INGERSOLL-RAND IR TOOL S12880

IR TRP-123

IR TRP-158

IR TRP-A365

IR UM-37-M

IR UW50A30-58

IR UWD-161

IR GEA2-29

IR VP1-BOOT-NP

AA 34022

AA Y325-222

IR VSM-6181

IR VSM-6410

IR QXFN2PT024ES06

3/8in 20V Cordless QX Precision Fastening ETS Screwdriver, 212 in-lb Torque, 500 RPM, Pistol

Description: Designed to replace traditional clutch tools, the 20V pistol grip QXFN Precision Screwdriver offers the precision and quality of the QX Connect Series in an affordable, simple to set up tool. Add mobility and enhance the simplicity and flexibility of Ingersoll Rand QX Connect Series cordless assembly tools with the INSIGHT Connect app. Reducing torque reaction doesn't have to be complicated with the QX Connect Series Ergonomic Tightening System. Control and ergonomics, not compromise - that is what the QX ETS is all about. The QX ETS offers all the capabilities found in the QX Series platform, without the torque reaction.

Features And Benefits:

• Comes with 32 programmable tightening configuration.
• 1,200 cycles of onboard tightening data storage
• Configurable preventative maintenance alarms.
• Intuitive qualitative feedback using Green, Red, and Yellow indicators.
• All QX Series IQV 20 tools are compatible with both the BL2022 and BL2012 batteries. The BL2022 is optimum for longer use applications while the BL2012 is ideal for tighter spaces and reduced weight. The 20 volt batteries utilize our 20V battery charger.
• Ergonomic tightening system to reduce torque reaction experienced by operator.
• Insight Connect Android APP Link.
• Programming Methods: Through USB with Insight Connect App available on Android, Through ICS Software, Through INISGHTqcx Controllers.

• Includes: Bare tool only, batteries and charger sold separately.
• Actuation/Throttle Type/Switch Type: Trigger
• Anvil Length: Standard

• Built-in Light: Yes

• Color: Grey
• Configuration/Handle Type: Pistol - ETS (ergonomic tightening system)
• Data Storage Capacity: 1200 cycles
• Drive Size (in): 3/8
• Drive Type: Square

• Max Free Speed (rpm): 500
• Max Torque (ft-lb): 18
• Max Torque (in-lb): 212
• Max Torque (nm): 24
• Motor: Brushless Motor

• Power Source: Battery Powered
• Product Length (in): 8.35

• Product Height (in) (with Battery): 10.07
• Product Weight (lb): 2
• Recommended Forward Torque Range (ft-lb): -
• Recommended Forward Torque Range (in-lb): -
• Recommended Forward Torque Range (nm): 4.8 - 24
• Retainer Type: Pin Detent
• Reversible: Reversible

• Side to Center Distance (in): 1
• Side to Center Distance (mm): 25

• User Interface: No Display
• Voltage DC: 20
• Warranty: 1-year Tool, 2-year Battery, 3-year Charger
• Wireless Tool Tracking: No Wireless Functionality
• Wireless Tool Tracking: Mini USB

IR QXFN5AT000E000

IR QXFN5AT020PS06

3/8" 40V Cordless QX Precision Fastening Angle Screwdriver, 177 in-lb Torque, 1045 RPM

Description: Designed to replace traditional clutch tools, the 40V high-torque angle QXFN Precision Screwdriver offers the precision and quality of the QX Connect Series in an affordable, simple to set up tool. Add mobility and enhance the simplicity and flexibility of Ingersoll Rand QX Connect Series cordless assembly tools with the INSIGHT Connect app.

Features And Benefits:

• Comes with 32 programmable tightening configuration.
• 1,200 cycles of onboard tightening data storage.
• Configurable preventative maintenance alarms.
• Intuitive qualitative feedback using Green, Red, and Yellow indicators.
• The QX Series IQV 40 high torque tools utilize the BL4011 40V 2.5Ah battery for increased torque and runtime. The BL4011 is optimum for longer use applications. The 40 volt batteries utilize our IQV Series 40V, 2.5Ah charger BC1161.
• Insight Connect Android APP Link.
• Programming Methods: Through USB with Insight Connect App available on Android, ICS Software, INISGHTqcx Controllers.

