Finishing Packages

GG 234916

TRITON SPRAYER, SS, PUMP CART MNT, STELLAIR, COMP

Triton SST Spray Package, Cart, 100 psi Regulator, Suction, Air & Fluid Hoses, Stellair Compliant Gun .055 in (1.4 mm) Nozzle for MetalTriton air operated diaphragm pump with Stellair air spray gun brings affordable, fine finish spraying to wood and metal applications.Effective alternative to traditional pressure pots and standard diaphragm pumps saves material and time during flushing, priming and color changes.Triton® air operated pump produces 30 percent more pumping power and 50 percent less pressure pulsation than standard diaphragm pumps.Rugged, stainless steel pump handles a wide variety of fluids.The Stellair air spray gun provides the ergonomics, performance and serviceability painters need to produce stellar results.High volume low pressure (HVLP) air spray produces a controlled, low velocity spray pattern that reduces bounce back and overspray, while meeting environmental regulations.

GG 234917

TRITON SPRAYER, AL PUMP WALL MNT, STELLAIR, COMP

Triton Alum Spray Package, Wall, 60 psi Regulator, Air & Fluid Hoses, Stellair Compliant Gun .055 in (1.4 mm) Nozzle for Metal ApplicationsTriton air operated diaphragm pump with Stellair air spray gun brings affordable, fine finish spraying to wood and metal applications.Effective alternative to traditional pressure pots and standard diaphragm pumps saves material and time during flushing, priming and color changes.Triton® air operated pump produces 30 percent more pumping power and 50 percent less pressure pulsation than standard diaphragm pumps.Rugged, aluminum pump handles a wide variety of fluids.The Stellair air spray gun provides the ergonomics, performance and serviceability painters need to produce stellar results.High volume low pressure (HVLP) air spray produces a controlled, low velocity spray pattern that reduces bounce back and overspray, while meeting environmental regulations.

GG 234918

TRITON SPRAYER, SS PUMP WALL MNT, STELLIAR, COMP

Triton SST Spray Package, Wall, 100 psi Regulator, Air & Fluid Hoses, Stellair Compliant Gun .055 in (1.4 mm) Nozzle for Metal ApplicationsTriton air operated diaphragm pump with Stellair air spray gun brings affordable, fine finish spraying to wood and metal applications.Effective alternative to traditional pressure pots and standard diaphragm pumps saves material and time during flushing, priming and color changes.Triton® air operated pump produces 30 percent more pumping power and 50 percent less pressure pulsation than standard diaphragm pumps.Rugged, stainless steel pump handles a wide variety of fluids.Delivers a consistent spray pattern and uniform film thicknessCompliant air spray reduces bounce back and overspray, while delivering high finish quality and transfer efficiency.

GG 247550

HYDRA-CLEAN SYSTEM, 12:1 WALL MT

Hydra-Clean® 12:1 Wall Mount Pneumatic Pressure Washer Package

Clean up your facility the quick, easy and efficient way with Graco Hydra-Clean pressure washers! Designed with Graco’s NXT air motor, it's ideal for industrial and sanitary applications including food processing facilities, heavy duty cleaning, maintenance, shipyards, oil rigs and more.

Ideal for heavy duty cleaning and maintenance for industrial and sanitary applicationsGreat for high pressure cleaning and sanitizingFits most pressure, flow and material requirementsUse with open-head universal drumsDesigned to use with cold or hot water up to 180°F (82°C)Spray down portability for use in sanitary applicationsSupports multiple gunsEfficient cleaning with water, detergent or chemical solutions

GG 247553

HYDRA-CLEAN SYSTEM, 30:1 CART MT

Hydra-Clean® 30:1 Cart Mount Pneumatic Pressure Washer Package

Clean up your facility the quick, easy and efficient way with Graco Hydra-Clean pressure washers! Designed with Graco’s NXT air motor, it's ideal for industrial and sanitary applications including food processing facilities, heavy duty cleaning, maintenance, shipyards, oil rigs and more.

