Sealant and Adhesives

LC 218330

LC 2265279

LC 231232

LC 2759219

LC 376747

LC 478490

LC 478602

LC 542208

LC 56531

LC 585583

LC 608966

LC 97226

LC 984117

LC 98501

LC 998400

GG 01/1453/99

GG 249572

REACTOR E-10 PROPORTIONER, CMPLT, 240V, 1X16A, HTD

Graco 249572 Reactor E-10 Heated Proportioner with 20 A Circuit, 240 V

Gracos Reactor E-10 is a small, ready-to-use system that helps you get in and get smaller jobs done fast without sacrificing performance. The Reactor E-10 sprayers are ideal for plural-component spray, joint-fill jobs and touch-ups. With smart controls that are easy to setup and simple to operate, the E-10 is a natural complement to any proportioning equipment line-up.

• Small size


  Ideal for on-site portability and hard-to-reach areas

• Cost Savings


  One-person operation saves time and money

• Extent your spray business


  Use as an add-on to your existing spray business

• Material savings


  Saves 30% on material costs compared to disposable foam systems

• Electric power


  Low draw and plugs into standard outlets

• Single Knob Operation


  Intuitive start, stop and digital temperature display with single knob operation

• Easily balancing


  Pressure balance valves give you quick and easy balancing of system pressures

  Balanced proportioning eliminates pressure fluctuations to give you a consistent spray pattern

• Easy-to-service fluid section


  Reduces maintenance and increases productivity

• Electric motor


  Improves performance and reduces operating costs

• Spray on-ratio


  Self-contained translucent material tanks show you that you are spraying on-ratio

• Pre-heat material


  Heaters and hose give you up to 2000 watts to pre-heat circulating material

• Model: Reactor
• Series: E-10

• Air Inlet Size (cm): 0.635
• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35

• Air Outlet Size (cm): 0.635
• Air Outlet Size (in): 1/4
• Air Outlet Size (mm): 6.35
• Air Outlet Thread Type: NPSM

• Amperage (A): 20
• Application: Spray Foam
• Applicator Type: Manual

• Compatible Material: Plural Components

• Component Type: Two Component

• Flush Type: Solvent

• Frequency (Hz): 50/60

• Gun Type: No Gun

• Hose Package: No Hose

• Material Application: Polyurethane Foam

• Maximum Flow Rate (kg/min): 5.44
• Maximum Flow Rate (lb/min): 12

• Maximum Fluid Temperature (°C): 71
• Maximum Fluid Temperature (°F): 160

• Maximum Fluid Temperature (°C): 71
• Maximum Fluid Temperature (°F): 160

• Maximum Hose Length (ft): 35
• Maximum Hose Length (m): 94.5

• Maximum Mix Ratio: 1:1

• Maximum Working Pressure (bar): 138
• Maximum Working Pressure (kPa): 13800
• Maximum Working Pressure (MPa): 13.8
• Maximum Working Pressure (psi): 2000

• Overall Depth (cm): 76.2
• Overall Depth (in): 30
• Overall Depth (mm): 762

• Overall Height (cm): 111.8
• Overall Height (in): 44
• Overall Height (mm): 1118
• Overall Width (cm): 67.3
• Overall Width (in): 26.5
• Overall Width (mm): 673

• Power Rating (HP): 5.10
• Power Rating (

GG 24R810

EXACTABLEND AGP SYSTEM, 100CC/100CC

Graco 24R810 55/5 gal (200/19 L) AGP-S100 Silicone Machine (Boom Not Included)

The Graco ExactaBlend AGP (Advanced Glazing Proportioner) provides on-ratio dispensing of two-component sealants and adhesives for curtainwall, insulating glass and other applications. The variable ratio ExactaBlend AGP offers advanced technologies at an affordable price.

Advanced pumping technology creates a better, more consistent bead – which results in reduced rework and less wasted material.

