INGERSOLL-RAND IR TOOL S12880

IR 71048284

Fitting

IR 7105JS2F08144

JIB, ZRS2 COLUMN MOUNTED

IR 7105JA2F08120

700J SERIES JIB 8FT BOOM 10FT U/C 1050LB CAPACIT

IR 71062723

ASSY, TOP HOOK, L5H200

IR 71064794

LABEL, P-SERIES, WARNINGNON-RETURNABLE PART

IR 71079602

BRAKE SET, L5H600/1200

IR 7121

HEX TO SQUARE ADAPTER

IR 71272454

LABEL, CAP, PT005NON-RETURNABLE PART

IR 71272991

PEND ASSEMBLY 21 FT

IR 71273528

TRANSFORMER (71275440)

IR 71273023

PEND ASSEMBLY 11 FT

IR 71275077

KIT, QCH50 BRAKE DISC SET

IR 71275127

GUIDE

IR 71275259

FUSE NON-RETURNABLE PART

IR 71276281

LOAD-WHEEL

IR 71275655

LATCH KIT

IR 71276323

LOAD-WHEEL

IR 71276299

WHEEL ASSEMBLY

IR 71276331

WHEEL ASSEMBLY

IR 71277735

LIMIT SWITCH

IR 71278048

BEARINGNON-RETURNABLE PART

IR 71278451

9210.3065.4 : SPRING, PRESSURE BRAKE

IR 71278444

SHEAVE, IDLER

IR 71284566

PINION

IR 71289326

LABEL, WARNING NON-RETURNABLE PART 71289326

IR 71291686

CHAIN STOPPER

IR 71307227

NUT

IR 71307276

Ring (BU7A-118)

IR 71315SAA2LZQ080

700 SERIES ARM

IR 71315SABB0ZP070

ARM 713 7FT REACH ASSEMBLY 150LB ZA PENDANT

IR 71315SABB0ZP08D

713 ARM 8 FT. LG. 150 LB. 9 FT. COLUMN HEIGHT

IR 71315SABB0ZT08C

713 ARM 8FT REACH 150LB CAP 8FT 6IN COL TRI-COIL

IR 71315SABB0ZT10E

ARM 713 150LB TRI COIL 10FT REACH 10FT COLUMN

IR 71316491

Screw, Hex Head, SC1.G5, 5/8NC x 1.75 In

IR 71315SATT0ZP100

ARM 713 150LB T MNT ZA CNTRL 10FT

IR 71320964

Washer

IR 71320SAA2HZP100

713 ARM A2 CARRAIGE 10' REACH 200 LB BALANCER

IR 71320SAA2LZT080

713 ARM LOW PROFILE CARRIAGE TRI COIL 8FT REACH

IR 71320SABB0BZ06E

713 SERIES ARM 6FT REACH 10FT COLUMN 200LB CAPAC

IR 71320SABB0EP100

713 ARM

IR 71320SABB0ZT10B

ARM 713 BOTTOM MOUNT 10FT REACH 8FT COLUMN 200LB

IR 71320SABB0ZQ08B

713 ARM 8FT REACH 8FT COL QUAD COIL 200LB CAP

IR 8230-6A

Inline Multi-Vane Air Motor, 3/8" Keyed Shaft, 1000 RPM, 0.6 HP, 16.3 NM, Non-reversible

Air Consumption at Max HP (scfm): 41
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 3/8
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 18.9:1
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 1000
Max Pressure (bar): 6.2
Max Torque (ft-lb): 12
Max Torque (in-lb): 144
Max Torque (nm): 16.3
Motor: Rotary Vane
Motor: In line
Mounting Type: Foot Mount Optional
Power Source: Air Powered
Product Weight (lb): 2.98
Rated Power (hp): 0.6
Rated Power (kW): 0.45
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 500
Torque Output @ Max HP (ft-lb): 6.2
Torque Output @ Max HP (nm): 8.4
Warranty: 1-year

IR 8230-9A

Inline Multi-Vane Air Motor, 3/8" Keyed Shaft, 500 RPM, 0.6 HP, 32.5 NM, Non-reversible