Ideal for heavy duty cleaning and maintenance for industrial and sanitary applicationsGreat for high pressure cleaning and sanitizingFits most pressure, flow and material requirementsUse with open-head universal drumsDesigned to use with cold or hot water up to 180°F (82°C)Spray down portability for use in sanitary applicationsSupports multiple gunsEfficient cleaning with water, detergent or chemical solutions

GG 247554

HYDRA-CLEAN SYSTEM, 30:1 WALL MT

Hydra-Clean® 30:1 Wall Mount Pneumatic Pressure Washer Package

Clean up your facility the quick, easy and efficient way with Graco Hydra-Clean pressure washers! Designed with Graco’s NXT air motor, it's ideal for industrial and sanitary applications including food processing facilities, heavy duty cleaning, maintenance, shipyards, oil rigs and more.

Ideal for heavy duty cleaning and maintenance for industrial and sanitary applicationsGreat for high pressure cleaning and sanitizingFits most pressure, flow and material requirementsUse with open-head universal drumsDesigned to use with cold or hot water up to 180°F (82°C)Spray down portability for use in sanitary applicationsSupports multiple gunsEfficient cleaning with water, detergent or chemical solutions

GG 247599

Hydra-Clean Pump, Disp, Recip

GG 247984

HYDRA-CLEAN SYSTEM, ACLEAN LT, 45:1

HydraClean® LT 45:1 Cart Mount Pneumatic Pressure Washer

Clean Your Equipment Where It Is

Less Water. Less Time. Longer Life.

Immensely portable and built for hazardous locations. The HydraClean LT keeps your equipment running longer underground, at sea, and in volatile manufacturing environments.

The Most Pressure for the Value on the Market.

HIGH-PRESSURE, SINGLE-GUN CLEANING

• Up to 4,500 psi (310.3 bar)
• ATEX approved for hazardous locations

EASY-TO-USE

• Use with cold or hot water up to 160°F (71°C)
• PPE friendly large pressure controls
• Includes 5 fan pattern spray tips for various applications

ROBUST CONSTRUCTION

• SST pump withstands cleaning chemicals and untreated water
• High quality Graco piston pump technology
• Strongest tubular steel cart on the market

GG 249617

GH SPRAYER, 833, COMPLETE

Graco 249617 GH 833 Gas Hydraulic Sprayer, Complete

The GH 833 is the preferred choice for high production professional contractors who spray the wide range of materials. This jobsite-proven workhorse is the answer when you demand ruggedness, performance and value.

• Honda Engine

  390 cc (13 HP) engine with integrated fuel tank to deliver maximum performance

  Contractor preferred engine with Oil Alert

• Heavy-Duty Hydraulic System

  Faster, more responsive changeover

  O-ring sealed to eliminate leaks

  High-precision pressure control

  No hydraulic reset button needed

  Durable hydraulic lines for long life

• Heavy-Duty Cooling System

  Large 4 gallon hydraulic reservoir

  Return line hydraulic filter extends life

  No special hydraulic fluid needed

  Proven cooler and blower system

  Easy to use drain plug

• MaxLife Endurance Pump

  Proven design and performance

  Only 16 cycles per gallon (4.2 cycles per liter)

  Exclusive MaxLife rod and sleeve delivers unmatched durability and life - Graco's best

  Exclusive QuikChange Pump System and QuikAccess Intake Valve eliminates downtime

• Flow-Through Filter System

  Inside/out design eliminates clogged filters

  Eliminates tip clogs

• Ready-To-Spray Complete System

  Configured with 50 feet of pressure-rated hose, gun, tips, and all the fittings you will need

• Model: GH
• Series: 833

• Compatible Material: Acrylics, Block Filler, Coal Tar, Contact Cement, Elastomerics, Enamel, Epoxies, Fibered Aluminum Emulsion, Fibered Asphalt Emulsion, Mastics, Non-Fibered Aluminum Emulsion, Non-Fibered Asphalt Emulsion, Paint, Polyester, Polyurethane, Primer, Texture Mud, Waterproofing
• Compatible Replacement Pump: 287834

