RAC X FFLP TIP, SPRAY, (208)

GG FFLP208

RAC X FFLP TIP, SPRAY, (208)

Fine Finish Low Pressure RAC X FF LP SwitchTip, 208 Spray at up to 50% lower pressure with the Reverse-A-Clean (RAC) 208 Fine Finish Low Pressure (FF LP) RAC X SwitchTip. This fine finish tip produces a 4 to 6 inch Fan pattern and has a 0.008 inch orifice, ideal for finishing materials. Reverse the SwitchTip to easily clear clogs. For fine finish applications Less Prep & Cleanup Time

Less mess with less overspray
Put the paint where you want it

Easiest Pattern Overlap

Softer spray fan pattern
Easy to apply any material to any surfance
Consistent blended finish quality

Extended Life

Spraying at half pressure doubles tip life
Reduced sprayer maintenance – up to 2X life

SmartTip Technology

Exclusive internal tip geometry
Reduces energy required to atomize paints, stains, and other materials
Delivers a superior finish with less pressure
Works with SmartControl on select Graco sprayers

Best Tip on the Market

Works with any airless sprayer
Longest lasting Fan pattern
Highest quality finish with a consistent spray pattern

Easy to Identify Tip Size

Large raised tip size numbers are always legible – even when covered with paint

Superior Tip Design

Locking tab ensures tip stays securely in guard
Snaps tip in spray or reverse position
OneSeal tip gasket installs with no tools
Solvent seal available when using extremely hot solvents

$82.00

RAC X FFLP TIP, SPRAY, (212)

GG FFLP212

RAC X FFLP TIP, SPRAY, (212)

Graco FFLP212 Fine Finish Low Pressure RAC X FF LP SwitchTip, 212

Spray at up to 50% lower pressure with the Reverse-A-Clean (RAC) 212 Fine Finish Low Pressure (FF LP) RAC X SwitchTip. This fine finish tip produces a 4 to 6 inch Fan pattern and has a 0.012 inch orifice, ideal for finishing materials. Reverse the SwitchTip to easily clear clogs.

Application: For fine finish applications

Less Prep & Cleanup Time
Less mess with less overspray
Put the paint where you want it
Easiest Pattern Overlap
Softer spray fan pattern
Easy to apply any material to any surfance
Consistent blended finish quality
Extended Life
Spraying at half pressure doubles tip life
Reduced sprayer maintenance – up to 2X life
Best Tip on the Market
Works with any airless sprayer
Longest lasting Fan pattern
Highest quality finish with a consistent spray pattern
Easy to Identify Tip Size
Large raised tip size numbers are always legible – even when covered with paint
Superior Tip Design
Locking tab ensures tip stays securely in guard
Snaps tip in spray or reverse position
OneSeal tip gasket installs with no tools
Solvent seal available when using extremely hot solvents

Model: RAC X
Series: FF LP SwitchTip

Compatible Material: Primer, Stains, Varnish, Water-Based Paint, Enamel, Latex, Solvent borne Paints
For Use With: RAC X HandTite Tip Guard
Material: Tungsten Carbide
Maximum Fan Width (cm): 10
Maximum Fan Width (in): 4
Maximum Fan Width (mm): 152
Maximum Flow Rate (GPM): 0.15
Maximum Flow Rate (L/min): 0.57
Maximum Working Pressure (bar): 280
Maximum Working Pressure (kPa): 28000
Maximum Working Pressure (psi): 4050
Minimum Fan Width (in): 4
Minimum Fan Width (mm): 102
Orifice Diameter (in): 0.012
Pattern Size (in): 4 to 6
Pattern Size (mm): 101.6 to 152.4

$82.00

RAC X FFLP TIP, SPRAY, (308)

GG FFLP308

RAC X FFLP TIP, SPRAY, (308)

Fine Finish Low Pressure RAC X FF LP SwitchTip, 308 Spray at up to 50% lower pressure with the Reverse-A-Clean (RAC) 308 Fine Finish Low Pressure (FF LP) RAC X SwitchTip. This fine finish tip produces a 6 to 8 inch Fan pattern and has a 0.008 inch orifice, ideal for finishing materials. Reverse the SwitchTip to easily clear clogs. For fine finish applications Less Prep & Cleanup Time

