Parts

GG 286451

RAC 5 TIP, SPRAY

Graco 286451 RAC 5 SwitchTip, 451

The Reverse-A-Clean (RAC) 451 RAC 5 SwitchTip produces an 8 to 10 inch fan and has a 0.051 inch orifice. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Lacquer to Mastic, Latex Paint

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 25.4
• Maximum Fan Width (in): 8
• Maximum Fan Width (mm): 254

• Maximum Flow Rate (GPM): 2.79
• Maximum Flow Rate (L/day): 10.57
• Maximum Flow Rate (L/min): 10.56

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 8
• Minimum Fan Width (mm): 203

• Orifice Diameter (in): 0.051

• Pattern Size (in): 8 to 10
• Pattern Size (mm): 203.2 to 254

GG 286525

RAC 5 TIP, SPRAY

Graco 286525 RAC 5 SwitchTip, 525

The Reverse-A-Clean (RAC) 525 RAC 5 SwitchTip produces a 10 to 12 inch fan and has a 0.025 inch orifice. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents




  • Model: RAC 5
  • Series: SwitchTip
  • Compatible Material: Latex Paint, Latex Stain, Oil-Based Paint, Oil-Based Stain
  • For Use With: RAC 5 HandTite Tip Guard
  • Maximum Fan Width (cm): 30.5
  • Maximum Fan Width (in): 10
  • Maximum Fan Width (mm): 305
  • Maximum Flow Rate (GPM): 0.67
  • Maximum Flow Rate (L/min): 2.54
  • Maximum Working Pressure (bar): 280
  • Maximum Working Pressure (kPa): 28000
  • Maximum Working Pressure (psi): 4050
  • Minimum Fan Width (in): 10
  • Minimum Fan Width (mm): 254
  • Orifice Diameter (in): 0.025

GG 286527

RAC 5 TIP, SPRAY

Graco 286527 RAC 5 SwitchTip, 527

The Reverse-A-Clean (RAC) 527 RAC 5 SwitchTip produces a 10 to 12 inch fan and has a 0.027 inch orifice. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Lacquer to Mastic, Latex Paint

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 30.5
• Maximum Fan Width (in): 10
• Maximum Fan Width (mm): 305

• Maximum Flow Rate (GPM): 0.77
• Maximum Flow Rate (L/min): 2.91

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 10
• Minimum Fan Width (mm): 254

• Orifice Diameter (in): 0.027

• Pattern Size (in): 10 to 12
• Pattern Size (mm): 254 to 304.8

GG 286609

RAC 5 TIP, SPRAY

Graco 286609 RAC 5 SwitchTip, 609

The Reverse-A-Clean (RAC) 609 RAC 5 SwitchTip produces a 12 to 14 inch fan and has a 0.009 inch orifice. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Lacquer to Mastic, Latex Paint

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 35.6
• Maximum Fan Width (in): 12
• Maximum Fan Width (mm): 356

• Maximum Flow Rate (GPM): 0.09
• Maximum Flow Rate (L/min): 0.34

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 12
• Minimum Fan Width (mm): 305

• Orifice Diameter (in): 0.009

• Pattern Size (in): 12 to 14
• Pattern Size (mm): 304.8 to 355.6

GG 286611

RAC 5 TIP, SPRAY

Graco 286611 RAC 5 SwitchTip, 611

The Reverse-A-Clean (RAC) 611 RAC 5 SwitchTip produces a 12 to 14 inch fan and has a 0.011 inch orifice. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Lacquer to Mastic, Latex Paint

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 35.6
• Maximum Fan Width (in): 12
• Maximum Fan Width (mm): 356

• Maximum Flow Rate (GPM): 0.12
• Maximum Flow Rate (L/min): 0.45

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 12
• Minimum Fan Width (mm): 305

• Orifice Diameter (in): 0.011

• Pattern Size (in): 12 to 14
• Pattern Size (mm): 304.8 to 355.6

GG 286615

RAC 5 TIP, SPRAY

Graco 286615 RAC 5 SwitchTip, 615

The Reverse-A-Clean (RAC) 615 RAC 5 SwitchTip produces a 12 to 14 inch fan and has a 0.015 inch orifice. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Latex Paint, Latex Stain, Oil-Based Paint, Oil-Based Stain

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 35.6
• Maximum Fan Width (in): 12
• Maximum Fan Width (mm): 356

• Maximum Flow Rate (GPM): 0.24
• Maximum Flow Rate (L/min): 0.91

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 12
• Minimum Fan Width (mm): 305

