GG 96G138

G3 PRO PUMP, G-24PR-8L0000-00C00000

Graco 96G138 G3 Pro Grease Lubrication Pump, 24 VDC, 8 Liter, CPC

Extend machinery life, reduce operating costs and increase productivity with a Graco G3 today! The G3 Pro has a flexible design that works with series progressive systems. A cost-effective pump designed to serve multiple markets and applications. Includes one adjustable pump element - standard, plus room for two more. The ultimate in flexibility - for a high value, custom fit on your application.

• Built-in controller with selectable pump on/pump off timer
• Low level indicator provides low warning and shut-down alarm
• Manual run initiates lube cycle on-demand (remote option also available)
• Pre-lube function can initiate lube cycle on start-up

• Model: G3
• Series: Pro

• Alarm Relay Inductive Maximum Operating Current (A): 1.5
• Alarm Relay Inductive Maximum Operating Voltage (VDC): 220
• Alarm Relay Inductive Maximum Switching Capacity: 25 VA, 30 W
• Alarm Relay Inductive Minimum Permissible Load: 10 ?A, 10m VDC
• Alarm Relay Inductive Rated Load (A): 1
• Alarm Relay Resistive Maximum Operating Current (A): 3
• Alarm Relay Resistive Maximum Switching Capacity: 50 VA, 60 W
• Alarm Relay Resistive Rated Load (A): 2

• Application: On-Road Vehicles, Off-Road Equipment

• Compatible Material: Grease
• Compatible Metering Device: Series Progressive

• Control Options: Pro

• Fluid Outlet Size (in): 0.25
• Fluid Outlet Size (mm): 6.3500
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPSF

• For Use With: Injector-Based Systems, Series Progressive Systems

• Includes: Wiper Arm

• Input Cycle Rate (Hz): 8
• Input Impedance: 1.1
• Input Load Current (mA @ 24 VDC): 22
• Input Maximum Off Current (mA): 1.5
• Input Maximum Residual Voltage (V): 4
• Input Required Switch Type: Normally Open
• Input Response Time (ms): 60
• Input Sensor Voltage (VDC): 24

• IP Rating: IP69K

• Low Level Carry Current (A): 1.2
• Low Level Contact Rating (W): 10
• Low Level Switch Rating (VDC): 200
• Low Level Switching Current (A): 0.5

• Maximum Fill Inlet Pressure (bar): 344.7
• Maximum Fill Inlet Pressure (kPa): 34470
• Maximum Fill Inlet Pressure (psi): 5000

• Maximum NLGI Grade: #2

• Maximum Run Time (min): 30

• Maximum Voltage (V dc): 32

• Maximum Working Pressure (bar): 351.6
• Maximum Working Pressure (kPa): 35160
• Maximum Working Pressure (MPa): 35.1
• Maximum Working Pressure (psi): 5100

• Minimum Voltage (V dc): 18

• Number of Machine Count Sensor Inputs: 1
• Number of Pressure and Cycle Sensor Inputs: 3
• Number of Pump Elements: Up to 3

• Overall Depth (cm): 25.4
• Overall Depth (in): 10
• Overall Depth (mm): 254

• Overall Height (cm): 47
• Overall Height (in): 18.5
• Overall Height (mm): 470
• Overall Width (cm): 23.5
• Overall Width (in): 9.25
• Overall Width (mm): 235

• Power Connection Type: CPC

• Power Type: Electric

• Pump Output with 0 Spacers (cu in/min): 0.25
• Pump Output with 1 Sp

GG 96G552

G3 MAX PUMP, G-24M2-8L0L00-NMCO000VP

Graco 96G552 G3 Max Full-Featured Grease Lubrication Pump, 24 VDC, 8 liter reservoir with low level paddle, CPC-7 I/O connector for power, remote button, and alarms for telematics, M12 connectors for vent valve, one pressure sensor (analog or digital), machine count and one cycle switch

Extend machinery life, reduce operating costs and increase productivity! The G3 Max has a flexible design that works with injector-based or series progressive systems. The ultimate in flexibility - for a high value, custom fit on your application.