• Includes: Bare tool only, batteries and charger sold separately.
• Actuation/Throttle Type/Switch Type: Trigger
• Anvil Length: Standard

• Built-in Light: No

• Color: Grey
• Configuration/Handle Type: Right Angle
• Data Storage Capacity: 1200 cycles
• Drive Size (in): 3/8
• Drive Type: Square

• Max Free Speed (rpm): 1045
• Max Torque (ft-lb): 15
• Max Torque (in-lb): 177
• Max Torque (nm): 20
• Motor: Brushless Motor

• Power Source: Battery Powered
• Product Length (in): 22.74

• Product Height (in): 3.94
• Product Weight (lb): 4.5
• Recommended Forward Torque Range (ft-lb): 3.0-15
• Recommended Forward Torque Range (in-lb): 35-177
• Recommended Forward Torque Range (nm): 4.0-20
• Retainer Type: Pin Detent
• Reversible: Reversible

• Side to Center Distance (in): 0.52
• Side to Center Distance (mm): 13

• User Interface: No Display
• Voltage DC: 40
• Warranty: 1-year Tool, 2-year Battery, 3-year Charger
• Wireless Tool Tracking: No Wireless Functionality
• Wireless Tool Tracking: Mini USB

IR QXFN5AT035PS06

3/8" 40V Cordless QX Precision Fastening Angle Screwdriver, 310 in-lb Torque, 640 RPM

Description: Designed to replace traditional clutch tools, the 40V high-torque angle QXFN Precision Screwdriver offers the precision and quality of the QX Connect Series in an affordable, simple to set up tool. Add mobility and enhance the simplicity and flexibility of Ingersoll Rand QX Connect Series cordless assembly tools with the INSIGHT Connect app.

Features And Benefits:

• Comes with 32 programmable tightening configuration.
• 1,200 cycles of onboard tightening data storage.
• Configurable preventative maintenance alarms.
• Intuitive qualitative feedback using Green, Red, and Yellow indicators.
• The QX Series IQV 40 high torque tools utilize the BL4011 40V 2.5Ah battery for increased torque and runtime. The BL4011 is optimum for longer use applications. The 40 volt batteries utilize our IQV Series 40V, 2.5Ah charger BC1161.
• Insight Connect Android APP Link.
• Programming Methods: Through USB with Insight Connect App available on Android, ICS Software, INISGHTqcx Controllers.

• Includes: Bare tool only, batteries and charger sold separately.
• Actuation/Throttle Type/Switch Type: Trigger
• Anvil Length: Standard

• Built-in Light: No

• Color: Grey
• Configuration/Handle Type: Right Angle
• Data Storage Capacity: 1200 cycles
• Drive Size (in): 3/8
• Drive Type: Square

• Max Free Speed (rpm): 640
• Max Torque (ft-lb): 26
• Max Torque (in-lb): 310
• Max Torque (nm): 35
• Motor: Brushless Motor

• Power Source: Battery Powered
• Product Length (in): 22.91

• Product Height (in): 3.94
• Product Weight (lb): 4.8
• Recommended Forward Torque Range (ft-lb): 5.2-26
• Recommended Forward Torque Range (in-lb): 62-310
• Recommended Forward Torque Range (nm): 7.0-35
• Retainer Type: Pin Detent
• Reversible: Reversible

• Side to Center Distance (in): 0.68
• Side to Center Distance (mm): 17

• User Interface: No Display
• Voltage DC: 40
• Warranty: 1-year Tool, 2-year Battery, 3-year Charger
• Wireless Tool Tracking: No Wireless Functionality
• Wireless Tool Tracking: Mini USB

IR QXFN5AT040ES08

1/2" 40V Cordless QX Precision Fastening ETS Angle Screwdriver, 354 in-lb Torque, 545 RPM

Description: Designed to replace traditional clutch tools, the 40V high-torque angle QXFN Precision Screwdriver offers the precision and quality of the QX Connect Series in an affordable, simple to set up tool. Reducing torque reaction doesn't have to be complicated with the QX Connect Series Ergonomic Tightening System. Add mobility and enhance the simplicity and flexibility of Ingersoll Rand QX Connect Series cordless assembly tools with the INSIGHT Connect app.

Features And Benefits:

• Comes with 32 programmable tightening configuration.
• 1,200 cycles of onboard tightening data storage.
• Configurable preventative maintenance alarms.
• Intuitive qualitative feedback using Green, Red, and Yellow indicators.
• The QX Series IQV 40 high torque tools utilize the BL4011 40V 2.5Ah battery for increased torque and runtime. The BL4011 is optimum for longer use applications. The 40 volt batteries utilize our IQV Series 40V, 2.5Ah charger BC1161.
• Ergonomic tightening system to reduce torque reaction experienced by operator.
• Insight Connect Android APP Link.
• Programming Methods: Through USB with Insight Connect App available on Android, ICS Software, INISGHTqcx Controllers.

