MD2 VALVE, DISPENSE, 10:1, ELITE, SNUFF

GG 255902

MD2 VALVE, DISPENSE, 10:1, ELITE, SNUFF

MD2 Valve, 10:1 Ratio, Elite Hard Seat, Non-adjustable Snuff-back Mixing dispense (MD) valve for 2 component materials minimizes maintenance while maximizing production. Static valve with Elite construction reliably dispenses highly abrasive thermal interface materials (TIMs), silicones, urethanes, and epoxies. 10:1 ratio nose handles a wide range of material. Hard seats with Elite construction withstand highly abrasive material at least 10 times longer than standard construction. (Data verified in Graco test environment.) Snuff-back control prevents dripping as it brings material back into the valve until next dispense. Non-adjustable snuff-back control keeps shut-off performance consistent for a clean bead dispense. Maximum flow rate is 25 to 30 cc/s, depending on material viscosity. Independent air cylinder improves mean time to repair (MTTR). No unique tools are required for maintenance or repair. No unique tools required