Less mess with less overspray
Put the paint where you want it

Easiest Pattern Overlap

Softer spray fan pattern
Easy to apply any material to any surfance
Consistent blended finish quality

Extended Life

Spraying at half pressure doubles tip life
Reduced sprayer maintenance – up to 2X life

SmartTip Technology

Exclusive internal tip geometry
Reduces energy required to atomize paints, stains, and other materials
Delivers a superior finish with less pressure
Works with SmartControl on select Graco sprayers

Best Tip on the Market

Works with any airless sprayer
Longest lasting Fan pattern
Highest quality finish with a consistent spray pattern

Easy to Identify Tip Size

Large raised tip size numbers are always legible – even when covered with paint

Superior Tip Design

Locking tab ensures tip stays securely in guard
Snaps tip in spray or reverse position
OneSeal tip gasket installs with no tools
Solvent seal available when using extremely hot solvents

$82.00

FITTING, QS, FEP, INIFLEX

GG FXFF01

FITTING, QS, FEP, INIFLEX

IniFlex Fitting, FEP Tube fitting style, quantity 1 Whether you’re setting up a new automated finishing system or upgrading a current installation, IniFlex makes accommodating diverse requirements and budgets more flexible than ever before. IniFlex fits into almost any industrial automation application that requires compact color change valves.

$100.50

FITTING, QS, NPT, INIFLEX

GG FXFP01

FITTING, QS, NPT, INIFLEX

IniFlex Fitting, NPT fitting style, quantity 1 Whether you’re setting up a new automated finishing system or upgrading a current installation, IniFlex makes accommodating diverse requirements and budgets more flexible than ever before. IniFlex fits into almost any industrial automation application that requires compact color change valves.

$50.75

XD SERIES 30 REEL, HOSE, 3/4 X 50, DEF, BLUE

GG HSDD5B

XD SERIES 30 REEL, HOSE, 3/4 X 50, DEF, BLUE

Graco HSDD5B XD30™, DEF, 3/4 in. (19 mm) Inlet, 3/4 in. X 50 ft. (19 mm X 15 m) Hose, NPT, Truck/Bench Mount, Metallic Blue

Graco’s XD30 Series Hose Reels are used in applications requiring longer-range dispense and higher capacity than the standard XD10 and XD20 Series. The Compact pedestal and spool fits into tight spaces and can accommodate 30-75 foot (9.1-22.8 meters) hose capacity for a wide variety of applications. Typical fluids handled include: Petroleum- and synthetic-based oils, diesel fuel, air, water, antifreeze, windshield washer fluid, pressure wash, waste oil and diesel exhaust fluid (DEF).

Application: Ideal for rugged indoor and outdoor use in heavy-duty truck dealerships, fleet maintenance, mining maintenance, public works garages, construction vehicle maintenance, agriculture and service trucks.

Spring Adjustment - Increase or decrease spring tension while reel is pressurized with fluid
Full-Flow Swivel - Maximize material flow with minimal pressure drop for faster fills to get more vehicles through your shop
Optional Adjustable Arm - Easily change the arm position for your application, order with arm (HS models) or without (HN models)
Large Hose Capacity with Small Profile - Compact pedestal and spool fits into tight spaces and can accommodate 30-75 foot (91-228 meters) hose capacity for a wide variety of applications

Model: XD
Series: 30

Application: Diesel Fuel
Color: Metallic Blue
Frame Type: Dual Pedestal
Hose Inside Diameter (in): 3/4
Hose Inside Diameter (mm): 19.05
Hose Length (ft): 50
Hose Length (m): 15
Hose Reel Type: Reel with Hose
Includes Hose: Yes
Inlet Size (in): 3/4
Inlet Size (mm): 19.05
Inlet Thread Type: BSPP
Maximum Working Pressure (psi): 50
Mount Location: Truck Mount, Bench Mount
Outlet Size (in): 3/4
Outlet Size (mm): 19.05
Overall Height (in): 23.10
Overall Height (mm): 588
Overall Length (in): 22.12
Overall Length (mm): 561.73
Overall Width (in): 9.0
Overall Width (mm): 229
Recommended Environment: Indoor, Outdoor
Recommended Fluid Type: DEF