• Includes: Bare tool only, batteries and charger sold separately.
• Actuation/Throttle Type/Switch Type: Trigger
• Anvil Length: Standard

• Built-in Light: No

• Color: Grey
• Configuration/Handle Type: Right Angle-ETS (ergonomic tightening system)
• Data Storage Capacity: 1200 cycles
• Drive Size (in): 1/2
• Drive Type: Square

• Max Free Speed (rpm): 545
• Max Torque (ft-lb): 30
• Max Torque (in-lb): 354
• Max Torque (nm): 40
• Motor: Brushless Motor

• Power Source: Battery Powered
• Product Length (in): 23.1

• Product Height (in): 3.94
• Product Weight (lb): 5
• Recommended Forward Torque Range (ft-lb): 5.9-30
• Recommended Forward Torque Range (in-lb): 71-354
• Recommended Forward Torque Range (nm): 8.0-40
• Retainer Type: Pin Detent
• Reversible: Reversible

• Side to Center Distance (in): 0.85
• Side to Center Distance (mm): 22

• User Interface: No Display
• Voltage DC: 40
• Warranty: 1-year Tool, 2-year Battery, 3-year Charger
• Wireless Tool Tracking: No Wireless Functionality
• Wireless Tool Tracking: Mini USB

IR QXFN5AT040PS08

1/2" 40V Cordless QX Precision Fastening Angle Screwdriver, 354 in-lb Torque, 545 RPM

Description: Designed to replace traditional clutch tools, the 40V high-torque angle QXFN Precision Screwdriver offers the precision and quality of the QX Connect Series in an affordable, simple to set up tool. Add mobility and enhance the simplicity and flexibility of Ingersoll Rand QX Connect Series cordless assembly tools with the INSIGHT Connect app.

Features And Benefits:

• Comes with 32 programmable tightening configuration.
• 1,200 cycles of onboard tightening data storage.
• Configurable preventative maintenance alarms.
• Intuitive qualitative feedback using Green, Red, and Yellow indicators.
• The QX Series IQV 40 high torque tools utilize the BL4011 40V 2.5Ah battery for increased torque and runtime. The BL4011 is optimum for longer use applications. The 40 volt batteries utilize our IQV Series 40V, 2.5Ah charger BC1161.
• Insight Connect Android APP Link.
• Programming Methods: Through USB with Insight Connect App available on Android, ICS Software, INISGHTqcx Controllers.

• Includes: Bare tool only, batteries and charger sold separately.
• Actuation/Throttle Type/Switch Type: Trigger
• Anvil Length: Standard

• Built-in Light: No

• Color: Grey
• Configuration/Handle Type: Right Angle
• Data Storage Capacity: 1200 cycles
• Drive Size (in): 1/2
• Drive Type: Square

• Max Free Speed (rpm): 545
• Max Torque (ft-lb): 30
• Max Torque (in-lb): 354
• Max Torque (nm): 40
• Motor: Brushless Motor

• Power Source: Battery Powered
• Product Length (in): 23.07

• Product Height (in): 3.94
• Product Weight (lb): 5
• Recommended Forward Torque Range (ft-lb): 5.9-30
• Recommended Forward Torque Range (in-lb): 71-354
• Recommended Forward Torque Range (nm): 8.0-40
• Retainer Type: Pin Detent
• Reversible: Reversible

• Side to Center Distance (in): 0.85
• Side to Center Distance (mm): 22

• User Interface: No Display
• Voltage DC: 40
• Warranty: 1-year Tool, 2-year Battery, 3-year Charger
• Wireless Tool Tracking: No Wireless Functionality
• Wireless Tool Tracking: Mini USB

IR QXFN5AT080ES08

1/2" 40V Cordless QX Precision Fastening ETS Angle Screwdriver, 708 in-lb Torque, 375 RPM

Description: Designed to replace traditional clutch tools, the 40V high-torque angle QXFN Precision Screwdriver offers the precision and quality of the QX Connect Series in an affordable, simple to set up tool. Reducing torque reaction doesn't have to be complicated with the QX Connect Series Ergonomic Tightening System. Add mobility and enhance the simplicity and flexibility of Ingersoll Rand QX Connect Series cordless assembly tools with the INSIGHT Connect app.

