GG 269417

CONTRACTOR FLAT TIP, SPRAY

Graco 269417 Contractor Flat Tip, 417

The 417 Contractor Flat Tip produces an 8 to 10 inch fan and has a 0.017 inch orifice.

• Model: Contractor
• Series: Flat Tip

• Compatible Material: Architectural Coating

• For Use With: Silver Plus Airless Spray Gun

• Maximum Fan Width (cm): 20
• Maximum Fan Width (in): 8
• Maximum Fan Width (mm): 254

• Maximum Flow Rate (GPM): 0.31
• Maximum Flow Rate (L/min): 1.17

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (psi): 5000

• Minimum Fan Width (in): 8
• Minimum Fan Width (mm): 203

• Orifice Diameter (in): 0.017

• Pattern Size (in): 8 to 10
• Pattern Size (mm): 203.2 to 254

GG 269427

CONTRACTOR FLAT TIP, SPRAY

Graco 269427 Contractor Flat Tip, 427

The 427 Contractor Flat Tip produces an 8 to 10 inch fan and has a 0.027 inch orifice.

• Model: Contractor
• Series: Flat Tip

• Compatible Material: Architectural Coating

• For Use With: Silver Plus Airless Spray Gun

• Maximum Fan Width (cm): 20
• Maximum Fan Width (in): 8
• Maximum Fan Width (mm): 254

• Maximum Flow Rate (GPM): 0.74
• Maximum Flow Rate (L/min): 2.80

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (psi): 5000

• Minimum Fan Width (in): 8
• Minimum Fan Width (mm): 203

• Orifice Diameter (in): 0.027

• Pattern Size (in): 8 to 10
• Pattern Size (mm): 203.2 to 254

GG 269513

CONTRACTOR FLAT TIP, SPRAY

Graco 269513 Contractor Flat Tip, 513

The 513 Contractor Flat Tip produces a 10 to 12 inch fan and has a 0.013 inch orifice.

• Model: Contractor
• Series: Flat Tip

• Compatible Material: Architectural Coating

• For Use With: Silver Plus Airless Spray Gun

• Maximum Fan Width (cm): 25
• Maximum Fan Width (in): 10
• Maximum Fan Width (mm): 305

• Maximum Flow Rate (GPM): 0.18
• Maximum Flow Rate (L/min): 0.68

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (psi): 5000

• Minimum Fan Width (in): 10
• Minimum Fan Width (mm): 254

• Orifice Diameter (in): 0.013

• Pattern Size (in): 10 to 12
• Pattern Size (mm): 254 to 304.8

GG 269515

CONTRACTOR FLAT TIP, SPRAY

Graco 269515 Contractor Flat Tip, 515

The 515 Contractor Flat Tip produces a 10 to 12 inch fan and has a 0.015 inch orifice.

• Model: Contractor
• Series: Flat Tip

• Compatible Material: Architectural Coating

• For Use With: Silver Plus Airless Spray Gun

• Maximum Fan Width (cm): 25
• Maximum Fan Width (in): 10
• Maximum Fan Width (mm): 305

• Maximum Flow Rate (GPM): 0.24
• Maximum Flow Rate (L/min): 0.91

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (psi): 5000

• Minimum Fan Width (in): 10
• Minimum Fan Width (mm): 254

• Orifice Diameter (in): 0.015

• Pattern Size (in): 10 to 12
• Pattern Size (mm): 254 to 304.8

GG 269519

CONTRACTOR FLAT TIP, SPRAY

Graco 269519 Contractor Flat Tip, 519

The 519 Contractor Flat Tip produces a 10 to 12 inch fan and has a 0.019 inch orifice.

• Model: Contractor
• Series: Flat Tip

• Compatible Material: Architectural Coating

• For Use With: Silver Plus Airless Spray Gun

• Maximum Fan Width (cm): 25
• Maximum Fan Width (in): 10
• Maximum Fan Width (mm): 305

• Maximum Flow Rate (GPM): 0.38
• Maximum Flow Rate (L/min): 1.44

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (psi): 5000

• Minimum Fan Width (in): 10
• Minimum Fan Width (mm): 254

• Orifice Diameter (in): 0.019

• Pattern Size (in): 10 to 12
• Pattern Size (mm): 254 to 304.8

GG 269523

CONTRACTOR FLAT TIP, SPRAY

Graco 269523 Contractor Flat Tip, 523

The 523 Contractor Flat Tip produces a 10 to 12 inch fan and has a 0.023 inch orifice.

• Model: Contractor
• Series: Flat Tip

• Compatible Material: Architectural Coating

• For Use With: Silver Plus Airless Spray Gun

• Maximum Fan Width (cm): 25
• Maximum Fan Width (in): 10
• Maximum Fan Width (mm): 305

• Maximum Flow Rate (GPM): 0.57
• Maximum Flow Rate (L/min): 2.16

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (psi): 5000

• Minimum Fan Width (in): 10
• Minimum Fan Width (mm): 254

• Orifice Diameter (in): 0.023

• Pattern Size (in): 10 to 12
• Pattern Size (mm): 254 to 304.8

GG 269613

CONTRACTOR FLAT TIP, SPRAY 613

Graco 269613 Contractor Flat Tip, 613

The 613 Contractor Flat Tip produces a 12 to 14 inch fan and has a 0.013 inch orifice.