• LCD screen provides detailed view of pump status and operation. Alarm screens include troubleshooting tips and a QR code links to the G3 Education Center for Training-on-Demand. Bright LEDs with nearly 180 degree viewing angle allow users to confirm pump status from a distance.
• Low level indicator provides low alert and shut-down alarm
• Manual run initiates lubrication on-demand (remote option also available)
• Pre-lube function can initiate lube cycle on start-up
• One pump works with either a cycle switch or pressure sensor for custom installations and feedback. Cycle input is compatible with PNP, NPN, and dry contact switches, Pressure input is compatible with analog transducers/sensors and normally open switches.
• Machine count input - ideally suited for inconsistently used equipment
• The new CPC-7 untilizes the same Circular Plastic Connector (CPC) as other G3 pump, now with all seven pins populated with input and output functions. Connections for tri-color remote manual run and LED push-button in CPC, (similar to CPC-5 on the EGJ and G-Mini Controller pumps) Two alarm output signal wires: one for low level and one for system alarmAccess to I/O features are dependent on selection of external wiring harness (power cord)
• Compatible with Normally Open Vent Valves - simplifies pump programming, with the added benefit of venting whenever the pump is not running.

• Model: G3
• Series: Max

• Compatible Material: Grease
• Compatible Metering Device: Series Progressive, Single Line Parallel

• Display Type: LCD

• Fluid Outlet Thread Type: NPSF

• For Use With: Injector-Based Systems, Series Progressive Systems

• Includes: Wiper Arm, Low Level Paddle, CPC-7 I/O connector for power, remote button, and alarms for telematics, M12 connectors for vent valve, one pressure sensor (analog or digital), machine count and one cycle switch

• Maximum Flow Rate (ci/min): 0.25

• Maximum NLGI Grade: #2

• Maximum Operating Temperature ( degree C): 70
• Maximum Operating Temperature ( degree F): 158

• Maximum Voltage (V dc): 30

• Maximum Working Pressure (bar): 351.6
• Maximum Working Pressure (psi): 5100

• Minimum Voltage (V dc): 18

• Number of Pump Elements: Up to 3

• Power Type: Electric

GG 96G554

PUMP, G3-G-ACM2-8L0L00-RMCD0A0VP

Graco 96G554 G3 Max Full-Featured Grease Lubrication Pump, 90-240 VAC, 8 liter reservoir with low level paddle, DIN Form-A connectors for power input and alarm relay output, M12 connectors for vent valve, one pressure sensor (analog or digital), machine count and one cycle switch

Extend machinery life, reduce operating costs and increase productivity! The G3 Max has a flexible design that works with injector-based or series progressive systems. The ultimate in flexibility - for a high value, custom fit on your application.

• LCD screen provides detailed view of pump status and operation. Alarm screens include troubleshooting tips and a QR code links to the G3 Education Center for Training-on-Demand. Bright LEDs with nearly 180 degree viewing angle allow users to confirm pump status from a distance.
• Low level indicator provides low alert and shut-down alarm
• Manual run initiates lubrication on-demand (remote option also available)
• Pre-lube function can initiate lube cycle on start-up
• One pump works with either a cycle switch or pressure sensor for custom installations and feedback. Cycle input is compatible with PNP, NPN, and dry contact switches, Pressure input is compatible with analog transducers/sensors and normally open switches.
• Machine count input - ideally suited for inconsistently used equipment
• DIN alarm relay connection can connect to a stack light to indicate pump status from a distance.
• Compatible with Normally Open Vent Valves - simplifies pump programming, with the added benefit of venting whenever the pump is not running.