Features And Benefits:

• Comes with 32 programmable tightening configuration.
• 1,200 cycles of onboard tightening data storage.
• Configurable preventative maintenance alarms.
• Intuitive qualitative feedback using Green, Red, and Yellow indicators.
• The QX Series IQV 40 high torque tools utilize the BL4011 40V 2.5Ah battery for increased torque and runtime. The BL4011 is optimum for longer use applications. The 40 volt batteries utilize our IQV Series 40V, 2.5Ah charger BC1161.
• Ergonomic tightening system to reduce torque reaction experienced by operator.
• Insight Connect Android APP Link.
• Programming Methods: Through USB with Insight Connect App available on Android, ICS Software, INISGHTqcx Controllers.

• Includes: Bare tool only, batteries and charger sold separately.
• Actuation/Throttle Type/Switch Type: Trigger
• Anvil Length: Standard

• Built-in Light: No

• Color: Grey
• Configuration/Handle Type: Right Angle-ETS (ergonomic tightening system)
• Data Storage Capacity: 1200 cycles
• Drive Size (in): 1/2
• Drive Type: Square

• Max Free Speed (rpm): 375
• Max Torque (ft-lb): 59
• Max Torque (in-lb): 708
• Max Torque (nm): 80
• Motor: Brushless Motor

• Power Source: Battery Powered
• Product Length (in): 23.1

• Product Height (in): 3.94
• Product Weight (lb): 5
• Recommended Forward Torque Range (ft-lb): 8.9-59
• Recommended Forward Torque Range (in-lb): 106-708
• Recommended Forward Torque Range (nm): 12.0-80
• Retainer Type: Pin Detent
• Reversible: Reversible

• Side to Center Distance (in): 0.85
• Side to Center Distance (mm): 22

• User Interface: No Display
• Voltage DC: 40
• Warranty: 1-year Tool, 2-year Battery, 3-year Charger
• Wireless Tool Tracking: No Wireless Functionality
• Wireless Tool Tracking: Mini USB

IR QXFN5AT080PS08

1/2" 40V Cordless QX Precision Fastening Angle Screwdriver, 708 in-lb Torque, 375 RPM

Description: Designed to replace traditional clutch tools, the 40V high-torque angle QXFN Precision Screwdriver offers the precision and quality of the QX Connect Series in an affordable, simple to set up tool. Add mobility and enhance the simplicity and flexibility of Ingersoll Rand QX Connect Series cordless assembly tools with the INSIGHT Connect app.

Features And Benefits:

• Comes with 32 programmable tightening configuration.
• 1,200 cycles of onboard tightening data storage.
• Configurable preventative maintenance alarms.
• Intuitive qualitative feedback using Green, Red, and Yellow indicators.
• The QX Series IQV 40 high torque tools utilize the BL4011 40V 2.5Ah battery for increased torque and runtime. The BL4011 is optimum for longer use applications. The 40 volt batteries utilize our IQV Series 40V, 2.5Ah charger BC1161.
• Insight Connect Android APP Link.
• Programming Methods: Through USB with Insight Connect App available on Android, ICS Software, INISGHTqcx Controllers.

• Includes: Bare tool only, batteries and charger sold separately.
• Actuation/Throttle Type/Switch Type: Trigger
• Anvil Length: Standard

• Built-in Light: No

• Color: Grey
• Configuration/Handle Type: Right Angle
• Data Storage Capacity: 1200 cycles
• Drive Size (in): 1/2
• Drive Type: Square

• Max Free Speed (rpm): 375
• Max Torque (ft-lb): 59
• Max Torque (in-lb): 708
• Max Torque (nm): 80
• Motor: Brushless Motor

• Power Source: Battery Powered
• Product Length (in): 23.07

• Product Height (in): 3.94
• Product Weight (lb): 5
• Recommended Forward Torque Range (ft-lb): 8.9-59
• Recommended Forward Torque Range (in-lb): 106-708
• Recommended Forward Torque Range (nm): 12.0-80
• Retainer Type: Pin Detent
• Reversible: Reversible

• Side to Center Distance (in): 0.85
• Side to Center Distance (mm): 22

• User Interface: No Display
• Voltage DC: 40
• Warranty: 1-year Tool, 2-year Battery, 3-year Charger
• Wireless Tool Tracking: No Wireless Functionality
• Wireless Tool Tracking: Mini USB