$2,700.00

XD SERIES 30 REEL, 3/4 X 50, A/W, BLUE

GG HSLD5B

XD SERIES 30 REEL, 3/4 X 50, A/W, BLUE

Graco HSLD5B XD30™, Air/Water/Antifreeze/WWS, 3/4 in. (19 mm) Inlet, 3/4 in. X 50 ft. (19 mm X 15 m) Hose, NPT, Truck/Bench Mount, Metallic Blue

Spring Adjustment - Increase or decrease spring tension while reel is pressurized with fluid
Full-Flow Swivel - Maximize material flow with minimal pressure drop for faster fills to get more vehicles through your shop
Optional Adjustable Arm - Easily change the arm position for your application, order with arm (HS models) or without (HN models)
Large Hose Capacity with Small Profile - Compact pedestal and spool fits into tight spaces and can accommodate 30-75 foot (91-228 meters) hose capacity for a wide variety of applications

Model: XD
Series: 30

Application: Air, Water, Antifreeze, WWS
Color: Metallic Blue
Dry Weight (lb): 98
Frame Type: Dual Pedestal
Hose Inside Diameter (in): 3/4
Hose Inside Diameter (mm): 19.05
Hose Length (ft): 50
Hose Length (m): 15
Hose Reel Type: Reel with Hose
Includes Hose: Yes
Inlet Size (in): 3/4
Inlet Size (mm): 19.05
Inlet Thread Type: NPSM
Maximum Working Pressure (psi): 300
Mount Location: Truck Mount, Bench Mount
Outlet Size (in): 3/4
Outlet Size (mm): 19.05
Overall Height (in): 23.10
Overall Height (mm): 588.00
Overall Length (in): 22.12
Overall Length (mm): 561.73
Overall Width (in): 9.0
Overall Width (mm): 229
Recommended Environment: Indoor, Outdoor
Recommended Fluid Type: Air, Water, Antifreeze, WWS

$1,825.00

XD SERIES 30 REEL, 3/4 X 50, OIL, BLUE

GG HSMD5B

XD SERIES 30 REEL, 3/4 X 50, OIL, BLUE

XD30™, Oil, 3/4 in. (19 mm) Inlet, 3/4 in. X 50 ft. (19 mm X 15 m) Hose, NPT, Truck/Bench Mount, Metallic Blue Graco’s XD30 Series Hose Reels are used in applications requiring longer-range dispense and higher capacity than the standard XD10 and XD20 Series. The Compact pedestal and spool fits into tight spaces and can accommodate 30-75 foot (9.1-22.8 meters) hose capacity for a wide variety of applications. Typical fluids handled include: Petroleum- and synthetic-based oils, diesel fuel, air, water, antifreeze, windshield washer fluid, pressure wash, waste oil and diesel exhaust fluid (DEF). Ideal for rugged indoor and outdoor use in heavy-duty truck dealerships, fleet maintenance, mining maintenance, public works garages, construction vehicle maintenance, agriculture and service trucks. Spring Adjustment - Increase or decrease spring tension while reel is pressurized with fluid Full-Flow Swivel - Maximize material flow with minimal pressure drop for faster fills to get more vehicles through your shop Optional Adjustable Arm - Easily change the arm position for your application, order with arm (HS models) or without (HN models) Durable Finish - Baked-on enamel finish protects reel from corrosion Large Hose Capacity with Small Profile - Compact pedestal and spool fits into tight spaces and can accommodate 30-75 foot (91-228 meters) hose capacity for a wide variety of applications

$2,000.00

LOWER, CHEMICAL, 010, SST, UCUP, HW

GG L010S5

LOWER, CHEMICAL, 010, SST, UCUP, HW

Graco L010S5 Z-Pump, 10cc, High Wear, S5

Z-Pumps are positive displacement pump components for use with the Graco and meter, mix, and dispense systems and are ideal for two-component sealant and adhesives requiring precision ratio, flow, and volume controls.

High Wear coatings and 1/2 inch (1.27 cm) checks easily manage material wear from thermal interface material (TIMs), acrylics, or other abrasive material applications.
Precision control eliminates pressure spikes and guarantees on ratio dispense.
Pump seals are the only wear parts, which reduces maintenance downtime and repair costs.

