Parts

GG 26A358

KIT, MIX MANIFOLD, LP

Graco 26A358 ProMix PD2K Low Pressure Mix at the Belt Manifold Kit

Mix Manifold Kits

• Model: ProMix
• Series: PD2K

GG 26A476

GG 26A502

GG 26A704

KIT,INLET REGULATOR,EFR,SS

KIT INCLUDES: REGULATOR, STAINLESS STEEL [QTY. 1], FITTING, ADAPTER, STRAIGHT SWIVEL [QTY. 1], NIPPLE, SST. [QTY. 1]

GG 26A777

GG 26A778

GG 26A781

GG 26A814

GLC CONTROL, X

Graco 26A814 GLC X Controller

The powerful, new, easy-to-use Graco GLC X auto lubrication controller captures more information more ways, so operators, technicians and managers can make faster, smarter decisions that drive more productivity.

• Indoor/Outdoor Mountable (IP69K) - Designed to withstand all the elements, including high-pressure washes and inclement weather encountered at the harshest and dirtiest sites.
• Easy-to-Read LED Screen - Soft amber LED lighting capable of displaying text codes, faults and other data clearly in any ambient light without distracting operators.
• Real-Time System Reporting - Program and display a wide range of customizable functions - including lubrication intervals, pressure limits, lubricant levels and more.
• Universal Compatibility - One controller for all your lubrication systems simplifies training and inventory.
• Active Current Protection - 9-30 VDC, 10 Amp continuous power supply protects grease pumps from over current and entire system from misfires, electrical shorts and surges.

• Model: GLC
• Series: X

• Amperage (A): 15
• Application: In-Plant Machinery, Off-Road Equipment, On-Road Vehicles

• Auxiliary Alarm Max Switching Current (A): 10
• Auxiliary Alarm Max Switching Voltage (VDC): 9-30
• Auxiliary Alarm Voltage: 9-30 VDC

• Control Mode: Timer, Pressure, Cycle

• Count Rate (counts/sec @ 50% duty cycle): 5
• Current Consumption (A): 15

• Intrusion Rating: IP69K

• Low Level Alarm Max Switching Current (A): 10
• Low Level Alarm Max Switching Voltage (VDC): 30

• Lubrication Level Input: Input 1: 10V
• Machine Count Control Input: Input 4

• Maximum Operating Temperature ( degree C): 70
• Maximum Operating Temperature ( degree F): 158

• Maximum Program Time (min): 99
• Maximum Program Time (sec): 5999

• Maximum Storage Temperature ( degree C): 70
• Maximum Storage Temperature ( degree F): 158
• Maximum System Cycle Count: 100

• Maximum Voltage (V dc): 30
• Maximum Voltage (V): 30

• Minimum Ambient Temperature ( degree F): -22

• Minimum Monitor Time (hrs): 0
• Minimum Monitor Time (min): 1
• Minimum Monitor Time (sec): 0

• Minimum Monitor Time (strokes): 1
• Minimum Operating Temperature ( degree C): -30
• Minimum Operating Temperature ( degree F): -22

• Minimum Program Time (hrs): 0
• Minimum Program Time (min): 0
• Minimum Program Time (sec): 10
• Minimum Program Time (strokes): 1
• Minimum Storage Temperature ( degree C): -30
• Minimum Storage Temperature ( degree F): -22

• Minimum System Cycle Count: 1
• Minimum Voltage (V dc): 9
• Minimum Voltage (V): 9

• Number of Pieces: 1

• Overall Depth (cm): 5
• Overall Depth (in): 1.98

• Overall Height (cm): 16.9
• Overall Height (in): 6.66
• Overall Height (mm): 169
• Overall Width (cm): 9.2
• Overall Width (in): 3.62
• Overall Width (mm): 92

• Power Consumption (W): 450

• Power Source: Electric

• Pump Control Max Switching Current (A): 10
• Pump Control Max Switching Voltage (VDC): 30
• Pump Control Voltage (VDC): 9-30

GG 26A853

BOX, TEST, GLCX

Graco 26A853 GLC X Pump Simulator

Pump simulator for the GLC X controller. This tool simply plugs into a wall outlet to quickly program the controller and simulate pump inputs. Great for pre-programming the controller or training.

• Application: In-Plant Machinery, Off-Road Equipment, On-Road Vehicles

GG 26A855

GLC CONTROL, X WITH CABLE

Graco 26A855 GLC X Controller w/14-Pin Connector, 2-Wire, 10 ft Power In and 12-Wire Color Coded 20 ft Cable, Flying Leads

The powerful, new, easy-to-use Graco GLC X auto lubrication controller captures more information more ways, so operators, technicians and managers can make faster, smarter decisions that drive more productivity.

• Indoor/Outdoor Mountable (IP69K) - Designed to withstand all the elements, including high-pressure washes and inclement weather encountered at the harshest and dirtiest sites.
• Easy-to-Read LED Screen - Soft amber LED lighting capable of displaying text codes, faults and other data clearly in any ambient light without distracting operators.
• Real-Time System Reporting - Program and display a wide range of customizable functions - including lubrication intervals, pressure limits, lubricant levels and more.
• Universal Compatibility - One controller for all your lubrication systems simplifies training and inventory.
• Active Current Protection - 9-30 VDC, 10 Amp continuous power supply protects grease pumps from over current and entire system from misfires, electrical shorts and surges.

• Model: GLC
• Series: X

• Application: In-Plant Machinery, Off-Road Equipment, On-Road Vehicles

• For Use With: Automatic Lubrication Pumps

GG 26A858

GG 26A882

HARNESS, GLC X, KIT

Graco 26A882 14-Pin Connector, 2-Wire, 10 ft Power In and 12-Wire Color Coded 20 ft Cable, Flying Leads

14-pin connector, 2-wire, 10 foot power in and 12-wire color coded 20 foot cable with flying leads

• Application: In-Plant Machinery, Off-Road Equipment, On-Road Vehicles

• For Use With: GLC X Controller

• Power Connection Type: 9-30 VDC, flying leads to 14 position AMPSEAL connector plug

GG 26B021

GG 26B022

GG 26B023

GG 26B024

GG 26B108

GG 26B190

GG 26B191

GG 26B192

GG 26B195

GG 26B236

GG 26B343

GG 26B539

GG 26B690

KIT, O-RING-D2 PT-4

Graco 26B690 1-inch PTFE Seal Kit for FG Pump Models