• Model: G3
• Series: Max

• Compatible Material: Grease
• Compatible Metering Device: Series Progressive, Single Line Parallel

• Display Type: LCD

• Fluid Outlet Thread Type: NPSF

• For Use With: Injector-Based Systems, Series Progressive Systems

• Includes: Wiper Arm, Low Level Paddle, DIN Form-A connectors for power input and alarm relay output, M12 connectors for vent valve, one pressure sensor (analog or digital), machine count and one cycle switch

• Maximum Flow Rate (ci/min): 0.25

• Maximum NLGI Grade: #2

• Maximum Operating Temperature ( degree C): 70
• Maximum Operating Temperature ( degree F): 158

• Maximum Voltage (V ac): 264

• Maximum Working Pressure (bar): 351.6
• Maximum Working Pressure (psi): 5100

• Minimum Voltage (V ac): 88

• Number of Pump Elements: Up to 3

• Phase: 1

• Power Type: Electric

GG 96G560

G3 MAX PUMP, G-24M2-160L00-NMCO000VP

Graco 96G560 G3 Max Full-Featured Grease Lubrication Pump, 24 VDC, 16 liter reservoir with low level paddle, CPC-7 I/O connector for power, remote button, and alarms for telematics, M12 connectors for vent valve, one pressure sensor (analog or digital), machine count and one cycle switch

Extend machinery life, reduce operating costs and increase productivity! The G3 Max has a flexible design that works with injector-based or series progressive systems. The ultimate in flexibility - for a high value, custom fit on your application.

• LCD screen provides detailed view of pump status and operation. Alarm screens include troubleshooting tips and a QR code links to the G3 Education Center for Training-on-Demand. Bright LEDs with nearly 180 degree viewing angle allow users to confirm pump status from a distance.
• Low level indicator provides low alert and shut-down alarm
• Manual run initiates lubrication on-demand (remote option also available)
• Pre-lube function can initiate lube cycle on start-up
• One pump works with either a cycle switch or pressure sensor for custom installations and feedback. Cycle input is compatible with PNP, NPN, and dry contact switches, Pressure input is compatible with analog transducers/sensors and normally open switches.
• Machine count input - ideally suited for inconsistently used equipment
• The new CPC-7 untilizes the same Circular Plastic Connector (CPC) as other G3 pump, now with all seven pins populated with input and output functions.: Connections for tri-color remote manual run and LED push-button in CPC, (similar to CPC-5 on the EGJ and G-Mini Controller pumps) Two alarm output signal wires: one for low level and one for system alarmAccess to I/O features are dependent on selection of external wiring harness (power cord)
• Compatible with Normally Open Vent Valves - simplifies pump programming, with the added benefit of venting whenever the pump is not running.

• Model: G3
• Series: Max

• Compatible Material: Grease
• Compatible Metering Device: Series Progressive, Single Line Parallel

• Display Type: LCD

• Fluid Outlet Thread Type: NPSF

• For Use With: Injector-Based Systems, Series Progressive Systems

• Includes: Wiper Arm, Low Level Paddle, CPC-7 I/O connector for power, remote button, and alarms for telematics, M12 connectors for vent valve, one pressure sensor (analog or digital), machine count and one cycle switch

• Maximum Flow Rate (ci/min): 0.25

• Maximum NLGI Grade: #2

• Maximum Operating Temperature ( degree C): 70
• Maximum Operating Temperature ( degree F): 158

• Maximum Voltage (V dc): 30

• Maximum Working Pressure (bar): 351.6
• Maximum Working Pressure (psi): 5100

• Minimum Voltage (V dc): 18

• Number of Pump Elements: Up to 3

• Power Type: Electric

GG 96G562

PUMP, G3-G-ACM2-160L00-RMCD0A0VP

Graco 96G562 G3 Max Full-Featured Grease Lubrication Pump, 90-240 VAC, 16 liter reservoir with low level paddle, DIN Form-A connectors for power input and alarm relay output, M12 connectors for vent valve, one pressure sensor (analog or digital), machine count and one cycle switch

Extend machinery life, reduce operating costs and increase productivity! The G3 Max has a flexible design that works with injector-based or series progressive systems. The ultimate in flexibility - for a high value, custom fit on your application.