Air Consumption at Max HP (scfm): 41
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 3/8
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 38.1:1
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 500
Max Pressure (bar): 6.2
Max Torque (ft-lb): 24
Max Torque (in-lb): 288
Max Torque (nm): 32.5
Motor: Rotary Vane
Motor: In line
Mounting Type: Foot Mount Optional
Power Source: Air Powered
Product Weight (lb): 2.98
Rated Power (hp): 0.6
Rated Power (kW): 0.45
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 250
Torque Output @ Max HP (ft-lb): 12
Torque Output @ Max HP (nm): 16.9
Warranty: 1-year

IR 8230-8A

Inline Multi-Vane Air Motor, 3/8" Keyed Shaft, 600 RPM, 0.6 HP, 26.5 NM, Non-reversible

Air Consumption at Max HP (scfm): 41
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 3/8
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 30.9:1
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 600
Max Pressure (bar): 6.2
Max Torque (ft-lb): 20
Max Torque (in-lb): 235
Max Torque (nm): 26.5
Motor: Rotary Vane
Motor: In line
Mounting Type: Foot Mount Optional
Power Source: Air Powered
Product Weight (lb): 2.98
Rated Power (hp): 0.6
Rated Power (kW): 0.45
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 315
Torque Output @ Max HP (ft-lb): 10.0
Torque Output @ Max HP (nm): 13.5
Warranty: 1-year

IR 8231-2B

Inline Multi-Vane Air Motor, 3/8" Keyed Shaft, 5300 RPM, 0.5 HP, 2.3 NM, Reversible

Air Consumption at Max HP (scfm): 41
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 3/8
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 3.4:1
Gear Reduction: Single
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 5300
Max Pressure (bar): 6.2
Max Torque (ft-lb): 1.7
Max Torque (in-lb): 20
Max Torque (nm): 2.3
Motor: Rotary Vane
Motor: In line
Mounting Type: Foot Mount Optional
Power Source: Air Powered
Product Weight (lb): 2.45
Rated Power (hp): 0.5
Rated Power (kW): 0.37
Reversible: Reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 2600
Torque Output @ Max HP (ft-lb): 1.0
Torque Output @ Max HP (nm): 1.3
Warranty: 1-year

IR 8231-5B

Inline Multi-Vane Air Motor, 3/8" Keyed Shaft, 1500 RPM, 0.5 HP, 8 NM, Reversible

Air Consumption at Max HP (scfm): 41
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 3/8
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 11.6:1
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 1500
Max Pressure (bar): 6.2
Max Torque (ft-lb): 5.9
Max Torque (in-lb): 71
Max Torque (nm): 8
Motor: Rotary Vane
Motor: In line
Mounting Type: Foot Mount Optional
Power Source: Air Powered
Product Weight (lb): 2.98
Rated Power (hp): 0.5
Rated Power (kW): 0.37
Reversible: Reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 780
Torque Output @ Max HP (ft-lb): 3.5
Torque Output @ Max HP (nm): 4.7
Warranty: 1-year

IR 8231-3B

Inline Multi-Vane Air Motor, 3/8" Keyed Shaft, 3200 RPM, 0.5 HP, 3.9 NM, Reversible

Air Consumption at Max HP (scfm): 41
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 3/8
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 5.56:1
Gear Reduction: Single
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 3200
Max Pressure (bar): 6.2
Max Torque (ft-lb): 2.9
Max Torque (in-lb): 35
Max Torque (nm): 3.9
Motor: Rotary Vane
Motor: In line
Mounting Type: Foot Mount Optional
Power Source: Air Powered
Product Weight (lb): 2.45
Rated Power (hp): 0.5
Rated Power (kW): 0.37
Reversible: Reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 1550
Torque Output @ Max HP (ft-lb): 1.7
Torque Output @ Max HP (nm): 2.3
Warranty: 1-year

IR 8231-6B

Inline Multi-Vane Air Motor, 3/8" Keyed Shaft, 950 RPM, 0.5 HP, 12.9 NM, Reversible

