Parts

GG 261732

GG 261733

GG 261734

GG 261735

GG 261865

GG 261886

GG 261890

GG 262004

LINEDRIVER MODULE, 160CC

Graco 262004 LineDriver Ride-On Attachment

Why walk when you can ride? Graco LineDriver Systems provide the most innovative, user-friendly ride-on systems in the industry. The LineDriver is the industry standard ride-on system that will help you maximize productivity on any striping, thermoplastic and scarifying application.

• FlexBeam LED Light System

  LED light for improved brightness with long life and less amp draw

  Retractable, breakaway design prevents damage and keeps you striping

• Patented Dual Foot Pedal System

  For forward and reverse

  Easily move between jobs without having to push

• ProStart Engine Starting System

  Easy Starting

  Up to 50% less pulling effort to start the engine - no more broken recoils

  Outperforms manual pull and electric start systems when the weather starts turning cooler

• Cool-Comfort Seat

  Gray color stays cool in direct sunlight

  High-back seat for added support

  Extra padding for all-day comfort

• Model: LineDriver

• Engine Brand: Honda
• Engine Model: GX Engine

• For Use With: GrindLazer, ThermoLazer 300TC, ThermoLazer ProMelt, LineLazer 130HS, LineLazer ES 1000, LineLazer V 200HS, LineLazer V 250DC, LineLazer V 250SPS, LineLazer V 3900, LineLazer V 5900
• Fuel Tank Capacity (gal): 0.95
• Fuel Tank Capacity (L): 3.6

• Maximum Operating Speed (km/h): 16
• Maximum Operating Speed (mph): 10

• Maximum Reverse Speed (km/h): 10
• Maximum Reverse Speed (mph): 6

• Power Rating (cc): 160
• Power Rating (HP): 5.5
• Power Rating (kW): 4.1

GG 262005

LINEDRIVER MODULE, HD 200CC

Graco 262005 LineDriver HD Ride-On Attachment

Why walk when you can ride? Graco LineDriver Systems provide the most innovative, user-friendly ride-on systems in the industry. The LineDriver HD provides the higher power and performance you need to maximize your productivity on any striping, thermoplastic and scarifying application.

• FlexBeam LED Light System

  LED light for improved brightness with long life and less amp draw

  Retractable, breakaway design prevents damage and keeps you striping

• Patented Dual Foot Pedal System

  For forward and reverse

  Easily move between jobs without having to push

• ProStart Engine Starting System

  Easy Starting

  Up to 50% less pulling effort to start the engine - no more broken recoils

  Outperforms manual pull and electric start systems when the weather starts turning cooler

• Cool-Comfort Seat

  Gray color stays cool in direct sunlight

  High-back seat for added support

  Extra padding for all-day comfort

• Model: LineDriver
• Series: HD

• Engine Brand: Honda
• Engine Model: GX Engine

• For Use With: LineLazer, GrindLazer, ThermoLazer
• Fuel Tank Capacity (gal): 0.95
• Fuel Tank Capacity (L): 3.6

• Maximum Operating Speed (km/h): 16
• Maximum Operating Speed (mph): 10

• Maximum Reverse Speed (km/h): 10
• Maximum Reverse Speed (mph): 6

• Power Rating (cc): 200
• Power Rating (HP): 6.5

GG 262120

GG 262371

GG 262374

GG 262375

GG 262416

GG 262478

GG 262783

GG 262806

GG 262828

GG 262936

GG 262940

GG 269215

CONTRACTOR FLAT TIP, SPRAY 215

Graco 269215 Contractor Flat Tip, 215

The 215 Contractor Flat Tip is designed for narrower surfaces. The 215 Flat Tip has a 0.015 inch orifice and produces a 4 to 6 inch fan.