• Control Type: N/A

• Engine Brand: Honda
• Engine Size (HP): 13

• Fluid Inlet Size (in): 1-1/2 to 11-1/2
• Fluid Inlet Thread Type: MNPT

• Fluid Outlet Size (in): 1 to 11-1/2
• Fluid Outlet Thread Type: FNPT

• Frame Configuration: Cart

• Includes: Silver Plus Gun, RAC X 517 Spray Tip, RAC X 655 Spray Tip, RAC X Guard, 3/8 in x 50 ft BlueMax II HP Airless Hose, 1/4 in x 3 ft BlueMax II HP Airless Whip Hose

• Material Application: Paints, Primers

• Maximum Flow Rate (GPM): 4.0
• Maximum Flow Rate (L/min): 15.1

• Maximum Hose Length (ft): 50
• Maximum Hose Length (m): 15

• Maximum Sound Pressure Level (dB(A)): 91

• Maximum Tip Size (in): 0.065
• Maximum Tip Size Gun 2 (in): 0.046
• Maximum Tip Size Gun 3 (in): 0.037
• Maximum Tip Size Gun 4 (in): 0.032
• Maximum Tip Size Gun 5 (in): 0.029

• Maximum Tip Size Gun 6 (in): 0.026

• Maximum Working Pressure (bar): 275.8
• Maximum Working Pressure (kPa): 27580
• Maximum Working Pressure (MPa): 27.6
• Maximum Working Pressure (psi): 4000

• Motor Type: Hydraulic Motor

• Number of Guns: 6

• Outlet Paint Filter: 60 Mesh Stainless Steel Screen

• Power Rating (cc): 390
• Power Rating (HP): 13
• Power Rating (kW): 9.7
• Power Rating (W): 9694
• Power Source: Gas Hydraulic
• Pressure Control Type: Pressure Control Knob

• Product Type

GG 249767

Gh System, 833, Oem

GG 24N548

Merkur Es Pump, 30:1, Isolation

GG 289630

TRITON SPRAYER, AL WALL MNT CONV STAIN

Triton Alum Spray Package, Wall, Air & Fluid Hoses, AirPro Conventional Gun .040 in (1.0 mm) Nozzle for Wood ApplicationsAir-operated diaphragm spray package designed for the finishing market. It is a more effective alternative to traditional pressure pots and standard diaphragm pumps.Superior finish quality for conventional, HVLP and compliant or electrostatic applicationsSupplies up to 35% extra air flow to gun for superior atomizationSaves material and time during flushing, priming and color changesDelivers a consistent spray pattern and uniform film thicknessRugged, stainless steel or aluminum construction pump handles a wide variety of fluids

GG G03C03

MERKUR SYSTEM, PUMP, 3:1, 125CC, CART, STD

3:1 Merkur Air Spray Package, 125cc, Cart, Pump/Gun Air Controls, Siphon Kit, Fluid Filter, No ApplicatorMake the right choice for your finishing applications with Merkur Low Pressure Packages. The Merkur low-pressure piston pump comes with advanced air spray technology.The pump lower has the best solution for smooth, low pulsation operation.The air motor operates efficiently with low air consumption.Cart mount configuration makes fine finish spraying easy in different locations.

GG G03W01

MERKUR SYSTEM, PUMP, 3:1, 125CC, WALL, STD

3:1 Merkur Air Spray Package, 125cc, Wall, Pump/Gun Air Controls, Siphon Kit, No ApplicatorMake the right choice for your finishing applications with Merkur Low Pressure Packages. The Merkur low-pressure piston pump comes with advanced air spray technology.The pump lower has the best solution for smooth, low pulsation operation.The air motor operates efficiently with low air consumption.Wall mount configuration offers easy access to data monitoring and controls.