Model: Z-Pump
Series: S5

Ambient/Warm Melt/Hot Melt: Ambient
Application: Industrial
Ball Check Size (in): .5"
Ball Material: Silicon Nitride
Coating Type: High Wear
Feed Type: Pressure Feed
Fluid Inlet Size (cm): 1.905
Fluid Inlet Size (in): 3/4
Fluid Inlet Thread Gender: Female
Fluid Inlet Thread Type: NPT
Fluid Outlet Size (in): 3/4-16
Fluid Outlet Thread Gender: Female
Fluid Outlet Thread Type: SAE
For Use With: EFR, HFR
Maximum Flow Rate (GPM): 0.16
Maximum Operating Temperature (°F): 180
Maximum Output (cm³): 10
Maximum Pump Speed (CPM): 60
Maximum Viscosity (cP): 3000000
Maximum Working Pressure (psi): 3500

$21,390.00

LOWER, CHEMICAL, 20, SST, UCUP

GG L020S1

LOWER, CHEMICAL, 20, SST, UCUP

Z-Pump, 20 cc, Severe Duty, S1 Z-Pumps are positive displacement pump components for use with the Graco meter, mix, and dispense systems and are ideal for two-component sealant and adhesives requiring precision ratio, flow, and volume controls. Severe Duty coatings and 1 inch (2.54 cm) checks easily manage material wear from silicones, sealants, epoxies, foam, and structural adhesives. Precision control eliminates pressure spikes and guarantees on ratio dispense. Pump seals are the only wear parts, which reduces maintenance downtime and repair costs.

$11,600.00

LOWER, CHEMICAL, 80, SST, UCUP

GG L080S1

LOWER, CHEMICAL, 80, SST, UCUP

Z-Pump, 80 cc, Severe Duty, S1 Z-Pumps are positive displacement pump components for use with the Graco meter, mix, and dispense systems and are ideal for two-component sealant and adhesives requiring precision ratio, flow, and volume controls. Severe Duty coatings and 1 inch (2.54 cm) checks easily manage material wear from silicones, sealants, epoxies, foam, and structural adhesives. Precision control eliminates pressure spikes and guarantees on ratio dispense. Pump seals are the only wear parts, which reduces maintenance downtime and repair costs.

$10,980.00

LOWER, CHEMICAL, 100, S8

GG L100S8

LOWER, CHEMICAL, 100, S8

Z-Pump, 100 cc, Elite, S8 Z-Pumps are positive displacement pump components for use with the Graco and meter, mix, and dispense systems and are ideal for two-component sealant and adhesives requiring precision ratio, flow, and volume controls. Elite coatings and 7/8 inch (2.22 cm) checks easily manage material wear from thermal interface material (TIMs) or other abrasive applications. Precision control eliminates pressure spikes and guarantees on ratio dispense. Elite high-wear pump seals reduce maintenance downtime and repair costs.

$20,290.00

DURA-FLO 430 PUMP, RECIP, DISPL

GG L430SM

DURA-FLO 430 PUMP, RECIP, DISPL

Graco L430SM Dura-Flo 1800 (430 cc) Lower, Stainless Steel, 4 Leather, 3 UHMWPE Throat/3 UHMWPE, 2 Leather Piston Packings

Application: With priming piston, rod and cylinder.

Model: Dura-Flo

Application: Bonding, Sealing, Gasketing, Potting, Encapsulation, Molding, Spray, Fluid Transfer, Unloading, Underfill
Compatible Material: Motor Oil, Gear Oil, Automatic Transmission Fluid, Oil
Fluid Inlet Size (cm): 5.08
Fluid Inlet Size (in): 2
Fluid Inlet Thread Gender: Female
Fluid Inlet Thread Type: NPT
Fluid Outlet Size (in): 1-1/2
Fluid Outlet Thread Gender: Male
Fluid Outlet Thread Type: NPT
For Use With: Dura-Flo Oil Pumps
Maximum Flow Rate (GPM): 6.9
Maximum Operating Temperature (°F): 150
Maximum Output (cm³): 430
Maximum Pump Speed (CPM): 60
Maximum Working Pressure (psi): 4700