• Model: Contractor
• Series: Flat Tip

• Compatible Material: Architectural Coating

• For Use With: Silver Plus Airless Spray Gun

• Maximum Fan Width (cm): 10
• Maximum Fan Width (in): 4
• Maximum Fan Width (mm): 152

• Maximum Flow Rate (GPM): 0.24
• Maximum Flow Rate (L/min): 0.91

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (psi): 5000

• Minimum Fan Width (in): 4
• Minimum Fan Width (mm): 102

• Orifice Diameter (in): 0.015

• Pattern Size (in): 4 to 6
• Pattern Size (mm): 101.6 to 152.4

GG 269315

CONTRACTOR FLAT TIP, SPRAY

Graco 269315 Contractor Flat Tip, 315

The 315 Contractor Flat Tip is designed for narrow surfaces. The 315 Flat Tip has a 0.015 inch orifice and produces a 6 to 8 inch fan.

• Model: Contractor
• Series: Flat Tip

• Compatible Material: Architectural Coating

• For Use With: Silver Plus Airless Spray Gun

• Maximum Fan Width (cm): 15
• Maximum Fan Width (in): 6
• Maximum Fan Width (mm): 203

• Maximum Flow Rate (GPM): 0.24
• Maximum Flow Rate (L/min): 0.91

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (psi): 5000

• Minimum Fan Width (in): 6
• Minimum Fan Width (mm): 152

• Orifice Diameter (in): 0.015

• Pattern Size (in): 6 to 8
• Pattern Size (mm): 152.4 to 203.2

GG 269325

CONTRACTOR FLAT TIP, SPRAY

Graco 269325 Contractor Flat Tip, 325

The 325 Contractor Flat Tip is designed for narrow surfaces and thicker materials. The 325 Flat Tip has a 0.025 inch orifice and produces a 6 to 8 inch fan.

• Model: Contractor
• Series: Flat Tip

• Compatible Material: Architectural Coating

• For Use With: Silver Plus Airless Spray Gun

• Maximum Fan Width (cm): 15
• Maximum Fan Width (in): 6
• Maximum Fan Width (mm): 203

• Maximum Flow Rate (GPM): 0.67
• Maximum Flow Rate (L/min): 2.54

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (psi): 5000

• Minimum Fan Width (in): 6
• Minimum Fan Width (mm): 152

• Orifice Diameter (in): 0.025

• Pattern Size (in): 6 to 8
• Pattern Size (mm): 152.4 to 203.2

GG 269327

CONTRACTOR FLAT TIP, SPRAY

Graco 269327 Contractor Flat Tip, 327

The 327 Contractor Flat Tip is designed for narrow surfaces and thicker materials. The 327 Flat Tip has a 0.027 inch orifice and produces a 6 to 8 inch fan.

• Model: Contractor
• Series: Flat Tip

• Compatible Material: Architectural Coating

• For Use With: Silver Plus Airless Spray Gun

• Maximum Fan Width (cm): 15
• Maximum Fan Width (in): 6
• Maximum Fan Width (mm): 203

• Maximum Flow Rate (GPM): 0.74
• Maximum Flow Rate (L/min): 2.80

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (psi): 5000

• Minimum Fan Width (in): 6
• Minimum Fan Width (mm): 152

• Orifice Diameter (in): 0.027

• Pattern Size (in): 6 to 8
• Pattern Size (mm): 152.4 to 203.2

GG 269415

CONTRACTOR FLAT TIP, SPRAY

Graco 269415 Contractor Flat Tip, 415

The 415 Contractor Flat Tip produces an 8 to 10 inch fan and has a 0.015 inch orifice.

• Model: Contractor
• Series: Flat Tip

• Compatible Material: Architectural Coating

• For Use With: Silver Plus Airless Spray Gun

• Maximum Fan Width (cm): 20
• Maximum Fan Width (in): 8
• Maximum Fan Width (mm): 254

• Maximum Flow Rate (GPM): 0.24
• Maximum Flow Rate (L/min): 0.91

• Maximum Working Pressure (bar): 345
• Maximum Working Pressure (kPa): 34500
• Maximum Working Pressure (psi): 5000

• Minimum Fan Width (in): 8
• Minimum Fan Width (mm): 203

• Orifice Diameter (in): 0.015

• Pattern Size (in): 8 to 10
• Pattern Size (mm): 203.2 to 254
