Parts

GG 26D767

GG 273136

GG 273158

PM SERIES VALVE, PM8, NPT, GEAR LUBE

Graco 273158 PM 8 Electronic Preset Gear Lube Meter - Rigid Extension - 1/2 in. (13 mm) Inlet - NPT

Use Graco's PM8 and PM20 electronic preset meters to dispense fluids quickly, reliably and accurately to vehicles, trucks, yellow iron machines and more in the most challenging, extreme environments.

• Proven in Harsh Conditions - Sealed electronics (IP69K) are protected against direct pressure washing and dust.
• Twist-Close Nozzle Prevents Leaking - Multiple extensions available including rigid, flexible and gear lube.
• Long-Life Valve Design - Poppet design offers exceptional valve life for heavy usage applications.
• Durable Cast Body - Designed for heavy duty and harsh applications.
• High-Flow Rates - Capable of up to 8 gpm (30.3 lpm).
• Long Battery Life - Features four easily-replaceable AA batteries.

• Series: 8

• Calibration Type: Factory Calibrated

• Compatible Material: Petroleum-Based Oil, Synthetic-Based Oil, Antifreeze

• Dispense Type: Preset

• Display Type: Electronic

• Extension Type: Rigid

• Fluid Inlet Thread Gender: Female

• Fluid Outlet Thread Gender: Female

• Includes: Nozzle, Extension
• Inlet Size (cm): 1.27
• Inlet Size (in): 1/2
• Inlet Size (mm): 12.7

• Inlet Thread Type: NPT

• IP Rating: 69K

• Maximum Flow Rate (cc/min): 30283

• Maximum Flow Rate (cc/sec): 505
• Maximum Flow Rate (GPM): 8
• Maximum Flow Rate (L/min): 30.3

• Maximum Operating Temperature ( degree C): 52
• Maximum Operating Temperature ( degree F): 125

• Maximum Recorded Dispense: 19999

• Maximum Storage Temperature ( degree C): 85
• Maximum Storage Temperature ( degree F): 185

• Maximum Totalizer: 19999

• Maximum Working Pressure (bar): 102
• Maximum Working Pressure (kPa): 10340
• Maximum Working Pressure (MPa): 10
• Maximum Working Pressure (psi): 1500
• Meter Accuracy: plus/minus 00.5
• Meter Accuracy (%): plus/minus 00.5
• Meter Pressure Loss (bar): 4.1 Bar at 6 GPM
• Meter Pressure Loss (psi): 60 PSI at 6 GPM
• Meter Technology: Oval Gear

• Metering Gun Weight (kg): 2.4
• Metering Gun Weight (lb): 5.2

• Minimum Flow Rate (GPM): 0.25

• Minimum Operating Temperature ( degree C): -29
• Minimum Operating Temperature ( degree F): -20

• Nozzle Type: Manual

• Outlet Size (cm): 1.905
• Outlet Size (in): 3/4
• Outlet Size (mm): 19.05
• Outlet Thread Type: ORB

• Overall Height (cm): 18.3
• Overall Height (in): 7.2
• Overall Height (mm): 183
• Overall Length (cm): 57.5
• Overall Length (in): 22.6
• Overall Length (mm): 575
• Overall Width (cm): 10.4
• Overall Width (in): 4.1
• Overall Width (mm): 103.5

• Recommended Environment: Indoor/Outdoor

GG 273165

PM SERIES VALVE, PM20, 1/2in NPT, RIGID

Graco 273165 PM 20 Electronic Preset Oil Meter - Rigid Extension - 1/2 in. (13 mm) Inlet - NPT

Use Graco's PM8 and PM20 electronic preset meters to dispense fluids quickly, reliably and accurately to vehicles, trucks, yellow iron machines and more in the most challenging, extreme environments.

• Proven in Harsh Conditions - Sealed electronics (IP69K) are protected against direct pressure washing and dust.
• Twist-Close Nozzle Prevents Leaking - Multiple extensions available including rigid, flexible and gear lube.
• Long-Life Valve Design - Poppet design offers exceptional valve life for heavy usage applications.
• Durable Cast Body - Designed for heavy duty and harsh applications.
• High-Flow Rates - Capable of up to 20 gpm (75.7 lpm).
• Long Battery Life - Features four easily-replaceable AA batteries.