$16,670.00

RAC 5 LINELAZER TIP, SPRAY, STRIPING

GG LL5315

RAC 5 LINELAZER TIP, SPRAY, STRIPING

LineLazer RAC 5 SwitchTip, 315 The Reverse-A-Clean (RAC) 315 LineLazer RAC 5 SwitchTip has a 0.015 inch orifice and produces a 4 to 6 inch line. Used for parking lots, roads, warehouse floors, crosswalks and athletic fields. Best used with materials ranging from heavy waterbase to thin alkyd traffic paints. LineLazer RAC 5 SwitchTip (Yellow Handle)

Creates clean, laser-sharp lines with no fuzzy edges or thin spots
Designed specifically for parking lots, roads, warehouse floors, crosswalks and athletic fields
Sprays heavy water-base to thin alkyd traffic paints
Ensures consistent paint thickness, from edge to edge, less overspray and long-lasting lines

$71.00

RAC 5 LINELAZER TIP, SPRAY, STRIPING

GG LL5317

RAC 5 LINELAZER TIP, SPRAY, STRIPING

Graco LL5317 LineLazer RAC 5 SwitchTip, 317

The Reverse-A-Clean (RAC) 317 LineLazer RAC 5 SwitchTip has a 0.017 inch orifice and produces a 4 to 6 inch line.

Application: Used for parking lots, roads, warehouse floors, crosswalks and athletic fields. Best used with materials ranging from heavy waterbase to thin alkyd traffic paints.

LineLazer RAC 5 SwitchTip (Yellow Handle)
Creates clean, laser-sharp lines with no fuzzy edges or thin spots
Designed specifically for parking lots, roads, warehouse floors, crosswalks and athletic fields
Sprays heavy water-base to thin alkyd traffic paints
Ensures consistent paint thickness, from edge to edge, less overspray and long-lasting lines

Model: LineLazer RAC 5
Series: SwitchTip

Application: Parking Lots, Roads, Warehouse Floors, Crosswalks, Athletic Fields Line Striping
Color: Yellow
Fan Angle (°): 30
For Use With: LineLazer V 3900 Airless Line Striper, LineLazer V 5900 Airless Line Striper
Maximum Fan Width (in): 6
Maximum Fan Width (mm): 152
Maximum Flow Rate (L/min): 1.17
Maximum Line Width (cm): 15
Maximum Line Width (in): 6
Maximum Line Width (mm): 152
Orifice Diameter (in): 0.017

$71.00

RAC 5 LINELAZER TIP, SPRAY, STRIPING

GG LL5321

RAC 5 LINELAZER TIP, SPRAY, STRIPING

LineLazer RAC 5 SwitchTip, 321 The Reverse-A-Clean (RAC) 321 LineLazer RAC 5 SwitchTip has a 0.021 inch orifice and produces a 4 to 6 inch line. Used for parking lots, roads, warehouse floors, crosswalks and athletic fields. Best used with materials ranging from heavy waterbase to thin alkyd traffic paints. LineLazer RAC 5 SwitchTip (Yellow Handle)

Creates clean, laser-sharp lines with no fuzzy edges or thin spots
Designed specifically for parking lots, roads, warehouse floors, crosswalks and athletic fields
Sprays heavy water-base to thin alkyd traffic paints
Ensures consistent paint thickness, from edge to edge, less overspray and long-lasting lines

$71.00

RAC 5 LINELAZER TIP, SPRAY, STRIPING

GG LL5323

RAC 5 LINELAZER TIP, SPRAY, STRIPING

LineLazer RAC 5 SwitchTip, 323 The Reverse-A-Clean (RAC) 323 LineLazer RAC 5 SwitchTip has a 0.023 inch orifice and produces a 4 to 6 inch line. Used for parking lots, roads, warehouse floors, crosswalks and athletic fields. Best used with materials ranging from heavy waterbase to thin alkyd traffic paints. Creates clean, laser-sharp lines with no fuzzy edges or thin spots Designed specifically for parking lots, roads, warehouse floors, crosswalks and athletic fields Sprays heavy water-base to thin alkyd traffic paints Ensures consistent paint thickness, from edge to edge, less overspray and long-lasting lines