IR JKST1000

IR JKST150

IR KIT-PFS

IR MS-SW-OPT-1

IR MS-SW-OPT-2

IR MS-SW-OPT-3

IR MTC-SW-BS-1

MTC Activation, 1 Tool Add-on

• For Use With: RTS025PQ4-K2
• For Use With: RTS060PH6-K2
• For Use With: RTS060PH8-K2
• For Use With: RTS060PS6-K2
• For Use With: RTS060PS8-K2
• For Use With: RTS140PH8-K2
• For Use With: RTS140PS8-K2
• For Use With: RTS225PH8-K2
• For Use With: RTS225PS8-K2

IR MTC-SW-OPT10

IR MTC-SW-OPT4-NA

IR NSP-299-72S12

IR NSP-766-52CR

IR NSP-766-52CR90

IR NSP-766-52NX060

IR NSP-766-52PPS060

IR NSP-766-52SL

IR NSP-766-52ST

IR NSP-766-72CR90

IR NSP-766-72ST

IR NSP-766-72STS070

IR NSP-766-72STSD079

IR NSP-766-72WR

IR PB006-30K

IR PC10569952

IR QAS-18-A550-SQ4

IR QC-A365-K2

IR QC-DIO-8CH

IR QCN2P08Q4

IR QCP2A30S6

3/8in 20V Cordless Angle Clutch Tool, 30 Nm, 300 RPM, Programmable

Description: QC Series Clutch Tools are engineered for robust performance, withstanding over 500k cycles in demanding assembly environments and delivering precision in every fastening application. The clutch tool offers a seamless setup experience via the INSIGHT Connect app, enabling quick programming of advanced parameters to meet specific application needs. Designed with user comfort in mind, the balanced ergonomic build helps reduce fatigue, while the dual-speed non-contact trigger provides smooth, efficient operation. Experience the perfect blend of durability, simplicity, and precision with the QC Series Clutch Tools.

Features And Benefits:

• Precise: Thanks to an auto shutoff clutch, QC Series Clutch tools achieve Cmk >1.67 at +/ - 10% accuracy, providing higher repeatability and consistent output, The QC Series Clutch Tool configuration is equipped with a lockable, tamper-proof clutch that delivers up to 30 Nm of torque for various applications, Program RPM and other advanced tool settings via the Insight CONNECT mobile and desktop app.
• Simple: The multi-color 360 degree status beam LED ring light illuminates the work area and provides clear feedback to the user on the workpiece, Combined with the Cycle Status Indicator, which shows pass/fail and helps users verify their work quickly, it helps minimize defects and improve overall quality, Unlock faster and smarter tool configurations with 8 programmable parameters, making it easy to meet specific application requirements, QC Series Clutch Tools are compatible with IQV20 battery and charger platform, providing flexibility and reducing operational costs.
• Durable: Designed to last more than 500k cycles in a high-speed assembly environment, QC Series Clutch Tools deliver reliable performance in almost any application.

Product Application and Uses:

For use in product environments on assembly lines.

• Includes: Bare tool only, batteries and charger sold separately or with other kits.
• Anvil Length: Standard

• Built-in Light: Yes

• Color: Grey
• Configuration/Handle Type: Right Angle
• Drive Size (in): 3/8
• Drive Type: Square
• Duty Rating: Production Environment

• Housing Material: Nylon

• Lumens: 11
• Max Free Speed (rpm): 300
• Motor: Brushless Motor

• Power Source: Battery Powered
• Product Length (in): 20.07

• Product Weight (lb): 3.7
• Product Weight (lb) (with Battery): 4.6
• Recommended Forward Torque Range (ft-lb): 11-22
• Recommended Forward Torque Range (in-lb): 133-266
• Recommended Forward Torque Range (nm): 15-30
• Retainer Type: Pin Detent
• Reversible: Reversible

• Sound Pressure/Power Db(A): 72 / 80

• Vibration Level (m/s2): 0.7
• Vibration Uncertainy K* (m/s2): 0.4
• Voltage DC: 20
• Warranty: 1-year Tool, 2-year Battery, 3-year Charger
• Wireless Tool Tracking: USB-C

• Accessories: BC1124
• Accessories: BC1221
• Accessories: BL2012
• Accessories: BL2022

• Parts: TK-QC2-300
• Parts: TK-QC2A-040

• Parts: TK-QC2A-054
• Parts: TK-QC2A-064
• Parts: TK-QC2A-105
• Parts: TK-QC2A-250
• Parts: TK-QC2A-499-P30
• Parts: TK-QC2A-550
• Parts: TK-QC2A-581
• Parts: TK-QC2A-750
• Parts: TK-QC2P-306
• Parts: VP1-365

IR QCP2P08Q4

1/4" Quick Change 20V Cordless Clutch Tool, 8 Nm, 700 RPM, Programmable, Pistol

Description: QC Series Clutch Tools are engineered for robust performance, withstanding over 500k cycles in demanding assembly environments and delivering precision in every fastening application. The clutch tool offers a seamless setup experience via the INSIGHT Connect app, enabling quick programming of advanced parameters to meet specific application needs. Designed with user comfort in mind, the balanced ergonomic build helps reduce fatigue, while the dual-speed non-contact trigger provides smooth, efficient operation. Experience the perfect blend of durability, simplicity, and precision with the QC Series Clutch Tools.