• Series: 20

• Calibration Type: Factory Calibrated

• Compatible Material: Petroleum-Based Oil, Synthetic-Based Oil, Antifreeze

• Dispense Type: Preset

• Display Type: Electronic

• Extension Type: Rigid

• Fluid Inlet Thread Gender: Female

• Fluid Outlet Thread Gender: Female

• Includes: Nozzle, Extension
• Inlet Size (cm): 1.27
• Inlet Size (in): 1/2
• Inlet Size (mm): 12.7

• Inlet Thread Type: NPT

• IP Rating: 69K

• Maximum Flow Rate (cc/min): 75708

• Maximum Flow Rate (cc/sec): 1262
• Maximum Flow Rate (GPM): 20
• Maximum Flow Rate (L/min): 75.7

• Maximum Operating Temperature ( degree C): 52
• Maximum Operating Temperature ( degree F): 125

• Maximum Recorded Dispense: 19999

• Maximum Storage Temperature ( degree C): 85
• Maximum Storage Temperature ( degree F): 185

• Maximum Totalizer: 19999

• Maximum Working Pressure (bar): 102
• Maximum Working Pressure (kPa): 10340
• Maximum Working Pressure (MPa): 10
• Maximum Working Pressure (psi): 1500
• Meter Accuracy: plus/minus 00.5
• Meter Accuracy (%): plus/minus 00.5
• Meter Pressure Loss (bar): 10.3 Bar at 12 GPM
• Meter Pressure Loss (psi): 150 PSI at 12 GPM
• Meter Technology: Oval Gear

• Metering Gun Weight (kg): 2.4
• Metering Gun Weight (lb): 5.2

• Minimum Flow Rate (GPM): 0.25

• Minimum Operating Temperature ( degree C): -29
• Minimum Operating Temperature ( degree F): -20

• Nozzle Type: Manual

• Outlet Size (cm): 1.905
• Outlet Size (in): 3/4
• Outlet Size (mm): 19.05
• Outlet Thread Type: ORB

• Overall Height (cm): 18.3
• Overall Height (in): 7.2
• Overall Height (mm): 183
• Overall Length (cm): 54.4
• Overall Length (in): 21.4
• Overall Length (mm): 544
• Overall Width (cm): 10.4
• Overall Width (in): 4.1
• Overall Width (mm): 103.5

• Recommended Environment: Indoor/Outdoor

GG 276067

GG 276734

GG 276974

GG 277064

GG 277674

GG 277755

GG 277869

CONTROL BOX, PROMIX 2KS EASYKEY REPL.

GG 280538

GG 280569

GG 285967

GG 286111

RAC 5 TIP, SPRAY

Graco 286111 RAC 5 SwitchTip, 111

The Reverse-A-Clean (RAC) 111 RAC 5 SwitchTip is designed for narrower surfaces and thin materials. The 111 SwitchTip has a 0.011 inch orifice and produces a 2 to 4 inch fan. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Lacquer to Mastic, Latex Paint

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 10.2
• Maximum Fan Width (in): 2
• Maximum Fan Width (mm): 102

• Maximum Flow Rate (GPM): 0.12
• Maximum Flow Rate (L/min): 0.45

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 2
• Minimum Fan Width (mm): 51

• Orifice Diameter (in): 0.011

• Pattern Size (in): 2 to 4
• Pattern Size (mm): 50.8 to 101.6

GG 286121

RAC 5 TIP, SPRAY

Graco 286121 RAC 5 SwitchTip, 121

The Reverse-A-Clean (RAC) 121 RAC 5 SwitchTip is designed for narrower surfaces. The 121 SwitchTip has a 0.021 inch orifice and produces a 2 to 4 inch fan. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Lacquer to Mastic, Latex Paint

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 10.2
• Maximum Fan Width (in): 2
• Maximum Fan Width (mm): 102