• LCD screen provides detailed view of pump status and operation. Alarm screens include troubleshooting tips and a QR code links to the G3 Education Center for Training-on-Demand. Bright LEDs with nearly 180 degree viewing angle allow users to confirm pump status from a distance.
• Low level indicator provides low alert and shut-down alarm
• Manual run initiates lubrication on-demand (remote option also available)
• Pre-lube function can initiate lube cycle on start-up
• One pump works with either a cycle switch or pressure sensor for custom installations and feedback. Cycle input is compatible with PNP, NPN, and dry contact switches, Pressure input is compatible with analog transducers/sensors and normally open switches.
• Machine count input - ideally suited for inconsistently used equipment
• DIN alarm relay connection can connect to a stack light to indicate pump status from a distance.
• Compatible with Normally Open Vent Valves - simplifies pump programming, with the added benefit of venting whenever the pump is not running.

• Model: G3
• Series: Max

• Compatible Material: Grease
• Compatible Metering Device: Series Progressive, Single Line Parallel

• Display Type: LCD

• Fluid Outlet Thread Type: NPSF

• For Use With: Injector-Based Systems, Series Progressive Systems

• Includes: Wiper Arm, Low Level Paddle, DIN Form-A connectors for power input and alarm relay output, M12 connectors for vent valve, one pressure sensor (analog or digital), machine count and one cycle switch

• Maximum Flow Rate (ci/min): 0.25

• Maximum NLGI Grade: #2

• Maximum Operating Temperature ( degree C): 70
• Maximum Operating Temperature ( degree F): 158

• Maximum Voltage (V ac): 264

• Maximum Working Pressure (bar): 351.6
• Maximum Working Pressure (psi): 5100

• Minimum Voltage (V ac): 88

• Number of Pump Elements: Up to 3

• Phase: 1

• Power Type: Electric

GG LM7214

LUBEMASTER PUMP

Graco LM7214 Lube Master Electric Pump, 12 lb. (5.44 kg) Metal Grease Reservoir with Clutch Drive and Low-Level Switch

The Lube Master is a rugged pump package designed for demanding applications. The adjustable output and anti-friction drive bearings make it both reliable and efficient. Rugged cast iron main body and heavy-duty internal components deliver consistent performance in harsh applications.

• Adjustable output
• Broad output range
• Simplified construction
• Soft-seat outlet check valve
• Modular components
• Driven by an electric motor (gear drive)

• Model: Lube Master

• Application: In-Plant Machinery

• Compatible Material: Grease
• Compatible Metering Device: Series Progressive

• Fluid Outlet Size (in): 0.25
• Fluid Outlet Size (mm): 6.3500
• Fluid Outlet Thread Type: NPSF

• Material: Metal

• Maximum Cycle Rate (strokes/min): 175

• Maximum Flow Rate (ci/min): 8.62

• Maximum Fluid Output Pressure (bar): 345
• Maximum Fluid Output Pressure (psi): 5000

• Maximum Fluid Output Pressure (bar): 345
• Maximum Fluid Output Pressure (psi): 5000

• Maximum NLGI Grade: #2

• Maximum Working Pressure (bar): 340
• Maximum Working Pressure (kPa): 34000
• Maximum Working Pressure (MPa): 34
• Maximum Working Pressure (psi): 5000

• Minimum Cycle Rate (strokes/min): 1
• Minimum Flow Rate (ci/min): 0.01

• Overall Depth (cm): 26
• Overall Depth (in): 10.25
• Overall Depth (mm): 260

• Overall Height (cm): 49.7
• Overall Height (in): 19.56
• Overall Height (mm): 497
• Overall Width (cm): 19.8
• Overall Width (in): 7.812
• Overall Width (mm): 198

• Power Type: Electric