GG G03W03

MERKUR SYSTEM, PUMP, 3:1, 125CC, WALL, STD

3:1 Merkur Air Spray Package, 125cc, Wall, Pump/Gun Air Controls, Siphon Kit, Fluid Filter, No ApplicatorMake the right choice for your finishing applications with Merkur Low Pressure Packages. The Merkur low-pressure piston pump comes with advanced air spray technology.The pump lower has the best solution for smooth, low pulsation operation.The air motor operates efficiently with low air consumption.Wall mount configuration offers easy access to data monitoring and controls.

GG G03W15

MERKUR SYSTEM, PUMP, 3:1, 125CC, WALL, STD

3:1 Merkur Air Spray Package, 125cc, Wall, No ApplicatorMake the right choice for your finishing applications with Merkur Low Pressure Packages. The Merkur low-pressure piston pump comes with advanced air spray technology.Wall mount configuration offers easy access to data monitoring and controls.The air motor operates efficiently with low air consumption.The pump lower has the best solution for smooth, low pulsation operation.

GG G05B01

MERKUR BELLOWS SYSTEM, PUMP, 150CC, STD

Merkur Bellows 5:1 Ratio Pump Package with V-Packing Seal, Wall Mount, Fluid FilterGraco’s Merkur bellows piston pumps provide low maintenance with no seals exposed to the atmosphere. These pumps are designed to eliminate conventional throat seals, providing high reliability for moisture-sensitive materials.Highest technology air motor on the marketLow air consumption for increased efficiencySimple air motor design and minimal parts reduces repair timeEasy-to-flush design allows for fast color changes and reduced material waste300 series stainless steel pump construction provides long-lasting durability

GG G05B09

MERKUR BELLOWS SYSTEM, PUMP, 150CC, STD

Merkur Bellows 5:1 Ratio Pump Package with U-Cup Seal, Wall Mount, Fluid FilterGraco’s Merkur bellows piston pumps provide low maintenance with no seals exposed to the atmosphere. These pumps are designed to eliminate conventional throat seals, providing high reliability for moisture-sensitive materials.Highest technology air motor on the marketLow air consumption for increased efficiencySimple air motor design and minimal parts reduces repair timeEasy-to-flush design allows for fast color changes and reduced material waste300 series stainless steel pump construction provides long-lasting durability

GG G10C03

MERKUR SYSTEM, PUMP, 10:1, 75CC, CART, STD

Graco G10C03 10:1 Merkur Pump, 1.2 gpm (4.5 lpm) fluid flow, Cart Mount, Pump/Gun Air Controls, Suction Hose

Designed to improve productivity, reduce costs, lower emissions and provide consistent, high quality finishes for all of your demanding applications.

• Proven to outperform and outlast other pumps in their class
• Highest technology air motor on the market
• Low air consumption for increased efficiency

• Model: Merkur

• Compatible Material: Waterborne, Solvent borne, High Solids, Single Components, Topcoats, Varnish, Lacquer, Acid Catalysts, Enamel, UV Coating

• Fluid Inlet Size (cm): 1.905
• Fluid Inlet Size (in): 3/4
• Fluid Inlet Size (mm): 19.05
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (cm): 0.9525
• Fluid Outlet Size (in): 3/8
• Fluid Outlet Size (mm): 9.525
• Fluid Outlet Thread Type: NPT

• Gun Included: 0
• Gun Model: No Applicator
• Gun Technology: Bare Package
• Gun Type: No Applicator

• Hose Inlet Diameter (cm): 0.476
• Hose Inlet Diameter (in): 3/16
• Hose Inlet Diameter (mm): 4.76

• Includes: Pump and Gun Air Controls, Suction Hose

• Maximum Air Inlet Pressure (bar): 7
• Maximum Air Inlet Pressure (kPa): 700
• Maximum Air Inlet Pressure (psi): 100

• Maximum Flow Rate (GPM): 1.2
• Maximum Flow Rate (L/min): 4.5

• Maximum Working Pressure (bar): 69
• Maximum Working Pressure (kPa): 6900
• Maximum Working Pressure (psi): 1000