• Maximum Flow Rate (GPM): 0.47
• Maximum Flow Rate (L/min): 1.78

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 2
• Minimum Fan Width (mm): 51

• Orifice Diameter (in): 0.021

• Pattern Size (in): 2 to 4
• Pattern Size (mm): 50.8 to 101.6

GG 286207

RAC 5 TIP, SPRAY

Graco 286207 RAC 5 SwitchTip, 207

The Reverse-A-Clean (RAC) 207 RAC 5 SwitchTip is designed for narrower surfaces and thinner materials. The 207 SwitchTip has a 0.007 inch orifice and produces a 4 to 6 inch fan. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents




  • Model: RAC 5
  • Series: SwitchTip
  • Compatible Material: Clear Coating, Lacquer, Oil-Based Stain
  • For Use With: RAC 5 HandTite Tip Guard
  • Maximum Fan Width (cm): 15.2
  • Maximum Fan Width (in): 4
  • Maximum Fan Width (mm): 152
  • Maximum Flow Rate (GPM): 0.05
  • Maximum Flow Rate (L/min): 0.19
  • Maximum Working Pressure (bar): 280
  • Maximum Working Pressure (kPa): 28000
  • Maximum Working Pressure (psi): 4050
  • Minimum Fan Width (in): 4
  • Minimum Fan Width (mm): 102
  • Orifice Diameter (in): 0.007

GG 286213

RAC 5 TIP, SPRAY

Graco 286213 RAC 5 SwitchTip, 213

The Reverse-A-Clean (RAC) 213 RAC 5 SwitchTip is designed for narrower surfaces. The 213 SwitchTip has a 0.013 inch orifice and produces a 4 to 6 inch fan. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents




  • Model: RAC 5
  • Series: SwitchTip
  • Compatible Material: Latex Paint, Latex Stain, Oil-Based Paint, Oil-Based Stain
  • For Use With: RAC 5 HandTite Tip Guard
  • Maximum Fan Width (cm): 15.2
  • Maximum Fan Width (in): 4
  • Maximum Fan Width (mm): 152
  • Maximum Flow Rate (GPM): 0.18
  • Maximum Flow Rate (L/min): 0.68
  • Maximum Working Pressure (bar): 280
  • Maximum Working Pressure (kPa): 28000
  • Maximum Working Pressure (psi): 4050
  • Minimum Fan Width (in): 4
  • Minimum Fan Width (mm): 102
  • Orifice Diameter (in): 0.013

GG 286215

RAC 5 TIP, SPRAY

Graco 286215 RAC 5 SwitchTip, 215

The Reverse-A-Clean (RAC) 215 RAC 5 SwitchTip is designed for narrower surfaces. The 215 SwitchTip has a 0.015 inch orifice and produces a 4 to 6 inch fan. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents




  • Model: RAC 5
  • Series: SwitchTip
  • Compatible Material: Latex Paint, Latex Stain, Oil-Based Paint, Oil-Based Stain
  • For Use With: RAC 5 HandTite Tip Guard
  • Maximum Fan Width (cm): 15.2
  • Maximum Fan Width (in): 4
  • Maximum Fan Width (mm): 152
  • Maximum Flow Rate (GPM): 0.24
  • Maximum Flow Rate (L/min): 0.91
  • Maximum Working Pressure (bar): 280
  • Maximum Working Pressure (kPa): 28000
  • Maximum Working Pressure (psi): 4050
  • Minimum Fan Width (in): 4
  • Minimum Fan Width (mm): 102
  • Orifice Diameter (in): 0.015

GG 286219

RAC 5 TIP, SPRAY

Graco 286219 RAC 5 SwitchTip, 219

The Reverse-A-Clean (RAC) 219 RAC 5 SwitchTip is designed for narrower surfaces and thick materials. The 219 SwitchTip has a 0.019 inch orifice and produces a 4 to 6 inch fan. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Lacquer to Mastic, Latex Paint

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 15.2
• Maximum Fan Width (in): 4
• Maximum Fan Width (mm): 152