• Real-time ratio assurance means less waste, more profits

  Provides automatic shut-down if off-ratio conditions occur

  Cuts material waste and reduces rework for a healthier bottom line

• Optimal mix for quality assurance

  Ultimately reduces the chance of seal failure on insulating glass

  Results in better quality end product

• Easy to operate

  Quick and easy setup – operator simply enters the ratio setting

  Easy to switch ratio settings

• Optional data download provides reports on ratio, flow rate and material usage

  A & B material usage

  Flow rate

  Alarm events

  Ratio

• Model: Exactablend
• Series: AGP

• Catalyst Inlet Size (in): 1/4
• Catalyst Inlet Thread Gender: Female
• Catalyst Inlet Thread Type: NPT

• Maximum Working Pressure (bar): 207
• Maximum Working Pressure (kPa): 20700
• Maximum Working Pressure (MPa): 21
• Maximum Working Pressure (psi): 3000

• Minimum Flow Rate (kg/min): 1
• Minimum Flow Rate (lb/min): 2.21

GG 24X160

LSR F4-5 SYSTEM, 5GAL/5GAL

Graco 24X160 1:1 Ratio 5 gal (20 liter) F4 Fluid Automation System with Casters

In the manufacturing of liquid silicone rubber products, precision is paramount. Material waste is an expensive problem and substandard products are an intolerable failure. Minimize both with the Graco Fluid Automation F4-5.

• Precise ratio control, minimal material waste

  The F4-5 system takes the ability to meter material flow to an almost microscopic level. Its helical gear uses multiple gear teeth to measure flow in very small increments. The increased number of measurements offers more assurance the machine remains on-ratio.

  The result: More precise mixing, a better end product and less wasted material.

  • Easier operation with Graco Control Architecture

    The Graco Fluid Automation F4-5 system features intuitive user interfaces based on the Graco Control Architecture (GCA), a modular system of processing and control components. GCA makes maintenance and service easy, thanks to built-in troubleshooting tools

    • Better Color Control

      Mix two additive streams at ratios ranging from 0.5 to 6%

      • Maintains Material Integrity

        Stainless steel components meet the standard for clean room applications to prevent contamination, and cure inhibition and discoloration of material

        • Cleanroom Convenience

          A smaller footprint and casters (optional on F4-5) allow for system movement and maintenance




          • Model: LSR
          • Air Inlet Size (in): 1/2
          • Air Inlet Thread Gender: Female
          • Air Inlet Thread Type: NPT
          • Amperage (A): 4
          • Applicator Type: Automatic
          • Frequency (Hz): 50/60
          • Maximum Flow Rate (kg/min): 2.3
          • Maximum Flow Rate (lb/min): 5
          • Maximum Working Pressure (bar): 207
          • Maximum Working Pressure (kPa): 20700
          • Maximum Working Pressure (MPa): 21
          • Maximum Working Pressure (psi): 3000
          • Minimum Flow Rate (GPM): 10

GG 24X166

LSR F4-55-5 SYSTEM, LSR55-5GAL/55-5GAL, CSTERS

Graco 24X166 1:1 Ratio 5 gal (20 liter) F4 Fluid Automation System with Casters

In the manufacturing of liquid silicone rubber products, precision is paramount. Material waste is an expensive problem and substandard products are an intolerable failure. Minimize both with the Graco Fluid Automation F4-55.

• Precise ratio control, minimal material waste

  The F4-55 system takes the ability to meter material flow to an almost microscopic level. Its helical gear uses multiple gear teeth to measure flow in very small increments. The increased number of measurements offers more assurance the machine remains on-ratio.

  The result: More precise mixing, a better end product and less wasted material.

  • Easier operation with Graco Control Architecture

    The Graco Fluid Automation F4-55 system features intuitive user interfaces based on the Graco Control Architecture (GCA), a modular system of processing and control components. GCA makes maintenance and service easy, thanks to built-in troubleshooting tools

    • Better Color Control

      Mix two additive streams at ratios ranging from 0.5 to 6%

      • Maintains Material Integrity

        Stainless steel components meet the standard for clean room applications to prevent contamination, and cure inhibition and discoloration of material

        • Cleanroom Convenience

          A smaller footprint and casters (optional on F4-55) allow for system movement and maintenance