• Orifice Diameter (in): 0.015

GG 286617

RAC 5 TIP, SPRAY

Graco 286617 RAC 5 SwitchTip, 617

The Reverse-A-Clean (RAC) 617 RAC 5 SwitchTip produces a 12 to 14 inch fan and has a 0.017 inch orifice. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Latex Paint, Latex Stain, Oil-Based Paint, Oil-Based Stain

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 35.6
• Maximum Fan Width (in): 12
• Maximum Fan Width (mm): 356

• Maximum Flow Rate (GPM): 0.31
• Maximum Flow Rate (L/min): 1.17

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 12
• Minimum Fan Width (mm): 305

• Orifice Diameter (in): 0.017

GG 286619

RAC 5 TIP, SPRAY

Graco 286619 RAC 5 SwitchTip, 619

The Reverse-A-Clean (RAC) 619 RAC 5 SwitchTip produces a 12 to 14 inch fan and has a 0.019 inch orifice. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Latex Paint, Latex Stain, Oil-Based Paint, Oil-Based Stain

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 35.6
• Maximum Fan Width (in): 12
• Maximum Fan Width (mm): 356

• Maximum Flow Rate (GPM): 0.38
• Maximum Flow Rate (L/min): 1.44

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 12
• Minimum Fan Width (mm): 305

• Orifice Diameter (in): 0.019

GG 286621

RAC 5 TIP, SPRAY

Graco 286621 RAC 5 SwitchTip, 621

The Reverse-A-Clean (RAC) 621 RAC 5 SwitchTip produces a 12 to 14 inch fan and has a 0.021 inch orifice. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Latex Paint, Latex Stain, Oil-Based Paint, Oil-Based Stain

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 35.6
• Maximum Fan Width (in): 12
• Maximum Fan Width (mm): 356

• Maximum Flow Rate (GPM): 0.47
• Maximum Flow Rate (L/min): 1.78

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 12
• Minimum Fan Width (mm): 305

• Orifice Diameter (in): 0.021

GG 286721

RAC 5 TIP, SPRAY

Graco 286721 RAC 5 SwitchTip, 721

The Reverse-A-Clean (RAC) 721 RAC 5 SwitchTip produces a 14 to 16 inch fan and has a 0.021 inch orifice. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Lacquer to Mastic, Latex Paint

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 40.6
• Maximum Fan Width (in): 14
• Maximum Fan Width (mm): 406

• Maximum Flow Rate (GPM): 0.47
• Maximum Flow Rate (L/min): 1.78

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 14
• Minimum Fan Width (mm): 356

• Orifice Diameter (in): 0.021

• Pattern Size (in): 14 to 16
• Pattern Size (mm): 355.6 to 406.4

GG 286723

RAC 5 TIP, SPRAY

Graco 286723 RAC 5 SwitchTip, 723

The Reverse-A-Clean (RAC) 723 RAC 5 SwitchTip produces a 14 to 16 inch fan and has a 0.023 inch orifice. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Lacquer to Mastic, Latex Paint

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 40.6
• Maximum Fan Width (in): 14
• Maximum Fan Width (mm): 406

• Maximum Flow Rate (GPM): 0.57
• Maximum Flow Rate (L/min): 2.16

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 14
• Minimum Fan Width (mm): 356

• Orifice Diameter (in): 0.023

• Pattern Size (in): 14 to 16
• Pattern Size (mm): 355.6 to 406.4

GG 286815

RAC 5 TIP, SPRAY

Graco 286815 RAC 5 SwitchTip, 815

The Reverse-A-Clean (RAC) 815 RAC 5 SwitchTip produces a 16 to 18 inch fan and has a 0.015 inch orifice. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Lacquer to Mastic, Latex Paint

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 45.7
• Maximum Fan Width (in): 16
• Maximum Fan Width (mm): 457

• Maximum Flow Rate (GPM): 0.24
• Maximum Flow Rate (L/min): 0.91

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 16
• Minimum Fan Width (mm): 406

• Orifice Diameter (in): 0.015

• Pattern Size (in): 16 to 18
• Pattern Size (mm): 406.4 to 457.2

GG 286819

RAC 5 TIP, SPRAY

Graco 286819 RAC 5 SwitchTip, 819

The Reverse-A-Clean (RAC) 819 RAC 5 SwitchTip produces a 16 to 18 inch fan and has a 0.019 inch orifice. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Lacquer to Mastic, Latex Paint

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 45.7
• Maximum Fan Width (in): 16
• Maximum Fan Width (mm): 457

• Maximum Flow Rate (GPM): 0.38
• Maximum Flow Rate (L/min): 1.44

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 16
• Minimum Fan Width (mm): 406