• Mount Type: Cart Mount

• Power Source: Air

• Pressure Type: High Pressure
• Product Type: Bare Package

• Pump Ratio: 10:1
• Pump Type: Pneumatic Piston Pump

GG G10W01

MERKUR SYSTEM PUMP 10:01 75CC WA STD

Graco G10W01 10:1 Merkur Pump, 1.2 gpm (4.5 lpm) fluid flow, Wall Mount, Pump/Gun Air Controls

Designed to improve productivity, reduce costs, lower emissions and provide consistent, high quality finishes for all of your demanding applications.

• Proven to outperform and outlast other pumps in their class
• Highest technology air motor on the market
• Low air consumption for increased efficiency

• Model: Merkur

• Compatible Material: Waterborne, Solvent borne, High Solids, Single Components, Topcoats, Varnish, Lacquer, Acid Catalysts, Enamel, UV Coating

• Fluid Inlet Size (cm): 1.905
• Fluid Inlet Size (in): 3/4
• Fluid Inlet Size (mm): 19.05
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (cm): 0.9525
• Fluid Outlet Size (in): 3/8
• Fluid Outlet Size (mm): 9.525
• Fluid Outlet Thread Type: NPT

• Gun Included: 0
• Gun Model: No Applicator
• Gun Technology: Bare Package
• Gun Type: No Applicator

• Hose Inlet Diameter (cm): 0.476
• Hose Inlet Diameter (in): 3/16
• Hose Inlet Diameter (mm): 4.76

• Includes: Pump and Gun Air Controls

• Maximum Air Inlet Pressure (bar): 7
• Maximum Air Inlet Pressure (kPa): 700
• Maximum Air Inlet Pressure (psi): 100

• Maximum Flow Rate (GPM): 1.2
• Maximum Flow Rate (L/min): 4.5

• Maximum Working Pressure (bar): 69
• Maximum Working Pressure (kPa): 6900
• Maximum Working Pressure (psi): 1000

• Mount Type: Wall Mount

• Power Source: Air

• Pressure Type: High Pressure
• Product Type: Bare Package

• Pump Ratio: 10:1
• Pump Type: Pneumatic Piston Pump

GG G10W03

MERKUR SYSTEM PUMP 10:01 75CC WA STD

Graco G10W03 10:1 Merkur Pump, 1.2 gpm (4.5 lpm) fluid flow, Wall Mount, Pump/Gun Air Controls, Suction Hose

Designed to improve productivity, reduce costs, lower emissions and provide consistent, high quality finishes for all of your demanding applications.

• Proven to outperform and outlast other pumps in their class
• Highest technology air motor on the market
• Low air consumption for increased efficiency

• Model: Merkur

• Compatible Material: Waterborne, Solventborne, High Solids, Single Components, Topcoats, Varnish, Lacquer, Acid Catalysts, Enamel, UV Coating

• Fluid Inlet Size (cm): 1.905
• Fluid Inlet Size (in): 3/4
• Fluid Inlet Size (mm): 19.05
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (cm): 0.9525
• Fluid Outlet Size (in): 3/8
• Fluid Outlet Size (mm): 9.525
• Fluid Outlet Thread Type: NPT

• Gun Included: 0
• Gun Model: No Applicator
• Gun Technology: Bare Package
• Gun Type: No Applicator

• Hose Inlet Diameter (cm): 0.476
• Hose Inlet Diameter (in): 3/16
• Hose Inlet Diameter (mm): 4.76

• Includes: Pump and Gun Air Controls, Suction Hose

• Maximum Air Inlet Pressure (bar): 7
• Maximum Air Inlet Pressure (kPa): 700
• Maximum Air Inlet Pressure (psi): 100

• Maximum Flow Rate (GPM): 1.2
• Maximum Flow Rate (L/min): 4.5

• Maximum Working Pressure (bar): 69
• Maximum Working Pressure (kPa): 6900
• Maximum Working Pressure (psi): 1000