Features And Benefits:

• Precise: Thanks to an auto shutoff clutch, QC Series Clutch tools achieve Cmk >1.67 at +/ - 10% accuracy, providing higher repeatability and consistent output, The QC Series Clutch Tool configuration is equipped with a lockable, tamper-proof clutch that delivers up to 30 Nm of torque for various applications, Program RPM and other advanced tool settings via the Insight CONNECT mobile and desktop app.
• Simple: The multi-color 360 degree status beam LED ring light illuminates the work area and provides clear feedback to the user on the workpiece, Combined with the Cycle Status Indicator, which shows pass/fail and helps users verify their work quickly, it helps minimize defects and improve overall quality, Unlock faster and smarter tool configurations with 8 programmable parameters, making it easy to meet specific application requirements, QC Series Clutch Tools are compatible with IQV20 battery and charger platform, providing flexibility and reducing operational costs.
• Durable: Designed to last more than 500k cycles in a high-speed assembly environment, QC Series Clutch Tools deliver reliable performance in almost any application.

Product Application and Uses:

For use in product environments on assembly lines.

• Includes: Bare tool only, batteries and charger sold separately or with other kits.
• Anvil Length: Standard

• Built-in Light: Yes

• Color: Grey
• Configuration/Handle Type: Pistol Grip
• Drive Size (in): 1/4
• Drive Type: Hex
• Duty Rating: Production Environment

• Housing Material: Nylon

• Lumens: 11
• Max Free Speed (rpm): 700
• Motor: Brushless Motor

• Power Source: Battery Powered
• Product Length (in): 8.26

• Product Weight (lb): 2.31
• Product Weight (lb) (with Battery): 3.21
• Recommended Forward Torque Range (ft-lb): 2.2-5.9
• Recommended Forward Torque Range (in-lb): 27-71
• Recommended Forward Torque Range (nm): 3-8
• Retainer Type: Quick Change
• Reversible: Reversible

• Sound Pressure/Power Db(A): 73 / 81

• Vibration Level (m/s2): 0.8
• Vibration Uncertainy K* (m/s2): 0.5
• Voltage DC: 20
• Warranty: 1-year Tool, 2-year Battery, 3-year Charger
• Wireless Tool Tracking: USB-C

• Accessories: BC1124
• Accessories: BC1221
• Accessories: BL2012
• Accessories: BL2022

• Parts: TK-QC2-300
• Parts: TK-QC2P-040

• Parts: TK-QC2P-054
• Parts: TK-QC2P-105
• Parts: TK-QC2P-250
• Parts: TK-QC2P-306
• Parts: TK-QC2P-499-P08
• Parts: TK-QC2P-581C
• Parts: TK-QC2P-727C
• Parts: TK-QC2P-750B
• Parts: TK-QC2P-ALED
• Parts: VP1-365

IR QCP2P12Q4

1/4" Quick Change 20V Cordless Clutch Tool, 12 Nm, 700 RPM, Programmable, Pistol

Description: QC Series Clutch Tools are engineered for robust performance, withstanding over 500k cycles in demanding assembly environments and delivering precision in every fastening application. The clutch tool offers a seamless setup experience via the INSIGHT Connect app, enabling quick programming of advanced parameters to meet specific application needs. Designed with user comfort in mind, the balanced ergonomic build helps reduce fatigue, while the dual-speed non-contact trigger provides smooth, efficient operation. Experience the perfect blend of durability, simplicity, and precision with the QC Series Clutch Tools.