$71.00

RAC 5 LINELAZER TIP, SPRAY, STRIPING

GG LL5621

RAC 5 LINELAZER TIP, SPRAY, STRIPING

LineLazer RAC 5 SwitchTip, 621 The Reverse-A-Clean (RAC) 621 LineLazer RAC 5 SwitchTip has a 0.021 inch orifice and produces an 8 to 12 inch line. Used for parking lots, roads, warehouse floors, crosswalks and athletic fields. Best used with materials ranging from heavy waterbase to thin alkyd traffic paints. Creates clean, laser-sharp lines with no fuzzy edges or thin spots Designed specifically for parking lots, roads, warehouse floors, crosswalks and athletic fields Sprays heavy water-base to thin alkyd traffic paints Ensures consistent paint thickness, from edge to edge, less overspray and long-lasting lines

$71.00

RAC 5 LINELAZER TIP, SPRAY, STRIPING

GG LL5623

RAC 5 LINELAZER TIP, SPRAY, STRIPING

LineLazer RAC 5 SwitchTip, 623 The Reverse-A-Clean (RAC) 623 LineLazer RAC 5 SwitchTip has a 0.023 inch orifice and produces an 8 to 12 inch line. Creates clean, laser-sharp lines with no fuzzy edges or thin spots Designed specifically for parking lots, roads, warehouse floors, crosswalks and athletic fields Sprays heavy water-base to thin alkyd traffic paints Ensures consistent paint thickness, from edge to edge, less overspray and long-lasting lines

$71.00

RAC 5 LINELAZER TIP, SPRAY, STRIPING

GG LL5625

RAC 5 LINELAZER TIP, SPRAY, STRIPING

LineLazer RAC 5 SwitchTip, 625 The Reverse-A-Clean (RAC) 625 LineLazer RAC 5 SwitchTip has a 0.025 inch orifice and produces an 8 to 12 inch line. Creates clean, laser-sharp lines with no fuzzy edges or thin spots Designed specifically for parking lots, roads, warehouse floors, crosswalks and athletic fields Sprays heavy water-base to thin alkyd traffic paints Ensures consistent paint thickness, from edge to edge, less overspray and long-lasting lines

$71.00

RAC X LP TIP, SPRAY, (517)

GG LP517

RAC X LP TIP, SPRAY, (517)

Low Pressure RAC X LP SwitchTip, 517 Spray at up to 50% lower pressure with the Reverse-A-Clean (RAC) 517 Low Pressure (LP) RAC X SwitchTip. This low pressure tip produces a 10 to 12 inch fan pattern and has a 0.017 inch orifice. Reverse the SwitchTip to easily clear clogs. For large surfance areas such as walls and ceilings Less Prep & Cleanup Time

Less mess with less overspray
Put the paint where you want it

Easiest Pattern Overlap

Softer spray fan pattern
Easy to apply any material to any surfance
Consistent blended finish quality

Extended Life

Spraying at half pressure doubles tip life
Reduced sprayer maintenance – up to 2X life

SmartTip Technology

Exclusive internal tip geometry
Reduces energy required to atomize paints, stains, and other materials
Delivers a superior finish with less pressure
Works with SmartControl on select Graco sprayers

Best Tip on the Market

Works with any airless sprayer
Longest lasting fan pattern
Highest quality finish with a consistent spray pattern

Easy to Identify Tip Size

Large raised tip size numbers are always legible – even when covered with paint

Superior Tip Design

Locking tab ensures tip stays securely in guard
Snaps tip in spray or reverse position
OneSeal tip gasket installs with no tools
Solvent seal available when using extremely hot solvents

$82.00

RAC X LP TIP, SPRAY, (631)

GG LP631

RAC X LP TIP, SPRAY, (631)

Low Pressure RAC X LP SwitchTip, 631 Spray at up to 50% lower pressure with the Reverse-A-Clean (RAC) 631 Low Pressure (LP) RAC X SwitchTip. This low pressure tip produces a 12 to 14 inch fan pattern and has a 0.031 inch orifice. Reverse the SwitchTip to easily clear clogs. For large surfance areas such as walls and ceilings Less Prep & Cleanup Time