          • Model: LSR
          • Air Inlet Size (cm): 1.27
          • Air Inlet Size (in): 1/2
          • Air Inlet Size (mm): 12.7
          • Air Inlet Thread Gender: Female
          • Air Inlet Thread Type: NPT
          • Amperage (A): 4
          • Applicator Type: Automatic
          • Frequency (Hz): 50/60
          • Maximum Flow Rate (kg/min): 2.27
          • Maximum Flow Rate (lb/min): 5
          • Maximum Working Pressure (bar): 207
          • Maximum Working Pressure (kPa): 20700
          • Maximum Working Pressure (MPa): 21
          • Maximum Working Pressure (psi): 3000
          • Minimum Flow Rate (GPM): 10

GG 255446

MD2 VALVE, ASSY, 10:1, HS, GUN, ELEC

Graco 255446 10:1 Wide Ratio, Hard Seat, Electric Actuated, Non-adjustable Snuff-back, Manual Handle

Manual gun option for mixing dispense (MD) valve for 2 component materials supports minimizing maintenance while maximizing production.

• Wide ratio valve with center injection tip works well when the low volume material has a much lower viscosity than the high volume material. Frequent cleaning intervals may be required to maintain the tip.
• Carbide hard seats and hardened needles are good for abrasive material and stall against pressure applications.
• Hand held valve with electric switch signals the controller to open and close the ports on the MD2 valve. The process uses a remote four-way air control (not included, must be ordered separately).
• Snuff-back control prevents dripping as it brings material back into the valve until next dispense.
• Hand held electric handle eases manual dispense.

• Model: Two Component Mixing Dispense Valve
• Series: MD2

• Air Inlet Size (in): 1/8
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Bonding, Sealing, Gasketing, Potting, Encapsulation, Thermal Management, Molding

• Compatible Material: 2K Sealants, Adhesives

• Component Type: Plural-Component

• Fluid Inlet Size (in): 9/16-18
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: UNF

• Fluid Outlet Size (in): 7/8-9
• Fluid Outlet Thread Gender: Male
• Fluid Outlet Thread Type: UNC

• Gun Activation: Manual

• Includes: 2K Dispense Handle, 10:1 Hard Seat Dispense Valve, 10:1 Ratio Check Kit, 10:1 Night Cap, ASM Aid Tool
• Inlet Size (in): 9/16-18

• Maximum Viscosity (cP): 1000000

• Maximum Working Pressure (bar): 207
• Maximum Working Pressure (kPa): 20700
• Maximum Working Pressure (MPa): 20.7
• Maximum Working Pressure (psi): 3000

• Mount Hole Thread Gender: Female
• Mount Hole Thread Type: Metric

GG 255902

MD2 VALVE, DISPENSE, 10:1, ELITE, SNUFF

Graco 255902 MD2 Valve, 10:1 Ratio, Elite Hard Seat, Non-adjustable Snuff-back

Mixing dispense (MD) valve for 2 component materials minimizes maintenance while maximizing production.

• 10:1 ratio nose handles a wide range of material.
• Hard seats with Elite construction withstand highly abrasive material at least 10 times longer than standard construction. (Data verified in Graco test environment.)
• Snuff-back control prevents dripping as it brings material back into the valve until next dispense.
• Independent air cylinder improves mean time to repair (MTTR).
• No unique tools are required for maintenance or repair.
• No unique tools required

• Model: Two Component Mixing Dispense Valve
• Series: MD2

• Air Inlet Size (in): 1/8
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Application: Bonding, Sealing, Gasketing, Potting, Encapsulation, Thermal Management, Molding

• Compatible Material: Sealants, Adhesives

• Component Type: Plural-Component

• Fluid Inlet Size (cm): 1.42875
• Fluid Inlet Size (in): 9/16
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: UNF

• Fluid Outlet Size (in): 7/8
• Fluid Outlet Thread Type: UNC

• Gun Activation: Automatic

• Includes: Dispense Valve, 10:1 Ratio Night Cap, 10:1 Ratio Check Adapter, ASM Aid Tool

• Maximum Viscosity (cP): 1000000

• Maximum Working Pressure (bar): 207
• Maximum Working Pressure (kg/cm²): 210.9
• Maximum Working Pressure (kPa): 20700
• Maximum Working Pressure (psi): 3000

• Mount Hole Thread Gender: Female
• Mount Hole Thread Type: Metric

GG 25A476

EXACTABLEND AGP SYSTEM,100CC/100CC,BOOM

Graco 25A476 Silicone ExactaBlend AGP Base Proportioner with Boom-Less One Lower Wiper

The Graco ExactaBlend AGP (Advanced Glazing Proportioner) provides on-ratio dispensing of two-component sealants and adhesives for curtainwall, insulating glass and other applications. The variable ratio ExactaBlend AGP offers advanced technologies at an affordable price.