Features And Benefits:

• Precise: Thanks to an auto shutoff clutch, QC Series Clutch tools achieve Cmk >1.67 at +/ - 10% accuracy, providing higher repeatability and consistent output, The QC Series Clutch Tool configuration is equipped with a lockable, tamper-proof clutch that delivers up to 30 Nm of torque for various applications, Program RPM and other advanced tool settings via the Insight CONNECT mobile and desktop app.
• Simple: The multi-color 360 degree status beam LED ring light illuminates the work area and provides clear feedback to the user on the workpiece, Combined with the Cycle Status Indicator, which shows pass/fail and helps users verify their work quickly, it helps minimize defects and improve overall quality, Unlock faster and smarter tool configurations with 8 programmable parameters, making it easy to meet specific application requirements, QC Series Clutch Tools are compatible with IQV20 battery and charger platform, providing flexibility and reducing operational costs.
• Durable: Designed to last more than 500k cycles in a high-speed assembly environment, QC Series Clutch Tools deliver reliable performance in almost any application.

Product Application and Uses:

For use in product environments on assembly lines.

• Includes: Bare tool only, batteries and charger sold separately or with other kits.
• Anvil Length: Standard

• Built-in Light: Yes

• Color: Grey
• Configuration/Handle Type: Pistol Grip
• Drive Size (in): 1/4
• Drive Type: Hex
• Duty Rating: Production Environment

• Housing Material: Nylon

• Lumens: 11
• Max Free Speed (rpm): 700
• Motor: Brushless Motor

• Power Source: Battery Powered
• Product Length (in): 8.26

• Product Weight (lb): 2.31
• Product Weight (lb) (with Battery): 3.21
• Recommended Forward Torque Range (ft-lb): 3.7-8.9
• Recommended Forward Torque Range (in-lb): 44-106
• Recommended Forward Torque Range (nm): 5-12
• Retainer Type: Quick Change
• Reversible: Reversible

• Sound Pressure/Power Db(A): 73 / 81

• Vibration Level (m/s2): 0.8
• Vibration Uncertainy K* (m/s2): 0.5
• Voltage DC: 20
• Warranty: 1-year Tool, 2-year Battery, 3-year Charger
• Wireless Tool Tracking: USB-C

• Accessories: BC1124
• Accessories: BC1221
• Accessories: BL2012
• Accessories: BL2022

• Parts: TK-QC2-300
• Parts: TK-QC2P-040

• Parts: TK-QC2P-054
• Parts: TK-QC2P-105
• Parts: TK-QC2P-250
• Parts: TK-QC2P-306
• Parts: TK-QC2P-499-P12
• Parts: TK-QC2P-581D
• Parts: TK-QC2P-727D
• Parts: TK-QC2P-750B
• Parts: TK-QC2P-ALED
• Parts: VP1-365

IR QCX-309-AN-K2

IR QCX-A499-CARR-NR-K

IR QCX-A830D-K

IR QE2AL015PA3Q04

IR QE2AL015PA3S06

IR QE2PS010P11Q04

IR QE2SC007FM0

IR QE2SL010PM0

IR QE2SP003P11Q04

IR QE2SP010P11Q04

IR QE2SP010P11S04

IR QE2TS002P11Q04

IR QE2TS005P11Q04

IR QE2TS007P11Q04

IR QE2TS010P11S04

IR QE4SC015B20Q04

IR QE4ST015B20Q04

IR QE4ST015B21Q04

IR QE4ST020B21Q04

IR QE4ST020R20Q04

IR QE6AT030PA4S06

IR QE6AT080PA5S08

IR QE6SC033F41S06

IR QE6SC050F61S08

IR QE6SE033F41S06

IR QE6SE050F41S08

IR QE6ST033B41S08

IR QE6ST033F41S06

IR QE6ST050B41S08

IR QE6ST050F41S08

IR QE8AC400FA8S12

IR QE8AT065PA5S08

IR QE8AT090FA5S08

IR QE8AT090PA5S08

IR QE8AT090PA6S08

IR QE8AT115PA6S08

IR QE8AT150PA6S08

IR QE8AT150RA6S08

IR QE8AT225FA7S12

IR QE8AT225PA7S12

IR QE8AT400FA8S12

IR QE8ST090B41S08

IR QE8ST150F61S08

IR QE8ST230F62S12

IR QM7SS220H62S12

IR QM9SS435H22S12

IR QXBD2AT000P000

IR QXBD2AT018PQ04

1/4" Hex 20V Cordless QX Precision Fastening Angle Torque Wrench, 159 in-lb Torque, 500 RPM

Description: Increase the productivity of your assembly line with the Cordless 20V Angle Wrench. Offering 32 programmable configurations in a single tool, this member of the QX Connect Series Precision Fastening System streamlines your operation into one tool with traceable, accurate results. The QXBD models also offer users the Bluetooth connectivity capability to wirelessly program the QX Connect Series tools using the INSIGHT Connect App.

