): 19.05
Hose Length (ft): 50
Hose Length (m): 15
Hose Reel Type: Reel with Hose
Includes Hose: Yes
Inlet Size (in): 3/4
Inlet Size (mm): 19.05
Inlet Thread Type: NPSM
Maximum Working Pressure (psi): 300
Mount Location: Truck Mount, Bench Mount
Outlet Size (in): 3/4
Outlet Size (mm): 19.05
Overall Height (in): 23.10
Overall Height (mm): 588.00
Overall Length (in): 22.12
Overall Length (mm): 561.73
Overall Width (in): 9.0
Overall Width (mm): 229
Recommended Environment: Indoor, Outdoor
Recommended Fluid Type: Air, Water, Antifreeze, WWS

$1,825.00

XD SERIES 30 REEL, 3/4 X 50, OIL, BLUE

GG HSMD5B

XD SERIES 30 REEL, 3/4 X 50, OIL, BLUE

XD30™, Oil, 3/4 in. (19 mm) Inlet, 3/4 in. X 50 ft. (19 mm X 15 m) Hose, NPT, Truck/Bench Mount, Metallic Blue Graco’s XD30 Series Hose Reels are used in applications requiring longer-range dispense and higher capacity than the standard XD10 and XD20 Series. The Compact pedestal and spool fits into tight spaces and can accommodate 30-75 foot (9.1-22.8 meters) hose capacity for a wide variety of applications. Typical fluids handled include: Petroleum- and synthetic-based oils, diesel fuel, air, water, antifreeze, windshield washer fluid, pressure wash, waste oil and diesel exhaust fluid (DEF). Ideal for rugged indoor and outdoor use in heavy-duty truck dealerships, fleet maintenance, mining maintenance, public works garages, construction vehicle maintenance, agriculture and service trucks. Spring Adjustment - Increase or decrease spring tension while reel is pressurized with fluid Full-Flow Swivel - Maximize material flow with minimal pressure drop for faster fills to get more vehicles through your shop Optional Adjustable Arm - Easily change the arm position for your application, order with arm (HS models) or without (HN models) Durable Finish - Baked-on enamel finish protects reel from corrosion Large Hose Capacity with Small Profile - Compact pedestal and spool fits into tight spaces and can accommodate 30-75 foot (91-228 meters) hose capacity for a wide variety of applications

$2,000.00

LOWER, CHEMICAL, 010, SST, UCUP, HW

GG L010S5

LOWER, CHEMICAL, 010, SST, UCUP, HW

Graco L010S5 Z-Pump, 10cc, High Wear, S5

Z-Pumps are positive displacement pump components for use with the Graco and meter, mix, and dispense systems and are ideal for two-component sealant and adhesives requiring precision ratio, flow, and volume controls.

High Wear coatings and 1/2 inch (1.27 cm) checks easily manage material wear from thermal interface material (TIMs), acrylics, or other abrasive material applications.
Precision control eliminates pressure spikes and guarantees on ratio dispense.
Pump seals are the only wear parts, which reduces maintenance downtime and repair costs.

Model: Z-Pump
Series: S5

Ambient/Warm Melt/Hot Melt: Ambient
Application: Industrial
Ball Check Size (in): .5"
Ball Material: Silicon Nitride
Coating Type: High Wear
Feed Type: Pressure Feed
Fluid Inlet Size (cm): 1.905
Fluid Inlet Size (in): 3/4
Fluid Inlet Thread Gender: Female
Fluid Inlet Thread Type: NPT
Fluid Outlet Size (in): 3/4-16
Fluid Outlet Thread Gender: Female
Fluid Outlet Thread Type: SAE
For Use With: EFR, HFR
Maximum Flow Rate (GPM): 0.16
Maximum Operating Temperature (°F): 180
Maximum Output (cm³): 10
Maximum Pump Speed (CPM): 60
Maximum Viscosity (cP): 3000000
Maximum Working Pressure (psi): 3500

$21,390.00

LOWER, CHEMICAL, 20, SST, UCUP

GG L020S1

LOWER, CHEMICAL, 20, SST, UCUP

Z-Pump, 20 cc, Severe Duty, S1 Z-Pumps are positive displacement pump components for use with the Graco meter, mix, and dispense systems and are ideal for two-component sealant and adhesives requiring precision ratio, flow, and volume controls. Severe Duty coatings and 1 inch (2.54 cm) checks easily manage material wear from silicones, sealants, epoxies, foam, and structural adhesives. Precision control eliminates pressure spikes and guarantees on ratio dispense. Pump seals are the only wear parts, which reduces maintenance downtime and repair costs.

$11,600.00

LOWER, CHEMICAL, 80, SST, UCUP

GG L080S1

LOWER, CHEMICAL, 80, SST, UCUP

Z-Pump, 80 cc, Severe Duty, S1 Z-Pumps are positive displacement pump components for use with the Graco meter, mix, and dispense systems and are ideal for two-component sealant and adhesives requiring precision ratio, flow, and volume controls. Severe Duty coatings and 1 inch (2.54 cm) checks easily manage material wear from silicones, sealants, epoxies, foam, and structural adhesives. Precision control eliminates pressure spikes and guarantees on ratio dispense. Pump seals are the only wear parts, which reduces maintenance downtime and repair costs.

$10,980.00

LOWER, CHEMICAL, 100, S8

GG L100S8

LOWER, CHEMICAL, 100, S8

Z-Pump, 100 cc, Elite, S8 Z-Pumps are positive displacement pump components for use with the Graco and meter, mix, and dispense systems and are ideal for two-component sealant and adhesives requiring precision ratio, flow, and volume controls. Elite coatings and 7/8 inch (2.22 cm) checks easily manage material wear from thermal interface material (TIMs) or other abrasive applications. Precision control eliminates pressure spikes and guarantees on ratio dispense. Elite high-wear pump seals reduce maintenance downtime and repair costs.

$20,290.00

DURA-FLO 430 PUMP, RECIP, DISPL

GG L430SM

DURA-FLO 430 PUMP, RECIP, DISPL

Graco L430SM Dura-Flo 1800 (430 cc) Lower, Stainless Steel, 4 Leather, 3 UHMWPE Throat/3 UHMWPE, 2 Leather Piston Packings

Application: With priming piston, rod and cylinder.

Model: Dura-Flo

Application: Bonding, Sealing, Gasketing, Potting, Encapsulation, Molding, Spray, Fluid Transfer, Unloading, Underfill
Compatible Material: Motor Oil, Gear Oil, Automatic Transmission Fluid, Oil
Fluid Inlet Size (cm): 5.08
Fluid Inlet Size (in): 2
Fluid Inlet Thread Gender: Female
Fluid Inlet Thread Type: NPT
Fluid Outlet Size (in): 1-1/2
Fluid Outlet Thread Gender: Male
Fluid Outlet Thread Type: NPT
For Use With: Dura-Flo Oil Pumps
Maximum Flow Rate (GPM): 6.9
Maximum Operating Temperature (°F): 150
Maximum Output (cm³): 430
Maximum Pump Speed (CPM): 60
Maximum Working Pressure (psi): 4700

$16,670.00