Application: Precise application of silicone materials in insulating glass or structural glazing applications is critical for delivering superior adhesion, durability and leak-free performance.Advanced pumping technology creates a better, more consistent bead – which results in reduced rework and less wasted material.

• Superior mixing and ratio assurance for the glass industry
• Optimal mixing and on-ratio proportioning capabilities for quality assurance
• Quick and easy base purge reduces material waste Optional data download provides reports on ratio, flow rate and material usage
• Angle adapter kit makes work easier and more comfortable
• Easy to operate

• Series: AGP

• Amperage (A): 4

• Compatible Material: Solventborne, High Solids, Xirallic, Metallics, Varnish, CARC

GG 25C720

INVISIPAC HM25C SYSTEM, 4CH, 480V

Graco 25C720 InvisiPac HM25c System, 4 Channel, 480 Voltage

This compact unit has a hot melt rate of 25 pounds (11.3 kilograms) per hour. Its melt-on-demand adhesive dispense technology easily integrates into middle to high volume packaging lines.

• Melter accommodates output dispense of 25 lb (11.3 kg) or less per hour.
• Four channel dispense accommodates four Plug-Free applicators and four heated hoses.
• Tank-Free melting chamber heats glue up to set temperature in about 10 minutes – the quickest start-up time for any end-of-line packaging operation.
• Patented self-learning feed algorithm automatically feeds adhesive pellets from the hopper into the melter without operator intervention. No direct contact with hot molten adhesive means no more safety hazards, such as burning, toxic fumes and slippage.
• Robust reporting capabilities deliver the data needed to improve productivity, decrease costs, and minimize downtime of case and carton sealing.
• High performance with lasting components
• Consistent adhesive viscosity
• No degraded material
• Little to no waste
• Better dispensing control
• Use any adhesive you choose

• Model: InvisiPac
• Series: HM25c

• Air Inlet Size (cm): 0.635
• Air Inlet Size (in): 1/4
• Air Inlet Size (mm): 6.35
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT

• Ambient/Warm Melt/Hot Melt: Hot Melt
• Amperage (A): 14
• Application: Bonding
• Applicator Type: Automatic

• Channels: 4

• Component Type: Single Component

• Footprint (in): 25.4 x 16.5 x 26.3

• Frequency (Hz): 50/60

• Gun Activation: Automatic

• Maximum Air Inlet Pressure (bar): 6.9
• Maximum Air Inlet Pressure (kPa): 690
• Maximum Air Inlet Pressure (psi): 100

• Maximum Flow Rate (kg/hr): 43.5
• Maximum Flow Rate (lb/hr): 96

• Maximum Fluid Temperature (°C): 204
• Maximum Fluid Temperature (°F): 400

• Maximum Fluid Temperature (°C): 204
• Maximum Fluid Temperature (°F): 400

• Maximum Hose Length (ft): 30
• Maximum Hose Length (m): 9.14

• Maximum Working Pressure (bar): 83
• Maximum Working Pressure (kPa): 8300
• Maximum Working Pressure (MPa): 8.3
• Maximum Working Pressure (psi): 1200
• Melt Rate (kg/hr): 11.3
• Melt Rate (lb/hr): 25

• Overall Depth (cm): 41.9
• Overall Depth (in): 16.5
• Overall Depth (mm): 419

• Overall Height (cm): 133.4
• Overall Height (in): 52.5
• Overall Height (mm): 1334
• Overall Width (cm): 64.5
• Overall Width (in): 25.4
• Overall Width (mm): 645

• Pattern Controller: No
• Phase: 3

• Power Source: Electric
• Power Type: Electric

• Pump: Pneumatic piston, 12:1

GG 25C863
