SD SERIES SDP18 VALVE, FC, 1/2NPT, RIDG, OIL

Graco 26C356 SDP18 Series Electronic Preset Oil/Antifreeze Meter - Rigid Extension - 1/2 in. (13 mm) Inlet

Graco's premium SD meters were designed from the ground up to provide the best user experience. These robust meters feature high flow, improved ergonomics and a large high-contrast LCD screen to make viewing dispense amounts easy in all lighting conditions.

• Upgradeable - SD Preset meters are compatible with PULSE FC fluid control system
• Large, Intuitive Display - high-contrast display for low and bright light conditions
• Long valve life - cartridge spool valve specifically designed to reduce wear and reduce costly down time
• Reliable - time-tested Graco engineering
• Durable - Thick cast aluminum body allows this meter to endure harsh, heavy-duty applications
• Long battery life - uses 4 AA easy-to-replace batteries

• Model: SDP18

• Compatible Material: Oil, Antifreeze, ATF, Gear Oil

• Dispense Type: Preset

• Display Type: Electronic

• Extension Type: Rigid

• Fluid Inlet Thread Gender: Female

• Fluid Outlet Thread Gender: Female

• Includes: Nozzle, Rigid Extension
• Inlet Size (cm): 1.27
• Inlet Size (in): 1/2
• Inlet Size (mm): 12.7

• Inlet Thread Type: NPT

• Maximum Flow Rate (GPM): 18
• Maximum Flow Rate (L/min): 68

• Maximum Operating Temperature ( degree C): 70
• Maximum Operating Temperature ( degree F): 158

• Maximum Recorded Dispense: 9999

• Maximum Storage Temperature ( degree C): 70
• Maximum Storage Temperature ( degree F): 158

• Maximum Working Pressure (bar): 103.4
• Maximum Working Pressure (kPa): 10340
• Maximum Working Pressure (MPa): 10.3
• Maximum Working Pressure (psi): 1500
• Meter Accuracy (%): plus/minus 00.5
• Meter Technology: Oval Gear

• Metering Gun Weight (kg): 2.4
• Metering Gun Weight (lb): 5.3

• Minimum Flow Rate (GPM): 0.25
• Minimum Flow Rate (L/min): 0.9

• Minimum Operating Temperature ( degree C): -16
• Minimum Operating Temperature ( degree F): 4

• Nozzle Type: Manual

• Outlet Thread Type: Straight Thread O-Ring Boss

• Overall Height (cm): 14.6
• Overall Height (in): 5.75
• Overall Height (mm): 146
• Overall Length (cm): 33
• Overall Length (in): 13
• Overall Length (mm): 330
• Overall Width (cm): 9.5
• Overall Width (in): 3.75
• Overall Width (mm): 95

• Product Type: Meter

• Recommended Environment: Indoor

GG 26C357

SD SERIES SDP18 VALVE, FC, 1/2NPT, FLEX, OIL

Graco 26C357 SDP18 Series Electronic Preset Oil/Antifreeze Meter - Flexible Extension - 1/2 in. (13 mm) Inlet

Graco's premium SD meters were designed from the ground up to provide the best user experience. These robust meters feature high flow, improved ergonomics and a large high-contrast LCD screen to make viewing dispense amounts easy in all lighting conditions.

• Upgradeable - SD Preset meters are compatible with PULSE FC fluid control system
• Large, Intuitive Display - high-contrast display for low and bright light conditions
• Long valve life - cartridge spool valve specifically designed to reduce wear and reduce costly down time
• Reliable - time-tested Graco engineering
• Durable - Thick cast aluminum body allows this meter to endure harsh, heavy-duty applications
• Long battery life - uses 4 AA easy-to-replace batteries

• Model: SDP18

• Compatible Material: Oil, Antifreeze, ATF, Gear Oil

• Dispense Type: Preset

• Display Type: Electronic

• Extension Type: Flexible

• Fluid Inlet Thread Gender: Female

• Fluid Outlet Thread Gender: Female

• Includes: Nozzle, Flexible Extension
• Inlet Size (cm): 1.27
• Inlet Size (in): 1/2
• Inlet Size (mm): 12.7

• Inlet Thread Type: NPT

• Maximum Flow Rate (GPM): 18
• Maximum Flow Rate (L/min): 68

• Maximum Operating Temperature ( degree C): 70
• Maximum Operating Temperature ( degree F): 158

• Maximum Recorded Dispense: 9999

• Maximum Storage Temperature ( degree C): 70
• Maximum Storage Temperature ( degree F): 158

• Maximum Working Pressure (bar): 103.4
• Maximum Working Pressure (kPa): 10340
• Maximum Working Pressure (MPa): 10.3
• Maximum Working Pressure (psi): 1500
• Meter Accuracy (%): plus/minus 00.5
• Meter Technology: Oval Gear

• Metering Gun Weight (kg): 2.4
• Metering Gun Weight (lb): 5.3

• Minimum Flow Rate (GPM): 0.25
• Minimum Flow Rate (L/min): 0.9

• Minimum Operating Temperature ( degree C): -16
• Minimum Operating Temperature ( degree F): 4

• Nozzle Type: Manual

• Outlet Thread Type: Straight Thread O-Ring Boss

• Overall Height (cm): 14.6
• Overall Height (in): 5.75
• Overall Height (mm): 146
• Overall Length (cm): 33
• Overall Length (in): 13
• Overall Length (mm): 330
• Overall Width (cm): 9.5
• Overall Width (in): 3.75
• Overall Width (mm): 95

• Product Type: Meter

• Recommended Environment: Indoor

GG 26C416

GG 26C482

GG 26C711

GG 26C882

GG 26C918

GG 26D002

KIT, CS T4, PUMP/FLUID

Graco 26D002 T4 Package: Includes 2 Pumps (Carbon Steel) and 2 Supply Hoses

Transfer Pumps are required to move A and B materials to the Reactor Spray Systems. The T4 Transfer Pump combines Graco's proven Merkur air-motor and carbon steel lower. The T4 is a 3:1 ratio pump with ProConnect technology - allowing you to quickly connect and disconnect the air motor from the pump lower.

• Quick Transfer Between Drums - quickly change to a new drum of material without the mess of dripping chemical by using multiple pump lowers.
• Easier to Maneuver - easily transfer the T4 pump between drums by quickly disconnecting the air motor from the lower before transferring. This makes the pump lighter weight and reduces the necessary ceiling height of your rig.
• Eliminate Downtime - get up and running quickly when your pump lower requires maintenance by having a spare pump lower that can easily be installed.

• Model: T4

• Material: Carbon Steel

• Package Options: Supply Hose

GG 26D274

VALVE, DISPENCE, MDX

Graco 26D274 MDX, High flow valve, 2-component

The Graco MDX valve is designed for a two-component high flow dispensing application. The high wear resistance design enables an excellent life performance even with dispensing highly abrasive material such as Thermal Interface Material. It`s a perfect fit in EV battery pack, solar energy, wind power and etc. markets.

• High flow rate
• Easy intergration for automation
• High wear resistance for reduced maintainance
• Recirculation function keeps material from settling.

• Model: MD2
• Series: MDX

• Fluid Outlet Thread Gender: Male

• Maximum Operating Temperature ( degree C): 70
• Maximum Operating Temperature ( degree F): 158

• Overall Height (cm): 29.5
• Overall Height (in): 11.62
• Overall Height (mm): 295
• Overall Width (cm): 14.5
• Overall Width (in): 5.72
• Overall Width (mm): 145.30000000000001