Air Consumption at Max HP (scfm): 41
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 3/8
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 18.9:1
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 950
Max Pressure (bar): 6.2
Max Torque (ft-lb): 9.5
Max Torque (in-lb): 114
Max Torque (nm): 12.9
Motor: Rotary Vane
Motor: In line
Mounting Type: Foot Mount Optional
Power Source: Air Powered
Product Weight (lb): 2.98
Rated Power (hp): 0.5
Rated Power (kW): 0.37
Reversible: Reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 480
Torque Output @ Max HP (ft-lb): 5.5
Torque Output @ Max HP (nm): 7.4
Warranty: 1-year

IR 8231-7B

Inline Multi-Vane Air Motor, 3/8" Keyed Shaft, 750 RPM, 0.5 HP, 16 NM, Reversible

Air Consumption at Max HP (scfm): 41
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 3/8
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 23.4:1
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 750
Max Pressure (bar): 6.2
Max Torque (ft-lb): 12
Max Torque (in-lb): 142
Max Torque (nm): 16
Motor: Rotary Vane
Motor: In line
Mounting Type: Foot Mount Optional
Power Source: Air Powered
Product Weight (lb): 2.98
Rated Power (hp): 0.5
Rated Power (kW): 0.37
Reversible: Reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 380
Torque Output @ Max HP (ft-lb): 7.0
Torque Output @ Max HP (nm): 9.5
Warranty: 1-year

IR 8231-8B

Inline Multi-Vane Air Motor, 3/8" Keyed Shaft, 575 RPM, 0.5 HP, 21 NM, Reversible

Air Consumption at Max HP (scfm): 41
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 3/8
Drive Type: Round Keyed
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 30.9:1
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 575
Max Pressure (bar): 6.2
Max Torque (ft-lb): 15
Max Torque (in-lb): 186
Max Torque (nm): 21
Motor: Rotary Vane
Motor: In line
Mounting Type: Foot Mount Optional
Power Source: Air Powered
Product Weight (lb): 2.98
Rated Power (hp): 0.5
Rated Power (kW): 0.37
Reversible: Reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 290
Torque Output @ Max HP (ft-lb): 9.0
Torque Output @ Max HP (nm): 12.2
Warranty: 1-year

IR 8232-3

Milling Air Motor, 1/4" Collet, 3500 RPM, 0.6 HP, 4.7 NM, Non-reversible

Air Consumption at Max HP (scfm): 41
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 1/4
Drive Type: Collet
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 5.56:1
Gear Reduction: Single
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 3500
Max Pressure (bar): 6.2
Max Torque (ft-lb): 3.5
Max Torque (in-lb): 42
Max Torque (nm): 4.7
Motor: Rotary Vane
Motor: Milling
Mounting Type: Foot Mount Optional
Power Source: Air Powered
Product Weight (lb): 2.87
Rated Power (hp): 0.6
Rated Power (kW): 0.45
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 1750
Torque Output @ Max HP (ft-lb): 1.8
Torque Output @ Max HP (nm): 2.4
Warranty: 1-year

IR 8232-4

Milling Air Motor, 1/4" Collet, 2800 RPM, 0.6 HP, 6.1 NM, Non-reversible

Air Consumption at Max HP (scfm): 41
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 1/4
Drive Type: Collet
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 6.86:1
Gear Reduction: Single
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 2800
Max Pressure (bar): 6.2
Max Torque (ft-lb): 4.5
Max Torque (in-lb): 54
Max Torque (nm): 6.1
Motor: Rotary Vane
Motor: Milling
Mounting Type: Foot Mount Optional
Power Source: Air Powered
Product Weight (lb): 2.87
Rated Power (hp): 0.6
Rated Power (kW): 0.45
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 1400
Torque Output @ Max HP (ft-lb): 2.2
Torque Output @ Max HP (nm): 3
Warranty: 1-year

IR 8232-5

Milling Air Motor, 1/4" Collet, 1650 RPM, 0.6 HP, 10.2 NM, Non-reversible

Air Consumption at Max HP (scfm): 41
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 1/4
Drive Type: Collet
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 11.6:1
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 1650
Max Pressure (bar): 6.2
Max Torque (ft-lb): 7.5
Max Torque (in-lb): 90
Max Torque (nm): 10.2
Motor: Rotary Vane
Motor: Milling
Mounting Type: Foot Mount Optional
Power Source: Air Powered
Product Weight (lb): 3.62
Rated Power (hp): 0.6
Rated Power (kW): 0.45
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 840
Torque Output @ Max HP (ft-lb): 3.8
Torque Output @ Max HP (nm): 5.1
Warranty: 1-year