• Maximum Flow Rate (GPM): 0.38
• Maximum Flow Rate (L/min): 1.44

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 4
• Minimum Fan Width (mm): 102

• Orifice Diameter (in): 0.019

• Pattern Size (in): 4 to 6
• Pattern Size (mm): 101.6 to 152.4

GG 286221

RAC 5 TIP, SPRAY

Graco 286221 RAC 5 SwitchTip, 221

The Reverse-A-Clean (RAC) 221 RAC 5 SwitchTip is designed for narrower surfaces and thick materials. The 221 SwitchTip has a 0.021 inch orifice and produces a 4 to 6 inch fan. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Lacquer to Mastic, Latex Paint

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 15.2
• Maximum Fan Width (in): 4
• Maximum Fan Width (mm): 152

• Maximum Flow Rate (GPM): 0.47
• Maximum Flow Rate (L/min): 1.78

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 4
• Minimum Fan Width (mm): 102

• Orifice Diameter (in): 0.021

• Pattern Size (in): 4 to 6
• Pattern Size (mm): 101.6 to 152.4

GG 286223

RAC 5 TIP, SPRAY

Graco 286223 RAC 5 SwitchTip, 223

The Reverse-A-Clean (RAC) 223 RAC 5 SwitchTip is designed for narrower surfaces and thick materials. The 323 SwitchTip has a 0.023 inch orifice and produces a 4 to 6 inch fan. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Lacquer to Mastic, Latex Paint

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 15.2
• Maximum Fan Width (in): 4
• Maximum Fan Width (mm): 152

• Maximum Flow Rate (GPM): 0.57
• Maximum Flow Rate (L/min): 2.16

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 4
• Minimum Fan Width (mm): 102

• Orifice Diameter (in): 0.023

• Pattern Size (in): 4 to 6
• Pattern Size (mm): 101.6 to 152.4

GG 286235

RAC 5 TIP, SPRAY

Graco 286235 RAC 5 SwitchTip, 235

The Reverse-A-Clean (RAC) 235 RAC 5 SwitchTip is designed for narrower surfaces and thicker materials. The 235 SwitchTip has a 0.035 inch orifice and produces a 4 to 6 inch fan. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Lacquer to Mastic, Latex Paint

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 15.2
• Maximum Fan Width (in): 4
• Maximum Fan Width (mm): 152

• Maximum Flow Rate (GPM): 1.31
• Maximum Flow Rate (L/min): 4.96

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 4
• Minimum Fan Width (mm): 102

• Orifice Diameter (in): 0.035

• Pattern Size (in): 4 to 6
• Pattern Size (mm): 101.6 to 152.4

GG 286409

RAC 5 TIP, SPRAY

Graco 286409 RAC 5 SwitchTip, 409

The Reverse-A-Clean (RAC) 409 RAC 5 SwitchTip produces an 8 to 10 inch fan and has a 0.009 inch orifice. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Lacquer to Mastic, Latex Paint

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 25.4
• Maximum Fan Width (in): 8
• Maximum Fan Width (mm): 254

• Maximum Flow Rate (GPM): 0.09
• Maximum Flow Rate (L/min): 0.34

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 8
• Minimum Fan Width (mm): 203

• Orifice Diameter (in): 0.009

• Pattern Size (in): 8 to 10
• Pattern Size (mm): 203.2 to 254

GG 286435

RAC 5 TIP, SPRAY

Graco 286435 RAC 5 SwitchTip, 435

The Reverse-A-Clean (RAC) 435 RAC 5 SwitchTip produces an 8 to 10 inch fan and has a 0.035 inch orifice. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Lacquer to Mastic, Latex Paint

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 25.4
• Maximum Fan Width (in): 8
• Maximum Fan Width (mm): 254

• Maximum Flow Rate (GPM): 1.31
• Maximum Flow Rate (L/min): 4.96

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 8
• Minimum Fan Width (mm): 203

• Orifice Diameter (in): 0.035

• Pattern Size (in): 8 to 10
• Pattern Size (mm): 203.2 to 254