• Mount Type: Wall Mount

• Power Source: Air

• Pressure Type: High Pressure
• Product Type: Bare Package

• Pump Ratio: 10:1
• Pump Type: Pneumatic Piston Pump

GG G10W07

MERKUR SYSTEM PUMP 10:1 75CC WALL STD

10:1 Merkur AA Package, 1.2 gpm (4.5 lpm) fluid flow, Wall Mount, PerformAA 15 Gun, Pump Air Controls, Gun Air/Fluid Hose, FilterDesigned to improve productivity, reduce costs, lower emissions and provide consistent, high quality finishes for all of your demanding applications.Proven to outperform and outlast other pumps in their classHighest technology air motor on the marketLow air consumption for increased efficiencyExternal valve access allows for easy servicing and online replacement to minimize downtime

GG G10W09

MERKUR SYSTEM PUMP 10:01 75CC WA STD

Graco G10W09 10:1 Merkur Pump, 1.2 gpm (4.5 lpm) fluid flow, Wall Mount

Designed to improve productivity, reduce costs, lower emissions and provide consistent, high quality finishes for all of your demanding applications.

• Proven to outperform and outlast other pumps in their class
• Highest technology air motor on the market
• Low air consumption for increased efficiency

• Model: Merkur

• Compatible Material: Waterborne, Solventborne, High Solids, Single Components, Topcoats, Varnish, Lacquer, Acid Catalysts, Enamel, UV Coating

• Fluid Inlet Size (cm): 1.905
• Fluid Inlet Size (in): 3/4
• Fluid Inlet Size (mm): 19.05
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (cm): 0.9525
• Fluid Outlet Size (in): 3/8
• Fluid Outlet Size (mm): 9.525
• Fluid Outlet Thread Type: NPT

• Gun Included: 0
• Gun Model: No Applicator
• Gun Technology: Bare Package
• Gun Type: No Applicator

• Hose Inlet Diameter (cm): 0.476
• Hose Inlet Diameter (in): 3/16
• Hose Inlet Diameter (mm): 4.76

• Maximum Air Inlet Pressure (bar): 7
• Maximum Air Inlet Pressure (kPa): 700
• Maximum Air Inlet Pressure (psi): 100

• Maximum Flow Rate (GPM): 1.2
• Maximum Flow Rate (L/min): 4.5

• Maximum Working Pressure (bar): 69
• Maximum Working Pressure (kPa): 6900
• Maximum Working Pressure (psi): 1000

• Mount Type: Wall Mount

• Power Source: Air

• Pressure Type: High Pressure
• Product Type: Bare Package

• Pump Ratio: 10:1
• Pump Type: Pneumatic Piston Pump

GG G15B01

MERKUR BELLOWS SYSTEM, PUMP, 50CC, STD

Merkur Bellows 15:1 Ratio Pump Package with V-Packing Seal, Wall Mount, Fluid FilterGraco’s Merkur bellows piston pumps provide low maintenance with no seals exposed to the atmosphere. These pumps are designed to eliminate conventional throat seals, providing high reliability for moisture-sensitive materials.Highest technology air motor on the marketLow air consumption for increased efficiencySimple air motor design and minimal parts reduces repair timeEasy-to-flush design allows for fast color changes and reduced material waste300 series stainless steel pump construction provides long-lasting durability

GG G15B17

MERKUR BELLOWS SYSTEM, PUMP, 50CC, STD

Merkur Bellows 15:1 Ratio Pump Package with U-Cup Seal, Wall Mount, Fluid FilterGraco’s Merkur bellows piston pumps provide low maintenance with no seals exposed to the atmosphere. These pumps are designed to eliminate conventional throat seals, providing high reliability for moisture-sensitive materials.Highest technology air motor on the marketLow air consumption for increased efficiencySimple air motor design and minimal parts reduces repair timeEasy-to-flush design allows for fast color changes and reduced material waste300 series stainless steel pump construction provides long-lasting durability