IR 8232-6

Milling Air Motor, 1/4" Collet, 1000 RPM, 0.6 HP, 16.3 NM, Non-reversible

Air Consumption at Max HP (scfm): 41
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 1/4
Drive Type: Collet
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 18.9:1
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 1000
Max Pressure (bar): 6.2
Max Torque (ft-lb): 12
Max Torque (in-lb): 144
Max Torque (nm): 16.3
Motor: Rotary Vane
Motor: Milling
Mounting Type: Foot Mount Optional
Power Source: Air Powered
Product Weight (lb): 3.62
Rated Power (hp): 0.6
Rated Power (kW): 0.45
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 500
Torque Output @ Max HP (ft-lb): 6.2
Torque Output @ Max HP (nm): 8.4
Warranty: 1-year

IR 8245-101-3

DRILL

IR 8232-7

Milling Air Motor, 1/4" Collet, 800 RPM, 0.6 HP, 20 NM, Non-reversible

Air Consumption at Max HP (scfm): 41
Air Inlet: 1/4" NPT
Air Pressure (psi): 90
Drive Size (in): 1/4
Drive Type: Collet
Exhaust Location: Exterior Muffler
Finish: Black Oxide
Gear Ratio: 23.4:1
Gear Reduction: Double
Gear Train: Planetary
Housing Material: Steel
Max Free Speed (rpm): 800
Max Pressure (bar): 6.2
Max Torque (ft-lb): 15
Max Torque (in-lb): 177
Max Torque (nm): 20
Motor: Rotary Vane
Motor: Milling
Mounting Type: Foot Mount Optional
Power Source: Air Powered
Product Weight (lb): 3.62
Rated Power (hp): 0.6
Rated Power (kW): 0.45
Reversible: Non-reversible
Sound Level dB(A): 80
Speed at Max Power (rpm): 390
Torque Output @ Max HP (ft-lb): 8.0
Torque Output @ Max HP (nm): 10.8
Warranty: 1-year

IR 8245-203-2

DRILL

IR 8245-203-2-CN4

SELF-FEED DRILL - " 000" SERIES

IR 8245-203-2EU

DRILL

IR 8245-203-3EU

DRILL

IR 8245-B30-3EU

DRILL

IR 8245-B45-1EU

DRILL

IR 8245-B45-3EU

DRILL

IR 8245-B8-3

DRILL

IR 8248-B45-1

DRILL

IR 8248-B30-1

DRILL

IR 8255-101-1

DRILL

IR 8255-101-3EU

DRILL

IR 8255-172-1

DRILL

IR 8255-172-2

DRILL

IR 8255-172-3

DRILL

IR 8245-B30-2EU

DRILL

IR 8255-172-3EU

DRILL ASSEMBLY

IR 8245-B30-1EU

DRILL

IR 8255-A14-2EU

DRILL

IR 8255-A14-3EU

DRILL

IR 8245-B45-2EU

DRILL

IR 8245-B8-3EU

DRILL

IR 8255-A21-2EU

DRILL

IR 8255-101-3

DRILL

IR 8255-A21-3EU

DRILL

IR 8255-A28-2EU

DRILL

IR 8255-A28-3EU

DRILL

IR 8255-A50-3EU

DRILL

IR 8255-A50-2EU

DRILL

IR 8255-A5-2EU

DRILL

IR 8255-A5-3EU

DRILL

IR 8255-A8-1

DRILL

IR 8255-A8-2EU

DRILL

IR 8255-A8-3EU

DRILL

IR 8257-A8-AEU

TAPPER

IR 8258-C14-3

DRILL

IR 8258-C21-1

DRILL

IR 8258-C50-1

DRILL

IR 8258-C50-2

DRILL

IR 8265-101-1

DRILL

IR 8265-12-3EU

DRILL

IR 8265-171-1

DRILL

IR 8265-171-3EU

FEED DRILL