• Model: Contractor
• Series: Flat Tip

• Compatible Material: Architectural Coating

• For Use With: Silver Plus Airless Spray Gun

• Maximum Fan Width (cm): 30
• Maximum Fan Width (in): 12
• Maximum Fan Width (mm): 356

• Maximum Flow Rate (GPM): 0.18
• Maximum Flow Rate (L/min): 0.68

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (psi): 5000

• Minimum Fan Width (in): 12
• Minimum Fan Width (mm): 305

• Orifice Diameter (in): 0.013

• Pattern Size (in): 12 to 14
• Pattern Size (mm): 304.8 to 355.6

GG 269925

CONTRACTOR FLAT TIP, SPRAY

Graco 269925 Contractor Flat Tip, 925

The 925 Contractor Flat Tip produces an 18 to 20 inch (46 to 51 cm) fan and has a 0.025 inch orifice.

• Model: Contractor
• Series: Flat Tip

• Compatible Material: Architectural Coating

• For Use With: Silver Plus Airless Spray Gun

• Maximum Fan Width (cm): 45
• Maximum Fan Width (in): 18
• Maximum Fan Width (mm): 508

• Maximum Flow Rate (GPM): 0.67
• Maximum Flow Rate (L/min): 2.54

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (psi): 5000

• Minimum Fan Width (in): 18
• Minimum Fan Width (mm): 457

• Orifice Diameter (in): 0.025

• Pattern Size (in): 18 to 20
• Pattern Size (mm): 457.2 to 508

GG 26A068

GG 26A079

GG 26A096

GG 26A097

GG 26A099

GG 26A100

GG 26A101

GG 26A123

KIT,CONTROL,AIR,PD2K

GG 26A126

GG 26A131

PANEL, FLUID, GREASE/PAINT, G3000

Graco 26A131 ProDispense Fluid Panel Kit, Grease/ Paint Meter, wide viscosity, high accuracy

This fluid panel kit for the ProDispense Electronic Preset Dispense System is ideal for grease and paint applications.

• Model: ProDispense

• Air Inlet Size (in): 5/32
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: Push

• Fluid Inlet Size (in): 1/4
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT

• Fluid Outlet Size (in): 3/8
• Fluid Outlet Thread Gender: Male
• Fluid Outlet Thread Type: NPT

• For Use With: G3000 meter

• Maximum Air Pressure (bar): 7.03

• Maximum Air Pressure (kPa): 703
• Maximum Air Pressure (psi): 102

• Maximum Flow Rate (cc/min): 3800

• Maximum Flow Rate (GPM): 1
• Maximum Flow Rate (L/min): 3.8

• Maximum Working Pressure (bar): 207
• Maximum Working Pressure (psi): 3000

• Minimum Flow Rate (GPM): 0.02

GG 26A132

PANEL, FLUID, GREASE/PAINT, HELIC

Graco 26A132 ProDispense Fluid Panel Kit, Helical Meter, wide viscosity, high accuracy

This fluid panel kit for the ProDispense Electronic Preset Dispense System is ideal for high viscosity applications.

• HG6000 Helical Gear meter

• Model: ProDispense

• For Use With: HG6000 meter

GG 26A134

KIT, FCM, FLUIDCTRL, PRODISPENSE

Graco 26A134 ProDispense Fluid Control Module

Fluid Control Module (FCM) expands the base ProDispense system by 2 fluid panels.

• A mounting plate makes attachment to the fluid panel easy.
• Up to 3 modules can be used on each system.
• Additional FCM is required only if more than 2 fluid panels need to be controlled.

• Model: ProDispense

• For Use With: ProDispense Electronic Fluid Dispense and Meter System

• Includes: Mounting plate

GG 26A165

PANEL, FLUID, SOLVENT

Graco 26A165 ProDispense Fluid Panel Kit, Solvent Meter, light viscosity, high accuracy

This fluid panel kit for the ProDispense Electronic Preset Dispense System is ideal for solvent applications.

• Use S3000 meter with solvents and clear light viscosity materials.

• Model: ProDispense

• For Use With: S3000 meter

GG 26A225

KIT, MIX MANIFOLD, HP

Graco 26A225 ProMix PD2K High Pressure Mix at the Belt Manifold Kit

Mix Manifold Kits

• Model: ProMix
• Series: PD2K

• Maximum Working Pressure (bar): 105
• Maximum Working Pressure (kPa): 10500
• Maximum Working Pressure (MPa): 10.5
• Maximum Working Pressure (psi): 1500