Less mess with less overspray
Put the paint where you want it

Easiest Pattern Overlap

Softer spray fan pattern
Easy to apply any material to any surfance
Consistent blended finish quality

Extended Life

Spraying at half pressure doubles tip life
Reduced sprayer maintenance – up to 2X life

SmartTip Technology

Exclusive internal tip geometry
Reduces energy required to atomize paints, stains, and other materials
Delivers a superior finish with less pressure
Works with SmartControl on select Graco sprayers

Best Tip on the Market

Works with any airless sprayer
Longest lasting fan pattern
Highest quality finish with a consistent spray pattern

Easy to Identify Tip Size

Large raised tip size numbers are always legible – even when covered with paint

Superior Tip Design

Locking tab ensures tip stays securely in guard
Snaps tip in spray or reverse position
OneSeal tip gasket installs with no tools
Solvent seal available when using extremely hot solvents

$82.00

RAC X LTX TIP, SPRAY, (221)

GG LTX221

RAC X LTX TIP, SPRAY, (221)

Graco LTX221 RAC X SwitchTip, 221

The Reverse-A-Clean (RAC) 221 RAC X SwitchTip is designed for narrower surfaces and thick materials. The 221 SwitchTip has a 0.021 inch orifice and produces a 4 to 6 inch fan. Reverse the SwitchTip to easily clear clogs.

Application: Used for residential, commercial or industrial applications.

Best Tip on the Market
Longest lasting fan pattern
Highest quality finish with a consistent spray pattern
Easy to Identify Tip Size
Large raised tip size numbers are always legible – even when covered with paint
Superior Tip Design
Locking tab ensures tip stays securely in guard
Snaps tip in spray or reverse position
OneSeal tip gasket installs with no tools
Solvent seal available when using extremely hot solvents

Model: RAC X
Series: LTX SwitchTip

Compatible Material: Lacquer to Mastic, Latex Paint
For Use With: RAC X HandTite Tip Guard
Maximum Fan Width (cm): 10
Maximum Fan Width (in): 4
Maximum Fan Width (mm): 152
Maximum Flow Rate (GPM): 0.47
Maximum Flow Rate (L/min): 1.78
Maximum Working Pressure (bar): 280
Maximum Working Pressure (kPa): 28000
Maximum Working Pressure (psi): 4050
Minimum Fan Width (in): 4
Minimum Fan Width (mm): 102
Orifice Diameter (in): 0.021
Pattern Size (in): 4 to 6
Pattern Size (mm): 101.6 to 152.4

$65.25

RAC X LTX TIP, SPRAY, (225)

GG LTX225

RAC X LTX TIP, SPRAY, (225)

RAC X SwitchTip, 225 The Reverse-A-Clean (RAC) 225 RAC X SwitchTip is designed for narrower surfaces and thicker materials. The 225 SwitchTip has a 0.025 inch orifice and produces a 4 to 6 inch fan. Reverse the SwitchTip to easily clear clogs. Used for residential, commercial or industrial applications. Best Tip on the Market

Longest lasting fan pattern
Highest quality finish with a consistent spray pattern

Easy to Identify Tip Size

Large raised tip size numbers are always legible – even when covered with paint

Superior Tip Design

Locking tab ensures tip stays securely in guard
Snaps tip in spray or reverse position
OneSeal tip gasket installs with no tools
Solvent seal available when using extremely hot solvents

$65.25

RAC X LTX TIP, SPRAY, (323)

GG LTX323

RAC X LTX TIP, SPRAY, (323)

RAC X SwitchTip, 323 The Reverse-A-Clean (RAC) 323 RAC X SwitchTip is designed for narrow surfaces and thick materials. The 323 SwitchTip has a 0.023 inch orifice and produces a 6 to 8 inch fan. Reverse the SwitchTip to easily clear clogs. Used for residential, commercial or industrial applications. Best Tip on the Market

Longest lasting fan pattern
Highest quality finish with a consistent spray pattern

Easy to Identify Tip Size

Large raised tip size numbers are always legible – even when covered with paint

Superior Tip Design

Locking tab ensures tip stays securely in guard
Snaps tip in spray or reverse position
OneSeal tip gasket installs with no tools
Solvent seal available when using extremely hot solvents

$65.25