Features And Benefits:

• Comes with 32 programmable tightening configuration.
• Bluetooth further add mobility to enable Wireless programming using the INSIGHT Connect app
• Enhanced quantitative feedback - displaying the actual measured torque or angle result.
• 1,200 cycles of onboard tightening data storage.
• Configurable preventative maintenance alarms.
• Intuitive qualitative feedback using Green, Red, and Yellow indicators.
• All QX Series IQV20 tools are compatible with both the BL2022 and BL2012 batteries. The BL2022 is optimum for longer use applications while the BL2012 is ideal for tighter spaces and reduced weight. The 20-volt batteries utilize our 20V battery charger.
• Insight Connect Android APP LINK.
• Optional ergonomic tightening system to reduce torque reaction experienced by operator.
• Multiple Programming Methods: Through USB with, INSIGHTqcx Controller, Insight Connect Android App, and ICS Software.

• Includes: Bare tool only, batteries and charger sold separately.
• Actuation/Throttle Type/Switch Type: Trigger
• Anvil Length: Standard

• Built-in Light: No

• Color: Grey
• Configuration/Handle Type: Right Angle
• Data Storage Capacity: 1200 cycles
• Drive Size (in): 1/4
• Drive Type: Hex

• Max Free Speed (rpm): 500
• Max Torque (ft-lb): 13
• Max Torque (in-lb): 159
• Max Torque (nm): 18
• Motor: Brushless Motor

• Power Source: Battery Powered
• Product Length (in): 24.34

• Product Height (in) (with Battery): 3.94
• Product Weight (lb): 2.8
• Recommended Forward Torque Range (ft-lb): 2.7-13
• Recommended Forward Torque Range (in-lb): 32-159
• Recommended Forward Torque Range (nm): 3.6-18
• Retainer Type: Quick Change
• Reversible: Reversible

• Side to Center Distance (in): 0.51
• Side to Center Distance (mm): 13

• User Interface: Display
• Voltage DC: 20
• Warranty: 1-year Tool, 2-year Battery, 3-year Charger
• Wireless Tool Tracking: Bluetooth
• Wireless Tool Tracking: USB-C

IR QXBD2AT027ES06

3/8in 20V Cordless QX Precision Fastening ETS Angle Screwdriver, 239 in-lb, 330 RPM

Features And Benefits:

• Comes with 32 programmable tightening configuration.
• Bluetooth further add mobility to enable Wireless programming using the INSIGHT Connect app
• Enhanced quantitative feedback - displaying the actual measured torque or angle result.
• 1,200 cycles of onboard tightening data storage.
• Configurable preventative maintenance alarms.
• Intuitive qualitative feedback using Green, Red, and Yellow indicators.
• All QX Series IQV20 tools are compatible with both the BL2022 and BL2012 batteries. The BL2022 is optimum for longer use applications while the BL2012 is ideal for tighter spaces and reduced weight. The 20-volt batteries utilize our 20V battery charger.
• Insight Connect Android APP LINK.
• Optional ergonomic tightening system to reduce torque reaction experienced by operator.
• Multiple Programming Methods: Through USB with, INSIGHTqcx Controller, Insight Connect Android App, and ICS Software.

• Includes: Bare tool only, batteries and charger sold separately.
• Actuation/Throttle Type/Switch Type: Trigger
• Anvil Length: Standard

• Built-in Light: No

• Color: Grey
• Configuration/Handle Type: Right Angle-ETS (ergonomic tightening system)
• Data Storage Capacity: 1200 cycles
• Drive Size (in): 3/8
• Drive Type: Square

• Max Free Speed (rpm): 330
• Max Torque (ft-lb): 20
• Max Torque (in-lb): 239
• Max Torque (nm): 27
• Motor: Brushless Motor

• Power Source: Battery Powered
• Product Length (in): 21.73

• Product Height (in) (with Battery): 3.94
• Product Weight (lb): 3.7
• Recommended Forward Torque Range (ft-lb): 4.0-20
• Recommended Forward Torque Range (in-lb): 48-239
• Recommended Forward Torque Range (nm): 5.4-27
• Retainer Type: Pin Detent
• Reversible: Reversible

• Side to Center Distance (in): 0.68
• Side to Center Distance (mm): 17

• User Interface: Display
• Voltage DC: 20
• Warranty: 1-year Tool, 2-year Battery, 3-year Charger
• Wireless Tool Tracking: Bluetooth
• Wireless Tool Tracking: USB-C

IR QXBD2PT000E000