• Orifice Diameter (in): 0.019

• Pattern Size (in): 16 to 18
• Pattern Size (mm): 406.4 to 457.2

GG 286821

RAC 5 TIP, SPRAY

Graco 286821 RAC 5 SwitchTip, 821

The Reverse-A-Clean (RAC) 821 RAC 5 SwitchTip produces a 16 to 18 inch fan and has a 0.021 inch orifice. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Lacquer to Mastic, Latex Paint

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 45.7
• Maximum Fan Width (in): 16
• Maximum Fan Width (mm): 457

• Maximum Flow Rate (GPM): 0.47
• Maximum Flow Rate (L/min): 1.78

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 16
• Minimum Fan Width (mm): 406

• Orifice Diameter (in): 0.021

• Pattern Size (in): 16 to 18
• Pattern Size (mm): 406.4 to 457.2

GG 286935

RAC 5 TIP, SPRAY

Graco 286935 RAC 5 SwitchTip, 935

The Reverse-A-Clean (RAC) 935 RAC 5 SwitchTip produces an 18 to 20 inch (46 to 51 cm) fan and has a 0.035 inch orifice. Reverse the SwitchTip to easily clear clogs.

• Most Widely Used Reversible Spray Tip on the Market (Black Handle)

  Used for residential and commercial applications

  Includes OneSeal for most common coatings

  Large selection of tip sizes available

  Easy to identify laser stamped tip size

  Solvent seal available when using extremely hot solvents

• Model: RAC 5
• Series: SwitchTip

• Compatible Material: Lacquer to Mastic, Latex Paint

• For Use With: RAC 5 HandTite Tip Guard

• Maximum Fan Width (cm): 50.8
• Maximum Fan Width (in): 18
• Maximum Fan Width (mm): 508

• Maximum Flow Rate (GPM): 1.31
• Maximum Flow Rate (L/min): 4.96

• Maximum Working Pressure (bar): 280
• Maximum Working Pressure (kPa): 28000
• Maximum Working Pressure (psi): 4050

• Minimum Fan Width (in): 18
• Minimum Fan Width (mm): 457

• Orifice Diameter (in): 0.035

• Pattern Size (in): 18 to 20
• Pattern Size (mm): 457.2 to 508

GG 287019

EXTENSION, TIP, 10"

Graco 287019 RAC X Tip Extension, 10 in

The 10 inch RAC X Tip Extension is ideal for hard-to-reach areas such as soffits, stairways, and vaulted ceilings. Includes RAC X HandTite Guard. Can be combined for extended reach up to 6 feet.

• Includes RAC X HandTite Guard standard with 7/8 inch gun nut and OneSeal
• Can be combined for extended reach up to 6 ft
• Ideal for hard-to-reach areas such as soffits, stairways, and vaulted ceilings
• Extend range and spray more efficiently without ladders or scaffolding
• Made from aluminum for a durable and lightweight design
• Extension lengths can be combined for extended reach up to 6 feet (1.82 meters)
• Includes RAC X HandTite Guard standard with 7/8 inch gun nut and OneSeal

• Model: RAC X
• Series: Tip Extension

• Compatible Spray Tip: RAC X

• For Use With: RAC X SwitchTips

• Includes: RAC X HandTite Guard Standard, 7/8 in Gun Nut, OneSeal

• Maximum Working Pressure (bar): 279
• Maximum Working Pressure (kPa): 27900
• Maximum Working Pressure (MPa): 27.9
• Maximum Working Pressure (psi): 4050

• Overall Length (cm): 25.4
• Overall Length (in): 10

GG 287095

KIT, ACCESSORY, FLEX, 3/8, LTX

Graco 287095 Flex Plus Airless Spray Gun, RAC X, BlueMax II Airless Hose, 1/4 in x 50 ft, 3 ft Whip Hose

Get up and spraying quickly with the ideal spray gun for applications using heavy coatings and joint compounds along with needed accessories. Keep a spare kit on hand to always be prepared for large projects where dual gun applications are required.

• Flex Plus Airless Spray Gun


  Ergonomic handle

  No adjustment needle

  Patented needle design

  Large fluid path

• RAC X LTX 517 SwitchTip


  Provides 10 inch spray pattern

  Ideal for larger surfaces such as houses/buildings, walls and ceilings

  100% tested for flow rate

• BlueMax II Airless Hoses


  The lightest, most flexible hoses on the market

  Easy to connect and maintain

  The highest level of performance from the sprayer to the gun

• Model: Silver Gun

• Kit Type: Spray Gun and Hose Kit

GG 287221

GG 287227

GG 287253

GG 287258

GG 287417

GG 287450

GG 287553

GG 287570
